Samsung X12ATSCF Guide

SMART TV
E-Manual

Contents
e-Manual Guide
Viewing the e-Manual
1 Scrolling a Page
1 Using the Top Icons
1 Returning to the Home Page
1 Searching the Index
2 Searching Pages
2 Closing the e-Manual
2 Jumping to a Menu Item
2 Updating the e-Manual
Getting Started
Antenna Connection
Video Device Connections
4 HDMI Connection
5 Component Connection
5 AV Connection
Audio Device Connections
6 Digital Audio (Optical) Connection
7 Audio Output Connection
7 ARC (Audio Return Channel)
Computer Connection
8 HDMI Connection
9 HDMI-to-DVI Connection
Switching Between Video Sources
Programming
11 Auto Program
Channel Management
13 Remove Channels
13 Restore Removed Channels
13 Channel Lock
13 Channel Unlock
13 Rename Analog Channels
Favorite Channels
14 Add Favorite Channels
14 AddFavoriteChannelsusingthe간편메뉴button
15 Remove Favorite Channels
15 Rearrange the Favorite Channels List
15 Rename a Favorite Channel List
15 Copy a Favorite Channels List
Network Configuration
16 Wired Network
17 Wireless Network
17 LED 6400 ~ 7200 Series models
18 LED 6300 Series models
19 Wireless Network Precautions
20 Network Security Protocols
Wired Network Setup
20 Automatic Wired Network Setup
21 Manual Wired Network Setup
22 Failed Wired Connection
Wireless Network Setup
23 Automatic Wireless Network Setup
24 Manual Wireless Network Setup
25 Using the WPS Button
26 Failed Wireless Connection
27 Dynamic versus Static IP Addresses
Checking the Network Status
Mobile Device Connection
28 Wi-Fi Direct
28 AllShare Settings
28 Rename the TV
ii

Controlling the TV
Smart Touch Control
29 Inserting the Batteries (AAA X 2)
30 Connecting to the TV
30 Reconnecting the Smart Touch Control
30 Battery Low Alarm
31 Buttons and Descriptions
32 Special Functions
Using the touch pad
33 Dragging
33 Press
34 Flicking
34 Pressing and Holding
34 Pressing and Dragging
35 Scrolling Up/Down
35 Scrolling Left/Right
36 ChangingChannelsbyEnteringNumbers
36 Numerical Input Guide
37 Adjusting the Touch pad
37 Show Status and Notification Banner
37 Recommended
37 History
37 Deleting History Data
37 Searching
Virtual Remote Control
38 Changing the Virtual Remote Control Panel
38 Change a position of the Virtual Remote Panel
38 Adjusting the virtual remote panel size
39 UsingtheNumberPanel
39 UsingthePlaybackControlPanel
40 Using the Quick Access Panel
Universal Remote Setup
41 Connecting the IR EXTENDER CABLE
41 Add the External Device
42 Using the Universal Remote Control
42 Registered External Device Management
Entering Text using the Onscreen Keypad
42 Entering Text using the QWERTY Keypad
42 Additional Features
SMART Interaction
43 Precautions
43 Face Recognition
43 TV Camera Use
43 Motion Control
44 Voice Recognition
Voice Recognition
44 Operating Environment
45 EnablingVoiceRecognition
45 Voice Recognition Tutorial
45 Basic Voice Recognition Use
45 Voice Recognition Settings
46 Interactive Voice Recognition Commands
46 Deactivating Voice Recognition
Motion Control
47 Operating Environment
48 Motion Control Environment Test
48 Motion Control Activation
48 Motion Control Tutorial
49 Using the Basic Motion Controls
49 Motion Control Options
50 Motion Control Screen
50 The Screen Composition while Viewing TV
51 TheSmartHubScreenComposition
Face Recognition
53 Operating Environment
54 Face Registration
54 FaceRegistrationfromtheSmartHubaccount
information screen
55 FaceRegistrationfortheSmartHubaccountusingface
recognition
55 Face Recognition Login
Using Peripheral Devices
56 KeyboardConnection
56 KeyboardUse
57 Mouse Connection
57 Mouse Use
ii iii

