Samsung LTM1555X User manual

LTM1555
LTM1755
(For NTSC systems)
TFT-LCD TV/Monitor
User’s
Manual
1E_cov.fm Page 1 Saturday, January 12, 2002 11:01 AM

1. Adjust computer resolution and screen injection rate (refresh rate) in the control panel of
your computer as described below to enjoy the picture quality.
• Resolution: 15” 1024 x 768 • Vertical frequency (refresh rate): 60 Hz
17” 1280 x 1024
2. This TFT LCD panel was manufactured by using advanced precision semiconductor technology.
Still, different color pixels may be seen. This is normal and not a defect.
• For example, the number of TFT LCD pixels that is contained in this product are
2,359,296 (15”), 3,932,160 (17”).
3. When you clean the outside of the monitor and panel, use a soft cloth with a small amount
of cleaner. Do not use excessive force as it can cause stains.
4. If you are not satisfied with the picture quality,
execute the "auto adjustment function" in the display screen that appearswhen window
termination button is pressed. If there's still picture noise after performing automatic adjustment, use FINE/
COARSE adjustment function.
ManufacturedunderlicensefromDolbyLaboratories“Dolby”,andthe aretrademarksofDolby
Laboratories.
Information in this document is subject to change without notice.
© 2001 Samsung Electronics Co., Ltd. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co.,
Ltd. is strictly forbidden.
Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use of this material.
The Samsunglogo istheregisteredtrademarkofSamsung Electronics Co.,Ltd.; Microsoft,Windows
®
and Windows
®
NT are registered trademarks of Microsoft Corporation; VESA, DPMS and DDC are
registered trademarks of Video Electronics Standard Association; the E
NERGY
S
TAR
name and logo are
registered trademarks of the U.S. Environmental Protection Agency (EPA). As an E
NERGY
S
TAR
Partner,
Samsung Electronics Co., Ltd. has determined that this product meets the E
NERGY
S
TAR
guidelines for
energy efficiency. All other product names mentioned herein may be the trademarks or registered
trademarks of their respective owners.
For Better Display
1E_cov.fm Page 2 Saturday, January 12, 2002 11:01 AM

English 1
FrançaisDeutschEspañolPortu-
English
Italiano
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Unpacking Your TV/Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Setting up Your LCD TV/Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Setting up an Ergonomic Workstation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
TV/Monitor Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Workstation Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Viewing Angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connecting Your LCD TV/Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Plug and Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Installing the Video Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Self-Test Feature Check (STFC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Warm-up Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Adjusting Your LCD TV/Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
User Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Automatic Save . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Direct-Access Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
On Screen Display (OSD) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Accessing the Menu System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
PC Functions and Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
TV/Video Functions and Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
DTV/DVD Functions and Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
OSD Functions and Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
V -Chip . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Remote-Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
PowerSaver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Display Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Attaching a Wall or Arm Mounting Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Installing VESA Compliant Mounting Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Wall Mount Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Retractable Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Maintenance of Your LCD TV/Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Regulatory Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Inside back cover
Customer Service / Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back cover
Table of Contents
2E_toc.fm Page 1 Saturday, January 12, 2002 11:01 AM

English 2
1
Before connecting the AC power cord to the DC adapter outlet, make sure the voltage
designation of the DC adapter corresponds to the local electrical supply.
2
Never insert anything metallic into the cabinet openings of the liquid crystal display (LCD)
TV/Monitor; doing so may create the danger of electric shock.
3
To avoid electric shock, never touch the inside of the LCD TV/Monitor. Only a qualified
technician should open the case of the LCD TV/Monitor.
4
Never use your LCD TV/Monitor if the power cord has been damaged. Do not allow
anything to rest on the power cord, and keep the cord away from areas where people can
trip over it.
5
Be sure to hold the plug, not the cord, when disconnecting the LCD TV/Monitor from an
electric socket.
6
Openings in the LCD TV/Monitor cabinet are provided for ventilation. To prevent
overheating, these openings should not be blocked or covered. Also, avoid using the LCD
TV/Monitor on a bed, sofa, rug, or other soft surface. Doing so may block the ventilation
openings in the bottom of the cabinet. If you put the LCD TV/Monitor in a bookcase or
some other enclosed space, be sure to provide adequate ventilation.
7
Put your LCD TV/Monitor in a location with low humidity and a minimum of dust.
8
DonotexposetheLCDTV/Monitortorainoruseitnearwater(inkitchens,nearswimming
pools, etc.). If the LCD TV/Monitor accidentally gets wet, unplug it and contact an
authorizeddealerimmediately.Youcan cleanthe LCDTV/Monitor withadamp clothwhen
necessary, but be sure to unplug the LCD TV/Monitor first.
9
Place the LCD TV/Monitor on a solid surface and treat it carefully. The screen is made of
thinglass with a plastic front surface and canbe damaged if dropped, hit or scratched. Do
not clean the front panel with keton-type materials (e.g., acetone), ethyl alcohol, toluene,
ethyl acid, methyl, or chloride – these may damage the panel.
10
Locate your LCD TV/Monitor near an easily accessible AC outlet.
11
If your LCD TV/Monitor does not operate normally – in particular, if there are any unusual
sounds or smells coming from it – unplug it immediately and contact an authorized dealer
or service center.
12
High temperature can cause problems. Don’t use your LCD TV/Monitor in direct sunlight,
and keep it away from heaters, stoves, fireplaces, and other sources of heat.
13
Unplug the LCD TV/Monitor when it is going to be left unused for an extended period of
time.
14
Unplug your LCD TV/Monitor from the AC outlet before any service.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER
(OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Safety Instructions
3E_saf.fm Page 2 Saturday, January 12, 2002 11:00 AM

