Samsung NX58J7750SG/AA User manual

Gas Range
User manual
NX58J7750S*
NX58J7750S�_AA_AC_DG68-00623A-02_EN.indd 1 2015-06-25 �� 10:15:34

2 English
WARNING: If the information in this manual is not followed
exactly, a re or explosion may result causing property damage,
personal injury, or death.
• DO NOT store or use gasoline or other ammable vapors and
liquids in the vicinity of this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS:
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch.
- DO NOT use any phone in your building.
- Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
- If you cannot reach your gas supplier, call the re
department.
• Installation and service must be performed by a qualied
installer, service agency, or the gas supplier.
Anti-tip device
WARNING
ALL RANGES CAN TIP, RESULTING IN PERSONAL INJURY.
TIPPING RANGES CAN CAUSE BURNS FROM SPILLS,
PERSONAL INJURY, AND/OR DEATH.
INSTALL AND CHECK THE ANTI-TIP BRACKET USING THE
INSTRUCTIONS AND TEMPLATE SUPPLIED WITH THE
BRACKET.
• To prevent accidental tipping of the range, attach an approved
anti-tip device to the oor. (See Installing the Anti-Tip Device
in the Installation Instructions.) Check for proper installation by
carefully tipping the range forward. The anti-tip device should
engage and prevent the range from tipping over.
NX58J7750S�_AA_AC_DG68-00623A-02_EN.indd 2 2015-06-25 �� 10:15:35

English 3
• If the range is pulled out away from the wall for any reason, make
sure the anti-tip device is reengaged after the range has been
pushed back into place.
• Follow the installation instructions found in the Installation
Manual. Failure to follow these instructions can result in death,
serious personal injury, and/or property damage.
• To prevent the range from tipping, do not step/sit/lean on the
door or drawer.
• If the range is pulled out away from the wall for service or
cleaning, make sure the anti-tip device is reengaged after the
range has been pushed back into place. See "Installing the Anti-Tip
Device" in the installation instructions.
NX58J7750S�_AA_AC_DG68-00623A-02_EN.indd 3 2015-06-25 �� 10:15:35

4 English
Contents
Contents
Key features 6
Bigger is better 6
A cooktop with 5 burners 6
Enhanced convenience with easy maintenance 6
Important safety information 7
Read all instructions before using this appliance 7
Symbols used in this manual 7
State of California Proposition 65 Warning 7
Commonwealth of Massachusetts 7
General safety 8
Fire safety 9
Gas safety 10
Electrical and grounding safety 10
Installation safety 11
Location safety 12
Cooktop safety 13
Oven safety 15
Storage drawer safety 16
Self-cleaning oven safety 16
Overview 17
Layout 17
What’s included 18
Control panel 19
Clock 20
Kitchen timer 21
Oven vent/cooling vent 21
Gas range 22
Cookware 22
Wok grate 23
Griddle 24
Gas burners 25
Ignition 26
NX58J7750S�_AA_AC_DG68-00623A-02_EN.indd 4 2015-06-25 �� 10:15:35

English 5
Contents
Gas oven 27
Single mode 27
Twin mode 28
Cooking mode 30
Broiling 33
Recipe guide 35
Temperature setting guides 37
Using the oven racks 39
Using the gliding rack 43
Cooking options 45
Slow cook, dehydrate, proong 56
Maintenance 62
Cleaning 62
Replacement 69
Reinstallation 70
Troubleshooting 72
Checkpoints 72
Information codes 80
Warranty 81
NX58J7750S�_AA_AC_DG68-00623A-02_EN.indd 5 2015-06-25 �� 10:15:35

6 English
Key features
Key features
Bigger is better
With a capacity of 5.8 cubic feet, this Samsung gas oven range offers more space than many
other leading brands in the United States and Canadian markets. The enhanced capacity
means a better cooking experience.
A cooktop with 5 burners
Power burners, simmer burners, as well as a center oval burner provide exible cooktop heat
for a variety of cookware. The center oval burner delivers heat evenly over a large area, and
provides the optimum temperatures for griddle cooking.
Enhanced convenience with easy maintenance
The Samsung gas oven range combines all the benets of 3 separate home appliances - gas
range, gas oven, and storage drawer - to maximize your convenience with its careful, stylish
design.
NX58J7750S�_AA_AC_DG68-00623A-02_EN.indd 6 2015-06-25 �� 10:15:35

English 7
Important safety information
Important safety information
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
• All electrical and gas equipment with moving parts can be dangerous. Please read the
important safety instructions for this appliance in this manual. The instructions must be
followed to minimize the risk of injury, death, or property damage.
• Save this manual. Please Do Not Discard.
Symbols used in this manual
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in electric shock, personal injury, or property
damage.
NOTE
Useful tips and instructions.
These warning icons and symbols are here to prevent injury to you and others. Please follow
them explicitly. After reading this section, keep it in a safe place for future reference.
State of California Proposition 65 Warning
• This product contains chemicals known to the State of California to cause cancer and
reproductive toxicity.
• Gas appliances can cause low-level exposure to Proposition 65 listed substances,
including but not limited to, benzene, carbon monoxide, formaldehyde and soot,
substances resulting from the incomplete combustion of natural gas or LP fuels.
Commonwealth of Massachusetts
• This product must be installed by a licensed plumber or gas tter qualied or licensed by
the State of Massachusetts. When using ball-type gas shut-off valves, you must use the
T-handle type. Multiple exible gas lines must not be connected in series.
NX58J7750S�_AA_AC_DG68-00623A-02_EN.indd 7 2015-06-25 �� 10:15:35

