Samsung WW65A Series User manual

WASHING MACHINE
DRUM TYPE
WASHING MACHINE (DRUM) CONTENTS
SERVICE
Manual
REPAIR GUIDE
1. Safety Instructions
2. FeaturesandSpecications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
6. Reference
Model Name : (WW5100A Project)
WW8*A******
WW7*A******
WW65A******
WW70AA626AE/LE
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Samsung
WW80AA126AE o cerca il tuo prodotto tra le migliori offerte di Lavatrici eAsciugatrici

CONTENTS
1. Safety instructions .........................................................................1
1-1. Safety instructions ...........................................................................1
2. FeaturesandSpecications ................................................................4
2-1. Specications................................................................................4
2-2. Comparingspecicationswithexistingmodels ................................................5
2-3. Optionsspecications........................................................................6
3. Disassembly and Reassembly...............................................................7
3-1. Toolsfordisassemblyandreassembly.........................................................7
3-2. Standarddisassemblydrawings...............................................................8
4. Troubleshooting ..........................................................................24
4-1. InformationCode ...........................................................................24
4-2. Problemcheckpoint ........................................................................28
5. Wiring diagram ...........................................................................29
5-1. Wiring Diagram .............................................................................29
6. Reference.................................................................................30
6-1. Modelname................................................................................30
6-2. Terminology ................................................................................31

Safety Instructions _ 1
1. SAFETY INSTRUCTIONS
1-1. SAFETY INSTRUCTIONS
► Makesuretoobservethefollowinginstructionstooperatetheproductcorrectlyandsafelyandpreventpossibleaccidentsand
hazardswhileservicing.
► Twotypesofsafetysymbols,WarningandCaution,areusedinthesafetyinstructions.
WARNING
Hazardsorunsafepracticesthatmayresultinseverepersonalinjuryordeath.
CAUTION
Hazardsorunsafepracticesthatmayresultinminorpersonalinjuryorpropertydamage.
► Followingtherepairbyanon-authorisedserviceprovider,self-repairornon-professionalrepairoftheproduct,Samsungisnot
liableforanydamagetotheproduct,anyinjuryoranyotherproductsafetyissuecausedbyanyattempttorepairtheproduct
whichdoesnotcarefullyfollowtheserepairandmaintenanceinstructions.Anydamagetotheproductcausedbyanattemptto
repairtheproductbyanypersonotherthanaSamsungcertiedserviceproviderwillnotbecoveredbythewarranty.
WARNING BEFORE SERVICING
• (Whenservicingelectricalpartsorharnesses)Makesuretodisconnectthepowerplugbeforeservicing.
4 Failingtodosomayresultinariskofelectricshock.
• Adviseconsumersnottoconnectseveralappliancestoasinglepoweroutletatthesametime.
4 Thereisariskofreduetooverheating.
• Whenremovingthepowercord,makesuretoholdthepowerplugwhenpullingtheplugfrom
theoutlet.
4 Failingtodosomaydamagetheplugorpoweroutletandresultinreorelectricshock.
• Whenthewashingmachineisnotbeingused,makesuretodisconnectthepowerplugfromthe
poweroutlet.
4 Failingtodosomayresultinresultinaccidentaloperationofthewashingmachine.
• Donotplaceorusegasoline,thinners,alcohol,orotherammableorexplosivesubstancesnearthewashingmachine.
4 Thereisariskofexplosionandrecausedfromelectricsparks.

