Samsung UN58J5190AF User manual

LED TV
SERVICEManual
LED TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
UN58J5190AF
Chassis : UNE50
Model : UN58J5190AF

Contents
1. Precautions...................................................................................................................1-1
1-1. Safety Precautions ..............................................................................................................1-1
1-1-1. Warnings...................................................................................................................1-1
1-1-2. Servicing the LED TV ...............................................................................................1-1
1-1-3. Fire and Shock Hazard.............................................................................................1-1
1-1-4. Product Safety Notices .............................................................................................1-2
1-2. Servicing Precautions..........................................................................................................1-3
1-2-1. General Servicing Precautions .................................................................................1-3
1-3. Static Electricity Precautions ...............................................................................................1-4
1-4. Installation Precautions .......................................................................................................1-5
2. Product Specications.................................................................................................2-1
2-1. Product information .............................................................................................................2-1
2-2. Product specication ...........................................................................................................2-2
2-2-1. Detailed Specications .............................................................................................2-2
2-2-2. Specications ...........................................................................................................2-7
2-3. Accessories ........................................................................................................................2-8
3. Disassembly and Reassembly ....................................................................................3-1
3-1. Disassembly and Reassembly ............................................................................................3-1
3-2. Disassembly(PTC)...............................................................................................................3-4
4. Troubleshooting ...........................................................................................................4-1
4-1. Troubleshooting...................................................................................................................4-1
4-1-1. Testing the Picture ....................................................................................................4-1
4-1-2. Testing the Sound.....................................................................................................4-3
4-1-3. There is a problem with the broadcast......................................................................4-4
4-1-4. My computer won’t connect......................................................................................4-4
4-1-5. I can’t connect to the Internet ...................................................................................4-4
4-1-6. My le won’t play ......................................................................................................4-5
4-1-7. I am having trouble launching/using apps ................................................................4-5
4-1-8. I want to reset the TV................................................................................................4-5
4-1-9. Other Issues .............................................................................................................4-6
4-2. Connect ...............................................................................................................................4-7
4-3. Factory Mode Adjustments..................................................................................................4-9
4-3-1. Detail Factory Option................................................................................................4-9
4-3-2. Entering Factory Mode ...........................................................................................4-10
4-3-3. Factory Data ........................................................................................................... 4-11
4-4. White Balance ...................................................................................................................4-24
4-4-1. Calibration ..............................................................................................................4-24
4-4-2. Service Adjustment.................................................................................................4-24
4-4-3. Adjustment..............................................................................................................4-26

4-5. Software Upgrade..............................................................................................................4-27
4-5-1. By USB ...................................................................................................................4-27
4-5-2. By Online ................................................................................................................4-27
4-5-3. Alternative Software (Backup) ................................................................................4-27
4-6. The Dimension of J5190 Models.......................................................................................4-28
5. Wiring Diagram.............................................................................................................5-1
5-1. Wiring Diagram....................................................................................................................5-1
5-2. Connector............................................................................................................................5-2
5-3. Connector Functions ...........................................................................................................5-4
5-4. Cables .................................................................................................................................5-5
5-5. The Types of Module ...........................................................................................................5-6
ANNEX. Exploded View & Part List [UN58J5190AFXZA IS01]........................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
2-1. Electrical Parts List................................................................................................... ANNEX-2

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2014 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea

3-1
3. Disassembly and Reassemble
3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LED TV.
WARNING
This LED TV contains electrostatically sensitive devices. Use caution when handling these components.
3-1. Disassembly and Reassembly
CAUTION
Disconnect the LED TV from the power source before disassembly.1.
Follow these directions carefully; never use metal instruments to pry apart the cabinet.2.
If there is no additional coment, it is same for all inches.3.
Description Picture Description Screws
1
Place TV face down on cushioned table.
2
Remove screws from the Stand and
Remove Stand.
58" : 4ea-
Torque :
7~ 8Kgf.cm
6003-001782
3
Remove screws of Rear Cover. Torque :
7~ 8Kgf.cm
6003-001782
Torque :
4~ 5Kgf.cm
6003-002755

3-2
3. Disassembly and Reassemble
Description Picture Description Screws
4
Remove screws of Main Board and Power
Board. Torque :
7~ 8Kgf.cm
6001-002756
5
Remove the speakers and power cables.
6
Remove the cables, function assy and
Panel drive cable.

3-3
3. Disassembly and Reassemble
Description Picture Description Screws
7
Completed disassembly.
NOTE
Reassembly procedures are in the reverse order of disassembly procedures.

3-4
3. Disassembly and Reassemble
3-2. Disassembly(PTC)
How to disassembly
Description Picture Description Refer
1
Place TV face up on cushioned table.
2
Remove the ASSY Function assy.
