SyncMaster 720XT

Notation
Failure to follow directions noted by this symbol could result in bodily harm or damage to the
equipment.
Prohibited Important to read and understand at all times
Do not disassemble Disconnect the plug from the outlet
Do not touch Grounding to prevent an electric shock
Powe
r
When not used for extended period of time, set your computer to DPMS.
If using a screen saver, set it to active screen mode.

Do not use a damaged or loose plug.
This may cause electric shock or fire.
Do not pull the plug out by the wire nor touch the plug with wet hands.
This may cause electric shock or fire.
Use only a properly grounded plug and receptacle.
An improper ground may cause electric shock or equipment damage.
Insert the power plug firmly so that it does not come loose.
A bad connection may cause fire.
Do not excessively bend the plug and wire nor place heavy objects upon them, which
could cause damage.
This may cause electric shock or fire.
Do not connect too many extension cords or plugs to one outlet.
This may cause fire.
Do not disconnect the power cord while using the monitor.
A surge may be caused by the separation and may damage the monitor.
Do not use the power cord when the connector or plug is dusty.
If the connector or plug of the power cord is dusty, clean it with a dry cloth.
Using the power cord with a dusty plug or connector may cause an electric shock
or fire.

Installation
Be sure to contact an authorized Service Center when installing your set in a location
with heavy dust, high or low temperatures, high humidity, and chemical substances,
or where it will be operated for 24 hours continuously such as an airport, train station
or etc.
Failure to do so may cause serious damage to your set.
Place your monitor in a location with low humidity and a minimum of dust.
Failure to do so may cause electric shock or fire inside the monitor.
Do not drop the monitor when moving it.
This may cause damage to the product or the person carrying it.
Install the monitor base in a showcase or shelf so that the end of the base does not
protrude from the showcase or shelf.
Dropping the product may cause damage to the product or the person carrying it.
Do not place the product on an unstable or small surface area.
Place the product on an even, stable surface, as the product may fall and cause
harm to someone walking by, specifically children.
Do not place the product on the floor.
Take care, as someone, specifically children may trip over it.
Keep any flammable objects such as candles, insecticides or cigarettes away from
the product.
Otherwise, this may cause fire.
Keep any heating devices away from the power cable.
A melted coating may cause electric shock or fire.

Do not install the product in places with poor ventilation, for instance, a bookshelf,
closet, etc.
Any increase in internal temperature may cause fire.
Set down the monitor carefully.
The monitor could be damaged or broken.
Do not place the monitor face down.
This may damage the TFT-LCD surface.
Installing a wall bracket must be done by a qualified professional.
Installation by unqualified personnel may result in injury.
Always use the mounting device specified in the owner's manual.
When installing the product, make sure to keep it away from the wall (more than 10
cm/4 inch ) for ventilation purposes.
Poor ventilation may cause an increase in the internal temperature of the product,
resulting in a shortened component life and degraded performance.
Keep the plastic packaging (bag) out of children’s reach.
The plastic packaging (bag) may cause suffocation if children play with it.
Cleanin
g
and Use
When cleaning the monitor case or the surface of the TFT-LCD screen, wipe with a
slightly moistened, soft fabric.
Do not spray water or detergent directly on the monitor.
This may cause damage, electric shock or fire.

Use the recommended detergent with a smooth cloth.
If the connector between the plug and the pin is dusty or dirty, clean it properly with a
dry cloth.
A dirty connector may cause electric shock or fire.
Make sure to unplug the power cord before cleaning the product.
Otherwise, this may cause electric shock or fire.
Unplug the power cord from the power outlet and wipe the product using a soft, dry
cloth.
Do not use any chemicals such as wax, benzene, alcohol, thinners, insecticide, air
freshener, lubricant or detergent.
Contact the Service Center or Customer Center for interior cleaning once a year.
Keep the product's interior clean.
Dust which has accumulated in the interior over an extended period of time may
cause malfunction or fire.
Others
Do not remove cover (or back).
This may cause electric shock or fire.
Refer servicing to qualified service personnel.
If your monitor does not operate normally - in particular, if there are any unusual
sounds or smells coming from it - unplug it immediately and contact an authorized
dealer or service.

