Sanyo Xacti VPC-C1EX User manual

INSTRUCTION MANUAL Digital Movie VPC-C1
Important note
This manual explains how to safely operate the VPC-C1EX and
VPC-C1. Any information regarding only one of these products will
be labeled as such.
Please read these instructions carefully before using the camera. Make
sure to read and understand the section “USING YOUR CAMERA
SAFELY AND CORRECTLY” on pages 7 to 24. Keep this manual in a
safe place for later reference.
INSTRUCTION MANUAL VPC-C1EX
VPC-C1
Digital Movie
Printed on recycled paper
1AG6P1P1704--
SX613/EX, U (1003KP-SY)
SANYO Electric Co., Ltd.
Printed in Japan
      !"#

iEnglish
Warning
TO PREVENT THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE
FOR AMERICAN USERS
eThis equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
dReorient or relocate the receiving antenna.
dIncrease the separation between the equipment and receiver.
dConnect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
dConsult the dealer or an experienced radio/TV technician for help.
eChanges or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
      !"#

English ii
Tested to Comply with FCC Standards
FOR HOME OR OFFICE USE
The FCC logo is included in the rating that can be found inside the battery case.
Declaration of Conformity
Model number : VPC-C1
Trade Name : SANYO
Responsible party: SANYO FISHER COMPANY
Address : 21605 Plummer Street, Chatsworth, California 91311
Telephone No. : [phone]
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
FOR CANADIAN USERS
eThis Class B digital apparatus complies with Canadian ICES-003.
Conformity to EC Directives
eThis unit complies with EC Directives 89/336/EEC
and 73/23/EEC.
eThe rating plate can be found inside the set after the
battery cover and battery are removed.
      !"#

1English
OUTLINE OF OPERATION
To help you get started enjoying using your camera right away, given below is
an outline of the fundamental operation, from setup to shooting to playback.
SETUP
(1) Connect the AC adapter/charger (page 128).
(2) Install the battery pack and SD Memory
Card*1in the camera (page 35, 36).
CAUTION
eThis camera uses an SD Memory Card
instead of photographic film to record
images. Be sure to install the SD Memory
Card before operating the camera. A 128MB
SD Memory Card is supplied with this
camera.
eBe sure to format the SD Memory Card with
this camera before using it. A card that is not
formatted using the camera may limit your
full use of all the camera’s capabilities.
SHOOTING
(1) Turn on the camera (page 37).
(2) Take photos in the BASIC operation mode*2.
eIn the BASIC mode, it's easy to take great photos
right away.
eTo switch the menu mode, see page 42.
eFor shooting video clips, see page 47.
eFor shooting still photos, see page 48.
      !"#

English 2
PLAYBACK
(1) View your photos in the BASIC operation
mode (page 64).
Playback as well is easy in the BASIC mode.
*1: About the SD Memory Card
In this manual, the SD Memory Card is
referred to as “card”.
*2: Shooting in the BASIC mode
For recording and viewing images, your
camera has two modes to choose from. In the
BASIC mode, only the basic camera functions
are used. In the EXPERT mode, you have full
access to all the camera's functions.
Symbols used in this manual
HINT Points that may prove useful when using the camera.
NOTE Points giving some extended instructions or special points to pay
attention to.
CAUTION Points that require special attention.
(page xx) Refer to the page indicated for detailed information.
You may find the answers to questions or problems concerning camera
operation in the sections “COMMONLY ASKED QUESTIONS”(page 149) and
“TROUBLESHOOTING”(page 157).
 $     !"#

3English
CONTENTS
OUTLINE OF OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
USING YOUR CAMERA SAFELY AND CORRECTLY . . . . . . . . .7
CHECKING THE INCLUDED ACCESSORIES . . . . . . . . . . . . . .25
GETTING THE MOST OUT OF YOUR CAMERA . . . . . . . . . . . .27
iPREPARATION
PARTS NAMES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
CHARGING THE BATTERY PACK. . . . . . . . . . . . . . . . . . . . . . .34
INSTALLING THE BATTERY PACK AND CARD . . . . . . . . . . . .35
TURNING THE POWER ON AND OFF. . . . . . . . . . . . . . . . . . . .37
OPERATION BUTTONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
SWITCHING THE MENU MODE. . . . . . . . . . . . . . . . . . . . . . . . .42
BEFORE TAKING PICTURES. . . . . . . . . . . . . . . . . . . . . . . . . . .44
      !"#

