Sanyo AVL-263 User manual

AVL263
1 682 345 75:
SM0915044

CONTENTS
Safety precautions………………………………………………………………………..…
Alignment instructions …………………………….…….…………………………………
Method of software upgrading……………………………………………………………..
Working principle analysis of the unit……………………………….………….………….
Block diagram…………………………………..………………………………….…………
IC block diagram………………………………………………………………………..……
Wiring diagram …………………………………………………………………………….
Troubleshooting guide ………………………………………………………………..……
Schematic diagram…………………………………………………………………………
APPENDIX-A: Main Assembly
APPENDIX-B: Exploded View
1
3
6
12
13
14
18
19
24
Removing or Installing the Stand
Wall mounting instructions

1
Safety precautions
1. Instructions
Be sure to switch off the power supply before replacing or welding any components or
inserting/plugging in connection wire Anti static measures to be taken (throughout the entire
production process!):
a) Do not touch here and there by hand at will;
b) Be sure to use anti static electric iron;
c) It’s a must for the welder to wear anti static gloves.
Please refer to the detailed list before replacing components that have special safety requirements.
Do not change the specs and type at will.
2. Points for attention in servicing of LCD
2.1 Screens are different from one model to another and therefore not interchangeable. Be sure to
use the screen of the original model for replacement.
2.2 The operation voltage of LCD screen is 700-825V. Be sure to take proper measures in
protecting yourself and the machine when testing the system in the course of normal operation or
right after the power is switched off. Please do not touch the circuit or the metal part of the module
that is in operation mode. Relevant operation is possible only one minute after the power is
switched off.
2.3 Do not use any adapter that is not identical with the TV set. Otherwise it will cause fire or
damage to the set.
2.4 Never operate the set or do any installation work in bad environment such as wet bathroom,
laundry, kitchen, or nearby fire source, heating equipment and devices or exposure to sunlight etc.
Otherwise bad effect will result.
2.5 If any foreign substance such as water, liquid, metal slices or other matters happens to fall into
the module, be sure to cut the power off immediately and do not move anything on the module lest it
should cause fire or electric shock due to contact with the high voltage or short circuit.
2.6 Should there be smoke, abnormal smell or sound from the module, please shut the power off at
once. Likewise, if the screen is not working after the power is on or in the course of operation, the
power must be cut off immediately and no more operation is allowed under the same condition.
2.7 Do not pull out or plug in the connection wire when the module is in operation or just after the
power is off because in this case relatively high voltage still remains in the capacitor of the driving
circuit. Please wait at least one minute before the pulling out or plugging in the connection wire.
2.8 When operating or installing LCD please don’t subject the LCD components to bending, twisting
or extrusion, collision lest mishap should result.
2.9 As most of the circuitry in LCD TV set is composed of CMOS integrated circuits, it’s necessary
to pay attention to anti static. Before servicing LCD TV make sure to take anti static measure and
ensure full grounding for all the parts that have to be grounded.
2.10 There are lots of connection wires between parts behind the LCD screen. When servicing or
moving the set please take care not to touch or scratch them. Once they are damaged the screen
Attention: This service manual is only for service personnel to take reference with. Before
servicing please read the following points carefully.

2
would be unable to work and no way to get it repaired.
If the connection wires, connectors or components fixed by the thermotropic glue need to disengage
when service, please soak the thermotropic glue into the alcohol and then pull them out in case of
damage.
2.11 Special care must be taken in transporting or handling it. Exquisite shock vibration may lead to
breakage of screen glass or damage to driving circuit. Therefore it must be packed in a strong case
before the transportation or handling.
2.12 For the storage make sure to put it in a place where the environment can be controlled so as to
prevent the temperature and humidity from exceeding the limits as specified in the manual. For
prolonged storage, it is necessary to house it in an anti-moisture bag and put them altogether in one
place. The ambient conditions are tabulated as follows:
Temperature Scope for operation 0 ~ +50 oC
Scope for storage -20 ~ +60 oC
Humidity Scope for operation 20% ~ 85%
Scope for storage 10% ~ 90%
2.13 Display of a fixed picture for a long time may result in appearance of picture residue on the
screen, as commonly called “ghost shadow”. The extent of the residual picture varies with the
maker of LCD screen. This phenomenon doesn’t represent failure. This “ghost shadow” may remain
in the picture for a period of time (several minutes). But when operating it please avoid displaying
still picture in high brightness for a long time.
3. Points for attention during installation
3.1 The front panel of LCD screen is of glass. When installing it please make sure to put it in place.
3.2 For service or installation it’s necessary to use specified screw lest it should damage the screen.
3.3 Be sure to take anti dust measures. Any foreign substance that happens to fall down between
the screen and the glass will affect the receiving and viewing effect
3.4 When dismantling or mounting the protective partition plate that is used for anti vibration and
insulation please take care to keep it in intactness so as to avoid hidden trouble.
3.5 Be sure to protect the cabinet from damage or scratch during service, dismantling or mounting.

