Sandstrom S60GW12 User manual

Instruction Manual
Frost Free Fridge Freezer
S60GW12

Contents
Unpacking..................................................................................................................................... 4
Location .......................................................................................................................................................................5
Reversing the Door Swing.....................................................................................................................................5
Levelling the Unit .....................................................................................................................................................7
Cleaning Before Use ................................................................................................................................................7
Before Using Your Unit............................................................................................................................................7
Interior Accessories..................................................................................................................................................7
Product Overview......................................................................................................................... 8
Display and Control Panel .....................................................................................................................................9
Operation .................................................................................................................................... 10
Temperature Setting ............................................................................................................................................10
Super Cooling .........................................................................................................................................................10
Alarm..........................................................................................................................................................................10
Noises Inside the Unit!.........................................................................................................................................11
Shopping for Chilled Foods ...............................................................................................................................11
Tips for Keeping Food in the Unit....................................................................................................................11
Shopping for Frozen Foods ............................................................................................................................... 11
Preparations for Freezing....................................................................................................................................12
Defrosting Frozen Food....................................................................................................................................... 12
Cleaning ...................................................................................................................................... 13
Defrosting ................................................................................................................................................................13
Cleaning the Interior and the Exterior of the Unit.....................................................................................13
Cleaning Tips...........................................................................................................................................................13
Maintenance ............................................................................................................................... 14
Changing the Internal Light ..............................................................................................................................14
Care When Handling / Moving the Unit........................................................................................................ 14
Servicing...................................................................................................................................................................14
Switching O for Long Periods of Time.........................................................................................................14
Disposal....................................................................................................................................... 14
Specications.............................................................................................................................. 15
Safety Warnings.......................................................................................................................... 16

4
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to
local regulations.
The following items are included:
Salad Bin Cover x 1
P.N.: 3001438700
Salad Bin x 1
P.N.: 3011197500
Large Freezer Drawer x 1
P.N.: 3011198000
Adjustable Glass Shelf x 3
P.N.: 3017851900
The Main Unit
Bottle Shelf x 1
P.N.: 3019055900
Egg Tray x 1
P.N.: 3011190800
Small Fridge Door Shelf x 1
P.N.: 3019056100
Large Fridge Door Shelf x 1
P.N.: 3019055800
Small Freezer Drawer x 2
P.N.: 3011197900
Ice Tray x 1
P.N.: 3010564910
Middle Fridge Door Shelf x 1
P.N.: 3019059700
Instruction Manual
P.N.: 3013912310
Thank you for purchasing your new Sandstrøm Fridge Freezer.
We recommend that you spend some time reading this instruction manual so that you fully
understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this instruction manual for
future reference.
If items are missing or damaged please contact Partmaster (UK only).
Tel: [phone] for assistance.

INSTALLATION
5
Location
When selecting a position for your unit you should make sure the floor is flat and firm, and the room
is well ventilated with an average room temperature of between 10°C and 43°C. Avoid locating your
unit near a heat source, e.g. cooker, boiler or radiator. Also avoid direct sunlight as it may increase the
electrical consumption. Extreme cold ambient temperatures may also cause the unit not to perform
properly. This unit is not designed for use in a garage or outdoor installation. Do not drape the unit
with any covering.
When installing the unit, ensure that 50 mm of free space is left at both sides, 50 mm at the rear and
50 mm at the top of the unit. The door can be opened to the right or the left, depending on what
better suits the location. Please ensure there is adequate space for the door to fully open.
• If you want to have the door swing reversed, we recommend that you contact a qualified
technician. You should only try to reverse the door yourself if you believe that you are qualified
to do so.
• All parts removed must be saved to do the reinstallation of the door. You should rest the unit
on something solid so that it will not slip during the door change process. Do not lay the unit
flat as this may damage the coolant system. Ensure the unit is unplugged and empty.
Reversing the Door Swing
The door of this unit can be reversed. However, due to electrical components, it is highly recommended
that you contact a suitably qualified technician. If you decide to reverse the door yourself, please follow
the steps below and take care to note the warnings.
The door of this unit can be reversed. However, due to electrical components, it is highly
recommended that you contact a suitably qualified technician.
• Before Reversing the Door
Disconnect the power from the mains.
• Be Careful with Electrical Connections
Be careful when unplugging and refitting electrical connections.
• Moving the Unit
2 people are required to move this unit.

