Samsung PS-42D5SD User manual

PDP (PLASMA DISPLAY PANEL)
DIGITAL TELEVISION
Owner’s Instructions
Before operating the unit,
please read this manual thoroughly,
and retain it for future reference.
ON-SCREEN MENUS
Picture InPicture (PIP)
Colour Weakness Enhancement Mode
MyColour Control
TELETEXT (Option)
SRS TruSurroundXT
Digital Natural Image engine
Digital Terrestrial Receiver
Register your product at www.samsung.com/global/register
This device is a Class B digital apparatus.
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 1

User Instructions
◆Screen Image retention
Do not display a still image (such as on a video game or when hooking up a PC to this PDP) on the
plasma monitor panel for more than 2 hours as it can cause screen image retention. This image
retention is also known as “screen burn”. To avoid such image retention, reduce the degree of
brightness and contrast of the screen when displaying a still image.
◆Height
The PDP can normally operate only under 2000m in height. It might abnormally function at a place
over 2000m in height so do not install and operate there.
◆Heat on the top of the PDP TV
The top side of the product may be hot after long periods of use as heat dissipates from the panel
through the vent hole in the upper part of the product.
This is normal and does not indicate any defect or operation failure of the product.
However, children should be prevented from touching the upper part of the product.
◆The product is making a ‘cracking’ noise.
A ‘cracking’ noise may occur when the product contracts or expands due to a change of
surrounding environment such as temperature or humidity. This is normal and not a defect of the unit.
◆Cell Defects
The PDP uses a panel consisting of 1,230,000(SD-level) to 3,150,000(HD-level) pixels which require
sophisticated technology to produce. However, there may be few bright or dark pixels on the screen.
These pixels will have no impact on the performance of the product.
◆Avoid operating the TV at temperatures below 5°C(41°F)
◆A still image displayed too long may cause permanent damage to the PDP Panel.
Watching the PDP TV in 4:3 format for a long period of time may leave
traces of borders displayed on the left, right and centre of the screen caused
by the difference of light emission on the screen.
Playing a DVD or a game console may cause similar effect to the screen.
Damages caused by the above effect are not covered by the Warranty.
◆Afterimage on the Screen.
Displaying still images from Video games and PC for longer than a certain period of time may
produce partial afterimages.
To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images.
◆Warranty
-Warranty does not cover any damage caused by image retention.
-Burn-in is not covered by the warranty.
◆Installation
Be sure to contact an authorized service centre, when installing your set in a location with heavy
dust, high or low temperatures, high humidity, chemical substance and where it operates continually
such as the airport, the train station etc.
Failure to do so may cause a serious damage to your set.
English - 2
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 2

Checking Parts
Owner’s Instructions Remote Control/
AAA Batteries
Power Cord
S-VIDEO Cable
PC Cable
HDMI Cable
HDMI/DVI Cable
Scart Cable PC Audio Cable
Component Cables
(RCA)
Sold Separately
English - 3
t.
Antenna Cable
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 3