3
Alignment instructions
1. Test equipment
PM5518 (video signal generator)
VG-848 (VGA and HDMI signal generator)
CA210 (color analyzer)
2 Alignment flow-chart
The alignment flow-chart is shown as fig-1
Fig-1 adjustment flow-chart
3 Unit adjustments
Connect all the boards according to wiring diagram, connect with power and observe the display.
Method for entering factory menu: press “INPUT”, “2”, “5”, ”8” and “0” in turn to enter factory
menu; press “CH+” and “CH-” to select adjustment items and press “VOL+” and “VOL-” to adjust
value items, press “MENU” continuously to exit.
Method for software upgrading: enter factory menu and select “OPTION”, set ISP to 1 or insert
jump wire J201, then you can upgrade the software on line. After upgrade, it needs to set ISP back
to 0 or pull out jump wire J201. After software upgrade finish, please turn off the TV and then turn on,
enter the factory menu and initialize the EEPROM (EEPROM-MEMORAY RECALL).
3.1 Initialization
The items are only for some units which have special demands. They do not need to be adjusted for
normal units.
Enter factory menu, select “OPTION” and “HOTEL OPTION” sub-menu, adjustment of items to see
table1.
Check DDC, HDCP KEY, FLASH and POWER control IC
Factory initialization setup
IF channel AFT voltage of TV and AGC voltage
White balance adjustment
Performance check
Preset ex-factory
ADC correction of VGA, YPbPr

4
Table1 sub-menu adjustment
Items Preset Introduce
HOTEL 0 1: HOTEL OPTION of factory menu is optional
0: HOTEL OPTION of factory menu is not optional
LOGO 1 1: display LOGO in no signal or turn on
0: no LOGO display
ADC PRESCALE 00A adjust according the power consumption
SIF PRESCALE 001 adjust according the power consumption
BACK LIGHT 100 Adjust according the screen
ALL COLOR 1 1: white balance of each channel auto offset based on the HDMI white
balance
0: white balance of each channel adjust the offset base separately
NO STANDY 11 01: turn on 00: memory function of turn on 10: standby
INIT VOLUME 0-100 Volume when turn on
INIT CHANNEL 1-200 Channel when turn on
INIT SRC Program source Input Source when turn on
EEPROM-MEMORAY
RECALL
> EEPROM Initialization (operate when EEPROM data chaos)
3.2 Adjustment for AFT and AGC of IF channel in TV
3.2.1 IF AFT adjustment
Turn on the TV then enter the factory menu, set IF VCO to 1, disconnect J601, adjust L610 to value
2.5V of TP603 (A face), then solder J601.
3.2.2 IF AGC adjustment
Input 172.25MHz RF signal of 60dB to RF terminal, adjust RP601 to value 3.3V of TP601 (A face)
and there should be no obvious snowy picture. Increase the TV signal to 90dBV and it should be no
obvious noisy.
3.3 White balance adjustment
3.3.1 HDMI white balance adjustment
a. Input VG-848 signal to HDMI: TIMING854(800*600/60Hz) 8 level gray scale of PAT920,
adjust the balance with CA210.
b. Enter COLOR TEMP sub menu and select color temperature of standard (1000K), the value
of coordinate is commend.
c. Fixed B OFF, adjust R OFF, G OFF to let the color coordinate of the second level be
(280,290) (CPT panel) and the brightness be 2-10nit or so; Fixed B GAIN, adjust R GAIN, G GAIN
to let the color coordinate of the seventh level be (280,290) (CPT panel). Repeat adjust R OFF, G
OFF, R GAIN and G GAIN, until the color coordinate of the two level gray scale be (280,290) (CPT
panel).
3.3.2 VGA/YPbPr/ AV white balance check and correct
a. Connect VG-848 signal of VGA to VGA terminal and input TIMING854(800*600/60HZ)
PATTERN921(16 gray levels), enter ADC ADJ sub menu, select AUTOTUNE and wait for OK
display. Input PAT920(8 gray levels), check if the white balance is normal, if not, set ALL COLOR to
0 and fine adjust according the method of 3.2.2.
b. connect VG-848 YPbPr signal to YPbPr terminal and input TIMING972(1080I/60Hz) PAT908

