Samsung SyncMaster 460UTn2-UD2 User manual

SyncMaster 460UTn-2, 460UTn2-UD2, 460UT-2, 460UTn-B, 460UT-B
LCD Display
User Manual
The color and the appearance may differ depending on the
product, and the specifications are subject to change
without prior notice to improve the performance.
Downloaded From TV-Manual.com Manuals

Safety Instructions
Notational
Note
These safety instructions must be followed to ensure your safety and prevent property dam-
age.
Make sure to read the instructions carefully and use the product in the correct manner.
Warning / Caution
Failure to follow directions noted by this symbol could result in bodily
harm or damage to the equipment.
Note
Prohibited Important to read and under-
stand at all times
Do not disassemble Disconnect the plug from the
outlet
Do not touch Ground to prevent an electric
shock
Power
When not used for extended period of time, set your computer to DPM.
If using a screen saver, set it to active screen mode.
Theimageshereareforreferenceonly,andarenotapplicableinallcases
(or countries).
Shortcut to Anti-Afterimage Instructions
Do not use a damaged power cord or plug or a damaged or
loose power outlet.
• Otherwise, this may result in electric shock or fire.
Do not touch the power plug with wet hands when removing or
plugging the plug into the outlet.
• Otherwise, this may result in electric shock.
Make sure to connect the power cord to a grounded power out-
let.
• Otherwise, it may result in electric shock or personal injury.
Downloaded From TV-Manual.com Manuals

Ensure that the power plug is plugged into the power outlet
firmly and correctly.
• Otherwise, this may result in fire.
Do not forcefully bend or pull the power plug and do not place
any heavy material on it.
• Otherwise, this may result in fire.
Do not connect multiple appliances to the same power outlet.
• Otherwise, this may cause fire due to overheating.
Do not disconnect the power cord while using the product.
•Otherwise, this may result in damage to the product due to
electric shock.
To disconnect the apparatus from the mains, the plug must be
pulled out from the mains socket, therefore the mains plug shall
be readily operable.
• Otherwise, this may cause electric shock or fire.
Use only the power cord provided by our company. Do not use
the provided power cord of another product.
• Otherwise, this may result in fire or electric shock.
Connect the power plug to a wall outlet that can be easily
reached.
•When a problem occurs with the product, you must unplug the
power plug to cut the power off completely. You cannot cut the
power off completely using only the power button on the prod-
uct.
Installation
Be sure to contact an authorized Service Center when installing your
monitor in a location with heavy dust, high or low temperatures, high hu-
midity, and exposed to chemical substances and where it operates for 24
hours such as at airports, train stations etc.
Failure to do so may cause serious damage to your monitor.
Ensure that at least two persons lift and move the product.
•Otherwise, it may be dropped and cause personal injury, and/
or damage the product.
When installing the product in a cabinet or rack, make sure that
the front end of the bottom of the product does not project out.
• Otherwise, it may fall or cause personal injury.
• Use a cabinet or rack of a size appropriate to the product.
Safety Instructions
Downloaded From TV-Manual.com Manuals

DO NOT PLACE CANDLES, MOSQUITO REPELLANT, CIG-
ARETTES AND ANY HEATING APPLIANCES NEAR THE
PRODUCT.
• Otherwise, this may result in fire.
Keep heatingappliances asfar awayfrom thepower cordor the
product as possible.
• Otherwise, this may result in electric shock or fire.
Do notinstallit inabadly ventilatedlocationsuch asabookcase
or closet.
•Otherwise, this may result in fire due to an increase in the in-
ternal temperature.
When putting the product down, make sure to put it down softly.
• Otherwise, this may result in damage to the screen display.
Do not place the front of the product on the floor.
• Otherwise, this may result in damage to the screen display.
Ensure that an authorized installation company installs the wall
mount.
•Otherwise, it may fall and cause personal injury.
• Make sure to install the specified wall mount.
Install your product in a well ventilated location. Ensure that
there is a clearance of more than 4 inches (10 cm) from the wall.
•Otherwise,it mayresult infire dueto anincrease inthe internal
temperature.
Ensure that the packaging vinyl is kept away from children.
•Otherwise,itmayresult inseriousharm(suffocation)ifchildren
play with it.
If the height of your monitor is adjustable, do not place any ob-
ject or part of your body on the stand when lowering it.
•This may cause damage to the product or the person carrying
it.
Clean
When cleaning the monitor case or the surface of the TFT-LCD screen,
wipe with a slightly moistened, soft cloth.
Do not spray cleaner directly onto the surface of the product.
•Otherwise, this may result in the discoloration and distortion of
the structure and the screen surface may peel off.
Safety Instructions
Edible oil, such as soybean oil, can damage or deform the prod-
uct.Donotinstalltheproductinakitchenornearakitchencounter.
Downloaded From TV-Manual.com Manuals

