Samsung RSG257AA Series User manual

Refrigerator
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at
www.samsung.com/global/register
RSG257AA
English
DA99-01746A(EN)-GGH.indd 1 2008.7.10 12:12:35 PM

Features of your new Refrigerator
KEY FEATURES OF YOUR NEW REFRIGERATOR
Your Samsung Side-By-Side Refrigerator comes equipped with many space-saving, innovative storage and
energy-efficient features.
• Twin Cooling Plus™
The Refrigerator and Freezer have separate evaporators. Due to this independent cooling system,
the Freezer and Refrigerator cool more efficiently. Additionally, this separate air flow system
prevents food odor of one compartment from seeping into other compartments.
• Multi Airflow
Provides even cooling throughout the refrigerator to maintain optimal temperatures
to keep food fresh.
• LED Tower Lighting
See everything in a new light with LED tower lighting.
• Premium Design Ice and Water Dispenser
Quick and easy access to filtered water and cubed/crushed ice with the external dispenser.
• External Digital Display and Control
Controlling the refrigerator is easy with the external digital display. It shows the inside
temperatures, when to change your filter and also controls the ice and water dispenser.
• Clear View Icemaker
The Icemaker is located in the freezer door, this ensures that all the freezer shelf space can be
fully utilized. Ice cubes are quickly produced and the clear ice bucket lets you easily see the
amount of ice cubes produced.
• Auto-moisture Drawer
A “Shape Memory Polymer” is equipped on the “Auto-moisture Drawer(crisper)”, which provides
automatic humidity control. To maintain the optimal humidity in the crisper, the fine-mesh holes in
the polymer control the flow of moisture.
For easy future reference write the model and serial
number down. You will find your model number on
the left hand side wall of the refrigerator.
Model #
Serial #
DA99-01746A(EN)-GGH.indd 2 2008.7.10 12:12:35 PM

Safety Information
SAFETY INFORMATION
Before using your new Samsung Side-By-Side Refrigerator, please read this manual thoroughly
to ensure that you know how to safely and efficiently operate the features and functions that your
new appliance offers.
Because the following instruction covers various models, the characteristics of your Refrigerator
may differ slightly from the Refrigerator described in this manual. If you have any question, contact
us at 1-800-SAMSUNG or find help and information online at www.samsung.com.
What the icons and signs in this user manual mean :
WARNING Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property
damage.
CAUTION
To reduce the risk of fire, explosion, electric shock, or personal injury when using your
refrigerator, follow these basic safety precautions:
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call the service center for help.
These warning signs are here to prevent injury to you and others.
Please follow them explicitly
Keep this manual in a safe place for future reference.
SEVERE WARNING SIGNS
Do not plug several appliances into the same power socket.
• Large appliances draw a lot of power. Powering more than one appliance or machine from a single power source
could cause overheating and cause a fire.
Make sure that the power plug is not kinked or damaged by the back of the Refrigerator.
• A damaged power plug may overheat and cause a fire.
Do not spray water directly into or on the outside of the Refrigerator/Freezer drawer.
• Water could get into the interior machine parts and cause electric shock.
Do not use aerosols near the Refrigerator.
• Aerosols used near the Refrigerator may cause an explosion or fire.
DA99-01746A(EN)-GGH.indd 3 2008.7.10 12:12:35 PM