2 _ SafetyInstructions
WARNING WHILE SERVICING
• Checkifthepowerplugandoutletaredamaged,attened,cutorotherwisedegraded.
4 Iffaulty,replaceitimmediately.
Failingtodosomayresultinelectricshockorre.
• Completelyremoveanydustorforeignmaterialfromthehousing,wiringandconnectionparts.
4 Thiswillpreventariskofreduetotrackingandshortsinadvance.
• Whenconnectingwires,makesuretoconnectthemusingtherelevantconnectorsandcheckthattheyareproperlyconnected.
4 Donotusetapeinsteadoftheconnectors,itmaycausereduetotracking.
• MakesuretodischargethePBApowerterminalsbeforestartingtheservice.
4 Failingtodosomayresultinahighvoltageelectricshock.
• Whenreplacingtheheater,makesuretofastenthenutafterensuringthatitisinsertedintothebracket-heater.
4 Ifnotinsertedintothebracket-heater,ittouchesthedrumandcausesnoiseandelectricleakage.
• Donotrepairthewashingmachinewithoutsafetygloves.
4 Itcancauseinjury.
WARNING AFTER SERVICING
• Checkthewiring.
4 Ensurethatthewiringcannotbedamagedbyanysharpedgesormovingparts.
• Checkforanywaterleakage.
4 Performatestrunforthewashingmachineusingthestandardcourseandcheckwhetherthereisanywaterleakage
throughtheoorsectionorthepipes.
• Adviseconsumersnottorepairorserviceanypartofthewashingmachinethemselves.
4 Thismayresultinpersonalinjuryandshortentheproductlifetime.

SafetyInstructions _ 3
CAUTION BEFORE SERVICING
• Donotsprinklewaterontothewashingmachinedirectlywhencleaningit.
4 Thismayresultinelectricshockorre,andmayshortentheproductlifetime.
• Donotplaceanycontainerswithwateroranyotherliquidonthewashingmachine
4 Ifthewaterisspilled,itmayresultinelectricshockorre.Thiswillalsoshortentheproduct
lifetime.
• Donotinstallthewashingmachineinalocationexposedtosnoworrain.
4 Thismayresultinelectricshockorre,andshortentheproductlifetime.
• Donotpressacontrolbuttonusingasharptoolorobject.
4 Thismayresultinelectricshockordamagetotheproduct.
CAUTION WHILE SERVICING
• Whenwiringaharness,makesuretosealitcompletelysonoliquidcanenter.
4 Takecarewhendisconnectingconnectors,donotuseexcessiveforceasthismaydamage
theconnector.
• Checkifthereisanyresiduethatshowsthatliquidenteredtheelectricpartsorharnesses.
4 Ifanyliquidhasenteredintoapart,replaceitorcompletelyremoveanyremainingmoisturefromit.
• Ifyouneedtoplacethewashingmachineonitsbackforservicingpurposes,placeasupport(s)ontheoorandlayitdown
carefullysoitssideisontheoor.
4 Donotlayitdownonitsfront.Thismayresultintheinsidetubdamagingparts.
• Atleasttwopeopleshouldworkwhenworkingwithheavyproducts.

FeaturesandSpecications_4
2. FEATURES AND SPECIFICATIONS
2-1. SPECIFICATIONS
MODEL WW70AA626AE/LE
Modelname FRONT LOADING TYPE
Dimensions 600x850x450
Water pressure 50kPa~800kPa
DrumVolume 48L
NETweight 48L
Washandspincapacity 7kg
Powerconsumption 1900 - 2300W
Spinrevolutions 1200rpm
- pleasevisitSamsungofcialwebsitetoreceivemostup-to-dateinformationaboutsoftwareandproductmaintenance.
Model WW70AA626AE/LE
Width(A) 600 mm
Height-Overall(B) 850 mm
Depth(C) 450 mm
Depthwithdooropen90°(D) 965 mm
A
B
C
D

5_FeaturesandSpecications
2-2. COMPARING SPECIFICATIONS WITH EXISTING MODELS
Model Name WW70AA626AE/LE
Main Spec
Capacity 7
DrumVolume 48
MaxRPM 1200
Motor DIT
WaterSupply Coldonly
Drainage Pump
USP
ECOBUBBLE ●
AddWash ●
Steam ●
AOW/AD X
SuperSpeed X
Wi X
Q-Drive X
Design
DOOR Basic
Drum Swirl
DISPLAY G. LED