Contents
◆FOREWORD
■User Instructions ........................................................................................................................ 2
◆CONNECTING AND PREPARING YOUR DISPLAY
■Control Panel.............................................................................................................................. 6
■Infrared Remote Control............................................................................................................ 8
■Inserting the Batteries in the Remote Control .......................................................................... 9
■Assembling the Stand-Base...................................................................................................... 9
■Installing the Display on the Wall Attachment Panel................................................................ 10
■Connecting to an Aerial or Cable Television Network ............................................................. 12
■Connecting a Satellite Receiver or Decoder ............................................................................ 12
■Switching Your Television On and Off...................................................................................... 13
■Familiarizing Yourself with the Remote Control ....................................................................... 14
■Plug & Play Feature................................................................................................................... 15
■Choosing Your Language ......................................................................................................... 16
◆SETTING THE CHANNELS (ANALOG TV)
■Storing Channels Automatically ................................................................................................ 17
■Storing Channels Manually .......................................................................................................18
■Skipping Unwanted Channels................................................................................................... 20
■Sorting the Stored Channels .....................................................................................................21
■Assigning Names to Channels.................................................................................................. 22
■Locking the Channel.................................................................................................................. 23
■Using the LNA (Low Noise Amplifier) Feature ......................................................................... 24
■Fine Tuning Channel Reception ............................................................................................... 25
◆USING YOUR DISPLAY
■Displaying Information ............................................................................................................... 26
■Changing the Picture Standard................................................................................................. 26
■Customizing the Picture Settings .............................................................................................. 27
■Setting the Picture (PC Mode) .................................................................................................. 28
■Selecting the Picture Size.......................................................................................................... 30
■Viewing the DNIe Demonstration.............................................................................................. 31
■Freezing the Current Picture ..................................................................................................... 31
■Setting the My Colour Control (Easy Control) .......................................................................... 32
■Setting the My Colour Control (Detail Control)......................................................................... 33
■Setting the Blue Screen............................................................................................................. 34
■Using the Colour Weakness Enhancement Feature ............................................................... 35
■Using the Energy Saving Feature............................................................................................. 36
■Viewing the Picture in Picture (PIP) .......................................................................................... 37
■Using the Digital NR (Noise Reduction) Feature ..................................................................... 40
■Preventing Screen Burn-in ........................................................................................................ 41
■Reducing the Effects of Screen Burn........................................................................................ 42
■Changing the Sound Standard.................................................................................................. 43
■Customizing the Sound Settings............................................................................................... 44
■Adjusting the Volume Automatically ......................................................................................... 44
■Setting the TruSurround XT ......................................................................................................45
■Selecting the Internal Mute........................................................................................................ 46
■Setting the Melody Sound ......................................................................................................... 46
■Selecting the Sound Mode (depending on the model) ............................................................ 47
■Setting and Displaying the Current Time.................................................................................. 48
■Setting the Sleep Timer ............................................................................................................. 49
■Switching the Television On and Off Automatically ................................................................. 50
■Viewing an External Signal Source........................................................................................... 52
■Redirecting an Input to the External Output ............................................................................. 53
English - 4
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 4

Contents (continued)
◆USING THE DTV FEATURE
■Previewing the DTV Menu System........................................................................................... 54
■Updating the Channel List Automatically.................................................................................. 55
■Updating the Channel List Manually......................................................................................... 56
■Editing Your Favourite Channels .............................................................................................. 57
■Viewing Channel Lists ............................................................................................................... 60
■Displaying Programme Information .......................................................................................... 60
■Viewing the EPG (Electronic Programme Guide) Information ................................................ 61
■Using the Scheduled List........................................................................................................... 62
■Setting the Default Guide .......................................................................................................... 63
■Viewing All Channels and Favourite Channels........................................................................ 64
■Selecting Category Colours....................................................................................................... 65
■Adjusting the Translucency Level ............................................................................................. 66
■Setting up the Parental Lock ..................................................................................................... 67
■Using the Prefered Features .....................................................................................................68
■Checking the Product Information............................................................................................. 69
■Checking the Signal Information ............................................................................................... 69
■Upgrading the Software (Option) .............................................................................................. 70
■Viewing Common Interface....................................................................................................... 71
■Selecting the CI (Common Interface) Menu............................................................................. 72
■Resetting .................................................................................................................................... 73
■Freezing the Current Picture ..................................................................................................... 73
◆USING THE TELETEXT FEATURE
■Teletext Feature......................................................................................................................... 74
■Displaying the Teletext Information........................................................................................... 75
■Selecting Display Options.......................................................................................................... 76
■Selecting a Teletext Page.......................................................................................................... 77
◆ADDITIONAL INFORMATION AND CONNECTIONS
■Connecting to External Input/Output......................................................................................... 78
■Connecting to the AV Output .................................................................................................... 79
■Connecting to the RCA Input .................................................................................................... 80
■Connecting to the S-Video Input ............................................................................................... 80
■Connecting to the Component Input......................................................................................... 81
■Connecting to the PC Input ....................................................................................................... 81
■Connecting to the HDMI Input................................................................................................... 82
■Connecting to the HDMI/DVI Compatible................................................................................. 82
■Connecting to the Common Interface....................................................................................... 83
■Connecting Home Theater System .......................................................................................... 84
■Setting up Your PC Software (Windows only) ........................................................................ 85
■Input Mode (PC)......................................................................................................................... 86
◆RECOMMENDATIONS FOR USE
■Troubleshooting: Before Contacting Service Personnel.......................................................... 87
☛➢
Press Important Note
Symbols
English - 5
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 5

