Samsung SV-7000W User manual

WORLDWIDE VIDEO
CASSETTE RECORDER
SV-7000W
Owner’s Instructions
VCR
POWER EJECT
INDEX REC.SPEED CLK/COUNT PICTURE TIMER
ART INPUT
123
456
789
0CLR/RST
100
CH
R
E
W
P
L
A
Y
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
INPUT
SYSTEM OUTPUT SYSTEM
AUTO MENU
REV
FWD
STOP
STROBE AUDIO
OK
T
R
A
C
K
I
N
G
S
L
O
W

3
GB
2
◆REWINDING AND FAST-FORWARDING
■Rewinding and Fast-forwarding a Cassette................................................... 33
■Playing a Cassette in Slow Motion................................................................ 33
■Playing a Sequence Frame by Frame........................................................... 34
■Playing a Sequence at Variable Speeds....................................................... 34
◆SPECIAL FUNCTION
■STROBE........................................................................................................ 35
■ART ............................................................................................................... 35
■MONITOR...................................................................................................... 35
◆SEARCHING FOR A SEQUENCE
■Searching for a Specific Sequence ............................................................... 36
■Using the Tape Counter ................................................................................ 37
◆ADVANCED RECORDING FEATURES
■Using the Assemble Edit Function................................................................. 38
■Connecting Other Equipment to Your VCR................................................... 39
■Recording from Another VCR or Camcorder................................................. 40
■TV System Conversion.................................................................................. 41
■Playback Conversion..................................................................................... 41
■Conversion Recording................................................................................... 42
■Hi-Fi Audio System........................................................................................ 43
■Audio Dubbing a Pre-recorded Cassette....................................................... 44
■Recording an FM Simulcast Program............................................................ 45
◆OTHER FUNCTIONS AND USEFUL RECOMMENDATIONS
■Locking Your VCR......................................................................................... 46
■Resetting Your VCR...................................................................................... 46
■Technical Specifications................................................................................ 47
◆SOLVING PROBLEMS
■Troubleshooting Guide.................................................................................. 48
◆GLOSSARY
■Glossary of Terms......................................................................................... 49
◆WORLD BROADCAST SYSTEMS ................................................................................. 50
◆INTERNATIONAL SERVICE NETWORK ......................................................................... 51
☛
➢
NoteImportantHold downPress/push
Symbols
Contents (cont.)
11
1
= Step number
Contents
◆FOREWORD
■Safety Instructions......................................................................................... 4
■Getting Started .............................................................................................. 5
◆VCR OVERVIEWS
■Front View of the VCR................................................................................... 6
■Rear View of the VCR ................................................................................... 6
■Display Indicators.......................................................................................... 7
■Infrared Remote Control................................................................................ 7
◆CONNECTING YOUR VIDEO CASSETTE RECORDER
■Worldwide VCR Background ........................................................................ 8
■Worldwide TV Color System.......................................................................... 8
■Multi-System VCR vs Worldwide VCR.......................................................... 9
■System Conversion with the Worldwide VCR................................................ 10
■Tape Conversion with the Worldwide VCR ................................................... 11
■Deciding How to Connect Your VCR............................................................. 13
■Connecting Your VCR to the TV.................................................................... 14
◆SETTING UPYOUR VIDEO CASSETTE RECORDER
■Inserting the Batteries in the Remote Control................................................ 15
■Plug and Initial Setting................................................................................... 15
■User Set1 Setting .......................................................................................... 16
■User Set2 Setting .......................................................................................... 16
■Setting the Date and Time............................................................................. 17
■To turn On-Screen Information on/off............................................................ 17
■Setting the VCR RF out System.................................................................... 18
■Setting the RF OUT CHANNEL..................................................................... 19
■Presetting the Stations Automatically............................................................ 20
■Presetting the Stations Manually................................................................... 21
◆RECORDING TELEVISION BROADCASTS
■Selecting the Cassette Type.......................................................................... 22
■Selecting the Recording Speed..................................................................... 22
■Protecting a Recorded Cassette.................................................................... 22
■Recording a Program .................................................................................... 23
■Stopping a Recording Temporarily................................................................ 23
■Recording a Program with Automatic Stop.................................................... 24
■Using the Timer Programming Feature......................................................... 25
■VCR Plus+ Recording (AMERICA only)........................................................ 26
■VCR Plus+ Set up (AMERICA only).............................................................. 27
■Checking a Preset Recording........................................................................ 28
■Cancelling a Preset Recording...................................................................... 28
◆PLAYING BACK
■Playing a Cassette......................................................................................... 29
■Selecting the PLAY SYSTEM Mode.............................................................. 29
■Receiving Stereo Broadcasts........................................................................ 30
■Receiving SAP Broadcasts............................................................................ 30
■SQPB (Super VHS Quasi PlayBack)............................................................. 31
■Adjusting Picture Alignment Manually........................................................... 31
■Adjusting Picture Sharpness ......................................................................... 32
■Selecting the Audio Output Mode.................................................................. 32

(EUROPE...) (AMERICA...)
5
GB
4
Getting Started
Thank you for purchasing a SAMSUNG Video Cassette Recorder (VCR).
Together with your VCR, you will find the following accessories in the box.
Your Owner’s Instructions contain much valuable information on setting up and using your VCR.
Please take the time to read them as they will help you take full advantage of the VCR’s features.
The manual is organized as follows:
◆A series of step-by-step procedures for each function available forms the main body of the
manual.
◆You can consult the glossary on page 49, to obtain an explanation of the main technical terms
used throughout this manual.
◆On pages 6 and 7, you will find illustrations of the VCR (front and rear), the display and the
remote control unit to help you find the buttons and understand the symbols displayed.
Preparing Your Video Cassette Recorder
Before being able to play and record video cassettes, you must prepare and connect your VCR.
◆Insert batteries in the remote control.
◆Connect your VCR to the television.
◆Set the date and time used to display information on the television screen.
◆Preset the stations.
All these operations are essential, so you must follow the step-by-step instructions carefully.
REMOTE CONTROL
(AC59-00010D)
BATTERIES “AAA”
(AC43-12002H)
OWNER’S
INSTRUCTIONS
(AC68-00407A)
COAXIAL CABLE
(AC39-42001L) COAXIAL CABLE
(AC39-42001J)
RF ADAPTORS
(M:3705-001095
F:3705-001096)
RCA CABLE(AUDIO)
(AC39-42001U)
RCA CABLE (VIDEO)
(AC39-22017Z)
VCR
POWER
EJECT
INDEXREC.SPEEDCLK/COUNT PICTURETIMER
ARTINPUT
123
456
789
0
CLR/RST
100
CH
R
E
W
P
L
A
Y
F
.
F
DISPLAYMONITORA.DUB
RECP/STILL
INPUT
SYSTEMOUTPUT
SYSTEM
AUTOMENU
REV
FWD
STOP
STROBEAUDIO
OK
T
R
A
C
K
I
N
G
S
L
O
W
The following illustrations represent the precautions to be taken when using this video cassette
recorder.
The lightning flash with arrowhead in the triangle is a warning sign alerting you to
dangerous voltage inside the product.
DO NOT OPEN THE VCR.
HH
5°C
40°C
10% 75%
THIS UNIT IS NOT FOR USE IN INDUSTRIAL
ENVIRONMENTS.
Safety Instructions
Do NOT expose the VCR to
extreme temperature conditions
(below 5°C(41°F) and above
40°C(104°F) or to extreme
humidity conditions (less than
10% and more than 75%).
Do NOT expose the VCR to
direct sunlight. Do NOT expose the VCR to any liquids.
Do NOT place any objects on
the VCR or remote control. During a storm and/or lightning, unplug the VCR from the AC
outlet and antenna.
If the remote control is not
used for a long period of time,
remove the batteries and store
it in a cool, dry place.