English 4
BASIC MODE
iSHOOTING
CAPTURING IMAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
ABOUT THE BASIC MODE SHOOTING SETTING SCREEN . . 52
CHANGING THE SHOOTING SETTINGS . . . . . . . . . . . . . . . . . 55
OTHER SHOOTING FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . 58
iPLAYBACK
VIEWING IMAGES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
ABOUT THE BASIC MODE PLAYBACK SETTING SCREEN . . 68
OTHER PLAYBACK FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . 70
 %     !"#

5English
EXPERT MODE
iSHOOTING
ABOUT THE EXPERT MODE SHOOTING SETTING SCREEN 78
VIDEO IMAGE QUALITY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .81
FOCUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .82
FLICKER-REDUCTION FUNCTION . . . . . . . . . . . . . . . . . . . . . .83
ISO SENSITIVITY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
WHITE BALANCE SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
EXPOSURE CORRECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . .86
iPLAYBACK
ABOUT THE EXPERT MODE PLAYBACK SETTING SCREEN.87
ROTATE IMAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
EDITING VIDEO CLIPS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
PRINT SETTINGS (STILL IMAGES ONLY) . . . . . . . . . . . . . . . .98
 &     !"#

English 6
OPTION SETTINGS
iCAMERA SETTINGS
ABOUT THE OPTION SETTING SCREEN . . . . . . . . . . . . . . . 105
GUIDANCE FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
OPERATIONAL SOUNDS SETTING . . . . . . . . . . . . . . . . . . . . 108
USB FUNCTION SETTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
FILE NO. RESET FUNCTION. . . . . . . . . . . . . . . . . . . . . . . . . . 111
DATE AND TIME SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
SCREEN LANGUAGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
TV SYSTEM SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
POWER SAVE SETTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
RESETTING THE CAMERA SETTINGS . . . . . . . . . . . . . . . . . 121
FORMATTING A CARD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
CHECKING THE REMAINING CARD MEMORY . . . . . . . . . . . 124
CHECKING THE REMAINING BATTERY PACK CHARGE. . . 126
iOTHER DEVICES AND CONNECTIONS
DOCKING STATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
CABLE ADAPTER . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
CONNECTING TO A PRINTER . . . . . . . . . . . . . . . . . . . . . . . . 139
iAPPENDICES
COMMONLY ASKED QUESTIONS . . . . . . . . . . . . . . . . . . . . . 149
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
      !"#

7English
USING YOUR CAMERA SAFELY AND
CORRECTLY
CAMERA
WARNING
i
ii
iIf the camera makes a strange noise, emits a
strange odor, or if smoke comes out from it,
immediately turn off the power and remove the
battery pack.
eIf the camera is used under these conditions, it may cause
a fire or electric shock. Immediately turn off the digital
camera, remove the battery pack, and wait to make sure
no more smoke comes from the camera. Then take it to the
dealer for service. Do not try to repair or open the camera
yourself.
i
ii
iDo not modify or open the cabinet
eHigh voltage circuits are inside, and there is a high risk of
fire or electric shock if they are touched. Any internal
check, setting, or repair should be performed by the dealer.
i
ii
iDo not use while driving
eDo not capture images, play back images, or watch the
LCD monitor while driving a vehicle. Doing so may cause
an accident.
eBe careful where you put down the camera inside an
automobile. During sudden stops or turns it may fall behind
the brake pedal and prevent braking.
i
ii
iBe aware of your surroundings when using the
camera
ePay close attention to your surroundings when using the
camera. Failure to do so may lead to an accident or injury.
eWhen using the camera while walking, be very careful of
your surroundings and especially the traffic to avoid
accidents.
eDo not use the camera inside an airplane or elsewhere
where its use may be restricted.
 '     !"#