This may cause electric shock or fire.
Keep the product away from places exposed to oil, smoke or moisture; do not install
inside a vehicle.
This may cause a malfunction, electric shock or fire.
Especially avoid operating the monitor near water or outdoors where the monitor
could be exposed to snow or rain.
If the monitor is dropped or the casing is damaged, turn the monitor off and unplug
the power cord. Then contact the Service Center.
The monitor may malfunction, causing an electric shock or fire.
Disconnect the plug from the outlet during storms or lightening or if it is not used for a
long period of time.
Failure to do so may cause an electric shock or fire.
Do not try to move the monitor by pulling only the wire or the signal cable.
This may cause a breakdown, electric shock or fire due to damage to the cable.
Do not move the monitor right or left by pulling only the wire or the signal cable.
This may cause a breakdown, electric shock or fire due to damage to the cable.
Do not cover the vents on the monitor cabinet.
Bad ventilation may cause a breakdown or fire.
Do not place water containers, chemical products or small metal objects on the
monitor.
This may cause a malfunction, electric shock or fire.
If a foreign substance enters the monitor, unplug the power cord and contact the
Service Center.
Keep the product away from combustible chemical sprays or inflammable
substances.

This may cause an explosion or fire.
Never insert anything metallic into the monitor openings.
This may cause electric shock, fire or injury.
Do not insert metal objects such as chopsticks, wire and gimlet or inflammable
objects such as paper and match into the vent, headphone port or AV ports.
It may cause a fire or an electric shock.
If an alien substances or water flows into the product, turn the product off, unplug
the power connector from the wall outlet and contact Service Center.
If you view a fixed screen for an extended period of time, residual image or blurriness
may appear.
Change the mode to energy save or set a screensaver to moving picture when you
need to be away from the monitor for an extended period of time.
A
djust the resolution and frequency to the levels appropriate for the model.
Inappropriate resolution may cause undesirable picture quality.
17 inch (43 cm) - 1280 x 1024
Keep the volume at a comfortable level when using the headphones.
Excessively loud volume levels may damage hearing.
Watching the monitor continuously at a too close angle may result in eyesight
damage.
To ease eye strain, take at least a five-minute break after every hour of using the
monitor.
Do not install the product on an unstable, uneven surface or a location prone to
vibrations.

Dropping the product may cause damage to the product or the person carrying it.
Using the product in a location prone to vibrations may shorten the lifetime of the
product or may catch fire.
When moving the monitor, turn off and unplug the power cord. Make sure that all
cables, including the antenna cable and cables connected to other devices, are
disconnected before moving the monitor.
Failure to disconnect a cable may damage it and lead to fire or an electric shock.
Place the product out of children's reach, as they could damage it by hanging onto it.
A falling product may cause injury to the person or even fatality.
When not using the product for an extended time period, keep the product unplugged.
Otherwise, this may cause heat emission from the accumulated dirt or degraded
insulation, leading to electric shock or fire.
Do not place children's favorite objects (or anything else that may be tempting) on the
product.
Children may try to climb on the product to retrieve an object.
The product could fall, causing physical damage or even death.
Pro
p
er Seatin
g
Posture Durin
g
Monitor Use
!Keep your back straight.
!Keep a distance of about 45 ~ 50 cm between your eyes and the
monitor screen. Look at the screen from slightly above it, and have
the monitor directly in front of you.
!Tilt the monitor upwards by 10 ~20 degrees. Adjust the monitor
height so that the top of the monitor is slightly below eye level.
!Adjust the monitor angle so that there is no reflected light on the
screen.Try to maintain your arms perpendicular to your armpits.
!Keep your arms level with the back of your hands.
!Keep the angle of the elbow perpendicular.
!Keep the angle of the knees at more than 90 degree. Do not let your
feet fall up from the floor. Adjust the arm position so that it is below
the heart.
!If you need repairs, contact a Samsung Service Center.
Correct Disposal of This Product
(Waste Electrical & Electronic Equipment) - Europe only
(Applicable in the European Union and other European countries with
separate collection systems)

This marking shown on the product or its literature, indicates that it should not
be disposed with other household wastes at the end of its working life. To
prevent possible harm to the environment or human health from uncontrolled
waste disposal, please separate this from other types of wastes and recycle it
responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this
product, or their local government office, for details of where and how they
can take this item for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product should not be mixed with
other commercial wastes for disposal.