7
GB
6
VIDEO
OUT 2
R
L
AUDIO
OUT 1
R - AUDIO - L VIDEO
LINE 2 IN
EURO AV
TV
VIDEO
OUTPUT 2
JACK
VIDEO
OUTPUT 1
JACK
RCA VIDEO
INPUT JACK
ANTENNA IN
RF CONNECTOR
Front View of the VCR
Rear View of the VCR
RCA AUDIO L, R
OUTPUT 2 JACKS
RCA AUDIO
L, R OUTPUT 1
JACKS
RCA AUDIO
L, R INPUT
JACKS
OUT TO TV
RF CONNECTOR
AUDIO/VIDEO IN/OUT
SCART (EURO-21) JACK
VCR
POWER EJECT
INDEX REC.SPEED CLK/COUNT PICTURE TIMER
ART INPUT
123
456
789
0CLR/RST
100
CH
R
E
W
P
L
A
Y
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
INPUT
SYSTEM OUTPUT SYSTEM
AUTO MENU
REV
FWD
STOP
STROBE AUDIO
OK
T
R
A
C
K
I
N
G
S
L
O
W
VPS PDC
SLP VCR
L
AUTO
NTSC4.43
PAL-MN
MESECAM
CONVERSION
STROBE
ART
THROUGH
NTSC4.43
PAL-MN
MESECAM
OUTPUT
INPUT SQPB DTR INDEX DUB Hi-Fi
R
+10+10
+5+5
0
-10
-20
-30
-40
VCR POWER BUTTON
REC.SPEED BUTTON
INDEX BUTTON
CLK/COUNT BUTTON
NUMERIC BUTTONS
100 BUTTON
PLAY BUTTON
REWIND/REVERSE PICTURE SEARCH
BUTTON
RECORD BUTTON
DISPLAY BUTTON
MONITOR BUTTON
INPUT SYSTEM BUTTON
OK BUTTON
MENU SELECTION SHIFT BUTTONS
AUTO TRACKING BUTTON
TRACKING BUTTONS
EJECT BUTTON
PICTURE BUTTON
TIMER PROGRAM BUTTON
STROBE BUTTON
AUDIO OUT SELECTION BUTTON
ART BUTTON
TUNER, SC, AV, LINE 1, LINE 2 SELECTION
BUTTON
CH UP/DOWN BUTTONS
STROBE, ART UP(+), DOWN(-) BUTTONS
CLR/RST BUTTON
FAST-FORWARD/FORWARD SEARCH BUTTON
STOP BUTTON
PAUSE/STILL BUTTON
AUDIO DUBBING BUTTON
OUTPUT SYSTEM BUTTON
MENU SELECTION UP/DOWN BUTTONS
MENU BUTTON
SLOW BUTTONS
JOG/SHUTTLE RING
@@@@@@@@e?
@@@@@@@@e?
@@h?
@@h?
@@h?
@@h?
@@h?
@@h?
@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e
@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e
@@@@@@@@
@@@@@@@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
?@@
?@@
?@@
?@@
?@@
?@@
?@@@@@@@@
?@@@@@@@@
?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@
?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@e?@@@@@@@@?e@@@@@@@@
@@g
@@g
@@g
@@g
@@g
@@g
@@@@@@@@
@@@@@@@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
@@
1 2 4 5 6 7 8 10
3 9 11
Display Indicators
Infrared Remote Control
1Timer indicator 5Conversion indicator 9Multi-function display
2Recording speed indicator 6Output select indicator 10 Hi-Fi indicator
3Cassette in/out indicator 7SQPB Indicator 11 Audio Level meter
4Input select indicator 8INDEX Indicator
EJECT
TRACKING SPEED AUDIO OUT
RESET
NORMAL(VHS) SQPB ONLY
VIDEO
LINE 1 IN
AUDIO
LR
PLAY
STOP
F.F REW
REC PAUSE/STILL
THROUGH
NTSC
NTSC4.43
MESECAM
PAL-M
SECAM
PAL-N
AUTO
SECAM
PAL-M
PAL-N
POWER
PAL
NTSC
PAL
CHANNEL
INPUT
OUTPUT
SQPB
SELECTION
SWITCH
RCA VIDEO
INPUT JACK
SYSTEM STANDARD
INPUT SELECTION
BUTTONS
SYSTEM
STANDARD
OUTPUT
SELECTION
BUTTONS
CHANNEL
BUTTONS
RECORD
BUTTON REW BUTTON STOP
BUTTON F.F BUTTON PAUSE/STILL
BUTTON RESET
BUTTON
POWER
BUTTON
TRACKING
BUTTONS
EJECT
BUTTON
RECORDING
SPEED SELECTION
BUTTON
AUDIO OUT
BUTTON
RCA AUDIO
L, R INPUT
JACKS
PLAY
BUTTON VIDEO CASSETTE
COMPARTMENT

9
GB
Multi-System VCR vs Worldwide VCRWorldwide VCR Background
8
Worldwide TV Color System
Many countries have different TV signal formats, with no exchangeability between them. This makes it
impossible to play back or record tapes with different signal formats. This worldwide common VCR
overcomes this problem by converting the signal format of any tape into the format you desire.
Comparison of TV color systems
☛ Classification of TV color systems by country
➢◆ NTSC : Korea, U.S., Canada, Japan, Taiwan, and Philippines
◆ PAL : United Kingdom, Germany, Western Europe, China, and Singapore
◆ SECAM : France, Eastern Europe, and CIS
◆ PAL-M : Brazil
◆ PAL-N : Argentina (The tape is the same as that of PAL)
◆ NTSC4.43 : Pseudo NTSC signal which is made to use NTSC tape in the Middle East
(The tape is the same as that of NTSC3.58)
◆ MESECAM : The name of a tape which uses the SECAM signal recording method.
The output signal during playback is SECAM signal.
➢ Worldwide Broadcasting system is B/G, I, D/K, M, N, L.
Number of
scanning lines
Field
frequency
Line frequency
Color signal
modulation
system
Color signal
frequency
Burst signal
NTSC NTSC4.43 PAL-M PAL PAL-N SECAM MESECAM
525 625
3.579545
MHz
Fixed phase Inverted by 1 H DR.DB alternation
FM modulation
4.433619
MHz 3.575611 MHz 4.433619 MHz 3.582056 MHz DB 4.25MHz
DR 4.40625MHz
60Hz 50Hz
15.734KHz 15.625KHz
Sub carrier suppression quadrature modulation
“Worldwide Communication through VCR”
Today, the Video Recorder is a major media and communication tool, used for both business and home
entertainment. Furthermore, the emergence of the camcorder has extended the versatility of video,
enabling home video making.
Video communication is increasingly becoming a global medium, but different TV broadcasting systems
around the world hinder the worldwide exchange of video tapes.
The Samsung SV-7000W overcomes the incompatibility of different TV broadcasting systems through
sophisticated digital technology, allowing any standard VHS tape to be played on any TV, anywhere in
the world (with free voltage).
The Worldwide VCR is similar to the Multi-System VCR in that it will play back tapes recorded in any
TV Broadcasting System. However, there are a few key differences:
NTSC
PAL
SECAM
NTSC PAL SECAM
Multi-System VCR
With a Multi-System VCR:
The TV must correspond to the system of the tape being
played, otherwise, a Multi-System TV is also required;
Tape duplication with system conversion (eg NTSC to PAL) is
not possible.
NTSC PAL SECAM
SV-7000W Worldwide VCR
ANY TV
With the Worldwide VCR:
Tapes can be played on any TV monitor;
Recordings can be made in any TV Broadcasting System,
even if the tape is of a different system;
Tape duplication with system conversion is possible.