When cleaning the power plug pins or dusting the power outlet,
clean it with a dry cloth.
• Otherwise, it may result in fire.
When cleaning the product, make sure to disconnect the power
cord.
• Otherwise, it may result in electric shock or fire.
When cleaning the product, disconnect the power cord and
clean it with a soft, dry cloth.
• (Do not use chemicals such as wax, benzene, alcohol, thinner,
mosquito repellant, lubricant, or cleaner.) These may change
the appearance of the product surface and peel off the indica-
tion labels on the product.
Since the product housing is easily scratched, make sure to use
the specified cloth only.
When cleaning the product, do not spray water directly onto the
main body of the product.
• Ensure that water does not enter the product and that it is not
wet.
•Otherwise, this may result in electric shock, fire or a malfunc-
tion.
Others
The product is a high voltage product. Do not disassemble, re-
pair or modify the product yourself.
•Otherwise,thismayresultinelectricshockorfire.Iftheproduct
needs to be repaired, contact a Service Center.
Ifthere isa strangesmell ora strangesound orsmoke iscoming
fromthe product,disconnect the powerplug immediatelyand con-
tact a Service Center.
• Otherwise, this may result in electric shock or fire.
Donotplacethisproductinalocationexposedtomoisture,dust,
smoke, water, or in a car.
• Otherwise, this may result in electric shock or fire.
Whenyou droptheproductor thecaseisbroken, turnthepower
off and disconnect the power cord. Contact a Service Center.
• Otherwise, this may result in electric shock or fire.
Safety Instructions
Downloaded From TV-Manual.com Manuals

If thunder or lightning is occurring, do not touch the power cord
or antenna cable.
• Otherwise, this may result in electric shock or fire.
Do not try to move the monitor by pulling only the wire or the
signal cable.
•Otherwise, it may fall and result in electric shock, damage to
the product or fire due to damage to the cable.
Do not lift or move the product back and forwards or right and
left while only holding the power cord or signal cables.
•Otherwise, it may fall and result in electric shock, damage to
the product or fire due to damage to the cable.
Make sure that the ventilating opening is not blocked by a table
or curtain.
•Otherwise,it mayresult infire dueto anincrease inthe internal
temperature.
Do not place any containers containing water, vases, flower-
pots, medicines as well as any metal on the product.
•Ifwater or aforeign materialenters theproduct, disconnectthe
power cord and contact a Service Center.
•This may result in a product malfunction, electric shock, or fire.
Do not use or keep combustible spray or flammable material
near the product.
• Otherwise, this may result in an explosion or fire.
Do not insert any metal, such as chopsticks, coins, pins and
steel, or flammable objects, such as matches or paper, inside the
product (through the ventilating openings, input and output termi-
nals, etc).
•If water or foreign material enters the product, disconnect the
power cord and contact a Service Center.
• Otherwise, this may result in electric shock or fire.
Whenusinga fixedscreen foralong time,an afterimageorstain
may occur.
•If you are not using your product for a long period of time, put
it into sleep mode or use a moving screen saver.
Set a resolution and frequency appropriate to the product.
• Otherwise, your eyesight may be damaged.
When using headphones or earphones, do not turn the volume
too high.
• Having the sound too loud may damage your hearing.
Safety Instructions
Downloaded From TV-Manual.com Manuals

