Digital Motor Protection Relay
www.samwhadsp.com
NewLeader !! Optimized PreventiveMaintenanceSolution!!
DSP - C Series

-Window 10 or more -Office(Excel) -Net Frame 4.0 or more(open protocol)
-Desk PC(with PCI Card) “samdsp”:monitoring & Analyzing” ✽“samdspdb”:monitoring & data base”
Main window
Graph window
Field
Office
◎System
●Created data for motor protection : Voltage, Current/KW, Earth current,
Isulation resistance, Temperature, Power factor, Unbalance
●Building data base(DB) up based on 485/Modbus network
●Analyzing and managing DB DATA in order to check the motor condition and
to make alarm in case of unstable condition : able to preset alarm level for each factor
●Possible to analyze accurate trip cause through stored data of trip instant in
MWR-S(Motor working Recorder) connected with converter directly
●Office PC is able to do master job without installation for additional Server as master
Motor Preventive Maintenance Diagnostic System(DSP-EFDS)
: VIP-PM/RTM, "samdsp","samdspdb"

“”
New Leader !! SamWha DSP!!
Digital Motor Protection Relay
DigitalMotorProtectionRelay,DSPVIP-Series ,P-Series,C-Series,A-Series,
is useful forlowvoltagemotorprotection. It is aimed to protectamotoragainsta
troublewhich is happened fromover/underload[current],lockedrotor,stall[shock],voltage
(powertype)/currentunbalance,phase loss,reversephase, short circuit,
groundfault,over/undervoltage(powertype) in motoroperation.
Also it is able to raisethe efficiency formotoroperationas being possibleto realizea
supervision, aprotectionand acontrol,furthermoreeach kind of series itemtakesit's own
specialized function, respectively, in order to meet variouscustomerneed such
as short circuit,alarm beforetrip,4~20mA output forloadcurrent,insulation
resistancemeasureemnt,vibratedfrequencydetectionthrough4~20mA output from
sensor,RS485 or Ethernet communication.
EspeciallyCurrent-Resistancetype canmeet twokind of differentjob which is
consistedof powerfulmotorprotectionduring amotorrunning stateand the insulation
resistancemeasurementforapowerline of the motorduring amotorstopstate.This
wouldbe morepowerfulto preventan industrialdisastercausedby adegradedpower
line of the motorused forthe longtermsincefirstinstallation
Nowwe launch newitemsuch as DSP-2SD/3SD which is based on 2CTor 3CTwith
basic essentialprotectivefunction except GR fault matched with ZCT. However, we
prepared 3SD-RG with GR fault protection through residual circuit for user who
want to take specific function like GF. We will do not cease R&D to meet customer's
need in any conditionin todayand in future.

Digital Motor Protection Realy
DSP-C Series
●● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
●
● ● ● ● ● ● ● ●
●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ●/Dua l ●
●● ● ●
●
TechincalFeature
3
Division
DSP-C Series
Panel Flush MountingType
Model
Control voltage
Available frequency/Inverter
CTM
CCM
CCM-E
CSM
CTM-DCCTM
CCM-N
100~240VAC[50/60HZ](90 ~ 370VDC)
30 ~ 400HZ
COM
Singlephase(1P)
Threephase(3P)
Overcurrent
Undercurrent
Phaseloss/load current
Reversephase/load current
Currentunbalance
Pre-alarm
Protection
Lockedrotor
Shock/Stall
ShortCircuit
Groundfault
Temperature
Control/ON-OFF
Load current
Standard:externalZCT/Optional:ZCTembeded
Remarks
Communication
Indication
Auxiliary
Groundfaultcurrent
Accumulated workingtime
Presetvaluecheck/
change in operation
Load factor/Bar Graph
Load factor/LF-%
Password
Maincontactorautoclose
4~20mA
RS 485/Modbus,RTU
Ethernet/ModbusTCP
(M Type)
(M Type)

