Samsung HG50NJ690U User manual
HG43NJ690U HG50NJ690U HG55NJ690U
HG65NJ690U HG75NJ690U
Thank you for purchasing this Samsung product.
To receive more complete service, please register your product at www.samsung.com
Model Serial No.
INSTALL GUIDE
English
Before Reading This Install Guide
This TV B2B (Business to Business) model is designed forhotels orthe other hospitality businesses, supports a variety
of special functions, and lets you limit some user (guest) controls.
Figures and illustrations in this Install Guide are provided for reference only and may differ from the actual product
appearance. Product design and specifications may change without notice.
Operational Modes
This TV has two modes: Interactive and Standalone mode.
Interactive mode: In this mode, the TV communicates with and is fully or partially controlled by a connected Set
Back Box (SBB) orSet Top Box (STB) provided by a hospitality System Integration (SI) vendor. When the TV is initially
plugged in, it sends a command that attempts to identify the SSB or STB connected to it. If the TV identifies the SBB
or STB and the SBB or STB identifies the TV, the TV gives full control to the SBB or STB.
Standalone mode: In this mode, the TV works alone without an external SBB or the STB.
The TV has a Hotel Option menu that lets you easily set its various hospitality functions. Please see page 29.
The menu also lets you activate or de-activate some TV and hospitality functions so you can create youroptimal
hospitality configuration.
Still image warning
Avoid displaying still images (such as jpeg picture files) or still image elements (such as TV channel logos, panorama
uneven screen wear, which will affect image quality. To reduce the chance that this effect will occur, please follow the
recommendations below:
Avoid displaying the same TV channel for long periods.
Always try to display a full screen image.
Reduce brightness and contrast to help prevent the occurrence of after-images.
Use all TV features designed to reduce image retention and screen burn-in.
English - 2
Warning! Important Safety Instructions
Please read the Safety Instructions before using your TV.
CAUTION Class II product: This symbol indicates that a
safety connection to electrical earth (ground) is
not required.
RISK OF ELECTRIC SHOCK. DO NOT OPEN.
AC voltage: Rated voltage marked with this
symbol is AC voltage.
This symbol indicates that high voltage is
present inside. It is dangerous to make any kind
of contact with any internal part of this product.
This symbol indicates that this product has
included important literature concerning
operation and maintenance.
Caution. Consult instructions for use: This
symbol instructs the userto consult the install
guide for further safety related information.
The slots and openings in the cabinet and in the back or bottom are provided for necessary ventilation. To ensure
reliable operation of this apparatus and to protect it from overheating, these slots and openings must never be
blocked or covered.
–
ventilation is provided.
–
–
in a wet basement, or near a swimming pool, etc.). If this apparatus accidentally gets wet, unplug it and contact an
authorized dealer immediately.
This apparatus uses batteries. In your community, there might be environmental regulations that require you to
dispose of these batteries properly. Please contact your local authorities fordisposal or recycling information.
electric shock.
Power-supply cords should be placed so that they are not likely to be walked on or pinched by items placed upon
or against them. Pay particular attention to cords at the plug end, at wall outlets, and at the point where they exit
from the appliance.
To protect this apparatus from a lightning storm, orwhen left unattended and unused forlong periods of time,
unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the set due
to lightning and power line surges.
adaptor corresponds to the local electrical supply.
Neverinsert anything metallic into the open parts of this apparatus. This may cause a danger of electric shock.
To avoid electric shock, never touch the inside of this apparatus. Only a qualified technician should open this
apparatus.
Be sure to plug in the powercord until it is firmly seated. When unplugging the power cord from a wall outlet,
with wet hands.
If this apparatus does not operate normally - in particular, if there are any unusual sounds or smells coming from
it - unplug it immediately and contact an authorized dealeror service center.
Be sure to pull the powerplug out of the outlet if the TV is to remain unused or if you are to leave the house foran
extended period of time (especiallywhen children, elderly, or disabled people will be left alone in the house).