FeaturesandSpecications_6
2-3. OPTIONS SPECIFICATIONS
NO Unit Part Code Figure Description Qty
1BoltSpanner DC60-40146A Toremovetheshippingbolts
Toadjustthelevelingleg 1
2
Assy Hose
Water
DC97-17845A(Cold)
DC97-17845B(Hot)
Tosetupwatersupply. Coldonly1,
Cold+Hot2(★)
3Hose Water
(Aqua-Stop) DC67-00675A Tosetupwatersupply. 1(★)
4ManualUsers DC68-03649A~Z Toexplaintheproduct
operationandinstallation 1
5CapFixer DC67-00307A Tocovertheholes 3
6Hose Hanger DC67-00357A Tosecurethedrainhose. 1
7GuideLiquid DC61-03510A Touseliquiddetergent. 1(★)
Note
• (H)issuppliedforspecicmodelsonlyamongthosewithoutwatersupplyhoses.
• Customercanpurchaseadditionalwatersupplyanddrainhosesfromaservicecenter.
• Forbuilt-inmodels,thespanner,watersupplyanddrainhosesarenotsupplied.Boththewatersupplyanddrainhosesare
suppliedduringtheinstallation.

Disassemblyand Reassembly _ 7
3. DISASSEMBLY AND REASSEMBLY
3-1. TOOLS FOR DISASSEMBLY AND REASSEMBLY
Tool Type Remarks
Boxdriver
10mm Heater(1),Tub(12),Fixerscrew(5),Motor(2),
Balance(9)
13mm ShockAbsorber(2holeseachinleft/right),
Damper(2),Damper(friction2)
19mm Pulley(1)
Double-ended
spanner
10mm
13mm
19mm
Replacedbyboxdriver
Leg
Vicepliers
AToolforprotectingemptyturningofboltor
abrasionfromusingboxdriver
FordisassemblyofSpindrum
Others
(screwdriver,nipper,long
nosepliers)
Commontoolsforservicing
Torquewrench TheToolforassemblyofheaterandTub
-Forinformationaboutpurchasingpartsandtool,pleasevisit
http://www.samsung.com/support
-Forthepartcodeinformation,pleaserefertheattachedle'ExplodedView'.

8 _ Disassemblyand Reassembly
3-2. STANDARD DISASSEMBLY DRAWINGS
► Thisisastandarddisassemblydiagramandmaydifferfromtheactualproduct.
Usethismaterialasareferencewhendisassemblingandreassemblingtheproduct.
Disassembly
Part Figure Description
Assy Cover Top
1. Remove2screwsholdingtheCoverTopatthe
backoftheunitusing(+)screwdriver.
BACK FRONT
2. RemovetheCoverTopbyliftingitupafter
pullingitbackabout15mm.
Assy Drawer
1. OpentheDrawerbyhand
2. Whileholdingdownthereleaseleverinsidethe
drawer(redbox),slideopenthedrawer.
3. PulluptheCapRinsetoremoveit.

Disassemblyand Reassembly _ 9
Reassembly
Part Figure Description
Assy Drawer
1. FittheholeandpresstheCapRinsesothatit
canbeassembled.
2. Makesuretottherailwhenreassemblingthe
Assydrawer.
3. Putthedrawerintherightdirection.

10 _ Disassemblyand Reassembly
Disassembly
Part Figure Description
Assy Panel Control
(LED)
-Beforeyoustart,disassembleAssyCoverTop,Assy
Drawer.
1. Remove2screwsholdingthedrawerandpanel
using(+)screwdriver.
2. RemovethescrewsatthetopoftheASSY-
PANELCONTROLusing(+)screwdriver.(3ea)
3. Grabthepanelandslightlypushthehousing
drawertoremovethehookandpullthepanel
upwardstodisassemblewithbody.
 Becarefulnottobreakthehook.
4. HoldtheASSY-PANELCONTROLwhilepulling
itupwardsanddisassembletheterminalto
removeit.Pressthehookwhileremovingthe
terminal.