CSM CCM-E CTM-D CCTM
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ●
● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ●
● ● ● ● ● ● ● ● ● ● ● ● ●
● ● ● ●
● ● ● ● ● ● ●
● ●
Panel Mounting Type
COM CCM CSM CCM-E CTM-D CCTM CCM-N
●● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
●
● ● ● ● ● ● ● ●
●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ● ●
● ● ● ● ● ● ●
● ● ●/Dual ●
●● ● ●
●
Panel Mounting Type
Samwh a D SP•4
DSP-C Series
Panel MountingType
Division
CTM-NCCM-ETCCM-PT
COL
CTL
CCL
CSL
CCL-PT
100~240VAC[50/60HZ](90 ~ 370VDC)
30 ~ 400HZ
Model
Controlvoltage
Available frequency/Inverter
Singlephase(1P)
Threephase(3P)
Overcurrent
Undercurrent
Protection
Phaseloss/load current
Reversephase/load current
Currentunbalance
Pre-alarm
Lockedrotor
Shock/Stall
ShortCircuit
Groundfault
Temperature
Control/ON-OFF
Indication
Loadcurrent
Groundfaultcurrent
Accumulatedworkingtime
Presetvaluecheck/
change in operation
Loadfactor/Bar Graph
Load factor/LF-%
Password
Auxiliary
Communication
Ethernet/ModbusTCP
Remarks
Standard:externalZCT/Optional:ZCTembeded
RS 485/Modbus, RTU
Maincontactorautoclose
4 ~ 20 mA
Panel Flush Mounting Type
(M Type)
(L Type)
(L Type)

Digital Motor Protection Relay
DSP-C Series
DSP-COL, CTL, CCL,CCL-PT : Panel Mounting Type
DSP-COM, CTM, CCM,CSM: Panel Flush Mounting Type
DSP-CCM-E,CTM-D,CCTM,CCM-N,CTM-N,CCM-ET,CCM-PT: Panel Flush Mounting Type
Panel Mounting Type → Unied meter with converter
Panel Flush Mounting Type → Seperated meter from converter
10 Type 0.5 ~ 10A Available for external CT
70 Type 5 ~ 70A
COM
COL
AssembledTerminal
Over/UnderCurrentProtection
TripOutput OperationPattern
10 Type
70 Type
0.5 ~10A AvailableforexternalCT
5 ~ 70A
Tripoutput :main/95-96(b)-98(a),aux/05-06(b)-08(a)
"b" is selectedin "out" mode :factorydefault
Controlpoweris on/unchanged output state:95-96(b)-98(a),
aux/ 05-06(b)- 08(a)
TRIP operationstate:95-96(a)-98(b), 05-06(a)-08(b)
"a" is selectedin "out" mode
Controlpoweris on/changed output state:
95-96(a)-98(b), 05-06(b)-08(a)
TRIP operationstate:95-96(b)-98(a), 05-06(a)-08(b)
GF protection
Basic
Optional
*zerophase currentis sensed through
externalZCT
*ZCT:200mA/1.5mA
*30mA~2A
*zerophase currentis sensed through
embedded ZCT
*30mA~2A
Aux output →:AL/pre-alarmto OC presetvaluebeforetrip
:Tripfactoris selectedin "AU-O" Mode
:Independent output contactfrommain trip output
: "Auo" mode /OFF, AL, UC, SHOCK, EC, rP, Ec-tb
: Ec/auto reset, Ec-tb/independent trip
5

