3-1
3. Disassembly and Reassemble
3. Disassembly and Reassembly
3-1. Disassembly and Reassembly
3-1-1. 49KU6500
CAUTION
Disconnect the LED TV from the power source before disassembly.1.
Follow these directions carefully; never use metal instruments to pry apart the cabinet.2.
Recommend Torque : 22.0 ~ 26.5lbf-
A strength of Torque can be changed depending on the situation.•
Description Picture Description
1
Carefully place the TV on the Curved
Cushion (or any material that will prevent
damage to the screen) so that the screen is
facing downwards.
2
Remove 4 Screws on the TV Stand Guide,
and then remove the Stand in the order
marked as 1~2.
Screws
BN61-09494D (M4,L14)
x 4EA
TORQUE : 22.0 ~ 26.5lbf
1
2

3-2
3. Disassembly and Reassemble
Description Picture Description
3
Remove the 3 screws on the bottom center
of the Rear Cover.
Screws
6001-002755 (M3,L6)
x 3EA
TORQUE : 22.0 ~ 26.5lbf
4
Insert the Samsung Service Jig at the
indicated positions (Holes) to release
bottom corners of the rear cover.
BN81-12884A (SVC-JIG)
Example

3-3
3. Disassembly and Reassemble
Description Picture Description
5
After pushing on coloured points of the
rear cover (in weight less than 10kg) and
inserting a Samsung service jig at holes
of Rear cover's bottom corners, lift up the
rear cover from bottom corners using the
service jig to release the hooks along both
sides of the rear cover.
Then, holding both sides of the rear cover
by hand and releasing the rest hooks on
the upper side of the rear cover, remove it.
All hooks' locations are indicated by Yellow
Circles in the picture.
(Side:8 points / Top:6 points
CAUTION
When you remove the rear cover, hooks
on the upper side of the Chassis Front
can be released. you should check it
before reassembling.
Jig Jig
6
Remove the Speakers and Speaker Cable.
AlsoRemovetheBT/Wimodule,Function
module and Cable of each module.
Speaker
BT/Wimodule
Function module

3-4
3. Disassembly and Reassemble
Description Picture Description
7
emove the Harness Cable (Main B'd
Power), (BLU Power) and the FFC Cable
(Main-Source B'd).
Harness Cable
(BLU Power)
Harness Cable
(Main B'd Power)
FFC Cable
(Main-Source B'd)
8
Remove 5 Screws on SMPS Board, and
then remove the board. (Power Cables
were already removed.)
Screws
6001-003016 5EA
TORQUE : 22.0 ~ 26.5lbf

3-5
3. Disassembly and Reassemble
Description Picture Description
9
Removing Main board.
Gently lift the top right corner of the•
board out to release the lock.
Use both hands to hold the board and•
slide to the left to release it.
CAUTION
When installing the Main board, verify
the board is properly positioned in all 4
mounting slots
1
2
Lift out of locks (top right corners) to release
Slide it out toward the left side to remove the board
* Panel
- Rear Side
CAUTION
Always remember to disconnect the Power Cord before assembling or disassembling the LED TV.1.
Always take precautions and follow the steps properly. Remember to take a picture before2.
disassembling if possible.
Recommeded screwdriver torque : 22.0 ~ 26.5lbf3.
The torque may need to be adjusted accordingly.-
NOTE
Reassembly procedures are in the reverse order of disassembly procedures.

3-6
3. Disassembly and Reassemble
3-1-2. 55KU6500
CAUTION
Disconnect the LED TV from the power source before disassembly.1.
Follow these directions carefully; never use metal instruments to pry apart the cabinet.2.
Recommend Torque : 22.0 ~ 26.5lbf-
A strength of Torque can be changed depending on the situation.•
Description Picture Description
1
Carefully place the TV on the Curved
Cushion (or any material that will prevent
damage to the screen) so that the screen is
facing downwards.
2
Remove 4 Screws on the TV Stand Guide,
and then remove the Stand in the order
marked as 1~2.
Screws
BN61-09494D (M4,L14)
x 4EA
TORQUE : 22.0 ~ 26.5lbf
1
2
3
Remove the screws for the Rear Cover.
Then carefully remove it.
Screws
6001-002755 (M3,L6)
x 17EA
C/R+PANEL: 16EA
C/R+MAIN: 1EA
TORQUE : 22.0 ~ 26.5lbf
CAUTION
When opening the cabinet, hooks at
the upper side of Front Chassis can be
released easily! If it is released after
removing the rear cover, you should
hook it to the bottom chassis before
closing.