English 3
Please make sure the following items are included with your TV/Monitor. If any items are
missing, contact your dealer.
Manual
Warranty Card
(Not available in all locations)
Installation CD
(Not available in all locations)
DC Adapter
Power Cord
TV/Monitor
15-pin D-Sub Signal Cable
Remote Control
Batteries
(AAA x 2)
Unpacking Your TV/Monitor
4E_body3p.fm Page 3 Saturday, January 12, 2002 11:08 AM

English 4
Setting up an Ergonomic Workstation
Consider the advice given below before you install your TV/Monitor.
TV/Monitor location
ChooseapositionthatexposesyourTV/Monitortotheleastreflectionfromlightsorwindows,
usually at a right angle to any window.
Workstation height
Placeyour LCD TV/Monitor sothat the topof the screenis slightly below youreye level when
you are comfortably seated.
Viewing angle
Tilt the screen until you feel comfortable working with your TV/Monitor.
Figure 1. Tilt the screen
Setting up Your LCD TV/Monitor
4E_body3p.fm Page 4 Saturday, January 12, 2002 11:08 AM

English 5
Setting up Your LCD TV/Monitor
Connecting Your LCD TV/Monitor
Figure 2. Cable connections
1. Connecting aComputer ( )
A. Connect the power cord to the DC Adaptor and connect the adaptor jack to the DC 14V
power connector on the back of the TV/Monitor.
B. Connect the 15-pin D-SUB of the video signal cable to the PC video connector on the
back of the TV/Monitor.
C. Connect the stereo audio cable to “Audio (ST)” on the back of the TV/Monitor and the
other end to “ Audio Out” terminal of the sound card on your computer.
D. If necessary, install TV/Monitor driver contained on the supplied CD. For
driver installation, please refer “Installing Video Driver” section on page 6.
2. Connecting External A/V Devices ( )
A. Connect RCA audio cables to “Audio (R)”and “Audio (L)”terminals and the other ends
to corresponding audio out terminals on the A/V device.
(Stereo-RCA Cable not included)
B. Connect RCA (Yellow) or S-VHS cable to an appropriate external A/V device such as a
VCR, DVD or camcorder. (RCA cable and S-VHS cable not included)
C. Headphones may be connected to the headphone output on the right-hand side of the
TV/Monitor( ). Whilethe headphones are connected, the sound from the built-
in speakers will be disabled.
3. Connecting aDTV Set-Top Box ( ) - Component 2
A. Connect the YPbPr DTV Cable to the YPbPr Component 2(DTV) jacks on the
TV/Monitor.
B. Connect the RCA Cable to “Audio (L)”and “Audio (R)”Component 2(DTV) Audio jacks on the back of the TV/Monitor
and the other end to “Audio out”terminal of the Set-Top Box.
4. Connecting TV/CATV ( )
A. Connect an antenna or CATV Cable to the antenna terminal on the back of the
TV/Monitor.
5. Connecting aDVD ( ) - Component 1
A. Connect YPbPr and Audio R/L Cables from the DVD Player to the Component 1(DVD) jacks on the back of the
TV/Monitor.
V
I
D
E
O
S
-
V
I
D
E
O
COMPONENT1 DVD
Y
Pr
Pb
DC
POWER VIDEO AUDIO(ST)
Y Pb Pr RF
AUDIO(L) AUDIO(R)
COMPONENT2 DTV
PC
DTV Settop Box
Y
123
4
5
6
8
9
7
10
11 12 13
4E_body3p.fm Page 5 Saturday, January 12, 2002 11:08 AM