①
④③②
⑥
⑤
⑦
①
⑤④③②
⑦
⑥
⑧
①⑨
⑤④③②
⑦
⑥
⑧
①
④③②
⑥
⑧
⑤
⑦
①⑤
④③②
⑦
⑥
⑧
①
⑤④③②
⑦
⑥
⑧
4~20mA
Digital Motor Protection Relay
DSP-C Series
① Control power
②Main Trip output
③Aux trip output(alarm)
④External ZCT/embedded if
Z1,Z2 is not marked
① Control power
② Main Trip output
③ Aux trip output(alarm)
④ External ZCT/embedded if
Z1,Z2 is not marked
① Control power
② Main Trip output
③ Aux trip output(alarm)
④RS-485 Modbus /RTU
⑤External ZCT/embedded if
Z1,Z2 is not marked
① Control power
② Main Trip output
③ Aux trip output(alarm)
④ External ZCT/embedded if
Z1,Z2 is not marked
① Control power
② Main Trip output
③ Aux trip output(alarm)
④ RS-485 Modbus / RTU
⑤ External ZCT/embedded if
Z1,Z2 is not marked
① Control power
② Main Trip output
③ Aux trip output(alarm)
④ RS-485 Modbus / RTU
⑤ External ZCT/embedded if
Z1,Z2 is not marked
Input/Output
DSP-COM
DSP-CCM-E
DSP-CCM
DSP-CTM
DSP-CCTM
DSP-CSM
⑤Power & Trip LED
⑥Test & Reset
⑦ 9Pin D-sup to connect meter
(RS-232)
⑧Terminal Without marks is not
used
⑥Power & Trip LED
⑦ Test & Reset
⑧ 9Pin D-sup to connect meter
(RS-232)
⑨ Terminal Without marks is not
used
⑤ Power & Trip LED
⑥RJ-45 (Ethernet)
⑦ 9Pin D-sup to connect meter
(RS-232)
⑧Reset
⑨External ZCT/embedded if
Z1,Z2 is not marked
⑥Power & Trip LED
⑦Test & Reset
⑧9Pin D-sup to connect meter
(RS-232)
⑨ 4~20mA,current output
⑩Terminal Without marks is not
used
⑤4~20mA, current output
⑥Power & Trip LED
⑦Test & Reset
⑧9Pin D-sup to connect meter
(RS-232)
⑨External ZCT/embedded if
Z1,Z2is not marked
⑥ Power & Trip LED
⑦ Test & Reset
⑧ 9Pin D-sup to connect meter
(RS-232)
⑨ External ZCT/embedded if
Z1,Z2 is not marked
6

Digital Motor Protection Realy
DSP-C Series
Operation Time
DIV
Description
Operationtime
Remark
Overcurrent(OC)
in casethe loadcurrentgreaterthan presetvalue
is sensed
Definitetime:0.1~60 sec/adjustable
Inversetime:5~30class
C Series
Under current(UC)
in casethe loadcurrentlowerthan preset
valueis sensed
0.1~30 sec
Phase loss(PLc)
In caseone of threephase is astateof phase loss
1sec~5sec
reversephase(rPc)
0.5sec
Lockedrotor(LC)
In casethe startingcurrentgreaterthan 300% of
"OC" presetvalueis keptafterdt is elapsed
0.1sec
0.5sec~3sec
In casethe 180~700% running currentof
preset"OC" valueis sensed
Shock/Stall
Current
unbalance(ub)
1sec ~8sec
0.1~30 sec
in casethe groundfaultcurrentgreaterthan
presetvalueis sensed
Groundfault(EC)
to ptotectovertemperaturesensed by PT100
8sec,onlyforCCM-PT/CCL-PT type
Technical Specification
DIV
Description
Load Current
range
10 Type
70 Type
With ExternalCT
*0.5A~10A or externalCT(0.5~6A)
*0.5~6A forshort circuitprotection
*InverseT-I :0.5~10A/800%
*5A~70A
*5~25A forshort circuitprotection
*InverseT-I :5~40A/800%
1A~1200A
Groundfault
Time preset
Zerophase current
*30mA~2A
*sensed throughexternalZCTor embedded ZCT
Startingdelay time(dt)
1~300 sec/def.
1~60 sec/def.
overcurrenttrip delay(ot)
5~30Class/inv.
under currenttrip delay(uc)
1~30sec/def.
Groundfaultstartingdelay time(Edt)
OFF,0.1~25 sec/def.
Groundfaulttrip delay time(Eot)
Shock/stalltrip delay time(st)
0.5~3sec/def.
Phase losstrip delay time(PLc)
1~5sec/def.
[max current-mincurrent)/maxcurrent]*100%
0.5~30 sec/def.
In casethe orderof load current phase
is changed like "RTS" from "RST"
7
Temperature(tEmP)