➢
Control Panel
➢
The actual configuration of your TV may be different, depending on
your model.
➢
➢
a)
b)
c)
d)
e)
f)
English - 6
Front of the TV
Speaker
a) SOURCE button
Select the external input source.
b) MENU button
Display the on-screen menu.
c) buttons
Adjust the volume.
d) C/P. buttons
Select channels.
e) ( ENTER) button
Confirm your choice (Store or Enter).
f) ( POWER) button
Press to turn the TV on and off.
Power Indicator
- Power Off: Blue
- Power On: Off
g) Remote Control Sensor
Aim the remote control towards this spot on the TV.
➢
◆You can use the C/P. buttons to switch on the TV when it is in standby mode
depending on the model.
◆The and C/P. buttons have the same function as the ▲/▼/œ/√buttons on the
remote control.
◆If the remote control no longer works or you have misplaced it, you can use the controls
on the panel of the TV.
➢
If the remote control no longer works or you have misplaced it, you can use the controls on the
panel of the TV.
◆Press the MENU button once in DTV mode, then the DTV menu is displayed.
e
e
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 6

Control Panel (continued)
➢
The actual configuration of your TV may be different, depending on
your model.
Rear Panel
➢For further details about connection, refer to pages 78~84.
➢Whenever you connect an audio or video system to your television, ensure that all elements
are switched off. Refer to the documentation supplied with your equipment for detailed
connection instructions and associated safety precautions.
a) HDMI/DVI IN
Connect to the HDMI jack of a device with HDMI output.
These inputs can also be used as a DVI connection with
separate analog audio inputs. An optional HDMI/DVI cable
will be necessary to make this connection.
When using the optional HDMI/DVI adapter, the DVI
analog audio inputs on your TV allowyou to receive left and
right audio from your DVI device. (Not compatible with PC)
b) DVI AUDIO IN L/R
DVI audio outputs for external devices.
c) AV OUT (VIDEO / AUDIO L/R)
Outputs for external devices.
d) AV IN (VIDEO / AUDIO L/R)
Video and audio inputs for external devices, such as a
camcorder or VCR.
e) PC IN / AUDIO
Connect to the video and audio output jack on your PC.
f) S-VIDEO
Video input for external devices with an S-Video output,
such as a camcorder or VCR.
g) COMPONENT IN
Video (Y/PB/PR) and audio (AUDIO L/R) inputs for
Component.
h) EXT 1, EXT 2
Inputs or outputs for external devices, such as VCR, DVD,
video game device or video disc players.
i) ANT IN (75Ω)
75ΩCoaxial connector for Aerial/Cable Network.
j) SERVICE
Connector for service only.
k) POWER IN
Connect the supplied power cord.
l) SERVICE PORT
Connector for service only.
m) COMMON INTERFACE Slot
Insert CI (Common Interface) card into the slot.
(refer to page 83)
English - 7
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 7

