Samsung UD6400 Installation guide

LCD TV
TRAINING MANUAL
UD6500
UD6400
UD6900

Agenda
I. Inside of UD6500
II. New Part of UD6500
III. Board description
IV. Disassembly
V. Trouble Shooting

SAMSUNG
Inside of UD6V

Items Specification
Model Name UN46D6500VFXZA
General
Size (W*D*H) with Stand 1068.40 x 275.0 x 683.60 (mm)
Weight with Stand 16.7 (kg)
Panel Resolution 1920*1080
A/V 2AV
S-Video X
DVD 1 component
480i/p,720p,1080i/p
PC 1 Dsub
HDMI 4 HDMI
Tuner 1 ATSC/Half NIM/QAM tuner
Sound Output 6 ohm, 10W
PIP O
Sound option SRS TruSurround HD
DNIe O
Headphone X
Response time 4ms
Luminance [cd/m2, typical] 500
C/R 50000:1
Anynet+(hdmi cec) O
View Angle(H/V) 178/178
Power Supply AC 110~220V,60Hz
Power Consumption <210W
Color System NTSC
Sound System PCM

Spec Comparison
Model
SAMSUNG
(UD6500 46”)
UN46D6500VFXZA
SAMSUNG
(LC6400 46”)
UN46C6400RFXZA
Design
Set Size 1068.4 x 275.0 x 683.6 mm 998.0 X 300.0 X 703.5 mm
Panel
Size Diagonal 46”Diagonal 46”
Resolution 1920 x 1080 1920 x 1080
Viewing angle H : 178 V : 178 H : 178 V : 178
Color System ATSC / NTSC ATSC / NTSC
Tuner 1 1
Function
Contrast (cd/m2)500 500
CR ( Dynamic ) 50000 : 1 50000 : 1
Enhancer DNIe(FBE3) DNIe(FBE3)
Additional Function
Contents library
Internet@TV
Media Play (USB&DLNA)
(MPEG)
Contents library
Internet@TV
Media Play (USB&DLNA)
(MPEG)
Power Consumption 200W 200W

Control & Connection Panel

Control & Connection Panel
Rear View

Control & Connection Panel

Control & Connection Panel

Control & Connection Panel

Remote control

IP Board, Main Board, Panel
Inner Feature of UD6V
Power Ass’y
T-con board
Power cable
Main Ass’y
Speaker
LVDS
cable
WiFi cable
WiFi module

IP Board, Main Board, Panel
Inner Feature of UD6000 32” / 40” / 46” / 55”

Arsenal / Valencia Block Diagram
DDR3-1333
256MB
GENOA-S
•Cortex-A9 (@600MHz)
Arsenal WW
•SD AFE
•SIF Decoder
•165MHz ADC
•VSB & QAM Decoder
•HDMI Decoder
•IF Demodulator
DDR3 I/F
Hotel/Wall
UART
MAX3222
DEBUG Debug
SPDIF Optical
HDMI
4x1 SW
SIL9389
TMDS
RMII
667MHz
Audio AMP
TAS5725 SPK
I2S0_SPK
IIC
RTL8201 LAN
AK4686
S/W, A/D
D/A*2, AMP
SIF_I2S
SPDIF
SD VIDEO
HD VIDEO
Interrupt
MMC
HDMI
(4ea)
AV In
PC
PC/DVI Audio
YPbPr
RGB HV
AV CVBS
I2S0_MONITOR
Tuner DIF
Monitor
Out
PCM_I2S_DATA
TS Parallel
OneNAND
128MB
MoviNAND
2GB
120Hz
USB 2.0
SMC
DDR3-1333
256MB
DDR3-1333
256MB
DDR3-1333
256MB x4
Wise Link
(1 (HDD)
,2, 3)
STB MICOM
WT61P8 IR/Key
UART
Component
USB Hub
(AU6275)
Bluetooth
Wi-fi
USB 2.0
USB 2.0
Parma