Digital Motor Protection Realy
DSP-C Series
DIV
Description
Allowable
tollerance
Current
Time
C<=2A:0.2A,C>2A:±5%
t<=2sec:± 0.2ec, t>2sec:±10%
Controlpower
Tripoutput
relay
Main:95-96-98
Aux:05-06-08
1c(1-SPDT),2A/Resistive
1c(1-SPDT),2A/Resistiveto alarm output one of Ec/Ect/AL/
uc/Shoc
Application
environment
temperature
Operation
Storage
Humidity
-25O
C~+70OC
-40O
C~+80OC
30~85%/Relative,non-condensing
Currenttolleranceagainstchangeable
frequency
Max Main ConductorSize
ScrewTorque
Insulation Resistence/IEC-60255-5
High VoltageWithstandTest/IEC-60255-5
Average+,- 5%,30Hz~400Hz
25SQ
100Mohm or more/500VDC,circuit-case
Max 0.6 N.m
*circuit-case:AC2000V,60Hz,1min
*contact-contact:AC1000V,60Hz,1min
Lightning Impulse VoltageWithstandTest)/
IEC-60255-5
*Circuit-Ground,Circuit-Circuit:1.2/50uS,5KV
*ControlCircuits:1.2/50uS,5KV
Power,Realyoutput:Level4, 4KV
1MHz BurstImmunity Test/:IEC61000-4-18
2.5KV,Positive/Negativeunder 2sec
ElectrostaticDischarge/IEC-61000-4-2
Air:Level3, 8KV,Contact:Level3,6KV
Level3, 10V/m
RadiatedElectromagneticField Disturbance/
IEC-61000-4-3
ElectricFastTransientBurst/IEC-61000-4-4
SurgeImmunity test:IEC-61000-4-5
ConductedDisturbenceTest:/IEC-61000-4-6
Relay output:1.2X50uS,2KV(0°,90°,180°,270°)
10V,Level 3
Physical
RS485
Digital
communication
Etherent
Powerconsumption
Address
Speed
Connection
Termination
resistance
Cable
Physical
Address
2wireRS 485,Modbus/RTU
1~250
Sheathed 2Pair
ModbusTCP,1Port/Isolation,LED Type
9.6/19.2/38.4/57.6/76.8/115.2kbps
Terminal:TRX(+),TRX(-)
it needs to use external resistance with 120 Ω
http://www.sollae.co.kr/kr/download/utility.php:
ezManager v3.2E
6W Max
AC100V~AC240V,50/60Hz(DC90V ~DC370V)
Samwh a D SP•8

Digital Motor Protection Realy
DSP-C Series
Preset Key Operation
1. "SET" key
*Press"SET" Keyto enterintosetting mode, then "P0000"
(factorydefault password)is shown
*Movecursorfromfirstdigit to right end digit by pressing"CLR"keyto
input password, like this manner makerequireddigit by using "UP","DN"
keyif it is customer'snumber ,finallypressoncemore,
then operatormeets possiblestateforpresetanumber or characterof mode.
*If thereis no input for15sec or pressingboth "SET" and "CLR"key,it can
be enteredintooperatingcondition.
2. Changed
feature
of Setting Key
*Afterenteringintoposiblestateforpreset,each keyacts its job
as follows:SET---> backwarddirection,CLR--->fowarddirection,
UP.DN--->ableto selectnumber or characterin presetmode.
*The previousmode based on setting mode is comeout as pressing"SET"
keyduring doing aprestjob
3. "SET" Key&
"CLR" Key/to
selectMODE
*Possible to selectMode by using "SET" or "CLR" key
4. "UP" key&
"DN" Key/
Adjust
*Possible to presetrequired valueas selectionacharacteror number by using
UP/DOWN
5."SET" &
"CLR" Key/
Store
*The storageforpresetdatais completedby pressingboth SET and CLR key
in the same time
6."CLR" key
*Whileeach factoris rotated,one of rotatedfactoris fixedby pressing
"CLR" key
*Afterfixing aoperatingfactor,the operatoris ableto rotatemanual one by
one as pressing"UP"(forwardly),"DN"(reversely)
to check and/
or to change
presetvalue
of each mode
during the
operation
*Possibleto check avalueand amode as pressing"SET" keyonceduring
the operation
•presetvalueand mode areappearedalternatively
•nextmode as pressing“CLR” Keyor previousmode as pressing“SET” key
*Possibleto change apresetvalueafterenteringintochecking stateif
the presetvalueof “OPSET” mode belongedto “CAB”mode groupis “ON”/
factorydefaultvalueis “OFF”
*Return to operatingmode as pressingboth “SET” and "CLR" keyin the
same time or waiting for
Test/
Reset:"CLR"
Key
*tocheck if this relayis readyto worknormallyor not.
*"tESt" is appearedin casethe operatorpressestestsw on the converter
or "CLR" keyfor3sec or more,then releasepressedtestsw or "CLR" key
*main trip(95-96-98) & aux trip(05-06-08) output will be trip after
countingdownpreseto-time(definiteT-I)
*In caseof display metertype, LED on the converteris flickeringafteratrip
*Aftermaking trip, press"CLR" keyforthe resetaction
9