TV Viewing
TV Viewing
58 Program Info
58 Change the Broadcast Signal
58 Guide
59 Change Channels
59 Recording the Current Program
59 Change Category
59 Quick Search
59 Schedule Viewing
59 Schedule Recording
59 Checking the Program Info
60 Channel List
61 Change Channels
61 Genre
61 Change the Broadcast Signal
61 Change the Channel List
Schedule Viewing
62 Digital Channel Schedule Viewing
62 Guide
62 Program Info
63 Analog Channel Schedule Viewing
63 Cancel a Schedule Viewing
63 Edit Schedule List
Schedule Recording
64 Precautions
65 Dedicated Recording Device Setup
65 Initial Setup
65 Dedicated Recording Device Management
66 Program Recording
66 Instant Recording
66 Guide
66 Program Info
66 Specified Time and Date
67 Cancel the Schedule Recording function
67 Edit Schedule List
Recorded Program Playback
67 Changing the Viewing Mode
67 Filtered View
68 Playlist Creation
68 Recording Lock/Unlock
68 Deleting Saved Programs
68 Rename
69 Device Management
69 Playing a Different Program
69 Program Scan
70 AdditionalRecordedProgramPlaybackSettings
Time Shift
71 Precautions
72 Activating the Time Shift function
3D TV
73 Precautions
73 Restrictions
73 Tips
74 Activating 3D Mode
74 Setting 3D Effects
74 3D Channel Viewing
PIP
Analog Screen Calibration
76 Fine Tune
Broadcast Audio Options
77 Digital Broadcast Audio Options
77 Analog Broadcast Audio Options
Subtitles
78 ShowSubtitles
78 SubtitleOptions
79 SubtitleDisplayOptions
iv

TV Settings
Basic Picture Settings
80 Changing the Picture Mode
81 Picture Quality
81 Applying the Current Picture Quality Setting to Another
Input
82 Picture Size
83 Screen Position
83 Picture Off
83 Reset Image Settings
Advanced Settings
Picture Options
Basic Sound Settings
87 Changing the Sound Mode
88 Adjusting the Sound Settings
88 Auto Volume
88 TV Installation Type
88 Resetting the Sound
3D Audio
Speaker Settings
90 Speaker Select
90 Digital Audio Output
90 Samsung Audio Device Connection
Clock and Timer
91 Setting the Time
91 Auto
91 Manual
92 Sleep Timer
92 On Timer
92 Off Timer
Screen Protection and Maintenance
93 Eco Solution
93 Auto Protection Time
Password
94 Change Password
Additional Features
95 Changing the Menu Language
95 Game Mode
95 Precautions and Restrictions
96 BD Wise
96 Menu Transparency
96 SoundFeedback
96 Panel Locking
96 Booting Logo
96 DivX® Video On Demand
SMART TV Features
Smart Hub
97 AgreementsRequiredtoUseSmartHub
98 Samsung Account
98 Creating a Samsung Account
98 Terms and Conditions, Privacy Policy
99 Logging In
99 Linking a Samsung Account to Other Accounts
99 Managing Accounts
100 ResettingSmartHub
Searching
100 Keyword Search
100 Setting Search Scope
Status and Notification
101 Show Status and Notification Banner
101 Voice Recognition & Motion Control Configuration
101 Samsung Account Configuration
101 Network Configuration
101 Notifications
Social
102 Social Settings
102 Checking the Application
102 Connecting a Service to a Samsung Account
103 Watching Videos
103 Friend Profile
103 Video Calling a Friend
103 Filters
iv v

Apps
104 Precautions
105 Installing Standard Applications
105 Launching an Application
105 Samsung Apps
105 Searching for Apps
105 Installing Applications
106 Apps Management
106 Edit My Apps
107 Deleting Applications
107 Managing Application Folders
107 Application Lock/Unlock
107 Application Update
108 Fitness
108 Creating a Profile
108 Kids
109 WebBrowser
109 Social Networks
109 Linking Service Accounts
110 Smart Tips
110 Naver Search
110 Real-Time Hot Issues from me2day
110 Music Search
110 Smart Tips Settings
110 3D Explorer
111 Apps Settings
111 Auto Ticker
111 Push Notifications
111 Channel-Bound Apps
111 Properties
On TV
112 On TV Settings
112 On TV Setup
112 Recommendation Notice
113 Auto Start
113 Recommendation Method
113 Adult Contents Block
113 Watching an On-Air Recommended Program
113 Scheduled Recommended Program Info
113 Activating the Guide
113 ProgramRecommendationsbyTime
113 Watching Recorded Programs
Movie & TV Shows
114 Custom Recommendations List
115 Watching Content
115 Parental Control
115 Miscellaneous
Photos, Videos & Music
116 Restrictions
117 Supported File Formats
117 USB Device Connection
117 USB Device Removal
117 Playing Media Files Stored on USB storage devices
117 Clearing the Recent Playlist
118 Using Networked External Storage Devices
118 Allowing DLNA Device Connections
118 AllShare
119 Exporting Contents
Videos
119 Changing the view mode
119 Playlist Creation
120 Opening a Different File
120 Video Scanning
120 ShowSubtitles
121 AdditionalVideoPlaybackSettings
Music
121 Changing the view mode
121 Playlist Creation
122 Music Scanning
122 Opening a Different File
122 AdditionalMusicPlaybackSettings
Photos
123 Changing the view mode
123 Slide Show
123 Slide Show Settings
124 Playlist Creation
124 Opening a Different File
124 Background Music
124 Mini Player
125 AdditionalPhotoPlaybackSettings
Anynet+ (HDMI-CEC)
126 Precautions
126 Anynet+ (HDMI-CEC) Setup
127 Using the Anynet+ (HDMI-CEC)
127 SwitchingbetweenAnynet+Devices
127 Anynet+ (HDMI-CEC) Device Menu
127 ARC
Sharing Mobile Device Screens on the TV
128 Screen Mirroring
128 MobileDeviceConnection
vi

