Anti-tip device
WARNING
To reduce the risk of tipping the range, the range must be secured
by a properly installed Anti-Tip device. AFTER THE RANGE HAS
BEEN INSTALLED, CONFIRM THAT THE ANTI-TIP DEVICE HAS BEEN
PROPERLY INSTALLED AND VERIFY THAT THE ANTITIP DEVICE
IS PROPERLY ENGAGED. Refer to the installation manual for
instructions.
a) If the anti-tip device is not installed, a child or adult can tip the
range and be killed.
b) Verify that the anti-tip device has been properly installed and
engaged at the rear right (or rear left) of the range bottom.
c) If you move the range and then move it back into place, ensure
the antitip device is re-engaged at the right or left rear of the
range bottom.
d) Do not operate the range without the anti-tip device in place and
engaged.
e) Failure to do so can result in death or serious burns to children
or adults.
WARNING
Do not step, lean, or sit on the doors of the range. You can
cause the range to tip, resulting in burns or serious injuries.
Conrm that the Anti-Tip device is installed properly. Then, to
verify that the Anti-Tip device is engaged, grasp the top rear
edge of the range and carefully attempt to tilt it forward. The
Anti-Tip device should prevent the range from tilting forward
more than a few inches.
If you pull the range out from the wall for any reason, make
sure the antitip device is properly engaged when you push the
range back against the wall. If it is not, there is a risk of the
range tipping over and causing injury if you or a child stand,
sit, or lean on the open door.
Never completely remove the leveling legs. If you remove
the leveling legs, the range will not be secured to the anti-tip
device properly.
NE59M4320_DG68-00882A-04_EN+MES+CFR.indb 2 2019-02-01  12:43:34

English 3
Contents
Contents
Important safety instructions 4
Introducing your new range 16
Overview 16
What’s included with your range 16
Before you begin 17
Energy saving tips 17
Cooktop cooking 17
About cooktop cooking 17
How to set the appliance for cooktop cooking 19
Using the proper cookware 20
Choosing the proper cookware 21
Protecting the smoothtop 21
Operating the oven 22
The oven control panel 22
Setting the clock 23
Setting the kitchen timer 23
Timed cooking 24
Delay start 24
Turning the oven light on and off 25
Minimum and maximum settings 25
Using the oven racks 25
Baking 26
Convection baking 27
Convection roasting 28
Broiling 28
Using the easy cook feature 29
Using the keep warm feature 30
Using the sabbath feature 31
Extra features 32
Maintaining your appliance 34
Self-cleaning 34
Steam-cleaning 36
Care and cleaning of the oven 36
Care and cleaning of the glass cooktop 38
Removing and replacing the oven door 40
Removing and replacing the storage drawer 41
Changing the oven light 41
Troubleshooting 42
Troubleshooting 42
Information codes 46
Warranty (U.S.A) 47
Warranty (CANADA) 48
NE59M4320_DG68-00882A-04_EN+MES+CFR.indb 3 2019-02-01  12:43:35

4 English
Important safety instructions
Important safety instructions
Read and follow all instructions before using your oven to prevent
the risk of re, electric shock, personal injury, or damage when using
the range. This guide does not cover all possible conditions that may
occur. Always contact your service agent or manufacturer about
problems that you do not understand.
WHAT YOU NEED TO KNOW ABOUT
SAFETY INSTRUCTIONS
Warnings and Important Safety Instructions in this manual do not
cover all possible conditions and situations that may occur. It is
your responsibility to use common sense, caution, and care when
installing, maintaining, and operating your oven.
Important safety symbols and precautions
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury
or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury
or property damage.
CAUTION
To reduce the risk of re, explosion, electric shock, or personal injury
when using your oven, follow these basic safety precautions.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
Note
These warning signs are here to prevent injury to you and others.
Please follow them explicitly.
After reading this section, keep it in a safe place for future reference.
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
NE59M4320_DG68-00882A-04_EN+MES+CFR.indb 4 2019-02-01  12:43:35

English 5
Important safety instructions
FOR YOUR SAFETY
When using electrical appliances, you should follow basic safety
precautions, including the following:
CAUTION
• Use this appliance only for its intended purpose as described in
this Owner’s Manual.
• Potentially hot surfaces include the cooktop, areas facing the
cooktop, oven vent opening, surfaces near the opening, crevices
around the oven door.
Be sure your appliance is properly installed and grounded by a
qualied technician.
User servicing - Do not repair or replace any part of the
appliance unless specically recommended in this manual. All
other servicing should be referred to a qualied technician.
Always disconnect the power to the appliance before servicing
by removing the fuse or switching off the circuit breaker.
• Do not enter the oven.
• Do not store items of interest to children in cabinets above a
range or on the back guard of a range. Children climbing on
the range to reach items could be seriously injured.
• Do not leave children alone. Never leave children alone or
unattended in an area where this appliance is in use. They should
never be allowed to sit or stand on any part of the appliance.
• Never use your appliance for warming or heating the room.
• Do not use water on grease res. Turn off the oven to avoid
spreading the ames. Smother the re or ames by closing the door
or use a dry chemical, baking soda, or foam-type extinguisher.
• Avoid scratching or impacting glass doors, cooktops or control
panels. Doing so may lead to glass breakage. Do not cook on a
product with broken glass. Shock, re, or cuts may occur.
• If there is a re in the oven during self clean, turn the oven
off and wait for the re to go out. Do not force the door
open. Introduction of fresh air at self-clean temperatures may
lead to a burst of ame from the oven. Failure to follow this
instruction may result in severe burns.
• If the oven is heavily soiled with oil, self clean the oven before
using the oven again. Leaving the oil in place creates a risk of re.
• Wipe up heavy soil on the oven bottom with a paper tower or
rag before self cleaning. Self cleaning the oven when there is
heavy soil on the oven bottom requires longer cleaning cycles
and produces more smoke.
• Do not lean on the range as you may turn the control knobs
inattentively.
NE59M4320_DG68-00882A-04_EN+MES+CFR.indb 5 2019-02-01  12:43:35

