Samsung SWV-1200F User manual

WASHING MACHINE
SWV-1200F/1100F/1000F/800F
P1291/P1091/P8091/P6091
SERVICE
Manual
WASHING MACHINE CONTENTS
1. SPECIFICATIONS
2. OVERVIEW OF THE WASHING MACHINE
3. OVERVIEW OF THE CONTROL PANEL
4. PROCESS TABLE
5. GENERAL REEOR FUNCTION
6. TROUBLE DIAGNOSIS
7. TEST MODE
8. DESIGNATION OF MAIN COMPONENTS
9. PCB SHEMATIC DIAGRAM
PCB CIRCUIT DIAGRAM
PCB PATTERN DIAGRAM
WIRING DIAGRAM
10.ASSEMBLE AND DISASSEMBLE
11.TOOLS FOR DISASSEMBLY AND ASSEMLY
12.EXPOLDED VIEW AND PARTS LIST

2 SAMSUNG ELECTRONICS CO., LTD
Caution for the safety during servicing
1. Do not allow the customer to repair the product.
☞ The person may be injured or the product life may be shortened.
2. Execute A/S after unplugging the power supply unit.
☞ Be care of the electric shock.
3. Do not plug several plugs in the same outlet.
☞ It may cause the fire due to overheat.
4. Check the damage, pressing or burning of the power plug or outlet.
☞ Replace it promptly if it has problem.(It may cause the electric shock or fire)
5. Do not clean the main body with the water.
☞ It may cause the electric shock and fire and shorten the product life)
6. The wiring of the harness shall be free from the moisture and tightened during serving.
☞ It shall not be deviated by certain impact.
7. Remove any dust or filth on the housing section,wiring section,connection section during servicing.
☞ Protect the cause of the fire such as the tracking,shortage and etc.
8. Check any mark of the moisture on the electrical parts, harness section and etc.
☞ Replace the parts or remove the moisture.
9. Check the assembly status of the parts after servicing.
☞ Maintain the status before servicing.
10. Pull out the power cord with holding the plug.
☞ Be care of the electric shock and fire when the cord is damaged.
11. Unplug the power plug from the outlet when the wash machine is not used.
☞ Be care of the electric shock and fire due to the strike of the lightening.
12. Do not use or store the spray or flammable materials(including gasoline,alcohol and etc.)
around the wash machine.
☞ Be care of the explosion or fire due to the electric spark.
13. Do not put the bowl of water or wet laundry on the wash machine.
☞ If the water is penetrated to the wash machine, this may cause the electric shock or fire.
14. Do not install the wash machine in the place where the snow or rain falls.
☞ It may cause the electric shock and fire and shorten the product life.
15. Do not push the control buttons with the awl,pin, or sharp materials.
☞ It may the electric shock and trouble.
16. Check the wash machine is leveled horizontally and installed properly on the floor.
☞ The vibration may shorten the product life.
17. Joint the wire by the connector correctly.
☞ When the wire is jointed by the tape, this may cause the fire due to the tracking.
18. When the wash machine is to be laid for the service, put the pad on the floor and lay the
product at side slowly.
☞ If the wash machine is laid front, the relay may be damaged by the tub.
19. When the wash-heater is replaced, check it is inserted in the bracket-heater and screw the nut.
☞ If the wash-heater is not inserted in the bracket-heater properly, this may cause the noise and
leakage since it is contacted to the drum.
!

