Before connecting, operating or adjusting this product, please read the manual completely.
Please keep this manual for future reference.
INSTRUCTION MANUAL
LCD-26XR7
LCD TV
IMPORTANT WARNINGS
♦ You MUST leave a space of at least 10 cm at the top, bottom, left, right and rear
of this TV for ventilation.
♦ No naked flame sources, such as lighted candles, should be placed on or
above this TV.
♦ This TV SHOULD NOT be exposed to dripping or splashing and NO objects ,
filled with liquids , such as vases should be placed on the TV.
♦ This TV is equipped with a three pin , earthed type power plug and should only
be connected to an earthed power outlet. DO NOT remove the earth pin , it will
compromise this safety feature. If you are unable to plug into the power outlet
please contact a qualified electrician.
Table of Contents
Important Safety Precautions .............................................................................................................................................1
Preparations .......................................................................................................................................................................4
Identification of Controls.....................................................................................................................................................6
Connections........................................................................................................................................................................9
Basic Operations ..............................................................................................................................................................14
Memorizing the Channels.................................................................................................................................................16
Setting Picture ..................................................................................................................................................................19
Setting Sound ...................................................................................................................................................................20
Stereo / Bilingual Selection...............................................................................................................................................21
Setting Advance ...............................................................................................................................................................22
Parental Control ...............................................................................................................................................................24
Adjusting On-Screen Display ...........................................................................................................................................25
Adjustment in PC (VGA) Mode ........................................................................................................................................26
Teletext .............................................................................................................................................................................27
Troubleshooting................................................................................................................................................................28
Care and Maintenance .....................................................................................................................................................29
Specifications ...................................................................................................................................................................30
Important Safety Precautions
Electrical energy can perform many useful functions, but it can also cause personal injuries and property damage if improperly handled.
This product has been engineered and manufactured with the highest priority on safety. But IMPROPER USE CAN RESULT IN
POTENTIAL ELECTRICAL SHOCK OR FIRE HAZARD. In order to prevent potential danger, please observe the following instructions
when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your LCD TV product, please read
the following precautions carefully before using the product.
1. Read these instructions---All operating instructions must be read and understood before the product is operated.
2. Keep these instructions---These safety and operating instructions must be kept in a safe place for future reference.
3. Heed all warnings---All warnings on the product and in the instructions must be observed closely.
4. Follow all instructions---All operating instructions must be followed.
5. Do not use this apparatus near water---for example, near a bathtub, washbowl,
kitchen sink, or laundry tub, in a wet basement, or near a swimming pool, and the like.
Do not use immediately after moving from a low temperature to high temperature
environment, as this causes condensation, which may result in fire, electric shock, or
other hazards.
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
6. Clean only with dry cloth---Unplug this product from the wall outlet before cleaning.
Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning if required.
7. Ventilation---Do not block any ventilation openings. Install in accordance with the
manufacturer instructions. The vents and other openings in the cabinet are designed for
ventilation. Do not cover or block these vents and openings since insufficient ventilation
can cause overheating and/or shorten the life of the product. Do not place the product on
a bed, sofa, rug or other similar surface, since they can block ventilation openings. This
product is not designed for built-in installation; do not place the product in an enclosed
place such as a bookcase or rack, unless proper ventilation is provided or the
manufacturer’s instructions are followed.
8.Heat sources---Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
9.Grounding or Polarization---Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10.Power cord protection---Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
NOTE: where the mains plug or an appliance coupler is used as the disconnect device, the disconnect device shall remain readily operable.
11.Attachments---Only use attachments/accessories specified by the manufacturer. Do not use attachments not recommended by the
manufacturer. Use of improper attachments can result in accidents.
1
Important Safety Precautions (continued)
12. Stand---Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. Do not place the product on an unstable trolley, stand, tripod or table.
Placing the product on an unstable base can cause the product to fall, resulting in serious personal
injuries as well as damage to the product. When mounting the product on a wall, be sure to follow
the manufacturer’s instructions. Use only the mounting hardware recommended by the
manufacturer.
13. Move Carefully---When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over. Sudden stops, excessive force and uneven floor surfaces
can cause the product to fall from the trolley.
Never attempt to move the TV unless the AC power cord has been disconnected.
