Samsung UN55KS9500F User manual

SUHD TV
SERVICEManual
SUHD TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
UN**KS9500F
Chassis : UWQ60
Model : UN55KS9500F
UN65KS9500F

Contents
1. Precautions...................................................................................................................1-1
1-1-1. Warnings...................................................................................................................1-1
1-1-2. Servicing the LED TV ...............................................................................................1-1
1-1-3. Fire and Shock Hazard.............................................................................................1-1
1-1-4. Product Safety Notices .............................................................................................1-2
1-2. Servicing Precautions..........................................................................................................1-3
1-2-1. General Servicing Precautions .................................................................................1-3
1-3. Static Electricity Precautions ...............................................................................................1-4
1-4. Installation Precautions .......................................................................................................1-5
2. Product Specications.................................................................................................2-1
2-1. Product information .............................................................................................................2-1
2-2. Product specication ...........................................................................................................2-2
2-2-1. Specications ...........................................................................................................2-2
2-2-2. Detailed Specications .............................................................................................2-3
2-3. Accessories ...................................................................................................................... 2-11
2-4. Viewing the Functions .......................................................................................................2-13
2-4-1. 2016' Smart Hub...........................................................................................2-13
2-4-2. Picture ....................................................................................................................2-16
2-4-3. Smart Things ..........................................................................................................2-17
2-4-4. Viewing the Panel...................................................................................................2-18
2-4-5. The Samsung Smart Control ..................................................................................2-21
2-4-6. Using Voice Interaction...........................................................................................2-22
2-4-7. Supported Resolutions for UHD Input Signals .......................................................2-23
2-4-8. Supported Formats.................................................................................................2-24
3. Disassembly and Reassembly ....................................................................................3-1
3-1. Disassembly and Reassembly ............................................................................................3-1
4. Troubleshooting ...........................................................................................................4-1
4-1. Previous Check ..................................................................................................................4-1
4-2. How to Check Fault Symptom.............................................................................................4-2
4-2-1. Power .......................................................................................................................4-2
4-2-2. Video.........................................................................................................................4-7
4-2-3. Audio....................................................................................................................... 4-11
4-2-4. Network...................................................................................................................4-12
4-2-5. Smart Hub ..............................................................................................................4-13
4-2-6. Bluetooth / WiFi Module .........................................................................................4-15
4-3. Factory Mode.....................................................................................................................4-16
4-4. Factory Mode Adjustments ................................................................................................4-20
4-4-1. Detail Factory Option..............................................................................................4-20
4-4-2. Factory Data ...........................................................................................................4-22
4-5. RS-232C............................................................................................................................4-35
4-6. AV Control Tabe.................................................................................................................4-36
4-7. Updating the TV’s Software...............................................................................................4-44

5. Wiring Diagram.............................................................................................................5-1
5-1. Wiring Diagram....................................................................................................................5-1
5-2. Connector............................................................................................................................5-4
5-2-1. Main Board ...............................................................................................................5-4
5-2-2. One Connect Board..................................................................................................5-9
5-2-3. SMPS Board........................................................................................................... 5-11
ANNEX. Exploded View & Part List [UN55KS9500FXZA FA01] ......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
1-2. ONE CONNECT Exploded View .............................................................................. ANNEX-2
1-2-1. Parts List........................................................................................................ ANNEX-2
2-1. Electrical Parts List................................................................................................... ANNEX-3
ANNEX. Exploded View & Part List [UN65KS9500FXZA FA01] ......................... ANNEX-1
1-1. Exploded View.......................................................................................................... ANNEX-1
1-1-1. Parts List........................................................................................................ ANNEX-1
1-2. ONE CONNECT Exploded View .............................................................................. ANNEX-2
1-2-1. Parts List........................................................................................................ ANNEX-2
2-1. Electrical Parts List................................................................................................... ANNEX-3

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2016 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea

3-1
3. Disassembly and Reassemble
3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LED TV.
WARNING
This LED TV contains electrostatically sensitive devices. Use caution when handling these components.
3-1. Disassembly and Reassembly
CAUTION
Disconnect the LED TV from the power source before disassembly.1.
Follow these directions carefully; never use metal instruments to pry apart the cabinet.2.
If there is no additional coment, it is same for all inches.3.
Description & Screws Picture Description
1
Place the TV on the Curved Cusion.
2
Remove the COVER-STAND DECORATION and
remove screws.
55" : 3 EA•
65" : 3 EA•
Screws
6003-001880
SCREW-TAPTYPE : M4 x L14, ZPC(BLK)
1
1
2COVER-STAND
DECORATION
3
Remove the ASSY STAND.

3-2
3. Disassembly and Reassemble
Description & Screws Picture Description
4
Remove the screws on ASSY COVER P-REAR
BOTTOM located at the bottom side.
55" : 4 EA•
65" : 4 EA•
Screws
6003-001438
SCREW-TAPTYPE : M2 x L6, ZPC(BLK)
ASSY COVER P-REAR BOTTOM
5
Insert the Samsung Service tool at the indicated
positions to release bottom corners of the ASSY
COVER REAR.
CAUTION
Disassemble ASSY COVER REAR
Insert Open Jig at the left and right side of•
ASSY COVER REAR. Slide it to the red
guideline and remove ASSY COVER REAR.
Do not insert Open Jig at the bottom side•
of ASSY COVER REAR. And do not use
Delpinus Jig.
Slide Open Jig until you hear 3 times of•
unlocking sound 'Tak'.
There are DECORATION at the top side of•
ASSY COVER REAR. And Liv shapes are
located at the both ends of the upper part.

3-3
3. Disassembly and Reassemble
Description & Screws Picture Description
If you slide Open Jig to the end of COVER•
REAR, liv shape can be broken.
Do not slide Open Jig over the guideline.
6
Gently lift up the ASSY COVER REAR from the
bottom corners to release all mounting clips as
indicated by .
7
After removing the ASSY SPEAKER P-FRONT
Cable and remove the ASSY SPEAKER
P-FRONT (A/B/C).
• Speaker Cable
Speaker Cable
8
After removing the ASSY BOARD P-FUNCTION
Cable and remove the IR/FUNCTION.
• ASSY BOARD P-FUNCTION Cable
ASSY BOARD P-FUNCTION Cable
9
After removing the NETWORK Cable and
remove the NETWORK.
• NETWORK Cable
NETWORK Cable

3-4
3. Disassembly and Reassemble
Description & Screws Picture Description
10
Remove the Cables marked.
• Power Cable
• ASSY BOARD P-FUNCTION Cable
Power Cable
ASSY BOARD P-FUNCTION Cable
• USI-T Cable
• BLU Cable
USI-T Cable
BLU Cable
11
After removing the Screws and remove the DC
VSS-PD BOARD(SMPS BOARD).
Screws
6001-003016
SCREW-MACHINE : M3 x L5, ZPC(WHT)
Removing DC VSS-PD BOARD(SMPS BOARD).
Gently lift up (Bottom Left corner) to release•
the lock (Locking ).
Use both hands to hold (Bottom chassis•
Guide Fixing Hole ) the board and slide to
the right to release.
NOTE
When installing the DC VSS-PD BOARD
(SMPS BOARD), verify the board is properly
positioned in all 6 mounting slots.