Infrared Remote Control
Y
yo
➢
English - 8
➢
The performance of the remote control may be affected by bright light.
➢Teletext Function : Refer to pages 74-77 for details
DIRECT CHANNEL SELECTION
ELECTRONIC PROGRAM GUIDE
(EPG) DISPLAY
AUTOMATIC SWITCH-OFF
(Refer to page 49) /
TELETEXT SUB PAGE
TURNS THE TV ON AND OFF
(Refer to page 13)
TV MODE SELECTION
DNIE DEMO ON/OFF
(Refer to page 31)
PICTURE STILL
(Refer to page 31, 73)
TEMPORARY SOUND
SWITCH-OFF
(Refer to page 14)
MENU DISPLAY (Refer to page 14) /
TELETEXT INDEX
SOUND MODE SELECTION
(Refer to page 47)
SOUND EFFECT SELECTION
(Refer to page 43)
DTV MENU DISPLAY
DIGITAL SUBTITLE DISPLAY/
TELETEXT STORE
VOLUME DECREASE
(Refer to page 14)
VOLUME INCREASE
(Refer to page 14)
SWITCH REPEATEDLY BETWEEN THE
LAST TWO CHANNELS DISPLYED/
TELETEXT HOLD
DTV MODE SELECTION
TELETEXT DISPLAY/
MIX BOTH TELETEXT INFORMATION AND
THE NORMAL BROADCAST/
DTV MHEG MENU DISPLAY
DTV CHANNEL LIST DISPLAY
EXTERNAL INPUT SELECTION
(Refer to page 52) /
TELETEXT MODE SELECTION
LIST/FASTEXT (UK)
INFORMATION DISPLAY
(Refer to page 26) /
TELETEXT REVEAL
CONFIRM YOUR CHOICE (Refer to page 14)
(ANALOG TV : STORE OR ENTER)
(DTV : OK, SELECT, OR ENTER)
PICTURE EFFECT SELECTION
(Refer to page 26)
PICTURE SIZE (Refer to page 30) /
TELETEXT SIZE SELECTION
TV MODE SELECTION/
EXIT MENU (Refer to page 14) /
EXIT TELETEXT
(DEPENDING ON THE MODEL)
PREVIOUS CHANNEL
(Refer to page 14) /
TELETEXT PREVIOUS PAGE
NEXT CHANNEL
(Refer to page 14) /
TELETEXT NEXT PAGE
TELETEXT CANCEL
PIP FUNCTIONS (Refer to page 37~39)
PIP : PIP ACTIVATION OR
DEACTIVATION (PIP)
P / : CHANNEL SELECTION
(P )
SWAP : SWAPPING THE MAIN AND
THE SUB PICTURE (SWAP)
BN68-00889A-00Eng_01-53 4/15/05 4:32 PM Page 8

You must insert or replace the batteries in the remote control when
you:
◆Purchase the television
◆Find that the remote control is no longer operating
correctly
1Remove the cover on the rear of the remote control by pressing
the symbol ( ) downwards and then pulling firmly to remove it.
2Insert two R03, UM4, “AAA” 1.5V or equivalent batteries taking
care to respect the polarities:
◆ - on the battery against - on the remote control
◆ + on the battery against + on the remote control
3Replace the cover by aligning it with the base of the remote
control and pressing it back into place.
➢ Do not mix battery types, i.e. alkaline and manganese.
Inserting the Batteries in the Remote Control
Assembling the Stand-Base
1Assemble the PDP with the stand and firmly secure the PDP using
4 screws provided.
➢◆
Two or more people should carry the PDP. Never lay the
PDP on the floor because of possible damage to the screen.
Always store the PDP upright.
English - 9
E
AND
14)
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 9

English - 10
➢
◆
Installing the Display on the Wall Attachment Panel
Wall Bracket
Components
Plastic Hanger: 4 Screw : 11
Screw : 4 Anchor : 11
Wall Bracket Assembly
Installation Notes
◆ Contact a technician for installing the wall bracket.
◆ Samsung Electronics is not responsible for any damages to the product or harm to customers when
the installation is done by the customer.
◆ This product is for installing on cement walls. The product may not stay in place when installed on
plaster or wood.
Hinge Accessories
➢
Refer to the correct installation guide according to your wall bracket.
1Insert and tighten the Captive Screw in
the direction of the arrow.
When done, mount the wall bracket on
the wall.
2Before drilling into the wall, check if the length
between the two locking holes at the back of
the product is correct.
If the length is too short or long, loosen all or
some of the 4 screws on the wall bracket to
adjust the length.
3Check the installation diagram and mark the drill
points on the wall. Use the 5.0 mm bit to drill holes
deeper than 35 mm.
Fix each anchor in the corresponding hole.
Match each of the brackets and hinge holes to the
corresponding anchor holes and insert and tighten
the 11 screws .
Length between the
two locking holes
Captive Screw
Wall Bracket
Hinge (Right)
There are two hinges
(left and right). Use the
correct one.
Hinge (Left)
1Left: 1 Right: 1
◆ Only use the components and accessories shipped with the product.
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 10