14. Lightning---Unplug this apparatus during lightning storms or when unused for long periods of
time.
For added protection for this television equipment during a lightning storm, or when it is left
unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the
antenna. This will prevent damage to the equipment due to lightning and power-line surges.
15. Servicing---Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally, or has been dropped.
16. Replacement parts---In case the product needs replacement parts, make sure that the service person uses replacement parts
specified by the manufacturer, or those with the same characteristics and performance as the original parts. Use of unauthorized parts can
result in fire, electric shock and/or other danger.
17.Overloading---Do not overload wall outlets, extension cords, or convenience receptacles on other equipment as this can result in a
risk of fire or electric shock.
18.Entering of objects and liquids---Never insert an object into the product through vents or openings. With high voltage in the product,
inserting an object can cause electric shock and/or short internal parts . For the same reason, do not spill water or liquid on the product.
19.Damage requiring service---If any of the following conditions occurs, unplug the power cord from the AC outlet, and request a qualified
service person to perform repairs.
a. When the power cord or plug is damaged.
b. When a liquid is spilled on the product or when objects have fallen into the product.
c. When the product has been exposed to rain or water.
d. When the product does not operate properly as described in the operating instructions.
Do not touch the controls other than those described in the operating instructions. Improper adjustment of controls not described in the
instructions can cause damage, which often requires extensive adjustment work by a qualified technician.
e. If the product has been dropped or the cabinet has been damaged in any way.
f. When the product displays an abnormal condition or exhibits a distinct change in performance. Any noticeable abnormality in the product
indicates that the product needs servicing.
20.Safety checks---Upon completion of service or repair work, request the service technician to perform safety checks to ensure that the
product is in proper operating condition.
21.Wall or ceiling mounting---When mounting the product on a wall or ceiling, be sure to install the product according to the method
recommended by the manufacturer. This is a safety feature.
2
<An outside antenna system should not be located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can collide with such power lines or circuits. When
installing an outside antenna system, extreme care should be taken to keep from touching such
power lines or circuits, as contact with them might be fatal.
23.Panel protection---The LCD panel used in this product is made of glass. Therefore, it can break
when the product is dropped or impacted upon by other objects. Be careful not to be injured by
broken glass pieces in case the LCD panel breaks.
24.Pixel defect---The LCD panel is a very high technology product, giving you finely detailed pictures. Occasionally, a few non-active
pixels may appear on the screen as a fixed point of blue, green or red. Please note that this does not affect the performance of your product.
Important Safety Precautions (continued)
22. Power source---This product is intended to be supplied by a listed power supply indicated on the marking label. If you are not sure of the
type of power supply to your home, consult your product dealer or local power company. For added protection for this product during a
lightning storm, or when it is left unattended and unused for long periods of time, unplug it from the wall outlet and disconnect the cable
system. This will prevent damage to the product due to lightning and power line surges. When the unit has to be used with another power
supply voltage, the power cable must be changed. Consult your product dealer. The socket outlet should be installed near the equipment
and easily accessible. Use only the power cord designated by our dealer to ensure safety and EMC. When connecting other products such
as VCRs and personal computers, you should turn off the power of the unit for protection against electric shock.
3
WARNING: For continued safety, apparatus with class I construction shall be connected to a mains socket outlet with a protective earthing
connection.
Preparations
4
Power Connection
Note:
<This product should be operated only from the type of power source indicated on the marking label.
<Always unplug the AC cord from power outlet when not using for a long period of time.
Insert the AC plug into a conveniently located AC outlet.
Using the Remote Control
<Use the remote control by pointing it towards the remote sensor window of the set. Objects between
the remote control and sensor window may prevent proper operation.
Cautions regarding use of remote control
<Do not expose the remote control to shock. In addition, do not expose the remote control to liquids,
and do not place in an area with high humidity.
<Do not install or place the remote control under direct sunlight. The heat may cause deformation of the unit.
<The remote control may not work properly if the remote sensor window of the main unit is under direct sunlight or strong lighting. In such a
case, change the angle of the lighting or LCD TV set, or operate the remote control closer to the remote sensor window.
Note: This illustration is for reference only. The remote sensor may be in different locations on
different models.
