Sanyo SFX-11 User manual

SANYO —
SERVICE MANUAL Facsimile Tranecener
PRODUCT CODE NO.
1 145 642 25 SFX-11
(GERMANY)
MAIN SPECIFICATIONS
ae
; Type
Desk-top type transceiver
K :
' Line connected | Public switched telephone network
!
_ Size of recording paper i 216mm (8.5”) x 30m (98)
' Effective scanning width | 208mm (8.2”)
: zs
Effective recording width 212mm (8.3”)
Transmission speed | 9600/7200/4800/2400 BPS e
Transmission time Approx. 15 sec. (Transmission aS standard)
Nae scanning density ” Fine mode: 8 ole: Senderdebne
Sub scanning density : 7.7 lines/mm (fine) 385: linpaiini(atandard) 154 lines/mm (Super fine mode) i
* Compression mode MH (Modified Huffman) and Sanyo original
| Reading method las
Recording method Thermal printing
| Power supply | 230V, 50/60Hz |
| Power consumption Stand-by: 5W, Transmission: 20W, Reception: 120W, Copy: 130W |
T Outer dimensions “| 378(W) x 80(H) x 227(D) mm |
(W x Hx D) 14.9” x3.1” x89”
| Weight Approx. 3.7kg (8.1 Ibs)
3.
| Ambient temperature | 5°C ~ 35°C (41°F ~ 95°F)
REFERENCE NO. SM620006