1. "SET" key
* Press "SET" Key to enter into setting mode, then "P0000"(factory default
password) is shown
* Move cursor from first digit to right end digit by pressing "CLR"key to
input password, in the same time make required digit by using "UP","DN"
key if it is customer's number , finally press once more,
then operator meets possible state for preset a number or character of
mode.
* If there is no input for 15sec or pressing both "SET" and "CLR"key, it can
be entered into operating condition.
2. Changed
feature
of Setting Key
* After entering into posible state for preset , each key acts its job as
follows : SET---> backward
direction, CLR--->foward direction,UP.DN--->able to select number or
character in preset mode.
* The previous mode based on setting mode is come out as pressing
"SET" key during doing a prest job
3. "SET" Key &
"CLR" Key/to
select MODE
* Possible to select Mode by using "SET" or "CLR" key
4. "UP" key &
"DN" Key/
Adjust
* Possible to preset required value as selection a character or number by
using UP/DOWN
5."SET" &
"CLR" Key/
Store
* The storage for preset data is completed by pressing both SET and CLR
key in the same time
6."CLR" key
* While each factor is rotated, one of rotated factor is fixed by pressing
"CLR" key
* After fixing a operating factor, the operator is able to rotate manual one
by one as pressing "UP"(forwardly), "DN"(reversely)
to check and/
or to change
preset value
of each mode
during the
operation
*Possible to check a value and a mode as pressing "SET" key once during
the operation
•preset value and mode are appeared alternatively
•next mode as pressing “CLR” Key or previous mode as pressing “SET”
key
*Possible to change a preset value after entering into checking state if
the preset value of “OPSET” mode belonged to “CAB” mode group is “ON”/
factory default value is “OFF”
*Return to operating mode as pressing both “SET” and "CLR" key in the
same time or waiting for
Test/
Reset:"CLR"
Key
*to check if this relay is ready to work normally or not.
*"tESt" is appeared in case the operator presses test sw on the converter
or "CLR" key for
3 sec or more, then release pressed test sw or "CLR" key
*main(95-96-98) & aux trip(05-06-08) output will be trip after counting
down preset o-time(definite T-I)
*In case of display meter type, LED on the converter is flickering after a
trip
*After making trip, press "CLR" key for the reset action
Preset Description
Mode
Function
Description
Factory
P0000
Password
P0000 is shownas pressingSET and need CLR 4times to
enterintomode to be preset
0000
b
*tomakeinitial state(aor b) of main trip
output(95-96-98) when controlpoweris powered
*a:normal energizedtype(95-96(a)-98(b)
*b: normal deenergizedtype(95-96(b)-98(a)/not
changed state
to decide initial stateof main
trip relay output
OUt
Ct
to selectfordirectthrough
it's own CT or externalCT
*This mode is availablefor10 Type
*TopresetCT ratio[primaryvalue/5]
*CT ratio:1~600
*2t:twicewinding throughCT hole/0.3~3A
*4t:fourtimes winding throughCT hole/0.2~2A
*1:tosense acurrentthroughits ownCT or externalCT with
5/5 ratio
1
*10:10A
*70:70A
5sec
10 type:0.5~10A, 70 type: 5~70A
to presetarangeto protect
overcurrent
OC
dt
to presetstartingtrip delay
time
dEF
dEF : definite,Inv :inverse
OtC
to selecttime-current
chracteristicsfor
Ot
to presetoperatingtrip delay
time
*definite:1sec~60sec
*inverse:5~30 Class
5sec
OFF
OFF
ON
OFF
2A
LC
ShoC
St
PLC
rPC
EC
to protectLockedRotor
to protectmechanicalshock
during motoris working
to presetatime forshock
protection
to protectphase lossby load
current
to protectreversephase by
loadcurrent
to presetarangeof zerophase
current to ground fault
0.5 ~3sec /definite
ON: available,0.5sec,OFF :not available
ON :available,1~5sec/adjustable,
OFF:not available
30mA~4A/adjustable,OFF :disable
1.0 ~300sec/adjustable
*it is availableforselectingON [operationtime: 0.1sec
afterdt is elapsed]
*conditoionfor"ON" :startrunning currentis kepton
300% afterdt is elapsed
*presetto "OC" :followedcalculation/max700% ~
-10Type:180%~[30/"OC"presetvalue]%
-70Type:180%~[200/"OC"presetvalue]%
--
Samwh a D SP•10