Bottom chassis Guide Fixing Hole
Locking

3-5
3. Disassembly and Reassemble
Description & Screws Picture Description
12
Removing ASSY PCB MAIN BOARD.
Gently lift up (Top Right corner) to release the•
lock (Locking ).
Use both hands to hold (Bottom chassis•
Guide Fixing Hole ) the board and slide to
the left to release the board.
NOTE
When installing the ASSY PCB MAIN BOARD,
verify the board is properly positioned in all 4
mounting slots.
Bottom chassis Guide Fixing Hole
Locking
13
Completed the disassembly.
NOTE
Reassembly procedures are in the reverse order of disassembly procedures.

ANNEX. Exploded View & Part List [UN55KS9500FXZA FA01]
1-1. Exploded View
1-1-1. Parts List
No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN95-02587C PRODUCT LCD-SDC; CY-XK055FLLV5V/H,KS9000, 1 SA
1-1 BN96-39385A ASSY COVER P-DECORATION; ABS+PC+GF15%,V-1 1 SA
2 BN96-39848B ASSY SPEAKER P-FRONT; 6ohm,-,-,40W,65KS90 1 SA
3 BN96-39849C ASSY SPEAKER P-FRONT; 3ohm,-,-,20W,55KS90 1 SA
4 BN44-00879A DC VSS-PD BOARD; L55E8_KHS,AC/DC,212W,100 1 SA
5 BN94-10844B ASSY PCB MAIN-SDC; UK9W 1 SA
6 BN59-01239A NETWORK-WLAN CLIENT; WCK730B,USB 2.0,16P, 1 SA
7 BN96-39802A ASSY BOARD P-FUNCTION TACT; KS9000,SJ16-0 1 SA
8 BN96-39795A ASSY COVER P-REAR BOTTOM; 55KS9000,NORTH 1 SA
9 BN96-39755A ASSY STAND P-NECK; 55KS9000,ALDC,NATURAL, 1 SA
10 BN96-39751A ASSY STAND P-BOTTOM; 55KS9000,ALDC,NATURA 1 SA
ANNEX-1
ANNEX. Exploded View & Part List

1-2. ONE CONNECT Exploded View
1-2-1. Parts List
No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN96-40188B ASSY COVER P-TOP; 55KS9000,ABS,V-0,BK0008 1 SA
2 BN94-10924A ASSY PCB MISC-ONE CONNECT MINI; Y16 OCM P 1 SA
3 BN63-15074B COVER-BOTTOM; OCM PLUS,PC+ABS,MOLD,V-0,BK 1 SA
ANNEX-2
ANNEX. Exploded View & Part List

Service Bom (SA: SERVICE AVAILABLE, SNA: SERVICE NOT AVAILABLE)
Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
UN55KS9500FXZA (FA01)
1 R001A BN90-08142A ASSY COVER REAR;UK9W,55" 1 SNA
0.2 BN96-39795A ASSY COVER P-REAR BOTTOM;55KS9000,NORTH 1 SA
..3 SCREW 6003-001438 SCREW-TAPTYPE;BH,+,B,M2,L6,ZPC(BLK) 6 SA
..3 BN61-13303A HOLDER-COVER;55KS8000,TPV,BK0008,HB 2 SNA
..3 BN63-07556C SHEET-PROTECTION COVER;TOC,PO,T0.068,W50 1 SNA
..3 BN63-15014A COVER-REAR BOTTOM;55KS9000,PC+ABS+ED20%, 1 SNA
..3 BN64-03528A INLAY-TERMINAL SIDE;55KS7000,PET,T0.125, 1 SNA
..3 BN68-07835A LABEL-STICKER LICENSE;40K5500,PET,0.125, 1 SNA
..3 BN95-02735A ASSY DECORATION SMT-REAR LEFT;KS9000,55" 1 SNA
...4 BN64-03340A COVER-DECORATION REAR LEFT;55KS9000,PC+A 1 SNA
..3 BN95-02736A ASSY DECORATION SMT-REAR RIGHT;KS9000,55 1 SNA
...4 0204-007315 COATING;CVM92000(VOC),CLEAR,1.06 0 SNA
...4 BN01-00160A TARGET-CHROMIUM CY;Chromium,99.95%,1800x 0 SNA
...4 BN01-00161A TARGET-CHROMIUM PL;Chromium,99.95%,1800x 0 SNA
...4 BN63-14373A SHEET-PROTECTION COVER;PO,W25,ROLL,CLEAR 1 SNA
...4 BN64-03363A COVER-DECORATION REAR RIGHT;55KS9000,PC+ 1 SNA
1 S001A BN90-08156A ASSY STAND;UK9W,55" 1 SNA
0.2 SB02A BN96-39751A ASSY STAND P-BOTTOM;55KS9000,ALDC,NATURA 1 SA
..3 6902-002654 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W70,L500 2 SNA
..3 6902-002655 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W80,L350 1 SNA
..3 BN61-13500A BRACKET-STAND BOTTOM;55KS8000,ALDC12,T1, 1 SNA
..3 RF01 BN61-13520A FOOT-RUBBER;KS8000,SI,GRAY,T5,5.5*5.5 5 SNA
..3 BN69-13618B PAD PACKING;65KS9000,PAPER,T0.03,W200,L5 2 SNA
..3 BN69-13618C PAD PACKING;65KS9000,PAPER,T0.03,W300,L5 1 SNA
0.2 SB01A BN96-39755A ASSY STAND P-NECK;55KS9000,ALDC,NATURAL, 1 SA
..3 6902-002656 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W180,L60 1 SNA
..3 BN02-00102B TAPE-FILAMENT;#8917,0.15,25,50,WHITE 0 SNA
..3 BN61-04692A ADHESIVE-AA;SHEET,CLEAR,C043 0 SNA
..3 BN61-07463N TAPE-DOUBLE FACE;ACRYL,T0.25,W12,CLEAR 0 SNA
..3 BN61-13499A BRACKET-STAND NECK;55KS9000,ALDC12,T1,NA 1 SNA
..3 BN61-13784A HOLDER-MAGNET;65KS9000,Nd,T0.6,SILVER,W1 2 SNA
..3 BN63-15139A COVER-STAND DECORATION;ABS,MOLD,HB,SILVE 1 SNA
..3 BN68-05381A LABEL-STICKER;ART 100G,T0.08,W20x50,WHIT 1 SNA
..3 BN69-13618A PAD PACKING;65KS9000,PAPER,T0.03,W700,L4 1 SNA