1. Specifications
SAMSUNG ELECTRONICS CO., LTD 3
WASH TYPE FRONT LOADING TYPE
DIMENSION GROSS W 669mm X D 656mm X H 910mm
NET W 598mm X D 550mm X H 844mm
WATER PRESSURE 50 kPa ~ 800 kPa
WEIGHT GROSS 80 kg
NET 75 kg
WASHand SPIN CAPACITY 5.0 kg (DRY LAUNDRY)
POWER CONSUMPTION WASHING 220 V 180 W
240 V 180 W
WASHING and 220 V 2000 W
HEATING 240 V 2400 W
MODEL P6091 SWV-800F/P8091 SWV-1000F/P1091 SWV-1100F SWV-1200F/P1291
SPIN 220 V 380 W 430 W 500 W 550 W 550 W
240 V 380 W 430 W 500 W 550 W 550 W
PUMPING 34 W
WATER CONSUMPTION 54l(STANDARD COURSE)
MODEL P6091 SWV-800F/P8091 SWV-1000F/P1091 SWV-1100F SWV-1200F/P1291
rpm 600 800 1000 1100 1200
SPIN REVOLUTION

2. Overview of the Washing Machine
4 SAMSUNG ELECTRONICS CO., LTD
ASSY PUMP
TUB
WATER SUPPLY VALVE
SENSOR
PRESSURE
ASSY DOOR
HOSE DRAIN(OPTION)
CAP DRAIN(OPTION)
ADJUSTABLE LEG
CONTROL-PANEL
DRAWER
DRAIN
HOSE
POWER CORD
BUFFER
SPRING
WEIGHT-BALANCE
SHOCK
ABSORBER
PULLEY
BELT
ASSY MOTOR

3. Overview of the control panel
SAMSUNG ELECTRONICS CO., LTD 5
1. Detergent dispenser
2. Display panel
Displays the remaining wash cycle time, error messages and cancel —.
3. Temperature selection button
Press the button repeatedly to cycle through the available water temperature options
(cold water, 30°C, 40°C, 60°C and 95°C).
4. Spin selection button
Press the button repeatedly to cycle through the available spin speed options
SWV-1200F/P1291 : (No spin, Rinse hold, 400, 600, 800, 1000and 1200rpms),
SWV-1100F : (No spin, Rinse hold, 400, 600, 800, 1000and 1100rpms),
SWV-1000F/P1091 : (No spin, Rinse hold, 400, 600, 800, and 1000rpms),
5. Delay Start button(OPTION)
Press the button repeatedly to cycle through the available delayed start options
(from 1 hour to 24 hours in one hour increments).
21 11 12 3 7 6 8 10
21 9 3 4 7 6 8 10
21 5 3 4 7 6 8 109
SWV-1200F/1100F/1000F, P1291/1091
SWV-800F/P8091
P6091

6 SAMSUNG ELECTRONICS CO., LTD
6. Course button
Press the button repeatedly to select available wash programs
7. Manual button
Press the button repeatedly to cycle through the available partial wash options
[Wash+Rinse+Spin➔Prewash+Wash+Spin➔Spin➔Rinse(1 time)+Spin➔
Rinse(2 times)+Spin➔Rinse(3 times)+Spin]
in case P6091
[Wash+Rinse+Spin➔Prewash+Wash+Spin➔Spin➔Rinse(3 times)+Spin]
Note : Prewash is only available when washing cotton, synthetic or delicate.
8. Start/Pause button
Press to pause and restart programs.
9. Door Open button(OPTION)
Press to open the washing machine door.
10. (On/Off) button
Press once to turn the washing machine on, press again to turn the washing machine off. If the
washing machine power is left on for longer than 10minutes without any buttons being touched,
the power automatically turns off.
11. No Spin button(OPTION)
Press to no spin program.
12. Rinse Hold button(OPTION)
Press to rinse hold program.
O