To avoid eyestrain, do not sit too close to the product.
Take a rest for at least five (5) minutes after using the monitor
for one (1) hour.
This reduces eye fatigue.
Do not install it in an unstable location such as an unstable rack
or uneven surface or a location exposed to vibrations.
•Otherwise,itmayfallandcausepersonalinjuryand/ordamage
the product.
•Ifyouusetheproductin alocationexposedto vibrations,itmay
damage the product and result in fire.
When moving the product, turn the power off and disconnect
thepower plug,antenna cable,and allthe cablesconnectedto the
product.
• Otherwise, it may result in electric shock or fire.
Ensure that children do not hang onto the product or climb up
onto the product.
• The product may fall and cause personal injury or death.
Ifyoudonotusetheproductforalongperiodoftime, disconnect
the power cord from the power outlet.
•Otherwise, this may result in overheating or fire due to dust,
and may result in fire due to electric shock or leakage.
Do not place any heavy items or toys or confectionery, such as
cookies etc. that may attract the attention of children and to the
product.
•Your children may hang onto the product causing it to fall and
this may result in personal injury or death.
Be careful that children do not place the battery in their mouths
when removed from the remote control. Place the battery in a lo-
cation that children or infants cannot reach.
•If children have had the battery in their mouths, consult your
doctor immediately.
When replacing the battery, insert it with the right polarity (+, -).
•Otherwise, the battery may become damaged or it may cause
fire, personal injury or damage due to leakage of the internal
liquid.
Use only the specified standardized batteries, and do not use a
new battery and a used battery at the same time.
•Otherwise, the batteries may be damaged or cause fire, per-
sonal injury or damage due to a leakage of the internal liquid.
Safety Instructions
Downloaded From TV-Manual.com Manuals

The batteries (and rechargeable batteries) are not ordinary re-
fuse and must be returned for recycling purposes. The customer
is responsible for returning the used or rechargeable batteries for
recycling.
•The customer can return used or rechargeable batteries to a
nearby public recycling center or to a store selling the same
type of the battery or rechargeable battery.
Do not place the product in a location exposed to direct sunlight
or near any heat such as a fire or heater.
•This may reduce the lifetime of the product, and may result in
fire.
Do not drop any objects onto the product or cause any impact
to the product.
• Otherwise, this may result in electric shock or fire.
Do not use a humidifier near the product.
• Otherwise, this may result in electric shock or fire.
When there is a gas leak, do not touch the product or the power
plug; ventilate immediately.
• If a spark occurs, it may cause an explosion or fire.
If the product has been turned on for a long time, the display
panel becomes hot. Do not touch it.
Keep the small accessories in a location out of the reach of
children.
Be careful when adjusting the angle of the product or the height
of the stand.
•This may result in personal injury as your hand or fingers may
become caught.
•Also,ifyoutilttheproducttoofar,itmayfallandcausepersonal
injury.
Do not install the product in a location low enough for children
to reach.
• Otherwise, it may fall and result in personal injury.
•Since the front part of the product is heavy, install the product
on a level and stable surface.
Safety Instructions
Downloaded From TV-Manual.com Manuals

Do not put any heavy objects on the product.
•This may result in personal injury and/or damage to the prod-
uct.
Safety Instructions
Downloaded From TV-Manual.com Manuals

Introduction
Package Contents
Checking the Contents of the Package
Remove the lock from the package box, as shown in the figure above.
Lift up the package box by
holding the grooves on
both sides of the package
box.
Check the contents of the
package. Remove the Styrofoam and vinyl cover.
Note
• After unpacking the package, make sure to check the contents of the package.
• Store the packaging box in case you need to move the Product later.
• If any items are missing, contact your dealer.
• Contact a local dealer to purchase optional items.
Unpacking
LCD Display
Downloaded From TV-Manual.com Manuals

