Sansui FHDBDP3209 User manual

32” TFT LCD DIGITAL TV WITH BD PLAYER
OWNER’S MANUAL
ATTENTION
If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the
required programming code.
AIR/CABLE MODE SELECTION
When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode.
If not using Cable TV, set this menu option to the “Air” position.
Before operating the unit, please read this manual thoroughly.
FHDBDP3209
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL
CUSTOMER SERVICE – 1-800-289-0980
ORION WEBSITE
FOR INFORMATION ON OUR OTHER PRODUCTS, PLEASE VISIT OUR WEBSITE AT
www.orionsalesinc.com
ENGLISH
Record the model number and serial number. The numbers are located at the rear of the unit.
Model number _______________ Serial number _______________
53C0221A_EN.indd 153C0221A_EN.indd 1 9/2/09 3:10:57 PM9/2/09 3:10:57 PM

2
CAUTION:
THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE
READ THIS OWNER'S MANUAL CAREFULLY AND RETAIN
FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE
MAINTENANCE, CONTACT AN AUTHORIZED SERVICE
LOCATION-SEE SERVICE PROCEDURE.
USE OF CONTROLS, ADJUSTMENTS OR THE
PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO THE LASER BEAM,
DO NOT TRY TO OPEN THE ENCLOSURE. RADIATION MAY
BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO
NOT STARE INTO THE BEAM.
Location of the required Marking
The rating sheet and the safety caution are
on the rear of the unit.
CERTIFICATION: COMPLIES WITH FDA
RADIATION PERFORMANCE STANDARDS, 21
CFR SUBCHAPTER J.
Complies with FDA performance standards
for laser products except for deviations
pursuant to Laser Notice No. 50, dated
June 24, 2007.
The lightning flash with arrowhead
symbol, within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES AWAY
FROM THIS PRODUCT AT TIMES.
CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE THIS POLARIZED PLUG WITH AN EX-
TENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE.
The lamp(s) within this product contain mercury.
Disposal should be in compliance with local, state or federal laws.
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful
interference in a residential installation.This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the partly responsible for compliance with the FCC Rules
could void the user’s authority to operate this equipment.
ENGLISH
CLASS 1
LASER PRODUCT
This Sansui LCD TV/Blu-ray Combo is in part operated by the Linux OS. The Linux OS contains software that
complies with GPL/LGPL. In order to obtain additional information and the source code please visit ORION’s
website at www.orionsalesinc.com/GPL.
53C0221A_EN.indd 253C0221A_EN.indd 2 9/2/09 3:10:59 PM9/2/09 3:10:59 PM

3
ENGLISH
15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such
as vases, should not be placed on the apparatus.
16) An outside antenna system should not be located in the vicinity of overhead power lines or
other electric light or power circuits, or where it can fall into such power lines or circuits. When
installing an outside antenna system, extreme care should be taken to keep from touching such
power lines or circuits, as contact with them might be fatal.
17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric
shock.
18) Do not push objects through any openings in this unit, as they may touch dangerous voltage
points or short out parts that could result in fire or electric shock. Never spill or spray any type of
liquid into the unit.
19) If an outside antenna or cable system is
connected to the unit, be sure the antenna or
cable system is grounded to provide some
protection against voltage surges and built-up
static charges, Section 810 of the National
Electrical Code, ANSI/NFPA 70, provides
information with respect to proper grounding of
the mast and supporting structure, grounding
of the lead-in wire to an antenna discharge
unit, size of grounding conductors, location
of antenna discharge unit, connection to
grounding electrodes, and requirements for the grounding electrode.
20) When replacement parts are required, be sure the service technician uses replacement parts
specified by the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21) Upon completion of any service or repairs to this unit, ask the service technician to perform
safety checks to determine that the unit is in proper operating condition.
22) Keep your fingers clear of the disc slot as it is closing. It may cause injury.
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA
LEAD IN WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC SERVICE
EQUIPMENT
NEC
-
NATIONAL
ELECTRICAL CODE
S2898A
EXAMPLE OF ANTENNA GROUNDING AS PER THE
NATIONAL ELECTRICAL CODE
53C0221A_EN.indd 353C0221A_EN.indd 3 9/2/09 3:11:00 PM9/2/09 3:11:00 PM

4
IMPORTANT SAFETY INSTRUCTIONS (continued)
23) When you connect the product to other equipment, turn off the power and unplug all of the equipment from
the wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's
manual of the other equipment carefully and follow the instructions when making any connections.
24) Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume
sound may cause hearing or speaker damage.
25) Do not allow the product to output distorted sound for an extended period of time. It may cause speaker
overheating and fire.
26) When you use the headphones, keep the volume at a moderate level. If you use the headphones
continuously with high volume sound, it may cause hearing damage.
27) Do not look into the opening of the disc slot or ventilation opening of the product to see the source of the
laser beam. It may cause eye damage.
28) Do not use a cracked, deformed, or repaired disc.These discs are easily broken and may cause serious
personal injury and product malfunction.
29) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the NEC
that provides guidelines for proper grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the point of cable entry as practical.
30) The socket-outlet must be installed near the unit and easily accessible.
CONDENSATION
Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm
room or if the temperature of the room rises suddenly. When this happens, player's performance will be impaired.
To prevent this, let the player stand in its new surroundings for about an hour before switching it on, or make sure
that the room temperature rises gradually.
Condensation may also form during the summer if the player is exposed to the breeze from an air conditioner. In
such cases, change the location of the player.
HOW TO HANDLE THE LCD PANEL
Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.
If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause
skin inflammation.
If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your
eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.
•
•
CHILD SAFETY:
It Makes A Difference How and Where You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:
THE ISSUE
The home theater entertainment experience is a growing trend and larger flat panel displays are popular
purchases. However, flat panel displays are not always supported on the proper stands or installed
according to the manufacturer’s recommendations.
Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers,
chests or carts may fall over and cause injury.
THIS MANUFACTURER CARES!
The consumer electronics industry is committed to making home entertainment enjoyable and safe.
TUNE INTO SAFETY
One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation and use of
your flat panel display.
Carefully read and understand all enclosed instructions for proper use of this product.
Don’t allow children to climb on or play with furniture and television sets.
Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers.
Remember that children can become excited while watching a program, especially on a “larger than life” flat
panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or
knocked down.
Care should be taken to route all cords and cables connected to the flat panel display so that they cannot be
pulled or grabbed by curious children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:
Use a mount that has been recommended by the display manufacturer and/or listed by an independent
laboratory (such as UL, CSA, ETL).
Follow all instructions supplied by the display and wall mount manufacturers.
If you have any doubts about your ability to safely install your flat panel display, contact your retailer about
professional installation.
Make sure that the wall where you are mounting the display is appropriate to support the weight of the unit/
product and wall mount. If you are unsure, contact a professional installer.
A minimum of two people are required for installation. Flat panel displays can be heavy.
53C0221A_EN.indd 453C0221A_EN.indd 4 9/2/09 3:11:00 PM9/2/09 3:11:00 PM