Arsenal WW Internal Block Diagram

GenoaS Internal Block Diagram

Video Input path
Genoa-S
T-half NIM
Tuner Sound
SIF_I2S
ASN_SPDIF
IF
I_SPDIF_RX
B_I2S_R
X1
O_I2S_TX0
PC/DVI Audio
SC1 In
AV2 In
Optical
SPK
HDMI Sound
PCM_I2S_DATA
Codec Sound
I_SPDIF_RX
O_SPDIF_TX
O_I2S_T
X1
(DATA0)
TAS5275
Head
Phone
AK4686
S/W, A/D
D/A*2, AMP
O_I2S_T
X1
(DATA1)
RF Out
Analog
Digital
※TX1 DATA0/1 라인별 차이
1. Data0/1 Post Processing 수행(AMP
출력)
2. Data0/1 Volume 저장값 다름
(Main Speaker용, Headphone용)
AV1 In
Component1
AE30
Line out
SC1_Sound
SPK
Line OUT
SDTI
2
SDTI
1
SCL_C
SDA_C
SCL
SDA
SDTO
1
LRIN
1
LRIN
4
LRIN
3
HP_LINE
LROUT1
LROUT2 SC1_SL/R_OUT
HPL/R_I
N
SDI
N
HPL/R_O
UT
OUT A-
D
SPDIF_OUT
TX1_SDOUT
Arsenal
WW
지 역 RF Out H/P LINE Out
미 주 X X O
성장/브라질 X O X
구 주 O O X
● 지역별 Audio Out사양
HP
미주
구주 / 성장
미주
구주/성장
미주
구주/성장
구주

Reset Tree
Genoa-S
⑤AK4686
(S-Codec)
TAS5725
(S-AMP)
nRESET_OUT
⑤LAN_nRESET RTL8201
Micom_RESET
TUNER
⑦LVDS_OUT
⑤USB_nRESET
ArsenalWW
KFG1G16U2D
(OneNAND)
Weltrend
MICOM
SMPS
Standby
B+ Power
RT9818
(Reset IC)
MICOM_nRESET
①
SW_POWER
②
RT9818
(Reset IC)
POWER_DET
③
SW_INVERTER
⑧
④
SYS_nRESET
PANEL
LVDS
B13V
SW_PVCC
⑥
nRESET
RESET
EPM240T
(CPLD)
AU6257
(USB HUB)
⑤NCI_RESET CI
⑤RESET_BT
Function
(Bluetooth)

I2C
Genoa-S
SCL_C
SDA_C
I2C1_CL
K
I2C1_D
AT
MI2C2_CLK
MI2C2_DAT
I2C2_CLK
I2C2_DAT
(CS2,3공용핀)
Sound AMP
TAS5725(0x44)
Switching IC
(NC7WB3125K8X)
SCL_ASN
SDA_ASN
Arsenal WW
ATSC:0x26
DVB-T:0x06 / DVB-C:0x16
SIL9287
(0xB0)
I2C0_CL
K
I2C0_D
AT
Audio Codec
AK4686 (0x24)
AT24C256BN
(0xA0)
SCL_PANEL
SDA_PANEL
SCL_MAIN_EEPROM
SDA_MAIN_EEPROM
LD
(0xD2)
SCL_LD
SDA_LD
TUNER
(0xC2)
SCL_TUNER
SDA_TUNER
MI2C0_CLK
MI2C0_DAT
MI2C1_CLK
MI2C1_DAT
Function Module
(Reserved)
MSCL_A5V
MSDA_A5V
Internal MICOM
I2C3_CLK
I2C3_DAT
(GPIO0,1공용핀)
S-24CS02AFJ
(0xA0)
SCL_SUB_EEPROM
SDA_SUB_EEPROM
MSPI / I2C
LNBH23 (EU-TS)
(0x14)
Sub MICOM
WELTREND
PANEL
(Depend on Panel Type)
SCL_TCON
SDA_TCON
Switching IC
(NC7WB3125K8X)
SCL_DOWN
SDA_DOWN

UART
GENOA-S
UART0_TX
UART0_RX
LVDS Connector
(PDP Option)
74HC4052D
TX_DEBUG
RX_DEBUG
MUART1_TX
MUART1_RX
MUART2_TX
MUART2_RX
ADM3232
MTX1_AUTOWALL
MRX1_AUTOWALL
TDA_MICOM
RDA_MICOM
TDB_LOGIC
RDB_LOGIC
TDB
RDB
MUART0_TX
MUART0_RX
Internal MICOM
Sub MICOM
WELTREND
3X/Y
0X/Y
2X/Y
D-SUB
1X/Y
MTX2_HOTEL
MRX2_HOTEL
SW_SEL1/2
FRAME_SYNC_OUT
FRAME_SYNC_IN
Bluetooth