5. General Error Function
SAMSUNG ELECTRONICS CO., LTD 7
•· When an error occurs, this function starts to keep generating error melody sounds and displays error
indicators as shown in the followings per corresponding error by blinking in 0.5sec interval until the error status
is completely cleared out. In this case, all the driving devices are turned off until the error is cleared out.
1. WATER SUPPLY ERROR
- Water Supply Error occurs when water level frequency does not show changes more than 50Hz or water
is not supplied up to the water level presetting for 20 min or more at the time of initial water supply, the
error status can be cleared by turning POWER S/W OFF and resuming the POWER ON initial status.
- Display shows ‘E1’.
2. WATER DRAIN ERROR
- In case the water level frequency is 25.3KHz or less in the initial phase of UNB-detecting cycle.
- Water Drain error can be cleared by turning POWER S/W OFF and resuming the POWER ON initial status.
- Display shows ‘E2’.
3. OVER-FLOW ERROR
- Over-Flow error occurs when the water level is in abnormal operation (OVER-FLOW: 22.40KHz/50ߧ or
more). It can be cleared by turning POWER S/W OFF. Water is drained prior to POWER S/W OFF and it
is forced to be drained for 2 min if a frequency of more than 25.24 KHz is detected.
- Display shows ‘E3’.
4. DOOR OPEN ERROR
- Door Open error can be cleared by closing the door.
- Display shows ‘dE’.
5. UNBALANCE ERROR
- Unbalance error is cleared by POWER S/W OFF and by resuming the POWER ON initial status.
- Display shows ‘E4’.
6. WATER HEATER ERROR
-In case the water temperature varies by 40°C or more in 5 min, or by 2°C or less in 10 min after heating is started.
- It can be cleared by turning POWER S/W OFF.
- Display shows ‘E5,E6’.
7. ASS’Y PRESSURE S/W ERROR
* Generated Frequency Signal of WATER LEVEL(W/L) S/W (KHz)
- If the same signal as the above table is detected for more than 5 seconds, it is a PRESSURE S/W Error.
- When the error occurs, perform the time-drain for 3 min and then turn off the water drain pump. Then the
display shows ‘E7’ as a pressure s/w error indicator.
8. ABNORMAL WATER TEMPERATURE ERROR
- In case the water temperature is 60°C or more in the synthetic course, 50°C or more in the delicate
course, and 40°C or more in the wool course.
- At the time of initial water supply, if the water temperature is not appropriate, water starts to be drained
and it is forced to be drained for 2 min when the abnormal frequency of 25.24KHz is detected.
- Display shows ‘E8’.
- This error can be cleared by POWER S/W OFF.
Lvevl Low Level High Level
Abnormal W/L Frequency 30.00 KHz 15.00 KHz
Course Water Temp
Synthetic 60˚C or more
Delicate 45˚C or more
Wool 45˚C or more

10. Assemble and Disassemble
SAMSUNG ELECTRONICS CO., LTD16
1. ASS’Y-COVER TOP
1) Remove two screws fixing the top-cover on back side.
2) Push the top-cover back about 15mm and pull it up.
3) It’s possible to exchange and service the trans
former, the pressure-senser, the noise-filter and
the water valve.
2. FRAME FRONT
1) Remove the top-cover and the ass’y drawer.
2) Remove two screws fixing the control-panel on
front side and the screw on right side.
3) Remove the cover-front(L) by using the (-)driver.
4) Pull the lever and open the ass’y-door.
5) Part the diaphragm and the wire diaphragm
away from the frame-front.
6) Remove the eight screws fixing the frame-front.
7) It’s possible to exchange and service the heater,
the pump, the shock-absorber and the door lock
s/w.
15mm
SCREW
LEVER

10. Assemble and Disassemble
17SAMSUNG ELECTRONICS CO., LTD
3. BELT
1) Remove the top-cover.
2) Disassemble and assemble the belt.
3) Check the belt is located at center of the motor-pulley.
<When assemble the belt>
Hook the belt on the motor pulley 1) and place it
around the pulley 2).
4. MOTOR
1) Lay down the washer on left side.
2) Remove the wire housing from the motor.
3) Remove the bolt fixing the motor with the box
drive on back side.
4) Remove the motor.
5. How to Assemble the RELAY Housing.
<CAUTION>
Insert the Relay Housing to the Relays on the
opposite direation each other.
1
2
BELT
MOTOR
PULLEY
Relay
Heat Sink
RELAY Housing
Motor Assemble Hole