..3 BN96-36261A ASSY ACCESSORY-SCREW;JU7000 75",6003-001 1 SNA
...4 SCREW 6003-001334 SCREW-TAPTYPE;BH,+,S,M4,L14,ZPC(BLK),SWR 4 SA
...4 6902-002476 BAG SCREW;LDPE,T0.05*,W70,L90,TRP,RECYCL 1 SNA
..3 BN96-40067A ASSY ACCESSORY-SCREW;65KS9000,6003-00188 1 SNA
...4 SCREW 6003-001880 SCREW-TAPTYPE;BH,+,M4,L14,ZPC(BLK),SWRCH 3 SA
...4 6902-002665 BAG SCREW;LDPE,T0.05,W70,L90,TRP,RECYCLE 1 SNA
1 BN90-08294B ASSY W/I;UKS* 1 SNA
0.2 BN81-08159Z A/S PART SET-ELEC W/I;LED TV ELEC spec-C 1 SNA
0.2 BN81-11282R A/S PART SET-MECH W/I;UKS9000W,U55KW* 1 SNA
ANNEX-3
ANNEX. Exploded View & Part List
2-1. Electrical Parts List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
1 BN91-17396A ASSY SHIELD;UK9W,55" 1 SNA
0.2 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 2 SA
0.2 SCREW 6003-000282 SCREW-TAPTYPE;BH,+,-,B,M3,L8,ZPC(BLK),SW 4 SA
0.2 BN02-00102K TAPE-FILAMENT;FILAMENT,T0.15,W25,ROLL,WH 0 SNA
0.2 10P150 BN39-02204A LEAD CONNECTOR-SUB ASSY;55KS9000,Lead Co 1 SA
0.2 30P300 BN39-02206A LEAD CONNECTOR-POWER;55KS9000,UL21016,30 1 SA
0.2 16P250 BN39-02212A LEAD CONNECTOR-SUB ASSY;65KS9000,UL21451 1 SA
0.2 P001 BN44-00879A DC VSS-PD BOARD;L55E8_KHS,AC/DC,212W,100 1 SA
0.2 WIFI BN59-01239A NETWORK-WLAN CLIENT;WCK730B,USB 2.0,16P, 1 SA
0.2 FB01A BN96-39802A ASSY BOARD P-FUNCTION TACT;KS9000,SJ16-0 1 SA
0.2 BN96-39820A FFC CABLE;55KS9000,Fold,L500,96P 1 SA
0.2 BN96-39821A FFC CABLE;55KS9000,Fold,L350,96P 1 SA
0.2 BN96-39848B ASSY SPEAKER P-FRONT;6ohm,-,-,40W,65KS90 1 SA
0.2 BN96-39849C ASSY SPEAKER P-FRONT;3ohm,-,-,20W,55KS90 1 SA
1 M0017 BN91-17405B ASSY CHASSIS;UK9W 1 SNA
0.2 M0014 BN94-10844B ASSY PCB MAIN-SDC;UK9W 1 SA
..3 BN62-00816A HEAT SINK-PS;55KS9000,A1050,T6.3,W145,L1 1 SNA
..3 BN63-15050C COVER-TERMINAL SIDE;55KS9000,HIPS,MOLD,H 1 SA
..3 BN97-10676H ASSY SMD;UKS9000W,55" ZA SDC 1 SNA
...4 0403-001164 DIODE-ZENER;MMSZ5232B,5.32~5.88V,500mW,S 1 SA
...4 0403-001831 DIODE-ZENER;KDZ12B,12~13.5V,1000mW,SOD-1 1 SA
...4 0403-002014 DIODE-ZENER;KDZ16B,16.2~18.3V,1000mW,SOD 2 SNA
...4 0404-001307 DIODE-SCHOTTKY;SSC54,40V,5000mA,DO-214AB 1 SA
...4 0404-001640 DIODE-SCHOTTKY;SS1060HEWS,60V,1000mA,SOD 1 SA
...4 0404-001881 DIODE-SCHOTTKY;SS3040-HE,40V,3000mA,SOD- 1 SA
...4 0404-001953 DIODE-SCHOTTKY;MBRA340F-HAF,40V,3000mA,S 3 SA
...4 0406-001628 DIODE-TVS;AOZ8804ADI,6V,1MAV,5A,TP 1 SA
...4 0406-001643 DIODE-TVS;1SMA33AT3G,36.7V,38.65V,40.6V, 1 SNA
...4 0504-000126 TR-DIGITAL;KSR1101,NPN,200mW,4.7K/4.7K,S 2 SA
...4 0505-001844 FET-SILICON;SI4435DDY-T1-GE3,P,30V,-11.4 4 SA
...4 0505-002598 FET-SILICON;AP2317GN,P,20V,-4.2A,0.052oh 1 SA
...4 0505-002660 FET-SILICON;Si2308BDS,N,60V,2.3A,0.156oh 1 SNA
...4 0505-002893 FET-SILICON;AO4801AS,P,30V,-5A,2W,SOIC-8 1 SA
...4 0505-003205 FET-SILICON;DMG4435SSS-13,P,30V,-7.3A,1. 1 SA
...4 0505-003264 FET-SILICON;AO4447AL,P,30V,-17A,7mohm,3. 1 SA
...4 0505-003391 FET-SILICON;AOD2922,N,100V,8A,140Mohm,18 1 SA
...4 0505-003397 FET-SILICON;2N7002K,N,60V,0.38A,1.19ohm, 1 SA
...4 1001-001998 IC-ANALOG MULTIPLEX;NX3DV221GM,USB switc 1 SA
...4 1006-001576 IC-DRIVER/RECEIVER;MAX3221ECPWR,TSSOP,16 1 SA
...4 1103-001564 IC-EEPROM;S-24C512CI-J800,512Kbit,64Kx8, 1 SA
...4 1105-002704 IC-DDR4 SDRAM;K4F8E304HB-MGCH,LPDDR4-SDR 3 SA
...4 1201-000166 IC-OP AMP;LM358,SOP,ST,8P,150MIL,DUAL,10 1 SA
...4 1201-004003 IC-AUDIO AMP;TAS880021,TSSOP,48P,12.5x6. 3 SA
...4 1203-004364 IC-VOL. DETECTOR;RT9818C-42PV,SOT-23,3P, 1 SA
...4 1203-008102 IC-POSI.FIXED REG.;S-13A1D12-E800,HSOP,8 1 SNA
...4 1203-008105 IC-POSI.FIXED REG.;S-13A1D33-E800,HSOP,8 1 SNA
...4 1203-008391 IC-DC/DC CONVERTER;AOZ1269QI-02,QFN-23L, 1 SA
ANNEX-4
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 1203-008392 IC-VOL. DETECTOR;S-6414AAB-L800X,TSOT-23 1 SA
...4 1203-008664 IC-DC/DC CONVERTER;RT6935BGQW,WQFN,56,7x 1 SA
...4 1203-008667 IC-DC/DC CONVERTER;RT6936A,WQFN,40,6x6mm 1 SA
...4 1203-008732 IC-DC/DC CONVERTER;SYD104ADC,TSOT-23,6,3 1 SA
...4 1203-008733 IC-DC/DC CONVERTER;AOZ1236QI-02,QFN,23,4 1 SA
...4 1203-008735 IC-DC/DC CONVERTER;AOZ1267QI-02,QFN,23,4 1 SA
