Samsung C103FL User manual

Code No.: DE68-02798A
MICROWAVE OVEN
Owner’s Instructions and Cooking Guide
C103FL
“Quick” Look-up Guide...........................................................................2
Oven.......................................................................................................2
Control Panel .........................................................................................3
Accessories............................................................................................3
Using this Instruction Booklet.................................................................4
Safety Precautions.................................................................................4
Installing Your Microwave Oven.............................................................6
Setting the Time.....................................................................................6
Checking that Your Oven is Operating Correctly...................................7
Setting a Standing Time.........................................................................7
How a Microwave Oven Works..............................................................8
What to Do if You are in Doubt or You have a Problem ........................8
Cooking/Reheating.................................................................................9
Power Levels and Time Variations.........................................................9
Stopping the Cooking.............................................................................9
Adjusting the Cooking Time.................................................................10
Selection and Change of Weight Unit..................................................10
Using the Auto Cook Feature...............................................................10
Using the Auto Reheat Feature............................................................12
Using the Power Defrost Feature.........................................................13
Using the Indian Recipe Feature..........................................................14
Multistage Cooking...............................................................................15
Fast Preheating the Oven ....................................................................16
Cooking by Convection ........................................................................16
Grilling..................................................................................................17
Choosing the Heating Element Position ..............................................17
Choosing the Accessories....................................................................18
Combining Microwaves and the Grill....................................................18
Combining Microwaves and Convection..............................................19
Using the Deodorize Feature...............................................................20
Safety-locking Your Microwave Oven..................................................20
Switching the Beeper Off .....................................................................20
Using the Memory Cook Feature.........................................................20
Cookware Guide...................................................................................21
Cooking Guide......................................................................................22
Cleaning Your Microwave Oven...........................................................32
Storing and Repairing Your Microwave Oven......................................33
Technical Specifications.......................................................................33
jXWZmsniUGGwGXGG{SGvG`SG WWZGG^a[^Ght

2
GB
“Quick” Look-up Guide
I want to cook some food
I want to add an extra 30 seconds
I want to Power defrost some food
Oven
1. Place the food in the oven.
Press the
Microwave ( ) button.
2. Press the Microwave( ) button until the appropriate
power level is displayed.
3. Select the cooking time by pressing the 10min, 1min and
10s buttons as required.
4. Press Start button.
Result: Cooking starts
◆
When cooking has finished, the oven will beep
and flash “0” four times. The oven will then
beep one time per minute.
Leave the food in the oven.
Press
+30s button one or more times for each extra 30
seconds that you wish to add.
1. Place the frozen food in the oven.
Press the
Power Defrost ( ) button.
2. Select the food category by pressing the Power
Defrost
() button, until the desired food category is
selected.
3. Select the weight by pressing the
() and () buttons as
required.
4. Press Start button.
Result: Defrosting starts
◆
When cooking has finished, the oven will beep
and flash “0” four times. The oven will then
beep one time per minute.
VENTILATION HOLES
DOOR LATCHES
DOOR
TURNTABLE
COUPLER
ROLLER RING SAFETY
INTERLOCK
HOLES
VENTILATION
HOLES
HEATING
ELEMENT
CONTROL PANE
L
DOOR
HANDLE
jXWZmsniUGGwG GG{SGvG`SG WWZGG^a[^Ght

3
GB
Control Panel Accessories
Depending on the model that you have purchased, you are supplied with
several accessories that can be used in a variety of ways.
1
2
3
4
5
6
7
8
9
10
13
12
14
15
16
17
20
19
18
1. DISPLAY
2. AUTO FAST PREHEAT
SELECTION BUTTON
3. CONVECTION BUTTON
4. MICROWAVE+CONVECTION
BUTTON
5. MICROWAVE BUTTON
6. GRILL BUTTON
7. MICROWAVE+GRILL BUTTON
8. TIME SETTING
9. UP/ DOWN BUTTON (Weight/
Serving/Time)
10. MORE/LESS BUTTON
11. STOP / CANCEL BUTTON
12. MEMORY BUTTON
13. CLOCK SETTING BUTTON
14. POWER DEFROST FEATURE
BUTTON
15. AUTO COOK FEATURE BUTTON
16. AUTO REHEAT FEATURE
BUTTON
17. INDIAN RECIPE FEATURE
BUTTON
18. HOLD TIMER BUTTON
19. DEODORIZE BUTTON
20. START / +30S BUTTON
11
1. Coupler , to be placed correctly over the motor shaft in the
base of the oven.
Purpose: The coupler rotates the turntable.
2. Roller ring, to be placed in the center of the oven.
Purpose: The roller ring supports the turntable.
3. turntable, to be placed on the roller ring with the center
fitting on to the coupler.
Purpose: The turntable serves as the main cooking
surface; it can be easily removed for cleaning.
4. Metal racks (High rack, Low rack), to be placed on the
turntable.
Purpose: The metal racks can be used to cook two
dishes at the same time. A small dish may be
placed on the turntable and a second dish on
the rack. The metal racks can be used in
grill, convection and combination cooking.
jXWZmsniUGGwGZGG{SGvG`SG WWZGG^a[^Ght