11. Tools for Disassembly and Assembly
SAMSUNG ELECTRONICS CO., LTD18
NO TOOL
1 Box driver 10mm Heater (1)
13mm Motor (1), Balance (5)
17mm 2 holes of each left and right of the shock absorber
19mm 1 Pulley hole
2 Double-ended 10, 13 Replaceable for the box driver.
spanner 17, 19mm Since the bolt runs idle when the box driver is used, use the box
driver 17mm.
3 Vice pliers Tool to protect the idle and abrasion of the bolt for the box driver.
4 Other(Driver, Nipper, Long nose) General tools for the after service.
5 JIG for the Tub 1 (Disassemble and Assemble)
19 mm 17 mm 13 mm 10 mm
17
19
12
13
8
10

8 SAMSUNG ELECTRONICS CO., LTD
6. Trouble Diagnosis
°· As the micom wash machine is configured of the complicate structure, there might be the service call.
Below information is prepared for exact trouble diagnosis and suitable repair guide.
1) As some electronic components are damaged by the charged static electricity from the resin part of wash
machine or the human body, prepare the human body earth or remove the potential difference of the
human body and wash machine by contacting the power supply plug when the work contacting to PCB is
executed.
2) Since AC220~240V is applied to the triac T1 and T2 on P.C.B, the electric shock may occur by touching
and be careful that the strong and weak electricity are mixed.
3) If the P.C.B assembly is out of order, do not replace the component on P.C.B except TACT switch since
the component is coated by the urethane.
4) As the P.C.B assembly is designed for no trouble, do not replace the P.C.B assembly by the wrong
diagnosis and follow the procedure of the trouble diagnosis when the micom is not operated normally.
5) As the parts on P.C.B are coated by the urethane, they can not be tested by the test bar of the meter.
Check the trouble by the test mode method according to the procedure.
Caution for the Repair and Replacement
Please follow below instruction for the trouble diagnosis and parts replacement.
POWER SUPPLY PLUG

6. Trouble Diagnosis
SAMSUNG ELECTRONICS CO., LTD 9
No Item Cause and treatment
1 The power is not supplied - Is the PCB connector connected well?
- Is the voltage normal?
- Is the power supply plug connected well?
- Is the noise filter connected well?
- Is the secondary output of the power supply transformation normal?
- Is the fuse disconnected?
• If above points are not found, the PCB assembly is out of order.
Replace it.
2 The water is not supplied. - Is the knob open?
- Did you push START/PAUSE button after selecting the course?
- Is the water supply valve connected well?
- Is the winding of the water supply valve continuous?
- Is the connection and operation of the pressure switch normal?
• If above points are not found, the PCB assembly is out of order.
Replace it.
3 The wash does not start though - Is the connection and operation of the pressure switch normal?
the water supply is stopped. - Is the pressure switch hose damaged so that the air is leaked?
- Is the pressure switch hose bent?
- Check the operation of the water level switch.
• If above points are not found, the PCB assembly is out of order.
Replace it.
4 The wash is executed while - The PCB assembly is out of order. Replace it.
the water is supplied.
5 The drum does not rotate - Is the belt connected well?
during washing. - Is the winding of the motor continuous?
(Rotor winding, stator winding, generator)
- Is the motor fuse normal?
• If above points are not found, the PCB assembly is out of order.
Replace it.
6 The drum rotates by one direction - The PCB assembly is out of order. Replace it.
during washing. (The drum rotates (Inversion relay open trouble)
to one direction for SPIN.)
7 Drainage problem. - Is the drainage hose bent?
- Is the winding of the drainage pump continuous?
- Is the drain filter clogged by the waste?
• If above points are not found, the PCB assembly is out of order.
Replace it.
8 Dehydration problem. - The unbalance is detected.
- Put in the laundry uniformly and start again.
9 Abnormal noise during SPIN. - Is the pulley nut loosen?
- Is the transport safety device removed?
- Is the product installed on the level and stable place?
(Little noise may be generated during the high-speed SPIN.)
10 Leak breaker or current/leak <When the leak breaker and current breaker is installed separately>
breaker is down during washing. - When the leak breaker is down, check and make the earth of the outlet.
- When the current is down, the current is leaked.
<Is the breaker down when the leak/current breaker is combined?>
- Check the rated capacity of the current and leak breaker.
The current breaker may be down due to the lack of the current when the
wash machine and other apparatus are used.
In this case, execute the cold water wash to check whether the current
capacity is lack.
11 The heating is not executed. - Is the wash heater terminal unplugged?
- Is the wash heater normal?(Resistance value : 20.5~21.5Ω)
- If above points are not found, the PCB assembly is out of order.
Replace it.