6 English
Important safety instructions
Important safety instructions
• Storage in or on the appliance. Do not store ammable
materials in the oven or near the surface units. Be sure all
packing materials are removed from the appliance before
operating it. Keep plastics, clothes, and paper away from parts
of the appliance that may become hot.
• Wear proper apparel. Never wear loose-tting or hanging
garments while using the appliance.
• Use only dry potholders. Placing moist or damp potholders
on hot surfaces may result in burns from steam. Do not let the
potholder touch hot heating elements. Do not use a towel or
other bulky cloth.
• Teach children not to play with the controls or any other part
of the range.
• For your safety, do not use high-pressure water cleaners or
steam jet cleaners.
• If the power cord is damaged, it must be replaced by the
manufacturer, its service agent, or similarly qualied persons
to avoid creating a hazard.
• The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
SURFACE COOKING UNITS
• Never leave surface units unattended at high heat settings.
Boilovers cause smoking and greasy spillovers that may
ignite.
• Protective Liners – Do not use aluminum foil to line surface
unit drip bowls or oven bottoms, except as suggested in the
manual. Improper installation of these liners may result in a
risk of electric shock or re.
• To avoid oil spillover and re, use a minimum amount of oil
when shallow pan-frying and avoid cooking frozen foods with
excessive amounts of ice.
• Do not lift the cooktop. Lifting the cooktop can damage the
range and cause the range to malfunction.
• Do not operate the cooktop without cookware. If the cooktop
operates without cookware, the control knobs will become
hot.
• Never use the glass cooktop surface as a cutting board.
NE59M4320_DG68-00882A-04_EN+MES+CFR.indb 6 2019-02-01  12:43:35

English 7
Important safety instructions
• Use care when touching the cooktop. The glass surface of the
cooktop will retain heat after the controls have been turned
off.
• Be careful when placing spoons or other stirring utensils on
the glass cooktop surface when it is in use. They may become
hot and could cause burns.
• Use proper pan sizes. This appliance is equipped with surface
units of different size. Select pots and pans that have at
bottoms large enough to cover the surface area of the heating
element. Using undersized cookware will expose a portion of
the heating element to direct contact and may result in the
ignition of clothing. Matching the size of the pot or pan to the
burner will also improve efciency.
• Utensil Handles Should Be Turned Inward and Not Extend
Over Adjacent Surface Units – To reduce the risk of
burns, ignition of ammable materials, or spillage due to
unintentional contact with utensils, position utensil handles so
that they are turned inward and do not extend over adjacent
surface units.
• Glazed cooking utensils. Only certain types of glass, glass/
ceramic, ceramic, earthenware, or other glazed cookware can
be used for rangetop service without breaking due to sudden
changes in temperature.
• Cleaning.Read and follow all instructions and warnings on
the cleaning cream labels.
• Be sure you know which control knob operates each surface
unit. Make sure you turned on the correct surface unit.
• Always turn the surface units off before removing cookware.
• When preparing aming foods under the hood, turn the fan
on.
• Keep an eye on foods being fried at high or medium high
heat settings.
• Do not store heavy items above the cooktop surface that
could fall and damage it.
• Do not Use Decorative Surface Element Covers – If an element
is accidentally turned on, the decorative cover will become
hot and possibly melt. Burns will occur if the hot covers are
touched. Damage may also be done to the cooktop.
NE59M4320_DG68-00882A-04_EN+MES+CFR.indb 7 2019-02-01  12:43:35