– Accumulated dust can cause an electric shock, an electric leakage, ora fire by causing the power cord to
generate sparks and heat or by causing the insulation to deteriorate.
Be sure to contact an authorized Samsung service center for information if you intend to install yourTV in a location
with heavy dust, high or low temperatures, high humidity, chemical substances, orwhere it will operate 24 hours a
day such as in an airport, a train station, etc. Failure to do so may lead to serious damage to your TV.
Use only a properly grounded plug and wall outlet.
– An improperground may cause electric shock orequipment damage. (Class l Equipment only.)
To turn off this apparatus completely, disconnect it from the wall outlet. To ensure you can unplug this apparatus
quickly if necessary, make sure that the wall outlet and power plug are readily accessible.
Store the accessories (batteries, etc.) in a location safely out of the reach of children.
service center.
not use any chemicals such as wax, benzene, alcohol, thinners, insecticide, airfresheners, lubricants, ordetergents.
These chemicals can damage the appearance of the TV or erase the printing on the product.
There is dangerof an explosion if you replace the batteries used in the remote with the wrong type of battery.
Replace onlywith the same or equivalent type.
Use care when touching the TV after it has been on for some time. Some parts can be warm to the
touch.
English - 4
Contents
Before Reading This Install Guide ---------------------------------------------------------------------------- 2
Warning! Important Safety Instructions ----------------------------------------------------------------------------
01 Package Content
02 TV Installation
---------------------------------------------------------------------------- 8
---------------------------------------------------------------------------- 9
Installing the wall mount kit ---------------------------------------------------------------------------- 12
Securing the TV to the Wall ----------------------------------------------------------------------------
---------------------------------------------------------------------------- 14
Providing properventilation foryour TV ----------------------------------------------------------------------------
03 The Remote Control
About the Buttons on the Remote Control ----------------------------------------------------------------------------
Installing batteries into the remote control ---------------------------------------------------------------------------- 17
04 Initial Setup
Using the TV Controller ---------------------------------------------------------------------------- 19
05 The Connection Panel
06 Connections
Connecting to your Internet network ---------------------------------------------------------------------------- 22
Connecting the TV to an SBB orSTB ---------------------------------------------------------------------------- 24
Connecting the Bathroom Speakers ----------------------------------------------------------------------------
Connecting the RJP (Remote Jack Pack) ---------------------------------------------------------------------------- 27
07 Setting the Hotel Option Menus
----------------------------------------------------------------------------
Welcome Message ----------------------------------------------------------------------------
----------------------------------------------------------------------------
USB Cloning ----------------------------------------------------------------------------
---------------------------------------------------------------------------- 42
Setting Auto Initialize ----------------------------------------------------------------------------
Updating the TV’s Software ---------------------------------------------------------------------------- 48
08 Using a Multi Code Remocon
09 Setting the Soundbar
----------------------------------------------------------------------------
10 Editing Channels
Channel Bank Editor(Smoovie TV Only) ----------------------------------------------------------------------------
Using Channel Editor ----------------------------------------------------------------------------
11 Anti-theft Kensington Lock
12 Specifications and OtherInformation
Specifications ----------------------------------------------------------------------------
Environmental Considerations ----------------------------------------------------------------------------
----------------------------------------------------------------------------
----------------------------------------------------------------------------
----------------------------------------------------------------------------
----------------------------------------------------------------------------
----------------------------------------------------------------------------
Important Warranty Information Regarding Television
Format Viewing ----------------------------------------------------------------------------
----------------------------------------------------------------------------
01 Package Content
Make sure the following items are included with your TV. If any items are missing, contact your dealer.
Remote Control
Batteries (AAA x 2) Power Cord
COMPONENT IN / AV IN Adapter Safety Guide / Quick Setup Guide /
Regulatory Guide
Wall Mount Adapter (x 4)
The items’ colors and shapes mayvary depending on the models.
Cables not included can be purchased separately.
Check for any accessories hidden behind or in the packing materials when opening the box.