7. Test Mode
1010 SAMSUNG ELECTRONICS CO., LTD
1. Driving Compartment Test Mode
A. Hold down “2” and ”1” keys simultaneously and then press (POWER S/W) on.
(Display shows “tE”)
Hold down “1” and “2” keys simultanesously (each processing for 0.3sec) and then
press (POWER S/W) on.
B. The driving compartment can be tested when you press “3” key right after entering
into the intial stage of the TEST MODE.
■ Driving Compartment Test
Pre-wash VALVE ON(0.3sec) ➔OFF(0.3sec) ➔Main wash(0.3sec) ➔OFF(0.3sec) ➔
Rinse VALVE ON(0.3sec) ➔OFF(0.3sec) ➔Pump MOTOR ON(0.3sec) ➔OFF(0.3sec) ➔
MOTOR RELAY1 ON(0.3sec) ➔OFF(0.3sec) ➔MOTOR RELAY2(0.3sec) ➔OFF(0.3sec) ➔
MOTOR RELAY2 ON(0.3sec) ➔OFF(0.3sec) ➔HEATER RELAY ON(0.3sec) ➔OFF(0.3sec) ➔
DOOR OPEN (Function continues when door is closed)
31 2
O
O

8. Designation of Main Components
8-1 Normal / Reverse Revolution of Motor and R. P. M. Control
8-2 Door safety Device
8-3 Heater
SAMSUNG ELECTRONICS CO., LTD 11
+
-
8 9
5 10
Rotor
Stator coil
CW
+
-
8 9
5
5
10
Rotor
Stator coil
CCW
<Figure1> <Figure2>
1 2 3 4 5 6 7 8 9 10
STATOR
WASHING MOTOR
TACHO
HIGH-SPEED
STATOR
PROTECTOR
MIDDLE-SPEED
ROTOR (150 C)
220/240V
ED 1.0%
KB 1s
SD 100s
220/240V
ED 1.0%
KB 1s
SD 100s
12A 125~250V AC
STATOR(5.10) STATOR(5.1) ROTOR(8.9) TACHO(3.4) PROTECTOR(6.7) “H”(mm) Code-No Remark
Resistance value 1.64 Ω0.91 Ω1.9 Ω42.7 Ω052 DC31-10181A A
2.07 Ω0.90 Ω2.35 Ω42.7 Ω045 DC31-00002C B
Rated value 220~240V / 50Hz
1) Capacity : AC 230V/2000W
2) Location : Bottom of TUB
3) Function : Raise the water temperature
supplied at the wash process.
4) Resistance value : 23Ω~ 29Ω
5) Thermo Fuse : 128°C
Thermistor
Solenoid
SOLENOID
Coil Resistance
210 Ω±10%
DC61-00115A DC61-00122A
HH
<Figure3>