...4 1204-003679 IC-DECODER;SDP1501,FCPBGAH,1230P,35*35mm 1 SA
...4 1205-004822 IC-SWITCH;TPS22965DSGR,SON,8P,2x2x0.75mm 3 SNA
...4 1205-005554 IC-REPEATER;TMDS181,VQFN,48P,7x7mm,PLAST 1 SA
...4 IS01 1209-002183 IC-SENSOR;S-5851AAA-M6T1U,SOT,6Z30,2.9x1 1 SA
...4 1404-001731 THERMISTOR-NTC;33Kohm,4050K,1mW/C,TP,1.6 2 SNA
...4 1405-001271 VARISTOR;35V,20Vdc,5A,1.0x0.5mm,TP,100V, 10 SA
...4 1405-001381 VARISTOR;11V,8Vdc,30A,1.6x0.8mm,TP,25V,5 3 SA
...4 1405-001382 VARISTOR;24.5V,16VDC,120A,2.0x1.25mm,TP, 2 SA
...4 2007-000039 R-CHIP;0ohm,1%,1/10W,TP,1608 13 SA
...4 2007-000040 R-CHIP;150ohm,1%,1/10W,TP,1608 1 SNA
...4 2007-000052 R-CHIP;10Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-000070 R-CHIP;0ohm,5%,1/10W,TP,1608 11 SA
...4 2007-000084 R-CHIP;4.7Kohm,5%,1/10W,TP,1608 2 SA
...4 2007-000146 R-CHIP;6.8Kohm,5%,1/16W,TP,1005 1 SNA
...4 2007-000309 R-CHIP;10ohm,5%,1/10W,TP,1608 1 SA
...4 2007-000736 R-CHIP;30Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-000932 R-CHIP;470ohm,5%,1/16W,TP,1005 1 SA
...4 2007-000939 R-CHIP;47Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-001125 R-CHIP;68Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-001292 R-CHIP;33ohm,5%,1/16W,TP,1005 12 SA
...4 2007-001298 R-CHIP;51ohm,5%,1/16W,TP,1005 8 SNA
...4 2007-002899 R-CHIP;10ohm,1%,1/10W,TP,1608 9 SA
...4 2007-007131 R-CHIP;13Kohm,1%,1/16W,TP,1005 4 SA
...4 2007-007231 R-CHIP;110Kohm,1%,1/10W,TP,1608 2 SA
...4 2007-007312 R-CHIP;20Kohm,1%,1/16W,TP,1005 13 SA
...4 2007-007313 R-CHIP;6.8Kohm,1%,1/16W,TP,1005 3 SA
...4 2007-007316 R-CHIP;3.3Kohm,1%,1/16W,TP,1005 3 SNA
...4 2007-007317 R-CHIP;2.2Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007334 R-CHIP;200Kohm,1%,1/16W,TP,1005 4 SA
...4 2007-007520 R-CHIP;20ohm,1%,1/10W,TP,1608 18 SA
...4 2007-007528 R-CHIP;1.5Kohm,1%,1/16W,TP,1005 7 SA
...4 2007-007627 R-CHIP;16Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007798 R-CHIP;10ohm,1%,1/16W,TP,1005 10 SA
...4 2007-008136 R-CHIP;36Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-008263 R-CHIP;3Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-008269 R-CHIP;51Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-008298 R-CHIP;49.9ohm,1%,1/16W,TP,1005 16 SA
...4 2007-008391 R-CHIP;6.34Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-008596 R-CHIP;0.1ohm,1%,1/4W,TP,3216 2 SC
...4 2007-009322 R-CHIP;1.3Kohm,1%,1/16W,TP,1005 3 SA
...4 2011-001264 R-NETWORK;10ohm,5%,1/16W,L,CHIP,8P,TP,2. 16 SNA
ANNEX-5
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 AD480 2203-000233 C-CER,CHIP;0.1nF,5%,50V,C0G,TP,1005 10 SA
...4 AD480 2203-000278 C-CER,CHIP;0.01nF,0.5pF,50V,C0G,TP,1005 1 SA
...4 AD480 2203-000386 C-CER,CHIP;0.015nF,5%,50V,C0G,TP,1005 3 SA
...4 AD480 2203-000438 C-CER,CHIP;1nF,10%,50V,X7R,TP,1005 15 SA
...4 AD480 2203-000489 C-CER,CHIP;2.2nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-000714 C-CER,CHIP;3.3nF,10%,50V,X7R,TP,1005 10 SA
...4 AD480 2203-002398 C-CER,CHIP;22nF,10%,50V,X7R,TP,1608 1 SNA
...4 AD480 2203-005054 C-CER,CHIP;0.0047nF,0.25pF,50V,NP0,TP,10 2 SA
...4 AD480 2203-006377 C-CER,CHIP;4700nF,10%,25V,X5R,TP,2012 3 SNA
...4 AD480 2203-006698 C-CER,CHIP;1000nF,10%,25V,X7R,TP,1608,0. 7 SA
...4 AD480 2203-006841 C-CER,CHIP;1000nF,10%,16V,X5R,TP,1005 3 SNA
...4 AD480 2203-006844 C-CER,CHIP;470nF,10%,10V,X5R,TP,1005 3 SA
...4 AD480 2203-007176 C-CER,CHIP;10000nF,10%,16V,X5R,TP,2012,1 25 SNA
...4 AD480 2203-008315 C-CER,CHIP;22000nF,20%,25V,X5R,TP,2012,1 4 SA
...4 2409-001240 C-ORGANIC,SMD;33uF,20%,25V,LR,TP,7343(1. 1 SA
...4 2409-001338 C-POLYMER ,CHIP;47uF,20%,6.3V,TP,3.2x1.6 1 SA
...4 2703-003747 INDUCTOR-SMD;22uH,20%,6060,0.135ohm,1300 2 SA
...4 2703-003862 INDUCTOR-SMD;10uH,20%,6060,0.065ohm,1900 3 SA
...4 2703-003913 INDUCTOR-SMD;2.2uH,20%,2520,1.2T,0.116Oh 1 SNA
...4 2703-003937 INDUCTOR-SMD;1uH,20%,7.0x6.47x3.0mm,0.00 3 SA
...4 2703-004724 INDUCTOR-SMD;8.2uH,20%,4T,0.072Ohm,2300m 10 SA
...4 2703-005376 INDUCTOR-SMD;10uH,20%,10x10.7mm,4.0T,0.0 1 SA
...4 2801-004021 CRYSTAL-SMD;24.576MHz,20ppm,28-AAN,12pF, 1 SA