3
Spread the both sides of PTC upper
(marked "▼") by use the tool.
CAUTION
Do not scratch on both side by use tool.
Gate Cof will be damaged.

3-5
3. Disassembly and Reassemble
Description Picture Description Refer
4
Separate the left and right side of the PTC
as shown.
5
Separate the Bottom of the PTC as shown
6
Raise up the PTC Bottom.
7
Disassembly is complete.

3-6
3. Disassembly and Reassemble
How to reassembly
Description Picture Description Refer
1
Attach the PTC Bottom rst to the Panel.
2
Secure the plastic latch on the left and right
side of the PTC as shown.

3-7
3. Disassembly and Reassemble
Description Picture Description Refer
3
Visually inspect the spacing between the
PTC and the Panel for equal clearance.
CAUTION
Combine to stick the PTC Rib into the
middle mold.

3-8
3. Disassembly and Reassemble
Description Picture Description Refer
4
Assembly is complete.

ANNEX. Exploded View & Part List [UN58J5190AFXZA IS01]
1-1. Exploded View
1-1-1. Parts List
No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN95-01724A PRODUCT LCD-INX; v580HJ1,CY-HH058BGNV1H/V 1 SA
1-1 BN96-33358A ASSY CHASSIS TOP P; Y14 F-LED 58,PC+ABS+G 1 SA
2 BN96-30902X ASSY BOARD P-FUNCTION; 58H5203,Function A 1 SA
3 BN44-00787A DC VSS-LED TV PD BD; L58GFB_ESM,L58GFB_ES 1 SA
4 BN94-10553A ASSY PCB MAIN; UN58J5190AFXZA 1 SA
5 BN61-11153A HOLDER-SIDE AV; UH5203,HIPS,UO 1 SNA
6 BN96-39100A ASSY COVER P-REAR; 58J5202,USA 1 SA
7 BN61-07962B BRACKET-STNAD LINK; UE6030 55",SECC,T1.6, 1 SA
8 BN96-33524A ASSY GUIDE P-STAND; UH5200 58,PC+G/F20%,B 1 SA
9 BN96-33225B ASSY STAND P-BASE; UH5200 58",ABS,HB,BLK 1 SA
ANNEX-1
ANNEX. Exploded View & Part List

Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UN58J5190AFXZA (IS01)
1 BN90-05304X ASSY W/I;UN40F6400AFXZA 1 SNA
0.2 BN81-08159Z PART SET-ELEC W/I;UF**,UH**,UG**,ELEC 1 SNA
0.2 BN81-09500R PART SET-MECH W/I;UH5H,U58HF* 1 SNA
1 S001A BN90-06123A ASSY STAND;UH5200 58" 1 SNA
0.2 SB04A BN96-33225B ASSY STAND P-BASE;UH5200 58",ABS,HB,BLK 1 SA
..3 SCREW 6001-003041 SCREW-MACHINE;FH,+,M4,L8,ZPC(BLK),SWRCH1 5 SA
..3 SCREW 6003-001782 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 4 SA
..3 6902-000518 BAG PE;HDPE/PE FOAM/HDPE,T0.015/T0.05,W8 1 SNA
..3 BN60-01083A SPACER-FOAM;PE FORM,30000mm(1PC),Dark Gr 1 SNA
..3 BN61-10856A BRACKET-STAND,BASE;H5200,58,SECC,2.0 1 SNA
..3 BN61-10895A GUIDE-STAND,NECK;UH5200 58",PC+GF20%,BK0 1 SNA
..3 CCM1 BN63-02183E SHEET-COVER;Rhcm,PE,T0.04,750mm,200M,HB, 1 SNA
..3 BN63-12618B COVER-STAND BASE;UH5200 58",ABS,HB,BLK 1 SNA
..3 BN67-00327D RUBBER-FOOT;STAND,SILICON,13*13,T2,GRAY( 6 SNA
0.2 SG01A BN96-33524A ASSY GUIDE P-STAND;UH5200 58,PC+G/F20%,B 1 SA
..3 0203-001602 TAPE-OPP MASKING;#232,0.14,15,50000,YEL 0 SNA
..3 6902-000110 BAG PE;LDPE,T0.05,W250,L400,TRP,2,N 1 SNA
..3 SG03 BN61-10894A GUIDE-STAND;UH5200 58",PC+GF20%,BK0007,V 1 SNA