8 English
Important safety information
Important safety information
General safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the following
precautions.
• Do not touch any part of the range, including but not
limited to, oven burners, surface burners, or interior
surfaces during or immediately after cooking.
• Know the location of the gas shut-off valve and how to
shut it off.
• Make sure the anti-tip device is properly installed on
the range. See the installation instructions for more
information.
• Do not let children near the range. Do not let children go into the range or onto the range.
Do not let children play with the range or any part(s) of the range. Do not leave children
unattended in an area where the range is in use. For children’s safety, we recommend
utilizing the control/door lockout feature.
• Remove all packaging materials from the range before operating to prevent ignition of
these materials. Keep all packaging materials out of children’s reach. Properly dispose the
packaging materials after the range is unpacked.
• Do not store any object of interest to children on the cooktop or backguard of the range.
Children climbing on the range to reach items could be killed or seriously injured.
• Do not operate the range if the range or any part of the range is damaged,
malfunctioning, or missing parts.
• Do not use the range as a space heater. Use the range for cooking only.
• Do not use oven cleaners or oven liners in or around any part of the oven.
• Use only dry pot holders.
• Do not use the range to heat unopened food containers.
• Do not strike the oven glass.
• When disposing of the range, cut off the power cord and remove the door.
• Unplug or disconnect power before servicing.
• Make sure all meat and poultry is cooked thoroughly. Meat should always be cooked to
an internal temperature of 160 °F (71 °C). Poultry should always be cooked to an internal
temperature of 180 °F (82 °C).
• Do not make any attempt to operate the electric ignition oven during an electrical power
failure.
• Keep the appliance area clear and free of combustible materials, gasoline, and other
ammable vapors and liquids.
NX58J7750S�_AA_AC_DG68-00623A-02_EN.indd 8 2015-06-25 �� 10:15:35

English 9
Important safety information
Fire safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the following
precautions.
• Do not store, place, or use ammable or combustible
materials such as paper, plastic, pot holders, linens,
curtains, gasoline or other ammable vapors or liquids
near the range.
• Do not wear loose tting or hanging garments while
using the range.
• To avoid grease buildup, regularly clean the vents.
• Do not let pot holders or other ammable materials
touch a heating element. Do not use a towel or other
bulky cloths in place of a pot holder.
• Do not use water on a grease re. To put out a grease re, turn off the heat source and
smother the re with a tight-tting lid or use a multipurpose dry chemical or foam-type
re extinguisher.
• If a grease re should occur in the oven, turn off the oven by pressing the OFF/CLEAR
button. Keep the oven door closed until the re goes out. If necessary, use a multipurpose
dry chemical or foam-type fire extinguisher.
• Do not heat unopened food containers. The buildup of pressure may cause the containers
to burst and result in injury.
• NEVER use this appliance as a space heater to heat or warm the room. Doing so may
result in carbon monoxide poisoning and overheating of the oven. Do not use the oven
for storage. Paper and other ammable items stored in the oven can ignite.
• Do not leave items such as paper, cooking utensils or food in the oven when not in use.
Items stored in an oven can ignite.
NX58J7750S�_AA_AC_DG68-00623A-02_EN.indd 9 2015-06-25 �� 10:15:36

10 English
Important safety information
Important safety information
Gas safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the following
precautions.
If you smell gas:
• Close the valve and do not use the range.
• Do not light a match, candle, or cigarette.
• Do not turn on any gas or electric appliances.
• Do not touch any electrical switches or plug a power
cord into an outlet.
• Do not use any phone in your building.
• Evacuate the room, building, or area of all occupants.
• Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the re
department.
Checking for gas leaks
• Leak testing of the appliance shall be conducted according to the manufacturer’s
instructions. Do not use a ame to check for gas leaks. Use a brush to spread a soapy
water mixture around the area you are checking. If there is a gas leak, you will see small
bubbles in the soapy water mixture at the leak point.
Electrical and grounding safety
WARNING
To reduce the risk of re, electric shock, personal injuries, and/or death, obey the following
precautions.
• Plug into a grounded 3-prong outlet.
• Do not remove the ground prong.
• Do not use an adapter or an extension cord.
• Do not use a damaged power plug, power cord, or loose
power outlet.
• Do not modify the power plug, power cord, or power
outlet in any way.
• Do not put a fuse in a neutral or ground circuit.
NX58J7750S�_AA_AC_DG68-00623A-02_EN.indd 10 2015-06-25 �� 10:15:36