4
GB
Using this Instruction Booklet
Thank you for purchasing a SAMSUNG microwave oven. Your Owner’s
Instructions contains much valuable information on cooking with your
new microwave oven:
• Safety precautions
• Accessories and cookware
• Useful cooking tips
Inside the cover you will find a quick look-up guide explaining three basic
cooking operations:
• Cooking (microwave mode)
• Defrosting
• Adding an extra 30 seconds, if the dish is inadequately
cooked or requires additional reheating
At the end of the booklet you will find illustrations of the oven, and more
importantly the control panel, so that you can find the buttons more easily.
The illustrations in the step-by-step procedures use two different symbols.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
Failure to observe the following safety precautions may result in harmful exposure to
microwave energy.
(a) Under no circumstances should any attempt be made to operate the oven with
the door open or to tamper with the safety interlocks (door latches) or to insert
anything into the safety interlock holes.
(b) Do not place any object between the oven door and front face, orallow food or
cleaner residues to accumulate on sealing surfaces. Ensure that the door and
door sealing surfaces are kept clean by wiping after use with first a damp cloth
and then a final wipe with a soft dry cloth.
(c) Do not operate the oven if it is damaged until it has been repaired by a
qualified microwave service technician trained by the manufacturer.
It is particularly important that the oven door closes properly and that there is no
damage to the:
(1) Door, door seals and sealing surfaces
(2) Door hinges (broken or loose)
(3) Power cable
(d) The oven should not be adjusted or repaired by anyone other than a properly
qualified microwave service technician trained by the manufacturer.
Safety Precautions
IMPORTANT SAFETY INSTRUCTIONS.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
Before cooking food or liquids in your microwave oven, please check that
the following safety precautions are taken.
1. DO NOT use any metallic cookware in the microwave oven:
• Metallic containers
• Dinnerware with gold or silver trimmings
• Skewers, forks, etc.
Reason: Electric arcing or sparking may occur and may damage the oven.
2. DO NOT heat:
• Airtight or vacuum-sealed bottles, jars, containers. Ex) Baby food jars
• Airtight food. Ex) Eggs, nuts in shells, tomatoes
Reason: The increase in pressure may cause them to explode.
Tip: Remove lids and pierce skins, bags, etc.
3. DO NOT operate the microwave oven when it is empty.
Reason: The oven walls may be damaged.
Tip: Leave a glass of water inside the oven at all times. The water will
absorb the microwaves if you accidentally set the oven going when
it is empty.
4. DO NOT cover the rear ventilation slots with cloths or paper.
Reason: The cloths or paper may catch fire as hot air is evacuated from the
oven.
5. ALWAYS use oven gloves when removing a dish from the oven.
Reason: Some dishes absorb microwaves and heat is always transferred
from the food to the dish. The dishes are therefore hot.
6. DO NOT touch heating elements or interior oven walls.
Reason: These walls may be hot enough to burn skin even after cooking is
finished, oven though they do not appear to be so. Keep away from
hot spot. Do not allow inflammable materials to come into contact
with any interior area of the oven. Let the oven cool down first.
7. To reduce the risk of fire in the oven cavity
• Do not store flammable materials in the oven
• Remove wire twist ties from paper or plastic bags
• Do not use your microwave oven to dry newspapers
• If smoke is observed, keep the oven door closed and switch off or
disconnect the oven from the power supply.
☛✉
Important Note
jXWZmsniUGGwG[GG{SGvG`SG WWZGG^a[^Ght

5
GB
Safety Precautions (continued)
8. Take particular care when heating liquids and baby foods.
• ALWAYS allow a standing time of at least 20 seconds after the oven has
been switched off to allow the temperature to equalize.
• Stir during heating if necessary and ALWAYS stir after heating.
• To prevent eruptive boiling and possible scalding, you should stir before,
during, and after heating.
• In the event of scalding, follow these FIRST AID instructions :
* Immerse hand in cold water for at least 10 minutes.
* Cover with clean, dry dressing.
* Do not apply any creams, oils or lotions.
•NEVER fill the container to the top and choose a container that is wider at
the top than at the bottom to prevent the liquid from boiling over. Bottles
with narrow necks may also explode if overheated.
•ALWAYS check the temperature of baby food or milk before giving it to
the baby.
•NEVER heat a baby's bottle with the teat on, as the bottle may explode if
overheated.
• During microwave heating of beverages, there are results in delayed
eruptive boiling, therefore care has to be taken when handling the
container.
9. Be careful not to damage the power cable.
• Do not immerse power cable or plug in water and keep power cable away
from heated surfaces.
• Do not operate this appliance if it has a damaged power cable or plug.
10. Stand at arm’s length from the oven when opening the door.
Reason: The hot air or steam released may cause scalding.
11. Keep the inside of the oven clean.
• Clean the inside of the oven right after each use with a mild detergent
solution, but let the microwave oven cool down before cleaning in order to
avoid injury.
Reason: Food particles or spattered oils stuck to oven walls or floor can
cause the damage of painting and reduce the efficiency of the oven.
12. “Clicking” sound might be noticed while operating, especially in defrosting
mode.
Reason: When the power output is changing electrically, you may hear that
sound. This is normal.
13. If the microwave oven is operating without any load, the power will cut off
automatically for safety. After standing for over 30 min, you can operate the
oven normally.
• Do not worry is the oven continues to work after cooking has finished.
Reason: This product is designed to fan for some minutes, not operating
microwave oven(MWO), to cool down the inner electronic parts
when the stop button is pressed or the door is opened after finishing
cooking in case that the oven operates for some minutes in
cooking(MWO, GRILL, CONVECTION, MWO+GRILL, MWO+
CONVECTION). When cooking has finished, the oven will beep
and flash “0” four times. The oven will then beep one time per
minute.
IMPORTANT SAFETY INSTRUCTIONS
During cooking, you should look into the oven from time to time when food is being
heated or cooked in disposable containers of plastic paper or other combustible
material.
WARNING:
Do not use the door or door seals are damaged, the oven must not be operated until it
has been repaired by a competent person.
WARNING:
It is hazardous for anyone other than a comperent person to carry out any service or
repair operation which involves the removal of a cover which gives protection against
exposure to microwave energy.
WARNING:
Liquids and other foods must not be heated in sealed containers since they are liable
to explode.
WARNING:
Only allow children to use the oven without supervicion when adequate instructions
have been given so that the child is able to use the oven in a safe way and
understands the hazards of improper use.
WARNING:
Oven casing and door will get hot during convection and combination cooking.
☛ DO NOT operate the microwave oven without the coupler, roller ring
and turntable.
jXWZmsniUGGwG\GG{SGvG`SG WWZGG^a[^Ght

