Samsung SyncMaster 955DF User manual

SyncMaster 955DF
Color Monitor
Owner’s
Instructions
9550eApp.book Page i Thursday, December 30, 1999 10:19 AM

Information in this document is subject to change without notice.
© 1999 Samsung Electronics Co., Ltd. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Samsung Electronics Co.,
Ltd. is strictly forbidden.
Samsung Electronics Co., Ltd. shall not be liable for errors contained herein or for incidental or
consequential damages in connection with the furnishing, performance, or use of this material.
The
Samsung logo and SyncMaster are registered trademarks of Samsung Electronics Co., Ltd.;
Microsoft, Windows
®
and Windows
®
NT are registered trademarks of Microsoft Corporation; VESA,
DPMS and DDC are registered trademarks of Video Electronics Standard Association; the E NERGY S TAR
name and logo are registered trademarks of the U.S. Environmental Protection Agency (EPA). As an
E
NERGY
S
TAR
Partner, Samsung Electronics Co., Ltd. has determined that this product meets the E
NERGY
S
TAR
guidelines for energy efficiency. All other product names mentioned herein may be the trademarks
or registered trademarks of their respective owners.
9550eApp.book Page ii Thursday, December 30, 1999 10:19 AM

English - 1
English
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Unpacking Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Setting up Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . .4
Connecting Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Plug and Play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . .5
Installing the Video Driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Windows
®
2000 and Windows
®
98 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Windows
®
95 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . .6
Self-Test Feature Check (STFC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Getting Help . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Warm-up Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Adjusting Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . .8
User Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Automatic Save . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Direct-Access Feature . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
OSD Lock/Onlock. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . 9
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Menu Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . .11
Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Zoom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Parallel / Rotation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . 13
Pincushion / Trapezoid . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Pinbalance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Linearity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Color . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Clear Moiré . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . 16
Focus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 16
Degauss . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Recall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . 18
User-Delete . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Sync. Input Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Video Input Level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Menu Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Menu Duration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Languages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . 21
Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
PowerSaver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . .23
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Pin Assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Display Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . .27
Contents
9550eApp.book Page 1 Thursday, December 30, 1999 10:19 AM

English - 2
1
Before connecting the AC power cord to the DC adapter outlet, make sure the voltage
designation of the DC adapter corresponds to the local electrical supply.
2
Never insert anything metallic into the monitor openings. Doing so may create the danger of
electric shock.
3
To avoid electric shock, never touch the inside of the monitor. Only a qualified technician should
open the monitor’s case.
4
Never use your monitor if the power cord has been damaged. Do not allow anything to rest on
the power cord, and keep the cord away from areas where people can trip over it.
5
Be sure to hold the plug, not the cord, when disconnecting the monitor from an electric socket.
6
Openings in the monitor cabinet are provided for ventilation. To prevent overheating, these
openings should not be blocked or covered. Also, avoid using the monitor on a bed, sofa, rug, or
other soft surface. Doing so may block the ventilation openings in the bottom of the cabinet. If
you put the monitor in a bookcase or some other enclosed space, be sure to provide adequate
ventilation.
7
Put your monitor in a location with low humidity and a minimum of dust.
8
Do not expose the monitor to rain or use it near water (In kitchens, near swimming pools, etc.).
If the monitor accidentally gets wet, unplug it and contact an authorized dealer immediately.
You can clean the monitor with a damp cloth when necessary, but be sure to unplug the monitor
first.
9
Place the monitor on a solid surface and treat it carefully. The screen is made of glass and can
be damaged if dropped or hit sharply.
10
Locate your monitor near an easily accessible AC outlet.
11
If your monitor does not operate normally – in particular, if there are any unusual sounds or
smells coming from it – unplug it immediately and contact an authorized dealer or service
center.
12
High temperature can cause problems. Don’t use your monitor in direct sunlight, and keep it
away from heaters, stoves, fireplaces, and other sources of heat.
13
Unplug the monitor when it is going to be left unused for an extended period of time.
14
Unplug your monitor from the AC outlet before any service.
CAUTION
RISK OF ELECRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Safety Instructions
9550eApp.book Page 2 Thursday, December 30, 1999 10:19 AM

