Sandstrom S4SSFF12 User manual

Instruction Manual
Fridge Freezer
S4SSFF12

Contents
Unpacking..................................................................................................................................... 4
Installation .................................................................................................................................... 5
Location .......................................................................................................................................................................5
Spacers .........................................................................................................................................................................5
Cupboard.....................................................................................................................................................................5
Fridge Freezer ............................................................................................................................................................5
Wall ................................................................................................................................................................................5
Cupboard.....................................................................................................................................................................5
Location .......................................................................................................................................................................6
Levelling the Unit .....................................................................................................................................................7
Cleaning Before Use ................................................................................................................................................7
Before Using Your Unit............................................................................................................................................7
Interior Accessories..................................................................................................................................................7
Product Overview......................................................................................................................... 8
Display and Control Panel .....................................................................................................................................9
Operation .................................................................................................................................... 10
Temperature Setting ............................................................................................................................................10
Super Freezing........................................................................................................................................................10
Beverage Cooling (Q. Drink) .............................................................................................................................. 11
Economic (ECO) Mode......................................................................................................................................... 11
Holiday Mode..........................................................................................................................................................11
Door Handle Lights On / O..............................................................................................................................12
Night sensor ............................................................................................................................................................12
Child Lock.................................................................................................................................................................12
Screen Saver............................................................................................................................................................ 12
Alarm..........................................................................................................................................................................12
Noises Inside the Unit!.........................................................................................................................................13
Shopping for Chilled Foods ...............................................................................................................................13
Tips for Keeping Food in the Unit....................................................................................................................13
Shopping for Frozen Foods ............................................................................................................................... 13
Preparations for Freezing....................................................................................................................................14
Defrosting Frozen Food.......................................................................................................................................14
In Case of Power Failure ...................................................................................................................................... 14
Cleaning ...................................................................................................................................... 15
Defrosting ................................................................................................................................................................15
Cleaning the Interior and the Exterior of the Unit.....................................................................................15
Cleaning Tips...........................................................................................................................................................15
Maintenance ............................................................................................................................... 16
Care when Handling / Moving the Unit ........................................................................................................ 16
Servicing...................................................................................................................................................................16
Switching O for Long Periods of Time.........................................................................................................16
Disposal....................................................................................................................................... 16
Helpful Tips and Guide............................................................................................................... 17
Fault Code ................................................................................................................................................................17
Fault nding ............................................................................................................................................................18
Fault nding (cont)................................................................................................................................................19
Specications.............................................................................................................................. 19
Safety Warnings.......................................................................................................................... 20

4
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to
local regulations.
The following items are included:
Adjustable Glass Shelf x 3
Salad Bin x 1 left
Salad Bin x 1 right
Upper Freezer Drawer x 2
Egg Tray x 2
The Fridge
Freezer
Fridge Door Shelf x 8
Cheese-Butter Shelf
Cover x 2
Salad Bin Cover x 1
Freezer Drawer Cover x 2
Door Railing x 2
Lower Freezer Drawer x 2
Ice Tray x 2
Fresh Food Drawer x 1
Spacer x 2 Instruction Manual
Thank you for purchasing your new Sandstrøm Fridge Freezer.
You must spend some time reading this instruction manual in order that you fully
understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction manual for
future reference.
If items are missing, or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.
Instruction Manual
Fridge Freezer
S4SSFF12
* All images are for indication only; please refer to your individual unit for actual item.

INSTALLATION
5
Location
When selecting a position for your unit you should make sure the floor is a flat and firm surface. Do
not stand your unit on carpet or rugs, which may obstruct the air flow around the unit. The room must
be well ventilated with an average room temperature of between 16°C and 43°C. Avoid locating your
unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the
electrical consumption. Extreme cold ambient temperatures may also cause the unit not to perform
properly. This unit is not designed for use in a garage or outdoor installation. Do not drape the unit
with any covering.
When installing the unit, ensure that 20 mm of free space is left at both sides, 30 mm at the rear of the
unit and 150mm above.
Spacers
To make sure you have the correct amount of
space between your fridge freezer and the
wall attach the two spaces to the black grill
on the back of your fridge freezer.
Slide the spacers between the grill and then
turn them 90oto lock them in position.
Be careful not to damage the grill.
Slide the unit towards the wall until the
spacer just touches the wall.
20mm 20mm
30mm
480mm
1162mm
1550mm
Wall
Fridge Freezer
CupboardCupboard
Installation

INSTALLATION
6
Always ensure that the hinged frame on the left side fridge door is facing inwards when
closing the door, otherwise the door will not close properly.
20mm
150mm
Location
When installing the unit, ensure that 150mm of free space is left at the top of the fridge freezer.