The screen can be damaged from direct pressure when handled
incorrectly. As shown in the figure, make sure to grip the edges
of the screen when you lift the TV.
Do Not Touch
This Screen!
English - 7
02 TV Installation
WARNING: If you configure the TV to swivel, you must attach it securely to the floor, a desk, a dressertop,
etc. as described in the installation instructions.
This function is not available on the model.
* 20° swivel
screws as shown below.
60° swivel
screws as shown below.
90° swivel
supplied screws into the stand as shown below.
English - 8
Installing the LED TV Stand
When installing the stand, use the provided components and parts.
AB
(43″-55″) (65″)
CBN96-32380B x 4 (M4 x L14)
DBN96-36261A x 4 (M4 x L14)
E43″-65″: x 4 (M4 x L14, SECURITY)
Stand x 1 Guide Stand x 1 Screws
x 4
(M4 x L14)
43″-55″
1
x 4
(M4 x L14)
65″
2
BN96-36261A x 4 (M4 x L14)
x 4 (M4 x L14, SECURITY)
or
Tight the bottom screw first, and upper screw last.
Progress the assembly of screw in the manual’s order.
Place a soft cloth over the table to protect the TV, and then
place the TV so that its screen faces down toward the table
surface.
Insert the Stand Guide into the slot on the bottom of the TV.
Slide and assemble it to the end line in the direction of arrow.
English - 9
4
NOTE
Make sure to distinguish between the front and back of each component when assembling them.
Make sure that at least two persons lift and move the TV.
AB
x 4 (M4 x L14)
Stand x 1 Screws
1
2
x 4
(M4 x L14)
NOTE
Make sure to distinguish between the front and back of each component when assembling them.
Make sure that at least two persons lift and move the TV.
ABCD
Short Bolt x 2 Washer x 2 Nut x 2
A B
C
D
or
[Affix the stand to a flat surface
such as a dressertop, desk top, or
entertainment center as shown.
WARNING: To prevent injury, you must attach this TV securely to the floor, a table, a dresser top, etc. with
English - 11
Installing the wall mount kit
Wall mount
bracket
Wall mount
bracket
TV
TV
C
Wall mount Adapter
Wall mount Adapter
C
The Product shape may differ depending on the model.
The wall mount kit (sold separately) allows you to mount the TV on a wall.
Fordetailed information on installing the wall mount, see the instructions provided with the wall mount. Contact
a technician forassistance when installing the wall mount bracket. Samsung Electronics is not responsible for any
damage to the product or injury to yourself or others if you select to install the TV on yourown.
English - 12
Securing the TV to the Wall
Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children
do not hang on or destabilize the TV. This action may cause the TV to tip over, causing serious injuries or
death. Follow all safety precautions provided in the Safety Flyer included with your TV. For added stability
and safety, you can purchase and install the anti-fall device.
To Prevent the TV from Falling
1. Insert the screws into the wall brackets and firmly fasten them to the wall. Make sure the screws are firmly fixed to
the wall.
– We strongly recommend you drive the screws into a stud.
2. Insert the screws into the wall brackets and firmly fasten the screws to the top VESA screw holes on the back of
the TV.
3. Connect the brackets on the TV and the brackets on the wall with a strong string or cable, and then tie the string or
cable tightly to the brackets.
– Verify all connections are properly secured. Periodically check the connections forany sign of fatigue orfailure. If
you have any doubt about the security of yourconnections, contact a professional installer.
– Install the TV close to the wall so that it does not fall.
– Connect the string or cable so that the brackets on the wall are at the same height or lowerthan the brackets on
the TV. Untie the string or cable before moving the TV.
Install yourwall mount on a solid wall perpendicular to the floor. If you are attaching the wall mount to building
materials otherthan plaster board, contact your nearest dealer. If installed on a ceiling or slanted wall, the TV may fall
and cause severe personal injury.
The wall mount kit is not supplied, but sold separately.