8-5 ASSY- FLANGE SHAFT
SAMSUNG ELECTRONICS CO., LTD12
8-4 ASSY-TUB
AC
OIL-SEAL
INNER-BEARING
OUT-BEARING
B
C
AB
TYPE INNER-BEARING(A) OUT-BEARING(B) OIL-SEAL(C) CODE-NO REMARK
I ø 30 ø 25 ø 43.9 DC97-00214A SPIN SPEED OVER 1000rpm
II ø 20 ø 17 ø 24.3 DC97-00214B SPIN SPEED BELOW 800rpm
(unit : mm)
(unit : mm)
TYPE (A) (B) (C) CODE-NO REMARK
I ø 25 ø 30 ø 44.7 DC97-00216A SPIN SPEED OVER 1000rpm
II ø 17 ø 20 ø 25 DC97-00214A SPIN SPEED BELOW 800rpm

12. Expolded View and Parts List
19SAMSUNG ELECTRONICS CO., LTD
1
2
3
15
4
5
6
7
8
9
14
10
11
13
12
NO Code No Q'ty Description Specification NSA Remark
1 DC47-00001A 1 HEATER 230V,2000W,230V,2000W,P6091
2 DC61-30346A 1 TUB-FRONT FRPP(GR30%),IVORY,SWF-P12
3 DC61-40348B 5 BRACKET-NUT SBHG-R,T3,P1291,NO-PAINT
4 DC61-40344A 1 BRACKET-HEATER STS430,T1,SWF-P12,-
5 DC61-60496A 2 SPACER-HEATER PBT,SWF-P12,-
6 DC60-20061C 3 SCREW TAPPING TH,+,2,D4,L12,STS304,-
7 DC62-20311A 1 VANE-CHECK EPDM,BLK,SWF-P12,-
8 DC60-60188A 1 WASHER-PLAIN -,ID4.5,OD15.5,T1,SWF-P12,STS3
9 DC60-20061C 1 SCREW TAPPING TH,+,2,D4,L12,STS304,-
10 DC91-12281A 1 ASSY-DRUM P1091
DC97-00785A 1 ASSY-DRUM SWF-P8/P6091
DC97-00785B 1 ASSY-DRUM P1291
11 DC62-40183A 1 PACKING-TUB EPDM,BLK,SWF-P12
12 DC61-30347A 1 TUB-BACK SWF-P12
DC61-30347B 1 TUB-BACK SWF-P12V
DC61-30347C 1 TUB-BACK SWF-P6V
13 DC61-60499B 8 CLIP-TUB HSWR,P1291,NO/PAINT
14 DC61-60520A 1 CLIP-TUB SK5,SWF-P12,PLATE-TYPE
15 DC97-00214A 1 ASSY-FLANGE SHAFT P1291/P1091, ALDC+SM45C Seeonpage12
15-1 DC97-00214A 1 ASSY-FLANGE SHAFT P8091/P6091, ALDC+SM45C Seeonpage12

12. Expolded View and Parts List
1
23
4
10
56718
21
8
9
10
11
12 13
20
19
17
16
22
26
27
29
28
24
25
SAMSUNG ELECTRONICS CO., LTD20