Other Information
Support
129 Remote Management
129 e-Manual
129 Self Diagnosis
130 Picture Test
130 Sound Test
130 Motion Control Environment Check
130 Signal Information
130 Reset
131 Updating the Software
131 Update now
131 Auto Update
132 Usage Mode
132 Support Info
Kensington Security Lock
Display Resolution
133 IBM
133 MAC
134 VESA DMT
Picture Size and Input Signal
Supported 3D Resolutions
135 HDMI
135 3D Format: L/R, T/B
135 3D Format: Frame Packing
136 Component
136 Digital Channel
136 Videos/Photos
136 Computer via HDMI
3D Precautions
Subtitle and Media Contents file formats, and Codec
140 Subtitle
140 External
140 Internal
141 Supported image resolutions
141 Supported music file formats
142 Video Codec
142 Other Restrictions
143 Video Decoders
143 Audio Decoders
Licenses
Troubleshooting
Sound
3D TV
Antenna (Air/Cable) Connection
PC Connection
Networking
Miscellaneous
Schedule Recording/Time Shift
Anynet+ (HDMI-CEC)
Apps
Photos, Videos & Music
Reset the Personal Info and TV settings
Web Browser
vi vii

1
Viewing the e-Manual
The embedded e-Manual contains information about your TV's key features.
Select the e-설명서 button on the virtual remote panel or select e-Manual (Troubleshooting) (Support>
e-Manual (Troubleshooting)) from the screen menu. Alternatively, you can download a copy of the
e-manual from Samsung's website and read it on your computer or print it out.
1.
Select a category from the left side of the screen.
2.
Select an item. The e-Manual will open on the page containing the selected information.
"Words in blue (e.g. Picture Mode) refer to screen menu options and words in light blue (e.g. 스마트허브
button) refer to remote control buttons.
"Arrows are used to indicate the menu path. (e.g. 가상리모컨¤> Menum> Picture > Picture Mode
Scrolling a Page
To scroll a page, use of one of the following methods:
●Press the or button on the scroll bar at the right edge of the screen.
●Drag or flick up or down up/down the line on either the left or right edge of the touch pad.
●Place the focus on the or button at the right edge of the screen, drag or flick up or down
on the touch pad.
Using the Top Icons
Use the Back, Forward, and Opened pages icons on the top left of the screen to navigate through
pages. These icons are available when two or more pages are passed.
Returning to the Home Page
To return to the home page, press the abutton or select on the top right of the screen.
Searching the Index
Press the bbutton or select on the top right of the screen to display the index. Select a term to
display the page containing the term.

2
Searching Pages
Press the {button or select on the top of the screen to access the search screen. Enter a search
phrase and select Done. Select an item from the search results list to navigate to the relevant page.
Closing the e-Manual
To close the e-Manual, select at the upper-right corner of the screen or press and hold the 복귀
button.
Jumping to a Menu Item
To directly jump to the menu item that is described in the current section, select Try Now . It is
possible to jump from a menu item directly to the related section in the e-Manual. On the screen
menu, select e-설명서 on the virtual remote's panel that appears on the screen.
"This feature may not be available, depending on the menu.
Updating the e-Manual
Press the button and select Apps, and then select More Apps. The e-manual can be updated in the
same way with an application update.
On the More Apps screen, select Update Apps, and then select e-Manual from the list. The e-Manual
starts updating to the latest version. However, Update Apps appears on the screen only when the
update is required.

