Samsung POWERbot SP2AK9350W series User manual

POWERbot
User manual
SR2AK9350WSeries
• Beforeoperatingthisunit,pleasereadtheinstructionscarefully.
• Forindooruseonly.
1_SR9300K_EN_DJ68-00743A-01_AA.indd 1 2016-01-26 오후 2:15:22

ENGLISH-02
Contents 03 Safety information
10 Installation
Accessories/Installationnote
12 Charging
Automaticcharging/Recharging/Low
battery(Lo)
14 Using POWERbot
Selectingcleaningmodes/Using
Energy-savingmode
16 Using the remote control
19 Name of each part
Top/Bottom/Displaypanel
20 Setting time/schedule
Settingthetime/Settingtheschedule
21 Cleaning and maintaining
Cleaningthedustbin/Cleaningthesensorsand
thecamera/CleaningthePetbrush/Cleaning
theDrivingwheel
23 Samsung Smart Home App
Preparingthenetwork/UsingtheSamsung
SmartHomeapp
31 Notes and cautions
Charging/Inuse/Cleaningandmaintenance/
Aboutbattery/AbouttheIrDAsensor/Aboutthe
boundarymarkers
33 Information codes
34 Troubleshooting
36 Open Source Announcement
37 Specifications
1_SR9300K_EN_DJ68-00743A-01_AA.indd 2 2016-01-26 오후 2:15:22

ENGLISH-03
Safety information
SAFETY INFORMATION
WARNING
•Beforeoperatingtheappliance,pleasereadthismanualthoroughlyandretainit
foryourreference.
WARNING
•Becausethesefollowingoperatinginstructionscovervariousmodels,the
characteristicsofyourvacuumcleanermaydifferslightlyfromthosedescribedin
thismanual.
CAUTION/WARNING SYMBOLS USED
WARNING
Indicates that a danger of death or serious injury exists.
CAUTION
Indicates that a risk of personal injury or material damage exists.
OTHER SYMBOLS USED
NOTE
Indicates that a risk of personal injury or material damage exists.
This Smart Robot vacuum supports from Samsung Smart Home.
More detailed information, please visit Samsung.com/Smarthome.
State of California Proposition 65 Warning (US only)
WARNING
This product contains chemicals known to the State of California to cause
cancer and reproductive toxicity.
L i - i o n
For battery recycling go to call2recycle.org;
or call 1-800-822-8837
1_SR9300K_EN_DJ68-00743A-01_AA.indd 3 2016-01-26 오후 2:15:22

ENGLISH-04
Safety information
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should be observed, including the
following:
READ ALL INSTRUCTIONS BEFORE USING YOUR POWERbot.
Unplug from outlet when not in use and before conducting maintenance.
WARNING: to reduce the risk of fire, electric shock, or injury:
GENERAL
•Useonlyasdescribedinthismanual.
•DonotoperatePOWERbotortheadapter/dockingstationifithasbeendamagedin
anyway.
•Ifthevacuumcleanerisnotworkingasitshould,hasbeendropped,damaged,left
outdoors,ordroppedinwater,returnittoacustomercarecenter.
•Donothandletheadapter/dockingstationorPOWERbotwithwethands.
•Useonlyondry,indoorsurfaces.
•Thisappliancecanbeusedbychildrenagedfrom8yearsandaboveandpersonswith
reducedphysical,sensoryormentalcapabilitiesorlackofexperienceandknowledge
iftheyhavebeengivensupervisionorinstructionconcerninguseoftheapplianceina
safewayandunderstandthehazardsinvolved.
•Childrenshallnotplaywiththeappliance.Cleaningandusermaintenanceshallnotbe
madebychildrenwithoutsupervision.
Adapter / Docking station
•Donotmodifythepolarizedplugtofitanon-polarizedoutletorextensioncord.
•Donotuseoutdoorsoronwetsurfaces.
•Unplugtheadapter/dockingstationfromtheoutletwhennotinuseandbefore
servicing.
•Useonlytheadapter/dockingstationsuppliedbythemanufacturertorecharge.
•Donotusewithadamagedcordorplugoraloosepoweroutlet.
•Donotpullorcarrybythecord,usethecordasahandle,closethedooronthecord,
orpullthecordaroundsharpedgesorcorners.Keepthecordawayfromheated
surfaces.
•Donotuseextensioncordsoroutletswithinadequatecurrentcarryingcapacity.
•Donotunplugbypullingonthecord.Tounplug,grasptheplug,notthecord.
•Donotmutilateorincineratebatteriesastheywillexplodeathightemperatures.
•Donotattempttoopentheadapter/dockingstation.Repairsshouldonlybecarried
outbyaqualifiedcustomercarecenter.
1_SR9300K_EN_DJ68-00743A-01_AA.indd 4 2016-01-26 오후 2:15:22