3-7
3. Disassembly and Reassemble
Description Picture Description
4
Remove the Filament tape shown on the
image.
CAUTION
WhenassemblingtheTV,thelament
tape must be applied on the same
location. Please remember where the
tapewasrstapplied.
Filament tape
5
Remove the Speakers and Speaker Cable.
AlsoRemovetheBT/Wimodule,Function
module and Cable of each module.
Speaker
BT/Wimodule
Function module

3-8
3. Disassembly and Reassemble
Description Picture Description
6
emove the Harness Cable (Main B'd
Power), (BLU Power) and the FFC Cable
(Main-Source B'd).
Harness Cable
(BLU Power)
Harness Cable
(Main B'd Power)
FFC Cable
(Main-Source B'd)
7
Remove 5 Screws on SMPS Board, and
then remove the board. (Power Cables
were already removed.)
Screws
6001-003016 5EA
TORQUE : 22.0 ~ 26.5lbf

3-9
3. Disassembly and Reassemble
Description Picture Description
8
Removing Main board.
Gently lift the top right corner of the•
board out to release the lock.
Use both hands to hold the board and•
slide to the left to release it.
CAUTION
When installing the Main board, verify
the board is properly positioned in all 4
mounting slots
1
2
Lift out of locks (top right corners) to release
Slide it out toward the left side to remove the board
* Panel
- Rear Side
CAUTION
Always remember to disconnect the Power Cord before assembling or disassembling the LED TV.1.
Always take precautions and follow the steps properly. Remember to take a picture before2.
disassembling if possible.
Recommeded screwdriver torque : 22.0 ~ 26.5lbf3.
The torque may need to be adjusted accordingly.-
NOTE
Reassembly procedures are in the reverse order of disassembly procedures.

3-10
3. Disassembly and Reassemble
3-1-3. 65KU6500
CAUTION
Disconnect the LED TV from the power source before disassembly.1.
Follow these directions carefully; never use metal instruments to pry apart the cabinet.2.
Recommend Torque : 22.0 ~ 26.5lbf-
A strength of Torque can be changed depending on the situation.•
Description Picture Description
1
Carefully place the TV on the Curved
Cushion (or any material that will prevent
damage to the screen) so that the screen is
facing downwards.
2
Remove 4 Screws on the TV Stand Guide,
and then remove the Stand in the order
marked as 1~2.
Screws
BN61-09494D (M4,L14)
x 4EA
TORQUE : 22.0 ~ 26.5lbf
1
2
3
Remove the screws for the Rear Cover.
Then carefully remove it.
Screws
6001-002755 (M3,L6)
x 21EA
C/R+PANEL: 20EA
C/R+MAIN: 1EA
TORQUE : 22.0 ~ 26.5lbf
6003-000003 (M4,L10)
x 1EA
C/R+SMPS: 1EA
TORQUE : 22.0 ~ 26.5lbf

3-11
3. Disassembly and Reassemble
Description Picture Description
4
Remove the Filament tape shown on the
image.
CAUTION
WhenassemblingtheTV,thelament
tape must be applied on the same
location. Please remember where the
tapewasrstapplied.
Filament tape Filament tape
5
Remove 4 Screws on the Bracket (Stand
Link), and then remove it.
6
Remove the Speakers and Speaker Cable.
AlsoRemovetheBT/Wimodule,Function
module and Cable of each module.
Speaker
BT/Wimodule
Function module

3-12
3. Disassembly and Reassemble
Description Picture Description
7
emove the Harness Cable (Main B'd
Power), (BLU Power) and the FFC Cable
(Main-Source B'd).
Harness Cable
(BLU Power)
Harness Cable
(Main B'd Power)
FFC Cable
(Main-Source B'd)
8
Remove 5 Screws on SMPS Board, and
then remove the board. (Power Cables
were already removed.)
Screws
6001-003016 5EA
TORQUE : 22.0 ~ 26.5lbf