Digital Motor Protection Realy
DSP-C Series
Mode
Function
Description
Factory
2sec
0.1sec
OFF
2sec
50%
OFF
90
6500
5
OFF
OFF
hr
9600
1
1
60
0.1
2400, 9600, 19200, 38400bps/CCM,CCL Type
to decide communication
speed
bPS
Addr
trIP
to put self-addressto
communicatewith pc
trip informationin order:faultyphase and faultyvalueis
appearedalternativelyas controlling"UP" or "DN" key
rangeof number:#1 ~#250/CCM,CCL Type
to showlatestnumber of 8trip
cause
t-AUt
to presettotalpossibletime
availableforexecutingdefined
times of autoreset
30min ~60min/adjustable
0.1 ,1~ 300sec/adjustable
to presetautoresettime
At
rESEt
to decide howto resettrip
state
*Hr:manual reset/Passwordinput →main trip,
Ec-tb trip(Aux)
*Er:electricalreset:"Reset" key,"CLR" Key,Control
power-off
*AuL-#(n times):Autoresetby followedcondition/
max n=9:n=1:possibleto do onlyby enteringpassword
*Passwordreset:resetis done by commingout from
operatingmode afterinput password
*Auto:onlyavailablefor"OC" trip
*OFF:3 phase current(L1,L2,L3),GFcurrent
*ON:[3 phase current],GF current]+[AWT]
*intervaltime betweeneach displayedfactor:3sec
to indicateadditional factor
besides basic factorto indicate
running operationvaluein aorder
rOtA
tEmP
dC
ALt
AL
to protectovertemperature
*8sec, 1~150OC, sensed by PT100, onlyforCCM-PT/
CCL-PT type
*totransfermaximum currentof 3phase currentinto20mA
,and 4mA means zeroampereoutput/CTM,CTLType
to decide max currentto
change into20mA
AU-O
to presetalimit of
accumulatedworkingtime
necessaryto givealarm.
0.1 hr ~6553.5 hr in 0.1 hr step
to preset alarm level
rate(%) to OC
* % range : 65%~100%/adjustable ("AL" is preset in
"Auo" mode)
Edt
EOt
UC
Ut
Ub
to presetakind of AUX trip
output
*oFF:same as main output
*trip output forAL/Uc/Shoc/Ec is independent from
main trip →this trip output is resetnaturallyif trip
causeis clear
*Ec-tb: onlyforgroundfaultprotection,but resetis not
happened eventhough trip causeis clear
*trip is storedin “trip” mode as aone of 8latestevent
*formular:[(max-min)/max]*100 [%]
*range:30%~90% *minimum availablecurrent:0.3A
to presetcurrentunbalance
rate(%)among 3phasea
to presettrip delay time to
protectunder current
1 ~ 30sec/adjustable
to presetarangeto protect
under current
*10 type :0.4A~under "OC" presetvalue
*70 type :4.9A~under "OC"presetvalue
0.1 ~30sec/adjustable
to presetoperatingtrip delay
time to protectgroundfault
to presetstartingtrip delay time 1 ~ 25sec/adjustable
11