English - 3
English
Unpacking Your Monitor
Please make sure the following items are included with your monitor. If any items are
missing, contact your dealer.
Manual
Power Cord
Monitor and Stand
Warranty Card
(Not available in all locations)
Driver Installation Diskette
(Not available in all locations)
9550eApp.book Page 3 Thursday, December 30, 1999 10:19 AM

English - 4
Setting up Your Monitor
Connecting Your Monitor
Figure 1. Cable connections
1
Turn off your computer and unplug its power cord.
2
If you are using an IBM-compatible computer, skip to step 4. If you are using a
Macintosh computer, connect the end of the signal cable to a Macintosh adapter.
3
Follow the instructions included with your adapter to set the pins on your adapter, if
necessary.
4
Connect the signal cable (with an adapter, if necessary) to the video port on the back
of your computer. This port might be directly attached to your computer, or it might be
part of a video adapter, video card, or graphics card.
5
Connect the power cord for your monitor to the power port on the back of the monitor.
6
Plug the power cords of your computer and your monitor into a nearby outlet.
7
Turn on your computer and monitor. If your monitor displays an image, installation is
complete.
9550eApp.book Page 4 Thursday, December 30, 1999 10:19 AM

English - 5
English
Setting up Your Monitor
Plug and Play
Our adoption of the new VESA
®
Plug and Play solution eliminates complicated and time
consuming setup. It allows you to install your monitor in a Plug and Play compatible system
without the usual hassles and confusion. Your PC system can easily identify and configure
itself for use with your display. This monitor automatically tells the PC system its Extended
Display Identification (EDID) data using Display Data Channel (DDC) protocols so the PC
system can automatically configure itself to use the flat panel display. If your PC system
needs a video driver, following the instructions given below according to the operating
system your computer uses.
Installing the Video Driver
When prompted by the operating system for the monitor driver, insert the Driver diskette
included with this monitor. Driver installation is slightly different from one operating system
to another. Follow the directions as appropriate for the operating system you have.
Windows
®
2000 and Windows
®
98
1
Windows
®
2000 and Windows
®
98 will auto-detect your new monitor and start the
“Add New Hardware Wizard” if the drivers are not already installed. Click the NEXT
button to search for drivers.
2
Check the diskette drive box to install the drivers off the diskette provided with your
monitor and click NEXT .
3
Confirm that Windows found the driver on the diskette and click NEXT again to install
the driver.
To manually install or update the driver, follow the directions below:
1
Click on START , SETTINGS , CONTROL PANEL , DISPLAY SETTINGS tab,
ADVANCED , MONITOR tab, CHANGE . This will start the “Add New Hardware
Wizard”.
2
Follow the same directions as given in the steps in the section above.
9550e4.fm Page 5 Thursday, February 3, 2000 10:42 AM

English - 6
Setting up Your Monitor
Windows
®
95
To determine the version of Windows
®
95 that your computer uses, right click on the My
Computer icon on the Windows desktop and select Properties . The version number can be
seen on the General section under “System:”. Follow the directions given below according
to the version of your Windows
®
95 operating system:
Version 4.00.950A
1
Click on START , SETTINGS , CONTROL PANEL , DISPLAY SETTINGS tab,
CHANGE DISPLAY TYPE , CHANGE , HAVE DISK .
2
Type the diskette drive letter in the box and click OK .
Version 4.00.950B
1
Click on START , SETTINGS , CONTROL PANEL , DISPLAY , ADVANCED
PROPERTIES , MONITOR tab, HAVE DISK .
2
Type the diskette letter in the box and click OK .
Self-Test Feature Check (STFC)
Your monitor provides a self test feature that allows you to check whether your monitor is
functioning properly. If your monitor and computer are properly connected but the monitor
screen remains dark and the power indicator is blinking, run the monitor self-test by
performing the following steps:
1
Turn off both your computer and the monitor.
2
Unplug the video cable from the back of the computer.
3
Turn on the monitor.
If the monitor is functioning properly, you will see a white box with a red border and black
text inside as shown in the following illustration:
9550e4.fm Page 6 Thursday, February 3, 2000 10:42 AM