NOTE
– Standard dimensions forwall mount kits are shown in the table below.
– Samsung wall mount kits contain a detailed installation manual. All parts necessary for assembly are provided.
–
–
specifications. Screws that are too long may cause damage to the inside of the TV set.
– Forwall mounts that do not complywith the VESA standard screw specifications, the length of the screws may
differdepending on the wall mount specifications.
–
personal injury. Samsung is not liable forthese kinds of accidents.
– Samsung is not liable forproduct damage orpersonal injury when a non-VESA ornon-specified wall mount is
used or the consumer fails to follow the product installation instructions.
–
– Always have two people mount the TV onto a wall.
TV size in inches VESA screw hole specs
C (mmStandard
Screw Quantity
M8 4
Do not install yourwall mount kit while your TV is turned on. This may result in personal injury from electric
shock.
English - 14
Providing properventilation foryour TV
When you install yourTV, maintain a distance of at least 4 inchescm) between the TV and other objects (walls,
cabinet sides, etc.) to ensure properventilation. Failing to maintain properventilation may result in a fire ora problem
with the product caused by an increase in its internal temperature.
When you install yourTV with a stand or a wall mount, we strongly recommend you use parts provided by Samsung
Electronics only. Using parts provided by anothermanufacturermay cause difficulties with the product orresult in
injury caused by the product falling.
Installation with a stand Installation with a wall mount
cm
cmcm cmcm
cm
cm
03 The Remote Control
About the Buttons on the Remote Control
The images, buttons, and functions of the remote control may differ depending on the model.
The remote control has Braille points on the Power, Channel, Volume, and Select buttons and can be used by
visually impaired persons.
video sources.
Turns the sound on and off.
Channel List.
Changes channels.
Exits the menu.
Use these buttons according to the
directions on the TV screen.
: Enterthe houryourwant the
TV to turn on.
Use these buttons with a specific
feature, according to the directions
on the TV's screen.
APPS.
screen.
Moves the cursor, selects the
onscreen menu items, and changes
the values seen on the TV's menu.
Turns the TV on and off.
Gives direct access to channels.
Adjusts the volume.
Selects additional digital channels
being broadcast by the same digital
station. Forexample, to select
Returns to the previous channel.
Quickly select frequently used
functions. (Not available)
Returns to the previous menu.
SLEEP
Sets the Sleep Timer.
X
available)
CC
When pressed the button, the
Accessibility Shortcuts menu
appears.
E(Select
Press this button to select orrun a
focused item.
Home Menu.
Installing batteries into the remote control
Match the polarity of the batteries to the symbols in the battery compartment.
Bright light may affect the performance of the remote control. Avoid using near bright fluorescent lights or neon
signs.
The colorand shape of the remote mayvary depending on the model.
English - 17
04 Initial Setup
When you turn on your TV for the first time, it immediately starts the Initial Setup. Follow the instructions displayed on
the screen and configure the TV's basic settings to suit yourviewing environment.
If you already completed the Initial Setup, run the Initial Setup again using the following menu.
Hotel Option (MUTE > 1> 1> 9> SelectE) > System > TV Reset
If you select TV Reset, the TV resets all values to their factory defaults. When the TV turns off, press the POWER button
on the remote control to turn on the TV. The TV starts the Initial Setup.
The image on your TV may differfrom the image above depending on the model and geographical area.
1
Next
Region Settings
Change the region settings ifyou are located in North America, Latin
America, orEurope. Your TV might not function if the region settings arenot
correctly configured. When the region settings are changed, your TV will
automaticallyrestart toapply them.
US
SD_MEXICO
SD_CANADA
CARRIBE
United State of America
Country List
Select the region settings
Before select region, referto the country list information on the right.
If you select the incorrect region, execute TV Reset again after the Initial Setup is
completed.
If the region is changed, the TV automatically turns off and on.
2
Welcome to Samsung TV!
Select yourlanguage to start the on screen setup.
Bienvenue!
Welcome!
Bienvenido!