Digital Motor Protection Realy
DSP-C Series
T-I Characteristic to protect over current
■ Inverse■ Definite
Samwh a D SP•12

Digital Motor Protection Realy
DSP-C Serie
OrderForm
DIV
Description
Remark
1
2
3
4
5
6
TerminalType:Basic referencecode+T :eg.XXXXXX -T
COL
COM
10
70
B
Z
7
ZCT
P
PanelMounting Type/Unified Metertype
5~6A with externalCT
PanelFlush Mounting Type/SeperatedMetertype
0.5~10A
5~70A
24VAC/DC
100VAC~240VAC(90VDC ~ 370VDC)
50/60Hz
Embedded ZCT
Optional by customer
not used forexternalCT type
Accessory
ExternalCT
Cable
ZCT
DSP - CABLE-12
DSP - C1
DSP - CC
DSP - C2
DSP - C3
DSP - C4
DSP -CABLE-18
DSP -CABLE-30
DSP -CABLE-50
DSP -ZCT-XX
*100mA/1.5mA
*XX :Inner diameterof ZCT
5m
3m
1.8m
1.2m
3CT/Rectangular,400/5
3CT/Rectangular,300/5
3CT/Rectangular,200/5
3CT/Rectangular,150/5
3CT/Rectangular,100/5
DSP-Type-Currentrating-Z7(ControlVoltage)-ZCT(EmbeddedZCT)-P(Customeroptional)
eg. ReferenceCode :DSP-COL-10-CC-Z7 →COL combinedwith externalCT 150/5, controlvoltage:
100VAC~240VAC,50/60Hz,possibleto use externalZCT
13

Digital Motor Protection Realy
DSP-C Series
wha
Sam
DSP Ltd.
ktTpp
L1
L2
L3
65 70 75 80 85 90 95 100%
Amp
Ec
Sec%
wha
Sam
DSP Ltd.
ktTpp
L1
L2
L3
65 70 75 80 85 90 95 100%
Amp
Ec
Sec%
ApplicationSequenceDiagram
Embedded ZCTType
ExternalCT, External ZCT Type
Samwh a D SP•14

Samwha DSP•15
Digital Motor Protection Realy
DSP-C Series
76,00
69,00
14,50
23,50
16,50
50,00
76,00
69,00
CUTTING HOLE SIZE ; 65Ø
Wire Through Type
Dimension
Terminal Type
Meter

16
120
3CT
DSP-3CT
2.5SQ /10M
Screw Fix
1.0, 3.0
3VA
1150V
4kV /1min
50 ~60Hz
5P 5
3CT with DSP
120
3CT
DSP-3CT
Item CT Ratio Reference Code
3CT
100 : 5 DSP-3CT-100
DSP-3CT-150
DSP-3CT-200
DSP-3CT-300
DSP-3CT-400
DSP-3CT
Specification
Model
Order
CT Ratio
Dimension
Burden(VA)
Class
1.0, 3.0
3CT ithDSP
Specification
DSP-3CT
Model
CT Ratio
100 :5A
150 :5A
200 :5A
300 :5A
400 :5A
Class
Burden(VA)
Maximum Voltage
Withstand Voltage
Cable Length(Max)
Installation
Frequency
Accuracy
•These CT has to combine with DSP product only.
Dimension
Order
Item
3CT
CT Ratio
100 : 5
Reference Code
DSP-3CT-100
DSP-3CT-150
DSP-3CT-200
DSP-3CT-300
DSP-3CT-400
150 : 5
200 : 5
300 : 5
400 : 5
Current Transfomer