English - 7
English
Setting up Your Monitor
Figure 2. Monitor self test screen
The three boxes inside the border are red, green and blue. Failure of any of the boxes to
appear indicates a problem with your monitor. This box also appears during normal operation
if the video cable becomes disconnected or damaged.
4
Turn off your monitor and reconnect the video cable; then turn on both your computer
and the monitor.
If your monitor screen remains blank after using the previous procedure, check your video
controller and computer system; your monitor is functioning properly.
Getting Help
If your monitor does not display an image, check your cable connections and refer to
Troubleshooting on page 23.
Warm-up Time
All monitors need time to become thermally stable the first time you turn them on each day.
Therefore, to achieve more accurate adjustments for parameters, allow the monitor to warm
(be on) for at least 30 minutes before making any screen adjustments.
Check Signal Cable
No Connection
9550eApp.book Page 7 Thursday, December 30, 1999 10:19 AM

English - 8
User Controls
Your samsung SyncMaster computer monitor allows you to easily adjust the characteristics
of the image being displayed. All of these adjustments are made using the control buttons on
the front of the monitor. These buttons operate the on-screen menu, which shows you the
monitor’s settings and allows you to change those settings.
Figure 3. User control locations
1
Information ( ) button
Use this button to show the horizontal and vertical frequencies and the resolution
received from your computer or video board.
2
EXIT ( ) button
Use this button to Exit the active menu or the OSD.
3
, , , buttons
These buttons allow you to highlight and adjust items in the menu. All menus
automatically save your adjustments 3 seconds after you stop adjusting the setting.
4
MENU ( ) button
Use this button to open the OSD and activate a highlighted menu item.
5
Brightness
This rotary control adjusts the overall brightness of the display image. Rotate the
control to the left to increase the level of brightness, or to the right to decrease the
brightness.
6
Contrast
This rotary control adjusts the monitor’s contrast. Rotate the rotary control to the left
to increase the contrast between dark colors and light colors, or move it to the right to
decrease the contrast.
i
3 4
2
1
5 6 7 8
i
Adjusting Your Monitor
9550eApp.book Page 8 Thursday, December 30, 1999 10:19 AM

English - 9
English
Adjusting Your Monitor
7
Power indicator
This light glows green during normal operation, and blinks amber once as the monitor
saves your adjustments.
8
Power button
Use this button to turn the monitor on and off.
Automatic Save
Whenever you open the on-screen menu and allow an adjustment window to remain active
for about 3 seconds without pressing another button, the monitor automatically saves any
adjustments you have made. These changes are saved into a user area in the monitor. User
areas are reserved according to the signal frequency from your computer. The monitor can
save adjustments for up to 10 user modes. It has 8 factory preset or preload modes, one for
each signal frequency as listed in Display Modes on page 26.
If you have made no adjustments, the on-screen menu disappears and the monitor does not
save anything. To exit without saving the changes you have made, press the EXIT ()
button before the 3 seconds elapse.
Direct-Access Feature
The feature described on this page and the next page can be accessed quickly, at the touch
of one button. When you finish making adjustments to a feature, push the EXIT ( ) button
to turn off the menu or allow the OSD to time out and disappear automatically
OSD Lock/Unlock
Allows you to secure the current control settings so
that they cannot be inadvertently changed. You can
unlock the OSD controls at any time by using the same
procedure.
1
Push and hold the MENU ( ) button for
10 seconds or moré to Lock or to Unlock.
Control Lock
Locked
Control Lock
Unlocked
9550eApp.book Page 9 Thursday, December 30, 1999 10:19 AM

English - 10
Adjusting Your Monitor
Information
The Information on this screen shows available
horizontal and vertical frequencies and display
resolution.
1
With the menu off, push the button
once to see information about your monitor.
The current Horizontal/Vertical frequencies
received from the computer or video board is
displayed along the bottom.
2
Push the button once moré to see the
user defined timing mode.
3
Scroll down with the button to display the
factory preset timings.
Note: These screens do not allow any changes to
the settings; they are for information only.
Information
Frequency Range:
H: 30 - 85KHz
V: 50 - 160Hz
Recommended Timing:
1280x1024 / 75Hz
Serial Number:
i
i
9550eApp.book Page 10 Thursday, December 30, 1999 10:19 AM