..3 BN68-05381A LABEL-BASE;Art Paper 100G,T0.08,20mmX50m 1 SNA
..3 BN96-29120C ASSY ACCESSORY-SCREW;6003-001782,8EA,LED 1 SNA
...4 SCREW 6003-001782 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 8 SA
...4 BN69-09241C BAG SCREW;LDPE,0.05,70,90,TRP,Vinyl pack 1 SNA
1 R001A BN90-06169S ASSY COVER REAR;UH5203 58" 1 SNA
0.2 SCREW 6001-002755 SCREW-MACHINE;BH,+,M3,L6,ZPC(BLK),SWRCH1 4 SA
0.2 SCREW 6003-001782 SCREW-TAPTYPE;BH,+,B,M4,L12,ZPC(BLK),SWR 16 SA
0.2 R001A BN96-39100A ASSY COVER P-REAR;58J5202,USA 1 SA
..3 R001 BN63-12619N COVER-REAR;H5203 58",HIPS,V0,BLK,MASTER 1 SNA
..3 T0071 BN64-02772G INLAY-TERMINAL;J6200,PC,T0.25,W165.4,L14 1 SNA
1 BN91-12976A ASSY LCM-AMLCD;BN95-01724A,CY-HH058BGNV1 1 SNA
0.2 PANEL BN95-01724A PRODUCT LCD-INX;v580HJ1,CY-HH058BGNV1H/V 1 SA
..3 SCREW 6001-002756 SCREW-MACHINE;BH,+,M3,L6,ZPC(WHT),SWRCH1 4 SA
..3 SCREW 6001-002757 SCREW-MACHINE;BH,+,M3,L4,ZPC(WHT),SWRCH1 6 SA
..3 CB20 BN61-07953A BRACKET-WALL;UE5000 46",EGI-SECC PL,T1.2 4 SA
..3 BN61-07962B BRACKET-STNAD LINK;UE6030 55",SECC,T1.6, 1 SA
..3 M0131 BN63-00520A GASKET;APPOLO_PAL,Conductive Fabric,0.13 4 SNA
..3 BN68-05595A LABEL-STICKER;Art Paper 100G,T0.2,80mmX2 1 SNA
..3 BN90-05987A ASSY MISC-BLU;MEGA MODEL,CY-HH058BGNV1V 1 SNA
...4 BN02-00043C TAPE ETC-SHEET FIXING;F-LED 32/40/46,3M 3 SNA
...4 BN02-00102B TAPE-FILAMENT;#8917,0.15,25,50,WHITE 3 SNA
...4 BN61-07891A SUPPORT-PLATE;Y12 FULL LED,PC,V2,CLEAR 9 SNA
...4 BN61-10791A LGP-DIFFUSESR PLATE;58inch Mega, Diffuse 1 SNA
...4 BN62-00635A INSULATION-SOURCE PCB R;Y14 58",PC,0.25, 1 SNA
...4 BN62-00635B INSULATION-SOURCE PCB L;Y14 58",PC,0.25, 1 SNA
ANNEX-2
ANNEX. Exploded View & Part List
2-1. Electrical Parts List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 BN63-12638A SHEET-COMPLEX;MEGA 58inch G230-54,PET,0. 1 SNA
...4 BN63-12640A SHEET-REFLECTOR;MEGA 58inch UXJP175,PET, 1 SNA
...4 BN96-32771A ASSY LED BAR P;58inch Left,Direct LED PK 6 SNA
...4 BN96-32772A ASSY LED BAR P;58inch Right,Direct LED P 6 SNA
...4 BN96-33354A ASSY CHASSIS BOTTOM P;Y14 F-LED 58,MEGA, 1 SNA
....5 AK63-00675A GASKET;BD-C7500,Conductive Fabric,2mm,5m 4 SNA
....5 BN02-00040C TAPE DOUBLE FACE-D-PLATE;F-LED ALL,MKT50 2 SNA
....5 BN02-00074D TAPE PET;58H5200,PET,T0.05,W40,L40,BLK,3 4 SNA
....5 BN02-00102B TAPE-FILAMENT;#8917,0.15,25,50,WHITE 0 SNA
....5 BN02-00134E TAPE ETC-SHEET FIXING;SFLED 32/40/46/55/ 6 SNA
....5 BN02-00324A TAPE-METAL FOIL;Y14 4K,T0.085,W25,NTR,3M 0 SNA
....5 BN02-00352B TAPE OPP;PET,T0.05,W30,L50M,BLK,ULNO.E16 0 SNA
....5 BN02-00352D TAPE OPP;PET,T0.05,W20,L50M,BLK,ULNO.E16 0 SNA
....5 EC13 BN39-01910A LEAD CONNECTOR;58inch Mega,Lead Connecto 1 SNA
....5 BN61-11027A HOLDER-SOURCE PCB;H4.2K 58",NYLON66,1.8T 4 SNA
....5 BN62-00501M INSULATION-PD BOARD 58;Y14 H4.2K 58,PC,0 1 SNA
....5 CC02 BN64-02743A CHASSIS-BOTTOM;Y14 F-LED 58",EGI-SECC AG 1 SNA
...4 BN96-33355A ASSY FRAME P-MOLD MIDDLE U;Y14 F-LED 58, 1 SNA