Manuals
Quick Setup Guide Warranty Card
(Not available in all loca-
tions)
User Manual
MagicInfo Software DVD
(Applicable to the
460UTn-2, 460UTn2-UD2,
460UTn-B model only)
Cables
Power Cord D-Sub Cable
Others
Remote Control
(BP59-00138B)
Batteries (AAA X 2)
(Not available in all loca-
tions)
Sold separately
Semi Stand KIT LAN Cable USB Cable
(Applicable to the
460UTn-2, 460UTn2-UD2,
460UTn-B model only)
Introduction
Downloaded From TV-Manual.com Manuals

Sold separately
RGB to BNC Cable RGB to Component Cable Network Box
(Applicable to the
460UT-2, 460UT-B model
only)
Wall Mount KIT TV Tuner Box (US Only)
Note
Accessories that can be purchased with the product vary by country.
Your LCD Display
Front
SOURCE button
Switches from PC mode to Video mode. Selects the input source that an
external device is connected to.
[PC] →[DVI] →[AV] →[Component] →[HDMI1] →[HDMI2] →[Dis-
playPort] →[MagicInfo] →[TV]
Note
•A TV tuner box (sold separately) must be connected to use the TV. (US
Only)
•A network box (sold separately) must be connected to use MagicInfo
with a 460UT-2, 460UT-B model.
POWER button
Use this button for turning the LCD Display on and off.
Introduction
Downloaded From TV-Manual.com Manuals

Power indicator
Shows PowerSaver mode by blinking green
Note
See PowerSaver described in the manual for further information regarding
power saving functions. For energy conservation, turn your LCD Display
OFF when it is not needed or when leaving it unattended for long periods.
Remote Control Sensor
Aim the remote control towards this spot on the LCD Display.
Rear
Note
See the "Connections" section for details about cable connections. The LCD Display's con-
figuration at the back may vary slightly depending on the model.
POWER S/W ON [ │] / OFF
Switches the LCD Display On/Off.
POWER
The power cord plugs into the LCD Display
and the wall outlet.
IR OUT/IN
Receives a signal from the remote control
andoutputsthesignalthroughLoopoutwhen
a removable sensor board is connected.
AMBIENT SENSOR IN
Supplies power to the removable sensor
board and receives a signal from the light
sensor.
Introduction
Downloaded From TV-Manual.com Manuals

DVI OUT (LOOPOUT)
•Connect a monitor to another monitor
through a DVI, DVI to HDMI cable.
•ConnectaDVI orDVI-HDMIcable to[DVI
OUT (LOOPOUT)] on the product and
[DVI IN] or [HDMI IN] on another monitor.
•HDMI and network signals sent via the
[DVI OUT(LOOPOUT)] port are dis-
played on the second display which has
the [DVI IN] port.
Note
• The Loopout function can be used to du-
plicate the screen of the primary display.
Connect [DVI OUT] on the primary dis-
play to [DVI IN] or [HDMI] on another
display.
• A maximum of 100 monitors can be con-
nected to DVI-Loopout (using a 2m-long
DVI cable). Up to HD resolution can be
supported. Compatible input sources in-
clude DVI IN, HDMI IN 1, and HDMI IN 2
(MagicInfo).
•The status of the cable may have a great
effect on the Loopout performance.
RGB/COMPONENT IN (PC/COMPO-
NENT Connection Terminal (Input))
•Connect the [RGB/COMPONENT IN]
portonthe monitorto theRGBporton the
PC using the D-SUB cable.
•Connect the [RGB/COMPONENT IN]
port on the monitor to the COMPONENT
portontheexternaldeviceusingthe RGB
to COMPONENT cable.
•Connect the [RGB/COMPONENT IN]
porton themonitorto theBNC porton the
PC using the RGB to BNC cable.
DVI IN (PC Video Connection Terminal)
Connect the [DVI IN] port on the monitor to
the DVI port on the PC using the DVI cable.
RGB/DVI/DP/HDMI AUDIO IN (PC/DVI/
DP/HDMI Audio Connection Terminal (In-
put))
Introduction
Downloaded From TV-Manual.com Manuals