5
ENGLISH
VENTILATION CAUTION
The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause
overheating. Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When
placing on a shelf leave 10 cm (4 inches) free space around the entire unit.
Notes when mounting the LCD TV/BD on a wall
If the unit is to be mounted on the wall, contact the retailer where you purchased the LCD TV/BD for advice, and
have the equipment professionally installed. Incomplete or improper installation may cause injury to you, and/or
damage to the LCD TV/BD.
IMPORTANT NOTICE
Possible Adverse Effects on LCD Panel: If a fixed (non-moving) pattern remains on the LCD Panel for
long periods of time, the image can become permanently engrained in the LCD Panel and cause subtle but
permanent ghost images.This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your
LCD Panel on for long periods of time while it is displaying the following formats or images:
Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.
Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on
a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on a
widescreen (16:9) display (black bars on left and right sides of screen).
The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim
any responsibility for these symptoms.
LCD Panels are manufactured using an extremely high level of precision technology, however sometimes
parts of the screen may be missing picture elements or have luminous spots.
This is not a sign of a malfunction.
Do not install the LCD Panel near electronic equipment that is susceptible to electromagnetic waves. Some
equipment placed too near this unit may cause interference.
Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless
headphones.
•
•
•
•
•
SAFETY PRECAUTIONS
* is a trademark of DVD Format/Logo Licensing Corporation.
*Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
* Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762; 6,487,535 & other U.S.
and worldwide patents issued & pending. DTS and DTS 2.0 + Digital Out are registered trademarks and the DTS logos and
Symbol are trademarks of DTS, Inc. © 1996-2008 DTS, Inc. All Rights Reserved.
* HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
VC-1 Patent Portfolio License
THIS PRODUCT IS LICENSED UNDER THE VC-1 PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-
COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE VC-1 STANDARD (“VC-1
VIDEO”) AND/OR (ii) DECODE VC-1 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL
AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE
VC-1 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR OTHER USE. ADDITIONAL INFORMATION MAY
BE OBTAINED FROM MPEG LA, L.L.C. SEE <HTTP://WWW.MPEGLA.COM>.
AVC Patent Portfolio License
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-
COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN COMPLIANCE WITH THE AVC STANDARD (“AVC
VIDEO”) AND/OR (ii) DECODE AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND
NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC
VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR OTHER USE. ADDITIONAL INFORMATION MAY BE
OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM
FCC Declaration of Conformity Compliance Statement (Part 15):
The Sansui FHDBDP3209, LCD TV/BD Combination complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired operation.
The party responsible for compliance to these rules is:
ORION SALES, INC
15 Essex Rd., Paramus, NJ 07652
Ph: 1-800-289-0980
53C0221A_EN.indd 553C0221A_EN.indd 5 9/2/09 3:11:00 PM9/2/09 3:11:00 PM

6
Playable discs
Disc type and logo mark content
Blu-ray Video
Audio
+
Video
(moving
pictures)
DVD Video
Audio
+
Video
(moving
pictures)
CD-DA Audio
The following discs are also available.
DVD-R/RW discs of DVD video format.
CD-R/RW discs of MP3/WMA/JPEG.
•
•
Disc
CAUTION:
Only the left types of discs can be played on this
unit. DVD-ROM, CD-ROM, SVCD, CVD, VCD, etc.
cannot be played.
8cm discs can be played directly. If an 8cm disc
adapter is used it will cause errors.
If you insert an irregular shaped disc, it may get
stuck and cause a malfunction.
The use of a ring protector or other disc
accessories will cause errors.
This unit is to be used exclusively with the NTSC
color system. PAL and SECAM system discs cannot
be used with this unit.
Some CD-R/RWs and DVD-R/RW cannot be played
back depending on the recording conditions.
•
•
•
•
•
•
Region codes
Blu-ray Discs and DVDs have region codes to help prevent illegal distribution of discs. If the disc’s region code
does not match the unit’s. region code, the disc will not play.
The unit’s region code is displayed on the back of the unit. The disc’s region code is displayed on the disc or
disc packaging.
Title
When two or more movies are recorded on a disc, the disc
is divided into two or more sections. Each section is called
a “TITLE”.
Chapter
The titles can be subdivided into many sections.
Each section is called a “CHAPTER”.
Track
An Audio CD can contain several items.
These are assigned to the tracks.
Removing Disc from Case
Be sure to hold the edge of disc. Do not touch the surface of the disc.
Pick up the disc gently from the case.
Do not scratch the disc.
Do not get dirt on the surface of the disc.
Do not stick a label or adhesive tape on the disc.
Do not drop or bend the disc.
Storing Disc
Store the disc in the case to avoid risk of scratches, dirt or damage.
Do not leave disc exposed to direct sunlight or in hot or humid places.
Cleaning Disc
Wipe the disc with a clean, dry cloth from center to edge.
Do not wipe the disc in a circular motion.
Do not use liquid or aerosol cleaners.
•
•
•
•
•
•
•
•
CHAPTER 1
TITLE 1 TITLE 2
Blu-ray DISC
CHAPTER 2 CHAPTER 2 CHAPTER 3CHAPTER 1
TRACK 1 TRACK 2 TRACK 3 TRACK 4 TRACK 5
Audio - CD
53C0221A_EN.indd 653C0221A_EN.indd 6 9/2/09 3:11:01 PM9/2/09 3:11:01 PM