INDEX
Page
ToS TALLATION ea isac3:o paid eee oe Soe Rite Sees a eG es ae rasa Gea Ba desea tboe aleacetangse si aleS alee aida tied aaays 1~8
2. PERIODICAL INSPECTION AND MAINTENANCE .......... 0... ccc ccc cece cece ence ene e tees teeeeeeeeene 9
BORITUEINE 73 'ci4 dior Yona eaaieat veal daw tees vetoing Meas EGA ae Redd curio eed eth genes Caan 10~ 12
4. MECHANICAL OUTLINE iciccieeseciie tend eeae Unies aie 4 diese a detleedi dau deeds dnielgne shee ae Se dkA 12,13
5. + ROUBLE SHOOTING
=-". Explanation of the function for each PCBS...... 2... ccc cece cece ee ence nee e ee eeeneeeeeeees 14,15
5-2. Trouble shooting for Mechanical Parts ........ ccc ccc cece ence cece nese eee sereeteeeeeeteee 16
5-3. Trouble shooting for circuitry 0.2... ccc ccc ccc cece ee cece eee eeeeeeeceeseeeeceeueeeens 17~ 21
DAS EXTOL CODE listisie, 25 ess eiahaie 4 ors ape ere ha Wises ove b5 ab yaen, cond Sou LhaySliwadt oe deg easeeale-ssaih bdgseras ge etaiee NEES 22, 23
6 =EPAIRS
2-1..‘Remioval of the: main parts: octets scan dejsseiici sas die eaen ed he saws selec Seiad orate lot ovecave tpi gew Via wiahovbes 24, 25
5-2. Replacement of the main parts .......... 0 ccc cece cece cc ccc cece eee e eee ee seeeeeeveveveuees 25, 26
5-2 Operation of the Test Mode... i ci3 ace oh. piedecia wid begie'Gaceeieiw's a ie 0 $4 Wines s A-oeuilia Wow dee aereled 27 ~ 30
7. PRINTING OF THE REPORTS AND LISTS
Pole ACIVItY REDON iia dee wtekn ues Seven ehendgieveuatdedaanleg tie iis Sa sD escugeepasd co ueeetevenes 30
¥=2. One-touch Dial Listinscisiodcociesaced Saioein bebo 8b Sa es ss Bes 5 He dae areas vices g baa ee owe be aN 30, 31
me SPO! Dial WiSt os acco sees viedo itisnsince-e oie so wien eve wyarereauin aie aeldeie eas aah Yc dle bane detours Ree anes 31
44... Feature Switch WSt! s40435 dee weeke taatnnseee awd new aend dedibbedd Leeekeiiawlee houdiedar eats 31, 32
eee RAM: CODE List) iid ciiasseenecietotine oes Saino dhe oe Va Mawiene ee Leas baled eeirn noecdd awe eed s eee heats Meow S 32
4B: TLANSMISSION; RODOMM csc o.o:eieisis cise Sosa a ha Wa seihin Sai wie i aitla ioe elas. nie 0 Soe Saag wisi Patents gave Deir ajeree, O40 33
7-7. Timer Transmission Report 22.0... . cc cece cece ccc cece cece eee e eee eeeeceseeeecceseees ve ipltal Miababasca, Bast 33
& AM CODE LIST and Its Explanation ...... 2... ccc ccc cece eee e cece e ene e eee tet eeeneeneseeees 34 ~ 37
9. AUTO RECEPTION MODE DESCRIPTION ............ ccc cece cece cece eee e eee seceeeeeenressneeeeaes 38 ~ 40
10. BLOCK DIAGRAM AND THE SIGNAL FLOW
40-1. BLOCK: DIAGRAM | « scie.e.e cee siete eecede oie cesets ois a was alee te wale oie Sea g ee Us OG Bau ee a elb ee Coe wu ees 41, 42
40=2: CIRCUIT DESCRIPTION 2.5 '6:0056.5 a6 secgie'ets aussie bine ehgds hgndie grad oie aia aie cresa did Gus) tale gia se'asd Waseca dagie-tiae tbe 43, 44
11. SCHEMATIC DIAGRAM
(7) ALL CONNECTION DIAGRAM........... cece ccc eee cee eee tenet nee e nee nett eeeeenreeeeens 45, 46
2) “SCHEMATIC DIAGRAM i :0:05-553255,04 606 Sh eatd coco bd slong sewn ae Re ee wanes bates wae oe 47 ~ 59
> “PC BOARD: DIAGRAM: on :%.dcesc ected cawede caqmesdewes detain wale daamiae quien ced euteey ee eees 60 ~ 62
4) Signal name and function ...... 6... cece ee ee eee ee nee eee eee ee eee nett nee e ne aeee 63
12 PARTS SPECIFICATION
Ci) sHOCONFIGURATION ) oi. ccc ecese'e ese seca cels eca f erarn ce. ores Gomue 6 bie Gee aiereye enw Wier berape whew olen dade aver 64 ~ 68
2) Parts specification for power supply ........ 0... ccc ccc cece eee cece cece cette eee eee e eres eeeeeeneees 69
<3) Figure of main parts for power SUPPlY...... 0.0... cece ccc een nee enter ene tence ten tee eenen ens 69
12. TIME CHARTS OF EACH COMMUNICATION MODE............ 000s cece cect eee e tee ee tee eeeeteeeeeenes 70
42> SXaNAL FLOW. CHART 4. 24.:65.0.55 fecletins dete ddan Galidlouitace ews tied acu nates vis ahead abe sean adoeae tintdans 71
1S: -SXPLODED VIEW 2 cits es wars cnaie ried certs diseeeiHereccsa tard aeeenie ged ote SoA ae adi woe wh altig ieee Halen esta ees 72~ 74
UG SAR Petia ccdute ain Geel ean Aad a th ctiues sae acco wim ee a hnueh Aas Sata ee ehadia oaeniie uate 75~ 79