11
GB
Tape Conversion with the Worldwide VCRSystem Conversion with the Worldwide VCR
10
System conversion is the most complex digital process undertaken by the Worldwide VCR, converting
the “input” into a different “output”, eg from NTSC to PAL, or from PAL to SECAM. One of the most useful functions of the Worldwide VCR is the combination of tape duplication and
system conversion, more simply known as “Tape Conversion”. This allows the user to copy, for
example, a SECAM tape and simultaneously convert it to PAL or NTSC. This is particularly useful for
duplicating home video camcorder recordings and sending them to friends or relatives abroad.
INPUT OUTPUT
NTSC (3.58)
NTSC 4.43
PAL
PAL-M
PAL-N
SECAM
NTSC (3.58)
NTSC 4.43
PAL
PAL-M
PAL-N
SECAM
MESECAM (TAPE ONLY)
NTSC PAL PAL-M SECAM MESECAM
NTSC PAL PAL-M SECAM MESECAM
I
INPUT SELECTION
II
OUTPUT SELECTION
III
SYSTEM CONVERSION
VCR automatically selects the
correct TV broadcast system of
the input signal:
VCR digitally converts scanning
lines, frequency fields and color
signal into the desired system as
selected in step ll.
A. When RECORDING
The ‘input’is the external TV
signal or the output from a
second VCR or LDP
B. During PLAYBACK
The ‘input’comes from the
tape loaded for playback
The broadcast system of the
tape - on which the recording is
to be made - is selected on the
VCR ‘output’panel
Recording in the desired
TV system
The broadcast system of the
TV - on which playback is to
be viewed - is selected on the
VCR ‘output’panel
Playback can be viewed
on any monitor
A. TV RECORDING
B. PLAYBACK
ANY
TAPE ANY TV
ANY
TAPE
Output:
Input signal converted to the
system of the tape loaded
Input Output
LINE IN
Input signal to be
recorded
EJECT
TRACKING SPEED AUDIO OUT
RESET
NORMAL(VHS) SQPB ONLY
VIDEO
LINE1 IN
AUDIO
LR
PLAY
STOP
F.F REW
REC PAUSE/STILL
THROUGH
NTSC
NTSC4.43
MESECAM
PAL-M
SECAM
PAL-N
AUTO
SECAM
PAL-M
PAL-N
POWER
PAL
NTSC
PAL
CHANNEL
INPUT
OUTPUT
PLAY
STOP
F.F REW
“input”
select panel “output”
select panel
NTSC
PAL
PAL-M
SECAM
MESECAM
NTSC
PAL
PAL-M
SECAM
MESECAM
NTSC
PAL
PAL-M
SECAM
MESECAM
NTSC
PAL
PAL-M
SECAM
MESECAM
NTSC
PAL
PAL-M
PAL-N
SECAM
MESECAM
NTSC
NT4.43
PAL
PAL-N
PAL-M
SECAM
Any VHS Tape Any VHS Tape
SV-7000W
AS A PLAYBACK VCR
SAMSUNG
Worldwide VCR
2nd VCR
AS A RECORDING VCR
Any VCR
SV-7000W
AS A RECORDING VCR
SAMSUNG
Worldwide VCR
2nd VCR
AS A PLAYBACK VCR
Corresponding VCR
VHS Tape
Corresponding
Any VHS Tape

13
GB
Deciding How to Connect Your VCR
You must take into account various factors when deciding how to connect up your various audio
and/or video systems.
◆Types of connectors available on your systems.
◆Systems connected permanently to the VCR (satellite receiver for example) or from time to
time (camcorder for example).
Your VCR is equipped with the following connectors.
Connector Location Type Direction Recommended Use
AV Rear SCART In/Out ◆Television
LINE Rear Audio/Video RCA Out ◆Television
◆Other VCR
LINE 1 Front Audio/Video RCA In ◆Audio system
◆Camcorder
◆Other VCR
LINE 2 Rear Audio/Video RCA In ◆Audio system
◆Camcorder
◆Satellite receiver
◆Other VCR
OUT TO TV Rear 75 ΩOut ◆Television
coaxial
IN FROM ANT. Rear 75 ΩIn ◆Antenna
coaxial ◆Cable television network
☛Whenever you connect an audio or video system to your VCR, ensure that all units are
switched off.
Refer to the documentation supplied with your equipment for detailed connection instructions
and associated safety precautions.
TV
EURO AV
VIDEO
OUT 2
R
L
AUDIO
OUT 1
R- AU
VIDEO
LINE1 IN
AUDIO
LR
R - AUDIO - L VIDEO
LINE 2 IN
12
NTSC
PAL
PAL-M
SECAM
MESECAM
NTSC
PAL
PAL-M
SECAM
MESECAM
PUSH
S-VIDEO
MIC
LOCK
STANDBY
PUSH
S-VIDEO
MIC
LOCK
STANDBY
V HS-C
Any 8mm Tape
8mm CAMCORDER
AS A PLAYBACK VCR
Corresponding
Camcorder
Any VHS Tape
SV-7000W
AS A RECORDING VCR
SAMSUNG Worldwide VCR
SV-7000W
AS A RECORDING VCR
SAMSUNG
Worldwide VCR
Any VHS-C
Tape
VHS-C Tape
Adapter
2nd VCR
AS A PLAYBACK VCR
Corresponding VCR
Any VHS Tape

15
GB
14
You must insert or replace the batteries in the remote control when
you:
◆purchase the video cassette recorder ; or
◆find that the remote control is no longer working
correctly.
1Push the tab in the direction of the arrow to release the battery
compartment cover on the rear of the remote control.
2Insert two AAA or equivalent batteries (supplied), taking care to
respect the polarities.
◆+ on the battery with + on the remote control.
◆–on the battery with –on the remote control.
3Replace the cover by aligning it with the base of the remote
control and pushing it back into place.
The VCR automatically displays the initial setting MENU when the
VCR is plugged into the AC outlet for first time.
1Plug the VCR into the AC outlet.
Result: The LANGUAGE SET is displayed.
2Press the , and OK button to select your favorite language.
Result: The COUNTRY SET is displayed.
3Press the , , button to select your country region.
Result: The country list is displayed.
4Press the , , and OK button to select your country.
➢If your country does not appear in the country list, then
select OTHERS.
Inserting the Batteries in the Remote Control
Plug and Initial Setting
1
Connecting Your VCR to the TV
To receive television programs from an over-the-air or cable
television network, a signal must be received from one of the
following sources.
◆An outdoor antenna.
◆An indoor antenna.
◆A cable television system.
☛Make sure that both the television and the VCR are
switched off before connecting the cables.
1Remove the 75Ωcoaxial cable from the television.
2Connect this cable to the 75Ωcoaxial socket marked on the
rear of your VCR.
3Plug the coaxial cable supplied into the socket on your VCR.
4Plug the other end of the coaxial cable into the connector
previously used for the antenna on the television.
5Connect one end of the RCA cable supplied to the output jacks
(OUT1 or OUT2) on the rear of the VCR.
➢Respect the color coding of the Audio and Video In/Out
cable.
6Connect one end of the SCART cable to the EURO AV socket on
the rear of the VCR.
7Plug the other end (of the RCA cable or SCART cable) into the
appropriate connector on the television.
◆Regardless of the type of connection chosen, you must
always connect the coaxial cable supplied. Otherwise, no
picture will be visible on the screen when the VCR is
switched off.
* NOTICE:
Use the supplied RF adaptors as needed when making RF
connections.
[NTSC/PAL-M Region]
TV
VIDEO
TV
VIDEO
TV
VIDEO
OUT 2
R
L
AUDIO
OUT 1
R - AUDIO - L VIDEO
LINE 2 IN
EURO AV
TV
TV
2
3
6
VIDEO
OUT 2
R
L
AUDIO
OUT 1
R - AUDIO - L VIDEO
LINE 2 IN
EURO AV
TV
5
** LANGUAGE SET **
❿ ENGLISH
DEUTSCH
FRANÇAIS
ITALIANO
ESPANOL
JAPANESE
#❷ MEMORY:(OK)
** COUNTRY SET **
EUROPE
❿ AMERICA
ASIA/OCEANIA
MIDDLE EAST/AFRICA
#❷ ❿
** AMERICA **
❿ U.S.A. CANADA
MEXICO BRAZIL
ARGENTINA CHILE
COLOMBIA VENEZUELA
PERU PANAMA
OTHERS:M
#❷ ❿ MEMORY:(OK)

