Samsung LED 5070 Series Guide

E-MANUAL
Thank you for purchasing this Samsung
product. To receive more complete service,
please register your product at
www.samsung.com/register
Model __________ Serial No.____________

Contents
Channel Setting
• UsingtheINFObutton(Now&Nextguide) 1
• Memorizingchannels 2
• UsingtheChannelmenu 6
• LockingProgramme 19
• OtherFeatures 21
Basic Features
• ChangingthePresetPictureMode 32
• AdjustingPictureSettings 33
• ChangingthePictureOptions 40
• ChangingthePresetSoundMode 46
• AdjustingSoundSettings 47
• SelectingtheSoundMode 54
Preference Features
• Executinginitialsetup 55
• SettingtheTime 56
• UsingtheSleepTimer 58
• SettingtheOn/OffTimer 59
• EconomicalSolutions 64
• OtherFeatures 66
Advanced Features
• UsingtheSourceList 70
• ConnectingaUSBDevice 71
• UsingtheMediaContents 77
• PlayingthePhotos/Videos/Music 79
Other Information
• Viewingthee-Manual 87
• UsingtheSelfDiagnosis 88
• UpdatingtheSoftware 90
• ChangingtheUseMode 92
• ViewingtheContactSamsung 93
• UsingtheSportsMode 94
• UsingtheSatelliteSystem 95
• UsingtheWiredNetwork 103

▶
❑Using the INFO button (Now & Next guide)
The display identifies the current channel and the status of certain audio-video
settings.
The Now & Next guide shows daily TV programme information for each channel
according to the broadcasting time.
NWhen you press the INFO button, a channel information banner will appear
on the top of the screen. And then press the ENTEREbutton, you can see
the details of the programme.
●Scroll ◄, ►to view information for a desired programme while watching
the current channel.
●Scroll ▲, ▼to view information for other channels.
Channel Setting
English

◀ ▶
❑Memorizing channels
■Aerial
OMENUm→Broadcasting → Aerial → ENTERE
Before your television can begin memorising the available channels, you must
specify the type of signal source that is connected to the TV.
English

◀ ▶
■Auto Tuning
(depending on the country)
OMENUm→Broadcasting → Auto Tuning → ENTERE
NAutomatically allocated programme numbers may not correspond to actual
or desired programme numbers. If a channel is locked, the PIN input window
appears.
●Auto Tuning
Aerial (Air / Cable): Select the aerial source to memorise.
NWhen selecting Air, scans for a channel automatically and stores in the
T V.
Channel Type (Digital & Analogue / Digital / Analogue): Select the channel
source to memorise.
English

◀ ▶
When selecting Cable →Digital & Analogue, Digital or Analogue
–Operator Selection (depending on the country): Selects a provider of
cable services.
–Search Mode: Scans for all channels with active broadcast stations and
stores them in the TV.
NIf you select Quick, you can set up the Network, Network ID,
Frequency, Modulation and Symbol Rate manually by pressing the
button on the remote control.
–Network: Selects the Network ID setting mode among Auto or Manual.
●Network ID: When Network is Manual, you can set up Network ID
using the numeric buttons.
English

◀ ▶
●Frequency: Displays the frequency for the channel (differs in each
country).
●Modulation: Displays available modulation values.
●Symbol Rate: Displays available symbol rates.
●Cable Search Option
(depending on the country & cable channels only)
Sets additional search options such as the frequency and symbol rate for a
cable network search.
Start Frequency / Stop Frequency: Set the start or stop frequency (differs in
each country).
Symbol Rate: Displays available symbol rates.
Modulation: Displays available modulation values.
English

◀ ▶
❑Using the Channel menu
OMENUm→Broadcasting →Channel List →ENTERE
■Channel List
The Channel List contains the channels your TV displays when you press the
channel button. You can view channel information, All, TV, Radio, Data/Other,
Analogue or Favourites 1-5.
Press ► (Mode) button to change the channel mode, or press ◄(Sorting)
button to change the channel order according to channel number or name on the
list.
NWhen you press the CH LIST button on the remote control, Channel List
screen will be displayed at once.
English

◀ ▶
Channel Sorting
●Number / Name: Arranges the channel order according to channel number
or name on the list.
Channel Mode
●Air / Cable: Switches to Air or Cable.
●Edit Favourites: Set channels you watch frequently as favourites.
NFor detailed information about using Edit Favourites, refer to “Edit
Favourites”.
●Favourites 1-5: Shows all favourite channels, arranged in up to five groups.
Each group has a separate screen.
NThe TV displays Favourites 1-5 only if you have added favourites using
Edit Favourites.
English

◀ ▶
●All: Shows all currently available channels.
●TV: Shows all currently available TV channels.
●Radio: Shows all currently radio channels.
●Data/Other: Shows all currently available MHP or other channels.
●Analogue: Shows all currently available analogue channels.
English