English - 11
Installing the Display on the Wall Attachment Panel (continued)
1Remove the 4 screws on the back of the product.
3Tighten the 4 screws in step 2 (plastic hanger
+ screw ) to the rear holes of the product.
2Insert the screw into the plastic hanger.
(See the figure below)
☛◆Mount the product on the wall bracket
and make sure it is properly fixed to
the left and right plastic hangers.
◆Be careful when installing the product
on the bracket as fingers can be
caught in the holes.
◆Make sure the wall bracket is securely
fixed to the wall, or the product may not
stay in place after installation.
4 Remove safety pin (#) and insert the 4 product
holders into the corresponding bracket holes (!). Then
place the product (@) so that it is firmly fixed to the
bracket. Make sure to reinsert and tighten the safety
pin (#) to securely hold the product to the bracket.
Wall Bracket Angle Adjustment
➢
Adjust the bracket angle to - 2
o
before installing it on the wall.
◆The shape of the product may vary depending on the model.
(The assemblies of the plastic hanger and the screw are the same)
PDP
Wall Bracket Wall
1Fix the product to the wall bracket.
2Hold the product at the top in the center and pull it
forward (direction of the arrow) to adjust the angle.
(See the figure to the right)
3You can adjust the bracket angle between -2° and 15°.
Make sure to use the top center,
and not the left or the right side of
the product to adjust the angle.
To mount the product on the wall bracket
t.
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 11

In order to watch television programmes broadcast via a satellite network,
you must connect a satellite receiver to the rear of TV. Also, in order to
descramble a coded transmission signal, you must connect a decoder to
the rear of TV.
Using a SCART cable
Connect the receiver (or decoder) SCART cable to one of the
SCART connectors on the rear of the television.
Using a coaxial cable
Connect a coaxial cable to the:
◆Receiver (or Decoder) output socket.
◆Television aerial input socket.
➢If you wish to connect both a satellite receiver (or decoder) and
a VCR, you should connect the:
◆Receiver (or Decoder) to the VCR
◆VCR to the television
Otherwise, connect the receiver (or decoder) directly to the
television.
Connecting a Satellite Receiver or Decoder
Rear of the TV
Satellite receiver/
Decoder
To view television channels correctly, a signal must be received by
the set from one of the following sources:
◆An outdoor aerial
◆A cable television network
◆A satellite network
1In these cases, connect the aerial or network input cable to
the ANT IN jack on the rear of the television.
2If you are using an indoor aerial, you may need to turn it when
tuning your television until you obtain a picture that is both sharp
and clear.
For further details, refer to:
◆“Storing Channels Automatically” on page 17
◆“Storing Channels Manually” on page 18
➢When installing or re-installing your TV, be sure to use the
supplied coaxial antenna cable. If you connect using a different
coaxial cable, there is risk of noise or interference to the screen
image. (You must not use another general purpose cable.
Use the 3M/5M/7M cable supplied by Samsung.)
Connecting to an Aerial or Cable Television Network
Rear of the TV
Cable Television
Network
or
English - 12
T
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 12

,
n
The mains lead is attached to the rear of your television.
1Plug the mains lead into an appropriate socket.
Result:The Standby indicator on the front of the television
lights up.
➢
The main voltage is indicated on the rear of the television
and the frequency is 50 or 60Hz.
2Press the power button on the front of the television (or POWER
()button on the remote control) to switch the television on.
Result:The programme that you were watching last is
re-selected automatically.
3Press the numeric button ( ~ ) or P or button
on the remote control or
C/P. button on the right side of
the panel.
➢
If you have not yet stored any channels, no clear picture
appears. Refer to “Storing Channels Automatically” on page
17 or “Storing Channels Manually” on page 18.
3To switch your television off, press the power button again.
Switching Your Television On and Off
English - 13
Front of the TV
Side of the TV
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 13