6
GB
Installing Your Microwave Oven
This microwave oven can be placed almost anywhere (kitchen work
surface or shelf, movable trolley, table).
☛Never block the air vents as the oven may overheat and
automatically switch itself off. It will remain inoperable until it has
cooled sufficiently.
☛ For your personal safety, plug the cable into a 3-pin, 230 Volt, 50Hz,
AC earthed socket. If the power cable of this appliance is damaged, it
must be replaced by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.
☛Do not install the microwave oven in hot or damp surroundings like
next to a traditional oven or radiator. The power supply specifications
of the oven must be respected and any extension cable used must be
of the same standard as the power cable supplied with the oven.
Wipe the interior and the door seal with a damp cloth before using
your microwave oven for the first time.
Setting the Time
Your microwave oven has an inbuilt clock. The time can be displayed in
either the 12-hour or 24-hour notation. You must set the clock:
• When you first install your microwave oven
• After a power failure
✉Do not forget to reset the clock when you switch to and from
summer or winter time.
1. When you install your oven, make sure there is adequate
ventilation for your oven by leaving at least 10 cm (4 inches)
of space behind, and on the sides of the oven and 20 cm (8
inches) of space above the oven and 85 cm (33 inches) of the
floor.
2. Remove all packing materials inside the oven.
Install the roller ring and turntable.
Check that the turntable rotates freely.
3. This microwave oven has to be positioned so that plug is
accessible.
20cm
above 10cm
behind
10cm on
the side
85 cm
of the floor 1. To display the time in Then press the Clock
the... button...
12-hour notation Once
24-hour notation Twice
2. Press the () and () buttons.
3. Press the Clock button.
4. Press the
() and () buttons to set the minute.
5. When the right time is displayed, press the Clock button to
start the clock.
Result: The time is displayed whenever you are not
using the microwave oven.
jXWZmsniUGGwG]GG{SGvG`SG WWZGG^a[^Ght

7
GB
Checking that Your Oven is Operating Correctly
The following simple procedure enables you to check that your oven is
working correctly at all times. If you are in doubt, refer to the section
entitled “What to Do if You are in Doubt or Have a Problem” on the page.
✉The oven must be plugged into an appropriate wall socket. The
turntable must be in position in the oven. If a power level other
than the maximum (100% - 900 W) is used, the water takes
longer to boil.
Open the oven door by pulling the handle on the right side of the door.
Place a glass of water on the turntable. Close the door.
Setting a Standing Time
The Hold Time can be used to set a standing time automatically (without
microwave cooking).
Press the Start button and set the time to 4 or 5 minutes, by
pressing the
Start button the appropriate number of times.
Result: The oven heats the water for 4 or 5 minutes.
The water should then be boiling.
1. Press the Hold Timer button.
Result: The following indication isdisplayed :
(Hold/Delay mode)
2.
Set the grilling time by pressing the 10min,1min and 10s
buttons .
3. Press Start button.
Result: The oven beeps when the standing time is over.
jXWZmsniUGGwG^GG{SGvG`SG WWZGG^a[^Ght

8
GB
How a Microwave Oven Works
Microwaves are high-frequency electromagnetic waves; the energy
released enables food to be cooked or reheated without changing either the
form or the colour.
You can use your microwave oven to:
• Defrost
• Reheat
•Cook
Cooking Principle
☛ As the centre of the food is cooked by heat dissipation, cooking
continues even when you have taken the food out of the oven.
Standing times specified in recipes and in this booklet must therefore
be respected to ensure:
• Even cooking of the food right to the centre
• The same temperature throughout the food
What to Do if You are in Doubt or You have a
Problem
Becoming familiar with a new appliance always takes a little time. If you
have any of the problems listed below, try the solutions given. They may
save you the time and inconvenience of an unnecessary service call.
◆The following are normal occurrences.
• Condensation inside the oven
• Air flow around the door and outer casing
• Light reflection around the door and outer casing
• Steam escaping from around the door or vents
◆The food is not cooked at all
• Have you set the timer correctly and pressed the Start button?
• Is the door closed?
• Have you overloaded the electric circuit and caused a fuse to blow or a
breaker to be triggered.
◆The food is either overcooked or undercooked
• Was the appropriate cooking length set for the type of food?
• Was an appropriate power level chosen?
◆Sparking and cracking occur inside the oven (arcing)
• Have you used a dish with metal trimmings?
• Have you left a fork or other metal utensil inside the oven?
• Is aluminium foil too close to the inside walls?
◆The oven causes interference with radios or televisions
• Slight interference may be observed on televisions or radios when the
oven is operating. This is normal.
* Solution: Install the oven away from televisions, radios and aerials.
• If interference is detected by the oven’s microprocessor, the display may
be reset.
* Solution: Disconnect the power plug and reconnect it. Reset the time.
◆“E3" message indicates
• The "E3" message is automatically activated prior to the microwave oven
overheating. Should the "E3" message be activated, then depress the
"Stop/Cancel" key to utilize the initialization mode.
If the above guidelines do not enable you to solve the problem, then
contact your local Samsung customer service centre.
Please have the following information read;
• The model and serial numbers, normally printed on the rear
of the oven
• Your warranty details
• A clear description of the problem
Then contact your local dealer or SAMSUNG aftersales service.
1. The microwaves generated by the magnetron reflected
at cavity and are distributed uniformly as the food
rotates on the turntable. The food is thus cooked
evenly.
2. The microwaves are absorbed by the food up to a
depth of about 1 inch (2.5 cm). Cooking then
continues as the heat is dissipated within the food.
3. Cooking times vary according to the container used
and the properties of the food:
• Quantity and density
• Water content
• Initial temperature (refrigerated or not)
jXWZmsniUGGwG_GG{SGvG`SG WWZGG^a[^Ght