17
GB
Your VCR contains a 12H/24H clock and calendar used to:
◆preset your VCR to record a program automatically.
You must set the date and time when:
◆you purchase the video cassette recorder.
◆the power supply remains off for more than 6 hours.
☛◆Do not forget to reset the time when you change
clocks from standard to daylight savings time and vice
versa.
1Press MENU on the remote control.
Result: The programming menu is displayed.
2Press the or buttons, until the cursor is placed in front of the
CLOCK SET option.
3Press the button to select this option.
Result: The CLOCK SET menu is displayed.
4Press or to select the hour, minutes, day, month and year.
Result: The option selected flashes.
5Press the or buttons to increase or decrease the value.
Result: The day of the week is displayed automatically.
➢You can hold the or buttons down to scroll more
quickly through the values.
6On completion, press MENU twice to exit the menu.
Setting the Date and Time
To turn On-Screen Information on/off
Your VCR displays most information both on the VCR and television.
You can choose to turn this information on/off the television screen
(except for the Index, Timer Programming function, Picture, which
cannot be turned off).
1Press MENU on the remote control.
Result: The programming menu is displayed.
2Press the corresponding or button, until the cursor is placed
in front of the USER SET option.
3Press the button to select this option.
Result: The USER SET1 menu is displayed.
4Press the corresponding or button, until the cursor is placed
in front of the OSD option.
5To: Press or , until:
display on-screen information ON is displayed.
turn on-screen information off OFF is displayed.
6After completion, press MENU twice to exit the menu.
USER SET1 Setting
16
The user set is initially set at the factory. If you want to make any
changes to the USER SET, please follow the instructions below.
1Press MENU on the remote control.
Result: The programming menu is displayed.
2Press the , , button to select user set.
Result: The USER SET1 is displayed.
3Press , , to select the USER SET1 item.
4Check below to change the item.
* USER SET1
ITEM USAGE COMMENT
TAPE tape length select Select the recording tape type for
SELECT remain time.
CLOCK 12H/24H mode Select your favorite clock type.
TYPE
PLAY play tape system The VCR automatically selects the
SYSTEM selection play system. If an auto detection
error occurs, then select the play
system manually.
OSD OSD display on/off Initial setting is on.
USER SET2 USER SET2 select Select to go to USER SET2 page.
** M E N U **
TIMER PROGRAMMING
❿ USER SET
INSTALLATION
LANGUAGE SET
CLOCK SET
#❷ ❿ END:(MENU)
** USER SET1 **
❿ TAPE SELECT :E180/
T120
CLOCK TYPE :12H
PLAY SYSTEM :AUTO
OSD :ON
USER SET2
#❷ ❿ END:(MENU)
1Press MENU on the remote control.
Result: The programming menu is displayed.
2Press the , , button to select user set.
Result: The USER SET1 is displayed.
3Press , , to select the USER SET2.
4Press , , to select the USER SET2 menu item.
5Check below to change the item.
* USER SET2
USER SET2 Setting
ITEM USAGE COMMENT
SAP SAP on/off Initial mode is SAP OFF.
COLOR COLOR or B/W Initial mode is on. Color off mode is
select B/W. If color distortion occurs in
the play or conversion mode, then
select color off mode.
BLUE BLUE SCREEN Initial is blue screen on. If any
SCREEN on/off problem occurs with the blue
screen, then select blue screen off.
USER SET1 USER SET1 select Select to go to USER SET1 page.
** M E N U **
TIMER PROGRAMMING
❿ USER SET
INSTALLATION
LANGUAGE SET
CLOCK SET
#❷ ❿ END:(MENU)
** USER SET1 **
TAPE SELECT :E180/
T120
CLOCK TYPE :12H
PLAY SYSTEM :AUTO
OSD :ON
❿ USER SET2
#❷ ❿ END:(MENU)
** USER SET2 **
❿ SAP :OFF
COLOR :ON
BLUE SCREEN :ON
USER SET1
#❷ ❿ END:(MENU)
INPUT
SYSTEM OUTPUT SYSTEM
AUTO MENU
OK
G
** M E N U **
TIMER PROGRAMMING
USER SET
INSTALLATION
LANGUAGE SET
❿ CLOCK SET
#❷
❿
END:(MENU)
AUTO MENU
T
R
A
C
K
I
N
G
S
L
O
W
1
** CLOCK SET **
12:00PM 1/JAN/1999
FRI
➛❿ #❷ END:(MENU)
3
2
2
** M E N U **
TIMER PROGRAMMING
❿ USER SET
INSTALLATION
LANGUAGE SET
CLOCK SET
#❷ ❿ END:(MENU)
** USER SET1 **
TAPE SELECT :E180/
T120
CLOCK TYPE :12H
PLAY SYSTEM :AUTO
❿ OSD :ON
USER SET2
#❷ ❿ END:(MENU)

The VCR RF out system and channel is used to connect the
SV-7000W to a TV with RF coaxial jacks.
The RF out system is automatically set by country selection (See
page 15).
➢If your selection of the country set is U.S.A., the RF out
system is automatically set to U.S.A-M system.
If after making your country selection, you have picture distortion
or no sound, you must set the RF out system and channel manually.
Change the RF out system according to the table below.
TV RF out
Broadcast system NATION
system
MM U.S.A, CANADA, KOREA,
JAPAN, BRAZIL,--
N M URUGUAY, ARGENTINA,--
L L FRANCE,--
B/G G GERMAN, ITALY, SPAIN,--
I I U.K, HONGKONG,--
D/K K CHINA, CIS, --
➢If you want to know the broadcast system of your
specific country, see the World Broadcast Systems
(page 50).
1Press the MENU button on the remote control.
Result: The programming menu is displayed.
2Press the or buttons to select installation.
Result: The INSTALLATION menu is displayed.
3Press the or buttons to select MANUAL SET UP.
Result: The MANUAL SET UP menu is displayed.
4Press the button until the cursor is placed in front of RF OUT
system.
5Press the or buttons to change the RF OUT system.
Result: The RF OUT system is changed.
19
GB
Setting the RF OUT CHANNELSetting the VCR RF out System
18
The initial setting of the RF OUT channel is off.
In order to view signals from the RF out connector on your TV, you
must set the RF OUT channel on the VCR to match the TV channel.
1Press MENU on the remote control.
Result: The programming menu is displayed.
2Press the or buttons to select installation.
Result: The installation MENU is displayed.
3Press the or buttons to select MANUAL SET UP.
Result: The MANUAL SET UP menu is displayed.
4Press the button until the cursor is placed in front of
RF OUT CHANNEL.
5Press the or buttons to change the RF OUT CHANNEL.
Result: The RF OUT CH is changed.
➢Your VCR RF out channel may need to be changed if
there is no picture or the picture suffers from interference.
For better picture and sound quality, connect your VCR to
the TV using the RCA cable (if the appropriate RCA input
is available on your TV).
** INSTALLATION **
COUNTRY
ANT./CATV:ANTENNA
AUTO SET UP
❿ MANUAL SET UP
#❷ ❿ END:(MENU)
** MANUAL SET UP **
GUIDE CH SET UP
CH ADD/DELETE
❿ RF OUT M/G/I/K :M
RF OUT CH 14-69:OFF
116-125
#❷ ❿ (END:MENU)
** INSTALLATION **
COUNTRY
ANT./CATV:ANTENNA
AUTO SET UP
❿ MANUAL SET UP
#❷
❿
END:(MENU)
** MANUAL SET UP **
GUIDE CH SET UP
CH ADD/DELETE
RF OUT M/G/I/K :M
❿ RF OUT CH 14-69:OFF
116-125
#❷ ❿ END:(MENU)