Do not put undue stress on the power cord or place heavy articles on it.
• Placing heavy articles on the power cord create the risk of explosion or fire.
Do not insert the power plug with wet hands.
• It may cause electric shock.
Do not put a container filled with water on the Refrigerator.
• If it spills, it may cause fire or electric shock.
Do not install the Refrigerator in a damp place or place where it may come in contact
with water.
• Wet and/or deteriorated insulation of the internal electrical parts may cause electric shock or fire.
Do not store volatile or flammable substances in the Refrigerator.
• Storing benzene, thinner, alcohol, ether, LP gas and other such products may cause explosions.
Do not disassemble or repair the Refrigerator by yourself.
• You may run the risk of fire, appliance malfunctions and/or personal injury. Call your nearest service center
for help from a qualified service technician.
Unplug the Refrigerator before changing the interior light.
• Changing the light while the Refrigerator is plugged in may cause electric shock.
If you wish to dispose of the Refrigerator, remove the doors and seals before throwing
it away.
• The doors(and their seals) can entrap a child if they climb into the Refrigerator.
Make sure that the doors are off, and ensure that no one is suffocated by being locked inside.
The Refrigerator must be safely grounded
• Always make sure that you have grounded the Refrigerator before attempting to investigate or repair any
part of the appliance. Power leakages can cause severe electric shock.
Never use gas pipes, telephone lines or other potential lightning attractors as an
electrical ground.
• Improper use of the grounding plug can result in a risk of electric shock. If it is necessary to use an
extension cord to power the Refrigerator, use only a 3-wire extension cord that has a 3-blade ground
plug and a 3-slot receptacle that will accept the plug on the appliance. The marked rating of the extention
cord should be AC 115V~120V, 10A, or more. Additionally, if a grounding adapter is used, make sure the
receptacle box is also fully grounded.
Safety Information
DA99-01746A(EN)-GGH.indd 4 2008.7.10 12:12:36 PM

CAUTION SIGNS
Use good judgment when filling the Refrigerator with food and drinks.
• In an overfull Refrigerator, heavy, fragile, bulky or breakable items may fall out and cause personal injury
and/or damage to surrounding objects.
Do not put bottles or glass containers in the Freezer drawer.
• When the contents freeze and then expand, the glass may break and cause personal injury or leave
dangerous glass shards in the Freezer.
If the electrical wall socket is loose, do not insert the power plug.
• There is a risk of electric shock or fire. Have the plug looked at by a licensed electrician.
Never unplug your Refrigerator by pulling on the power cord.
• Always grip the power cord firmly and pull straight out from the outlet. Yanking or pulling on the power
cord may cause a short-circuit, fire and/or electric shock.
• A damaged power cord must be replaced by the manufacturer, a certified service agent or qualified
service personnel.
Do not store articles on the top of the appliance.
• When you open or close the door, the articles may fall and cause personal injury and /or damage to
surrounding objects.
Do not store pharmaceutical products, scientific materials and temperature-sensitive
products in the refrigerator.
• Products that require exact temperature controls should not be stored in the Refrigerator.
Do not allow children to climb, stand or hang on shelves and handles of the
Refrigerator. They could damage the Refrigerator and seriously injure themselves.
Do not sit on the freezer door. The door may break.Do not allow children to climb into
the freezer basket.
If you notice a chemical or burning plastic smell or see smoke, unplug the Refrigerator
immediately and contact your Samsung Electronics Service Center.
After your Refrigerator is in operation, do not touch the cold surfaces in the Freezer
compartment. Particularly when hands are damp or wet, skin may adhere to these
extremely cold surfaces.
• Skin may stick to the surface and you may get frostbite.
Do not put your hands under the appliance.
• Any sharp edges may cause personal injury.
CAUTION
DA99-01746A(EN)-GGH.indd 5 2008.7.10 12:12:36 PM

Never put fingers or other objects into the water dispenser hole or ice chute.
• It may cause personal injury and/or material damage.
If the Refrigerator will not be used for a long period of time (for example, over
several months), unplug the power from the wall.
• Over time, deterioration in the power cord insulation may cause fire.
Do not use a wet or damp cloth when cleaning the plug.
Remove any dust or foreign matter from the power plug pins.
• A dirty power plug can increase the risk of fire.
If the Refrigerator is disconnected from the power supply, you should wait for
at least five minutes before plugging it back in.
Do not place the refrigerator directly in sunlight.
The appliance must be positioned for easy access to power source.
If the power cord is damaged, it must be replaced by the manufacturer, a
certified service agent or qualified service personnel.
If you have a long vacation planned, empty the Refrigerator and turn it off.
• Wipe excess moisture from the inside and leave the doors open to keep odor and mold from
developing.
Service warranty and Modification
• Any changes or modifications performed by a 3rd party on this finished appliance is not covered
under Samsung warranty service, nor can Samsung be responsible for safety issues that result
from 3rd party modifications.
Children can get trapped inside Refrigerators.
Before you throw away your old Refrigerator or Freezer, make sure that you;
• Take off the doors.
• Leave all shelves in places so that children may not easily climb inside and shut the door while
they are inside.
This appliance is not intended for use by small children or infirm persons without
capable, adult supervision. Small children should be supervised when using the
appliance.
Do not block air holes
• If the air holes are blocked, especially with a plastic bag, refrigerator can be over cooled.
If this cooling period lasts long, the water filter may break and cause water leakage.
Safety Information
CAUTION
DA99-01746A(EN)-GGH.indd 6 2008.7.10 12:12:36 PM