1. INSTALLATION
To unpack the SFX-11:
1. Open the carton.
2. Remove the accessories (handset, recording paper roll, etc.) from the carton.
3. Remove the fax machine along with the foam braces on both sides.
4, Remove the polyethylene wrapping ‘around the fax machine.
5. Remove the transportation tapes.
6. Save the carton and the foam braces for later storage and/or shipping.
7. Place the machine where there is access to an AC outlet and a modular phone jack. (Be sure to observe the
precautions below.)
Placement precautions
@ Avoid placing the SFX-11 in humid or dusty places, or in places where it will be exposed to excessive heat
(direct sunlight, heaters, etc.).
@ Do not step on, or set anything on, the AC cord. DAMAGE TO THE AC CORD IS A SAFETY RISK AND CAN
CAUSE A FIRE.
@ install the unit only on a stable surface.
@ Do not connect the SFX-11 to the same AC outlet as appliances that generate large amounts of interference
(heaters with thermostats, appliances with motors, etc.). It is best to use a completely separate electrical
outlet.
@ Keep the SFX-11 away from water. If water accidentally enters the unit, unplug the AC power cord immediately.
DO NOT SWITCH THE UNIT ON AGAIN. Contact an authorized Sanyo service center or dealer.
Handling precautions
e Do not remove any parts that are held in place with screws. (The SFX-11 does not contain any user-serviceable
items).
@ Maintain standard room temperature 5°C — 35°C(41°F —95°F) during use. Do not subject the unit to shock or
vibration. Do not move the unit while it is in use.
eA rapid increase in room temperature in cool weather can cause condensation to form inside the unit. If this
happens, wait at least 15 minutes after turning the unit on before attempting to operate it. Failure to do so may
result in paper jams and/or poor print quality.
® When cleaning the cover or operation panel of the unit, wipe gently using a damp cloth to which a small
amount of a neutral detergent has been added. NEVER USE SOLVENTS OR CHEMICALLY TREATED CLOTHS.
Telephone line and AC connections
Connecting telephone line
© The SFX-11 should be not share a telephone line cord with other communica-
tion equipment, except extension telephone and/or answering machine pre-
pared tor the connection, as this may obstruct the proper functioning or the
unit
Connecting handset
Handset Coiled cord
To wall jack
Telephone line cord*
* The telephone line cord differ with each country.
Handset jack
® Another telephone and/or answering machine can be connected to the SFX-11
through the line cord supplied by SANYO dealer.
Power supply
Connecting AC
AC outlet
|
Connect AC plug into AC outlet.

Setting
the
dialing
mode
switch
Installing
recording
paper
Set the dialing mode switch (DIAL) to the correct position for
your telephone line Press the [OPEN | button to open
the recording paper cover.
Your current
telephone
Push-button Rotary-dialing =
telephone telephone tage \neaihy Sob tke na
| Insert the supplied roll of recording
| paper in the paper holder with
both sides seated securely.
The sound
heard when Short audible tones Continuous
you'dial clickin
ig
sounds O x
Cas
Your
telephone
line is
Touch-Tone Puise-Dialing
Pull out the end of the recording
paper from the recording paper
: exit until it extends 4 inches.
Touch-Tone + Puise-Dialing
MFV o> IWV
Close the recording paper cover
by pressing both left and right
corners of the far end of the cover
If you are not sure which dialing system your telephone is using,
contact your telephone company.
Cut the extra recording paper.
@ Use only the recording paper specified for the SFX-11:
Type JH-A4T, 8.5” (216 mm) wide and 98° (30m) long. To purchase, contact
your dealer.
The supplied roll is 49' (15m) long.

<MACHINE INITIAL>
1.
2.
<SETTING YOUR STATION NAME AND FAX NUMBER>
1.
2.
3.
Turn the Power Switch ON.
Slide the Service Switch to ON position
(Refer to Page 27)
. Press! MENU! 5 times.
. Press: SET) .
. Press! SET .
. Press| SET] or| MENU! .
20 Jul.’92 12:00
TEST MODE ?
INITIAL SET ?
ALL CLEAR?
Press| SET] to clear the all data. ——-——__________> Return to Stand-by
Press| MENU! to clear the data individually.
Each time pressing the | MENU) , display scrolls as
shown right.
®
®-:
@
RAM CODE CLEAR ?
No
So
—@
AW
So
~o
ae m >
2 ~
REPORT DATA CLR?
Press| SET| to clear the data at the display. ——-—~__-> Return to Stand-by
Press! MENU! 4 times.
Press| SET).
Press| MENU} twice.
. Press| SET).
. Enter your station name.
A maximum of 24 characters can be entered.
(See page 4.)
. Press| SET .
. Enter your fax number.
Your fax number can be entered up to 20 digits in
length.
Example: 01234567
. Press SET).
, PBX MODE SETTING
Press ;
Press| SET).
Case of select “Nr”, into PBX No. setting mode.
(Case of “NEIN”, “ERDE”, “FLASH” ——> Return to Stand-by)
SET MODE ?
Oo.T DIAL SET
|
STATION CODE SET
ABCDEFGE
01234569
20 Jul .'92 12:00
NST MODE? NEIN
NST MODE? Nr
NST MODE? ERDE
NST MODE? FLASH
NST Nr. =
Mt
NST Nr. = 1239
Entered
up
number
to
4
digits
in
length,
press
|
SET}.
a
ee
Return
to
Stand-by
(if you make a mistake, press |STOP/C | then enter
the correct number.) 93