5
color bar(include back/white bars), enter submenu of ADC ADJ, select AUTOTUNE and wait for OK
display. Input PAT920(8 gray levels), check if the white balance is normal, if not, set ALL COLOR to
0 and fine adjust according the method of 3.2.2
c. Input AV signal(PM5518, 8 gray levels, PAL for Chinese and NTSC for America) to VIDEO 1
terminal, check if the white balance is normal, if not, set ALL COLOR to 0 and fine adjust according
the method of 3.2.2.
Note: it can’t set back to 1 once ALL COLOR changes to 0.
4 Performance check
4.1 TV function
Enter searching menu →auto search, connect RF-TV terminal with central signal source and check
if the picture is normal, if there are channels be skipped. Check CCD and V-CHIP for America.
4.2 AV/S, YPbPr terminals
Input AV/S, YPbPr / YCbCr HD signal, check if it is normal.
4.3 VGA terminal
Insert VGA terminal, input VGA format signal of 640X480@60 Hz and check if the display is normal.
4.4 HDMI terminal
Insert HDMI terminal, input 640X480@60Hz signal, check if the display is normal. Check HDCP
function.
4.5 check sound channel
Check the speaker and earphone of each channel.
4.6 RS232 terminal
Insert the earphone wire to COM port, check the long-distance control function with special test
software.
4.7 other function check
Check the turn on/turn off timer, asleep timer, picture/sound mode, OSD, freeze/mute, stereo/SAP,
magic picture, ect.
4.8 presetting before ex-factory
4.9 software instruction
No. Code Model Function Flash write
before paste Method
N303 5272404002 AT24C04IV-10SU-2.7 HDCP Yes FSX.2A3360-034
N305 5272540003 EN25F40 Flash Yes FSX.2A3360-062
N202 5272402002 AT24C02BN10SU-1.8 VGA EDID Yes FSX.2A3360-030
N501 5272404002 AT24C02BN10SU-1.8 HDMI EDID Yes FSX.2A3360-030
N502 5272404002 AT24C02BN10SU-1.8 HDMI EDID Yes FSX.2A3360-030
N503 5272404002 AT24C02BN10SU-1.8 HDMI EDID Yes FSX.2A3360-030
N601 5270008001 ATMEGA8L-8AI Power control Yes FSX.2A3360-061
Item Setting Item Setting Item Setting
PICTURE MODE NAUTRAL
SOUND MODE NEWS OSD English
VGA/HDMI color
temperature
STANDARD
NR LOW HALFTONE 50 ANTENNA CATV
ZOOM FULL DURATION 15 Turn off channel TV

6
Method of software upgrading
1. The tools and software demanded
1) Please confirm that PC has the software of ISP_TOOL and install the parallel interface drive
program Port95nt.
2) ISP_TOOL icon is bellow:
3) One serial cable (25 pins) and one VGA cable (15 pins), the parallel cable connects the PC and
the upgrade instrument, the VGA cable connects the TV and the upgrade instrument.
2. The steps for upgrading software
1) Please confirm that the connection wires and the upgrade instrument are connected well before
the software written and then power on the TV.
2) Double click the icon ISP_TOOL to open it:
3) Press “Connect“ to connect TV, if the connection is done successfully as shown below, then
press “enter”.

7
Note: if it appears error, check the connection wires and check if ISP item of the factory menu is set
to 1, if not, please set it to 1.
4) After connection is done, it needs to read the Binary document. Press “Read” as shown below:
5) Search the document needed to write in the “Read” check box.

8
6) Select the document then the window will appear as shown below:
Select

9
7) Press “Auto” to select the writing function.
Select the items shown in the picture above:
(a) Read File

10
(b) Program
(c) Exit ISP
(d) Erase Device
(e) File Area
8) Press “Run” to begin the writing program, wait till the blue bar is complete.
After writing, it will display OK:
If there is error appeared (shown as below), press “Run” again to rewrite the program till it is
success.