Contents
SETTING UP YOUR SIDE-BY-SIDE
REFRIGERATOR
08
OPERATING THE SAMSUNG
SIDE-BY-SIDE REFRIGERATOR
18
TROUBLESHOOTING
29
WARRANTY
30
8 Getting ready to install the refrigerator
10 Setting up the refrigerator doors
13 Levelling the refrigerator
14 Making minor adjustments to the doors
15 Checking the water dispenser line
16 Installing the water line
18 Using the control panel/Digital display
20 Controlling the temperature
21 Using the ice and cold water dispenser
22 Storing food
24 Removing the freezer/fridge accessories
25 Cleaning the refrigerator
26 Changing the interior lights, the water filters
27 Using the doors
28 Before using icemaker
29 Troubleshooting
30 Warranty
DA99-01746A(EN)-GGH.indd 7 2008.7.10 12:12:36 PM

8_ setting up
setting up your side-by-side refrigerator
GETTING READY TO INSTALL THE REFRIGERATOR
Congratulations on the purchase of your Samsung Side-By-Side Refrigerator. We hope you will enjoy the many
state-of-the-art features and efficiencies that this new appliance has to offer.
Selecting the best location for the refrigerator
• Select a location with easy access to the water supply.
• Select a location without direct exposure to sunlight.
• Select a location with level (or nearly level) flooring.
• Select a location with enough space for the refrigerator doors to open easily.
• Allow sufficient space to install the refrigerator on a flat surface.
- If your refrigerator is not level, the internal cooling system may not work correctly.
- Overall space required in use. Refer to drawing and dimension as below.
When moving your refrigerator
To prevent floor damage, be sure the front levelling legs are
in the up position (above the floor). Refer to ‘Levelling the
refrigerator’ in the manual(page 12).
To protect the finish of the flooring, place a protection sheet,
such as packing carton under the refrigerator.
When installing, servicing or cleaning behind the
refrigerator, be sure to pull the unit straight out
and push back in straight after finishing.
at least
¼”
at least
¼”
Leg
Screw Driver
CAUTION
DA99-01746A(EN)-GGH.indd 8 2008.7.10 12:12:37 PM

Setting Up _9
SETTING UP THE REFRIGERATOR
Now that you have your new Refrigerator installed in place, you are ready to set up and enjoy the features and
functions of the appliance. By completing the following steps, your Refrigerator should be fully operational.
If not, first check the power supply and electricity source or try the troubleshooting section at the back of
this user’s guide. If you have any further questions, contact your Samsung Electronics service center.
1. Place the Refrigerator in an appropriate location with reasonable clearance between the wall and the
Refrigerator. Refer to installation instructions in this manual.
2. Once the Refrigerator is plugged in, make sure the interior light comes on when you open the doors.
3. Set the Temperature control to the coldest temperature and wait for an hour. The Freezer will get slightly
chilled and the motor will run smoothly.
4. After powering the Refrigerator, it will take a few hours to reach the appropriate temperature. You can
store food and drinks in the Refrigerator after the temperature is sufficiently cool.
Check the accessory list below.
01 SETTING UP
First things first! Make sure that you can easily move your refrigerator to its final location by measuring
doorways (both width and height), thresholds, ceilings, stairways, etc.
The following chart details the exact height and depth.
MODEL RSG25**
Dimensions(inch)
Width Only Cabinet 35 3/4
With Leg Front 35 15/16
Depth
Only Cabinet 23 5/8
With Door 27 7/16
With Handle 30
Height
Only Cabinet 68 5/8
With Hinge 69 5/16
With Door 70
• Allow clearance to the right, left, back and top when installing. This will help reduce power
consumption and keep your energy bills lower.
• Do not install the refrigerator where the temperature can drop below 50°F (10°C).
• Make sure you disconnect the water supply line BEFORE removing the freezer door. See the
next section on “Separating the Water Line” to avoid damage.
Water filter
(DA29-00003B)
Hex wrench
(DA80-00002C)
Compression fitting
(DA62-00305A)
Compression nut
(DA74-00070B)
Clip
(DA61-04521A)
Clip
(DA61-04522A)
Screw
(6001-000541)
DA99-01746A(EN)-GGH.indd 9 2008.7.10 12:12:37 PM