ENGLISH-05
•Donotexposetheadapter/dockingstationtohightemperaturesorallowmoistureor
humidityofanykindtocomeintocontactwiththeadapter/dockingstation.
POWERbot
•Donotpickuphardorsharpobjectssuchasglass,nails,screws,coins,andetc.
•Donotusewithoutafilterinplace.Whenservicingtheunit,neverputfingersorother
objectsintothefanchamberincasetheunitaccidentallyturnson.
•Donotputanyobjectsintoopenings.Donotusewithanyopeningsblocked;keep
openingsfreeofdust,lint,hair,andanythingthatmayreduceairflow.
•Donotpickuptoxicmaterials(chlorinebleach,ammonia,draincleaner,etc.).
•Donotpickupanythingthatisburningorsmoke,suchascigarettes,matches,orhot
ashes.
•Donotusetopickupflammableorcombustibleliquidssuchasgasoline,noruseon
areaswheretheymaybepresent.
•Locationswithcandlesordesklampsonthefloor.
•Locationswithunattendedfires(fireorembers).
•Locationswithdistilledalcohol,thinner,ashtrayswithburningcigarettes,etc.
•DonotusePOWERbotinanenclosedspacefilledwithvapoursgivenoffbyoilbased
paint,paintthinner,mothproofingsubstances,flammabledust,orotherexplosiveor
toxicvapours.
•Leaksfrombatterycellscanoccurunderextremeusageortemperatureconditions.
Iftheliquidgetsonskin,washquicklywithwater.Iftheliquidgetsintotheeyes,
flushthemimmediatelywithcleanwaterforaminimumof10minutes.Seekmedical
attention.
SAVE THESE INSTRUCTIONS
POLARIZED PLUG INSTRUCTIONS
•Toreducetheriskofelectricshock,thisappliancehasapolarizedplug(onebladeis
widerthantheother).Thisplugwillfitinapolarizedoutletonlyoneway.Iftheplug
doesnotfitfullyintheoutlet,reversetheplug.Ifitstilldoesnotfit,contactaqualified
electriciantoinstallaproperoutlet.Donotmodifythepluginanyway.
1_SR9300K_EN_DJ68-00743A-01_AA.indd 5 2016-01-26 오후 2:15:22