W
se
T
Familiarizing Yourself with the Remote Control
English - 14
The remote control is used mainly to:
◆Change channels and adjust the volume.
◆Set up the television using the on-screen menu system.
The following table presents the most frequently used buttons and
their functions.
Button Viewing Function Menu Function
Used to display the next
stored channel.
Used to display the
previous stored channel.
Used to display the
on-screen menu system.
Used to return to the previous
menu or normal viewing.
-
-
-
-
Used to:
◆Display a sub-menu
containing selections for
the current menu option.
◆Increase/decrease a
menu option value.
Used to confirm your choice.
Used to display the corresponding channels.
➢
For double digit channels, the second digit must be
pushed immediately after the first. Failure to do this
will result in a single digit channel being displayed.
Used to increase the volume.
Used to decrease the volume.
Used to switch the sound off temporarily.
➢
To turn the sound back on, press this button
again, or press the or button.
Press the PRE-CH button. The TV will switch to the last
channel viewed. To quickly switch between two channels
that are far apart, select the first channel, then use the
numeric buttons to select the second channel. Then, use the
PRE-CH button to quickly alternate between them.
to
MUTE
()
MENU
()
Used to exit from the menu
system and return to normal
viewing directly.
EXIT
()
PRE-CH
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 14

When the television is initially powered on, several basic customer
settings proceed automatically and subsequently.
The following settings are available.
1If the television is in standby mode, press the POWER ()button
on the remote control.
Result:The message to start Plug & Play is displayed.
2To start Plug & Play, press the ENTER ()button.
Result:The Language menu is displayed.
➢The Language menu will automatically appear after several
seconds, even if the ENTER ()button is not pressed.
3Select the appropriate language by pressing the …or †button.
Press the ENTER ()button.
Result:The message to check the connected status of the
antenna is displayed.
4Make sure that the antenna is connected to the TV.
Press the ENTER ()button.
Result:The Country menu is displayed.
5Select your country or area by pressing the …or †button.
Press the ENTER ()button.
Result:The menu to select channels is displayed.
6To start channel store, press the ENTER ()button.
Result:The search will end automatically. Channels are sorted
and stored in the order which reflects their position in
the frequency range (with lowest first and highest last).
When this has finished, the menu to set the time will be
displayed.
➢To stop the search before it has finished or return to normal
viewing, press the MENU ()or the ENTER ()button.
➢Press the ENTER ()button to set the clock.
7Press the œor √button to select the hour or minute.
Set these by pressing the …or †button.
➢
You can enter the hours or minutes by using the
numeric buttons on the remote control.
8The settings are complete, and the stored channel will be
activated.
Plug & Play Feature
English - 15
Plug & Play
Start Plug & Play
OK
Check antenna input.
OK
Plug & Play
Plug & Play
Enjoy your viewing
Language
English
Deutsch
Français
Move Enter Skip
Plug & Play
Plug & Play
Country
Belgium
France
Germany
Move Enter Skip
Enter Exit
Enter Skip
Plug & Play
Clock Set
--
:
--
Auto Store
P1 C
--
40 MHz
0 %
Start
Enter Skip
OK
Enter Skip
Plug & Play
Clock Set 00 : 00
Move Adjust Enter Skip
e
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 15