...4 3301-001364 BEAD-SMD;1000ohm,1608,TP,1085ohm/108MHz, 6 SNA
...4 3601-001376 FUSE-SURFACE MOUNT;32V,3A,FAST-ACTING,Hi 1 SNA
...4 3708-003241 CONNECTOR-FPC/FFC/PIC;96P,0.5mm,SMD-A,AU 2 SNA
...4 3711-007587 CONNECTOR-HEADER;BOX,18P,2R,2mm,ANGLE,SN 1 SA
...4 3711-007741 CONNECTOR-HEADER;BOX,14P,2R,2.0mm,ANGLE, 1 SA
...4 3711-007975 CONNECTOR-HEADER;BOX,10P,1R,1.25mm,SMD-A 1 SA
...4 EH01 3711-008098 HEADER-BOARD TO CABLE;BOX,20P,1R,1.25mm, 1 SNA
...4 3711-009090 CONNECTOR-HEADER;BOX,16P,1R,1.25mm,SMD-A 1 SA
...4 3711-009106 CONNECTOR-HEADER;BOX,20P,2R,2.0mm,ANGLE, 1 SA
...4 3722-003199 JACK-MODULAR;8P/8C,Y,ANGLE,NONE,AU,1PORT 1 SA
...4 3722-003394 JACK-PHONE;1P/6C,AU,BLK,ANGLE,3.6PI,9x14 1 SA
...4 6302-001376 GASKET-SMD;,,CONDUCTIVE FABRIC,T14,W43,L 6 SNA
...4 BN13-00067B IC-PLD;MAXQ636V-2605+T,9,3.3,1.64,3.6,0t 1 SNA
...4 BN41-02504A PCB-MAIN;KS8000/KS9000,FR-4,4L,1.2T,214x 1 SNA
...4 CB07 BN61-13312B BRACKET-PCB;55KS8000,SK5,0.3,13.7,11.4,S 4 SNA
...4 BN97-10856A ASSY MICOM-SUB;JMMICOM_TV,UWQ60,W25Q40CL 1 SNA
....5 1107-002226 IC-NOR FLASH;W25Q40CLSSIP,4Mbit,SOIC,8P, 1 SA
...4 BN97-10857A ASSY MICOM-MAIN;T-JZMAKUC,UWQ60,KLM8G1GE 1 SNA
....5 1107-002362 IC-EMMC;KLM8G1GEND-B031,8GB,64Gb MLC x 1 1 SNA
...4 BN97-10881A ASSY MICOM;TCON,55-SDC-Curved,W25Q80DVSS 1 SNA
....5 1107-002339 IC-NOR FLASH;W25Q80DV,8Mbit,SOP,5.28x5.2 1 SNA
....5 BN46-00508A S/W MICOM;K55ABU0C,SDC,55A1MU*XK,Curved 1 SNA
....5 BN46-00515A S/W MICOM;Jazz M-L,TCON F/W 1 SNA
..3 BN97-10872A ASSY DRM;Jazz M,ATSC,NagSam, MAC, HDCP 1 SNA
ANNEX-6
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 BN46-00109H KEY CODE-CERTIFICATION;MAC,TV/AV,General 1 SNA
...4 BN46-00110P KEY CODE-CERTIFICATION;MIRACAST(HDCP2.2) 1 SNA
...4 BN46-00495A KEY CODE-CERTIFICATION;Jazz-M,Nagra CSC 1 SNA
..3 M0131 MD63-00103A GASKET-TAPE;GRANDSLAM,Conductive Fabric, 2 SNA
1 BN91-17814A ASSY FIXING-JACKPACK;Y16 OCM 1 SNA
0.2 6902-001408 BAG PE;HDPE/PE FOAM,T0.015/T0.5,W120,L25 1 SNA
0.2 BN39-02248A ONECONNECTMINI CABLE;KS7000~KS9000,44,L2 1 SA
0.2 RB01 BN63-15074B COVER-BOTTOM;OCM PLUS,PC+ABS,MOLD,V-0,BK 1 SA
0.2 T0527 BN68-00513A LABEL-E PASS;ALL MODEL,WW,YUPO,W50,L15,W 2 SNA
0.2 BN69-13267A BOX ACCESSORY;CB,SW-E,L373,W308,YELLOW 1 SNA
0.2 OCMPBA BN94-10924A ASSY PCB MISC-ONE CONNECT MINI;Y16 OCM P 1 SA
..3 AH020 BN62-00659A HEAT SINK-ES;UN55H6203AFXZA,A6063,W26.8, 1 SNA
..3 BN97-10869A ASSY SMD;7/8/9 SERIES 1 SNA
...4 0202-001976 SOLDER-CREAM;LST-309M-K21,20~38um,96.5Sn 3 SNA
...4 DS01A 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 2 SA
...4 0403-001783 DIODE-ZENER;BZB84-C6V2,5.8~6.6V,300mW,SO 4 SNA
...4 0404-001404 DIODE-SCHOTTKY;BAT721C,40V,200mA,SOT-23, 3 SA
...4 0406-001200 DIODE-TVS;RClamp0504F,6V,1MAV,TP 1 SA
...4 0406-001317 DIODE-TVS;SMAJ14A,15.6V,17.2V,1MAV,6.5VP 1 SNA
...4 0406-001635 DIODE-TVS;SMF5.0A,6.4V,6.7V,7V,200MAV,20 1 SA
...4 0501-000002 TR-SMALL SIGNAL;KSA812,PNP,150mW,SOT-23, 1 SNA
...4 0501-000445 TR-SMALL SIGNAL;KTC3875S-Y,NPN,150mW,SOT 11 SC
...4 0505-003507 FET-SILICON;AO3424,N,30V,3.8A,1.4W,SOT-2 2 SA
...4 0801-003292 IC-CMOS LOGIC;7WB66,Bus Switch,MAB08A,8P 1 SA
...4 0801-003598 IC-CMOS LOGIC;TC7SZ00FU,2-Input NAND Gat 1 SA
...4 0801-003604 IC-CMOS LOGIC;NL17SZ17DFT2G,SC-70,5P,TP, 1 SA
...4 1103-001583 IC-EEPROM;BR24T02FJ-WGE2,2Kbit,256x8,SOP 4 SNA
...4 1203-008104 IC-POSI.FIXED REG.;S-13A1D18-E800,HSOP,8 1 SNA
...4 1203-008345 IC-POSI.ADJUST REG.;S-13A1ADJ-E800X,HSOP 1 SA
...4 1203-008522 IC-DC/DC CONVERTER;SN1501019DDCR,SOT-23, 3 SNA
...4 1204-003677 IC-DECODER;SDP1503,FCPBGAH,396P,18*18mm, 1 SA
...4 1205-005519 IC-SWITCH;ET20163,SOT23-5,5P,2.95x3.02mm 2 SA
...4 1205-005537 IC-REPEATER;TCA9517,VSSOP,8P,3.00x3.00mm 1 SA
...4 2007-000137 R-CHIP;2Kohm,5%,1/16W,TP,1005 2 SNA
...4 2007-000143 R-CHIP;4.7Kohm,5%,1/16W,TP,1005 11 SA
...4 2007-000157 R-CHIP;47Kohm,5%,1/16W,TP,1005 11 SNA
...4 2007-000171 R-CHIP;0ohm,5%,1/16W,TP,1005 16 SA
...4 2007-000173 R-CHIP;22ohm,5%,1/16W,TP,1005 1 SA
...4 2007-000879 R-CHIP;4.7ohm,1%,1/10W,TP,1608 1 SA
...4 2007-000999 R-CHIP;510ohm,1%,1/10W,TP,1608 1 SA