7
ENGLISH
How to attach the stand
Installing the stand
Tips
Unplug the AC cord from the AC INPUT jack.
Before beginning this process, make sure that you
lay the unit on a clean, safe, and cushioned surface
to avoid any damage to the unit.
Do not touch or press the TV screen. The glass
might break under pressure.
To install the stand:
1Place the unit face down on table, aligning the
bottom of the unit with the edge of the table.
Place a towel or similar material between the
screen and the table to protect the screen.
2Align the stand assembly with the metal bracket
on the bottom of the unit. The bracket will only fit in
one direction. Do not touch or apply pressure to the
screen. It may break.
3Place the base on the stand assembly. Make sure
that the symbol ▲is pointing toward the screen
side of the unit.
•
•
•
4Secure the bottom plate with the four provided
silver screws (M4×10mm)
Note:
To remove the stand, reverse these steps.•
53C0221A_EN.indd 753C0221A_EN.indd 7 9/2/09 3:11:01 PM9/2/09 3:11:01 PM

8
Contents
Before using your unit
IMPORTANT SAFETY INSTRUCTIONS...........3
SAFETY PRECAUTIONS .................................5
IMPORTANT NOTICE.......................................5
Disc...................................................................6
How to attach the stand ....................................7
Contents ...........................................................8
Location of controls...........................................9
Remote control ...............................................11
Power source ..................................................12
Antenna connections ......................................13
Cable TV connections.....................................14
TV operation
Starting setup .................................................15
TV operation ...................................................15
Quick guide for menu operation ......................16
Convenience functions ...................................17
Memorizing channels......................................18
Checking the digital-signal strength ................19
Labeling channels...........................................19
Labeling video inputs ......................................19
Setting the V-Chip ...........................................20
Closed Caption ...............................................21
CC advanced..................................................21
Setting the picture size....................................22
Blu-ray operation
Using the Blu-ray Disc player ..........................23
Using Media Launcher....................................23
Special playback.............................................24
Status display of disc ......................................24
Repeat playback .............................................24
Changing soundtrack language ......................24
Locating desired scene..................................... 25
Subtitles..........................................................25
Changing angles.............................................25
Using PIP (picture-in-picture) mode................25
MP3/WMA/JPEG and Audio CD playback ......25
Viewing JPEG files..........................................27
Quick guide for Setup Menu operation............27
Setup Menu options........................................28
Setting disc parental controls..........................29
Additional information
Connections to other equipment.....................30
Reception disturbances ..................................33
Problems and troubleshooting ........................34
Specifications .................................................36
53C0221A_EN.indd 853C0221A_EN.indd 8 9/2/09 3:11:04 PM9/2/09 3:11:04 PM

9
ENGLISH
Location of controls
Front
To display the menu screen.
Press MENU button to display the menu screen.
CHANNEL / buttons, VOLUME +/–buttons and INPUT/ENTER button can be used to select the desired
setting during the menu screen operations.
POWER button
INPUT/ENTER button
VOLUME +/– buttons
CHANNEL /1 (PLAY) button
MENU button
Remote sensor
EJECT button
Left side
CHANNEL /3(STOP) button
DISC slot
POWER indicator
Red : Standby
Blue : On
53C0221A_EN.indd 953C0221A_EN.indd 9 9/2/09 3:11:04 PM9/2/09 3:11:04 PM

10
Location of controls (continued)
Rear side
AC INPUT jack
HDMI 1/DVI IN jack
DVI AUDIO IN jack
VAR (VARIABLE)AUDIO OUT jacks
USB IN jack
ETHERNET IN jack
VIDEO2 IN jack
(VIDEO/ AUDIO (L/R))
RF (ANT)IN jack
DIGITAL AUDIO COAXIAL OUT jack
COMPONENT IN/AUDIO (L/R)IN jack
VIDEO1 IN jack
(VIDEO/S-VIDEO/ AUDIO (L/R))
HEADPHONE jack
HDMI2 IN jack
VGA IN jackVGA AUDIO IN jack
53C0221A_EN.indd 1053C0221A_EN.indd 10 9/2/09 3:11:05 PM9/2/09 3:11:05 PM