◀ ▶
■Guide
OMENUm→Broadcasting →Guide →ENTERE
The EPG (Electronic Programme Guide) information is provided by broadcasters.
Using programme schedules provided by broadcasters, you can specify
programmes you want to watch in advance so that the channel automatically
changes to the selected programme channel at the specified time. Programme
entries may appear blank or out of date depending on a channel status.
●aRed (Quick Nav): Viewing the TV programmes on the list quickly using
▲/▼/◄/► buttons.
●bGreen (Channel Category): Select the type of channels you want to
display.
●{Yellow (Schedule Manager): Moves to the reserved programmes in
Schedule Manager.
English

◀ ▶
■Schedule Manager
OMENUm→Broadcasting →Schedule Manager →ENTERE
You can set a desired channel to be displayed automatically at the intended time.
In addition, you can view, modify or delete a channel you have reserved to watch.
NYou must set the current time first using the Time →Clock function in the
System menu to use this function.
1. Press the Schedule on the Schedule Manager screen. The Schedule
Viewing menu appears.
2. Press the ▲/▼/◄/► buttons to set each option menu.
●Aerial: Select the desired broadcasting signal.
●Channel: Select the desired channel.
English

◀ ▶
●Repeat: Select Once, Manual, Sat~Sun, Mon~Fri or Everyday to set at
your convenience. If you select Manual, you can set the day you want.
NThe (c) mark indicates the day you’ve selected.
●Date: You can set the desired date.
NIt is available when you select Once in Repeat.
●Start Time: You can set the start time you want.
NIf you want to edit or cancel a reserved schedule, select the reserved
schedule on Schedule Manager. Then press the ENTEREbutton and
select the Edit or Delete.
English

◀ ▶
■Edit Channel
OMENUm→Broadcasting →Edit Channel →ENTERE
You can edit or delete channels.
1. Go to Edit Channel screen.
2. Press the ▲/▼ buttons to select the desired channel, then press the
ENTEREbutton. The (c) mark indicates the channel you’ve selected.
NYou can select more than one channel.
NPress the ENTEREagain to deselect the channel.
English

◀ ▶
NUsing the coloured and function buttons with the Edit Channel.
●aRed (Change Number): Changes channel order on the channel list.
–E(Done): Completes changing the channel order.
●bGreen (Lock / Unlock): Lock a channel so that the channel cannot be
selected and viewed. / Unlock the channel that you locked.
NThis function is available only when the Channel Lock is set to On.
NThe PIN input screen appears. Enter your 4-digit PIN. Change the
PIN using the Change PIN option.
●{Yellow (Delete): Deletes a channel from the channel list.
English

◀ ▶
●} Blue (Select All / Deselect All): Selects or deselects all channels at
once.
●(Go To): Goes to channel directly by pressing numbers (0~9).
●k(Page): Move to previous or next page.
●T(Tools): Displays the option menu. The option menu items that appear
may differ depending on the channel status and type.
–Sorting (digital channels only): Changes the list ordered by channel
number or channel name.
–Aerial: Select the desired broadcasting signal.
English

◀ ▶
–Category: Change the channel mode to All, TV, Radio, Data/Other,
Analogue, Recently Viewed, Most Viewed. The selected channel
mode is displayed.
–Edit Favourites: Go to Edit Favourites screen directly.
–Rename channel (analogue channels only): Assign a name of up to
five characters to a channel. For example, Food, Golf, etc. This makes
it easier to find and select the channel.
–Channel Info: Display details of the selected channel.
–Information: Display details of the selected programme.
English

◀ ▶
■Edit Favourites t
OMENUm→Broadcasting →Edit Favourites →ENTERE
You can add, edit or delete favourite channels.
1. Go to Edit Favourites screen.
2. Press the ▲/▼ buttons to select the desired channel, and then press
ENTEREbutton.
3. Choose a specific favourite list among Favourites 1-5 using b(Change Fav.)
button, and then press the {(Add) button. The selected channel has been
added in Favourites 1-5.
NOne favourite channel can be added in several of favourites among
Favourites 1-5.
English

◀ ▶
NUsing the coloured and function buttons with the Edit Favourites.
●aRed (Category / Change order)
–Category: Changes the channel mode to All, TV, Radio, Analogue,
Data/Other, Recently Viewed, Most Viewed. The selected channel
mode is displayed.
–Change order: Changes the favourite channel order.
–E(Done): Completes changing the channel order.
●bGreen (Change Fav.): Changes favourite list among Favourites 1-5.
●{Yellow (Add / Delete)
–Add: Adds selected channels to Favourites 1-5.
–Delete: Deletes the favourite channel from Favourites 1-5.
●}Blue (Select All / Deselect All): Selects or deselects all channels at
once.
English

◀ ▶
●(Go To): Goes to channel directly by pressing numbers (0~9).
●k(Page): Move to previous or next page.
●T(Tools): Displays the option menu. The option menu items that appear
may differ depending on the channel status and type.
–Copy to favourites: Edit the selected favourite channel in Favourites
1-5.
–Rename Favourites: Assign your own favourite channel name.
–Aerial: Select the desired broadcasting signal.
–Edit Channel: Go to Edit Channel screen directly.
–Information: Display details of the selected programme.
English