English - 11
English
Adjusting Your Monitor
Menu Features
The following features can all be accessed using your monitor’s on-screen menu system.
Follow the instructions below to adjust the features.
Once you are finished making adjustments to a feature, push the EXIT button to return to the
then push EXIT again to turn off the menu.
Position
Follow these instructions to change the position of
the monitor’s entire display.
1
With the menu off, push the button.
Push the button or button until the
“Position / Size” screen is displayed.
2
Push the button or button to select
Position .
3
Push the button to open the Position
adjustment screen.
4
Use the and buttons to change the
vertical position of the monitor’s viewing
area; use the and buttons to change
the horizontal position of the monitor’s
viewing area.
RGB
:
Position/Size
Position
Size
Zoom
Access Function
:
2
8
Position
Previous Menu
9550eApp.book Page 11 Thursday, December 30, 1999 10:19 AM

English - 12
Adjusting Your Monitor
Size
Follow these instructions to change the size of the
monitor’s entire display.
1
With the menu off, push the button.
Push the button or button until the
“Position / Size” screen is displayed.
2
Push the button or button to select
Size .
3
Push the button to open the Size
adjustment screen.
4
Use the and buttons to change the
vertical Size of the monitor’s viewing area;
use the and buttons to change the
horizontal Size of the monitor’s viewing
area.
Zoom
Follow these instructions to get a close-up or a
longshot view of the monitor’s viewing area.
1
With the menu off, push the button.
Push the button or button until the
“Position / Size” screen is displayed.
2
Push the button or button to select
Zoom .
3
Push the button to open the Zoom
adjustment screen.
4
Use the button to decrease the screen
viewing area. Use the button to enlarge
the screen viewing area.
RGB
:
Position/Size
Position
Size
Zoom
Access Function
:
2
8
Size
Previous Menu
RGB
:
Position/Size
Position
Size
Zoom
Access Function
:
Zoom
Previous Menu
9550eApp.book Page 12 Thursday, December 30, 1999 10:19 AM

English - 13
English
Adjusting Your Monitor
Parallel / Rotation
Adjust the parallelogram setting when the display
is leaning left or right; adjust the rotation setting
when the entire display is tilted left or right.
1
With the menu off, push the button.
Push the button or button until the
“Geometry” screen is displayed.
2
Push the button or button to select
Parallel / Rotation .
3
Push the button to open the Parallel/
Rotation adjustment screen.
4
Use the button or button to adjust the
parallel setting; use the button
or button to adjust the rotation setting.
Pincushion / Trapezoid
Adjust the pincushion setting when the sides of the
display are bowed in or bowed out; adjust the
trapezoid setting when the top or bottom of the
display is too large or small.
1
With the menu off, push the button.
Push the button or button until the
“Geometry” screen is displayed.
2
Push the button or button to select
Pincushion / Trapezoid .
3
Push the button to open the
Pincushion/Trapezoid adjustment screen.
4
Use the button or button to adjust the
pincushion setting; use the button or
button to adjust the trapezoid setting.
RGB
:
Geometry
Parallel/Rotation
Pincushion/Trapezoid
Pinbalance
Linearity
Access Function
:
2
17
Parallel/Rotation
Previous Menu
RGB
:
Geometry
Parallel/Rotation
Pincushion/Trapezoid
Pinbalance
Linearity
Access Function
:
20
35
Pincushion/Trapezoid
Previous Menu
9550eApp.book Page 13 Thursday, December 30, 1999 10:19 AM

English - 14
Adjusting Your Monitor
Pinbalance
Adjust the pinbalance setting when the sides of the
display are bowed towards the left or right.
1
With the menu off, push the button.
Push the button or button until the
“Geometry” screen is displayed.
2
Push the button or button to select
Pinbalance .
3
Push the button to open the Pinbalance
adjustment screen.
4
Use the button or button to adjust the
pinbalance setting.
Linearity
Adjust the linearity setting when the display image
is compressed at the left, right or top, bottom.
1
With the menu off, push the button.
Push the button or button until the
“Geometry” screen is displayed.
2
Push the button or button to select
Linearity .
3
Push the button to open the Linearity
adjustment screen.
4
Use the button or button to adjust the
vertical Linearity.
RGB
:
Geometry
Parallel/Rotation
Pincushion/Trapezoid
Pinbalance
Linearity
Access Function
:
53
Pinbalance
Previous Menu
RGB
:
Geometry
Parallel/Rotation
Pincushion/Trapezoid
Pinbalance
Linearity
Access Function
:
44
Linearity
Previous Menu
9550eApp.book Page 14 Thursday, December 30, 1999 10:19 AM