11
ENGLISH
Remote control
POWER Power On/Off
DISPLAY/– Call TV information
Call DVD information
Input “–” for digital channels
TV/BD Switch between TV/AV and Blu-ray
EJECT Eject a disc
0-9 Direct channel selection of TV
Input setting
Enter a password
INPUT Display source selection menu
MUTE Switch off the sound
CH /Select channel of TV
VOL +/– Adjust volume of TV
TV MENU Display menu of TV
SETUP Call up initial setup mode
▲▼◀▶ Cursor buttons
ENTER Enter information in the menu
EXIT Exit from On-Screen menu
POPUP MENU/
TITLE
In Blu-ray mode, press to open the top menu.
DISC MENU In Blu-ray mode, press to open the Blu-ray setup menu.
ANGLE Press to select an alternate viewing angle (if available) on a
Blu-ray Disc or DVD.
RANDOM In Audio CD mode, press to play songs in random order.
RETURN Press to exit the Blu-ray setup menus.
AUDIO Press to cycle through the languages available on a Blu-ray
Disc.
SUBTITLE Press to cycle through the available subtitle languages or a
Blu-ray Disc or DVD.
REPEAT Press to repeat the current title, chapter, track, or repeat all.
REPEAT A-B Press to repeat a specific portion of a Blu-ray Disc, DVD,
or CD.
SECONDARY
AUDIO
In PIP mode, press to turn the audio for the secondary video
on or off.
SECONDARY
SUBTITLE
In PIP mode, press to turn the subtitle for the secondary
video on or off.
PIP Press to turn PIP (picture-in-picture) mode on or off.
JUMP Locating desired scene
CCD Closed Caption
RECALL Switch between present/last channel
SLEEP Sleep timer
SCREEN SIZE Display SCREEN SIZE menu
STEP Press to advance one frame at a time on a Blu-ray Disc
or DVD. Press PLAY to resume normal playback.
SLOW Press to play forward slowly on a Blu-ray Disc or DVD.
SEARCH 8Press to fast-reverse on a Blu-ray Disc, DVD, or CD.
PLAY 1 Press to start playback on a Blu-ray Disc, DVD, or CD.
SEARCH 9Press to fast-forward on a Blu-ray Disc, DVD, or CD.
SKIP 6Press to go to the previous chapter on a Blu-ray Disc or
DVD or to the previous track on a CD.
PAUSE 4Press to pause playback on a Blu-ray Disc, DVD, or CD.
STOP 3Press to stop disc playback.
SKIP 7Press to go to the next chapter on a Blu-ray Disc or DVD
or to the next track on a CD.
(blue) (red) (green)
(yellow)
So Blu-ray Discs (those with Java™ ) are programmed
to use these buttons to access certain playback
features. If you insert a Java Blu-ray Disc, follow the
on-screen instructions or the documentation that
came with the disc.
53C0221A_EN.indd 1153C0221A_EN.indd 11 9/2/09 3:11:07 PM9/2/09 3:11:07 PM

12
Approximately 15 feet
Inserting Batteries
1Open the battery compartment
cover in the direction of the arrow. 2Install two “AA” batteries, paying
attention to the polarity diagram
in the battery compartment.
3Replace the compartment cover.
Operation
Aim the remote control at the remote sensor and press control
buttons to operate.
Operate the remote control within a 30° angle on either side of
the remote sensor, up to a distance of approximately 15 feet.
•
•
Remote control (continued)
NOTE:
Do not leave the remote control unit exposed to direct sunlight or in hot or humid places.
The remote control unit uses infrared beams to transmit signals, so sunlight or fluorescent light on the remote
sensor may shorten operating distance.
Incorrect use of batteries may cause them to leak or burst. Read the battery warnings and use the batteries
properly.
Do not mix old and new batteries.
Remove batteries if the remote control will not be operated for an extended period of time.
•
•
•
•
•
Power source
TO USE AC POWER
Connect the AC cord plug into this unit’s AC IN jack.
Connect the AC cord into an AC outlet.
1.
2.
AC cord (supplied)
AC 120V, 60Hz
AC Outlet
NOTE:
Please make sure to insert the cord securely at both the LCD TV/BD and the wall outlet.
The AC Cord has a grounding-type AC line plug. If the supplied AC cord does not match your AC outlet,
contact a qualified electrician, do not defeat the purpose of a grounding plug.
WARNING:
DO NOT CONNECT THIS UNIT TO THE POWER USING ANY DEVICE OTHER THAN THE SUPPLIED AC
CORD. THIS COULD CAUSE FIRE, ELECTRICAL SHOCK, OR DAMAGE.
DO NOT USE WITH A VOLTAGE OTHER THAN THE POWER VOLTAGE DISPLAYED. THIS COULD CAUSE
FIRE, ELECTRICAL SHOCK, OR DAMAGE.
CAUTION:
WHEN THIS UNIT IS NOT USED FOR A LONG TIME, (E.G., AWAY ON A TRIP) IN THE INTEREST OF
SAFETY, BE SURE TO UNPLUG IT FROM THE AC OUTLET.
DO NOT PLUG/UNPLUG THE PLUG WHEN YOUR HANDS ARE WET. THIS MAY CAUSE ELECTRICAL
SHOCK.
IF YOU NEED TO REPLACE THE SUPPLIED AC ADAPTER OR AC CORD, THE SPECIFIED ONE IS
RECOMMENDED. CONTACT THE DEALER THAT YOU PURCHASED THE UNIT FROM.
•
•
•
•
•
•
•
53C0221A_EN.indd 1253C0221A_EN.indd 12 9/2/09 3:11:08 PM9/2/09 3:11:08 PM

