HA Repair Guide
Refrigerator
SSEDA –RS261*

- 2/47 -
•No Ice / dispensing problem
•Shortage of ice
No Ice
•No Water / Water Dripping
•Water Leak
No Water
•Evap Defrost build
Defrost
•Water hose Noise
•Unit Noise
Noise
•Weak Cooling(F/R)
•Cooling Too Cold
Cooling
•Detail Error Code
Error CODE
SSEDA-PJT Repair Guide
[ RS261M* ]

- 3/47 -
●Ice & Water
#1. Symptom : No Ice Repair Schematic
Check-1
Reason Step
Check-2
Tip
Code
Block
# 1
# 2
# 3
Ice Bucket
ice exist
(dispensing
problem)
Display selection
problem
Inspect Display Water
& Ice selection
1-1
Panel-
PBA
Wire
Harness
Main
PBA
Lever S/W sensing
problem
Inspect LEVER S/W
operation
Inspect Bucket
assembly
1-2
Panel-
PBA
Wire
Harness
Ice
Bucket
Auger Motor S/W
defect
Inspect Auger Motor
S/W operation
Auger
Motor
S/W
Wire
Harness
Auger Motor failure
InspectASSY AUGE
R-MOTOR operation
1-3
ASSY
Auger
Motor
Wire
Harness
Main
PBA
Ice Bucket
No ice/less ice
(ice making
problem)
Ice maker water
supplying problem
Inspect WATER
connection/ supply
2-1
External
conn.
(Water
supply)
Water
Hose
Filter
Inspect Ice Valve
operation
2-2
Wire
Harness
Ice Valve
Inspect ASSY PIPE-
WATER (HEATER)
freezing
2-3
Pipe -
WATER
Ice maker/sensor /
Fan Motor
problem
Self diagnosis test
Display “Lighting”+
“Energy Saver”
2-4
Ice
Maker
Sensor
Fan
Damper
Wire
Harness
Main
PBA
Cooling power
failure
(Water exist on
Tray)
Measure cooling
power inspection
Inspect Comp / Fan
motor
2-5
Comp
Relay
Cycle
Shield
System
C-fan
Chassis
Project
Basic Model
Type
SBS
SSEDA
RS261M*
Plastic Ice Maker
※ Check Display “ICE off” selecting

- 4/47 -
Step 1
① Check “Child Lock” selection
② Inspect “Ice Type” Key operation
- Key normal Inspect Tip 1-2
- Key failure Inspect Step 2
Step 2
①Check PANEL PBA WIRE HARNESS contact
- Inspect No.10(WHT)”and 14(W/BLK)” WIRE
②Check Wire harness after disassemble the
HINGE-UPP COVER
- Inspect No.10(WHT)and 14(W/BLK) Wire
Step 3
①Disassemble Main PBA Cover which is on the
back
②Inspect Connector which is on the right
bottom
- Inspect CN51 No.10(WHT)and
No.12(W/BLK)
③If there is no problem fro all
- Check the PANEL PBA replacement and
repairing
If it is not solved
- Replace and repair MAIN PBA
Check Point Inspect “Ice Type” button select operation
Tip 1-1. Inspect Display Water & Ice selection

- 5/47 -
Step 1
①Check the Auger motor rotation sound which
is inside of F room with pushing DISPENSER
LEVER.
- When operation sound does not appear,
check Step 2
- When operation sound appears, check
“STEP 4”
Step 2
①Check Auger Motor S/W which is on the
door top of F room
- Check the S/W button with F room door
closing condition.
(Check it couldn’t push or damaged)
②After disassemble Connector and set Tester
as resistance and push S/W with hand, check
that is “0Ω”
※ It does not operate when the F room
door S/W is failure
Step 3
①After disassemble Display, push Lever and
check the Micro S/W pushing check which is
on left side.
※ Check it couldn’t push or damaged.
When there is no problem
①Check the wire Harness contact after
disassemble HINGE-UPP COVER
- Inspect No.6(YEL)and 10(GRAY) Wire
②Inspect Main PBA Connector
- Inspect CN50 No.6(YEL) and 10(GRAY)
Wire
Step 4
①Inspect less inserting of Ice Bucket.
- Pull the Bucket with pushing up toward top
※ if less inserting, Auger Motor rotation is
not passed and ice does not dispense
Check Point Inspect Dispenser Lever S/W operation.
Tip 1-2. Inspect Lever S/W & Auger Motor S/W operation