English - 15
English
Adjusting Your Monitor
Color
Color temperature is a measure of the “warmth” of
the image colors. The available range is between
5000 to 9300K. Follow these steps to change the
color temperature and adjust individual R, G, B
color control.
1
With the menu off, push the button.
Push the button or button until the
“Color” screen is displayed.
2
Use the button or button to select
Color 1 , Color 2 , or Color 3 .
3
Push the button to open the “Color 1”,
“Color 2”, or “Color 3” adjustment screen.
4
The current color temperature is shown
highlighted between 9300 and 5000K. Use
the button or button to adjust the
color temperature.
5
Adjust the color temperature as close to the
desired temperature as possible using only
the and buttons. To fine tune the color
hue, use the or button to select R (ed),
G (reen), or B (lue), then use the and
buttons until you reach the desired color.
Note: Recall does not reset the color settings.
RGB
:
Color
Color1
Color2
Color3
Access Function
:
50
50
50
9300 9300K 5000
R
G
B
Color1
Previous Menu
:
50
50
50
9300 6500K 5000
R
G
B
Color2
Previous Menu
:
50
50
50
9300 5000K 5000
R
G
B
Color3
Previous Menu
9550eApp.book Page 15 Thursday, December 30, 1999 10:19 AM

English - 16
Adjusting Your Monitor
Clear Moiré
A “moiré” pattern can appear on your screen,
looking like a series of concentric circles or arcs. To
eliminate this pattern, use the clear moiré
adjustments.
1
With the menu off, push the button.
Push the button or button until the
“Screen” OSD is displayed.
2
Push the button or button to select
Clear Moiré .
3
Push the button to open the clear moiré
adjustment screen.
4
Use the button or button to adjust
horizontal moiré; use the button
or button to adjust vertical moiré.
Focus
Use the focus control when the image displayed on
the screen is not sharp in all areas.
1
With the menu off, push the button.
Push the button or button until the
“Screen” OSD is displayed.
2
Push the button or button to select
Focus .
3
Push the button to open the Focus
adjustment screen.
4
Use the button or button to adjust the
focus along the left and right areas of the
screen. Use the button or button to
adjust the center area of the screen.
RGB
:
F
Screen
Clear Moire
Focus
Access Function
:
2
17
Clear Moire
Previous Menu
RGB
:
F
Screen
Clear Moire
Focus
Access Function
:
2
17
Fv
Fh Fh
Fv
Focus
Previous Menu
9550eApp.book Page 16 Thursday, December 30, 1999 10:19 AM

English - 17
English
Adjusting Your Monitor
Degauss
The Degauss feature will remove color impurities
caused by magnetic fields. Do not use the Degauss
feature moré than once within a 30-minute period.
1
With the menu off, push the button.
Push the button or button until the
Advanced” screen is displayed.
2
Push the button or button to select
Degauss .
3
Push the button to execute the degauss
function. The degaussing screen will appear.
NOTE: The monitor may buzz momentarily, the
image colors may change and the image will
jiggle for a few seconds. These effects are
normal.
4
After a few seconds, the degauss main
menu will return.
RGB
:
+++
G
Advanced
Degauss
Recall
Sync. Input Type
Video Input Level
Access Function
:
Degauss
Degaussing...
Previous Menu
9550eApp.book Page 17 Thursday, December 30, 1999 10:19 AM

English - 18
Adjusting Your Monitor
Recall
Use the recall feature to reset these monitor
settings to their original levels: Position, Size,
Pincushion, Trapezoid, Parallelogram, Pinbalance,
Rotation, and Clear Moiré.
1
With the menu off, push the button.
Push the button or button until the
“Advanced” screen is displayed.
2
Push the button or button to select
Recall .
3
Push the button to open the recall
selection screen.
4
Push the button to select YES . If you
don’t want to reset the monitor, use
the button to select NO .
NOTE: If you have selected “YES”, all settings
listed above will be reset. All other settings
will remain the same.
CAUTION: This operation resets all of the data in
the user memory area for the current
timing signal.
User-Delete
Push and hold EXIT ( ).button for at least 5
seconds.
CAUTION: This operation resets all of the data in
the user memory area. If this occurs,
you must remake your user
adjustmensts.
RGB
:
+++
G
Advanced
Degauss
Recall
Sync. Input Type
Video Input Level
Access Function
:
Recall
YES NO
Previous Menu
9550eApp.book Page 18 Thursday, December 30, 1999 10:19 AM