Y
de
m
yo
to
When you start using your television for the first time, you must
select the language which will be used for displaying menus and
indications.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the …or †button to select Setup.
Result:The Setup menu is displayed.
3Press the ENTER ()button.
4Press the …or †button to select Language.
Press the ENTER ()button.
Result:The available languages are listed.
5Select the appropriate language by pressing the …or †button.
Press the ENTER ()button.
To activate Plug & Play on the menu, follow the instructions below.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the …or †button to select Setup.
Result:The Setup menu is displayed.
3Press the ENTER ()button.
4Press the ENTER ()button again to select Plug & Play.
Result:The message to start Plug & Play is displayed.
5For further details on settings, refer to the previous page.
Plug & Play Feature (continued)
Choosing Your Language
English - 16
Plug & Play
Language : English
Time
Child Lock
Blue Screen : Off
Melody : Off
Colour Weakness :Off
More
Setup
TV
Move Enter Return
Plug & Play
Language : English
Time
Child Lock
Blue Screen : Off
Melody : Off
Colour Weakness :Off
More
Setup
TV
Move Enter Return
Plug & Play
Language : English
Time
Child Lock
Blue Screen : Off
Melody : Off
Colour Weakness :Off
More
Setup
TV
Move Enter Return
English
Deutsch
Français
Nederlands
Español
➢
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 16

You can scan for the frequency ranges available to you (availability
depends on your country). Automatically allocated programme numbers
may not correspond to actual or desired programme numbers. However
you can sort numbers manually and clear any channels you do not wish
to watch.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the …or †button to select Channel.
Result:The Channel menu is displayed.
3Press the ENTER ()button.
Result:The Country is selected.
4Press the ENTER ()button again.
Result:The available countries are listed.
5Select your Country by pressing the …or †button.
➢If you have selected the Others option but do not wish to
scan the PAL frequency range, store the channels manually
(“Storing Channels Manually” on page 18).
6Press the ENTER ()button.
7Press the …or †button to select Auto Store.
Press the ENTER ()button.
Result:The Auto Store menu is displayed.
8Press the ENTER ()button again to start the search.
Result:The search will end automatically. Channels are sorted
and stored in an order which reflects their position in
the frequency range (with lowest first and highest last).
The programme originally selected is then displayed.
➢To stop the search before it has finished, press the MENU
()or the ENTER ()button.
9When the channels have been stored, you can:
◆Sort them in the order required (“Sorting the Stored
Channels” on page 21).
◆Clear a channel (“Skipping Unwanted Channels” on page 20).
◆Fine-tune channel reception if necessary (“Fine Tuning
Channel Reception” on page 25).
◆Assign a name to the stored channels (“Assigning Names to
Channels” on page 22).
◆Activate/deactivate the Digital NR (Noise Reduction) feature
(“Using the Digital NR (Noise Reduction) Feature” on page 40).
◆Activate/deactivate the LNA (Low Noise Amplifier) feature
(“Using the LNA (Low Noise Amplifier) Feature” on page 24).
Storing Channels Automatically
w.
English - 17
Country : Belgium
Auto Store
Manual Store
Add/Delete
Sort
Name
Fine Tune
LNA : Off
Channel
TV
Country : Belgium
Auto Store
Manual Store
Add/Delete
Sort
Name
Fine Tune
LNA : Off
Channel
TV
Move Enter Return
Country : Belgium
Auto Store
Manual Store
Add/Delete
Sort
Name
Fine Tune
LNA : Off
Channel
TV
Move Enter Return
Move Enter Return
Belgium
France
Germany
Italy
Netherlands
Spain
Auto Store
P1 C
--
40 MHz
0 %
Start
Enter Return
➢Not available in DTV or external input mode.
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 17