Precaution on battery use
Improper use of batteries can result in a leakage of chemicals and/or explosion. Be sure to follow the instructions below.
<Place batteries with their terminals corresponding to the (+) and (–) indications.
<Different types of batteries have different characteristics. Do not mix batteries of different types.
<Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new batteries and/or cause old batteries to leak
chemicals.
<Remove batteries as soon as they are non-operable. Chemicals that leak from batteries can cause a rash. If chemical leakage is found,
wipe with a cloth.
<If the remote control is not used for an extended period of time, remove the batteries from the remote control.
<The batteries (battery pack of batteries installed) shall not be exposed to excessive heat such as sunshine, fire or the like.
Batteries for the Remote Control
If the remote control fails to operate the LCD TV functions, replace the batteries in the remote control.
<(Place the batteries with their terminals
corresponding to the (+) and (–) indications in
the battery compartment.)
Open the battery cover.
1Insert two size-AAA batteries.
2Replace the cover.
3
5m
0
3
30
Speaker connection
Note:
4Unplug the LCD display and all connected
component before connecting the speakers.
4The illustration may be different depending on
model.
Connect the speaker audio cable to the external
speaker output jack on the unit matching the "+" and "-"
ends of the cable with color.
INSTALL the unit in a room where direct light will not fall upon the screen. Total darkness or a reflection on the picture screen may
cause eyestrain. Soft and indirect lighting is recommended for comfortable viewing.
Optimum reception of colour requires a good signal and will generally mean that an outdoor antenna must be used. The exact type
and position of the antenna will depend upon your particular area.
It is recommended that the 75-ohm coaxial cable be used to eliminate interference and noise which may occur due to radio wave
conditions.The antenna cable should not be bundled with the power cord and the like.
Note:
Antenna Connection
Preparations (continued)
5
RF
(Black)
(Red)
(Right speaker) (Left speaker)
(Red)
(Black)
Identification of Controls
6
Main Unit
Note:
Functions of VOL+/-, CH+/-, MENU, SOURCE and POWER are also provided to the remote control. This operation manual provides
a description based on operating functions with the remote control.
OSD means On Screen Display.
1. POWER
2. SOURCE
To access signal source select menu
3. MENU
Press this button to access the Menu main page
4. VOL+/-
Press the VOL+ or VOL- button to directly increase or decrease the sound volume level;
In OSD Menu, press these buttons to adjust the value or setting of each item.
5. CH+/-
Press these two buttons to directly change the TV channel;
In OSD Menu, press these buttons to choose the OSD item.
Press this button to turn the unit ON from STANDBY mode. Press it again to turn the set back to STANDBY.
SOURCE
Channel Down/Up
Volume Down/Up Select Input Signal
Power On/Standby
Menu
MENU
VOL+
VOL-
CH+
CH-
Power Indicator
Remote Sensor
Power Switch
Identification of Controls (continued)
Main Unit
7
SCART1 INTERFACE
HEADPHONE JACK
ANTENNA INPUT
RS232 interface
Pr
Pb
Y
D-Sub
AUDIO
HDMI/DVI IN
AUDIO R
AUDIO L
D-Sub IN
COMPONENT IN
SCART2 INTERFACE
S-VIDEO
VIDEO
AUDIO L/MONO
AUDIO R AV INPUT/
S-VIDEO IN
1. AV inputs (Video, Audio L/MONO, R) / S-Video input
Receive video/audio signals from external sources such as VCR or DVD player.
Receive a S-Video signal from external source such as VCR or DVD player.
2. 21-pin Euro-SCART2 (VIDEO/S-VIDEO) interface
3. HDMI/DVI interface
4. D-Sub input/Audio in
Connect to the D-Sub /audio output sockets on your PC.
5. RS232 interface
For service use only. The user cannot operate the unit through the RS232 interface.
6. Component inputs (Y, Pb, Pr, Audio L, R)
Connect to the component and audio output sockets of a DVD player or Set-Top Box.
7. Antenna input
Allows you to connect cable or outdoor antenna.
8. Headphone jack
9. 21-pin Euro-SCART1 (VIDEO/RGB) interface
SPEAKER OUTPUT JACKS
RS -23 2
Note: Before you connect
external devices with the unit,
please remove the back cover
firstly.