2 3
Antenna Connection
Refer to the diagram and connect the antenna cable to the antenna input connector. Make sure that you
do not bend the cable. The number of connectors and their names and locations may vary depending
on the model.
Connect the correct antenna cable for your viewing environment (over-the-air or cable broadcasting).
However, an antenna connection is not necessary if you are using a cable box or satellite receiver.
Video Device Connections
This TV has a wide range of connectors for video input from video devices such as Blu-ray players,
DVD players, camcorders and gaming consoles. Below is a list of featured connectors shown in
descending order of picture quality.
●HDMI
●Component
●AV
Connect the video device to the TV via an HDMI connector for the best picture quality. If the device
does not have an HDMI connector, try a component connector to get the next best possible picture
quality.
The number of connectors and their names and locations may vary depending on the model.
When connecting an external device, refer to the device's operating manual. The number of external
device connectors and their names and locations may vary depending on the manufacturer.

4
HDMI Connection
Refer to the diagram and connect the HDMI cable to the video device's HDMI output connector and the
TV's HDMI input connector. One of the following HDMI cable types is recommended:
●High-Speed HDMI Cable
●High-Speed HDMI Cable with Ethernet
Use an HDMI cable with a thickness of 14 mm or less. Using a non-certified HDMI cable may result in
a blank screen or a connection error.
"Some HDMI cables and devices may not be compatible with the TV due to different HDMI specifications.
"This TV does not support the HDMI Ethernet Channel. Ethernet is a LAN (Local Area Network) built on
coaxial cables standardized by the IEEE.

4 5
Component Connection
Refer to the diagram and connect the TV’s component video and audio input connectors to the
external device’s component video and audio output connectors using a component cable, so that the
connectors of the same color connect to each other, as shown in the figure.
AV Connection
efer to the diagram and connect the AV cable to the TV's external input connectors and the device's
AV output connectors. Certain models combine the external video input connector and the component
Y connector into a single connector. If this is the case, connect the video cable to the Y connector.

6
Audio Device Connections
This TV has a wide range of connectors for audio input from devices such as amplifiers, Blu-ray
players and DVD players. For better audio quality, it is a good idea to use an AV receiver.
●Digital Audio (Optical)
●Audio
●ARC (Audio Return Channel)
The number of connectors and their names and locations may vary depending on the model.
When connecting an external device, refer to the device's operating manual. The number of external
device connectors and their names and locations may vary depending on the manufacturer.
Digital Audio (Optical) Connection
Refer to the diagram and connect the optical cable to the TV's digital audio output connector and the
device's digital audio input connector.
Connecting the device using an optical cable does not automatically turn off the TV speakers. To turn
off the TV speakers, open the Speaker Select (Sound > Speaker Settings > Speaker Select) menu,
then set External Speaker.
Adjust the audio device's volume using its remote control.
An unusual noise coming from the audio device while it is being used may indicate a problem with the
audio device itself. If this is the case, ask for assistance from the audio device manufacturer.
5.1-channel audio for digital channels is only available with broadcasts that support 5.1-channel audio.

6 7
Audio Output Connection
Refer to the diagram and connect the audio cable to the TV's audio output connector and the device's
audio input connector.
ARC (Audio Return Channel)
This TV supports 3D and ARC (Audio Return Channel) functions via an HDMI cable. ARC enables
digital sound to be output using just an HDMI cable. However, ARC is only available through the HDMI
(ARC) port and only when the TV is connected to an ARC-enabled AV receiver. Connect the HDMI
cable to the TV's HDMI (ARC) connector and the device's HDMI output connector.

8
Computer Connection
This TV supports the HDMI/DVI port for connect the computer. Not all computers are HDMI-enabled.
In this case, use an HDMI-to-DVI cable to connect the computer to the TV. Refer to the "Display
Resolution" for information on the resolution settings supported to the TV.
HDMI Connection
Refer to the diagram and connect the HDMI cable to the TV's HDMI input port and the computer's
HDMI output port.

8 9
HDMI-to-DVI Connection
Refer to the diagram and connect the HDMI-to-DVI cable to the TV's HDMI (DVI) port and the
computer's DVI output port. The HDMI-to-DVI connection is available through the HDMI (DVI) port
only.
DVI cannot carry audio. To listen to the computer sound, connect the external speaker to the
computer’s audio output connector.