....5 BN61-10803A FRAME-MOLD MIDDLE U;Y14 F-LED 58",PC+G/F 1 SNA
...4 BN96-33356A ASSY FRAME P-MOLD MIDDLE D;Y14 F-LED 58, 1 SNA
....5 BN60-00744A SPACER-RUBBER;Y13 F-LED SLIM,SH-0140U+AT 1 SNA
....5 BN60-00999E SPACER-PANEL(UD);14 ENTRY MODEL 58",SI,6 2 SNA
....5 BN61-10804A FRAME-MOLD MIDDLE D;Y14 F-LED 58",PC+G/F 1 SNA
...4 BN96-33357A ASSY FRAME P-MOLD MIDDLE LR;Y14 F-LED 58 2 SNA
....5 BN60-00999F SPACER-PANEL(LR);14 ENTRY MODEL 58" & quot 2 SNA
....5 BN61-10805A FRAME-MOLD MIDDLE LR;Y14 F-LED 58",PC+G/ 2 SNA
..3 FL06 BN96-30782D ASSY CABLE P-FFC;H7000,FFC,NH,68mm짹1,60 2 SNA
..3 BN96-32743A ASSY OPEN CELL;V580HJ1-PD6,CY-HH058BGNV1 1 SNA
...4 BN81-10743A A/S-A/S-IC DRIVER SOURCE;INX 58 FHD 60Hz 1 SNA
...4 BN81-10744A A/S-A/S-IC DRIVER GATE;INX 58 FHD 60Hz,6 1 SNA
...4 BN81-10745A A/S-A/S-ASSY PCB-SOURCE (XR);INX 58 FHD 1 SNA
...4 BN81-10746A A/S-A/S-ASSY PCB-SOURCE (XL);INX 58 FHD 1 SNA
...4 BN81-10747A A/S-A/S-POLARIZER-C/F;INX 58 FHD 60Hz,41 1 SNA
...4 BN81-10748A A/S-A/S-POLARIZER-TFT;INX 58 FHD 60Hz,41 1 SNA
..3 TCON BN96-32745A ASSY T CON P;V580HJ1-PE6,V580HJ1-PE6,10b 1 SA
..3 TC01A BN96-33358A ASSY CHASSIS TOP P;Y14 F-LED 58,PC+ABS+G 1 SA
...4 BN60-00667K SPACER-GASKET;Y13 SF-LED,CONDUCTIVE FABR 3 SNA
...4 BN60-00715A SPACER-TOP,CORNER;Y13 Slim F-LED,CONDUCT 4 SNA
...4 BN60-00746A SPACER-TOP;GASKET+PET,L1000M,GOLD,T0.2,W 4 SNA
...4 BN60-01005G SPACER-TOP (LR);Y14 ENTRY MODEL 58",EVA, 2 SNA
...4 AS080 BN63-07229K SHEET-COVER;rose70",SI,T0.052,W36mm,100M 1 SNA
...4 BN63-10182A SHEET-COVER;Y12 F-LED,SHEET*,0.052,33mm, 3 SNA
...4 AC157 BN64-02744A CHASSIS-TOP;Y14 F-LED 58",PC+ABS+G/F15%, 1 SNA
...4 T0382 BP61-00509C HOLDER-CARE;PJT,ACRYL,T0.25,W20.0mm,L33M 0 SNA
1 BN91-13443P ASSY SHIELD;UH5200 58" 1 SNA
0.2 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 9 SA
0.2 BN02-00102K TAPE FILAMENT;PE,0.15,25,55,WHITE 0 SNA
ANNEX-3
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
0.2 EC13 BN39-01889K LEAD CONNECTOR;UE50H6300,Flat Connector, 1 SA
0.2 M-F BN39-01903N LEAD CONNECTOR-FUNCTION;58H5203,Lead Con 1 SA
0.2 P001A BN44-00787A DC VSS-LED TV PD BD;L58GFB_ESM,L58GFB_ES 1 SA
0.2 WIFI BN59-01174A NETWORK-WIFI MODULE;WIDT-30Q,Internal Wi 1 SA
0.2 HOLDER-
LED SCREW BN61-09175B SCREW-MACHINE;BH,+,M3,L10,ZPC(WHT),SWRCH 1 SA
0.2 BN62-00670A INSULATION;H5203,PET,0.1,54,54,BLK 1 SNA
0.2 M0131 BN63-00520A GASKET;APPOLO_PAL,Conductive Fabric,0.13 1 SNA
0.2 M0131 BN63-00985A GASKET;DS15AS,Conductive Fabric,1.5mm,4m 1 SNA
0.2 AS080 BN63-07229A SHEET-COVER;rose70",SI,T0.052,W50mm,100M 0 SNA
0.2 FB01A BN96-30902X ASSY BOARD P-FUNCTION;58H5203,Function A 1 SA
0.2 SPK BN96-32113E ASSY SPEAKER P-H5203 58";6ohm,10W,H5203 1 SA
0.2 FL06 BN96-33236H ASSY CABLE P-FFC;58H5203,FFC,NH,500mm,51 1 SA
1 M0017 BN91-16525A ASSY CHASSIS;UN58J5190AFXZA 1 SNA
0.2 M0014 BN94-10553A ASSY PCB MAIN;UN58J5190AFXZA 1 SA