13
ENGLISH
Antenna connections
If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your
antenna system. If you are using a Cable TV service, see page 14 for Cable TV connections.
Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire)
Combination VHF/UHF Antenna (Separate VHF and UHF 300 ohm twin-lead wires)
Separate VHF/UHF Antennas (75 ohm VHF cable and 300 ohm UHF twin-lead wires)
Connect the 75 ohm cable from the combination
VHF/UHF antenna to the antenna jack.
If your combination VHF/UHF antenna has a 300
ohm twin-lead wire, the use of the 300-75 ohm
matching transformer may be necessary.
Connect the UHF 300 ohm twin-lead wire to
the Combiner (not supplied). Connect the VHF
300 ohm twin-lead wire to the 300-75 ohm
Matching Transformer. Attach the Transformer to
the Combiner, then attach the Combiner to the
Antenna Jack.
Connect the VHF 75 ohm cable and UHF 300 ohm
twin-leadwire tothe Combiner (not supplied). Attach
the Combiner to the Antenna Jack.
75 ohm
Coaxial
Cable
300-75 ohm
Matching
Transformer
Antenna
Jack
Antenna
Jack
300-75 ohm Matching Transformer
UHF 300 ohm
Antenna
Jack
Combiner
VHF 300 ohm
VHF 75 ohm
Antenna
Jack
Combiner
UHF 300 ohm
53C0221A_EN.indd 1353C0221A_EN.indd 13 9/2/09 3:11:08 PM9/2/09 3:11:08 PM

14
Cable TV connections
For basic Cable TV service not requiring a Converter/
Descrambler box, connect the 75 ohm Coaxial Cable directly
to the Antenna Jack on the back of the TV.
For subscribers to scrambled Cable TV service
If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect
the incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial
Cable, connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV. Follow the
connections shown below. Set the TV to the output channel of the Converter/Descrambler box (usually channel
3 or 4) and use the Converter/Descrambler box to select channels.
For subscribers to unscrambled Cable TV service with scrambled premium
channels
If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require
the use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available
from the Cable TV company or an electronics supply store). Follow the connections shown below. With the
switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the
“A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the
Converter/Descrambler box to tune scrambled channels.
This TV has an extended tuning range and can tune most cable channels without using a Cable TV
Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled.
Descrambling these signals for normal viewing requires the use of a descrambler device which is
generally provided by the Cable TV company.
For subscribers to basic Cable TV service
75 ohm
Coaxial Cable
Antenna
Jack
Incoming
75 ohm
Cable TV
Cable 75 ohm Cable to TV
Antenna
Jack
Converter/
Descrambler
Splitter B
A
Incoming
75 ohm
Cable TV
Cable A/B Switch 75 ohm Cable to TV
Converter/
Descrambler Antenna
Jack
53C0221A_EN.indd 1453C0221A_EN.indd 14 9/2/09 3:11:09 PM9/2/09 3:11:09 PM

15
ENGLISH
Starting setup
The Starting Setup menu appears the first time
you turn on the TV, and assists you to select the
menu language, specify the Air/Cable setting,
and program your channels automatically.
IMPORTANT: Make sure that the antenna or cable
TV system connection is made!
1To turn on the TV, press POWER (POWER
indicator on the front of the unit changes blue.
It may take approx. 10 seconds for a picture to
appear on screen.).The starting setup function
begins. Press ◀or ▶to select your desired
language.
Automatic Search Start
Auto Setup
Language English
Signal Type Cable
: Adjust
: Select
2Press ▲or ▼to select “Signal Type”, then press
◀or ▶to select “Cable” or “Air”.
3Press ▲or ▼to select “Automatic Search”, then
press ▶or ENTER.
4Now the “Auto Setup” starts. After the starting
setup is completed, the TV channel appears on
the screen.
•
Depending on the reception condition, it may
take from 15 minutes to 30 minutes to complete
memorizing digital cable channels. Please be
patient.
NOTE:
If you press EXIT in the process of “Auto Setup”,
the Starting Setup stops and changes to the normal
screen.
When you make a menu selection, your changes
occur immediately.You do not have to press EXIT to
see your changes.
When you are finished programming the menus,
press EXIT.
TV operation
1To turn on the TV, press POWER.
(POWER indicator on the front of the unit
changes blue. It may take approx. 10 seconds for
a picture to appear on screen.)
2Adjust the volume level by pressing VOL + or –.
The volume level will be indicated on the screen
by blue bars. As the volume level increases, so do
the number of bars. If the volume decreases, the
number of blue bars also decreases.
3Set the Signal Type option to the appropriate
position (see “Air/Cable selection” on page 18).
4Press the Direct Channel Selection (0-9, –)
buttons to select the channel.
(If you press only channel number, channel
selection will be delayed for a few seconds.)
•
•
•
TO SELECT ANALOG CHANNELS
1-9: Press 1-9 as needed. Example, to
select channel 2, press 2, then press
ENTER.
10-99: Press the 2 digits in order. Example,
to select channel 12, press 1, 2, then
press ENTER.
100-135: Press the 3 digits in order. Example, to
select channel 120, press 1, 2, 0, then
press ENTER.
TO SELECT DIGITAL CHANNELS
Press the first 3 digits, then press the –button,
followed by the remaining number.
Example, to select channel 015-001, press 0,1,
5,–, 0,0,1, then press ENTER.
If a channel is selected with only audio content,
“Audio only” will be displayed on the screen.
If a channel is selected with a weak digital
signal, “Digital channel signal strength is low”
will be displayed on the screen.
The same program may be available on either
an analog channel or a digital channel.You may
choose to watch either format.
If a channel is selected to which you have not
subscribed,
“Digital channel is encrypted” will
be displayed on the screen.
•
•
•
VHF/UHF/CABLE CHANNELS
Air Cable
VHF
2-13
VHF
2-13
UHF
14-69
STD/HRC/IRC
14-36 (A) (W)
37-59 (AA) (WW)
60-85 (AAA) (ZZZ)
86-94 (86) (94)
95-99 (A-5) (A-1)
100-135 (100) (135)
01 (4A)
NOTE:
If a channel with no broadcast is selected, the
sound will automatically be muted.
It may take a few seconds for a digital channel
picture to appear on screen after being selected.
To select the video input source
To view a signal from another device connected to
your LCD TV, such as a VCR player, press INPUT,
then press ▲/▼or corresponding Number buttons
(0-7), then press ENTER.You can select TV, Video 1,
Video 2, Component, HDMI1, HDMI2, PC or Blu-ray
depending on which input jacks you used to connect
your devices.
Source Selection
[0-7]:Select
0.TV
1.Video 1
2.Video 2
3.Component
4.HDMI 1
5.HDMI 2
6.PC
7.Blu-ray
CH +/ -
Press and release CH +/ - . The channel automatically
stops at the next channel set into memory.
For proper operation, before selecting channels, they
should be set into the memory. See “Memorizing
channels” on pages 18 and 19.
•
•
53C0221A_EN.indd 1553C0221A_EN.indd 15 9/2/09 3:11:09 PM9/2/09 3:11:09 PM