- 6/47 -
Step 1
①Disassemble ice Bucket which is in F room.
②Disassemble 3 screws on the top.
Step 2 (Single product inspection)
①Disassemble ice bucket which is in freezer.
②Disassemble Auger Motor, inspect Motor
- Normal product GRY+BLK 3~4 Ω
- Failure part : Open & 0 Ω
Step 3
①Disassemble the Main PBA Cover which is on
the back
②Inspect Connector which is on right bottom
- Inspect CN70 No.3(RED)and CN73 No.9(PRK)
Check Point InspectAuger Motor.
Tip 1-3. Inspect ASSY Auger Motor operation

- 7/47 -
Step 1
①Inspect water comes when lever operation
after Water selection.
※ Initial product needs Water Tank filling time
- When the water does not comeCheck Step 2
- When the water comesCheck TIP 2-4
Step 2 (Connection problem- Bending Hose)
①Inspect connection condition between
external tap and product connect
- Inspect connection of water pipe
- Inspect tap is closed.
②Inspect back Water Hose bending.
Step 3 (Piercing Valve using problem)
①Check hole blocking to not supplying water
when use Piercing Valve.
※ Check water supplying after disassemble
refrigerator connecting Hose
Step 4 (Filter Case problem)
①Water supplies after remove Water Filter, but
water does not come after connect.
- Replace filter case in same problem when
replace other filters.
Step 5
①When the water comes well through water
line, check water pressure when use external
water filter.
※ Water pressure of supplying should over
20PSI.
Check Point Inspect Water supply failure
Tip 2-1. Inspect Water supply / supply
※ Need lever operation for 3 min on initial and after replace Filter !
Piercing Valve

- 8/47 -
Step 1
①Push the button for 2 sec which is on the
bottom of ice maker after disassemble Ice
Bucket.
②Check the water supplying after ice maker
tray twist operation.
- When the water does not come Check
the Step 2
- When the water comes Check TIP 2-5
① 점ㄱ
Step 2
①Disassemble the backside Unit Cover .
②Check Purple 2-Wire after disassemble ASSY
Valve
- Normal part: 350~450 Ω
- Failure part : Open or 0 Ω
③Disassemble the Main PBA Cover which is on
the back
④Inspect Connector which is on right bottom
- Inspect CN70 No.3(RED)and CN73
No.7(PRP)
①Disassemble Unit Cover 2-
inspect Wire
CN 73 No.7(PRP) + CN70
No. 3(RED)
Check Point Inspect ice maker Water supplying problem
Tip 2-2. Inspect Ice Valve operation
CN 73
CN 70

- 9/47 -
Step 1
①Disassemble the Ice Maker which is on top of
F room.
②Disassemble top PIPE-WATER Heater Wire.
- Normal product 1.8 ~ 2.5 KΩ
- Failure part : Open or 0 Ω
Circuit diagram ①Inspect 2-Wire connector
-Main PBA : CN70
No.5(BRN) + CN71
No.1(ORG)
Main PBA
Check Point Inspect ice maker Water supply problem
Tip 2-3. Inspect ASSY PIPE-WATER (Heater) freezing
Connector
CN 70,71