NO Code No Q'ty Description Specification NSA Remark
1DC91-12078A 1 ASSY-WIRE DIAPHRAGM SWF-P12,-
2 DC61-20219A 1 DOOR-DIAPHRAGM EPDM,GRY,SWF-P12
3 DC91-12077A 1 ASSY-CLAMP DIAPHGRAM SWF-P12,-
4 DC60-40138A 2 BOLT-W.MOTOR SM10C,HEX,M8,L62,-,ZPC2(YEL),-,-
5 DC60-60044B 5 WASHER-PLAIN SBC,ID8.4,OD30,T3,-,-,-
6 DC60-60040A 3 WASHER-NYLON -,ID10.5,OD32,T2,-,PBSP-1/2H
7 DC66-60154A 1 WEIGHT-BALANCER CONCRETE,SWF-P12,LOWER
8 DC61-60497A 1 CLAMP-HOSE HSWR,SWF-P12,ID70/OD75.8(TUB)
9 DC62-10305A 1 HOSE-DRAWER TUB EPDM,ID35,BLK,L158,SWF-P12/OD4
10 DC60-40140A 2 BOLT-HEX WEIGHT-UL/SM10C,HEX,M8,L147,-,ZPC2(YEL)
11 DC60-40132B 1 BOLT-FLANGE M8,L210,ZPC2(YEL),SS41C
12 DC62-10303A 1 HOSE-AIR EPDM,ID24,BLK,L130,SWF-P12/OD4
13 DC66-60153A 1 WEIGHT-BALANCER CONCRETE,SWF-P12,UPPER
16 DC62-40184A 1 PACKING-TRAP EPDM,BLK,SWF-P12(T3)
17 DC61-10676A 1 CAP-TRAP PP(TB53),-,SWF-P12
18 DC60-20014A 2 SCREW TAPPING TH,-,2,D4,L12,ZPC2,-
19 DC61-60497A 1 CLAMP-HOSE HSWR,SWF-P12,ID70/OD75.8(TUB)
20 DC62-10304A 1 HOSE-FILTER TUB EPDM,ID65,BLK,L151,SWF-P12/OD7
21 DC65-60118F 1 BAND RING PW1,YEL,-,PI/33
22 DC66-10176B 1 PULLEY ALDC,-,D297,P1291,ID12.5
24 DC60-60049A 1 WASHER-SPRING -,ID10.5,OD18,T2.5,-,SIR
25 DC60-50014A 1 NUT-HEX HEXAGON,M(12),ZPC2(YEL),SM10C,
26 DC66-10139B 1 BELT-TRANSMISSION -,-,-,-,-
27 DC31-10181A 1 MOTOR-DRUM MCC 52/64 148/SEC1,220~240V,50HZ,52MM Seeon page11
27-1 DC31-00002C 1 MOTOR-DRUM MCC 45/64 148/SEC1,220~240V,50HZ,45MM Seeon page11
28 DC61-00041A 2 CUSHION-MOTOR BUTYL,SWF-6V,ID16/OD20
29 DC60-40138A 1 BOLT-W.MOTOR SM10C,HEX,M8,L62,-,ZPC2(YEL),-,-
12. Expolded View and Parts List
21SAMSUNG ELECTRONICS CO., LTD

12. Expolded View and Parts List
1
2
3
9
10
6
4
5
28
26
11
12
13
14
15
16
17
18
19
20
25 27
24
21
22
23
30
32
33
34
35
36
37
38
39
40
41
7
22 SAMSUNG ELECTRONICS CO., LTD