..3 BN61-11153A HOLDER-SIDE AV;UH5203,HIPS,UO 1 SNA
..3 AH020 BN62-00659A HEAT SINK;UN55H6203AFXZA,A6063,BLACK 1 SNA
..3 T0527 BN68-00513A LABEL-E,PASS;ALL MODEL,YUPO(110G),BLACK, 1 SNA
..3 BN97-09494A ASSY DRM-KEY;HU7*,NT14U,US 1 SNA
...4 BN46-00109H KEY CODE-CERTIFI;MAC,TV/AV,General 1 SNA
...4 BN46-00110P KEY CODE-CERTIFI;MIRACAST(HDCP2.2), TV 1 SNA
..3 BN97-10423A ASSY SMD;LED TV 1 SNA
...4 0202-001976 SOLDER-CREAM;LST-309M-K21,20~38um,96.5Sn 3 SNA
...4 0403-001783 DIODE-ZENER;BZB84-C6V2,5.8/6.6V,300mW,SO 2 SNA
...4 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 2 SA
...4 0406-001200 DIODE-TVS;RCLAMP0504F,6/-/-V,150W,SC-70 2 SA
...4 0406-001628 DIODE-TVS;AOZ8804ADI,6/-/-V,150W,SLP2510 1 SA
...4 0406-001635 DIODE-TVS;SMF5.0A,6.4V, 6.7V, 7V,200W,SM 5 SA
...4 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, 1 SNA
...4 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 2 SC
...4 0505-002560 FET-SILICON;AO6415,P,-20V,-3.3A,0.15ohm, 1 SA
...4 0505-002598 FET-SILICON;AP2317GN,P,-20V,-4.2A,0.052o 1 SA
...4 0505-002893 FET-SILICON;AO4801AS,P,-30V,-5A,2W,SOIC- 1 SA
...4 0505-003397 FET-SILICON;2N7002K,N,60V,380mA,1.19ohm, 5 SA
...4 1001-001860 IC-ANALOG SWITCH;NX5L2750CGU,QFN,10P,1.4 1 SNA
...4 1006-001576 IC-DRIVER/RECEIVER;MAX3221ECPWR,TSSOP,16 1 SA
...4 1103-001487 IC-EEPROM;AT24C256C-SSHL-T,256Kbit,32Kx8 1 SA
...4 1105-002529 IC-DDR3 SDRAM;K4B4G1646D-BCK0,DDR3 1600, 2 SA
...4 1201-003690 IC-AUDIO AMP;TAS5747PHPR,QFP,48P,DUAL,PL 1 SA
...4 1203-004363 IC-VOL. DETECTOR;SOT-23,3Z30,2.9x1.6mm,P 1 SA
...4 1203-006017 IC-VOL. DETECTOR;RT9824GJ8,TSOT23,8P,2.9 1 SA
...4 1203-006130 IC-POSI.FIXED REG.;S-1172B25-U5T1G,SOT-8 1 SA
...4 1203-007238 IC-PWM CONTROLLER;TPS54427,DDA,8P,4.8x3. 1 SNA
...4 1203-007242 IC-POSI.ADJUST REG.;G2992BP11U,SOP-8,8P, 1 SA
...4 1203-007984 IC-DC/DC CONVERTER;AOZ3015PI,SO-8,8P,6.2 1 SA
...4 1203-008104 IC-POSI.FIXED REG.;S-13A1D18-E800,HSOP,8 2 SNA
...4 1203-008105 IC-POSI.FIXED REG.;S-13A1D33-E800,HSOP,8 1 SNA
ANNEX-4
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 1203-008118 IC-DC/DC CONVERTER;AOZ3013PI,SO-8,8P,4.9 3 SA
...4 1204-003558 IC-VIDEO PROCESS;SENK15,HS-TFBGA,626P,26 1 SA
...4 1205-004447 IC-SWITCH;TPS2051CDBVR,SOT23-5,5P,3x1.65 1 SA
...4 1205-004983 IC-SWITCH;BD82032FVJ,TSSOP-B8J,8P,3.0x4. 1 SA
...4 1405-001271 VARISTOR;35V,20Vdc,5A,1.0x0.5mm,TP,100V, 17 SA
...4 2007-000138 R-CHIP;100ohm,5%,1/16W,TP,1005 22 SA
...4 2007-000140 R-CHIP;1Kohm,5%,1/16W,TP,1005 9 SA
...4 2007-000141 R-CHIP;2.2Kohm,5%,1/16W,TP,1005 6 SA
...4 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 26 SA
...4 2007-000148 R-CHIP;10Kohm,5%,1/16W,TP,1005 19 SA
...4 2007-000153 R-CHIP;22Kohm,5%,1/16W,TP,1005 6 SNA
...4 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 15 SNA
...4 2007-000162 R-CHIP;100Kohm,5%,1/16W,TP,1005 1 SA
...4 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 9 SA