16
DISPLAY
Press DISPLAY to display the current information on
the screen.
When the TV receives a digital signal, the digital
information will appear.
62-001 HDTV Moving Picture1
CH-1 TV-14
Digital Air
No Program Information is available
Sleep Timer
Off
Wide
1080i
English
Channel number• Station name•
Channel label (if preset)•
Broadcast program name •
V-Chip rating• Signal type•
Sleep timer• Audio language•
Program guide• Picture size•
Resolution•
When the TV receives an analog signal, the analog
information will appear.
14
TV-PG
Analog Cable
Sleep Timer
Off
Mono
Wide
480i
Channel number• Channel label (if preset)•
V-Chip rating• Signal type•
Sleep timer• Picture size•
Audio information
(Stereo, SAP or Mono)
• Resolution
•
Press DISPLAY again to clear the call display.
NOTE:
After a few seconds, DISPLAY screen will return to
normal TV-operation automatically.
RECALL
This button allows you to go back to the last channel
selected by pressing RECALL. Press RECALL again to
return to the last channel you were watching.
MUTE
Press MUTE to switch off the sound. The TV’s sound
will be silenced and “Mute” will appear on the screen.
The sound can be switched back on by pressing this
button again or the VOL + or –.
SLEEP
To set the TV to turn off after a preset amount of time,
press SLEEP on the remote control. The clock will
count up 10 minutes for each press of the SLEEP
button (Off, 5m, 10m, 15m, 30m, 45m, 1h 0m, ..., 4h
0m). After the sleep time is programmed, the display
will appear briefly every ten minutes to remind you
that the sleep timer is operating. To confirm the sleep
timer setting, press SLEEP and the remaining time
will be displayed for a few seconds. To cancel the
sleep timer, press SLEEP repeatedly until the display
turns to Off.
•
Quick guide for menu
operation
Call menu and for example: Select Language.
1Press INPUT to select TV mode.
2Press TV MENU. The TV menu screen will
appear.
Audio
Channel
Lock
Setup
Main Menu
Picture >>
: Select ENTER:Set
3Press ▲or ▼to select “Setup”, then press ▶or
ENTER.
4Press ▲or ▼to select “Language”, then press
◀/▶to select the desired language.
…on the following pages the menu can be called
in the same way as here.
5Press EXIT to return to the normal screen.
NOTE:
If no buttons are pressed for more than about 40
seconds, the menu screen will return to normal
operation automatically.
•
53C0221A_EN.indd 1653C0221A_EN.indd 16 9/2/09 3:11:10 PM9/2/09 3:11:10 PM

17
ENGLISH
Convenience functions
You can change the default settings to convenience use.
Icon Selected Items Setup hint
Picture Picture
Setting
Brightness /
Contrast /
Sharpness /
Color / Tint
You can adjust the picture quality to your preference.
Color
Temperature
Bluish (Cool) / Neutral (Normal) / Reddish (Warm)
Backlight The Backlight feature adjusts the screen brightness for improved picture clarity.
DBC *1On/Off Use this feature to change the Back light automatically according to the
brightness of an image.The Back light will become bright in a bright
scene, and will become dark in a dark scene.
Preference
Vivid Bright and dynamic picture (factory-set)
Standard Standard picture quality (factory-set)
Theater Movie-like picture setting (factory-set)
Custom Your personal preferences (set by you; see “Picture Setting”)
Picture Size See page 22.
Film Mode On/Off A smoother motion may be obtained by setting the Film Mode to “On” when you
view a Blu-ray or DVD.
PC Setting Hor Position /
Ver Position
To adjust the horizontal / vertical position of the image on the PC Monitor
screen. Each video standard will require a different value for this setting.
Clock To minimize any vertical bars or stripes visible on the screen background.
Phase This must be adjusted after the frequency has been set optimize picture quality.
Auto Adjust To adjust the all PC settings automatically.
DNR On/Off DNR (Digital Noise Reduction) can reduce the roughness of the picture.
Audio Bass / Treble / Balance You can adjust the sound quality to your preference.
MTS Stereo / SAP /
Mono
The multi-channel TV sound (MTS) feature provides high-fidelity stereo sound.
MTS also can transmit a second audio program (SAP) containing a second
language or other audio information.
When the TV receives a stereo or SAP broadcast, the word “Stereo” or “SAP”
displays on-screen every time you press DISPLAY.
Surround On/Off The dynamic presence and sound created offers a thoroughly enjoyable
listening experience.
Audio Language When two or more audio languages are included in a digital signal, you can
select one of the audio language. (This function is available only for digital
broadcast.)
Digital Audio
Mode
RAW Select this option when
your unit is connected to a Dolby Digital amplifier.Your
unit outputs original Dolby sound.
PCM
Select this option when your unit is connected to a PCM amplifier.Your unit
converts Dolby sound to PCM sound automatically.
HDMI1 Audio HDMI When you connect the HDMI device to the TV, select this setting.
DVI When you connect the DVI device to the TV with analog audio cords, select this
setting.
Speakers On/Off Use this feature to turn the TV speakers off when you connect an audio system.
Channel Add / Delete See page 18.
DTV Signal See page 19.
Auto Ch Memory See page 18.
Ch Label See page 19.
Lock See page 20, 21.
Setup Closed Caption See page 21.
Language You can choose from three different languages (English, Français (French) and
Español (Spanish)) for the on-screen displays.
Select the language you prefer first, then proceed with the other menu options.
Video Label See page 19.
Auto Shut Off On/Off If the Auto Shut Off feature is On, a station being viewed stops broadcasting and
the TV is not operated, the TV will automatically shut itself off after 15 minutes.
Reset The Reset function returns your settings to the factory settings.
“Picture Size”, “MTS”, “Speakers”, “Audio Language” and “HDMI1 Audio” cannot
be reset by this function.
Note:
*1 In PC mode, the DBC option is not available.
53C0221A_EN.indd 1753C0221A_EN.indd 17 9/2/09 3:11:10 PM9/2/09 3:11:10 PM