Features
What is a network monitor?
A network monitor can be used for the same purposes as a common monitor. It also provides the
functionalities of most computers, such as an Internet connection, creating documents, editing
images, via a connection to the host PC over the LAN. In addition, it allows you to connect an
external device (DSC, MP3, external storage media) to the USB port and play music, movies and
games. It is a new concept monitor.
You also can share the screen being displayed on your network monitor with other users by
connecting a projector or other display device to its VGA OUT port. You can use this functionality for
video conferencing and a variety of shared tasks.
In addition, because Windows XP is installed on your network monitor, you can perform Internet
searches and USB memory searches independently of your host PC.

Packa
g
e Contents
Please make sure the following items are included with your monitor.
If any items are missing, contact your dealer.
Contact a local dealer to buy optional items.
Un
p
ackin
g
Without stand With Stand
Manual
Quick Setup Guide Warranty Card (Not available in all
locations)
User's Guide, Monitor Driver,
Natural Color software,
MagicTune™ software
Cable
D-Sub Cable Power Cord
Sold se
p
aratel
y
Keyboard (USB) Mouse (USB)
Y
our Monito
r
Front

MENU button [ ]
Opens the OSD menu. Also use to exit the OSD menu or return to the previous menu.
MagicBright™ button
[]
MagicBright™ is a new feature providing optimum viewing environment
depending on the contents of the image you are watching. Currently six
different modes are available : Custom, Text, Internet, Game, Sport and
Movie. Each mode has its own pre-configured brightness value. You can
easily select one of six settings by simply pressing MagicBright™ control
button.
1) Custom
Although the values are carefully chosen by our engineers, the pre-
configured values may not be comfortable to your eyes depending on
your taste.
If this is the case, adjust the brightness and contrast by using the
OSD menu.
2) Text
For documentations or works involving heavy text.
3) Internet
For working with a mixture of images such as text and graphics.
4) Game
For watching motion pictures such as a game.
5) Sport
For watching motion pictures such as a sport.
6) Movie
For watching motion pictures such as a DVD or Video CD.
>> Click here to see an animation clip
Volume button [ ] When OSD is not on the screen, push the button to adjust volume.
Adjust buttons [ ] Adjust items in the menu.
Enter button [ ] Activates a highlighted menu item. /

/ SOURCE button Push the 'SOURCE', then selects the video signal while the OSD is off.
(When the SOURCE button is pressed to change the input mode, a
message appears in the upper left of the screen displaying the current
mode -- Analog or MagicNet input signal.)
AUTO button Use this button for auto adjustment.
>> Click here to see an animation clip
Power button [ ] Use this button for turn the monitor on and off.
Be careful as pressing the Power button in client mode will shut down
Windows XPe. Be careful that if you force shut down Windows it may
cause damage.
Power indicator
This light glows green during normal operation, and blinks green once as the monitor saves your adjustments.
See PowerSaver described in the manual for further information regarding power saving
functions. For energy conservation, turn your monitor OFF when it is not needed, or
when leaving it unattended for long periods.
Rea
r
The configuration at the back of the monitor may vary from product to product.
POWER IN port Connect the power cord for your monitor to the power port on the back of
the monitor.
VGA IN port Connect the signal cable to the 15-pin, D-sub port on the back of your
monitor.
RS-232C Connection
Terminal Connect a RS-232C cable to this terminal.
VGA OUT port Connect a monitor to another monitor through a D-Sub cable.
Kensington Lock The Kensington lock is a device used to physically fix the system when
using it in a public place.
The locking device has to be purchased
separately.
For using a locking device, contact where
you purchase it.
Cable Fix Ring When connecting the cable is finished, fix the cables to the Cable Fix
Ring.

Earphone jack [ ] Headphone connection terminal.
The Microphone
connection terminal (MIC) Connect a microphone to the MIC terminal.
USB
(USB Connection
Terminal)
Connect USB devices such as a mouse, keyboard and external storage
devices (DSC, MP3, external storage, etc.).
LAN
(LAN Connection
Terminal)
Connect when using it as a monitor.
AUDIO IN Connect the audio cable for your monitor to the audio port on the back of
your computer.
See Connecting Cables for further information regarding cable connections.