10_ setting up
setting up your side-by-side refrigerator
SETTING UP THE REFRIGERATOR DOORS
If your entrance won’t allow the refrigerator to pass easily through it, you can remove the doors.
Removing the Front Leg Cover
First, open both the freezer and refrigerator doors, and then take off the front leg cover by turning the
three screws counter-clockwise
Separating the Water Supply Line from the Refrigerator
1. Remove the water line(gray and transparent colors) by pressing the coupler 1and pulling the
water line 2away.
Reattaching the Water Supply Line
1. The Water Line must be fully inserted to
the marked line to prevent water leakage
from the dispenser.
2. Insert the 4 clips in the install
pack and check that each clip
holds the line firmly.
Do not cut the water line. Gently separate it from the coupler.
1
2
Make sure the color of the
water lines match.
Line Line
Coupler Coupler
Coupler
clip A
(¼”)
clip B
(5/16”)
clip A
(¼”)
clip A
(¼”)
DA99-01746A(EN)-GGH.indd 10 2008.7.10 12:12:38 PM

setting up _11
Removing the freezer door
A few things to mention first.
• Make sure that you lift the door straight up so the hinges are not bent or broken.
• Be careful not to pinch the water tubing and wire harness on the door.
• Place doors on a protected surface to prevent scratching or damage.
1. With the Freezer door closed, remove the upper hinge cover 1and wire cover 2using a
screwdriver, and then disconnect the wires by gently pulling them apart 3.
2. Remove hinge screws 4and the ground screw 5by turning counter-clockwise, and take off
the upper hinge 6. Be careful that the door does not fall on you as you are removing it
3. Next, remove the door from the lower hinge 7by carefully lifting the door straight up 8.
4. Remove the lower hinge 9from the bracket 10 by gently
lifting the lower hinge upwards.
Reattaching the freezer doors
To reattach the freezer doors, replace parts in reverse order
01 SETTING UP
7
2
1
Be careful not to pinch
the water tubing and
wire harness on the
door.
4
5
6Be sure to keep track of all
parts you are removing.
8
10
9
DA99-01746A(EN)-GGH.indd 11 2008.7.10 12:12:42 PM

12_ setting up
Removing the Fridge Door
1. With the door closed, remove the upper hinge cover 1using a screwdriver.
2. Remove hinge screws 2and the ground screw 3by turning counter-clockwise, and take off
the upper hinge 4. Be careful that the door does not fall on you as you are removing it.
3. Remove the door from the lower hinge 5by lifting the door
straight up 6.
4. Remove the lower hinge 7from the bracket 8by gently
lifting the lower hinge upwards.
Reattaching the Fridge door
To reattach the fridge doors, replace parts in reverse order.
Fixing the Doors
Fix the Doors by
replacing 2 screws( in
the accessory pack) as
shown after finishing all
operations.
1
4
2
3
Be sure to keep track of all
parts you are removing.
DA99-01746A(EN)-GGH.indd 12 2008.7.10 12:12:45 PM

setting up _13
01 SETTING UP
LEVELLING THE REFRIGERATOR
Now that the doors are back on the refrigerator, you want to make sure the refrigerator is level so that you can
make final adjustments. If the refrigerator is not level, it will not be possible to get the doors perfectly even.
The front of the refrigerator is also adjustable.
Before levelling the refrigerator, remove the front leg cover
Open both the freezer and fridge doors, and then take off the front leg cover by turning the three
screws counter-clockwise.
When the Freezer part is lower than the Fridge part.
Insert a flat-blade screwdriver into a slot on the Freezer Leg, then turn it clockwise.
When the Fridge part is lower than the Freezer part.
Insert a flat-blade screwdriver into a slot on the Fridge Leg, then turn it clockwise.
Refer to the next section for the best way to make very minor adjustments to the doors.
Fridge Leg
Screw Driver
Freezer Leg
Screw Driver
DA99-01746A(EN)-GGH.indd 13 2008.7.10 12:12:45 PM