18
Memorizing channels
This TV is equipped with a channel memory
feature which allows channels to skip up or down
to the next channel set into memory, skipping
over unwanted channels. Before selecting
channels, they must be programmed into the
TV’s memory. To use this TV with an antenna, set
the Signal Type option to the Air mode. When
shipped from the factory, this menu option is in
the Cable mode.
Air/Cable selection
1Select “Channel”, then press ▶or ENTER.
2Press ▲or ▼to select “Auto Ch Memory”, then
press ▶or ENTER.
3Press ▲or ▼to select “Signal Type”.
4Press ◀or ▶to select “Air” or “Cable”.
Air - VHF/UHF channels
Cable - CABLE TV channels
Automatic Search Start
Auto Ch Memory
Signal Type Cable
: Adjust
: Select
CABLE CHART
The chart below is typical of many cable system
channel allocations.
NOTE:
It may take a few seconds for a digital channel
picture to appear on screen after being selected.
Automatic search
1Select “Channel”, then press ▶or ENTER.
2Press ▲or ▼to select
“Auto Ch Memory”, then
press ▶or ENTER.
3Press ▲or ▼to select “Automatic Search”, then
press ▶or ENTER.
Auto Ch Memory
Signal Type Cable
Digital Channel Found : 5
Analog Channel Found : 7
Programming Now
: Select ENTER:Cancel
Automatic Search Stop
•
4The TV will begin memorizing all the channels
available in your area.
It may take from 15 minutes to 30 minutes to
complete memorizing digital cable channels.
Depending on the reception condition, a bar
display may not advance for several minutes,
please be patient.
•
NOTE:
Memorizing channels is best accomplished during
evening “PRIMETIME” hours, as more stations are
broadcasting digital signals. Memorizing channels can
only be accomplished while a station is broadcasting
a digital signal to set that channel into memory.
If you are unsure of the digital channels available
in your area, you may visit www.antennaweb.org to
receive a list based on your address or zip code.
Should you require further assistance you may call
our toll-free customer service line at 1-800-289-0980.
New digital channels may be added to your area
periodically, it is recommended to perform the
“Automatic Search” procedure regularly.
Adding Channel
If you find a new digital channel unregistered, you can
add the new channel into the channel memory.
1Tune in the new channel.
2Select “Channel”, then press ▶or ENTER.
3Press ▲or ▼to select “Add/Delete”, then press ▶
or ENTER.
Add/Delete >>
Clear All >>
Add/Delete
Adding Channel >>
: Select ENTER:Set
4Press ▲or ▼to select “Adding Channel”, then
press ▶or ENTER. The new channel will be
added into the channel memory.
Add/Delete channel
You can select the channel that you want to skip.
1Select “Channel”, then press ▶or ENTER.
2Press ▲or ▼to select “Add/Delete”, then press
▶or ENTER.
3Press ▲or ▼to select “Add/Delete”, then press
▶or ENTER.
4Press ▲or ▼to select the channel that you want
to skip.
CH Signal
2 Analog
3 Analog Add
3-001 Digital Delete
3-002 Digital Add
4 Analog Delete
Add/Delete
: Adjust
Add
: Select
5Press ◀or ▶to select “Add” or “Delete”,
whichever function you want to perform.
6Repeat steps 4 - 5 for other channels you want to
add or delete.
•
•
•
53C0221A_EN.indd 1853C0221A_EN.indd 18 9/2/09 3:11:10 PM9/2/09 3:11:10 PM

