Samsung QB24R User manual

Quick Setup Guide
QB24R QB24R-T
*Recommended hours of use per day of this product is under 16 hours. If the product is
used for longer than 16 hours a day, the warranty may be void.
*The colour and the appearance may differ depending on the product, and the content in
the manual is subject to change without prior notice to improve the performance.
*Download the user manual from the following Samsung Electronics Website for further
details.
http://www.samsung.com/displaysolutions
-00
Checking the Components
Issues Solutions
The screen keeps
switching on and off.
Check that the cable between the product
and the PC is connected correctly.
No Signal is
displayed on the
screen.
Check that products (including source
device) are connected correctly with a cable.
Check that the source device connected to
the product is powered on.
Depending on the type of external device,
the screen may not display properly. In this
case, connect it with the HDMI Hot Plug
function turned On.
Not Optimum Mode
is displayed.
This message is displayed when a signal
from the graphics card exceeds the product’s
maximum resolution and frequency.
Refer to the Standard Signal Mode Table
and set the maximum resolution and
frequency according to the product
specifications.
The images on
the screen look
distorted.
Check the cable connection to the product.
The screen appears
unstable and shaky. Check that the resolution and frequency of
the PC and graphics card are set within a
range compatible with the product. Then,
change the screen settings if required by
referring to ‘Preset Timing Modes’.
There are shadows or
ghost images left on
the screen.
Troubleshooting Guide
Contact the vendor where you purchased the product if any
components are missing.
Components may differ in different locations.
Quick Setup Guide
Warranty card
(Not available in
some locations)
Power cord
Batteries (AAA x 2)
(Not available in
some locations)
Remote Control RS232C adapter
TOUCH OUT cable
(Supported model:
QB24R-T)
The terms HDMI and HDMI High-Definition Multimedia Interface,
and the HDMI Logo are trademarks or registered trademarks of HDMI
Licensing Administrator, Inc. in the United States and other countries.
*Touching and holding on the screen when the product is turned on displays the administrator menu.
*If the touchscreen control is not available, use the remote control to go to System → Touch Control → Touch Control and select On from
the OSD menu. And go to Device to Control and select Samsung SMART Signage or Auto.
*If the administrator menu is not displayed, use the remote control to go to System → Touch Control → Admin Menu Lock and select Off
from the OSD menu.
*Administrator menu may not work properly when connecting a source device.
Administrator menu (Supported model: QB24R-T)
Parts
1 Remote sensor
Press a button on the remote control pointing at the sensor on the front of the product to perform the corresponding function.
*Using other display devices in the same space as the remote control of this product can cause the other display devices to be
inadvertently controlled.
2 Power button
Turns the product on or off.
Speaker

Model Name QB24R / QB24R-T
Panel
Size 60.4 cm
Display area
527.04 mm (H) x 296.46 mm (V)
Power Supply AC100-240V~ 50/60Hz
Refer to the label at the back of the product as the standard voltage can vary in different countries.
Environmental
considerations
Operating Temperature: 0 °C – 40 °C (32 °F – 104 °F)
Humidity: 10% – 80%, non-condensing
Storage Temperature: -20 °C – 45 °C (-4 °F – 113 °F)
Humidity: 10% – 90%, non-condensing
*This device is a Class B digital apparatus.
*For detailed device specifications, visit the Samsung Electronics website.
*The PVC Free (except for accessory cables) logo is the self-declared trademark of Samsung.
- Accessory cables: signal cables and power cords
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre.
Tel. 1800 40 SAMSUNG (1800 40 7267864) (Toll-Free) / 1800 5 SAMSUNG (1800 5 7267864) (Toll-Free)
www.samsung.com/in/support
Contact SAMSUNG WORLD WIDE
Warning! Important Safety Instructions
Please read the appropriate section that corresponds to the marking on your Samsung product before attempting to install the product.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). THERE ARE NO USER SERVICEABLE
PARTS INSIDE. REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present
inside. It is dangerous to make any kind of contact with
any internal part of this product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
This product is RoHS compliant.
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger,
headset, USB cable) should not be disposed of with other household waste at the end of theirworking life. To prevent
possible harm to the environment or human health from uncontrolled waste disposal, please separate these items from
other types of waste and recycle them responsibly to promote the sustainable reuse of material resources.