9
GB
Cooking/Reheating
The following procedure explains how to cook or reheat food.
☛ ALWAYS check your cooking settings before leaving the oven
unattended.
Open the door. Place the food in the centre of the turntable. Close the
door. Never switch the microwave oven on when it is empty.
Quick Start:
✉If you wish to heat a dish for a short period of time at maximum
power (900W), you can also simply press the Start button once
for each 30 seconds of cooking time. The oven starts
immediately.
Power Levels and Time Variations
The power level function enables you to adapt the amount of energy
dissipated and thus the time required to cook or reheat your food,
according to its type and quantity. You can choose between six power
levels.
The cooking times given in recipes and in this booklet correspond to the
specific power level indicated.
Stopping the Cooking
You can stop cooking at any time so that you can:
• Check the food
• Turn the food over or stir it
• Leave it to stand
1. Press the Microwave ( ) button.
Result: The following indications are displayed:
(one-stage cooking)
(microwave mode)
2. Select the appropriate power level by pressing the
Microwave( ) button again until the corresponding
output power is displayed. Refer to the power level table
below for further details.
3. Set the cooking time by pressing the 10min, 1min and 10s
buttons.
Result: The cooking time is displayed.
4. Press the Start button.
Result: The oven light comes on and the turntable starts
rotating. Cooking starts and when it has
finished:
◆
The oven will beep and flash “0” four times.
The oven will then beep one time per minute.
✉If you would like to know the current Power
Level of the oven cavity, press Microwave()
button once. If you would like to change the
power level during cooking, press the
Microwave()button twice or more times to
select the desired power level.
Power Level Percentage Output
HIGH
MEDIUM HIGH
MEDIUM
MEDIUM LOW
DEFROST
LOW
100 %
67 %
50 %
33 %
20 %
11 %
900 W
600 W
450 W
300 W
180 W
100 W
If you select a... Then the cooking time must be...
Higher power level
Lower power level Decreased Increased
To stop the cooking... Then...
Temporarily Open the door.
Result: Cooking stops.
To resume cooking, close the door again and press
the
Start button.
Completely Press the Stop button.
Result: Cooking stops.
If you wish to cancel the cooking settings, press the
Stop button again.
jXWZmsniUGGwG`GG{SGvG`SG WWZGG^a[^Ght

10
GB
Adjusting the Cooking Time
You can increase the cooking time by pressing +30s button once for each
30seconds to be added.
• Check how cooking is progressing at any time simply by
opening the door
• Increase the remaining cooking time
Selection and Change of Weight Unit
The weight unit of this MWO is basically set in "Grams".
Using the Auto Cook Feature
The five Auto Cook( ) features include/provide pre-programmed
cooking times. You do not need to set either the cooking times or the power
level.
You can adjust the size of the serving by pressing the ( ) and ( ) buttons.
☛ Use only recipients that are microwave-safe.
Open the door. Place the food in the centre of the turntable. Close the
door.
To increase the cooking time of your food, press the Start
button once for each 30 seconds that you wish to add.
• Example: To add three minutes, press the Start button
six times.
1.
If you want to change the weight unit to " Pounds ",
Press the
Convection ( ) and Microwave ( ) buttons at
the same time for about one second.
Result: The letters "Oz" will appear in the display panel
and blink three times.
This means weight unit is set in "Pounds".
2. To set weight unit back to "Grams",
Press the Convection ( ) and Microwave ( ) buttons at
the same time for about one second.
Result: The letter "g" will appear in the display panel
and blink three times.
This means weight unit is set in "Grams".
1. Press the Auto Cook ( ) button.
2. Select the type of food that you are cooking by pressing
the Auto Cook( ) button. Refer to the table on the
following page for a description of the various pre-
programmed settings.
3. Select the size of the serving by pressing the
() and ()
buttons.
4. Increase or decrease the cooking time, if necessary, by
pressing the More/Less buttons respectively.
5. Press the Start button.
Result: The food is cooked according to the pre-
programmed setting selected.
◆
When cooking has finished, theovenwill beep
and flash “0” four times. The oven will then
beep one time per minute.
jXWZmsniUGGwGXWGG{SGvG`SG WWZGG^a[^Ght