ENGLISH-06
Safety information
REGULATORY NOTICE
1. FCC Notice
CAUTION
FCC CAUTION:
•Anychangesormodificationsnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser’sauthoritytooperatetheequipment.
•ThisdevicecomplieswithPart15ofFCCRules.OperationisSubjecttofollowingtwo
conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received including interference that
cause undesired operation.
•ForproductavailableintheUSA/Canadamarket,onlychannel1~11canbeoperated.
Selectionofotherchannelsisnotpossible.
FCC STATEMENT:
•ThisequipmenthasbeentestedandfoundtocomplywithinthelimitsforaClass
Bdigitaldevice,pursuanttopart15oftheFCCRules.Theselimitsaredesignedto
providereasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.
•Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergyand,ifnot
installedandusedinaccordancewiththeinstructions,maycauseharmfulinterference
toradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccur
inaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradio
ortelevisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,
theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing
measures:
–Reorientorrelocatethereceivingantenna
–Increasetheseparationbetweentheequipmentandreceiver
–Connecttheequipmentintoanoutletonadifferentcircuitfromthattowhichthe
receiverisconnected
–Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
FCC RADIATION EXPOSURE STATEMENT:
•ThisequipmentcomplieswithFCCradiationexposurelimitssetforthforanuncontrolled
environment.Thisequipmentshouldbeinstalledandoperatedwithaminimumdistance
of20cmbetweentheradiatorandyourbody.Thisdeviceanditsantenna(s)mustnot
beco-locatedoroperationinconjunctionwithanyotherantennaortransmitter.
1_SR9300K_EN_DJ68-00743A-01_AA.indd 6 2016-01-26 오후 2:15:22

ENGLISH-07
2. IC Notice
•Theterm“IC”beforetheradiocertificationnumberonlysignifiesthatIndustryCanada
technicalspecificationsweremet.Operationissubjecttothefollowingtwoconditions:
(1)thisdevicemaynotcauseinterference,and(2)thisdevicemustacceptany
interference,includinginterferencethatmaycauseundesiredoperationofthedevice.
•ThisClassBdigitalapparatuscomplieswithCanadianICES-003.
•CetappareilnumériquedelaclasseBestconformeálanormeNMB-003duCanada.
•ForproductavailableintheUSA/Canadamarket,onlychannel1~11canbeoperated.
Selectionofotherchannelsisnotpossible.
IC RADIATION EXPOSURE STATEMENT:
•ThisequipmentcomplieswithICRSS-102radiationexposurelimitssetforthforan
uncontrolledenvironment.Thisequipmentshouldbeinstalledandoperatedwith
minimumdistance20cmbetweentheradiator&yourbody.Thisdeviceandits
antenna(s)mustnotbeco-locatedoroperationinconjunctionwithanyotherantennaor
transmitter.
Open Source License Notice
•Thisdeviceusesopensourcesoftware.OpenSourceLicensesareavailableonthe
productmenu.
•Tap“Settings>Network>SoftwareUpdate>LegalInformation”onthedeviceformore
details.
1_SR9300K_EN_DJ68-00743A-01_AA.indd 7 2016-01-26 오후 2:15:22

ENGLISH-08
WARNING Power related
fPleasepreventanyriskofelectricshockor
fire.
–Donotdamagethepowercord.
–Donotpullthepowercordtoohardortouch
thepowerplugwithwethands.
–Donotuseapowersourceotherthan100-
240V~andalsodonotuseamultioutletto
supplypowertonumberofdevicesatthesame
time.(Donotleavethecordcarelesslyonthe
floor.)
–Donotuseadamagedpowerplug,powercord
orloosepoweroutlet.
fCleandustoranyforeignmattersonthepin
andcontactpartofthepowerplug.
–Thereisariskofelectricshockormalfunction.
WARNING Before use
fDonotusePOWERbotnearcombustible
materials.
–Placenearcandle,desktoplamps,fireplaceor
nearcombustiblematerialssuchasgasoline,
alcohol,thinnersetc.
fThePOWERbotisintendedforhousehold
usethereforedonotuseitinanattic,
basement,storage,industrialbuilding,outof
indoorspace,placeswithmoisture(suchas
bathroom,laundry),onthetableorshelves.
–ThePOWERbotcanbedamagedor
malfunction.
fBesurePOWERbotdoesnotpassthroughor
touchanykindofliquids.
–ThePOWERbotcanbeseverelydamagedand
itmaycontaminateotherareasifthewheels
passthroughliquid.
fDonotspillanyliquidsonthedockingstation.
–Thereisariskoffireorelectricshock.
fDonotusethedockingstationforanything
otherthanitsintendedpurpose.
–Thereisariskoffireorseveredamagetothe
dockingstation.
fAlwayskeepthecliffsensorcleanforyour
safety.
WARNING In use
fIfanyabnormalsounds,smellsorsmoke
comefromPOWERbot,immediatelyshut
offtheemergencyswitchatthebottomof
POWERbotandcontactaservicecenter.
WARNING Cleaning and
maintenance
fWhenpowercordisdamaged,contacta
servicecentertogetitreplacedbycertified
repairman.
–Thereisariskoffireorelectricshock.
fPleasecheckwithaSamsungElectronics
servicecenterwhenexchangingbatteries.
–Usingbatteriesfromotherproductscancause
malfunction.
Safety information
1_SR9300K_EN_DJ68-00743A-01_AA.indd 8 2016-01-26 오후 2:15:22