20
Presetting the Stations Automatically
Your VCR contains a built-in tuner used to receive television
broadcasts. It can also receive cable television broadcasts.
You must preset the stations received through the tuner. This can
be done:
◆automatically ; or
◆manually (see page 21).
1Press the MENU button on the remote control.
Result: The programming menu is displayed and the cursor is
automatically placed in front of the AUTO SET UP option.
2Press the button to select AUTO SET UP.
3Press OK to start the Auto scanning.
Result: The AUTO indication flashes on the VCR display.
➢The number of channels automatically stored by the
VCR depends on the number of channels that have
been found (reception conditions, etc).
4To exit AUTO TUNING, press the MENU button.
➢Once the Auto scanning procedure has finished, some channels
may have been stored more than once. Select the channels with
the best reception and delete the ones no longer required.
(see page 21.)
AMERICA
U.S.A.
PRESS (OK) TO CONTINUE
(MENU) TO EXIT
AUTO SET UP
PLEASE WAIT
CH 2
END:(MENU)
AUTO MENU
V
F
OK
T
R
A
C
K
I
N
G
S
L
O
W
** INSTALLATION **
COUNTRY
ANT./CATV:ANTENNA
❿ AUTO SET UP
MANUAL SET UP
#❷ ❿ END:(MENU)
1
21
GB
Presetting the Stations Manually
Your VCR contains a built-in tuner used to receive television
broadcasts. It can also receive cable television broadcasts.
You must preset the stations received through the tuner. This can
be done:
◆automatically (see page 20) ; or
◆manually.
1Press the MENU button on the remote control.
Result: The programming menu is displayed.
2Press the corresponding or buttons, until the cursor is placed
in front of the INSTALLATION option.
3Press the button to select this option.
Result: The INSTALLATION menu is displayed.
4Press the corresponding or buttons, until the cursor is placed
in front of the MANUAL SET UP option.
5Press the corresponding or buttons, until the cursor is placed
in front of the CH ADD/DELETE option.
6Press the or button to select channel that you want to
memorize or delete.
If you:
wish to store the ◆press OK buttons to memorize current
displayed channel channel.
wish to delete the ◆press CLR/RST button to delete current
channel displayed channel.
7Press OK button to memorize.
Result: The selected channel is memorized.
8Press CLR/RST button to delete.
Result: The selected channel is deleted.
** M E N U **
TIMER PROGRAMMING
USER SET
❿ INSTALLATION
LANGUAGE SET
CLOCK SET
#❷ ❿ END:(MENU)
** INSTALLATION **
COUNTRY
ANT./CATV:ANTENNA
AUTO SET UP
❿ MANUAL SET UP
#❷ ❿ END:(MENU)
** MANUAL SET UP **
GUIDE CH SET UP
❿ CH ADD/DELETE
RF OUT M/G/I/K :M
RF OUT CH 14-69:60
116-125
#❷ ❿ END:(MENU)
** CH ADD/DELETE **
AMERICA
U.S.A.
❿ CH : 3(ADDED)
MFT : -
#❷ ➛❿!!!!!!!!! DELETE:CLR/RST
END:(MENU)

23
GB
Recording a Program
Before recording a program, you must have preset the corres-
ponding channel (unless you are recording via an external video
source). If you have not done so, refer to pages 20 and 21.
1Switch on the television.
2To monitor the program being recorded, select the television AV
input.
3Insert the cassette on which the program is to be recorded.
Result: The VCR is switched on automatically.
4Select:
◆ the selected channel to be recorded using the CH ( or )
buttons ;
or
◆the AV source using the INPUT button for a satellite tuner or
external video source.
Result: The channel number is displayed and the program can
be seen on the television.
5Select the recording speed by pressing the REC.SPEED button as
many times as required (see page 22).
6Press the REC button for at least one second to start recording.
Result:
The record indicator appears on the television and VCR
display. An index is recorded on the tape (see page 36).
7To stop recording, press STOP ( ) once.
➢◆If the cassette is ejected when you start recording,
check that the safety tab is intact or the opening is
covered with adhesive tape.
◆If you reach the end of the tape while recording, the
cassette rewinds automatically.
You can stop recording temporarily (pause mode), to avoid
recording commercials or to change channels for example.
To: press:
stop recording temporarily P/STILL ( ).
start recording again P/STILL ( ) or REC.
☛If the VCR is left in pause mode for more than ten
minutes, recording will be stopped automatically to
protect the heads and the cassette.
Stopping a Recording Temporarily
D
EX REC.SPEED CLK/COUNT PICTURE TIMER
ART INPUT
1
23STROBE AUDIO
R
E
W
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
STOP
R
E
W
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
STOP
5
7
6
ART INPUT
23
56
89
0CLR/RST
CH
4
4
22
You can record a cassette at two different speeds:
PAL/SECAM/MESECAM NTSC/PAL-M
◆SP (Standard Play) ◆SP (Standard Play)
◆LP (Long Play) ◆SLP (Super Long Play)
In Long Play or Super Long Play modes:
◆the recording is of a slightly lower quality.
To record a cassette: Press the REC.SPEED button on the
remote control, until:
in standard play mode SP is displayed.
in long play mode LP is displayed (PAL/SECAM/MESECAM).
in super long play mode SLP is displayed (NTSC/PAL-M).
Selecting the Cassette Type
If you wish to use the tape counter to display the time remaining on
a cassette, you must indicate the type of cassette inserted.
1Press MENU on the remote control.
Result: The programming menu is displayed.
2Press the or button, until the cursor is placed in front of the
USER SET option.
3Press the button to select this option.
Result: The cursor is set to the TAPE SELECT option.
4Press the or button as many times as required, until the
correct cassette length is displayed.
E180/T120 E240/T160
E 300 E260/T180
5Press MENU twice to exit the menu.
Selecting the Recording Speed
Type Recording Time
PAL/ SECAM NTSC
E-180/T120 180 mins 120 mins
E-240/T160 240 mins 160 mins
E-260/T180 260 mins 180 mins
E-300 300 mins
N
DEX REC.SPEED CLK/COUNT PICTURE TIMER
ART INPUT
123
456
STROBE AUDIO
Protecting a Recorded Cassette
Video cassettes have a safety tab to prevent accidental erasure.
When this tab has been removed, you cannot record on the tape.
1If you wish to protect a cassette, break off the tab using a small
screwdriver.
2To re-record over a protected cassette (safety tab broken), cover
the hole with adhesive tape.
1
** USER SET1 **
❿ TAPE SELECT :E180/
T120
CLOCK TYPE :12H
PLAY SYSTEM :AUTO
OSD :ON
USER SET2
#❷ ❿ END:(MENU)