- 10/47 -
※ Fan motor Fan motor displays failure for
power on condition.
Touch Display “Lighting”+ “Energy Saver” Key for
8 sec at the same time.
- Press until all LED blink and “dingdong” sound
appears.
- No problem on self-diagnosischeck TIP 2-2
Tip 2-4. Inspect Self diagnosis test (※Must select “Power Freeze” first)
Display (Image)
Failure Item
Measure
R실"약"
Ice Maker Sensor
Inspect F ice maker + Wire
Harness
①F room icemaker connector
②Main PBA CN90
R실"강"
Ice Maker function
failure
F실"약약중"
F cabinet Sensor
Disassemble Cover Multi Front
①Inspect Sensor Wire
②Main PBA CN40 No.5(YEL)
CN50 No.5(GRY)
F실“weak-mid”
Fdefrost SENSOR
Disassemble Cover Evap
①Inspect Sensor Wire
②Main PBA CN40 No.6(BLU)
CN50 No.5(GRY)
F실"중"
F-cabinet FAN
Disassemble Cover Multi
①Inspect Fan Wire
②Main PBA CN75
No.4(YEL)+No.5(BLK)+No.1
0(GRY)
F실"강"
F defrost Error
Check Evap Cover disassemble
defrost heater
①Inspect defrost heater
housing
②CN70 No.5(BRN)+CN72
No.1(ORG)
R “Mid”
Rcabinet Sensor
Disassemble R Cover Damper
①Main PBA CN40 No.9(BLK)
CN50 No.5(GRY)
R “Mid-mid-strong”
Rvibration
Damper
Heater
Disassemble R Cover Damper
①Inspect Main PBA CN76
No.4~9
F“Mid-mid-strong"
C-FAN ERROR
Inspect machinery room
COVER disassemble C-Fan
F“weak"
External air SENSO
R
Check R door HINGE-UPP
disassemble
①Main PBA CN40
- No.1(YEL)+2(YEL)

- 11/47 -
Tip 2-4-1. Inspect self-diagnosis test
Inspect Ice Maker
Block
①Disassemble F Ice Maker Screw Top
②Inspect Wire Harness connection which is on
The top part.
※ Ice maker test operates and water does not come,
Check TIP 2-2
※ No problem on Test and water supply, check TIP 2-5
Circuit diagram ①When Sensor failure
:Inspect No.5(WHI) + 6(WHI)
②When the Sensor is normal
: Ice Maker bottom Test
button
※ Press 2sec
③Check ice maker operation
※Inspect Twist problem Wire
check and replace ice maker
Main PBA ①When the Sensor is failure
“CN 90”
: Inspect No.5(WHI) + 6(WHI)
②When the Ice Maker Test
operation is failure
Inspect “CN 90”
- rotate operation:
1(RED)=2(BLK)
- output sensing: 5(BLU)
- Test input: 4(S/BLU)
Sensor
Test
button
Connector
CN 90
Motor Twist Water supply

- 12/47 -
Tip 2-4-2. Inspect self-diagnosis test
F Sensor / Cabinet Fan / Defrost Sensor / Defrost Error
Block
①Disassemble F Ice Maker Screw top
②Inspect Cover Multi Front disassemble
③Inspect Evap Cover disassemble
Circuit diagram ①When the F cabinet Sensor
failure
: Inspect disassembled Cover
Multi Front blue2-Wire
connector
-Main PBA : CN40 No.5(YEL)
+ CN50 No.5(GRY)
②When F Fan is failure
: Inspect disassembled Cover
Multi Front 3-Wire connector
-Main PBA : CN75 No.4(YEL)
/ No.5(BLK) / No.10(GRY)
③When the Defrost Sensor is
failure
: Inspect Evap Cover
disassembled blue 2-Wire
-Main PBA : CN40 No.6(BLU)
+ CN50 No.5(GRY)
④Defrost Error
: Inspect brown 2-Wire
connector
-Main PBA : CN70 No.5(BRN)
+ CN71 No.1(ORN)
Main PBA
CN 50
F-Sensor
Fan Motor
D-Sensor
Heater
Defrost
Sensor
CN 40
CN 70,71
CN 75