ENGLISH-09
CAUTION Before use
fInsertthedustbinbeforeusingPOWERbot.
fBecarefulwiththefollowingsforproper
automaticrecharging.
–Alwaysturnonthepowerofthedocking
station.
–InstallthedockingstationwherePOWERbot
caneasilyfind.
–Donotleaveanyobjectinfrontofthedocking
station.
fWheninstallingthedockingstation,donot
leavethecordcarelesslyonthefloorsince
POWERbotmaygettangledbyit.
fDonotusePOWERbotonblackcolored
floors.
–ThePOWERbotmaynotbeabletooperate
normally.
fDonotpickupPOWERbotbythedustbin
holder.
fDonotplaceanyobjectswithin19in(0.5m)
tobothsidesand39in(1m)tothefrontof
thedockingstation.
fMakesurethedockingstation'scharging
contactisnotdamagedorhaveanyforeign
mattersonit.
fDonotinstallthedockingstationinanarea
withadarkfloor.
–Iftheflooraroundthedockingstationisdark,
rechargingishindered.
fMoveanyobstaclesthatmaydisturb
POWERbot'smovement(suchaschildren's
indoorswingorslides)beforecleaning.
CAUTION In use
fUsingPOWERbotonthickcarpetmay
damagebothPOWERbotandthecarpet.
–ThePOWERbotcannotpassovercarpetthatis
thickerthan0.4in(1cm).
fDonotusePOWERbotontablesorother
highsurfaces.
–Thereisariskofdamageifitfalls.
fThePOWERbotmaybumpintochair,desk
legsthereforemovethemawayforfasterand
efficientcleaning.
fWhenPOWERbotisoperating,donotliftitup
orcarryittoanotherarea.
fDonotholdbydrivingwheelsofPOWERbot
whencarryingittoanotherarea.
fDonotputanyobjectsontopofPOWERbot
sinceitmaycausemalfunction.
fRemoveanylargepapersorplasticbags
immediatelywhenusingPOWERbotsince
theymayblocktheintake.
fDonotaimtheredpointerdirectlyatpeople
oranimals.
CAUTION Cleaning and
maintenance
fPreventanydamagetoPOWERbotby
complyingthefollowings.
–DonotcleanPOWERbotbysprayingwater
directlyontoitorusebenzene,thinner,acetone
oralcoholtocleanit.
fDonotdisassembleorrepairPOWERbot.
Thisshouldonlybedonebyacertified
repairman.
fAlwayskeeptheobstaclesensorandcliff
sensorclean.
–Ifforeignmatteraccumulates,sensorsmay
malfunction.
1_SR9300K_EN_DJ68-00743A-01_AA.indd 9 2016-01-26 오후 2:15:22

ENGLISH-10
1Connect the
adapter jack
to the docking
station
2Connect the
power cord to
the adapter
Whenusingtheadapter,
thesidewiththesticker
attachedmustfacedown.
3Connect the
power plug to
the outlet
Thepowerindicatorlamp
(Red)willturnon.
Installation
The docking station must be plugged in and turned on at all times.
DC-IN
DC-IN
Powerlamp(Red)
About39in
(1m)
About19in
(0.5m)
About
19in
(0.5m)
Installthedockingstationinaplace
withoutobstaclesanddangerof
falling.
1_SR9300K_EN_DJ68-00743A-01_AA.indd 10 2016-01-26 오후 2:15:23