Use the Up and Down buttons to change the
language.
Next
Selecting your language
3
Next
TV installation Type
Select yourTV installation type.
TV Basic Setup
Cloning Mode
Factory Menu
Start basic setup to use yourTV.
Selecting yourTV installation type
TV Basic Setup: Select to proceed to the next step to set the basic options for
using your TV.
Cloning Mode: Copy the system settings from the USB or server to the TV.
Factory Menu: End Initial Setup and go to Hotel Option menu directly.
4
Next
Configure Your TV
Set basic options to use your TV.
Picture Mode Standard Select the picture mode that best suits your
viewing environment.
12 3
Setting basic options for using your TV
Picture Mode
experience.
5
Next
Scan Channels
Scanning for channels...
DTV Air
DTV Cable
Stop
23
Air
Cable
Previous
Scanning Channel
Afterchannel sanning is completed, select Next or press the right directional
button on the remote control.
When the RF cable is not connected, this step is skipped.
English - 18
6
NextPrevious
Clock Settings
Set the correct time by applying daylight saving time (if
required) and setting yourlocal time zone.
Auto Current Time
--:-- --
23
Clock Mode
--/--/----
Date
--:-- --
Time
Off
DST
Eastern
Time Zone
Setting the current time
If the TVwill be tuned to digital broadcast channels, and these channels transmit
date and time information, set the Clock Mode to Auto. The TV will set the date
and time automatically.
If the TVwill not be tuned to digital broadcast channels, set the Clock Mode to
Manual, and then set the date and time on the TV manually.
Set DSTOn or Off to apply to the TV.
Select your time zone on the map that appears.
7
Setup Complete!
Your TV is now ready to use.
Done
Setup complete
Select the Done button to complete the Initial Setup. Then Hotel Option menu
appears. Press POWER button to exit.
Using the TV Controller
TV Controller button at the bottom of the TV, and then use the Control menu. The
Control menu appears when the TV Controller is pressed while the TV is On. Formore information about its usage, refer
to the figure below.
The screen may dim if the protective film on the SAMSUNG logo or the bottom of the TV is not detached. Please
remove the protective film.
TV Controller / Remote control sensor
Press: Move
Press & Hold: Select
The TV Controller is located on the bottom of the TV.
Control menu
: Power Off : Volume Up
: Channel Up :
: : Source
English - 19
05 The Connection Panel
➀
➁
➂
➃
➄
➅
➆ ➇
➈
➉
AV IN COMPONENT IN
Wheneveryou connect an external device to your TV, make sure that power on the TV and the device is turned off.
When connecting an external device, match the colorof the connection terminal to the cable.
① ,
– Connector for software upgrades and Media Play, etc.
– Service connection.
②
③ HDMI IN1, 2,
–
and video.
–
contact to the Samsung customer care center.
This manual suits for next models
5
Table of contents
Other Samsung UHD TV manuals
Samsung
Samsung 7 Series User manual
Samsung
Samsung UA55NU7100WXXY User manual
Samsung
Samsung NU8000 User manual
Samsung
Samsung UA65NU8500 User manual
Samsung
Samsung UA43RU7100K User manual
Samsung
Samsung UE49NU8000 User manual
Samsung
Samsung UN55NU8000 User manual
Samsung
Samsung QE75QN800BTXXC User manual
Samsung
Samsung QLED 8K QN55Q900RB User manual
Samsung
Samsung HG43EJ670U User manual
Samsung
Samsung LH65QMBEBGCXEN User manual
Samsung
Samsung UE43NU7100U User manual
Samsung
Samsung UA43TU7000 User manual
Samsung
Samsung UA43RU7400 User manual
Samsung
Samsung UE48JU6400 User manual
Samsung
Samsung HG43AJ690UB User manual
Samsung
Samsung QM75F User manual
Samsung
Samsung UE50NU7002U User manual
Samsung
Samsung UE48JU6400 User manual
Samsung
Samsung HG43ET690U User manual