...4 2007-007107 R-CHIP;100Kohm,1%,1/16W,TP,1005 8 SNA
...4 2007-007108 R-CHIP;43.2Kohm,1%,1/16W,TP,1005 1 SA
...4 2007-007136 R-CHIP;4.7Kohm,1%,1/16W,TP,1005 3 SNA
...4 2007-007138 R-CHIP;27Kohm,1%,1/16W,TP,1005 2 SA
...4 2007-007139 R-CHIP;47Kohm,1%,1/16W,TP,1005,T0.35 2 SA
...4 2007-007142 R-CHIP;10Kohm,1%,1/16W,TP,1005 20 SA
...4 2007-007306 R-CHIP;100ohm,1%,1/16W,TP,1005 3 SNA
ANNEX-7
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 2007-007309 R-CHIP;12Kohm,1%,1/16W,TP,1005,T0.35 1 SA
...4 2007-007318 R-CHIP;1Kohm,1%,1/16W,TP,1005 14 SA
...4 2007-007488 R-CHIP;75Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007517 R-CHIP;240ohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007587 R-CHIP;3.6Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007766 R-CHIP;2Kohm,1%,1/16W,TP,1005 4 SA
...4 2007-007767 R-CHIP;200ohm,1%,1/16W,TP,1005 3 SA
...4 2007-007868 R-CHIP;90.9ohm,1%,1/10W,TP,1608 2 SA
...4 2007-007942 R-CHIP;1Mohm,1%,1/16W,TP,1005 1 SNA
...4 2007-007992 R-CHIP;1ohm,1%,1/10W,TP,1608 1 SA
...4 2007-008015 R-CHIP;75ohm,1%,1/16W,TP,1005 1 SA
...4 2007-008067 R-CHIP;21Kohm,1%,1/10W,TP,1608 1 SA
...4 2007-008134 R-CHIP;12.4Kohm,1%,1/16W,TP,1005 2 SC
...4 2007-008167 R-CHIP;120Kohm,1%,1/16W,TP,1005 1 SNA
...4 2007-008294 R-CHIP;33ohm,1%,1/16W,TP,1005 1 SA
...4 2011-001449 R-NETWORK;22ohm,5%,1/16W,L,4P,TP,1.0x1.0 4 SA
...4 AD480 2203-000359 C-CER,CHIP;0.15nF,5%,50V,C0G,TP,1005,0.5 3 SA
...4 AD480 2203-000425 C-CER,CHIP;0.018nF,5%,50V,C0G,TP,1005 2 SA
...4 AD480 2203-000585 C-CER,CHIP;0.22nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-000812 C-CER,CHIP;0.033nF,5%,50V,C0G,TP,1005 2 SA
...4 AD480 2203-000940 C-CER,CHIP;0.47nF,10%,50V,X7R,TP,1005 1 SA
...4 AD480 2203-002285 C-CER,CHIP;10nF,10%,50V,X7R,TP,1005 1 SNA
...4 AD480 2203-005344 C-CER,CHIP;22nF,10%,25V,X7R,TP,1005,0.5T 2 SNA
...4 AD480 2203-006158 C-CER,CHIP;100nF,10%,16V,X7R,TP,1005,T0. 89 SA
...4 AD480 2203-006324 C-CER,CHIP;2200nF,10%,10V,X5R,TP,1608 7 SA
...4 AD480 2203-006562 C-CER,CHIP;1000nF,10%,10V,X5R,TP,1005 11 SNA
...4 AD480 2203-006824 C-CER,CHIP;4700nF,10%,10V,X5R,TP,1608 2 SNA
...4 AD480 2203-006890 C-CER,CHIP;10000nF,20%,6.3V,X5R,TP,1608 28 SNA
...4 AD480 2203-007240 C-CER,CHIP;22000nF,20%,6.3V,X5R,TP,1608( 3 SA
...4 AD480 2203-007269 C-CER,CHIP;22000nF,20%,10V,X5R,TP,2012(2 15 SA
...4 AD480 2203-007306 C-CER,CHIP;10000nF,10%,25V,X5R,TP,2012,1 6 SNA
...4 AD480 2203-007513 C-CER,CHIP;10000nF,10%,10V,X5R,TP,1608,0 1 SA
...4 AD480 2203-007544 C-CER,CHIP;100nF,10%,50V,X7R,TP,1005,0.5 4 SA
...4 2703-000213 INDUCTOR-SMD;470nH,10%,1.35Ohm,35mA,15,M 1 SA
...4 2703-001938 INDUCTOR-SMD;56nH,5%,1005,1.5Ohm,200mA,1 3 SA
...4 2703-005191 INDUCTOR-SMD;1.5uH,20%,4.5,0.02Ohm,5300m 1 SA
...4 2703-005193 INDUCTOR-SMD;2.2uH,20%,4.5,0.024Ohm,5100 1 SA
...4 2703-005194 INDUCTOR-SMD;3.3uH,20%,4.5,0.03Ohm,4500m 1 SA
...4 2801-005372 CRYSTAL-SMD;24.576MHz,20ppm,HCX-3SB,12 p 1 SA
...4 3301-002039 BEAD-SMD;26ohm,1608,TP 18 SA
...4 3601-001374 FUSE-SURFACE MOUNT;32V,5A,FAST-ACTING,PL 1 SA
...4 3701-001949 CONNECTOR-HDMI;19P,A,FEMALE,AU,0.5mm,BLK 4 SA
...4 3707-001104 CONNECTOR-OPTICAL;ANGLE,SPDIF 1 SA
...4 3710-004144 CONNECTOR-SOCKET;44P,1R,0.5mm,SMD-A,AU,B 1 SA
...4 3722-003457 JACK-USB;4P/1C,NI,BLK,ANGLE,A,2.0,13.1x1 2 SA
...4 BN40-00321A TUNER-DTV AIR CABLE;DTVS20EH6A,DTVS20EH6 1 SA
...4 BN41-02510A PCB-OCM;KS8000/KS9000,FR-4,4L,1.2T,199x6 1 SNA
ANNEX-8
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
...4 BN68-04746A LABEL-SMD;all model,POLY*,polyester,comm 1 SNA
0.2 T001A BN96-40188B ASSY COVER P-TOP;55KS9000,ABS,V-0,BK0008 1 SA
..3 M0131 BN63-00558A GASKET-EMI;GG15AS,Conductive Fabric,T3,W 1 SNA
..3 BN63-07272J SHEET-PROTECTION COVER;OCM+,PE,W205,Roll 0 SNA
..3 F001 BN63-15073B COVER-TOP;OCM PLUS,ABS,HB,K21294,HF-0680 1 SNA
1 BN92-20052A ASSY P/MATERIAL;UK9W,55" 1 SNA
0.2 6902-001611 BAG ROLL;HDPE/PE FOAM,T0.5/T0.015,W1500, 2 SNA
0.2 6922-000013 BAND;PP,W18,L2300/L2900,TRP 1 SNA
0.2 BH69-00418A WRAP;762,1828M,SAMEX FACTORY 2 SNA
0.2 BN02-00319B TAPE-OPP;OPP,T0.05,W75,L800m,CLEAR 3 SNA