...4 2007-000172 R-CHIP;10ohm,5%,1/16W,TP,1005 2 SNA
...4 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 16 SA
...4 2007-000256 R-CHIP;1.6Kohm,1%,1/10W,TP,1608 3 SA
...4 2007-000265 R-CHIP;1.8Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-000583 R-CHIP;22Kohm,1%,1/10W,TP,1608 3 SA
...4 2007-000691 R-CHIP;3.3Mohm,5%,1/10W,TP,1608 1 SA
...4 2007-000726 R-CHIP;300ohm,1%,1/10W,TP,1608 2 SA
...4 2007-000775 R-CHIP;33Kohm,5%,1/16W,TP,1005 1 SNA
...4 2007-000803 R-CHIP;36Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 8 SA
...4 2007-001125 R-CHIP;68Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-001168 R-CHIP;75ohm,5%,1/4W,TP,3216 1 SA
...4 2007-001288 R-CHIP;18ohm,5%,1/16W,TP,1005 4 SA
...4 2007-003022 R-CHIP;62ohm,5%,1/16W,TP,1005 26 SNA
...4 2007-007001 R-CHIP;3.9Kohm,5%,1/16W,TP,1005 1 SA
...4 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 4 SNA
...4 2007-007108 R-CHIP;43.2Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007136 R-CHIP;4.7Kohm,1%,1/16W,TP,1005 18 SNA
...4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 16 SA
...4 2007-007156 R-CHIP;1ohm,5%,1/16W,TP,1005 2 SA
...4 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 3 SNA
...4 2007-007309 R-CHIP;12Kohm,1%,1/16W,TP,1005,0.35T 3 SA
...4 2007-007311 R-CHIP;22Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007312 R-CHIP;20Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 15 SA
...4 2007-007470 R-CHIP;7.5Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007517 R-CHIP;240ohm,1%,1/16W,TP,1005 2 SNA
...4 2007-007538 R-CHIP;56Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007942 R-CHIP;1Mohm,1%,1/16W,TP,1005 1 SNA
...4 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 13 SA
...4 2007-008117 R-CHIP;2.7Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-008275 R-CHIP;30Kohm,1%,1/16W,TP,1005 2 SNA
...4 2007-008298 R-CHIP;49.9ohm,1%,1/16W,TP,1005 4 SA
ANNEX-5
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 2007-008779 R-CHIP;0ohm,1%,1/16W,TP,1005 3 SA
...4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4Points,TP,10 2 SA
...4 2011-001506 R-NETWORK;10Kohm,5%,1/16W,L,CHIP,4P,TP,1 1 SA
...4 2011-001527 R-NETWORK;4.7Kohm,5%,1/16W,L,CHIP,4P,TP, 2 SA
...4 2011-001587 R-NETWORK;100ohm,5%,1/16W,L,CHIP-V,4P,TP 2 SA
...4 AD480 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 4 SA
...4 AD480 2203-000278 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,TP,1005 1 SA
...4 AD480 2203-000330 C-CER,CHIP;0.012nF,5%,50V,C0G,TP,1005 2 SA
...4 AD480 2203-000359 C-CER,CHIP;0.15nF,5%,50V,C0G,TP,1005,0.5 1 SA
...4 AD480 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 15 SA
...4 AD480 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 4 SA
...4 AD480 2203-000575 C-CER,CHIP;220nF,10%,25V,X7R,TP,2012 6 SA
...4 AD480 2203-000585 C-CER,CHIP;0.22nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-000627 C-CER,CHIP;0.022nF,5%,50V,C0G,TP,1005 3 SNA