ENGLISH-11
Accessories
Remote control Batteries (AAA
type)
User manual Spare filter Cleaning brush
Docking station Power cord Adapter Boundary markers
 Refertopage32fortheinstallationofboundarymarkers.
Installation note
Note
fInstallthedockingstationinaplacewherethefloorandwallarelevel.
fItisbesttoinstallthedockingstationalongthegrainofwoodenfloors.
fIftheemergencyswitchisoff,thePOWERbotwillnotchargeevenifitisdockedonthedocking
station.
fAlwaysturnonthepowerofthedockingstation.
–Ifpowerisnotsuppliedtothedockingstation,thePOWERbotcannotfinditandcannotautomatically
recharge.
–IfthePOWERbotisleftdetachedfromthedockingstation,thebatterywilldrainnaturally.
fIfthePOWERbotisinsleepmode,powerwillnotcomeoneveniftheemergencyswitchisturned
offandthenon.Pressandholdthe[Start/Stop]buttononthePOWERbottoturnthesleepmode
off.
1_SR9300K_EN_DJ68-00743A-01_AA.indd 11 2016-01-26 오후 2:15:23

ENGLISH-12
Charginglightturnsgreenduringcharging.
It takes approximately 240 minutes to
completely charge the POWERbot when
charging it for the first time after purchase.
Once charged, the POWERbot can be used
for approximately 30 minutes in Max mode.
Charging
1Turn on the
emergency switch
on the bottom
Youmustturnonthe
emergencyswitchtoturnon
thePOWERbot.
Pressandreleasethe
button.
2Manually charge
the POWERbot by
placing it on the
docking station
Makesurethechargingpins
onthePOWERbotandthe
dockingstationarealigned.
3Check the
charging status
“ ”willturnon
accordingtocharging
progressand"FULL"will
turnonwhenchargingis
complete.
WARNING
•Ratedinputvoltageofthisproduct
is100-240V~.
1_SR9300K_EN_DJ68-00743A-01_AA.indd 12 2016-01-26 오후 2:15:23

ENGLISH-13
When the battery indicator blinks
during cleaning, the POWERbot
will return to the docking station to
charge itself automatically.
Automatic charging
You can command the POWERbot
to recharge at the docking station
while it is in cleaning.
Recharging
Manually charge the POWERbot by
placing it on the docking station.
Low battery (Lo)
Steps to take if recharging not occuring:
Check the installation status of the
docking station when:
fthedockingstationislocatedinaplacewherethe
POWERbotcannoteasilyaccessit.
fthedistancebetweenthedockingstationand
POWERbotisover196.8in(5m)
-ItmaytakealongtimeforPOWERbottoreturnto
thedockingstationforrecharging
Manually charge the POWERbot when:
fthedockingstationislocatedinacorner
fthebatteryisfullyexhausted
fthePOWERbotisimmobilizedbyanobstacle
(furnitureetc.)
fthePOWERbotcan'tclimbathresholdnearthe
dockingstation(Themaximumheightofathreshold
thePOWERbotcanclimbisabout0.8in(2.0cm)).
fwhenthebatteryindicatorblinksand"Lo"is
displayed
fwhenthePOWERbotissettotheSpotcleanor
Manualcleanmode
1_SR9300K_EN_DJ68-00743A-01_AA.indd 13 2016-01-26 오후 2:15:24