Samwha DSP•17
DSP-ZCT
DSP-ZCT
R30
60
25
Ă30
80
90
6
30
12
15
Ă35
Ă55
7
26 2
20
30
40
80
6
90
30
19.4
B
B
A
A
100
110
6
30
60
19.4
2
45
102.5
Ă50
R41.5
8.3
Ă50
21
25
30
A
A
130
120
6
30
R2
70
19.4
Ă80
R60
26
63.5
140
2
30
Ă80
21
2.5
A
A
(30~80)
Specification
30
50
80
120
200mA
1.5mA
100
250
600
1000
-25。C ~ +70。C
-35。C ~ +80。C
AC 2000V, 1min
DC 500V,
10MOhm
50/60Hz
10%
Screw Fix
170
215
345
700
Order Form
Item
Reference
Code
Inner
Diameter
(mm)
ZCT
30
50
80
120
DSP-ZCT-30N
DSP-ZCT-50N
DSP-ZCT-80N
DSP-ZCT-120N
80
50
30
ZeroPhase CurrentTransformer
Inner Diameter
Z.P.PrimaryCurrent
Z.P.SecondaryCurrent
Primary Current
Operating Temperature
Storage Temperature
High Potential Test
Insulation Resistance
Operating Frequency
Error Tolerance
Installation
Weight

18
New Leader! Motor Protection Relay
Digital Motor Protection Relay
전자식 모터보호 계전기
DIGITAL STANDARD PROTECTION
“모터보호 계전기의 New Leader”
·운영 효율성 향상 ·설비 가동률 향상 ·예지 예방 보전 향상
DIGITAL STANDARD PROTECTION
삼화DSP : 경기도 군포시 엘에스로 91번길 69(금정동 693-2 청산빌딩 3층)
TEL : [phone] / FAX : [phone]
대구지사 : 대구광역시 북구 유통단지로 16, 18동 9~10호(산격동, 유통단지 산업용재관)
TEL : [phone] / FAX : [phone]
www.samwhadsp.com / E-mail : [email protected]
DSP-ZCT
DSP-ZCT
(Zero Phase Current Transformer)
(120)
ZeroPhase CurrentTransformer

New Leader! Motor Protection Relay
Digital Motor Protection Relay
전자식 모터보호 계전기
DIGITAL STANDARD PROTECTION
DIGITAL STANDARD PROTECTION
삼화DSP : 경기도 군포시 엘에스로 91번길 69(금정동 693-2 청산빌딩 3층)
TEL : [phone] / FAX : [phone]
대구지사 : 대구광역시 북구 유통단지로 16, 18동 9~10호(산격동, 유통단지 산업용재관)
TEL : [phone] / FAX : [phone]
www.samwhadsp.com / E-mail : [email protected]
Optimized Preventive Maintenance Solution!!
New Leader! Motor Protection Relay
Digital Motor Protection Relay
전자식 모터보호 계전기
DIGITAL STANDARD PROTECTION
DIGITAL STANDARD PROTECTION
삼화DSP : 경기도 군포시 엘에스로 91번길 69(금정동 693-2 청산빌딩 3층)
TEL : [phone] / FAX : [phone]
대구지사 : 대구광역시 북구 유통단지로 16, 18동 9~10호(산격동, 유통단지 산업용재관)
TEL : [phone] / FAX : [phone]
www.samwhadsp.com / E-mail : [email protected]
HEAD OFFICE : 69, LS-ro 91beon-gil, Gunpo-si, Gyeonggi-do
Tel : [phone] Fax : [phone]
DAEGU OFFICE : 18dong 9ho, 16, Yutongdanji-ro, Buk-gu, Daegu
Tel : [phone] Fax : [phone]
Homepage : samwhadsp.com E-mail : [email protected]
"NewLeader !!"