Connect the [RGB/DVI/DP/HDMI AUDIO
IN] terminal of the monitor and the speaker
output terminal of your computer's sound
card using a stereo cable (sold separately).
DP IN
Receives a signal from the Display port.
ConnectaDP cableto [DPIN]onthe product
and DP IN on another display.
AV/COMPONENT AUDIO IN [R-AUDIO-
L]
Connect the [AV/COMPONENT AUDIO IN
[R-AUDIO-L]]portonthemonitortotheaudio
output port on the PC or on the external de-
vice using an audio cable.
AV IN
Connect the [AV IN] terminal of your monitor
to the video output terminal of the external
device using a VIDEO cable.
AUDIO OUT
Connect a headphone or an External speak-
er.
DC OUT
Make sure to use connecting [DC OUT] ter-
minal to the authorized TV-Tuner Box. (US
Only)
Otherwise, this may result in damage
to the product.
HDMI IN 1
•Connect the [HDMI IN 1] terminal at the
back of your LCD Display to the HDMI
terminal of your digital output device us-
ing a HDMI cable.
• Up to HDMI 1.3 can be supported.
Note
•A normal external device (DVD player or
camcorder,etc.) ora TVtuner boxcan be
connected to the [HDMI IN 1] terminal.
Introduction
Downloaded From TV-Manual.com Manuals

•To use a TV tuner box (US Only), make
sure to connect it to the [HDMI IN 1] ter-
minal.
HDMI IN 2 (MAGICINFO)
•Connect the [HDMI IN 2 (MAGICINFO)]
terminal at the back of your LCD Display
tothe HDMIterminal ofyourdigital output
device using a HDMI cable.
• Up to HDMI 1.3 can be supported.
Note
The MAGICINFO OUT port must be connec-
ted to the [HDMI IN 2 (MAGICINFO)] port.
RJ 45 MDC (MDC PORT)
MDC(Multiple Display Control) Program Port
ConnecttheLANcableto[RJ45MDC]onthe
productand LANon thePC. Touse anMDC,
the MDC program must be installed on the
PC.
Note
Go to Multi Control and select RJ45 MDC
as the MDC Connection.
RS232C OUT/IN (RS232C Serial PORT)
MDC(Multiple Display Control) Program Port
Connect a serial cable (cross type) to
[RS232C]ontheproductandRS232Conthe
PC. To use an MDC, the MDC program must
be installed on the PC.
Note
Go to Multi Control and select RS232C
MDC as the MDC Connection.
Introduction
Downloaded From TV-Manual.com Manuals

RGB OUT
MagicInfo video output port
Note
Applicable to the 460UTn-2, 460UTn2-UD2,
460UTn-B model only.
MAGICINFO OUT
Outputs MagicInfo DP signals. It should be
connected to [HDMI IN 2 (MAGICINFO)] via
a DP to HDMI cable.
LAN (LAN Connection Terminal)
Connects to a LAN cable to allow Internet or
network access in MagicInfo mode.
Note
Applicable to the 460UTn-2, 460UTn2-UD2,
460UTn-B model only.
USB (USB Connection Terminal)
Keyboard / Mouse, Mass Storage Device
Compatible.
Note
Applicable to the 460UTn-2, 460UTn2-UD2,
460UTn-B model only.
Kensington Lock slot
AKensingtonLock isananti-theftdevice that
enablesuserstolock theproduct sothatthey
cansafely useit inpubliclocations. Sincethe
shape and usage of the locking device may
differ depending on the model and the man-
ufacturer, for more information, refer to the
UserManualsuppliedwith thelockingdevice
for more information.
To lock the product, follow these
steps:
1. Wrap the Kensington lock cable around
a large, stationary object such as a desk
or chair.
2. Slide the end of the cable with the lock
attached through the looped end of the
Kensington lock cable.
Introduction
Downloaded From TV-Manual.com Manuals