3-13
3. Disassembly and Reassemble
Description Picture Description
9
Removing Main board.
Gently lift the top right corner of the•
board out to release the lock.
Use both hands to hold the board and•
slide to the left to release it.
CAUTION
When installing the Main board, verify
the board is properly positioned in all 4
mounting slots
1
2
Lift out of locks (top right corners) to release
Slide it out toward the left side to remove the board
* Panel
- Rear Side
CAUTION
Always remember to disconnect the Power Cord before assembling or disassembling the LED TV.1.
Always take precautions and follow the steps properly. Remember to take a picture before2.
disassembling if possible.
Recommeded screwdriver torque : 22.0 ~ 26.5lbf3.
The torque may need to be adjusted accordingly.-
NOTE
Reassembly procedures are in the reverse order of disassembly procedures.

ANNEX. Exploded View & Part List [UN55KU650DFXZA FA01]
1-1. Exploded View
1-1-1. Parts List
No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN95-02923B PRODUCT LCD-SDC; CY-WK055HGLV2V/H,KU63 1 SA
2 BN96-35008A ASSY SPEAKER P-FRONT; TV-SPK,JU6700,6ohm, 1 SA
3 BN44-00807A DC VSS-PD BOARD; L55S6_FHS,AC/DC,203W,100 1 SA
4 BN94-10827C ASSY PCB MAIN; LED 6K TV 1 SA
5 BN63-15236A COVER-TERMINAL SIDE; 55KU6000,HIPS,MOLD,H 1 SA
6 BN59-01239A NETWORK-WLAN CLIENT; WCK730B,USB 2.0,16P, 1 SA
7 BN96-39955B ASSY BOARD P-IR; KU6300,IR ASSY_KU6300 1 SA
8 BN96-35345B ASSY BOARD P-FUNCTION JOG; JU7500,CT15S 1 SA
9 BN96-40434A ASSY COVER P-REAR; 55KU6300,PC+ABS+GF1 1 SA
10 BN96-36255G ASSY GUIDE P-STAND; JU6670,V STAND,HIPS,B 1 SA
11 BN96-38964J ASSY STAND P-BOTTOM; J5500 48",PC+ABS+GF2 1 SA
ANNEX-1
ANNEX. Exploded View & Part List

Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UN55KU650DFXZA (FA01)
1 R001A BN90-08282A ASSY COVER REAR;LEDTV 6K 1 SNA
0.2 SCREW 6001-002755 SCREW-MACHINE;BH,+,M3,L6,ZPC(BLK),SWRCH1 17 SA
0.2 R001A BN96-40434A ASSY COVER P-REAR;55KU6300,PC+ABS+GF15%, 1 SA
..3 R001 BN63-15774C COVER-REAR;55KU6300,PC+ABS+GF15%,MOLD
,V- 1 SNA
..3 BN68-07838D INLAY-TERMINAL SIDE;55KU6000,PET,T0.125, 1 SNA
1 S001A BN90-08287A ASSY STAND;LEDTV 6K 1 SNA
0.2 SG01A BN96-36255G ASSY GUIDE P-STAND;JU6670,V STAND,HIPS,B 1 SA
..3 0203-001602 TAPE-OPP;#232,0.14,15,50000,YEL 0 SNA
..3 6902-001063 BAG PE;LDPE,T0.05,W180,L350,TRP,RECYCLE 1 SNA
..3 SG03 BN61-11965A GUIDE-STAND;JU6740,PC+GF20%,V-2,BK0007 1 SA
..3 BN96-35528A ASSY ACCESSORY-SCREW;JU7500,40 1 SNA
...4 6902-002474 BAG SCREW;LDPE,T0.05*,W70,L90,TRP,RECYCL 1 SNA
...4 HOLDER-
BOLT BN61-09494D HOLDER-BOLT;BH+,SWRCH18A,BLACK,PRESS,B T 8 SA
0.2 SB02A BN96-38964J ASSY STAND P-BOTTOM;J5500 48",PC+ABS+GF2 1 SA
..3 SCREW 6003-001001 SCREW-TAPTYPE;FH,+,-,B,M3,L8,ZPC(BLK),SW 2 SA
..3 SCREW 6003-001239 SCREW-TAPTYPE;FH,+,B,M4,L10,ZPC(WHT),SWR 4 SA
..3 SCREW 6003-001315 SCREW-TAPTYPE;BH,+,B,M4,L20,ZPC(WHT),SWR 4 SNA
..3 BN61-07463B TAPE-DOUBLE FACE;ACRYL,T0.25,W7,Transpar 0 SNA
..3 BN61-11431B BRACKET-STAND BODY;Y15 F-LED J5100/5500 1 SNA
..3 BN61-13134A BRACKET-STAND BOTTOM;15Y J5500 48",HGI,T 1 SNA
..3 CCM1 BN63-05199H SHEET-PROTECTION COVER;AMBER,PE,T0.08,W1 1 SNA
..3 BN63-13259E COVER-STAND TOP;ABS+PC+GF20%,V-1,Add bra 1 SNA
..3 RF01 BN67-00327M FOOT-RUBBER;STAND,SILICONE,GRAY,T1.5 2 SNA
..3 RF01 BN67-00398P FOOT-RUBBER;SILICONE,GRAY,T2.5 1 SNA
..3 RF01 BN67-00538A FOOT-RUBBER;SILICONE,GRAY,T3 4 SNA
..3 BN68-05381A LABEL-STICKER;ART 100G,T0.08,W20x50,WHIT 2 SNA
..3 BN95-02141D ASSY COVER STAND SMT;J5500 48,48,DARK TI 1 SNA
...4 0204-006861 COATING;SMT-L100,CLEAR,0.928 4 SNA
...4 BN01-00160A TARGET-CHROMIUM CY;Chromium,99.95%,1800x 1 SNA
...4 BN01-00161A TARGET-CHROMIUM PL;Chromium,99.95%,1800x 1 SNA
...4 BN63-14276A COVER-STAND DECORATION;J5500 48",PC+ABS, 1 SNA
...4 BN68-06391B LABEL-STICKER;SMT,ART,W10,L20,Brown,Dark 1 SNA
1 BN90-08338A ASSY W/I;UKU6300G 1 SNA
0.2 BN81-08159Z A/S PART SET-ELEC W/I;LED TV ELEC spec-C 1 SNA
0.2 BN81-11259X A/S PART SET-MECH W/I;UKU6300G,U55KG* 1 SNA
1 M0017 BN91-17362C ASSY CHASSIS;LED TV 6K 1 SNA
0.2 M0014 BN94-10827C ASSY PCB MAIN;LED 6K TV 1 SA
..3 AH63-02994A GASKET;DA-E750,Conductive Fabric,1,10,15 1 SNA
..3 BN62-00817A HEAT SINK-PS;55KU6000,A1050,T1.5,W115,L1 1 SNA
..3 BN63-15236A COVER-TERMINAL SIDE;55KU6000,HIPS,MOLD,H 1 SA
..3 T0527 BN68-00513A LABEL-E PASS;ALL MODEL,WW,YUPO,W50,L15,W 1 SNA
ANNEX-2
ANNEX. Exploded View & Part List
2-1. Electrical Parts List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
..3 BN97-10915A ASSY DRM;JAZZ-L,ATSC,NagSam, MAC, HDCP 1 SNA
...4 BN46-00109H KEY CODE-CERTIFICATION;MAC,TV/AV,General 1 SNA