14_ setting up
MAKING MINOR ADJUSTMENTS TO THE DOORS
Remember, a level refrigerator is necessary for getting the doors perfectly even. If you need help, review
the previous section on levelling the refrigerator.
When the door of the freezer is higher
than the fridge
In the case of the process to correct the imbalance is the same. Open the doors and adjust them,
one at a time, as follows:
1. Unscrew the nut 1from the lower hinge until it reaches the upper end of the bolt 2.
When you release the nut 1, make sure that you use the Allen wrench provided 3to loosen
the bolt 2in a counter-clockwise direction. You should then be able to unscrew the nut 1
with your fingers.
2. Adjust the height difference between the doors by turning the bolt 2clockwise or counter
clockwise .
When you turn clockwise , the door will move up.
3. After adjusting the doors, turn the nut 1clockwise until it reaches the lower end of the
bolt, then tighten the bolt again with the wrench 3to fix the nut in place 1.
If you do not secure the nut firmly, the bolt may release.
3
2
1
Wrench
Bolt
Nut
Adjustment part
3
2
1
Wrench
Bolt
Nut
3
2
Wrench
Bolt
DA99-01746A(EN)-GGH.indd 14 2008.7.10 12:12:47 PM

setting up _15
CHECKING THE WATER DISPENSER LINE
A water dispenser is one of the helpful features on your new Samsung Refrigerator. To help promote better
health, the Samsung water filter removes unwanted particles from your water. However, it does not sterilize or
destroy microorganisms. You may need to purchase a water purifying system to do that.
In order for the ice maker to operate properly, a water pressure of 20~125 psi (pound per square inch) is
required. Under normal conditions, a 170 cc (5.75 oz.) paper cup can be filled in 10 seconds.
If the Refrigerator is installed in an area with low water pressure (below 20psi), you can install a booster pump to
compensate for the low pressure.
Make sure the water storage tank inside the Refrigerator is properly filled. To do this, press the water dispenser
lever until the water runs from the water outlet.
Water line installation kits are available at extra cost from your dealer. We recommend using a water supply
kit that contains copper tubing.
Connecting to the water supply line
1. First, shut off the main water supply line and turn the ice-maker off.
2. Locate the nearest cold, drinking water line.
3. After connecting the water supply to the water filter, turn your main water supply back on and flush four
or more gallons into a bucket to clear and prime the water filter.
01 SETTING UP
1Cold water line
2Pipe clamp
3Water line installation kit
4Shut off valve
DA99-01746A(EN)-GGH.indd 15 2008.7.10 12:12:47 PM

16_ setting up
setting up your side-by-side refrigerator
INSTALLING THE WATER LINE
Connecting the water line to the Refrigerator.
There are several items that you need to purchase to complete this connection. You
may find these items sold as a kit at your local hardware store.
• 1/4” compression nut • plastic tubing
• copper tubing • ferrule
1. Slip the compression nut through the supplied plastic tubing .
2. Tighten the compression nut onto the 1/4” compression fitting.
- If you are using copper tubing, slip the compression nut (not included) and ferrule (not included)
on copper tubing (not included) as shown.
- If you are using plastic tubing , insert the molded end of the plastic tubing into the
compression fitting.
3. Tighten the compression nut onto the compression fitting. Do not over-tighten the compression nut .
4. Turn water on and check for any leakage.
Only connect the water line to a drinkable water source.
If you have to repair or disassemble the water line, cut off 1/4“ of the plastic tubing to make sure
you get a snug, leak-free connection.
Installing the water filter.
Before installing the water filter, please remove the
top shelf.
1. Remove the water filter cover( 1)
2. Remove the fixed cap by turning it counter
clockwise. Keep the cap in a safe place for later use
if you don’t use a filter.
3. Remove the water filter from the box and put a
replacement indicator sticker on the filter as shown.
Place a sticker on the filter that dates six months
in the future. For example, if you install the water
filter in March, put the “SEP” sticker on the filter to
remind you to replace in September. That way you’ll
know when it is time to replace the filter. Normally, a
filter life is about 6 months.
1
2 3
Sticker
(month indicator)
1
Need to purchase
Ferrule
(Not supplied)
Copper tubing
(Not supplied)
Compression fitting
(Supplied)
Plastic tubing
(Supplied) Compression nut
(1/4”) (Supplied)
Compression nut
(1/4”) (Not supplied)
Plastic tubing
(Not supplied)
DA99-01746A(EN)-GGH.indd 16 2008.7.10 12:12:49 PM