English 8
WARNING
i
ii
iDo not get the camera wet
eThis camera is not water-resistant. Do not allow it to get
wet, as doing so may cause a fire or electric shock.
eDo not use the camera in a bathroom.
eIf the camera gets wet, immediately turn it off and remove
the battery pack. Then take it to a dealer for repair. Using
the camera after it has been become wet may cause a fire,
electric shock, or other accident.
i
ii
iDo not use during a storm
eTo avoid the risk of being struck by lightning, do not use the
camera during a thunderstorm. In particular, if used in an
open field, you have an increased chance of being struck by
lightning. Quickly seek refuge in a place that will protect you
from lightning.
i
ii
iDo not place on an unstable surface
eThe camera may fall, resulting in damage to the camera or
injury.
eIf the camera has fallen and its body is damaged, turn it off,
remove the battery pack, and take it to the dealer for repair.
Using the camera after its body has been damaged may
cause a fire or electric shock.
i
ii
iDo not look through the camera into the sun
eDo not look through the camera at the sun or any other
strong source of light. Doing so may seriously injure your
eyes.
i
ii
iDo not use the flash close to a person’s face
eTo prevent possible eye injury, do not use the flash near a
person’s face (especially young children or babies). If the
flash is used close to a person’s opened eyes, there is a risk
that it may damage that person’s eyesight.
 (     !"#

9English
USING YOUR CAMERA SAFELY AND CORRECTLY
WARNING
i
ii
iDo not use where there is risk of explosion
eDo not use the camera in a location where there is explosive
gas, or any other flammable material in the air. Doing so may
cause a fire or an explosion.
i
ii
iKeep the camera out of the reach of children
eThe following may happen if children play with the camera:
dThey may wrap the strap around their neck and suffo-
cate.
dThey may swallow the battery pack or other small
parts. In such a case, consult a physician immedi-
ately.
dThey may damage their eyesight if the flash goes off
too close to their eyes.
dThey may get hurt by the camera.
CAUTION
i
ii
iCautions when carrying the camera
eDo not walk around holding the camera by the handstrap. It
may hit other objects and get damaged. When walking
around, hold the camera in your hand or place it in a pocket.
eBe careful not to drop the camera or subject it to strong
shocks.
eMake sure direct sunlight does not hit the camera lens, as
that may damage the internal parts. When not using the
camera, be sure to always turn it off and close the lens cover.
i
ii
iIf the camera is not going to be used for a long
period of time
eFor safety’s sake, remove the battery pack from the camera.
This will prevent any possible excess heat or leakage of
battery fluid that may result in injuries or damage to nearby
objects. (Note that when the battery pack is removed for a
long period, the time and date settings will be cleared.)
 )     !"#

English 10
CAUTION
i
ii
iCautions during use and storage
eThis camera is a precision instrument. When using or
storing the camera, make sure to avoid the following
locations to avoid damage.
dPlaces in direct sunlight
dPlaces where humidity and temperature are high
dPlaces that may get wet
dPlaces close to an air conditioner or heater
dInside a car
dPlaces where there is dust and dirt
dPlaces where there is a fire burning
dPlaces where volatile products are stored
dPlaces subject to vibration
Operating environment:
dTemperature 0°C to 40°C (operation)
–20 to 60°C (storage)
dHumidity 30 to 90% (operation, no condensation)
10 to 90% (storage, no condensation)
 *     !"#

11 English
USING YOUR CAMERA SAFELY AND CORRECTLY
DOCKING STATION AND AC ADAPTER/
CHARGER
DANGER
i
ii
iDo not recharge battery packs that are not Li-ion
battery packs (Model DB-L20)
eDo not recharge a battery pack other than the supplied Li-ion
battery pack (DB-L20). Recharging a dry-cell battery or other
type of rechargeable battery may cause excess heat,
combustion, or leakage, and cause a fire, injuries, burns, or
damage to nearby objects.
i
ii
iUse a 100 to 240 V AC power supply
eIf used with a power supply other than the one specified, it
may cause a fire or electric shock. The power cord is rated
for 125 V AC. Therefore, if you plan to use the docking
station and/or the AC adapter/charger in a region with a
different voltage, it may be necessary to replace the power
cord with one that can be used in that location. For details,
please see page 168.
i
ii
iDo not disassemble or modify
eIt is dangerous to touch the inside. Doing so may cause a fire
or electric shock.
eDo not use as a direct current generator.
i
ii
iDo not get the docking station or AC adapter/
charger wet
eMake sure they do not get wet, as doing so may cause a fire
or electric shock.
eDo not use the camera in a bathroom.
eIf the docking station or AC adapter/charger gets wet,
immediately unplug it from the power outlet and remove the
battery pack. Then contact the place of purchase. If used
while wet, it may cause a fire, electric shock, or an accident.
      !"#