- 13/47 -
Tip 2-4-3. Inspect self-diagnosis test
R Sensor / F Damper Motor
Block
①Disassemble R Ice Maker Screw top
②Inspect Cover Multi Front disassembly
③Inspect Evap Cover disassembly
Circuit diagram ①When the R cabinet Sensor is
failure
: Inspect disassembled Cover
Damper blue 2-Wire
connector
-Main PBA : CN40 No.9(BLK)
+ CN50 No.5(GRY)
②When the R Damper Motor is
failure
: Inspect disassembled Cover
Damper 6-Wire connector
-Main PBA : CN76 No.4(BLK)
/ 5(BRN) / 6~9
Main PBA
CN 50
CN 40
CN 70,71
CN 76
R-Sensor
Damper
Damper
R-Sensor

- 14/47 -
Tip 2-4-4. Inspect self-diagnosis test
External R Sensor / C-Fan Motor
CN 50
CN 40
CN 70,71
CN 76
EXT-Sensor
Block
- Inspect external air sensor
①Inspect R top HINGE-UPP Cover disassembled Wire
- Inspect C-Fan Error
①Inspect disassembled Unit Cover Fan restriction / Wire
Circuit diagram ①When external air Sensor is
failure
: Inspect R HINGE-UPP Cover
disassembled yellow 2-Wire
-Main PBA : CN40 No.1(YEL)
+ 2(YEL)
②When the C-Fan Motor is
failure
: Inspect Unit Cover
disassembled 3-Wire
connector
-Main PBA : CN75
No.2(S/BLU) / 7(RED) /
10(GRY)
Main PBA
Inspect
Connector
C-Fan

- 15/47 -
Tip 2-5. Inspect cooling power (※Must select “Power
Freeze” first)
※ Do not off the power Measure self-diagnosis test on
“TIP 2-4”
Step 1
Press Display “Lighting”+ “Energy Saver” Key for
8sec at the same time.
- Press until all LEDs are Blinking and “dingdong”
sound appears
※ When the Error occur Move to TIP 2-4
-If there is no problem Check Step 2
Step 2 (Inspect Comp operation)
① Press Display “Freezer” for 3sec to being
“Power Freeze”.
※ Satisfy setting temperature and defrost
performance comp off.
(Operate 7min off when the COMP operate
again)
②Inspect backside Comp operation.
(Check operation with touching comp using
hand.)
- Comp does not operated Check Step 3
- Comp operates Check Step 6
Step 3 (Inspect Comp Wire )
①Inspect backside left of Unit Comp Wire
Connector
②Disassemble Comp left Relay Cover and
inspect OLP & PTC-Relay separation
③Inspect PTC-Relay Wire changing
- Sub Coil left PNK, Main right S/BLU
Connector
separation
Relay
separation
Changed PTC
Relay
Normal
Next Page

- 16/47 -
Step 4 (Comp single product operation failure)
①Inspect rotation failure by Comp Coil cutting
- Measure Common + Sub resistance
- Measure Common + Main resistance
Normal : 1~50 Ω
Failure : Open ∞Ω
Step 5 (Comp Relay Failure)
①Inspect power supply Line
- Comp operation condition is normal : AC
100~125 V
- Failure : AC voltage non-applying (Inspect
power line)
②Inspect Comp OLP(Over Load Protection)
- Normal : applying an electric current 0~1 Ω
- Failure : Open ∞Ω
③Inspect PTC Relay
- Normal : 0.8~1.4 KΩ
- Failure : Open ∞Ω
Step 6 (Gas Leak failure)
①Comp operates but, if Comp-dome & Pipe-
Condenser temperature is not high, repair
cycle shield system because it is failure of
Gas Leak & Clogged
Step 4 (When C-Fan is failure)
①When C-Fan operates or “FG” Signal is failure,
comp stops after 60min..
※ Must check “FG” failure through self-
diagnosis test, even the Fan is still rotating.
Inspect
Connector

