Samsung LE32C530F1W User manual

English -4
¦Connecting a AV device
W
R
Y
WR
Y
WR
W
R R GB
WR
RG B
HD connection
DVD, Blu-ray player,
HD cable box, HD
STB (Set-Top-Box)
satellite receiver, cable
box, satellite receiver
(STB)
Using an HDMI Cable
HDMI OUT
Device
Using a Scart Cable
EXT
HD connection
Component connection
DVD / Blu-ray player
Using an HDMI to DVI Cable
DVI OUT
AUDIO OUT
VCR, DVD, Blu-
ray player, cable
box, STB satellite
receiver
Using a Component Cable
AUDIO OUTCOMPONENT OUT
Device
AUDIO OUTVIDEO OUT
Using an Audio/Video Cable
Device
[QSG]BN68-02687A-00Eng.indd 1 2010-03-05 오전 1:21:52

¦The Supplied Accessories
yRemote Control & Batteries (AAA x 2)
yOwner’s Instructions
yCleaning Cloth
yBlanking Bracket
See separate guide for installing the stand.
M4 X L12
yStand (1EA) yGuide Stand (1EA)
yScrews (8EA)
(LE32C530: 7EA)
LCD TV
QUICK SETUP GUIDE
English - 1
BN68-02687A-00
or
[QSG]BN68-02687A-00Eng.indd 2 2010-03-05 오전 1:21:53

¦Installing the Stand
✎ Preset: Place the Guide Stand and Cover Neck onto the stand and fasten it using the screws. Applicable to models
(Depending on the model)
Step 1. Attach your LCD TV to the stand.
✎ Two or more people should carry the TV.
✎ Make sure to distinguish between the front and back of the stand when assembling them.
✎ To make sure the TV is installed on the stand at a proper level, do not apply excess downward pressure to the upper
left of right sides of the TV.
Step 2. Fasten two screws at position 1 and then fasten two screw at position 2.
✎ Stand the product up and fasten the screws. If you fasten the screws with the LCD TV placed down, it may lean to
one side.
¦Using the remote control buttons
¦Installing Batteries in the Remote Control
✎
NOTE
x
Use the remote control within 23 feet from the TV.
x
Bright light may affect the performance of the remote control. Avoid
using nearby special fluorescent light or neon signs.
x
The colour and shape may vary depending on the model.
English - 2
RETURN Button
Return to the previous menu.
ENTER
E / DIRECTION Buttons
Move the cursor and select an
item. Select the currently selected
item. Confirm the setting.
EXIT
Exit the on-screen menu.
MENU Button
Display the main on-screen menu.
C
H LIS
T
MUTE
PO
WER
SOU
R
CE
P
RE-CH
G
UID
E
MEDIA
.
P
MENU
TOO
L
S
RETURN
P
.MODE
AD
P
.
S
IZ
E
SU
BT.
S.MOD
E
DUA
L
I
-
II
EXIT
INF
O
TTX
/
MI
X
A
B
C
D
HDMI
3
4
1
2
s
s
ss
s
Preset Step 1 Step 2
ss
s
s
s
Rear
Front
ss
s
s
s
Top View
[QSG]BN68-02687A-00Eng.indd 3 2010-03-05 오전 1:21:54

English - 3
¦Plug & Play
When the TV is initially powered on, basic settings proceed automatically and subsequently.
If you want to reset this feature, press the MENU button to display menu.
You can set the Plug & Play by selecting ‘Setup →Plug & Play’.
On the screen, you can set as follows.
✎ The each step may vary depending on the Antenna source.
ANT OUT
1
1
VHF/UHF Antenna
or
Cable
Power Input
Step 1 Step 2 Step 3
Step 4 Step 5 Step 6
Step 7 Step 8
Plug & Play
Select the OSD Language.
Menu Language : : English
▲
Nederlands
English
Eesti
▼
U Move E Enter
Plug & Play
Select Country.
Country :
▲
Turkey
United Kingdom
Estonia
▼
U Move E Enter
Plug & Play
Enjoy your TV.
OK
Plug & Play
Select the usage mode.
Store Demo Home Use
Previous U Move E Enter
Plug & Play
Antenna Source : Air ►
Channel Source : Digital & Analogue
Previous Skip U Move E Enter
Serch
Plug & Play
Auto Store in progress.
Channels : 7
15%
Digital 2
TV:2 Radio:0 Data/Other: 0
Analogue 0
E Enter
Stop
Plug & Play
Set the Clock Mode.
Clock Mode : Manual ►
U Move E Enter
Auto
Manual
Plug & Play
How to get the best perfotmance from your new HDTV
1/2
Step 1. Connect the HD Box to the using HDMI or Component
cables.
TV rear view ►
HDMI Cable
HDMI Cable
Previous Skip ► Next
[QSG]BN68-02687A-00Eng.indd 4 2010-03-05 오전 1:21:55