INSTALLATION
7
Levelling the Unit
To do this use the two levelling feet at the front of the unit.
If the unit is not level, the magnetic door seals will not align
correctly.
Cleaning Before Use
Wipe the inside of the unit with a weak solution of Bicarbonate of soda. Then rinse with warm water
using a ‘damp’ sponge or cloth. Wipe completely dry before replacing the shelves, drawers and salad
bins. Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working
properly and to allow it time to fall to the correct temperature. Your unit should not be overfilled.
Interior Accessories
Various glass or plastic storage shelves are included with your appliance – different models have
different combinations.
You should always slide one of the full size glass storage shelves into the lowest set of guides, above
fresh food drawer, and keep it in this position. Support the shelf underneath, lift and bring forwards, to
change shelf positions place a shelf into the fridge and ensure the rear corners are on the supports and
lower the front on the front supports.
For the lowest shelf, lower the shelf into position on the lower runner and slide into place.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the unit and
easily accessible or an easily accessible switch incorporated in the fixed wiring.
• Before Turning On!
Do not turn on until three hours after moving the unit. The coolant fluid needs time to settle.
In order to make the most of the volume of the fresh food storage compartment and frozen-food
storage compartment, the user can remove one or more shelves, or drawers, out of the appliance,
according to daily use.

8
Product Overview
Egg Tray
Ice Tray
Cheese-Butter
Shelf Cover
Adjustable Shelves
Cheese-Butter
Shelf with Cover
Salad Bin Cover
Door Railing
Fresh Food
Drawer Cover
Salad Bins
Fresh Food Drawer
Upper Fridge
Door Shelves
Ice Trays
Freezer Drawer
Cover
Upper Freezer
Drawer
Lower Freezer
Drawer
Upper Freezer
Drawer
Lower Freezer
Drawer
Levelling Feet
Freezer Drawer
Cover
Night Sensor
Egg Tray
Internal Light
* All images are for indication only; please refer to your individual unit for actual item.

9
20
19
18
17
16
15
8
9
10
11
12
Display and Control Panel
The display control panel is on the front of the left side fridge door. Please see below for the details:
1. Door Handle Lights On / Off Indicator
2. Night Sensor Indicator
3. Fridge Compartment Temperature Indicator
4. Super Cooling Indicator
5. Left Freezer (Zone 1) Compartment Temperature Indicator
6. Super Freezing Indicator
7. Right Freezer (Zone 2) Compartment Temperature Indicator
8. Child Lock Indicator
9. Low Voltage Warning Indicator
10. Alarm Indicator
11. Screen Saver (s. saver) Control
12. Right Freezer (zone 2) Compartment Control
13. Left Freezer (zone 1) Compartment Control
14. Beverage Cooling (q. drink) Control
15. Cooler Control
16. Mode Control
17. Holiday Mode Indicator
18. Economy Mode Indicator
19. Beverage Cooling (Q. Drink) Indicator
20. Beverage Cooling (Q. Drink) Alarm Counter
1 43 65 72
14 13

10
Operation
Temperature Setting
Fridge Compartment Temperature Setting
• Touch the cooler control repeatedly to adjust the fridge temperature between 2°C to 8°C and SC.
Freezer Compartment Temperature Setting
• As a Freezer Mode
Touch the zone 1 (left freezer compartment) or zone 2 (right freezer compartment) control repeatedly
to adjust the freezer compartment temperature between -16°C to –24°C and SF.
• As a Cooler Mode
1. Touch and hold the zone 1 (left freezer compartment) or zone 2 (right freezer compartment)
control for 3 seconds to switch to cooler mode. The temperature will be automatically set to 8°C.
2. Touch the zone 1 (left freezer compartment) or zone 2 (right freezer compartment) control
repeatedly to adjust the freezer compartment temperature between 2°C to 8°C.
• If the temperature in the fridge storage compartment is too low, the super cooling function may
not work.
• The super cooling function will automatically deactivate after 4 to 6 hours.
• In Super Cooling mode, more energy will be consumed.
• If Zone 2 is set to Cooler mode or to SF, Super Cooling will not be available.
Super Cooling
Touch the cooler control repeatedly until the temperature display shows SC and the “sc” indicator
illuminates. This function will automatically deactivate when the fridge storage compartment temperature
decreases to 2°C.
• The temperature shown on the display is the temperature you have set the fridge/freezer to get to.
NOT the actual temperature inside the fridge/freezer.
• It may take a few hours (approx. 5 hours) for the unit to reach the target temperatures. The time to
reach the set temperatures will vary depending on the temperature difference and the type and
amount of food stored in the compartments.
• Please note the Ice Trays are in Zone 2. Any ice in these trays will melt if set to cooler mode.
• Make sure you don’t have any frozen food in zone 1 or 2 if you are activating the cooler mode, or
remove any food you do not want freezing if setting to Freezer mode.
• If setting from Freezer to Cooler mode, leave the door open for 4 hours to allow the temperature to
rise.
• If only one zone is to be set as Freezer, then use Zone 1.
• Do not use Zone 2 in cooler mode at ambient temperatures over 38°C.
Super Freezing
Touch the zone 1 (left freezer compartment) or zone 2 (right freezer compartment) control repeatedly
until the temperature display shows SF and the “sf” indicator illuminates. This function will automatically
deactivate when the freezer storage compartment temperature decreases to -32°C.