11
GB
Using the Auto Cook Feature(continued)
The following table presents the various Auto Cook Programmes,
quantities, standing times and appropriate recommendations.
Programmes no 1 and 2 are running with microwave energy only.
Programmes no 5 are running with a combination of microwaves and
convection.
Programmes no 3 and 4 are running with a combination of microwaves
and grill.
Code Food Serving Size Standing
Time Recommendations
1 Vegetables
200-250 g
300-350 g
400-450 g
500-550 g
600-650 g
700-750 g
2-3 min. Weigh the vegetables after washing,
cleaning and cutting into similar size.
Put them into a glass bowl with lid.
Add 30 ml (2 tablespoons) water when
cooking for 200-250 g, add 45 ml
(3 tablespoons) for 300-450 g and add
60-75 ml (4-5 tables-poons) for
500-750 g.Stir after cooking.
When cooking higher quantities stir
once during cooking.
2 Peeled
Potatoes
300-350 g
400-450 g
500-550 g
600-650 g
700-750 g
2-3 min. Weigh the potatoes after peeling,
washing and cutting into a similar size.
Put them into a glass bowl with lid.
Add 45 ml (3tablesp-oons) water when
cooking 300-450g, add 60ml
(4 tablespoons) for cooking 500-750 g.
3 Roast Fish 200-300g
(1 pc)
400-500g
(1-2 pcs)
600-700g
(2 pcs)
800-900g
(2-3 pcs)
3 min. Brush skin of whole fish with oil and add
herbs and spices. Put fish side by side,
head to tail on rack. Turn over, as soon
as the beep sounds.
4 Chicken
Pieces
200-300g
(1pc)
400-500g
(2pcs)
600-700g
(3pcs)
800-900g
(3-4pcs)
2-3min. Brush the chicken pieces with oil and
spice them with pepper, salt and
paprika. Put them in a circle on the high
rack with the skin-side down.
Turn over, as soon as the beep sounds.
5 Roast
Lamb
900-1000 g
1200-1300 g
1400-1500 g
10-15min. Brush the lamb with oil and spices
(pepper only,saltshould be added after
roasting). Put it on the low rack with the
fat-side down. Turn over, when the oven
beeps. After roasting and during
standing time it should be wrapped in
aluminium foil.
jXWZmsniUGGwGXXGG{SGvG`SG WWZGG^a[^Ght

12
GB
Using the Auto Reheat Feature
The four Auto Reheat( ) features provide four pre-programmed
cooking times. You do not need to set either the cooking times or the power
level.
You can adjust the size of the serving by pressing the ( ) and ( ) buttons.
☛ Use only recipients that are microwave-safe.
Open the door. Place the food in the centre of the turntable. Close the
door.
The following table presents the various Auto Reheat Programmes,
quantities, standing times and appropriate recommendations.
Programmes no 1,2 and 3 are running with microwave energy only.
Programmes no 4 are running with a combination of microwaves and
convection.
1. Press the Auto Reheat ()button.
2. Select the type of food that you are cooking by pressing
the Auto Reheat ( ) button. Refer to the table on the
following page for a description of the various pre-
programmed settings.
3. Select the size of the serving by pressing the
() and ()
buttons.
4. Increase or decrease the cooking time, if necessary, by
pressing the More/Less buttons respectively.
5. Press the Start button.
Result: The food is cooked according to the pre-
programmed setting selected.
◆
When cooking has finished, the oven will beep
and flash “0” four times. The oven will then
beep one time per minute.
Code Food Serving Size Standing
Time Recommendations
1 Beverage
(room-
temperature)
150 ml
(1 cup)
300 ml
(2 cups)
450 ml
(3 cups)
600 ml
(4 cups)
1-2 mins Pour the liquid into ceramic cups
only and reheat uncovered. Place
one cup in the centre, 2 cups
opposite to each other and 3 or
4 cups in a circle.Leave them to
stand in the microwave oven.
Stir beverage before and after
standing time.
Be careful while taking the cups out
(see safety instructions for liquids).
2 Ready Meal
(chilled) 300 - 350 g 400 - 450 g
500 - 550 g
3min. Put on a ceramic plate and cover
with microwave cling film. This
programme is suitable for meals
consisting of 3 components
(e.g. meat with sauce, vegetables
and a side dish like potatoes, rice or
pasta).
3 Soup/Sauce
(chilled) 200 - 250 ml 300 - 350 ml
400 - 450 ml
500 - 550 ml
600 - 650 ml
700 - 750 ml
2 - 3min. Pour intoa deep ceramic soup plate
or bowl and cover with plastic lid
during heating.Stir the soup, as
soon as the oven beeps
(oven keeps operating and is
stopped, when you open the door).
Stir carefully before and after
standing time.
4 Frozen Pizza 300-400 g
450-550 g
600-700 g
- Place one frozen pizza (-18°C) on
the low rack, place two frozen
pizzas on the low and high rack
jXWZmsniUGGwGX GG{SGvG`SG WWZGG^a[^Ght