ENGLISH-14
Using POWERbot
You must turn on the emergency switch on the bottom of the unit before using POWERbot.
Turning the power on/off
Press the button for more than
3 seconds
Starting Auto clean mode
Pressandreleasethisbutton.ThePOWERbot
movesandcleansautomaticallyuntilthebatteryis
depleted.
 Stopcleaning:Pressandreleasethe button
Recharging/Energy-saving
mode
fRecharging
YoucancommandPOWERbottorechargeatthe
dockingstationautomaticallywhileitiscleaning
bypressingthisbutton.
fEnergy-savingmode
Refertopage16.
Using Spot clean mode
ThePOWERbotcleansalocalizedareaintensely.
WARNING
•WhenPOWERbotisnotusedfor
30minutes,itwillreturntothecharger
tochargeitselfautomatically.
1_SR9300K_EN_DJ68-00743A-01_AA.indd 14 2016-01-26 오후 2:15:24

ENGLISH-15
Cleaning mode How to select Displayed icon
Auto clean
Spot clean
 Spotcleanmodecanbeselectedonly
bypressingthisbuttononthemain
bodyofthePOWERbot.
Manual clean
 Manualcleanmodecanbeselected
bythedirectioncontrolbuttonsofthe
remotecontrol.
 WhendustintakeisdetectedinSpot/Manualcleanmode,suctionofthePOWERbotwillbecome
stronger.
 Chargingandcleaningtimescandifferaccordingtoconditionsofuse.
Cleaning method for each modes
About59in(1.5m)
About59in(1.5m)
Auto clean
Cleansautomaticallyuntilthe
batteryisdepleted.
Spot clean
Cleansalocalizedarea
intensely.Itcanbeusedto
cleanbreadorcookiecrumbs.
Manual clean
YoucanmovePOWERbotwith
theremotecontroltocleanthe
desiredspot.
Selecting cleaning modes
1_SR9300K_EN_DJ68-00743A-01_AA.indd 15 2016-01-26 오후 2:15:24

ENGLISH-16
Using Energy-saving mode
YoumayselecttheEnergy-savingmodewhenyougooutforalongtimeorwanttosaveenergy.
YoucanselectorcanceltheEnergy-savingmodeonlywhilethePOWERbotisdockedonthedockingstation.
How to select or cancel Displayed icon
Pressfor5sec.
 About3secondslater,
thepreviousindicatorwill
appear.
 WhenthePOWERbotisintheEnergy-savingmode,thegreenlampofthedockingstationwillblink.
Note
fIfyouselecttheAuto/ManualcleanmodeorpressPointcleaningbutton,theEnergy-savingmode
willbecancelled.
fIfyousetscheduleintheEnergy-savingmode,themodewillbecancelled.
–IfyouselecttheEnergy-savingmodeaftersettingtheschedule,theschedulewillnotbecancelled.
fIfthepowerofthedockingstationisoff,theEnergy-savingmodewillbecancelled.
Location recognizing function
fIfthePOWERbotisrepositionedwhenthecleaningisnotcompleteorifthePOWERbotoperatesagainafter
anInformationcodeappears,itsearchesthecurrentlocationandcleanstheareawherewasnotcleaned
previously.
-Whenthelocationrecognizingfunctionoperates,thePOWERbotsearchesthecurrentlocation.
-Ifthesearchingisfailedmorethan3times,thePOWERbotwillstarttocleanfromthebeginning.
Note
fStartthecleaningagainattheareawithin39in(1m)aroundwherethePOWERbotstopped.
–Ifyoustartthecleaningattheareamorethan39in(1m)fromwherethePOWERbotstopped,itisdifficult
tosearchthelocationandthePOWERbotmaycleantheareawhereitalreadycleaned.
Using POWERbot
1_SR9300K_EN_DJ68-00743A-01_AA.indd 16 2016-01-26 오후 2:15:25