setting up _17
4. Remove the filter cap and insert the filter
into the filter housing.
5. Slowly turn the water filter 90º clockwise
to align with the printing mark on the
cover, locking the filter in position. Make
sure to align the water filter label mark
with center of cover filter printing as
illustrated. Remember, do not over-
tighten.
Removing any residual matter inside the water
supply line after installing filter.
1. Turn ON the main water supply.
2. Press the water button and push the disperser pad.
3. Run water through the dispenser until the water runs clear (approx.
3L). This will clean the water supply system and remove air from the
lines.
4. Additional flushing may be required in some households.
5. Open the refrigerator door and make sure there are no water leaks
coming from the water filter.
A newly installed water filter cartridge may cause water to briefly
spurt from the water dispenser. This is due to air getting into the
line. It should pose no problem to operation.
Check the amount of water supplied to the ice tray.
1. Lift up the icemaker cover and gently pull it out.
2. When you press the Test button for 3 seconds, the ice cube container is filled with water from the
water supply tap. Check to make sure the amount of water is correct(see the illustration below).
If the water level is too low, the ice cubes will be small. This is a water pressure problem from
within the main water pipes, not the refrigerator.
- It will take a few minutes to reach the amount of water you want.
- Do not press the test button continuously when the tray is filled with ice or water.
Water may overflow or ice jamming may occur.
- When the bucket is not installed, the ice maker does not work.
- When ICE OFF blinks on the display panel, reinsert the bucket and/or make sure it’s
installed properly.
CAUTION
01 SETTING UP
Cover filter
Align the indication
mark with lock position
Separation
of red cap
4 5
Water
Ice
Ice maker
1
Test button
Check the water level
2
DA99-01746A(EN)-GGH.indd 17 2008.7.10 12:12:50 PM

operating the SAMSUNG side-by-side
refrigerator
Using the Control Panel / Digital Display
Power Freeze
Button
Speeds up the time needed to freeze products in the freezer. This can be
helpful if you need to quickly freeze items that spoil easily or if the temperature
in the freezer has warmed dramatically (For example, if the door was left open).
Freezer Button Press the Freezer button to set the freezer to your desired temperature. You
can set the temperature between 8°F and -14°F.
Energy Saver
For better energy efficiency, press the Energy Saver button. If condensation
occurs on the doors, turn the Energy Saver Button function off.
When you change the filter, press and hold this button for 3 seconds to reset
the filter schedule.
Lighting Button Press the Lighting button to turn on the dispenser LED lamp.
Fridge Button
Press the Fridge button to set the fridge to your desired temperature.
You can set temperature between 34°F~46°F.
Power cool will operate when the temperature is set lower than 34°F.
Ice Off Button
Press the Ice Off button to turn the ice making function off.
If press and hold this button for 3 seconds, all buttons will be locked. The Ice
Type button and the dispenser pad will not work either. To cancel this function,
press and hold this button again.
Ice Type Button Press the Ice Type button to choose cubed or crushed ice.
Water Button Press the Water button for water.
18_ Operating
1
2
3
4
5
6
7
8
4
1
7
2
3
5
6
8
DA99-01746A(EN)-GGH.indd 18 2008.7.10 12:12:51 PM