11
Note1: keep the connection well and don’t cut off the power during the writing process.
Note2: the writing speed can be adjusted as shown below. Select “Config” then adjust Speed BAR,
the value is bigger the speed is faster. But it is easier to appear error when increase the speed, so it
need to select a suitable speed according the PC.
Step 1
Step 2

12
Working principle analysis of the unit
The RF signal received by antenna will be sent to tuner TUNER601, then IF signal will be
obtained through high amplified, mixed frequency. After pre-intermediate amplified by V602, it will
be sent to acoustic surface-wave Z602 to do IF filter and get better IF characteristics, then it will be
sent to N602 (R2S40401) to do intermediate amplification, phase-lock loop VCO and synchronous
wave detection to get the composite video signal TV-CVBS; after pre-intermediate amplification IF
will also be sent to acoustic surface-wave Z601 to do filter at the same time, the it will be sent to
N602 to do intermediate amplification and output the second sound intermediate frequency signal
TV-SIF.
The TV-CVBS and TV-SIF signal will be sent to main IC N304 (MST9U89). Video signal of AV1,
AV2, S-VIDEO, YPbPr1 and YPbPr2 will also be sent to MST9U89, their audio signal via audio
switch N207 (HEF4052BT) selection to MST9U89 (AV1 and S-VIDEO share the same audio jacks).
HDMI1, HDMI2 and HDMI3 via HDMI switch N504 (TMDS351) selection, then sent to MST9U89
together with VGA.
The main IC N304(MST9U89) is a high performance and fully integrated IC, which can realize
HDMI interface processing, video decoding, video switch selection, A/D and D/A conversion,
interlace/de-interlace processing, modes conversion, OSD and low-voltage differential output, ect.
And it also has functions of audio selection, processing and MCU.
The video signal via MST9U89 processing, output 4 pairs differential signal and 1 pair clock
signal for LCD panel display.
The audio signal via MST9U89 processing, it will be sent to N206 (BH3547F) amplifying to
earphone. The audio signal will also sent to sound amplifier N203 (TPA3120) amplifying to speaker.

13
Block diagram
TUNER
HDMI 2
AV 1
YPrPb1 &L/R
R2S10401
VGA&L/R
YPrPb2 &L/R
MST9U89CL
P A N E L
I/O port
KEY
Power manage Meg8
DDR
Serial flash
HDCP KEY
EEPROM
Earphone amplifier BH3547
EDID
EDID
Earphone
Speaker
HDMI 1
HDMI 3
EDID
EDID
HDMI switch
AV 2
D class amplifier TPA3120
S-VIEDO
AV-OUT

14
IC block diagram
1. MST9U89BL
The MST9U89BL is a high performance and fully integrated IC for multi-function LCD monitor/TV
with resolutions up to full HD (1920x1080). It is configured with an integrated triple-ADC/PLL, an
integrated DVI/HDCP/HDMI receiver, a multi-standard TV video and audio decoder, two video
de-interlacers, two scaling engines, the MStarACE-3 color engine, an on-screen display controller,
an 8-bit MCU and a built-in output panel interface. By use of external frame buffer, PIP/POP is
provided for multimedia applications Furthermore, 3-D video decoding and processing are fulfilled
for high-quality TV applications. To further reduce system costs, the MST9U89BL also integrates
intelligent power management control capability for green-mode requirements and spread-spectrum
support for EMI management.

15
2. R2S10401SP
R2S10404SP is a semiconductor integrated circuit consisting of PLL split-carrier VIF/SIF signal
processing system compliant with PAL.

16
3. TPA3120D2
The TPA3120D2 is a 20-W (per channel) efficient, Class-D audio power amplifier for driving stereo
single ended speakers or mono bridge tied load. The TPA3120D2 can drive stereo speakers as low
as 4Ω. The efficiency of the TPA3120D2 eliminates the need for an external heat sink when playing
music.
The gain of the amplifier is controlled by two gain select pins. The gain selections are 20, 26, 32, 36
dB.
The outputs are fully protected against shorts from GND to ROUT or LOUT and output-to-output
shorts with an auto recovery feature.

17

18
Wiring diagram
main board
power board
connection board