12. Expolded View and Parts List
NO Code No Q'ty Description Specification NSA Remark
1 DC96-00070A 1 ASSY-M.WIRE HARNESS P1291/1191/1091/8091,COLD+HOT
1-1 DC96-00070B 1 ASSY-M.WIRE HARNESS P1291/1191/1091/8091,COLD-ONLY
1-2 DC96-00052B 1 ASSY-M.WIRE HARNESS P6091,COLD-ONLY
2 DC96-00053A 1 ASSY-WIRE HARNESS P1291/1191/1091(SUB),HIGH-RPM
2-1 DC96-00053B 1 ASSY-WIRE HARNESS P8091/P6091,(SUB),LOW-RPM
3 DC60-20136A 2 SCREW TAPPING TH,+,2,D5,20,ZPC3,COVER-TOP
4 DC61-30344A 1 FRAME-PLATE(U) EGI,NTR,SWF-P12
5 DC32-30006P 1 SENSOR PRESSURE DN-S14,TERMINAL-TYPE(DC5V)
6 DC61-60063B 1 CLAMP-HOSE SK5,-,YEL
7 DC62-10311A 1 HOSE-PRESSURE EPDM,ID13.5,BLK,-,SWF-P12/OD17
9 DC60-20050C 2 SCREW TAPPING -,-,2S,D3,L8,FZY,-
10 DC60-20054C 1 SCREW TAPPING TH,+,1,D4,L12,FE FZY,-
11 DC60-30015B 2 SCREW-SPECIAL FLANGE,PH,+,D4,L12,ZnFe(YEL),-
12 DC97-00851A 1 ASSY-COVER TOP SWF-P12, WOOD TYPE
12-1 DC97-00218A 1 ASSY-COVER TOP STEEL TYPE
13 DC61-30345A 1 FRAME-FRONT EGI,WHT,SWF-P12
13-1 DC61-00056A 1 FRAME-FRONT EGI,WHT,P6091
14 DC60-20054C 6 SCREW TAPPING TH,+,1,D4,L12,FE FZY,-
15 DC60-20030A 1 SCREW TAPPING FH,-,1,D4,L12,NTR,-
16 DC61-00115A 1 DOOR-LOCK S/W 230V/50HZ,GRY,250V(16A)
See on page11
16-1 DC61-00122A 1 DOOR-LOCK S/W P6091 See on page11
17 DC66-30160A 1 LEVER PE,L335,SWF-P12(ORG)
18 DC61-70216C 1 SPRING-HANGER HSWR,OD24,-,-,-,-,P1291,LEFT(RED/SPRAY)
19 DC61-60180A 3 SLEEVE-PLUG NYLON#6,SEW-720DR,NTR
20 DC61-70217C 2 SPRING-HANGER HSWR,OD30,-,-,-,-,P1291,RIGHT(NO-PAINT)
21 DC62-30313A 1 VALVE-WATER NYLON#6,SWF-P12,EATON(COLD)
21-1 DC62-30314A 1 VALVE-WATER NYLON#6,SWF-P12,EATON(COLD+HOT)
22 DC61-60063B 6 CLAMP-HOSE SK5,-,YEL
23 DC62-10068A 0.23 HOSE-DRAWER SOFT-PVC,ID10,NTR,L350,-
24 6001-000947 2 SCREW-MACHINE TH,+,M4,L10,NTR/WHT,STS304
25 DC29-00003A 1 FILTER-EMI FA-2151TS-1,250V,15A,2200PF,P1291,-25/+85'C
DC29-90001A 1 FILTER-EMI AC LINE:FA-215T2-D
26 DC60-20138A 1 SCREW TAPPING PH,TORX,1,D4,L12,ZPC2,-
27 DC96-00146A 1 ASSY-POWER CORD P1291~P6091,250V/16A(PV)
28 DC61-40081A 5 HOLDER-WIRE NYLON66,-,DAWH-3NB,NTR(PI15)
30 DC97-00139B 1 ASSY-HOSE DRAIN(O) SWF-P12V,PP(BB110)2200
32 DC65-60118F 1 BAND RING PW1,YEL,-,PI/33
33 DC99-00033A 1 PAINT SBHG1-A,WHT,P1291(COLD)
DC99-00040A 1 PAINT P6091,COLD
34 DC91-12292A 4 ASSY-LEG SWF-P12,-
35 DC66-60149A 2 DAMPER-SHOCK -,SWF-P12,80N
36 DC60-40026A 2 BOLT-HEX M10,-,-,SCP
37 DC61-10672A 1 COVER-FRONT(L) PP(BJ-730),WHT,SWF-P12
38 DC61-10673A 1 CAP-DRAIN PP(TB53),WHT,SWF-P12
39 DC62-10302A 1 HOSE-DRAIN EPDM,ID5.5,BLK,L220,OD9.5
40 DC90-11110K 1 ASSY-PUMP DRAIN P1291/P1091, 220V~240V/50Hz
40-1 DC96-00149A 1 ASSY-PUMP DRAIN P8091/P6091, 220V~240V/50Hz
40-2 DC96-00035J 1 ASSY-PUMP DRAIN 220V~240V/60Hz
41 6002-000444 2 SCREW-TAPPING TN,+,2S,M4,L14,NTR,STS304
23SAMSUNG ELECTRONICS CO., LTD