13
GB
Using the Power Defrost Feature
The Power Defrost ( ) feature enables you to defrost meat, poultry, fish,
bread , cake and fruit. The defrost time and power level are set
automatically. You simply select the programme and the weight.
☛ Use only containers that are microwave-safe.
Open the door. Place the frozen food on a ceramic in the centre of the
turntable. Close the door.
☛ You can also defrost food manually. To do so, select the microwave
function with a power level of 180 W. Refer to the section entitled
“Defrosting” on page 26 for further details.
The following table presents the various Power Defrost programmes,
quantities, standing times and appropriate recommendations. Remove
all kind of package material before defrosting.
Place meat, poultry and fish on a flat glass plate or on a ceramic plate,
arrange bread on kitchen paper.
1. Press the Power Defrost ( ) button.
2. Select the type of food that you are cooking by pressing
the Power Defrost ( ) button. Refer to the table on the
following page for a description of the various pre-
programmed settings.
3. Select the food weight by pressing the
() and ()
buttons.
4. Press Start button.
Result: ◆
Defrosting begins.
◆ The oven beeps through defrosting to remind
you to turn the food over.
5. Press the Start again to finish defrosting.
Result: When cooking has finished, the oven will beep
and flash “0” four times. The oven will then beep
one time per minute.
Code Food Serving
Size Standing Time Recommendations
1 Meat
200-2000g 20-90 min. Shield the edges with aluminium foil. Turn
the meat over, when the oven beeps. This
programme is suitable for meat, lamb, pork,
steaks, chops and minced meat.
2Poultry 200-2000g 20-90 min. Shield the leg and wing tips with aluminium
foil. Turn the poultry over, when the oven
beeps. This programme is suitable for
whole chicken as well as for chicken
pieces.
3Fish 200-2000g 20-60 min. Shield the tail of a whole fish with
aluminium foil. Turn the fish over, when the
oven beeps. This programme is suitable for
whole fishes as well as for fish fillets.
4 Bread 125-1000g 10-60 min. Put bread on a piece of kitchen paper and
turn over, assoon as the oven beeps (oven
keeps operating and is stopped, when you
open the door).
This programme is suitable for all kinds of
bread, sliced or whole, as well as for bread
rolls and baguettes. Arrange bread rolls in a
circle.
This programme is suitable for all kinds of
yeast cake, biscuit, cheese cake and puff
pastry.
It is not suitable for short/crust pastry, fruit
and cream cakes as well as for cake with
chocolate topping.
5Fruit 100-600g 5-20 min. Spread fruits evenly into a flat glass dish or
use a flat ceramic plate. This programme is
suitable for all kinds of fruit.
jXWZmsniUGGwGXZGG{SGvG`SG WWZGG^a[^Ght

14
GB
Using the Indian Recipe Feature
With the Indian Recipe feature, the cooking time is set automatically.
First, place the food in the centre of the turntable on rack and close the
door.
The following table presents Auto Programmes for types of food and
Indian Recipe which are favoured by children and for trendy finger
food. It contains its quantities, standing times and appropriate
recommendations.
Programmes no 1, 2, 3, 4, 5 and 6 are running with microwave energy
only.
1. Press the Indian Recipe button.
2. Select the type of food that you are cooking by pressing
the
Indian Recipe button. Refer to the table on the
following page for a description of the various pre-
programmed settings.
3. Press Start button.
Result: The food is cooked according to the auto-setting
selected.
◆
When cooking has finished, the oven will beep
and flash “0” four times. The oven will then
beep one time per minute.
Code Recipe Serving
Size Standing Time Ingredients Recommendations
1
Instant
Dhokla 8 pcs 3 min. Sooji (1/4 cup), Baisan ( 3/4 cup), Curd (1 cup),
Salt (1 tsp), Sugar (2 Tsp)
, Lemon juice(1Tsp),
Haldi(1/2 Tsp), Oil (1 Tsp)
, Eno salt (3/4 Tsp)
Mix basin, sooji, curd,
salt,sugar,lemon juice,
Haldi,oil & Eno salt in the
last. Pour intomicrowave
safe greased bowls
(Katories) or idli maker
with cover or lid.
2 Instant
Idli 8 pcs 3 min. Rawa Sooji(1 cup), Curd (1 cup),Heeng (1 pinch),
Eno salt (3/4 Tsp), Lemon
juice (1 Tsp), Roasted/
FriedMoongfali(optional),
Roasted Channa Dal
(optional), Green chillies
(1no)
Mix sooji, curd, salt,
heeng ,lemon juice,
Green chilli, Nut or dal
(roasted). Add Eno salt
last of all & pour into
microwave safe bowls
(katories) or idli maker.
3 Kadai
Paneer 200~250 gms 3 min. Paneer(250g), Capsicum (1 cut julliens), Fresh
Tomato (1 Chopped-
medium), Tomato puree
(3-4 Tsp),Salt (1 Tsp) ,
Sugar (1*1/2 Tsp), Red
Chille wole (2-3), Red
chilli powder (1/2 Tsp),
Ginger (1 Shreded),
Garlic (1 Tsp paste),
Garam Masala (1 Tsp),
Dhaniya Powder(1*1/2
Tsp), Kastoori Methi
(Dry fenugreek-2 Tsp),
Green Dhaniya
(For garnishing), Oil
(1 Tsp)
Mix all the ingredients in
a microwave safe bowl.
jXWZmsniUGGwGX[GG{SGvG`SG WWZGG^a[^Ght