25
GB
Using the Timer Programming Feature
24
This function enables you to record up to nine hours of programs.
Your VCR stops automatically after the preset length of time.
1Switch on the television.
2Select the AV input on the television for use with your VCR.
3Insert the cassette on which the program is to be recorded.
Result: The VCR is switched on automatically.
4Select:
◆ the station to be recorded using the CH ( or ) buttons ;
or
◆the AV source using the INPUT button for a satellite tuner or
external video source
Result: The channel number is displayed and the program can
be seen on the television.
5Select the recording speed by pressing the REC.SPEED button as
many times as required (see page 22).
6Press the REC button for at least one second to start recording.
Result: The record indicator appears on the television screen
and VCR display. An index is recorded on the tape
(see page 36).
7Press the REC button several times to increase the recording time
in:
◆30-minute intervals up to four hours ; or
◆1-hour intervals up to nine hours.
Result: The length is displayed on the VCR and television
displays. The selected program is recorded for the
length of time requested. At the end of that time, the
VCR stops recording automatically.
8If you wish to cancel the recording before the end, press POWER.
☛If the end of the tape is reached while recording:
◆the recording stops ; and
◆the VCR automatically turns off.
Recording a Program with Automatic Stop
INDEX REC.SPEED CLK/COUNT PICTURE TIMER
ART INPUT
123
456
789
0CLR/RST
100
CH
R
E
W
P
L
A
Y
F
.
F
STROBE AUDIO
4
DISPLAY MONITOR A.DUB
REC P/ST
INPUT OUTPU
STOP
VPS PDC
SLP VCR
L
AUTO
NTSC4.43
PAL-MN
MESECAM
CONVERSION
STROBE
ART
THROUGH
NTSC4.43
PAL-MN
MESECAM
OUTPUT
INPUT INDEX DUBSQPB DTR INDEX DUB Hi-FHi-Fi
R
+10
+5
0
-10
-20
-30
-40
6
4
5
EJECT
TRACKING SPEED AUDIO OUT
RESET
NORMAL(VHS) SQPB ON LY
VIDEO
LINE1 IN
AUDIO
LR
PLAY
STOP
F.F REW
REC PAUSE/STILL
THROUGH
NTSC
NTSC4.43
MESECAM
PAL-M
SECAM
PAL-N
AUTO
SECAM
PAL-M
PAL-N
POWER
PAL
NTSC
PAL
CHANNEL
INPUT
OUTPUT
The Timer Programming feature enables you to preset the VCR to
record a program up to one month before it is to be broadcast. Up
to six programs can be preset.
☛Before presetting a recording, check that the date and
time are correct. If not, refer to page 17. If the clock has
not been set, the Date/Time Setting function is activated
automatically.
1Insert the cassette and press the TIMER button.
Result: The Timer selection is displayed.
2Press to select the standard timer.
3Select the required channel by pressing the or buttons or
INPUT to select the SC, AV, L l or L2 input sources.
4Press to select the recording day.
5Select the required day by pressing the or buttons.
➢DLY (daily program).
W-SU, W-MO, ...., W-SA(weekly program).
6Press to select the recording start time.
7Select the required hour value by pressing the or buttons.
8Press to select the minutes.
9Select the required minute value by pressing the or buttons.
10 Press to select the recording stop time.
11 Select the required recording stop time by pressing the or
buttons, following the same procedure as when selecting the
recording start time.
12 Press to select the REC SYSTEM.
13 Select the required recording system value by pressing the
or buttons. Offset value is THROUGH.
14 Press to select the recording speed.
15 Select the required recording speed value by pressing the
or buttons. Offset value is SP.
Result: If you select AUTO mode, the VCR compares the
timer duration with the remaining time on the cassette.
If the tape is not long enough, the speed automatically
changes from SP to LP/SLP.
16 When you have finished, press the MENU button.
Result:SET is displayed, indicating that the VCR has been
programmed.
17 Press the VCR POWER button to activate the timer.
X REC.SPEED CLK/COUNT PICTURE TIMER
ART INPUT
23
56
STROBE AUDIO
1
VCR
POWER
INDEX REC.SPEED CLK/COUNT PICTURE
123STROBE
17
INPUT
SYSTEM OUTPUT SYSTEM
AUTO MENU
OK
T
R
A
C
K
I
N
G
S
L
O
W
4
CLOCK: 1/JAN FRI 12:32
CH DAY START
→ STOP
❿ --- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
#❷ SET: ❿
DELETE:(CLR/RST) (MENU)
❿ STANDARD TIMER
VCR PLUS
#❷ ❿ EXIT:(TIMER)

27
GB
26
With VCR Plus+, each channel is assigned a VCR Plus+ guide
number, which can be found in most TV program guides. If your
VCR comes with VCR Plus+, you can use this system when
recording. Before using VCR Plus+, set the channel and VCR Plus+
numbers to match.
* VCR Plus+ is trademark of Gemstar Development Corporation.
Be sure to select the correct signal source (Antenna/Cable TV
depending on your hook-up) before performing Guide Channel
Setup.
1Press MENU for the Main Menu. Press and to select
“INSTALLATION”. Press and to select “MANUAL SET UP”.
2Press to select “GUIDE CH SET UP”.
3VCR Plus+ Guide channel numbers appear on the top row.
Receiving channels are on the bottom.
Press or to select a VCR Plus+ Guide channel number.
4Press or for the correct receiving channel number.
For example : If receiving channel 23 corresponds to the
VCR Plus+ Guide channel 45, press and until 45 appears in
the top row of numbers with the downward pointing arrow directly
below.
Press the and until 23 appears on the bottom row.
The channel number that changes is always the receiving channel
rather than the VCR Plus+ Guide channel.
5Press or to select the next VCR Plus+ Guide channel
number. Enter all the receiving channel numbers and press MENU
to finish.
VCR Plus+ Set up (AMERICA Only)
VCR Plus+ Recording (AMERICA Only)
VCR Plus+ selects programs to be recorded with a Plus Code
number, usually found in most of the program listings. Before using
VCR Plus+, you must set up your Guide Channel.
Set clock first (page 17).
1To enter a Plus Code, press the TIMER button.
Press the and buttons to select “VCR Plus”.
2Locate the program’s Plus Code in a local TV program guide.
Press up to eight number buttons to set the Plus Code. Use to
correct any mistakes.
3Press OK to save the code. The channel number appears on the
left side. The start and end recording times, recording date and
speed also appear.
4Press MENU to finish. Check whether there is enough time left on
the video tape to record the program.
5To stop a Timer Recording, press the VCR POWER button. When
using a cable decoder box, make sure the decoder box is on.
STANDARD TIMER
❿ VCR PLUS
#❷ ❿ EXIT:(TIMER)
VCR PLUS
CODE --------
CODE:0-9 CORRECT:
➛
END:(MENU)
VCR PLUS
CODE 12345---
CODE:0-9 CORRECT:
➛
COMPLETE:OK END:(MENU)
CLOCK: 10/JUL SAT 4:21P
CH DAY START
→ STOP
❿ 16 FR16 7:30P → 8:00P ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
#❷ SET: ❿
DELETE:(CLR/RST) (MENU)
** INSTALLATION **
COUNTRY
ANT./CATV:ANTENNA
AUTO SET UP
❿ MANUAL SET UP
#❷ ❿ END:(MENU)
** MANUAL SET UP **
❿ GUIDE CH SET UP
CH ADD/DELETE
RF OUT M/G/I/K :M
RF OUT CH 116-125:60
#❷
❿
END:(MENU)
** GUIDE CH SET UP **
40 41 42 43 44 45
❷
40 41 42 43 44 45
ENTER ACTUAL
RECEIVING CHANNEL
#❷ ❿ END:(MENU)
** GUIDE CH SET UP **
40 41 42 43 44 45
❷
40 41 42 43 44 23
ENTER ACTUAL
RECEIVING CHANNEL
#❷ ❿ END:(MENU)

29
GB
This function enables you to play back any pre-recorded cassette.
1Switch on both the television and your VCR.
2Select the television AV or AUX input.
3Insert the video cassette to be played. If the safety tab on the
cassette is intact, press PLAY ( ).
Otherwise, the cassette is played automatically.
➢When a cassette is loaded, the tape position is optimized
automatically to reduce disturbance (Digital Auto Tracking).
When playing a cassette, if the end of the tape is reached,
the cassette is rewound automatically.
4To: press:
stop the playback STOP ( ).
eject the cassette EJECT ( ).
0
R
E
W
P
L
A
Y
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
STOP
EJECT
RACKING SPEED AUDIO OUT
T
E
R
CHANNEL
Playing a Cassette
3
4
4
Selecting the PLAY SYSTEM Mode
You can choose the PLAY SYSTEM if your system does not match
the SV-7000W VCR.
This function only needs to be used when there is no color or
picture during playback.
1Press MENU on the remote control.
Result: The programming menu is displayed.
2Press the corresponding or buttons, until the cursor is placed
in front of the USER SET option.
3Press the button to select this option.
Result: The USER SET1 menu is displayed.
4Press the corresponding or buttons, until the cursor is placed
in front of the PLAY SYSTEM option.
5Press or buttons until you select the appropriate system is
selected.
Case1 : NTSC or PAL-M Tape Playback
AUTO
➝ NTSC ➝ PAL-M
Case2 : PAL, SECAM, MESECAM Tape Playback
AUTO
➝ PAL ➝ SECAM ➝ MESECAM
6On completion, press MENU twice to exit the menu.
☛If you encounter a system error or the picture has no color
when in AUTO mode, select the play system manually.
28
You can cancel any programs that are:
◆incorrect.
◆no longer required.
1Press the TIMER button and select STANDARD TIMER.
Result: The preset programs are displayed.
2Select the program to be cancelled by pressing the or
button.
3Press the CLR/RST button to cancel the selected program.
Result: All the recording information is deleted and the broad-
cast will not be recorded.
4On completion, press MENU twice.
You can check your preset recordings:
◆when you have finished presetting the VCR ; or
◆if you have forgotten which programs will be recorded.
1Press the TIMER button and select STANDARD TIMER.
Result: The preset programs are displayed.
2Press the or button to select the required program.
3Press the button to select the CH.
4Press the or button to select and change any values as
required.
5On completion, press MENU twice.
Checking a Preset Recording
Cancelling a Preset Recording
REC.SPEED CLK/COUNT PICTURE TIMER
ART INPUT
23
56
STROBE AUDIO
1
789
0CLR/RST
100
R
E
W
P
L
A
Y
F
.
F
REC P/S
STOP
3
CLOCK: 1/JAN WED 12:32P
CH DAY START
→ STOP
❿ 1 SU19 7:05P → 7:25P ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
#❷ SET: ❿
DELETE:(CLR/RST) (MENU)
CLOCK: 1/JAN WED 12:32P
CH DAY START
→ STOP
❿ 1 SU19 7:05P → 7:25P ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
--- ---- --:-- → --:-- ❿❿
#❷ SET: ❿
DELETE:(CLR/RST) (MENU)
** USER SET1 **
TAPE SELECT :E180/
T120
CLOCK TYPE :12H
❿ PLAY SYSTEM :AUTO
OSD :ON
USER SET2
#❷ ❿ END:(MENU)
** M E N U **
TIMER PROGRAMMING
❿ USER SET
INSTALLATION
LANGUAGE SET
CLOCK SET
#❷ ❿ END:(MENU)