Disassembly and Reassembly _11
Reassembly
Part Figure Description
Assy Panel Control
(LED)
1. Connecttheterminalbyhand.Takealookat
thehookandputitintherightplace.
 MakesuretheWireharnessarenotgetting
stuckinotherparts.
2. Assemblethehookofhousingdrawerand
aseemblescrewsatthetopoftheASSY-PANEL
CONTROLwith(+)screwdriver.
 Becarefulnottobreakthehook.
3. Assemble2screwsholdingthedrawerand
panelwith(+)screwdriver.

12 _ Disassemblyand Reassembly
Disassembly
Part Figure Description
Assy Housing-Drawer
Beforeyoustart,disassembleAssyCoverTop,Assy
PanelControl.
1. Remove4screwstodisassembleframeplate-
upusing(+)screwdriver.
2. RemovetheBand-ring.(2ea)
 Becarefulnottobreakthehose.

Disassembly and Reassembly _13
Part Figure Description
Assy Housing-Drawer
3. Separatethewatervalvehosewithlongnose
plier.
4. SeparateHousingDrawerlowbypressingthe
hooksonbothsidesbyhand.Tofullyseparate,
disassembleWaterValve.
 Becarefulnottobreakthehook.

14 _ Disassemblyand Reassembly
Reassembly
Part Figure Description
Assy Housing-Drawer
1. AssembletheHousingDrawerlowbypressing
thehooksonbothsidesbyhand.
 Becarefulnottobreakthehose.
2. Assemblethewatervalvehosewithlongnose
plier.
 Becarefulnottobreakthehook.
 Makesuretoinsertthehosesandassemble
theclamp,bandringscorrectly.There’re
risksofleakageorpoorperformancewhen
it’smisassembled.

Disassembly and Reassembly _15
Part Figure Description
Assy Housing-Drawer
3. AssembletheBandrings.(2ea)
 Makesuretoinsertthehosesandassemble
theclamp,bandringscorrectly.There’re
risksofleakageorpoorperformancewhen
it’smisassembled.
4. Remove4screwstodisassembleframeplate-
upusing(+)screwdriver.

16 _ Disassemblyand Reassembly
Disassembly
Part Figure Description
Frame Front
Beforeyoustart,disassembleAssyCoverTop,Assy
PanelControl.
 Becarefulnottotearupthediaphragm.
1. Usinglongnosepliers,pickuponeofthe
ringsonWire-Diaphragmwhichconnectthe
springandthewireends.Then,separatethe
Wire-DiaphragmfromtheFRAME-FRONTand
DisconnecttheDiaphragm.
2. Remove2screwsholdingtheDOOR-LOCK
switchwith(+)screwdriver.
3. Disassembletheterminal(theblueboxis
terminallocation)bypressingthebluecircle
partandremove2screwsholdingtheFrame
Frontwith(+)screwdriver.
4. Pressthecircledplacetoopenupthecover
lter.
5. Remove3screwsholdingthebottomofthe
FRAME-FRONTwith(+)screwdriver.

Disassembly and Reassembly _17
Part Figure Description
Frame Front
6. Removecoverlterbyhand.
7. PressthehooktoremoveGuidecoverlter
using(-)screwdriver.
 Becarefulnottobreakthehook.
8. PulltheGuideltertowardsyou.
9. LiftFramefrontuptodisassemble.
Cover-Back
Unfasten6(Dependingonthemodel,therecanbe
4screws)screwsthatholdthecoverbackinplace
with(+)screwdriver.
Removethebackcoverbyslidingitup.
(Whenassembling,slidethebackcoverdown.)

18 _ Disassemblyand Reassembly
Disassembly
Part Figure Description
Assy Door
Beforeyoustart,disassembleAssyCoverTop,Assy
PanelControlandFrameFront.
1. Removethewirebydisassemblingthe3hooks
usinglongnoseplier.
2. Disassembletheterminalandremovethe
holdersusinglongnosepliers.
3. Remove2screwsholdingtheAssydoor.
Removethedoorbyslightlyliftingthedoor.