15
GB
Using the Indian Recipe Feature(continued) Multistage Cooking
Your microwave oven can be programmed to cook food in up to four
stages (the Convection , Microwave+Convection and Fast Preheat mode
can not be used in Multistage cooking). Example: You wish to Power
defrost food and cook it without having to reset the oven after each stage.
You can thus defrost and cook a 1.8 kg chicken in four stages:
• Defrosting
• Microwave cooking for 30 minutes
• Grill for 15 minutes
☛ Defrosting and standing must be the first two stages. Combination
and Grill can only be used once during the remaining two stages,
However microwave can be used twice(at two different power levels).
Code Recipe Serving
Size Standing Time Ingredients Recommendations
4
Veg.
Pulao 50grm/ ½cup 5 min. Rice(1/2 cup-washed & soaked in 1 cup of
water for 1 hrs),
Veg ( 1/4cup peas,
beans,tomato,etc),Oil
(1/2 Tsp), Salt(1/2 Tsp),
Red chilli powder(1/2
Tsp-Optional), Clove
(2-3), Cinnamom
( 1/2"), Bayleaf(1),
Black peeper Corn(2-3)
Add rice, water, oil, salt,
all vegetables & whole
spices in a microwave
safe bowl with lid or
cover with clingfilm.
5 Lemon
Chichen 2 drum- stick 3 min. Chicken(2pcs preferably drumsticks),
Lemon juice(2),
Dalchini(1),Long (Clove
2-3), Black Pepper
Corn (5-6), Moti illachi
dana (Black Cardamon
-1),Salt ( 3/4- 1 Tsp),
Butter (2 Tsp, optional)
Make a couple of cuts
into each drumsticks
(legs) & mix with butter ,
lemon juice, dalchini,
Clove, Black peeper
corns,moti illachi dana,
salt. Pour into a
microwave safe bowl
with lid or cover it with
clingfilm.
6 Chocolate
Cake 400 gms 5 min. Eggs(2), Flour (100g/1cup),Butter
(100g / 1/2 cup), Coster
Sugar ( 15g / 2 Tsp),
Coco powder (15g / 2
Tsp), Baking powder
(1/2 Tsp), Milk (1/4 Cup
-To make batter
pouring), Vanilla
Essence (1 tsp)
Shift the flour with
baking powder & mix
with coco powder. Keep
aside. Beat eggs till fluffy
& light with hands or
electric beater. Beat
together softened butter
& sugar till creamy. Add
egg & continue to beat..
Add flour mixture
gradually into egg
mixture & continue
mixing clockwise only.
Add milk to make the
batter of pouring
consistency. Line the
base of microwave safe
baking dish walls with
butter/grease paper or
oil & pour in the batter.
(Note :- Add Walnut to
make Walnut Chocolate
Cake)
1. Press the Power Defrost ( ) button..
2. Select the type of food that you are cooking by pressing
the Power Defrost ()button.
3. Set the weight by pressing the
() and () buttons the
appropriate number of times (1800 g in the example).
4. Press the Microwave ( ) button.
5. Set the microwave power level by pressing the Microwave
( ) button to select the appropriate Power Level
(450W in the example).
6. Set the cooking time by 10min, 1min, and 10s button.
(30 minutes in the example)
7. Press the Grill ( ) button.
8. Pressing the10min, 1min, and 10s buttons appropriate
number of times (15 minutes in the example).
9. Press Start button.
Result: Cooking starts:
◆
When cooking has finished, theovenwill beep
and flash “0” four times. The oven will then
beep one time per minute.
jXWZmsniUGGwGX\GG{SGvG`SG WWZGG^a[^Ght

16
GB
Fast Preheating the Oven
For convection cooking, it is recommended that you preheat the oven to
the appropriate temperature before placing the food in the oven.
When the oven reaches the requested temperature, it is maintained for
approximately 10 minutes; it is then switched off automatically.
Check that the heating element is in the correct position for the type of
cooking that you require.
✉In case the inner temperature has reached the preset
temperature, the beeps 6 times when temperature and the preset
temperature is kept for 10 minutes.
✉If you would like to know the current temperature of oven cavity,
press Fast Preheat button.
Cooking by Convection
The convection mode enables you to cook food in the same way as in a
traditional oven. The microwave mode is not used. You can set the
temperature, as required, in a range varying from 40°C to 250°C in eight
preset levels. The maximum cooking time is 60 minutes.
☛ If you wish to Fast Preheat the oven, see page 16.
• Always use oven gloves when touching the recipients in the
oven, as they will be very hot.
• You can get better cooking and browning, if you use the low rack.
Check that the heating element is in the horizontal position and that the
turntable is in position. Open the door and place the recipient on the low
rack and set on turntable.
✉You can check the temperature at any time by pressing the
Fast Preheat button.
1. Press the Fast Preheat button.
Result: The following indications are displayed:
250°C (temperature)
2. Press the Fast Preheat button one or more times to set
the temperature.
3. Press the Start button.
Result: The oven is preheated to the requested
temperature.
◆
Upon arrival at the preset temperature, the
oven beeps 6 times and the temperature is
kept for 10 minutes.
◆ After 10 minutes, the beeps 4 times and the
operation stops.
1. Press the Convection ()button.
Result: The following indications are displayed:
(convection mode)
250°C (temperature)
2. Press the Convection ( ) button once or more times to
set the temperature.
3. Set the cooking time by pressing the 10min, 1min and 10s
button.
4. Press the Start button.
Result: Cooking starts:
◆
When cooking has finished, theovenwill beep
and flash “0” four times. The oven will then
beep one time per minute.
jXWZmsniUGGwGX]GG{SGvG`SG WWZGG^a[^Ght

17
GB
Grilling
The grill enables you to heat and brown food quickly, without using
microwaves.
• Always use oven gloves when touching the recipients in the
oven, as they will be very hot.
• You can get better cooking and grilling results, if you use the
high rack.
Check that the heating element is in the horizontal position, and that the
appropriate rack is in position.
Choosing the Heating Element Position
The heating element is used when grilling. There is only one position
listed. We need to tell consumers when it should be placed in the vertlcal
position.
• Horizontal position for grilling or combined microwave +
grill cooking
☛ Only change the position of the heating element when it is cold and
do not apply excessive force when placing it in the vertical position.
1. Open the door and place the food on the rack.
2. Press the Grill ( ) button.
Result: The following indications are displayed:
(one-stage cooking)
(grill mode)
• You cannot set the temperature of the grill.
3. Set the grilling time by pressing the 10min, 1min and 10s
buttons.
• The maximum grilling time is 60 minutes.
4. Press the Start button.
Result: Grilling starts:
◆
When cooking has finished, the oven will beep
and flash “0” four times. The oven will then
beep one time per minute.
To set the heating element
to the... Then...
Horizontal position
(grillorcombined microwave
+ grill)
◆Pull the heating element
towards you
◆Push it upwards until it is
parallel with the roof of the
oven
When cleaning the upper part inside the cavity, it will be
convenient to turn heater downward by 90° and clean it.
jXWZmsniUGGwGX^GG{SGvG`SG WWZGG^a[^Ght