31
GB
30
STEREO 13
SAP 6
1:23:28
L, R (stereo) ➝L ➝R ➝MONO
MAIN ➝SAP ➝MONO
Receiving Stereo Broadcasts
Receiving SAP Broadcasts
The VCR can receive and record stereo broadcasts.
It can also be set to record the secondary audio program (SAP) of
any broadcast with second language audio.
The VCR records the same audio on both the Hi-Fi linear tracks on
the tape.
1Press AUDIO button on the remote control to select stereo.
You can also select left, right or mono.
2When the stereo sound is poor, press the AUDIO button to select
mono for sound without noise.
1Press MENU on the remote control and select user set.
2Press the and buttons to select USER SET2.
3Press the and buttons to set SAP to ON.
4Press menu key twice to exit MENU.
5To select SAP, press the AUDIO button on the remote control until
“SAP” is displayed on the screen.
“SAP” will be displayed on the TV screen when a SAP broadcast
is received.
6Press the REC button at least one second for SAP recording.
❊ When main is displayed, stereo is selected.
SQPB (Super VHS Quasi PlayBack)
This function is for playback of Super VHS format tapes only, not
for recording.
1Insert the Super-VHS format cassette.
2Set the SQPB selection switch to SQPB.
3Press the PLAY ( ) to play.
Result: SQPB indicator illuminates.
☛ If the SQPB selection switch is set to the normal playback
position, the video output will be distorted.
The Fine Adjustment feature enables you to adjust the alignment
manually to obtain the best possible picture.
When noise bars or streaks appear during playback, adjust alignment
manually by pressing the TRACKING
( or ) buttons until the picture
is clear and stable.
Result:◆The tracking bar appears.
◆The image is adjusted.
◆The tracking bar disappears when you release the button.
Adjusting Picture Alignment Manually
AUTO MENU
REV
FWD
T
R
A
C
K
I
N
G
S
L
O
W
** USER SET2 **
❿ SAP :OFF
COLOR :ON
BLUE SCREEN :ON
USER SET1
#❷ ❿ END:(MENU)
NORMAL(VHS) SQPB ONLY

33
GB
32
Rewinding and Fast-forwarding a Cassette
You can:
◆rewind or fast-forward a cassette without seeing the
picture on the television.
◆search for a given sequence forwards or backwards on
the tape.
To: press:
rewind the tape without
REW ( ) when the cassette is stopped.
viewing the picture
rewind the tape while REW ( ) when the cassette is playing
viewing the picture (Reverse Search function).
switch from reverse search REW ( ) while rewinding the tape with
to playback again the picture displayed.
fast-forward the tape without F.F ( ) when the cassette is stopped.
viewing the picture
fast-forward the tape while F.F ( ) when the cassette is playing
viewing the picture (Forward Search function).
switch from forward search F.F ( ) while fast-forwarding the tape
to playback again with the picture displayed.
➢The cassette is rewound automatically when the end of
the tape is reached.
If you press POWER while a cassette is being rewound,
the VCR switches off automatically when the beginning of
the cassette is reached.
You can play a cassette in slow motion.
➢No sound is heard when playing back a cassette in slow
motion.
1Press:
◆PLAY ( ) to start playing the cassette ;
◆SLOW ( or ) to start slow mode play ;
◆SLOW ( or ) as many times as required to decrease or
increase the speed respectively ; and
◆PLAY ( ) to return to normal speed.
2When playing back in slow motion, picture interference may occur.
Press the TRACKING
( or ) buttons to minimize this effect.
☛If the slow motion function is used for more than five
minutes, the VCR will automatically play to protect the:
◆cassette ; and
◆video heads.
Playing a Cassette in Slow Motion
R
E
W
P
L
A
Y
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
STOP
R
E
W
P
L
A
Y
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
STOP
The Picture Sharpness feature enables you to adjust the sharpness
of the image according to your own preferences.
1During playback, press the PICTURE button.
Result: The picture bar appears.
2Press the and buttons until the picture is adjusted to your
liking.
➢If you do not press a button within six seconds, the picture
bar automatically disappears.
3On completion, press the PICTURE button again.
Adjusting Picture Sharpness
REC.SPEED CLK/COUNT PICTURE TIMER
ART INPUT
23
56
STROBE AUDIO
1
SYSTEM SYSTEM
AUTO MENU
OK
T
R
A
C
K
I
N
G
S
L
O
W
2
2
Selecting the Audio Output Mode
You can select the mode in which the sound is reproduced on the
LINE and AV outputs. The following options are available.
Option Description
L Used to listen to the sound on the left Hi-Fi channel.
R Used to listen to the sound on the right Hi-Fi channel.
MIX Used to listen to the mixed sound of the Hi-Fi and linear
audio. (For example, you can play back Hi-Fi audio sound
while at the same time listening to narration dubbed onto
the normal audio track. See pages 43 and 44 for further
details of the Audio Dubbing feature.)
MONO Used to listen to the sound on the linear mono channel.
L R Used to listen to Hi-Fi stereo sound on the left and right
channels.
➢When playing back tapes recorded in Hi-Fi, the
sound switches to Hi-Fi after five seconds of Mono.
To select the sound mode, simply press the AUDIO button on the remote
control until the required option is displayed.
ART INPUT
23
56
89CH
STROBE AUDIO
L R MIX
L R MONO
MENU
REV
FWD
C
K
I
N
G
S
L
O
W
1
1
AUTO MENU
REV
FWD
T
R
A
C
K
I
N
G
S
L
O
W
2
2