English 6
Setting up Your LCD TV/Monitor
Plug and Play
The adoption of the new VESA
®
Plug and Play solution eliminates complicated and time
consuming setup. It allows you to install your TV/Monitor in a Plug and Play compatible
system without the usual hassles and confusion. Your PC system can easily identify and
configure itself for use with your display. This TV/Monitor automatically tells the PC system
itsExtendedDisplayIdentificationData(EDID)usingDisplayDataChannel(DDC)protocols.Thisway
the PC system can automatically configure itself to use the LCD. If your PC system needs a
video driver, follow the instructions given below according to the operating system your
computer uses.
Installing the Video Driver
The CD that accompanies this product contains the necessary drivers for installing your
TV/Monitor.Please refer tothe driver installation instructions includedwith your CDpackage
for more information.
Self-Test Feature Check (STFC)
YourTV/Monitorprovidesaself-testfeaturethatallowsyoutocheckwhetheryourTV/Monitoris
functioning properly. Make sure that PC is selected as a primary source by checking if the source
indicatorLED labeled “PC”ison. If your TV/Monitor andcomputerareproperlyconnectedbutthe
TV/Monitorscreenremains dark and thepowerindicator is blinking, runtheTV/Monitorself-test
byfollowingthe steps given below:
Figure 3. Power Indicator
1
Turn off both your computer and the TV/Monitor.
2
Unplug the video cable from the back of the computer.
3
Turn on the TV/Monitor.
Power Indicator
4E_body3p.fm Page 6 Saturday, January 12, 2002 11:08 AM

English 7
Setting up Your LCD TV/Monitor
If the TV/Monitor is functioning properly, you will see a white box with a large blue oval
Samsung logo and an error message “Check Signal Cable.”in red color.
Figure 4. TV/Monitor self-test screen
This box also appears during normal operation if the video cable becomes disconnected or
damaged.
4
Turnoff your TV/Monitor and reconnectthe video cable; then turnon both your computer
and the TV/Monitor.
If your TV/Monitor screen remains blank after following the previous procedure, check your
video controller and computer system; your TV/Monitor is functioning properly.
Getting Help
If your TV/Monitor does not display an image, check your cable connections and refer to
"Troubleshooting" on page 28. If you experience difficulties with the quality of the displayed
image, push Auto Button (see page 9) and refer to "Adjusting Your LCD TV/Monitor" on page
8 or "Troubleshooting" on page 28.
Warm-up Time
All LCD TV/Monitors need time to become thermally stable whenever you turn them
on. Therefore, to
achieve more accurate adjustments for parameters, allow the LCD TV/Monitor to warm
(be on) for at least 20 minutes before making any screen adjustments.
Check Signal Cable
4E_body3p.fm Page 7 Saturday, January 12, 2002 11:08 AM

English 8
Adjusting Your LCD TV/Monitor
User Controls
Your LCD TV/Monitor allows you to easily adjust the characteristics of the image being
displayed. All of these adjustments are made using the control buttons on the top of the
TV/Monitor. While you use these buttons to adjust the controls, an OSD shows you their
numeric values as they change.
Figure 5. User control locations
No. Name Description
1 PC
■
Selects PC source.
■
PIP window off.
2 PIP
■
ActivatesPIP(Picture-in-Picture) window directly in
PC mode only.
■
Selects video sources in PIP.
(TV/DTV/DVD/VIDEO/S-VIDEO)
3TV/VIDEO
■ Activates full screen TV/Video window.
■
Selects TV/Video sources.
(TV/DTV/DVD/VIDEO/S-VIDEO)
4 MUTE
■
Selects sound mute.
5 MENU
■
Opens the OSD and selects the highlighted
function.
6
CH
■
Moves the selector up or down on the OSD.
■
Increases or decreases the channel number.
4E_body3p.fm Page 8 Saturday, January 12, 2002 11:08 AM

English 9
Adjusting Your LCD TV/Monitor
Automatic Save
Whenever you open the OSD and allow an adjustment window to remain active for about 3
seconds without pressing other buttons, the TV/Monitor automatically saves any adjustment
you have made. These changes are saved into a user area in the TV/Monitor.
The TV/Monitor can save adjustments for up to 5 user modes. It has 9 for LTM1555 (11 for
LTM1755)factorypreset or preload modes,onefor each signalfrequencyas listed in table10
on page 34.
If you have made no adjustments, the OSD disappears and the TV/Monitor does not save
anything.
7
VOL
■
Moves the selector left or right on the OSD.
■
Increases or decreases the values of the selected
function.
■
Increases or decreases the audio volume.
8EXIT
■
Exits from menus and sub-menus.
■
Exits from the OSD system.
9AUTO
■
“Auto”allowsthe TV/Monitor to self-adjust to the
incoming video signal. The values of fine, coarse
and position are adjusted automatically.
10 POWER
■
Turns the TV/Monitor ON/OFF.
■
Indicates the status of the TV/Monitor.
- Green: Normal operation.
- Green, Blinking: Power saving Mode or
Disconnected Signal Cable
No. Name Description
4E_body3p.fm Page 9 Saturday, January 12, 2002 11:08 AM