English 12
DANGER
i
ii
iCautions when plugging in
eSecurely plug the power cord all the way into the power
outlet. If the docking station or AC adapter/charger is used
with the power cord not fully plugged in, heat may be
generated and cause a fire.
eDo not use if the power cord is damaged or cannot be
correctly plugged into the power outlet. Using in this
condition may cause a fire or electric shock.
eDo not allow dust, etc., to build up on the power cord or
power outlet. A build-up of dust may cause a short circuit
or generate heat and cause a fire.
eWhen unplugging the power cord, be sure to hold the plug
part and slowly pull it out of the power outlet. Pulling the
cord portion may damage the power cord and cause a fire
or electric shock.
i
ii
iDo not pull on the power cord to unplug it
eDo not leave the power cord plugged into the power outlet
while the other end is not plugged into the docking station
or AC adapter/charger. The loose end can cause
electrocution if touched with wet hands or if handled by
children.
eUse only the supplied power cord. If a different power
cord is used, it may be rated for a different current load,
and that may cause a fire.
eThe supplied power cord is for exclusive use with the
devices supplied with your camera. Do not use it with
other devices, as doing so may cause a fire or electric
shock.
eDo not use a bundled power cord, as the heat generated
may cause a fire.
eWhen using an extension cord, make sure that the total
wattage of the connected devices does not exceed the
rated value of the extension cord. If the power load
exceeds the rated value, it may cause a fire.
 $     !"#

13 English
DANGER
i
ii
iKeep out of the reach of children
eChildren may place the battery pack or other small
components in their mouth or perform some other such
unforeseeable action. If swallowed, consult a physician
immediately.
i
ii
iIf smoke or a strange odor is emitted, or if
strange noises are heard, immediately unplug
the power cord from the power outlet
eIf used under these conditions, it make cause a fire or
electric shock.
eIf strange conditions such as these occur, immediately
unplug the device, remove the battery pack, and wait to
make sure no more smoke is emitted. Then contact the
place of purchase. Do not try to repair or open the device
yourself.
i
ii
iDo not handle with wet hands
eHandling the docking station or AC adapter/charger with
wet hands may cause an electric shock.
i
ii
iDo not use during a storm
eDo not touch the docking station, AC adapter/charger or
power cord while it is plugged into a power outlet during a
thunderstorm. Doing so may cause an electric shock.
      !"#

English 14
CAUTION
i
ii
iDo not damage the power cord
eDo not place heavy objects on the power cord. Do not
place the power cord near a heat source. Do not
excessively bend the power cord, modify it, or secure it
with staples. Doing so may damage the power cord and
cause a fire or electric shock.
eIf the power cord is damaged, or if it does not plug
properly into the docking station, AC adapter/charger or
wall outlet, contact the place of purchase.
i
ii
iDo not place on an unstable surface
eThe camera may fall, resulting in damage to the camera
or injury.
eIf it falls and the body is damaged, remove the battery
pack and contact the place of purchase. If used while
damaged, it may cause a fire, electric shock, or other
damage.
i
ii
iOperating and storage conditions
eDo not use close to a heat source (close to a stove or
heater) or leave it exposed to direct sunlight.
Operating environment:
dTemperature 0 to 40°C (charging)
–20 to 60°C (storage)
dHumidity 20 to 80%
(charging and storage)
 %     !"#