8 English
Important safety instructions
Important safety instructions
ELECTRICAL SAFETY
• Proper Installation - Be sure your appliance is properly
installed and grounded by a qualied technician.
• The appliance should be serviced only by qualied service
personnel. Repairs carried out by unqualied individuals may
cause injury or a serious malfunction. If your appliance is in
need of repair, contact a Samsung authorized service center.
Failure to follow these instructions may result in damage and
void the warranty.
• Flush - mounted appliances may be operated only after they
have been installed in cabinets and workplaces that conform
to the relevant standards. This ensures that the appliances are
installed in compliance with the appropriate safety standards.
• If your appliance malfunctions or if fractures, cracks, or splits
appear:
- switch off all cooking zones
- unplug the range from the AC wall outlet
- contact your local Samsung service center.
WARNING
If the surface is cracked, switch off and unplug the appliance to avoid
the possibility of electrical shock. Do not use your cooktop until the
glass surface has been replaced.
WARNING
• Ensure that the appliance is switched off before replacing the
lamp to avoid the possibility of electric shock.
• The range should not be placed on a base.
CHILD SAFETY
WARNING
• This appliance is not intended for use by young children or inrm
persons without the adequate supervision of a responsible adult.
• Young children should be supervised to ensure that they do not
play with the appliance.
• Keep children away from the door when opening or closing it as they
may bump themselves on the door or catch their ngers in the door.
• The cooking zones will become hot when you cook. To keep small
children from being burned, always keep them away from the
appliance while you are cooking.
• During self cleaning, the surfaces may get hotter than usual. Keep
small children away from the range when it is in the self-cleaning
mode.
WARNING
Accessible parts may become hot during use. To avoid burns, young
children should be kept away.
NE59M4320_DG68-00882A-04_EN+MES+CFR.indb 8 2019-02-01  12:43:35

English 9
Important safety instructions
OVEN
• DO NOT TOUCH THE HEATING ELEMENTS OR INTERIOR
SURFACES OF THE OVEN. Heating elements may be hot even
though they are dark in color. Interior surfaces of an oven
become hot enough to cause burns. During and after use, do
not touch or let clothing or other ammable materials contact
the heating elements or interior surfaces of the oven until
they have had sufcient time to cool. Other surfaces of the
appliance may become hot enough to cause burns. Among
these surfaces are oven vent openings and surfaces near these
openings, the oven door, and the window of the oven door.
• Do not heat unopened food containers. The build-up of
pressure may cause the container to burst and result in injury.
• Do not use the oven to dry newspapers. If overheated,
newspapers can catch on re.
• Do not use the oven for a storage area. Items stored in an
oven can ignite.
• Use care when opening the door. Let hot air or steam escape
before you remove food from or put food into the oven.
• Protective liners. Do not use aluminum foil to line the oven
bottoms, except as suggested in the manual. Improper
installation of these liners may result in a risk of electric
shock or re.
• Keep oven vent ducts unobstructed. The oven vent is located
above the right rear surface unit. This area could become hot
during oven use. Never block this vent or place plastic or
heat-sensitive items on it.
• Placement of oven racks. Always place oven racks in the
desired location while the oven is cool. If the rack must be
moved while the oven is hot, use potholders. Do not let the
potholders come in contact with the hot heating element in
the oven.
• Do not allow aluminum foil or a meat probe to contact the
heating elements.
• During use, the appliance becomes hot. Care should be taken
to avoid touching heating elements inside the oven.
• Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass. They can scratch the surface which
may result in the glass shattering.
CAUTION
Do not attempt to operate the oven during a power failure. If the
power fails, always turn the oven off. If the oven is not turned off
and the power returns, the oven may begin to operate again. Food
left unattended could catch re or spoil.
NE59M4320_DG68-00882A-04_EN+MES+CFR.indb 9 2019-02-01  12:43:35

10 English
Important safety instructions
Important safety instructions
SELFCLEANING OVENS
Do not clean the door gasket. The door gasket is essential for a
good seal. Care should be taken not to rub, damage, or move the
gasket.
• Never keep pet birds in the kitchen. Birds are extremely
sensitive to the fumes released during an oven self-clean
cycle. Fumes may be harmful or fatal to birds. Move birds to a
well-ventilated room.
• Clean only the parts listed in this manual in the self-clean
cycle. Before self-cleaning the oven, remove the partition,
rack, utensils, and any food.
• Before operating the self-clean cycle, wipe grease and food
soils from the oven. Excessive amounts of grease may ignite,
leading to smoke damage to your home.
• Do not use any commercial oven cleaner or oven liner
protective coating of any kind in or on the outside of the oven.
• Remove the nickel oven shelves from the oven before you
begin the self cleaning cycle or they may discolor.
• If the self-clean mode malfunctions, turn the oven off and
disconnect the power supply. Have it serviced by a qualied
technician.
• Excess spillage must be removed before you run the self
cleaning cycle.
GLASS/CERAMIC COOKING SURFACES
• DO NOT TOUCH SURFACE UNITS OR AREAS NEAR UNITS.
Surface units may be hot even though they are dark in color.
Areas near surface units may become hot enough to cause
burns. During and after use, do not touch, or let clothing or
other ammable materials contact the surface units or areas
near the units until they have had sufcient time to cool.
Among these areas are the cook-top and the facing of the
cook-top.
• Do not cook on a broken cooktop. If the cooktop should
break, cleaning solutions and spillovers may penetrate the
broken cook-top and create a risk of electric shock. Contact a
qualied technician immediately.
Clean the cooktop with caution. If a wet sponge or cloth is used
to wipe spills on a hot cooking area, be careful to avoid steam
burns. Some cleaners can produce noxious fumes if applied to a
hot surface.
NE59M4320_DG68-00882A-04_EN+MES+CFR.indb 10 2019-02-01  12:43:35