Connectin
g
Cables
Connect to the host PC usin
g
a LAN cable
Host PC Hub LAN Cable Monito
r
Connect the power cord to the power terminal at the back of the monitor.
Connect the mouse and the keyboard to the USB ports.
Connect the LAN port on the back of the monitor and the hub.
Connect the hub and the LAN port of the host PC.
The host PC must have an IP address.
A
fter connecting the LAN and setting the IP address, you can view the host PC screen on the
monitor.
Use the VGA IN port to directly connect the monitor to a PC.
Connect to the VGA OUT port to display the same picture on another monitor such as the
projector. (For presentation purposes)
Use the USB port to connect an external storage device (DSC, MP3, external storage, etc.).

Connectin
g
Cables
(
When used as a normal monitor
)
Connect the power cord for your monitor to the power port on the back of the monitor.
Plug the power cord for the monitor into a nearby outlet.
Using the D-sub (Analog) connector on the video card.
- Connect the D-Sub Cable to the VGA IN port on the back of your monitor.
[VGA IN]
Using Macintosh
- Connect the monitor and the Macintosh computer using the computer connection cable.
If the monitor and the computer are connected, you can turn them on and use them.
External Device Connection
USB
(USB Connection Terminal) Connect USB devices such as a mouse, keyboard and external
storage devices (DSC, MP3, external storage, etc.).
(You cannot use these devices without connecting to the host PC or
switching to the MagicNet.)
LAN
(LAN Connection Terminal) Connect the LAN cable.
RS-232C Connection
Terminal Connect a RS-232C cable to this terminal.
D-sub 15-pin port
[VGA OUT] Use it by connecting it to another monitor. (The picture of the main monitor is displayed on the connected
monitor.)

Usin
g
the Stand
Tilt an
g
le
You can tilt the monitor screen forward to adjust the angle to a particular angle.
Swivel stand
You can easily adjust the position of the monitor screen from right to left using the rotating stand. Rubber
stubs are attached at the bottom of the monitor to help fix it to the installation location.
Usin
g
Other Stands
Attachin
g
a Base
This monitor accepts a 100 mm x 100 mm VESA-compliant mounting interface pad.

Monitor Mounting interface pad ( Sold separately )
Turn off your monitor and unplug its power cord.
Lay the LCD monitor face-down on a flat surface with a cushion beneath it to protect the screen.
Remove four screws and then remove the stand from the LCD monitor.
Align the mounting interface pad with the holes in the rear cover mounting Pad and secure it with four
screws that came with the arm-type base, wall mount hanger or other base.

What is XPe Client?
A
n Microsoft Windows XP Embedded(XPe) client uses the Microsoft Windows XP Embedded operating
system. When an XPe client is connected to a Citrix ICA server or another server that can provide the
Microsoft RDP service, data for the keyboard, mouse, audio/video and display are transmitted through
the network between the client and the server.
Connectable Servers
A Citrix ICA
(
Inde
p
endent Com
p
utin
g
Architecture
)
Server
-
A
Microsoft Windows 2000/2003 Server where the terminal services and Citrix MetaFrame are
installed
-
A
Microsoft Windows NT 4.0 Server where the Citrix MetaFrame is installed
A Microsoft RDP
(
Remote Deskto
p
Protocol
)
Server
-
A
Microsoft Windows 2000 Server where the terminal services are installed
-
A
Microsoft Windows 2003 Sever
-
A
Microsoft Windows XP Professional
This manual describes the functions provided by the XPe Client. However, it does not explain
general functionalities of Windows XP Embedded. For more general information on Windows XP
Embedded , refer to Windows XP Embedded Help provided by Microsoft.
Lo
g
on
Lo
g
on
When the client starts, you can logon to the server by entering your username and password. The default usernames already configured are ‘Administrator’ and ‘User’, and their passwords are a space.
Auto Lo
g
On
The client can log onto the server using a predefined account without the user information having to be
manually entered every time.
Only an administrator (that is, only when you logged on as an administrator) can specify the username,
password, and domain for an account for which ‘auto log on’ is activated. At this time, the password
cannot be left empty.