- 17/47 -
Check-1
Reason Step
Check-2
Tip
Code
Block
# 1
# 2
# 3
No Water
WATER supply
problem
Inspect WATER
connection / supply
ASSY CASE-WATER
FILTER supply failure
3-1
External
connecti
on
(Water
supply)
Water
Hose
CASE-
Filter
WATER VALVE
problem
Inspect WATER
VALVE
3-2
WATER
VALVE
WIRE
HARNES
S
WATER LEVER S/W
Inspect LEVER S/W
operation
Door S/W
3-3
LEVER
S/W
DOOR
S/W
WIRE
HARNES
S
WATER Hose
Problem
WATER HOSE
bending
Inner door hose
blocking/freezing
3-4
TUBE-FI
TTING
F-DOOR
Other
Water Leak
&
Noise
WATER LINE Leak
CONNECTOR
WATER LINE
4-1
TUBE-FI
TTING
CASE-
FILTER
WATER
VALVE
DISPENSER DRIP
- WATER DROP
- ICE ROUTE
Inspect connection
part
Inspect WATER
VALVE
Inspect supplied
WATER
4-2
TUBE-FI
TTING
WATER
VALVE
COCK
WATER HOSE
Noise
Inspect FILTER CASE
(quake failure)
4-3
cock
CASE-FI
LTER
Chassis
Project
Basic Model
Type
SBS
SSEDA
RS261M*
Plastic Ice Maker
※ Check Display “Hold” selection
●Ice & Water
#2. Symptom : No Water & other(LEAK) Repair distribution diagram

- 18/47 -
Step 1
①Inspect lever water coming after Water
selecting.
※ Takes water tank filling time of initial product
- When the water does not come Check Step
2
- When the water comes Check TIP 2-4
Step 2 (Connection problem-Hose bending)
①Inspect external tap and product connection
condition
- Inspect the water pipe is not connected
- Inspect the tap is closed.
②Inspect backside Water Hose bending.
Step 3 (Piercing Valve using problem)
①Check the water supplying when use Piercing
Valve.
※ Check water supplying after disassemble
refrigerator hose
Step 4 (CASE WATER Filter problem)
①When remove Water Filter water supplies,
when connect it water does not come.
※ When the other filter replace, and same
symptom appear, Replace case water filter.
※ Check Filter & Water tank freezing when Too
Cold
①Replace filter for long term using FILTER
Step 5 (Water pressure problem)
①If the water supplies well through water line,
check water pressure can be decreased when
the external Water Filter using.
※ Supply water should be at least over
20PSI.
Check Point Inspect Water supply failure
Tip 3-1. Inspect WATER connection / supply
※ Need lever operation for 3 min on initial and after filter
replacement !
Piercing Valve
Freeze the filter & tank

- 19/47 -
Step 1
①Disassemble backside UNIT COVER.
Step 2
①After disassemble ASSY Valve and check
WHITE 2-Wire
- Normal parts : 350~450 Ω
- Failure parts : Open or 0 Ω
②Disassemble Main PBA cover which is in the
backside
③Inspect Connector which is on the right
bottom
- Inspect CN70 No.3(RED)and CN73
No.1(W/BLK)
①Inspect disassembled Unit
Cover 2-Wire
CN 73 No.1(W/BLK) +
CN70 No.3(RED)
Check Point Inspect WATER VALVE failure
Tip 3-2. Inspect WATER VALVE operation
CN 73
CN 70

- 20/47 -
Step 1
①After select DISPENSER WATER and check
water coming with pressing LEVER
Step 2
①Inspect F DOOR UPP MAGNET existence
②Inspect disassembled HINGE-UPP COVER
DOOR S/W &WIRE CONNECTOR OPEN
※ Not operation when DOOR S/W is
failure
Step 3
①After disassemble Display, check left micro
S/W pressing to press Lever.
※Check non-pressing, damage
②After disassemble HINGE-UPP COVER and
check WIRE HARNESS connection
- Inspect PINK & GRAY Wire
③Inspect Main PBA Connector
- Inspect CN50 No.7(PIK)and 10(GRAY) Wire
Check Point Inspect Dispenser Lever S/W operation.
Tip 3-3. Inspect WATER Lever S/W operation
MAGNET CHECK
CN 50