You can store television channels, including those received via cable
networks.
When storing channels manually, you can choose:
◆Whether or not to store each of the channels found.
◆The programme number of each stored channel which you
wish to identify.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the …or †button to select Channel.
Result:The Channel menu is displayed.
3Press the ENTER ()button.
4Press the …or †button to select Manual Store.
Press the ENTER ()button.
5If necessary, select the broadcasting standard required.
Press the …or †button to select Colour System.
Press the ENTER ()button.
6Select the required colour standard by pressing the …or †
button. Press the ENTER ()button.
Result:The following options are available.
(depending on the model)
AUTO - PAL - SECAM - NTSC 4.43
7Press the …or †button to select Sound System.
Press the ENTER ()button.
8Select the required sound standard by pressing the …or †
button. Press the ENTER ()button.
Result:The following options are available.
BG - DK - I- L
Storing Channels Manually
☛
English - 18
Country : Belgium
Auto Store
Manual Store
Add/Delete
Sort
Name
Fine Tune
LNA : Off
Channel
TV
Move Enter Return
Programme : P 1
Colour System : AUTO
Sound System : BG
Channel : C 5
Search : 175 MHz
Store : ?
Manual Store
TV
Move Enter Return
Programme : P 1
Colour System : AUTO
Sound System : BG
Channel : C 2
Search : 48 MHz
Store : ?
Manual Store
TV
Move Enter Return
AUTO
PAL
SECAM
NTSC 4.43
Programme : P 1
Colour System : AUTO
Sound System : BG
Channel : C 2
Search : 48 MHz
Store : ?
Manual Store
TV
Move Enter Return
BG
DK
I
L
➢Not available in DTV or external input mode.
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 18

Storing Channels Manually (continued)
9If you know the number of the channel to be stored, see the
following steps.
◆ Press the …or †button to select Channel.
Press the ENTER ()button.
◆ Press the …or †button to select C(Air channel) or
S(Cable channel).
◆ Press the √button.
◆ Press the …or †button to select the required number.
Press the ENTER ()button.
➢If there is abnormal sound or no sound, re-select the
sound standard required.
10 If you do not know the channel numbers, select Search by
pressing the …or †button. Press the ENTER ()button.
Press the …or †button to start the search.
Press the ENTER ()button.
Result:The tuner scans the frequency range until the first
channel or the channel that you selected is received on
your screen.
11 To assign a programme number to a channel, select Programme
by pressing the …or †button. Press the ENTER ()button.
12 Press the …or †button until you find the correct number.
Press the ENTER ()button.
13 To store the channel and associated programme number, select
Store by pressing the …or †button. Set to OK by pressing the
ENTER ()button.
14 Repeat steps 9to 13 for each channel to be stored.
☛Channel mode
◆P (Programme mode): When completing tuning, the
broadcasting stations in your area have been assigned to
position numbers from P00 to P99. You can select a
channel by entering the position number in this mode.
◆C(Air channel mode): You can select a channel by entering
the assigned number to each air broadcasting station in this
mode.
◆S(Cable channel mode): You can select a channel by entering
the assigned number for each cable channel in this mode.
English - 19
Programme : P 1
Colour System : AUTO
Sound System : BG
Channel :C05
Search : 175 MHz
Store : ?
Manual Store
TV
Adjust Enter Return
Programme : P 1
Colour System : AUTO
Sound System : BG
Channel : C 5
Search : 175 MHz
Store : ?
Manual Store
TV
Adjust Enter Return
Programme : P 1
Colour System : AUTO
Sound System : BG
Channel : C 5
Search : 175 MHz
Store : OK
Manual Store
TV
Move Enter Return
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 19

You can exclude the channels of your choice from the channel scan
operation. When you scan through the stored channels, those that you
have chosen to skip are not displayed.
All channels that you do not specifically choose to skip are displayed
during scanning.
1Press the MENU ()button.
Result:The main menu is displayed.
2Press the …or †button to select Channel.
Result:The Channel menu is displayed.
3Press the ENTER ()button.
4Press the …or †button to select Add/Delete.
Press the ENTER ()button.
Result:The Add/Delete menu is displayed with the current
channel selected.
5Press the P or button to delete or add the required
channel.
Press the ENTER ()button.
6Repeat step 5for each channel to be deleted or added.
Skipping Unwanted Channels
English - 20
T
st
Country : Belgium
Auto Store
Manual Store
Add/Delete
Sort
Name
Fine Tune
LNA : Off
Channel
TV
Move Enter Return
Add/Delete
P 1 In Memory
Delete
Change Enter Return
Add/Delete
P 1 Not in Memory
Add
Change Enter Return
➢Not available in DTV or external input mode. ➢
BN68-00889A-00Eng_01-53 4/15/05 1:49 PM Page 20