0.2 BN68-02422B LABEL-WARNING;ALL,ART,T0.05,W240,L100,Wh 1 SNA
0.2 BN69-00391Y PACKING ANGLE;PAPER 1 SNA
0.2 BN69-13622B PAD-CUSHION FRONT;55KS7500,CB,DW2+EPE,W6 1 SNA
0.2 BN69-13648A CUSHION-SET SIDE;55KS9000,EPS,16.7g/l,WH 1 SNA
0.2 BN69-13649A CUSHION-SET;55KS9000,EPS,16.7g/l,WHT,FLA 1 SNA
1 BN92-20064A ASSY BOX;UK9W,55" 1 SNA
0.2 BH68-00697A LABEL BOX;ALL,ART,90g,W60,L100,WHT,NO SI 1 SNA
0.2 BN69-13661B BOX UNIT;55KS9500,CB,DW3,F1,L1313,W157,H 1 SNA
1 BN92-20072B ASSY LABEL;UK9W 1 SNA
0.2 BN68-05050A LABEL-RATING;ALL MODEL,SS,PE,T0.05,W93,L 1 SNA
0.2 BN68-07834A LEAFLET-QUICK SETUP GUIDE;KS9500,ZA,W/P, 1 SNA
0.2 BN68-07854A LABEL-ENERGY;UN55KS9500FXZA,PET,T0.1,38, 1 SNA
0.2 BN74-00053G TAPE-PAPER;PAPER,3M2307,0.14T,W10,60M,WH 0 SNA
1 ACCE1 BN92-20078U ASSY ACCESSORY;UK9W 1 SNA
0.2 BN96-39424U ASSY ACCESSORY-MANUAL CABLE;UK9W 1 SNA
..3 T0268 3903-000853 CBF-POWER CORD;DT,UL/CSA,LP-11L,125V,7A, 1 SA
..3 4301-000101 BATTERY-ALKALINE;1.5V,1650mAH,LR6,14.5x5 2 SNA
..3 6801-002215 CARD COUPON;7 Series and SUHD, SEA,PLAST 1 SNA
..3 6902-001962 BAG PE;LDPE,BIOBASED,T0.05,W400,L300,TRP 1 SNA
..3 BN59-01241A REMOCON-SMART CONTROL;2016 TV,Samsung,14 1 SA
..3 AH089 BN61-14021A HOLDER-CABLE;55KS8000,PA66,MOLD,BK0007,V 2 SNA
..3 M9889 BN63-02368B CLOTH-CLEAN;CLOTH,W120,L160,sea blue,ToC 1 SNA
..3 BN65-00017A HOLDER-WIRE;PA66,PA66,MOLD,BLACK,V-2 1 SNA
..3 BN68-04972E LEAFLET-REGULATORY GUIDE;ALL,SAMSUNG,W/W 1 SNA
..3 BN68-05723A LABEL-ACCESSORY;ALL MODELS,YUPO,T0.2,W20 1 SNA
..3 BN68-07836A MANUAL USERS;KS9500,ZA,W/P,00 1 SNA
..3 BN68-08011A LEAFLET-QUICK SETUP GUIDE;KS9500,W/P,148 1 SNA
..3 BN96-40106A ASSY ACCESSORY-WALL MOUNT;KS9000,WORLDWI 1 SNA
...4 6902-001404 BAG PE;LDPE,T0.05,W80,L100,TRP,N 1 SNA
...4 BN61-13852A STUD-PEM;55KS9000,SUM24L,W8.0,L43.7,BLAC 2 SNA
...4 BN61-13853A STUD-PEM;55KS9000,SUM24L,W6,L54.9,BLACK 2 SNA
..3 BN96-40150A ASSY HOLDER P-CABLE;65KS9000,ABS,SILVER, 1 SNA
...4 BN61-05704A TAPE-DOUBLE FACE;T1.1,W8,Dark Gray,3M #4 0 SNA
...4 AH089 BN61-13456A HOLDER-CABLE;55KS9000,ABS,MOLD,SILVER,HB 1 SNA
0.2 FC05A BN96-40102A ASSY COVER P-TERMINAL;55UKS9000,PC+ABS+T 1 SA
..3 BN63-12643A SHEET-PROTECTION COVER;ALL MODEL,AL,T0.0 0 SNA
..3 BN63-15418A COVER-TERMINAL;55KS9000,PC+ABS+ED20%,T2. 1 SNA
ANNEX-9
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
..3 T0527 BN68-00513A LABEL-E PASS;ALL MODEL,WW,YUPO,W50,L15,W 1 SNA
1 PANEL BN95-02587C PRODUCT LCD-SDC;CY-XK055FLLV5V/H,KS9000, 1 SA
0.2 6001-002912 SCREW-MACHINE;CH,+,M3,L3,ZPC(BLK),SWRCH1 12 SA
0.2 6001-003168 SCREW-MACHINE;CH,+,M3,L5,ZPC(BLK),SWRCH1 6 SNA
0.2 BN68-05595A LABEL-STICKER;ART 100G,T0.2,W80X23,WHITE 1 SNA
0.2 BN90-07923A ASSY MISC-BLU;LCM 1 SNA
..3 BN61-13647A OPTICAL SHEET-REFLECTOR;16Y_KS9000_55INC 1 SNA
..3 BN61-13662A OPTICAL SHEET-DBEF;16Y_KS9000_55INCH_DBE 1 SNA
..3 BN61-13663A OPTICAL SHEET-COMPLEX;16Y_KS9000_COMPLEX 1 SNA
..3 BN61-13664A OPTICAL SHEET-HIGH COLOR;16Y_KS9000_QD,P 1 SNA
..3 BN61-13688A LGP;16Y_KS9000_55INCH_LGP,MS,MS Lenti (V 1 SNA
..3 BN96-39352A ASSY LED BAR P;55 KS9000_L,ALUMINUM,7032 1 SNA
..3 BN96-39353A ASSY LED BAR P;55 KS9000_R,ALUMINUM,7032 1 SNA
..3 BN96-39383A ASSY CHASSIS REAR P;SECC AG,NATURAL 1 SNA
...4 SCREW 6001-002759 SCREW-MACHINE;CH,+,M3,L4,ZPC(BLK),SWRCH1 6 SA
...4 SCREW 6001-003016 SCREW-MACHINE;PWH,+,M3.0,L5.0,ZPC(WHT),S 14 SA
...4 SCREW 6003-000115 SCREW-TAPTYPE;BH,+,B,M3,L6,ZPC(BLK),SWRC 4 SA
...4 6041-001068 RIVET-PH;SWRCH10A,OD3.2,L4.3,ZPC(WHT) 15 SNA
...4 BN02-00040X TAPE DOUBLE FACE;F-LED ALL,PET,T0.15,W3, 2 SNA
...4 BN02-00102B TAPE-FILAMENT;#8917,0.15,25,50,WHITE 1 SNA
...4 BN02-00493A TAPE PET;55KS9000,PET,T0.05,W5,L50,BLACK 5 SNA
...4 BN02-00497A TAPE DOUBLE FACE;55KS9000,PET,T0.05,W3,L 2 SNA
...4 BN39-02227A LEAD CONNECTOR-BLU;55KS8000,UL21016,18P, 1 SNA
...4 BN60-01049C SPACER-FOAM;55KS9000,PU FOAM,L1213,BLACK 1 SNA
...4 BN60-01409A SPACER-FOAM;55KS9000,PU FOAM,L60,BLACK,T 2 SNA
...4 BN60-01413A SPACER-PU FOAM;55KS9000,PU FOAM,L60,BLAC 3 SNA
...4 BN61-04692A ADHESIVE-AA;SHEET,CLEAR,C043 0 SNA