19
ENGLISH
Clear All
All channels are deleted from the channel memory.
1Select “Channel”, then press ▶or ENTER.
2Press ▲or ▼to select “Add/Delete”, then press ▶
or ENTER.
3Press ▲or ▼to select “Clear All”, then press ▶or
ENTER.
Add/Delete >>
Add/Delete
Adding Channel >>
: Select ENTER:Set
Clear All >>
Checking the digital-
signal strength
This TV will allow you to view the digital signal
meter for digital channels.
1Select “Channel”, then press ▶or ENTER.
2Press ▲or ▼to select “DTV Signal”.
3Press ▶or ENTER to check the Digital-signal
strength.
The Digital-Signal strength screen will appear.
If necessary, adjust the direction of the antenna to
obtain the maximum signal strength.
Signal Level
0 50 100
DTV Signal
NOTE:
Signal meter feature is not available for analog
channels.
After 240 seconds, DTV Signal screen will return to
normal TV-operation automatically.
•
•
Labeling channels
Channel label appear with the channel number
display each time you turn on the TV, select a
channel, or press DISPLAY.
You can choose any four characters to identify a
channel.
To create channel labels
1Select “Channel”, then press ▶or ENTER.
2Press ▲or ▼to select “Ch Label”, then press ▶
or ENTER.
The “Ch Label” menu will appear.
3Press ◀or ▶to select a channel you want to
label, then press ▼.
Ch Label
Label Clear >>
: Adjust
Ch Label
Channel Number 15-1
: Select
4Press ◀or ▶repeatedly until the character you
want appears in the first space.
Label Clear >>
: Adjust
Ch Label
Channel Number 15-1
: Select
Ch Label A
ENTER:Set
The characters rotation as follows:
SPACE
-
, () @ / + = -
If the character which you desire appears, press
ENTER.
Repeat this step to enter the rest of the characters.
If you would like a blank space in the label name,
you must choose the empty space from the list of
characters.
5When you finish inputting the label name, press
EXIT to return to the normal screen.
6Repeat steps 3-4 for other channel.You can
assign a label to each channel.
To clear a Ch Label
After step 3 above, press ▲or ▼to select “Label
Clear”, then press ▶or ENTER.
NOTE:
The channel labels will be reset after “Automatic
Search” on page 18.
Labeling video inputs
The Video Label feature allows you to label each
input source for your TV.
1Select “Setup”, then press ▶or ENTER.
2Press ▲or ▼to select “Video Label”, then press
▶or ENTER.
3Press ▲or ▼to select an input which you want to
label.
4Press ◀or ▶to select the desired label for that
input source.
Video2 -
Component -
HDMI1 -
HDMI2 -
Video Label
: Adjust
: Select
Video1 -
– : Uses the default label name
VCR : Video cassette recorder
DVD : DVD video
DTV : Digital TV set-top box
SAT : Satellite box
CABLE : Cable box
HD : HDMI device (only for HDMI inputs)
•
53C0221A_EN.indd 1953C0221A_EN.indd 19 9/2/09 3:11:11 PM9/2/09 3:11:11 PM

20
Setting the V-Chip
An age limitation can be set to restrict children from
viewing or hearing violent scenes or pictures that you
may choose to exclude. The restriction applies to “TV
Rating” and “Movie Rating” if this data is transmitted.
You may set this restriction separately. To use the
V-Chip function, you must register a password.
To register a password
1Select “Lock”, then press ▶or ENTER.
2Select and enter your password (4 digits) using
Number buttons (0-9), then press ENTER.
[0-9]
Lock
New Password * * *_
: Select ENTER:Set
“ ” appears instead of the number.
3Enter the same password again to confirm, then
press ENTER.
The password is now registered.
NOTE:
If you forget the password, contact Customer
Service at 1-800-289-0980 for assistance.
Your original remote control will be required.
To avoid forgetting the password, write it down and
keep in a safe place.
To set the V-Chip
1Select “Lock” menu, then press ▶or ENTER.
2Use Number buttons (0-9) to enter your
password, then press ENTER.Then Lock menu
will appear.
3Press ▲or ▼to select “V-Chip”, then press
◀or ▶to select “On” .
4Press ▲or ▼to select “V-Chip Set”, then press
▶or ENTER.
The V-Chip Set Menu appears.
5Press ▲or ▼to select which rating will be used,
then press ▶or ENTER. Each rating below will
appear.
TV Rating
ALL D L S V FV
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
ENTER:Set
TV Rating
: Select
You can set the rating using age level and genre.
Age:
TV-Y: All children
TV-Y7 : 7 years old and above
TV-G : General audience
TV-PG : Parental guidance
TV-14 : 14 years old and above
TV-MA : 17 years old and above
•
•
Genre:
ALL : All
D: Dialogue
L: Language
S: Sex
V: Violence
FV : Fantasy Violence
Movie Rating
G
PG
PG-13
R
NC-17
X
ENTER:Set
Movie Rating
: Select
G: All ages
PG : Parental guidance
PG-13 : Parental guidance
less than 13 years old
R: Under 17 years old parental guidance
suggested
NC-17 : 17 years old and above
X: Adult only
6Press ▲/▼/◀/▶to select the desired rating, then
press ENTER.
7
Press EXIT to return to the normal screen.
V-Chip function is activated now.
To use the TV after the TV is protected.
When a program is received that is blocked by the
V-Chip, press MUTE, then enter your password.
The protection will be temporarily overridden. If the
TV is turned off or the channel is changed, the V-Chip
restriction will be reactivated.
NOTE:
The V-Chip function is activated only on programs
and input sources that include a rating signal.
To change the password
1Select “Lock”, then press ▶or ENTER.
2
Use Number buttons (0-9) to enter your password,
then press ENTER. The Lock menu will appear.
3Press ▲or ▼to select “Change Password”, then
press ▶or ENTER.
The Change Password screen will appear.
4Enter a new password using Number buttons
(0-9), then press ENTER.
5Enter the same password again to confirm, then
press ENTER.
The password is now registered.
Downloading the additional V-Chip rating system
As a supplement to the standard V-Chip rating
system, your television will be able to download an
additional rating system, if such a system becomes
available in the future.
To download the additional V-Chip rating system
(when available)
1Select “Lock”, then press ▶or ENTER.
2
Use Number buttons (0-9) to enter your password,
then press ENTER.The Lock menu will appear.
•
53C0221A_EN.indd 2053C0221A_EN.indd 20 9/2/09 3:11:12 PM9/2/09 3:11:12 PM
