Sanav ML-7 User manual
The operation guide of ML-7
This is a guide to instruct the user to use ML-7 properly. You can find the information
to define every parameter of ML-7 at the following chapters. If you still have any
questions, please send your valua le comments to sanav@sanav.com. We shall
reply you in the soonest time.
1. Appearance
2. Package Contents
- ML-7 device
- AP data ca le
- Power Adapter
- A CD disk with user guide and utility
3. Introduction
ML-7 is the smallest GPS data logger in the world! With small in size, light in weigh
and mini to hidden, ML-7 is the most suita le GPS data logger for you to apply the
GPS logger to difference applications such as dove tracking, photo management,
sport tracking and vehicle tracking. It will definitely e your est helper on your
journey.
4. eatures
-51 independent tracking channels
-Ultra small size
-16M flash memory
- The data will e just logged only when the GPS is fixed
5. Applications
LED Light Status
Blue Red Orange
AP and Battery charge
Light
Power Light Low Power Light
6. Specifications
General Descriptions Parameters
requency L1 frequency; 1575.42MHz support 51 independent
tracking channels
Sensitivity -146dBm
Update Rate 1Hz
Acquisition
Cold Start: 36 sec.
Warm Start: 33 sec.
Hot Start: 1 sec.
Reacquisition <1 sec.
Dynamics
Altitude: 18000m (max.)
Velocity: 515 m/sec. (max.)
Vi ration: 4G (max.)
Supply Voltage DC 5V
Power Consumption
Data Record Mode <60mA
Power Saving Mode<0.5mA
Tracking: 30mA
NMEA Message
NMEA0183, default 115200
Output:GGA,GSA,GSV,RMC
Log: RMC
Datum Default WGS-84
Serial Interface T[email protected]
Weight 12.4g
Dimension 46.9mm(L) x 18.1mm(W) x 14.9mm(H)
Battery Include 170mA
Battery Life 5-6 Hours
Operating Temperature 0~550C
Storage Temperature 0~550C
Operating Humidity <= 95%, non condensing
Accessories USB to RS232 ca le charger
8. The instruction of AP utility
a. Download the AP utility from CD disk and install the AP to your computer.
! Please note the install password is “demover”.
! Please install the USB driver efore operating the AP utility.
b. When the AP is installed, make the connector etween the ML-7 and computer.
c. To download the file
C.1. Below is the window that shows the data has een downloading.
Choose the Comm. Port
that the computer detects.
Press the Port to select the communication
Press this utton to download
the data that has een logged
This ar shows how much percentage of data has een downloaded.
The downloaded data
The data is completely
downloaded
d. Log Setting
PS: The data downloaded will e fixed data only
If you would like to erase the data,
please choose “Yes”; otherwise,
please choose “No”
Choose the log setting to define
the interval of logged data
You are a le to define the interval
of the logged y the num er
etween 1-999 seconds
This window represents that the
setting is defined successfully.
e. To erase the data.
Choose “Erase” to erase the logged data
If you would like to erase the data,
please choose “Yes”; otherwise,
please choose “No”
f. Connect to Google Earth Map
The traces will e shown on Google Map
Choose “Google Earth” to link to Google
Earth Map.
Choose a .nme file and the
utility will automatically to link
the file to Google Earth. The
route should e C:\nme\....
You can also download the free
software from Locr. Please refer
to the we site link as elow:
http://www.locr.com to locate
your digital photos and other
applications.
Locr Demo:
The demo window will e like following:
-Locate the point.
-Locate your digital photos.
g. To check the version of the utility.
Choose “A out” to check the version of utility.
Click Google Earth to download
the Google Earth map.
The version of utility
Press OK to exit this window
8. Mechanical