3. Insert the Kensington Lock into the se-
curity slot ( ) on the back of the dis-
play.
4. Lock the lock ( ).
Note
• You must purchase the Kensington Lock
separately.
•These are general instructions. For exact
instructions, see the User Manual sup-
plied with the locking device.
•You can purchase the locking device
from an electronics store, an online shop,
or our service center.
Note
See the "Connections" section for details about cable connections.
Remote Control
Note
•The performance of the remote control may be affected by a TV or other electronic device
operating near the LCD Display , causing a malfunction due to interference with the fre-
quency.
• A TV tuner box (sold separately) must be connected to use the TV. (US Only)
POWER
OFF
Number Buttons
/ GUIDE button
+ VOL -
SOURCE
D.MENU
TOOLS
Up-Down Left-Right buttons
INFO
TheColor buttonand thePC/DVI/HDMI/DP
selection button
TTX/MIX
MTS/DUAL
ENTER/PRE-CH
Introduction
Downloaded From TV-Manual.com Manuals

MUTE
CH/P
TV
MENU
RETURN
EXIT
MagicInfo
POWER Turns the product On.
OFF Turns the product Off.
Number Buttons Used to enter the password during the OSD adjustment or
to use MagicInfo.
Press to change the channel.
/ GUIDE button The "-" button is used to select Digital channels.
Electronic Program Guide (EPG) display.
- This function does not work for this LCD Display.
+ VOL - Adjusts the audio volume.
SOURCE Selects a connected external input source or MagicInfo
mode.
Press the button to change the input signal SOURCE.
Changing the SOURCE is only allowed for external devices
that are connected to the LCD Display at the time.
D.MENU DTV menu display
- This function does not work for this LCD Display.
TOOLS Use to quickly select frequently used functions.
- This function does not work for this LCD Display.
Up-Down Left-Right but-
tons
Movesfromonemenuitemtoanotherhorizontally,vertically
or adjusts selected menu values.
INFO Current picture information is displayed on the upper left
corner of the screen.
The Color button and the
PC/DVI/HDMI/DP selection
button
In TV mode, these buttons can be used for setting the
broadcasting announcement function of a digital channel.
You can select the PC, DVI, HDMI or DP(DisplayPort) ex-
ternal input directly in a mode other than TV mode.
Introduction
Downloaded From TV-Manual.com Manuals

TTX/MIX TV channels provide written information services via tele-
text.
- Teletext Buttons
- This is activated when a TV tuner box is installed.
MTS/DUAL MTS-
YoucanselectMTS(MultichannelTelevisionStereo)mode.
Audio Type MTS/S_Mode Default
FM Stereo Mono Mono Manual
Change
Stereo Mono ↔Stereo
SAP Mono ↔SAP Mono
DUAL-
STEREO/MONO, DUAL l / DUAL ll and MONO/NICAM
MONO/NICAMSTEREOcan beoperateddependingonthe
broadcasting type by using the DUAL button on the remote
control while watching TV.
- This is activated when a TV tuner box is installed.
ENTER/PRE-CH This button is used to return to the immediately previous
channel.
- This is activated when a TV tuner box is installed.
MUTE Pauses (mutes) the audio output temporarily. This is dis-
played on the lower left corner of the screen. The audio
comes back on if MUTE or - VOL + is pressed in the Mute
mode.
CH/P In TV mode, selects TV channels.
- This is activated when a TV tuner box is installed.
TV Selects the TV mode directly.
- This is activated when a TV tuner box is installed.
MENU Opens the on-screen menu and exits from the menu or
closes the adjustment menu.
RETURN Returns to the previous menu.
EXIT Exits from the menu screen.
MagicInfo MagicInfo Quick Launch Button.
Note
This button is disabled for products that do not support
MagicInfo.
Introduction
Downloaded From TV-Manual.com Manuals