...4 AD480 2203-000679 C-CER,CHIP;0.027nF,5%,50V,C0G,TP,1005 2 SA
...4 AD480 2203-000714 C-CER,CHIP;3.3nF,10%,50V,X7R,TP,1005 5 SA
...4 AD480 2203-000812 C-CER,CHIP;0.033nF,5%,50V,C0G,TP,1005 4 SA
...4 AD480 2203-000940 C-CER,CHIP;0.47nF,10%,50V,X7R,TP,1005 2 SA
...4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,TP,1005 20 SNA
...4 AD480 2203-002711 C-CER,CHIP;100nF,10%,25V,X7R,TP,1608 6 SA
...4 AD480 2203-005249 C-CER,CHIP;100nF,10%,50V,X7R,TP,1608 5 SA
...4 AD480 2203-005344 C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,0.5T 1 SNA
...4 AD480 2203-005968 C-CER,CHIP;4.7nF,10%,50V,X7R,TP,1005,0.5 3 SNA
...4 AD480 2203-006048 C-CER,CHIP;100nF,10%,10V,X7R,TP,1005 93 SA
...4 AD480 2203-006126 C-CER,CHIP;47nF,10%,16V,X7R,TP,1005 13 SNA
...4 AD480 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,TP,1005,0.5 17 SA
...4 AD480 2203-006324 C-CER,CHIP;2200nF,10%,10V,X5R,TP,1608 6 SA
...4 AD480 2203-006348 C-CER,CHIP;1000nF,10%,25V,X5R,TP,1608,0. 2 SA
...4 AD480 2203-006361 C-CER,CHIP;10000nF,10%,10V,X5R,TP,2012 26 SC
...4 AD480 2203-006474 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,2012 33 SA
...4 AD480 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 13 SNA
...4 AD480 2203-006824 C-CER,CHIP;4700nF,10%,10V,X5R,TP,1608 5 SNA
...4 AD480 2203-006838 C-CER,CHIP;2200nF,10%,6.3V,X5R,TP,1005 1 SA
...4 AD480 2203-006841 C-CER,CHIP;1000nF,10%,16V,X5R,TP,1005 4 SNA
...4 AD480 2203-006842 C-CER,CHIP;0.47nF,5%,50V,C0G,TP,1005 2 SNA
...4 AD480 2203-006890 C-CER,CHIP;10000nF,20%,6.3V,X5R,TP,1608 26 SNA
...4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012,1 5 SNA
...4 AD480 2203-007269 C-CER,CHIP;22000nF,20%,10V,X5R,TP,2012(2 2 SA
...4 AD480 2203-007513 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608,0 4 SA
...4 AD480 2203-007544 C-CER,CHIP;100nF,10%,50V,X7R,TP,1005,0.5 10 SA
...4 2409-001213 C-ORGANIC,SMD;150uF,20%,6.3V,-,TP,3.5x2. 2 SNA
...4 2503-001051 C-NETWORK;100nFx4,20%,16V,2012 1 SA
...4 2703-000158 INDUCTOR-SMD;1uH,10%,2012,.4Ohm,50mA,45, 4 SA
...4 2703-000213 INDUCTOR-SMD;470nH,10%,1608,1.35Ohm,35mA 1 SA
...4 2703-001938 INDUCTOR-SMD;56nH,5%,1005,1.5Ohm,200mA,1 2 SA
...4 2703-003713 INDUCTOR-SMD;1.5uH,20%,7366,0.015ohm,700 2 SA
...4 2703-003790 INDUCTOR-SMD;4.7uH,20%,8080,0.025ohm,450 1 SA
ANNEX-6
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 2703-003930 INDUCTOR-SMD;4.7uH,20%,5050,0.072Ohm,245 4 SA
...4 2703-004145 INDUCTOR-SMD;2.2uH,20%,6.5 x 6.9mm,0.20o 1 SNA
...4 2703-004462 INDUCTOR-SMD;3.3uH,20%,10x10x8mm,0.0082O 1 SA
...4 2801-003773 CRYSTAL-SMD;12MHz,30ppm,28-AAN,20pF,50oh 1 SA
...4 3301-000314 BEAD-SMD;120ohm,1608,TP,120ohm/100MHz 6 SNA
...4 3301-001364 BEAD-SMD;1000ohm,1608,TP,1085ohm/108MHz, 2 SNA
...4 3301-002039 BEAD-SMD;26ohm,1608,TP 35 SA
...4 3601-001374 FUSE-SURFACE MOUNT;32V,5A,FAST-ACTING,PL 2 SA