35
GB
34
STROBE
You can see still images in succession.
1Press the STROBE button during playback.
Result:
“STROBE”is displayed on the screen.
A Discrete image is displayed on screen similar to
SLOW mode.
2Press the +/- to vary the speed of STROBE mode.
3To exit the STROBE mode, press the STROBE button.
When in the ART mode, the picture contrast is changed to
resemble artwork.
1Press the ART button during PLAY or STROBE mode.
Result:
The contrast of the image is changed.
2Press the +/- buttons to vary the contrast of ART mode.
3To exit the ART mode, press the ART button.
ART
ART INPUT
23
56
89
CLR/RST
CH
STROBE AUDIO
ART
INPUT
56
89
0CLR/RST
CH
R
E
W
P
L
A
Y
F
.
F
1
2
ART INPUT
23
56
89
CLR/RST
CH
STROBE AUDIO
ART
INPUT
56
89
0CLR/RST
CH
R
E
W
P
L
A
Y
F
.
F
1
2
DISPLAY MONITOR A.DUB
REC P/STILL
INPUT
SYSTEM OUTPUT SYSTEM
STOP
1
MONITOR
You can see the original input signal during a conversion recording.
1Press the MONITOR button during conversion.
Result:◆
Original input signal is displayed on screen.
2Press the MONITOR button again.
Result:◆
The converted output signal is displayed on screen.
You can:
◆stop the cassette at a given frame (image) ; and
◆advance one frame at a time.
➢No sound is heard when playing back frame by frame.
1Press the PLAY ( ) button to start playing the cassette.
2Press the P/Still button ( ) to stop the tape at a given frame.
3 Press the P/Still button ( ) again to advance forward frame by frame.
4Instead of Step 3 you can also turn the JOG to the left or right to
advance frame by frame backward or forward.
5To return to normal playback, press the PLAY ( ) button.
☛If the Frame-by-Frame function is used for more than five
minutes (except for JOG function), the VCR will auto-
matically play to protect the cassette and video heads.
You can vary the playback speed using the Shuttle function (up to
nine times the normal speed).
Example: You wish to analyze an athlete’s technique, movement
by movement.
The Shuttle function is available on the remote control.
➢No sound is heard when playing a sequence at variable
speeds.
1Press the PLAY ( ) button to start playing the cassette.
2Turn the SHUTTLE RING to the left or right to vary the playback
speed.
3Each time you turn the shuttle ring, the speed will change as
shown in the following illustration.
☛When you activate Variable Speed play, there will be no
color in some modes. This is normal operation. Modes
with no color are shown below.
◆No color modes : • Variable Speed play of LP recordings
on any system.
• X2 and Still/Slow play of SLP
recordings in PAL-M mode.
☛ If the picture is noisy or distorted during X2 play or other
variable speed play, adjust the tracking manually for a
cleaner picture.
Playing a Sequence at Variable Speeds
Playing a Sequence Frame by Frame
AUTO MENU
REV
FWD
T
R
A
C
K
I
N
G
S
L
O
W
0
R
E
W
P
L
A
Y
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
STOP
1
2, 3
AUTO MENU
REV
FWD
T
R
A
C
K
I
N
G
S
L
O
W
4
2
(LP on PAL/SECAM/MESECAM/PAL-N)
REVERSE
X9 REVERSE X 7
(SP on All Systems)
(SLP on NTSC/PAL-M)
REVERSE
X3 REVERSE PLAY
REVERSE
SLOW
(1/5)
SLOW
(1/5) SLOW (1/10)
PLAY PLAY
X2 PLAY X7 PLAY X9
REVERSE
X15 REVERSE X9 REVERSE X5 REVERSE PLAY
REVERSE
SLOW
(1/5)
SLOW
(1/5) SLOW (1/10)
PLAY PLAY
X2 PLAY X9 PLAY X15
REVERSE
X15 REVERSE X9 REVERSE X7 REVERSE PLAY
REVERSE
SLOW
(1/5)
SLOW
(1/5) SLOW (1/10)
PLAY PLAY
X2 PLAY X9 PLAY X15
REVERSE
SLOW
(1/10)
STILL
STILL
STILL
REVERSE
SLOW
(1/10)
REVERSE
SLOW
(1/10)

37
GB
The tape counter:
◆indicates the elapsed time in the play and record modes
(hours, minutes and seconds) ;
◆is reset when a cassette is inserted in the VCR ; and
◆enables you to find the beginning of a sequence easily.
☛To enable the remaining time to be calculated correctly,
you must indicate the type of cassette being used. See
page 22.
1Insert a cassette in your VCR.
2Press CLK/COUNT twice.
Result: The tape counter is displayed:
0:00:00.
➢The tape counter does not necessarily start from zero at the
beginning of the tape.
3Select the required operation (play, record, fast-forward, rewind).
Result: The tape counter indicates how long the cassette has
been running.
4To set the tape counter to zero at the beginning of a sequence:
◆press DISPLAY twice to display the counter ; and
◆press CLR/RST when you want to set the tape counter to
zero.
5To fast-forward or rewind to the sequence at which the counter
was set to zero, simply press
REW ( ) or F.F ( ).
Result: The VCR stops automatically when the counter
reaches zero.
➢Some VCR information, such as the counter, can be
displayed on the television screen (unless you have
deactivated the OSD mode; refer to page 17).
Press DISPLAY:
◆once to display the current function, program
number, recording speed, date, time and counter ;
◆twice to display the counter only ;
◆three times to display the time remaining on the
cassette ; and
◆four times to clear the display.
VPS PDC
SLP VCR
L
AUTO
NTSC4.43
PAL-MN
MESECAM
CONVERSION
STROBE
ART
THROUGH
NTSC4.43
PAL-MN
MESECAM
OUTPUT
INPUT PB DTR INDEX DUBSQPB DTR INDEX DUB Hi-FHi-Fi
R
+10
+5
0
-10
-20
-30
-40
EX REC.SPEED CLK/COUNT PICTURE TIMER
ART INPUT
23STROBE AUDIO
Using the Tape Counter
0:00:00
0CLR/RST
100
R
E
W
P
L
A
Y
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
STOP
2
4
4
36
Searching for a Specific Sequence
Each time you record a cassette on this VCR, an “index” is
automatically marked on the tape when recording starts.
The Search function enables you to fast-forward or rewind to a
specific index and start playback from that point. Depending on the
direction selected, the indexes are numbered as follows.
etc. Prev
Seq. Seq. being
played Next Seq. etc.
21 12
➞
➢This VCR uses a standard indexing system (VISS). As a
result, it will recognize any indexes marked by other
VCRs using the same system and vice versa.
1To search for a specific index, press INDEX.
2Enter the number of the index to be found using the numeric
buttons.
➢When entering a single-digit number, do not forget to
precede it with a zero.
Example:02.
Result: The index number is displayed.
3Select the direction in which the VCR is to search:
◆ REW ( ) to search backwards ; or
◆F.F ( ) to search forwards.
Result: When the index is found, cassette playback starts.
INDEX: --
VCR
POWER EJ
INDEX REC.SPEED CLK/COUNT PICTURE T
123STROBE A
1
0
R
E
W
P
L
A
Y
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
STOP
33

39
GB
Connecting Other Equipment to Your VCR
➢The RCA output connectors (OUT1 or OUT2) on the rear of the VCR
are used to output signals to equipment such as a stereo sound
system.
REAR OF THE VCR
Stereo sound system
➢The LINE 1 input connectors on the front of the VCR are used to input
signals from equipment such as camcorders, VCRs or stereo sound
systems.
VIDEO
OUT 2
R
L
AUDIO
OUT 1
R - AUDIO - L VIDEO
LINE 2 IN
EURO AV
VIDEO
OUT 2
R
L
AUDIO
OUT 1
R - AUDIO - L VIDEO
LINE 2 IN
EURO AV
FRONT OF THE VCR
You can connect other audio and/or video equipment to your VCR in different ways. The following
illustrations give a few examples of the connection possibilities.
Camcorder
Stereo sound system
VCR
➢The EURO AV connector on the rear of the VCR is used for equipment
with a SCART input/output such as a satellite tuner or VCR.
REAR OF THE VCR
Satellite tuner
VCR
or
38
Using the Assemble Edit Function
This function enables you to start a new recording at a specific
position on the cassette while maintaining a very smooth scene
change.
1Insert the cassette to be edited in your VCR.
2Press the PLAY button ( ) to start playback.
3When you reach the position from which you wish to start the new
recording, press the P/STILL button ( ).
4Press the P/STILL button ( ) again as often as necessary to
advance frame by frame, until the exact recording position is
located.
5While the VCR is in still mode, press the REC button at least one
second to activate the Assemble Edit function.
Result: The Record symbol ( ) flashes on the display.
6Select the source from which you wish to record by pressing:
◆the CH ( or ) buttons for television channels ; or
◆the INPUT button for the SC, AV, LI or L2 input sources.
◆Perform necessary hookups and activate source. Refer to
page 39.
7Press the P/STILL button ( ) to start recording.
8When you have finished recording, press STOP ( ).
R
E
W
P
L
A
Y
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
STOP
3
R
E
W
P
L
A
Y
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
STOP
5
ART INPUT
56
89
0CLR/RST
CH
P
L
A
Y
R
E
W
P
L
A
Y
F
.
F
DISPLAY MONITOR A.DUB
REC P/STILL
STOP
2
4
6
6
DISPLAY MONITOR A.DUB
REC P/STILL
INPUT
SYSTEM OUTPUT SYSTEM
STOP
7
8
VIDEO
LINE 1 IN
AUDIO
LR