INSTALLATION
6
When replacing the top hinge cover, use the available fixing screw holes
(these may not be in the same locations as the right hand side).
1. Remove the top hinge cover, carefully disconnecting the wiring harness, then remove the top
hinge (1). Carefully remove the fridge door and place it on a padded surface to avoid scratching or
damage.
2. Remove the middle hinge (2). Carefully remove the freezer door.
3. Remove the bracket cover (4), then remove the bottom hinge (3).
4. Reverse the position of the bushing cover of the fridge door (6):
From the top of the fridge door, unscrew and remove the harness cover, then remove the left door
harness. Secure the right hand harness within the door and assemble the harness cover.
5. Reverse the position of the bushing cover of the freezer door (8):
6. Reverse the position of the door switch by swapping it with the blanking plate (5):
Unscrew the door switch cam and move it to the left hand side. Assemble the bracket on the left.
7. Reverse the position of the fridge door stopper (7) and freezer door stopper (9).
8. Attach the freezer door to the unit.
9. Fix the middle hinge (2) on the new side. Attach the fridge door to the unit. Do not drop the door.
10. Fix the top hinge to the door and connect the wires for the door switch (1) and wire harness.
11. Connect the door switch wire housing. Assemble the door switch on the new side.
12. Fix the bracket cover (4) to the unit.
1
2
3
4
5
6
8
7
9
1 Top hinge cover,
screws & top hinge
2 Middle hinge, screws
& plug
3 Lower hinge & screws
4 Bracket cover
5 Door switch cam &
screw
6 Fridge door bushing
cover
7 Fridge Door stopper
8 Freezer door bushing
cover
9 Freezer door stopper
* All images are for indication only; please refer to your individual unit for actual item.

INSTALLATION
7
Cleaning Before Use
Wipe the inside of the unit with a weak solution of bicarbonate soda. Then rinse with warm water using
a ‘wrung-out’ sponge or cloth. Wipe completely dry before replacing the shelves, drawers and salad
bins. Clean the exterior of the unit with a damp cloth.
If you require more information refer to the Cleaning section.
Levelling the Unit
To ensure the unit is level, adjust the two levelling feet at the
front of the unit.
If the unit is not level, the doors and magnetic seal will not align
properly.
In order to make the most of the volume of the fresh food storage compartment and frozen-food
storage compartment, the user can remove one or more shelves, or drawers, out of the appliance,
according to daily use.
• Before Plugging in YOU MUST
Check that you have a socket which is compatible with the plug supplied with the unit.
• Before Turning On!
Do not turn on until six hours after moving the unit. The coolant fluid needs time to settle.
Before Using Your Unit
Before placing any food in your unit, turn it on and wait for 24 hours, to make sure it is working
properly and to allow it time to fall to the correct temperature. Your unit should not be overfilled.
Interior Accessories
Various glass or plastic storage shelves are included with your appliance – different models have
different combinations.
You should always slide one of the full size glass storage shelves into the lowest set of guides, above
the fruit and vegetable containers, and keep it in this position. To do this, pull the storage shelf forward
until it can be swivelled upwards or downwards and remove.
Please do the same in reverse to insert the shelf at a different height.

8
Product Overview
Egg Tray Ice Tray
Adjustable Glass
Shelves
Salad Bin Cover
LED Light (built into
the back of the unit)
Small Fridge Flap
Door Shelf
Middle Fridge
Door Shelf (model
variation)
Bottle Fridge Door
Shelf
Large Fridge Door
Shelf
Large Freezer
Drawer
Salad Bin
Small Freezer
Drawers
Levelling Feet

9
1
2
3
4
Display and Control Panel
The control panel is located at the front of the fridge. Please see below for the details:
It may take a few hours (approx. 5 hours) for the unit to reach the target temperatures. The time
to reach the set temperatures will vary depending on the ambient temperature and the type and
amount of food stored in the compartments.
1. Temperature Display
Displays the current setting between
MIN to MAX.
2. S-COOL Indicator
Displays the S-COOL function is activate.
3. TEMP Button
Selects among the different
temperatures.
4. S-COOL Button
Lower the fridge freezer temperature to
the required level.
*Usual S-COOL or Fast-Freeze is used
when a fresh food load is installed.

10
Super Cooling
• Press the S-COOL button, the indicator will light up, press the S-COOL button again to cancel.
• This function will automatically deactivate when the fridge storage temperature decreases to the
required level.
Alarm
Door Opening Alarm
The buzzer will sound when the fridge door is left open for over 1 minute. If the fridge door is left open,
the buzzer will sound every 1 minute for 5 minutes. After 10 minutes, the unit will turn off the internal
light. The alarm and light will reset once the door has been closed.
Operation
Temperature Setting
1. Connect the mains cable to the mains socket. The
internal temperature of your unit is controlled by a
control panel at the front of the fridge. There are five
settings, of which position MAX is the coldest and
position MIN is the warmest.
2. Press the TEMP button repeatedly to select “NORMAL”,
“HIGH NORMAL”, “MAX”, “MIN” or “LOW NORMAL”
MIN Low
Normal
Normal High
Normal
MAX
Normal
(3°C)
High Normal
(1°C)
Max
(–1°C)
Min
(5°C)
Low Normal
(4°C)
The setting will be automatically confirmed after 5
seconds.