English 10
Adjusting Your LCD TV/Monitor
Direct-Access Features
While you are watching full screen TV or in PIP mode
Initial OSD icons
➮
CertainOSDmenusaredisabled(gray color) when they arenotavailableinacertainmode
of operation. Those menus are enabled when corresponding OSD menus are activated.
Program
Validonly after performing "Channel searchprogram".(Seepage17)
When OSD is not on the screen, push the" " or
" "buttonto select program channelnumber.
1
Pushthe" " buttontodecrease channel
number .
2
Push the " " button to increase the
channel number.
Volume
When OSDisnotonthe screen,pushthe" "or
" " button to adjust volume.
1
Push the " " button to decrease the
volume.
2
Push the " " button to increase the
volume.
CH
20
4E_body3p.fm Page 10 Saturday, January 12, 2002 11:08 AM

English 11
Adjusting Your LCD TV/Monitor
On Screen Display (OSD)
Accessing the menu system
1
With the OSD off, push the MENU button to display the main OSD menu.
2
Use the " " buttons to move from one function to another. Press MENU
toaccessthefunctionsub-menu.
See Table 1 starting on the next page to view a
complete list of all of the functions available for the TV/Monitor.
3
4
Use " " and " " to select desired item.
5
After selecting item, use the " " and " " buttons to make necessary
adjustments.Thesettingbarmovesandthenumericvalueindicatorchangestorefect
your adjustments.
6
Push the EXIT button a couple of times to return to the main menu to select another
function or to exit from the OSD.
4E_body3p.fm Page 11 Saturday, January 12, 2002 11:08 AM

English 12
Adjusting Your LCD TV/Monitor
PC functions and adjustments
Table 1. Screen controls
Main
Menu Icon Menus and
Sub-menus Function Descriptions
Contrast
Brightness
Color
Control
The tone of color can be changed from redish
white to bluish white. The individual color
components are also user customizable.
■
Mode1 Reddish white.
■ Mode2 Plain white.
■
Mode3 Bluish white.
■
User Mode
User customizable.
■
Reset Color parameters are replaced with the factory
default values.
-+
Contrast
Press MENU Key
Function icons
Function name
Setting bar
Tool Tip
Main menu
5E_body12p.fm Page 12 Saturday, January 12, 2002 11:07 AM

English 13
Adjusting Your LCD TV/Monitor
Image • Image Lock
• Image Size
• Image Effect
ImageLock Image Lock is used to fine tune the
image by removing picture jitter.
■
Coarse
■ Fine The Coarse and Fine adjustments allow you to finetune the image quality of your TV/Monitor to
your preference.
Use the " " and " " buttons to remove any
noise.
If satisfactory results are not obtained using the
Fine adjustment, use the Coarse adjustment and
then use Fine again.
Thisfunctionmaychangethe widthoftheimage.
Use the H-Position menu to center the image on
the screen.
When Coarse valueis
wrong.
When Fine valueis
wrong.
■
Information Displayscurrent display mode.
■
Reset Image lock and position parameters are replaced
with the factory default values.
Table 1. Screen controls (Continued)
Main
Menu Icon Menus and
Sub-menus Function Descriptions
5E_body12p.fm Page 13 Saturday, January 12, 2002 11:07 AM

English 14
Adjusting Your LCD TV/Monitor
Image Size The size of the image being displayed can be
set in several different ways.
■
Expand1 Resizetheimage to fill thewholescreen.
(applicable to PC RGB only)
■
Expand2 Expand images keeping the original aspect ratio.
(applicable to PC RGB only)
■
Normal Displaytheincoming image as itis.
(applicable to PC RGB only)
■
Zoom Theimage can bemagnifiedupto64times larger
than the original image. The enlarged image can
also be panned.
■
Pan Move the zoomed image horizontally and
vertically.
Effect
Image being displayed can be made softer or
sharper.
• Sharpen More
• Sharpen
• Medium
• Soften
• Soften More
Table 1. Screen controls (Continued)
Main
Menu Icon Menus and
Sub-menus Function Descriptions
5E_body12p.fm Page 14 Saturday, January 12, 2002 11:07 AM