USING THE DIGITAL DISPLAY
“ Freezer Temp.” indicates the current Freezer temperature.
“ Fridge Temp.” indicates the current Fridge temperature.
When not in use the Display will turn off, this is normal.
Power Freeze
This icon will light up when you activate the “Power Freeze” feature. “Power Freeze” is great for times
when you need a lot of ice. When you have enough, just press the button again to cancel the “Power
Freeze” mode.
When you use this function the energy consumption of the refrigerator will increase. Remember
to turn it off when you don’t need it and return the freezer to your original temperature setting.
Energy Saver
This icon will light up when you activate the “Energy Saver” function. The Energy Saver function is
automatically set to “ON” when power is supplied to the Refrigerator. If condensation occurs on the
doors, turn the Energy Saver function off.
Alarm
This icon will be lit all the time. The door alarm will sound if any door is open for more than 2 minutes.
The beeping stops when you close the door. If you need to turn off the Alarm function, press the
Lighting and Fridge buttons for 3 seconds at the same time.
Lighting
This icon will light up when you activate the “Lighting” feature. In this case, the dispenser light (under
the display) will be on constantly. If you would like the dispenser light to come on only when using the
dispenser, turn the “Lighting” feature off by pressing the “Lighting” button..
Power Cool
This icon will light up when you activate the “Power Cool” feature(refer to 5. Fridge Button on Page
18 to select this function). For a quick fridge cool down, use “Power Cool”. If you select “Power
Cool”, the inside temperature of the Fridge will decrease for about two and a half hours.
Filter Indicator
When the filter indicator light changed to red, it is time to change the filter. Typically this happens
about every 6 months.
The filter Indicator will be Blue when you initially insert the water filter.
The filter Indicator will be purple when you have used your water filter for 5 months.
The filter Indicator will be Red when you have used your water filter for 6 months.
After removing the old water filter and installing a new one (see page 29 for instructions on how to do
this), reset the indicator status light by pressing the Ice off button for about 3 seconds.
Cubed Ice , Crushed Ice
Enjoy cubed or crushed ice by selecting your preference from the digital control panel. The ice type
light indicates the type of ice that is currently chosen.
Water
This icon will light up when you activate the “Water” feature.
Operating _19
02 OPERATING
DA99-01746A(EN)-GGH.indd 19 2008.7.10 12:12:52 PM

20_ Operating
Ice Off
This icon will light up when you activate the “Ice Off” feature. In this case, the ice will not be produced.
When ICE OFF blinks on the display panel, reinsert the bucket and/or make sure it’s installed properly.
Child Lock
This icon will light up when you activate the “Lock” feature. In this case, you won’t be able to use the
control panel. If you press and hold the Ice Off/Hold 3 sec for Child Lock Button you will be able to
use the control panel again.
Canceling Cooling Off Mode (“OF & OF” code on the display)
This function is for store display. It is not for customer use.
In case of Cooling Off Mode, It seems working but doesn’t make cool air. To cancel this
mode, press the Power Freeze and Freezer buttons at the same time for 3 seconds
until “Ding-dong” sounds.
CONTROLLING THE TEMPERATURE
Basic Temperature of Freezer and Fridge
The basic and recommended temperature of Freezer and Fridge compartments are -4ºF/38ºF.
If the temperature of Freezer and Fridge compartments are too high or low, adjust the temperature
manually.
Controlling the Freezer temperature
The freezer temperature can be set between 8ºF and -14ºF to suit your particular needs. Press the
Freezer button repeatedly until the desired temperature is shown in the temperature display. Keep in
mind that foods like ice cream may melt at 4ºF.
The temperature display will move sequentially from 8ºF and -14ºF. When the display reaches 8ºF, it
will begin again at -14ºF.
Five seconds after the new temperature is set the display will again show the actual current freezer
temperature. However, this number will change as the Freezer adjusts to the new temperature.
Controlling the Fridge temperature
The refrigerator temperature can be set between 46ºF and 34ºF to suit your particular needs. Press
the Fridge button repeatedly until the desired temperature is shown in the temperature display.
The temperature control process for the Fridge works just like the Freezer process.
Press the Fridge button to set your desired temperature. After a few seconds, the Fridge will begin
tracking towards the newly set temperature. This will be reflected in the digital display.
- The temperature of the freezer or the refrigerator may rise from opening the doors too
frequently, or if a large amount of warm or hot food is placed in either side.
- This may cause the digital display to blink. Once the freezer and refrigerator return to their
normal set temperatures the blinking will stop.
- If the blinking continues, you may need to “reset” the refrigerator. Try unplugging the
appliance, wait about 10 minutes and then plug back in.
CAUTION
Cooling Off
mode
DA99-01746A(EN)-GGH.indd 20 2008.7.10 12:12:52 PM