ENGLISH-17
Using the remote control
1 Power / Recharging / Start/Stop
Power TurnPOWERbot'spoweron/off
Recharging SelecttorechargePOWERbotatthedockingstation
automatically
Start/Stop Selecttostartorstopcleaningprocess
2 Suction power
Max mode Selecttocleanwiththestrongestsuctionpower
Normal mode Selecttocleanwithmoderatesuctionpower
Quiet mode Selecttocleanwithloweroperationnoise
3 Additional function
Sound Eachtimeyoupressthisbutton,SoundEffectsMuteis
selectedinthissequence.
Smart control
Selecttoturnonoroffthesmartcontrol
 Press[Sound]buttonfor3seconds..
 Wi-Ficonnectionshouldbedonetocontrolthe
POWERbotusingSamsungSmartHomeapp.
 Thepreviouslyselectedsettingwillnotchangeeveniftheemergencyswitchisturnedoffandthenon.
Inserting batteries
Openthebatterycoverbyliftingitup
whilepressingthelockingtaband
insertthebatteriesasshowninthe
illustration.Then,closethecoveruntil
itclicksintoplace.
1_SR9300K_EN_DJ68-00743A-01_AA.indd 17 2016-01-26 오후 2:15:25

ENGLISH-18
You can use the remote control to point and clean
the desired spot while the POWERbot is in cleaning
process.
Point the red light on the floor within 39 in (1 m) around
POWERbot's location.
PressandholdthePointcleaningbuttontomovetheredlightto
thedesiredspot.ThePOWERbotwillfollowthelightwhilecleaning.
39 in
(1 m)
 
Operating distance of the remote control
Heightoftheremote
control
Operatingdistance
Height of the remote
control 39in(1m) 59in(1.5m)
Operating distance About78in(2m) About98in(2.5m)
5 Point cleaning
4 Manual clean mode & Direction
control
Selecttomoveforward
Selecttoturnleft
Selecttoturnright
 Movingbackwardisnotavailable.
1
1
2
4
3
Referto
page20
5
Using the remote control
1_SR9300K_EN_DJ68-00743A-01_AA.indd 18 2016-01-26 오후 2:15:26

ENGLISH-19
Name of each part
1
4
2
35
3
3
6
7
8
Top
1. Displaypanel
2. Dustbinholder
3. Remotecontrolsignalreceiver
4. Obstaclesensor
5. Dustbin
6. Camera
7. Dustbinhandle
8. Bumpersensor
1
4
2
6
5
5
4
7
4
8
9
3
Bottom
1. Chargepins
2. Petbrush
3. Petbrushcover
4. Cliffsensor
5. Roller
6. Batterycover
7. Petbrushcoverbutton
8. Drivingwheel
9. Emergencyswitch
13 149121110
6
16
17
3
4
5
8
1
7
2
15
Display panel
1. Mute
2. InformationIndicator
3. Filterinspection
4. SmartControlOff/Onindicator
5. Wi-Fi
6. Batteryindicator
7. One-time/Dailyschedule
8. Numberdisplay
9. Spotcleanmode
10.Manualcleanmode
11.Quietmode
12.Normalmode
13.Maxmode
14.Dustsensor
15.Spotcleaningbutton
16.Start/Stopbutton
17.Rechargingbutton
1_SR9300K_EN_DJ68-00743A-01_AA.indd 19 2016-01-26 오후 2:15:26

ENGLISH-20
Setting time/schedule
Only Auto clean mode can be scheduled.
Setting the time
YoumustsetthecurrenttimebeforeusingtheOne-time/dailyschedule.
Start setting Select "Hour" Select "Minute"
Select "AM/PM"Setting complete
Skip to previous, next setting
Setting the schedule
Setting/cancellingtheschedulecanonlybedonewhilePOWERbotisdockedonthedockingstation.
Start setting Select "One-time" or
"Daily" schedule
Select "Hour"
Select "Minute"Select "AM/PM"Setting complete
Skip to previous, next setting
Cancelling during setup fSettingwillbecanceledautomaticallywhenthere'snoinput
for7seconds
Cancelling One-time/Daily schedule
When both One-time/
Daily schedule is set or or
Pressfor3sec. Selecttheschedule Cancelcomplete
When either one of
One-time or Daily
schedule is set Pressfor3sec.
1_SR9300K_EN_DJ68-00743A-01_AA.indd 20 2016-01-26 오후 2:15:27