English 15
Adjusting Your LCD TV/Monitor
H-position
V-position
Sound The TV/Monitor has a built-in high fidelity stereo
audioamplifier.Theaudiocircuit processesaudio
signalsfrom various external input sources such
as DVD, VCR, TV, PC or DTV.
■
Bass Emphasizeslow frequency audio.
■
Treble Emphasizeshigh frequency audio.
■ Virtual
Dolby
(Surround)
On, Off
PIP
(Picture-
in-Picture)
When external A/V devices such as VCR,
Component1 (DVD), Component2 (DTV) or RF(TV)
cable are connected to the TV/Monitor, PIP
allowsyou towatch videofrom such devices in a
small window super-imposed on the PC video signal.
NOTE: Applicated to PIP mode in activity.
■
Size ResizesPIP window.
■
Position ChangesPIP window position.
Table 1. Screen controls (Continued)
Main
Menu Icon Menus and
Sub-menus Function Descriptions
5E_body12p.fm Page 15 Saturday, January 12, 2002 11:07 AM

English 16
Adjusting Your LCD TV/Monitor
TV/Video functions and adjustments
Table 2. Screen controls
Main
Menu Icon Menus and Sub-menus Function Descriptions
Picture This function is active if you select an input source
other than PC.
(TV/DTV/DVD/VIDEO/S-VIDEO)
■
Mode Displays available picture modes.
(Standard, Natural, Mild, Custom)
■
Contrast Adjuststhe contrast of video or TV without
affecting PC RGB’s contrast.
(Applicable to Custom mode only)
■
Brightness Adjuststhe brightness of video or TV without
affecting PC RGB’s brightness.
(Applicable to Custom mode only)
■
Sharpness Adjuststhe sharpness of video or TV image.
(Applicable to Custom mode only)
■
Color Changesthe richness of color.
(Applicable to Custom mode only)
■
Tint Changesthe tone of color.
(Applicable to Custom mode only)
Press MENU Key
Mode Standard
Contrast 47
Brightness 62
Sharpness 43
Color 40
Tint 58
Main menu
Function icons
Function name
Setting bar
Tool Tip
6E_body16p.fm Page 16 Saturday, January 12, 2002 11:02 AM

English 17
Adjusting Your LCD TV/Monitor
Sound The TV/Monitor has a built-in high fidelity stereo
audio amplifier. The audio circuit processes audio
signalsfrom various external input sources such as
DVD, VCR, TV, DTV, or PC.
■ Mode Displays available sound modes.
(Standard, Music, Movie, Speech, Custom)
■
Bass Emphasizeslow frequency audio.
(Applicable to Custom mode only)
■
Treble Emphasizeshigh frequency audio.
(Applicable to Custom mode only)
■
Virtual
Dolby
(Surround)
On, Off
Setup Thechannelsystem can beset in severaldifferent
ways.
■
Channel
System Selecta channel system that is being used in your region.
(See “NTSC broadcasting systems” on page 34)
• US-Air
• US-Cable
Select “US-Air” or “US-Cable” to perform the
“Channel search program”.
(See page 20 for “Channel search program”.)
Table 2. Screen controls (Continued)
Main
Menu Icon Menus and Sub-menus Function Descriptions
6E_body16p.fm Page 17 Saturday, January 12, 2002 11:02 AM

English 18
Adjusting Your LCD TV/Monitor
■
Channel
Edit In rare cases, "Channel search program" may miss a couple of channels that you want to add due to weak signals,
or you may simply want to remove a channel. To add or remove a channel,
please follow the steps described below.
• Push MENU button and then select "Channel
Edit" under "Setup" menu, then press MENU button again.
• Select "Add" to add the channel or select
"Erase" to remove the channel.
■
Fine Tune Due to weak signals,
some of the channels may not be
tuned correctly. Select "Fine Tune" under "Setup"
menu to make the video image as clear as
possible.
• Use " " to fine tune the
image quality.When you are satisfied with the setting,
press " " to highlight "Save" or "Cancel"
menu.
•Select "Save" to save or "Cancel" to cancel the
setting.
■ LNA This function is provided to amplify signals
automatically in case of bad reception.
If mis-operation occurs due to
interference with the received signal,
shut down the LNA(Low Noise Amplifier).
Table 2. Screen controls (Continued)
Main
Menu Icon Menus and Sub-menus Function Descriptions
6E_body16p.fm Page 18 Saturday, January 12, 2002 11:02 AM