...4 BN46-00110P KEY CODE-CERTIFICATION;MIRACAST(HDCP2.2) 1 SNA
...4 BN46-00499A KEY CODE-CERTIFICATION;JAZZ-L,Nagra CSC 1 SNA
..3 BN97-10984A ASSY SMD;LED 6K 1 SNA
...4 0202-001976 SOLDER-CREAM;LST-309M-K21,20~38um,96.5Sn 5 SNA
...4 DS01A 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 SA
...4 0403-001164 DIODE-ZENER;MMSZ5232B,5.32~5.88V,500mW,S 1 SA
...4 0403-001783 DIODE-ZENER;BZB84-C6V2,5.8~6.6V,300mW,SO 3 SNA
...4 0403-001831 DIODE-ZENER;KDZ12B,12~13.5V,1000mW,SOD-1 1 SA
...4 0403-002014 DIODE-ZENER;KDZ16B,16.2~18.3V,1000mW,SOD 2 SNA
...4 0404-001307 DIODE-SCHOTTKY;SSC54,40V,5000mA,DO-214AB 1 SA
...4 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 4 SA
...4 0404-001640 DIODE-SCHOTTKY;SS1060HEWS,60V,1000mA,S
OD 1 SA
...4 0404-001881 DIODE-SCHOTTKY;SS3040-HE,40V,3000mA,SOD- 1 SA
...4 0404-001953 DIODE-SCHOTTKY;MBRA340F-HAF,40V,3000mA,S 3 SA
...4 0406-001200 DIODE-TVS;RClamp0504F,6V,1MAV,TP 2 SA
...4 0406-001628 DIODE-TVS;AOZ8804ADI,6V,1MAV,5A,TP 1 SA
...4 0406-001635 DIODE-TVS;SMF5.0A,6.4V,6.7V,7V,200MAV,20 1 SA
...4 0406-001643 DIODE-TVS;1SMA33AT3G,36.7V,38.65V,40.6V, 1 SNA
...4 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, 1 SNA
...4 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 7 SC
...4 0504-000126 TR-DIGITAL;KSR1101,NPN,200mW,4.7K/4.7K,S 1 SA
...4 0505-001844 FET-SILICON;SI4435DDY-T1-GE3,P,30V,-11.4 1 SA
...4 0505-002560 FET-SILICON;AO6415,P,20V,-3.3A,0.15ohm,1 1 SA
...4 0505-002598 FET-SILICON;AP2317GN,P,20V,-4.2A,0.052oh 1 SA
...4 0505-002660 FET-SILICON;Si2308BDS,N,60V,2.3A,0.156oh 1 SNA
...4 0505-002893 FET-SILICON;AO4801AS,P,30V,-5A,2W,SOIC-8 2 SA
...4 0505-003205 FET-SILICON;DMG4435SSS-13,P,30V,-7.3A,1. 1 SA
...4 0505-003391 FET-SILICON;AOD2922,N,100V,8A,140Mohm,18 1 SA
...4 0505-003397 FET-SILICON;2N7002K,N,60V,0.38A,1.19ohm, 1 SA
...4 0505-003507 FET-SILICON;AO3424,N,30V,3.8A,1.4W,SOT-2 5 SA
...4 1001-001998 IC-ANALOG MULTIPLEX;NX3DV221GM,USB switc 2 SA
...4 1103-001564 IC-EEPROM;S-24C512CI-J800,512Kbit,64Kx8, 1 SA
...4 1105-002704 IC-DDR4 SDRAM;K4F8E304HB-MGCH,LPDDR4-
SDR 2 SA
...4 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 SA
...4 1201-003690 IC-AUDIO AMP;TAS5747PHPR,QFP,48P,DUAL,PL 1 SA
...4 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 SA
...4 1203-008102 IC-POSI.FIXED REG.;S-13A1D12-E800,HSOP,8 1 SNA
...4 1203-008104 IC-POSI.FIXED REG.;S-13A1D18-E800,HSOP,8 1 SNA
...4 1203-008105 IC-POSI.FIXED REG.;S-13A1D33-E800,HSOP,8 1 SNA
...4 1203-008391 IC-DC/DC CONVERTER;AOZ1269QI-02,QFN-23L, 1 SA
...4 1203-008392 IC-VOL. DETECTOR;S-6414AAB-L800X,TSOT-23 1 SA
...4 1203-008454 IC-DC/DC CONVERTER;TPS56528,HSOP8,8,4,89 2 SA
...4 1203-008522 IC-DC/DC CONVERTER;SN1501019DDCR,SOT-23, 2 SNA
...4 1203-008551 IC-DC/DC CONVERTER;BM81244,QFN,40P,6x6mm 1 SNA
ANNEX-3
ANNEX. Exploded View & Part List