10
Switching Between Video Sources
Press the 외부입력 button to switch between devices connected to the TV.
For example, to switch to a game console connected to the second HDMI connector, press the 외부입력
button. From the Source list, select HDMI2. The connector names may vary depending on the product.
Select Tools at the upper-right corner of the Source screen to access the following functions.
●Edit Name: Users can rename devices connected to the TV to more easily identify external
sources.
With a computer connected to the TV's HDMI (DVI) port via an HDMI cable, for example, you can
change Edit Name to PC.
With a computer connected to the TV's HDMI (DVI) port via an HDMI-to-DVI cable, for example,
you can change Edit Name to DVI PC.
With an AV device connected to the TV's HDMI (DVI) port via an HDMI-to-DVI cable, for
example, you can change Edit Name to DVI Devices.
●Information: View detailed information about the connected devices.
●Refresh: Select this if a connected device does not appear in the list. If the list does not show the
device after selecting Refresh, check the status of the TV-to-device connection.
●Remove USB: Remove the USB device from the list to safely. This function is only available when
the USB device selected.
Select Universal Remote Setup at the top right of the Source screen. Using the universal remote
control, users can control external devices connected to the TV, such as a set-top box, Blu-ray player,
and AV receiver. For details, see "Universal Remote Setup".

10 11
Programming
Scan and index available channels.
Broadcasting
Auto Program
Antenna Cable
Channel List
Guide
Schedule Manager
Edit Channel
Edit Favorites
"The displayed image may differ depending on the model.
Users can also remove channels from the index, restore removed channels and designate favorite
channels for a more convenient TV viewing experience. Programming is not necessary if you are
connected to a cable or satellite receiver.
Auto Program
가상리모컨¤> Menum> Broadcasting > Auto Program Try Now
Automatically scans and indexes all channels received through the TV's antenna input connector.
1.
To start, navigate to Broadcasting and select Auto Program.
2.
Select Start when prompted with a message. This initiates the Auto Program function. The
process can take up to 30 minutes to complete. If Starting the Auto Program function when there
is an existing index of channels overwrites the previous index.

12
Channel Management
가상리모컨¤> Menum> Broadcasting > Edit Channel Try Now Try Now
Broadcasting
Auto Program
Antenna Cable
Channel List
Guide
Schedule Manager
Edit Channel
Edit Favorites
"The displayed image may differ depending on the model.
Remove channels from the index, restore removed channels, and rename analog channels. The Edit
Channel screen icons indicate the following:
●: An analog channel
●: A favorite channel
●: A locked channel
Select the 간편메뉴 button on the virtual remote panel from the Edit Channel screen to access the
following options:
●Antenna: Choose between Cable and Air.
●Category: The TV's channel index is divided into different categories such as All, Added Ch.,
Recently Viewed and Mostly Viewed. Choose a category.
●Edit Favorites: Organize favorites lists to find favorite channels and switch between channels
more easily. For details, see "Favorite Channels".
●Information: View detailed information about the current program.

12 13
Remove Channels
Remove registered channels from the index. Removing channels appearing in the Recently Viewed or
Mostly Viewed list clears the channels from the list only and does not remove them from the index.
1.
From the screen, select the channels you wish to remove. Unselect channels by choosing them
again.
2.
Press the {button. The selected channel(s) will be deleted.
Restore Removed Channels
Restore removed channels. Removed channels are displayed in gray on the All list. In addition, the Add
option is only available for removed channels.
1.
Select the 간편메뉴 button on the virtual remote panel. The list screen appears. Select Category
and then select All.
2.
From the All list, select the channels you wish to restore. Unselect channels by choosing them
again.
3.
Press the {button. The selected channel(s) will be added.
Channel Lock
Users can lock channels you don't want your children to view.
Lock is only available with Channel Lock set to On. Navigate to Channel Lock (Broadcasting > Channel
Lock) and set On. Try Now
Navigate to the Edit Channels screen, select the channels you wish to lock, press bbutton, and then
enter the password. This locks the selected channels.
Channel Unlock
Unlock locked channels. Navigate to the Edit Channels screen, select the locked channels you wish to
unlock, press the bbutton and then enter the password. This unlocks the selected channels.
Rename Analog Channels
From the screen, select an analog channel, and then select the 간편메뉴 button on the virtual remote
panel. The list screen appears. Select Rename channels from the list.
Users can now rename the selected channel. The new name can be up to 5 characters long.