...4 BN61-05728C TAPE-DOUBLE FACE;ACRYL,T0.4,W16,DARK GRA 3 SNA
...4 BN61-08235A HOLDER-LGP;SNB,SWRCH10A,BLACK,PRESS 2 SNA
...4 BN61-08235F HOLDER-LGP;55KS7500,SWRCH10A,EXTRUSION,S 2 SNA
...4 CB20 BN61-08936C BRACKET-WALL;HGI-SGHC,T2,BLACK,BLACK ED- 2 SNA
...4 CB20 BN61-13221A BRACKET-WALL;55KS8000,EGI-SECC,T1.2,BLAC 2 SNA
...4 BN61-13245C BRACKET-LED PCB;55KS9000,Al,T1.5,NATURAL 1 SNA
...4 BN61-13264A FRAME-CHASSIS REAR;55KS9000,HGI,PRESS,NA 1 SNA
...4 CB18 BN61-13305A BRACKET-STAND LINK;55KS9000,HGI,T2.5,NAT 1 SNA
...4 BN61-13307A BRACKET-CLIP;KS8500,SK5,T0.2 11 SNA
...4 BN61-13557B BRACKET-WIRE;KS7000,SW-C,1,232,SILVER,ZI 2 SA
...4 BN61-13781A HOLDER-LGP LEFT;55KS7500,TPV,BK0008,HB 1 SNA
...4 BN61-13782A HOLDER-LGP RIGHT;55KS7500,TPV,BK0008,HB 1 SNA
...4 BN61-13860A HOLDER-SHEET;55KS9000,ABS,BLACK,HB,DOUBL 5 SNA
...4 BN61-13907A HOLDER-WIRE;55KS9000,PA66,MOLD,NATURAL,V 1 SNA
...4 AH358 BN61-13908A HOLDER-REAR;55KS9000,ABS,MOLD,BK0007,HB 4 SNA
...4 BN63-15279A INSULATOR-SMPS;55KS9000,PC,BLACK,L375,W2 1 SNA
...4 BN63-15282A INSULATOR-SOURCE PCB LEFT;55KS8500,PET,B 1 SNA
...4 BN63-15283A INSULATOR-SOURCE PCB RIGHT;55KS8500,PET, 1 SNA
...4 CC04 BN64-03322A CHASSIS-REAR;EGI-SECC,SECC-AG 1 SNA
...4 BN96-40144A ASSY COVER P-REAR TOP;55KS9000,PC+ABS+ED 1 SNA
ANNEX-10
ANNEX. Exploded View & Part List

Level Location No. Code No. Description & Specication Q’ty SA/SNA Remark
....5 BN63-15013A COVER-REAR TOP;55KS9000,PC+ABS+ED20%,MOL 1 SNA
....5 BN63-15616B SHEET-PROTECTION COVER;55KS8000,PE,T0.05 1 SNA
..3 BN96-39475A ASSY FRAME P-MIDDLE BOTTOM;55KS9000,PC+G 1 SNA
...4 BN02-00493B TAPE PET;49,55KS9000,PET,T0.05,W5,L10,BL 2 SNA
...4 BN60-01175H SPACER-SILICONE;55KS9000,Si,L602,GRAY,T0 2 SNA
...4 BN60-01356G SPACER-FOAM;55KS9000,PU FOAM,L603,WHITE, 2 SNA
...4 BN64-03344A FRAME-MIDDLE BOTTOM;55KS9000,PC+GF10%,V- 1 SNA
0.2 BN96-39136A ASSY OPEN CELL;LSF550FJ08-L,16:9,UHD 120 1 SNA
..3 BN81-07437A A/S-ADHESIVE ACF;LSJ400HL02-E,ADHESIVE A 1 SNA
..3 BN81-07943A A/S-ADHESIVE ACF;LSF320AN01-A,0201-00237 1 SNA
..3 BN81-12875A A/S-POLARIZER TFT;POLARIZER TFT,LJ01-107 1 SNA
..3 BN81-12876A A/S-IC DRIVER SOURCE;IC DRIVER SOURCE,LJ 1 SNA
..3 BN81-12877A A/S-POLARIZER CF;POLARIZER CF,LJ01-10863 1 SNA
..3 BN81-12878A A/S-SOURCE PCB LEFT;SOURCE PCB LEFT,LJ94 1 SNA
..3 BN81-12879A A/S-SOURCE PCB RIGHT;SOURCE PCB RIGHT,LJ 1 SNA
0.2 BN96-39370A ASSY CHASSIS FRONT P;Al,SILVER, HAIR LIN 1 SNA
..3 BN02-00054B TAPE PET;49/55/55(AUO)KS9000,PET,T0.05,W 2 SNA
..3 BN02-00467A TAPE PET;KS9000,PET,T0.05,W10,L10,BLACK 2 SNA
..3 BN02-00486A TAPE DOUBLE FACE;55KS9000,PU FOAM,T0.5,W 3 SNA
..3 BN02-00488A TAPE PET;55KS7500,PET,T0.1,W3.3,L682,BLA 2 SNA
..3 BN02-00489A TAPE PET;55KS7500,PET,T0.22,W3.5,L18,GRE 3 SNA
..3 BN02-00493A TAPE PET;55KS9000,PET,T0.05,W5,L50,BLACK 5 SNA
..3 BN60-01412A SPACER-PU FOAM;65KS9000,PU FOAM,L26,BLAC 2 SNA
..3 BN60-01418B SPACER-FOAM;55KS9000,PU FOAM,L33,BLACK,T 2 SNA
..3 BN60-01418C SPACER-FOAM;55KS9000,PU FOAM,L50,BLACK,T 2 SNA
..3 BN63-15553B SHEET-PROTECTION COVER;55KS9000,PO,T0.04 3 SNA
..3 AC155 BN64-03337A CHASSIS-FRONT;55KS9000,Al,SILVER,SILVER 1 SNA
0.2 BN96-39384A ASSY COVER P-SOURCE PCB LEFT;SECC AG 1 SNA
0.2 BN96-39385A ASSY COVER P-DECORATION;ABS+PC+GF15%,V-1 1 SA
..3 SCREW 6003-001591 SCREW-TAPTYPE;FH,+,B,M2,L5,NI PLT,SWRCH1 2 SNA
..3 SCREW 6003-001881 SCREW-TAPTYPE;CH,+,M2,L3,ZPC(BLK),SWRCH1 14 SA
..3 BN02-00496A TAPE PET;55KS9000,PET,T0.05,W30,L55,BLAC 2 SNA
..3 BN60-01360D SPACER-FOAM;55KS9000,PU FOAM,L1219,BLACK 2 SNA
..3 BN63-14373B SHEET-PROTECTION COVER;PO,W16,ROLL,CLEAR 1 SNA
..3 BN63-15055A COVER-DECORATION LEFT;55KS9000,PC+ABS+MF 1 SNA
..3 BN63-15100A COVER-DECORATION TOP;55KS9000,STS430J1L, 1 SNA
..3 BN63-15321A COVER-DECORATION RIGHT;55KS9000,PC+ABS+M 1 SNA
..3 BN96-39800A ASSY BLU P-DECO;KS9000,M16-KS9000,L44.4, 1 SNA
...4 AS080 BN63-10945A SHEET-PROTECTION COVER;Y13 SF-LED,PO,W10 0 SNA
0.2 BN96-39386A ASSY COVER P-SOURCE PCB RIGHT;SECC AG 1 SNA
..3 BN60-00554A SPACER-SILICONE;SNB 40/46/55,Si,L10,ID2, 4 SNA
ANNEX-11
ANNEX. Exploded View & Part List