For more information on safe disposal and recycling visit ourwebsite www.samsung.com/in or contact our Helpline numbers
- 1800 40 SAMSUNG (1800 40 7267864) (Toll-Free) / 1800 5 SAMSUNG (1800 5 7267864) (Toll-Free)
ꞏIf your equipment uses an AC adapter:
‐Only use the AC adapter with your product by
Samsung.
‐Do not use the power cord with other products.
ꞏDo not install this equipment in a confined space such as a case or
similar.
ꞏThe slots and openings in the cabinet and in the back or bottom
are provided for necessary ventilation. The slots and openings
must never be blocked or covered.
ꞏThe product should be located away from heat sources such as
radiators, heat registers, or other products that produce heat.
ꞏ
(ForIndoor equipment only) Do not place a vessel containing water
(vases etc.) on this apparatus, as this can result in a risk of fire orelectric
shock. (Apparatus shall not be exposed to dripping or splashing)
ꞏThe apparatus must be connected to an earthed MAINS socket-
outlet (Class l Equipment only). Or Use only a properly grounded
plug and receptacle (Class l Equipment only).
ꞏTo disconnect the apparatus from the mains, the plug must be
pulled out from the mains socket, therefore the mains plug shall
be readily operable.
ꞏAs long as this unit is connected to the AC wall outlet, it is not
disconnected from the AC power source even if you turn off this
Power button on the body of the product.
Specifications
Connecting to a PC
DP IN (DAISY CHAIN IN)
DVI/HDMI AUDIO IN
DVI/MAGICINFO IN
DVI/HDMI AUDIO IN
HDMI
HDMI
HDMI
DP IN (DAISY CHAIN IN)
DVI/HDMI AUDIO IN
DVI/MAGICINFO IN
DVI/HDMI AUDIO IN
HDMI
HDMI
HDMI
Connecting to MDC
RS232C IN
RJ45
HUB
RS232C OUT
RJ45
RS232C IN
RS232C OUT
For details on how to use the MDC programme, refer to Help after
installing the programme.
The MDC programme is available on the website.
http://www.samsung.com/displaysolutions
Connecting the LAN Cable
DP IN
HDMI IN
HDMI IN
HDMI IN
DVI/HDMI/AUDIO IN
DVI/MAGICINFO IN
DVI/HDMI/AUDIO IN
AUDIO OUT
RJ45
Use Cat7(*STP Type) cable for the connection. (10/100 Mbps)
*Shielded Twist Pair
Connecting to an Audio System
DP IN (DAISY CHAIN IN)
DVI/HDMI AUDIO IN
DVI/MAGICINFO IN
DVI/HDMI AUDIO IN
HDMI
HDMI
HDMI
Connecting and Using a Source Device
DP IN (DAISY CHAIN IN)
DVI/HDMI AUDIO IN
DVI/MAGICINFO IN
DVI/HDMI AUDIO IN
HDMI
HDMI
HDMI
DP IN (DAISY CHAIN IN)
DVI/HDMI AUDIO IN
DVI/MAGICINFO IN
DVI/HDMI AUDIO IN
HDMI
HDMI
HDMI
Connecting to a Video Device
Ports
1 Connects to MDC using an RS232C adapter.
2 Connects to a PC using a TOUCH OUT cable to enable touch
functions.
*Supported model: QB24R-T
3 Connects to a source device using a HDMI cable or HDMI-DVI
cable.
4 Connects to MDC and the Internet using a LAN cable. (10/100
Mbps)
*Use Cat7(*STP Type) cable for the connection.
- Shielded Twist Pair.
5 Connect to a USB memory device.
*The USB ports on the product accept a maximum constant
current of 1.0A. If the maximum value is exceeded, USB ports
may not work.
6 Connects to an external IR cable that receives signals from the
remote control.
7 Outputs sound to an audio device via an audio cable.
*This model supports a Bluetooth.
Wall Mount Kit Specifications
Model Name VESA screw hole specs
(A * B) in millimeters C Standard Screw Quantity Wall mount bracket
C
Product
QB24R
QB24R-T 100 x 100 8.5 mm M4 4