...4 3701-001856 CONNECTOR-HDMI;19P,FEMALE,AU,0.5mm,BLK,S 2 SA
...4 3707-001106 CONNECTOR-OPTICAL;STRAIGHT W/L,SPDIF 1 SA
...4 3708-003073 CONNECTOR-FPC/FFC/PIC;51P,0.5mm,SMD,AU,N 1 SA
...4 EH01 3711-008131 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5mm,AN 1 SA
...4 EH01 3711-008453 HEADER-BOARD TO CABLE;BOX,18P,2R,2mm,ANG 1 SA
...4 EH01 3711-008558 HEADER-BOARD TO CABLE;BOX,26P,2R,1.25mm, 1 SA
...4 3722-003226 JACK-PHONE;7P/1C,SN,BLK 1 SA
...4 3722-003229 JACK-MODULAR;8P/8C W/L,Y,STRAIGHT,N,Au,1 1 SA
...4 3722-003248 JACK-USB;4P/1C(W/L),NI/PD/AU/SN,BLK,STRA 2 SA
...4 JACK PIN 3722-003546 JACK-PIN;5P+Screw hole,NI+SN,G,Y/BLU/RED 1 SA
...4 3722-003667 JACK-PHONE;1P/7C,SN/NI,BLK,STRAIGHT,3.6P 1 SA
...4 ET01 BN40-00308A TUNER;GVTH-F16B/FNS,GVTH-F16B/FNS,ATSC H 1 SNA
...4 BN41-02275A PCB MAIN;H5203,FR-4,4,A,1.2,192*122,1 1 SNA
...4 BN68-04746A LABEL-SMD;all model,POLY*,25.4mm x 9.53m 1 SNA
...4 BN97-10110B ASSY MICOM;T-N14M6AUSS,J6200,NORTH AMERI 1 SNA
....5 1107-002226 IC-NOR FLASH;W25Q40CLSSIP,4Mbit,SOIC,8P, 1 SA
...4 BN97-10579A ASSY MICOM;T-N14M6AKUC,BN97-10110A,J6200 1 SNA
....5 1107-002374 IC-EMMC;KLM4G1FEPD-B031,4Gbyte,BGA,153P, 1 SNA
1 BN92-15960A ASSY P/MATERIAL;UH5200 58" 1 SNA
0.2 6902-001960 BAG ROLL;HDPE/PE FOAM+HDPE,T0.015/T0.5,W 2 SNA
0.2 6922-000013 BAND;PP,W18,L2300/L2900,TRP 1 SNA
0.2 BH69-00418A WRAP;762,1828M,SAMEX FACTORY 2 SNA
0.2 BN02-00319B TAPE OPP;OPP,T0.05,W75,L800m,CLEAR 4 SNA
0.2 BN68-02422B LABEL-WARNING SHIPPING;ALL MODEL,A/P,T0. 1 SNA
0.2 BN69-09624A CUSHION-FRONT;UH6300-60,EPS 1 SNA
0.2 BN69-10618A CUSHION-SET;UH5200 58",EPS,Overseas 1 SNA
0.2 BN69-12806A PAD-ANGLE;40J6400,PAPER,5 mm,100,1500,YE 1 SNA
1 BN92-17030A ASSY LABEL;J5000 1 SNA
0.2 BN68-07568L LEAFLET-QSG;J5202,United States,ART*,62. 1 SNA
0.2 BN68-07705H LABEL-ENERGY;UN58J5190AFXZA,PET,T0.1,38, 1 SNA
0.2 BN74-00053G TAPE-PAPER;PAPER,3M2307,0.14T,W10,60M,WH 0 SNA
0.2 T0527 BP68-00052B LABEL-00,RATING;FPTV,PET,T0.05,93,73 1 SNA
1 ACCE1 BN92-17477P ASSY ACCESSORY;LED_J6K 1 SNA
0.2 BN96-38848Z ASSY ACCESSORY MANUAL/CABLE;LED TV 1 SNA
..3 T0268 3903-000853 CBF-POWER CORD;DT,UL/CSA,LP-11L,125V,7A, 1 SA
..3 4301-000103 BATTERY-ALKALINE;1.5V,750mAH,LR03,10.2x4 2 SNA
..3 6902-001962 BAG PE;LDPE,BIOBASED,T0.05,W400,L300,TRP 1 SNA
..3 BN59-01199F REMOCON-REMOCON;TM1240A,44,3.0V,TM1240A_ 1 SA
ANNEX-7
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
..3 HOLDER-
WIRE BN61-08370A HOLDER-WIRE STAND;26UE4000 GUIDE STAND,P 1 SA
..3 BN68-04972A MANUAL FLYER-12,REGULATORY GUI;ALL,SAMSU 1 SNA
..3 BN68-05723A LABEL-ACCESSORY;ALL MODELS,YUPO,0.2,20,7 1 SNA
..3 BN68-07181P MANUAL USERS-01;J5202,United States,W/P* 1 SNA
1 BN92-19443X ASSY BOX;LED TV 1 SNA
0.2 BH68-00697A LABEL BOX-00;ALL MODEL,ART PAPER 90G,60, 1 SNA
0.2 BN69-11019N BOX UNIT;58J5190-SS,CB,A-01,DW3,W1555,D1 1 SNA
ANNEX-8
ANNEX. Exploded View & Part List