18
GB
Choosing the Accessories
☛ For further details on suitable cookware and utensils, refer to the
Cookware Guide on page 21.
Combining Microwaves and the Grill
You can also combine microwave cooking with the grill, to cook quickly
and brown at the same time.
☛ ALWAYS use microwave-safe and oven-proof cookware. Glass or
ceramic dishes are ideal as they allow the microwaves to penetrate
the food evenly.
ALWAYS use oven gloves when touching the recipients in the oven,
as they will be very hot.
You can improve cooking and grilling, if you use the high rack.
Open the door. Place the food on the rack best suited to the type of food to
be cooked. Place the rack on the turntable. Close the door.
Traditional convection cooking does require cookware.
You should, however, use only cookware that you would
use in your normal oven.
Microwave-safe cantainers are not usually suitable for
convection cooking; don’t use plastic containers, dishes,
paper cups, towels, etc.
If you wish to select a combined cooking mode
(microwave and grill or convection), use only recipients
that are microwave-safe and oven-proof. Metallic
cookware or utensils may damage your oven.
1. Press the Microwave + Grill ( ) button.
Result: The following indications are displayed:
(one - stage cooking)
(microwave & grill combi mode)
2. Select the appropriate power level by pressing the
Microwave + Grill( ) button until the corresponding
output power is displayed (300-600W).
• You cannot set the temperature of the grill.
3. Set the cooking time by pressing the 10min, 1min and 10s
buttons.
• The maximum cooking time is 60 minutes.
4. Press the Start button.
Result: ◆
Combination cooking starts.
◆ When cooking has finished, theovenwill beep
and flash “0” four times. The oven will then
beep one time per minute.
jXWZmsniUGGwGX_GG{SGvG`SG WWZGG^a[^Ght

19
GB
Combining Microwaves and Convection
Combination cooking uses both microwave energy and convection
heating. No preheating is required as the microwave energy is immediately
available.
Many foods can be cooked in combination mode, particularly:
• Roast meats and poultry
• Pies and cakes
• Egg and cheese dishes
☛ ALWAYS use microwave-safe and oven-proof cookware. Glass or
ceramic dishes are ideal as they allow the microwaves to penetrate
the food evenly.
ALWAYS use oven gloves when touching the recipients in the oven,
as they will be very hot.
You can get better cooking and browning, if you use the low rack.
Open the door . Place the food on the turntable or on the low rack
which should then be placed on the turntable. Close the door. The
heating element must be in the horizontal position.
✉If you would like to know the current temperature of the oven
cavity, press the Fast Preheat button.
1. Press the Microwave + Convection ()button.
Result: The following indications are displayed:
(microwave & convection combi mode)
250°C (temperature)
2. Select the temperature by pressing the Microwave +
Convection( ) button.
3. Set the cooking time by pressing the 10min, 1min and 10s
button.
• The maximum cooking time is 60 minutes.
4. Set the appropriate power level by pressing the
Microwave + Convection( ) button until the
corresponding output power is displayed (100-600W).
5. Press the Start button.
Result: ◆
Combination cooking starts.
◆ The oven is heated to the required
temperature and then microwave cooking
continues until the cooking time is over.
◆ When cooking has finished, theovenwill beep
and flash “0” four times. The oven will then
beep one time per minute.
jXWZmsniUGGwGX`GG{SGvG`SG WWZGG^a[^Ght

20
GB
Using the Deodorize Feature
Use this feature after cooking odorous food or when there is a lot of smoke
in the oven interior.
First clean the oven interior.
✉The deodorization time has been specified as 5 minutes. It
increases by 30 seconds whenever the +30s button is pressed.
✉You can also adjust Deodorize time by pressing the +30s button.
✉The maximum deodorization time is 60 minutes.
Safety-locking Your Microwave Oven
Your microwave oven is fitted with a special Child Safety programme,
which enables the oven to be “locked” so that children or anyone
unfamiliar with it cannot operate it accidentally.
The oven can be locked at any time.
Switching the Beeper Off
You can switch the beeper off whenever you want.
Using the Memory Cook Feature
If you often cook or reheat the same types of dishes, you can store the
cooking times and power levels in the oven’s memory, so that you do not
have to reset them each other.
Storing the Settings
Using the Settings
First, place the food in the centre of the turntable
Press the Deodorize button after you have finished cleaning.
you will hear four beeps.
1. Press the Grill () and Microwave + Convection ()
buttons at the same time(about three second).
Result: ◆
The oven is locked.
◆ The follow indication is display “ L ”.
2. To unlock the oven, press the Grill()and Microwave
+ Convection( ) buttons again at the same time
(about three second).
Result: The oven can be used normally.
1. Press the Fast Preheat and Microwave Grill ( ) buttons
at the same time (about one second).
Result: The oven does not beep to indicate the end of a
function.
2. To switch the beeper back on, press the Fast Preheat and
Microwave Grill
() buttons again at the same time
(about one second).
Result: The oven operates normally.
1.
To programme the... Then press MEMORY
button.
Setting Once (Display is
MEMORY )
Resetting Twice (Display is
MEMORY )
2. Set your cooking programme as usual
(MW, Grill, Convection, Combi)
3. Press the Start button.
Result: Your settings are now stored in the oven’s
memory.
1.
Press MEMORY button.
2. Press the Start button.
Result: The food is cooked as requested.
jXWZmsniUGGwG WGG{SGvG`SG WWZGG^a[^Ght