15 English
LI-ION BATTERY PACK (DB-L20)
DANGER
This camera uses a Li-ion battery pack (Model DB-L20).
i
ii
iIf there is leaking, discoloration, change of
shape, rise in temperature, damaged exterior,
strange odor or any other abnormal condition,
immediately discontinue use and remove the
battery pack from the camera, taking care to
keep it well away from fire.
eContinued use of the battery pack under any of these
conditions may result in fire, injury, explosion or other
serious damage.
eIf battery fluid is leaking, placing the battery pack in close
proximity to a fire or other heat source may ignite the
battery fluid and result in fire, damage, eruption of battery
fluid, or smoke fumes.
i
ii
iDo not transform, take apart, or modify.
eSafety mechanisms and protective devices have been in
incorporation in the battery pack for the purpose of
preventing danger. Any modification, by transforming,
disassembling, or directly soldering to it, etc., will defeat
these safety devices and possibly cause the battery pack
to catch fire, explode, or leak or spew battery fluid.
i
ii
iDo not connect the (+) and (–) terminals with a
wire or other metal implement. Do not carry
loose or keep with necklaces, hairpins, etc.
eDoing so may result in a short circuit, high voltage flow,
fire, explosion, leaking or spewing battery fluid, or heat
generation. Metal such as a wire or necklace, etc. may
cause heat to be generated.
i
ii
iDo not throw the battery pack in the fire or sub-
ject it to heat
eDoing so may cause the insulation to melt, damage the
gas discharge valve and safety mechanisms, or ignite
the battery fluid, resulting in fire or explosion.
 &     !"#

English 16
DANGER
i
ii
iDo not drop, hit, or submit the battery pack to
strong shocks
eIf the safety mechanisms and protective devices are
broken, an abnormal chemical reaction may occur inside
the battery pack, or cause the battery pack to catch fire,
explode, leak or spew battery fluid, or generate heat.
i
ii
iDo not allow the battery pack to come into con-
tact with fresh or salt water, or allow the termi-
nals to become wet.
eIf the safety mechanisms and protective devices are
damaged by corrosion, an abnormal chemical reaction
may occur inside the battery pack, or cause the battery
pack to catch fire, explode, leak or spew battery fluid, or
generate heat.
i
ii
iOperating and storage conditions
eTemperature when using or recharging: 0 to 40°C
eDo not use, recharge, store or leave the battery pack near fire or
inside a car exposed to the hot sun, etc. (locations in which the tem-
perature reaches 60°C or higher).
eAt high temperatures, the safety mechanisms and protective devices
inside the battery pack may be damaged by corrosion, causing an
abnormal chemical reaction to occur, or cause the battery pack to
catch fire, explode, leak or spew battery fluid, or generate heat. If the
safety mechanisms and protective devices are damaged, the battery
pack will become unusable. An environment with extremely high or
low temperatures will cause the battery capacity to deteriorate and
shorten the usable time, and may even shorten the battery life.
eAvoid storing the battery pack with it near full charge. It is recom-
mended to store the battery pack when it is near fully discharged.
eIf the battery pack is completely discharged, it may become unable to
be recharged again. To avoid this, charge the battery pack for at
least five minutes every six months.
eStorage temperature: –10°C to 30°C
When not using the battery pack, remove it from the camera and
store at 0°C to 30°C in a place with no condensation.
eHumidity: 10% to 90% (no condensation)
      !"#

17 English
DANGER
i
ii
iUse only the supplied docking station and AC
adapter/charger
eIf another charger is used, the battery pack may be
overcharged, or recharged with an abnormal voltage,
causing an abnormal chemical reaction to occur, or cause
the battery pack to catch fire, explode, leak or spew battery
fluid, or generate heat.
i
ii
iUse the battery pack only in the specified device
eIf the battery pack is used in a device other than that
specified, it may cause an abnormal voltage flow, or cause
the battery pack to catch fire, explode, leak or spew battery
fluid, or generate heat.
i
ii
iDo not peel or damage the outer case
eDamaging the outer case, inserting nails, hitting with a
hammer, stepping on the battery pack, etc. may cause a
short circuit inside the battery pack or cause the battery
pack to catch fire, explode, leak or spew battery fluid, or
generate heat.
i
ii
iIf the battery pack is leaking and the electrolyte
gets on your skin or clothing, immediately rinse
with clean water
eIf the electrolyte gets into your eyes, you risk losing your
eyesight. Immediately rinse your eyes with clean,
running water, and seek medical attention right away.
Any electrolyte that comes into contact with your skin or
clothing may harm your skin. Immediately rinse the area
with clean, running water.
i
ii
iInsert the battery pack correctly, as specified
eWhen installing the battery pack in the charger or
camera, pay attention to the indicated polarity (+ and –),
and insert it correctly.
eIf the battery pack is installed with the wrong orientation,
it may cause an abnormal chemical reaction while in the
charger, an abnormal voltage flow when it is used, or
cause the battery pack to catch fire, explode, leak or
spew battery fluid, or generate heat.
 '     !"#
