Sanyo SC 90 Series User manual

INSTRUCTION
MANUAL
SC 90 SERIES
ii
VACUUM CLEANER
SPECIFICATIONS
MODEL POWER LED POWER
LEVEL MITE BEDDING FRAGRANCE FLOOR
NUMBER CONTROL INDICATOR HUNTER TOOL TOOL
WITH
INCENSE TURBINE
SC T93 YES YES YES YES METAL &
PERFUME BRUSH
BOTTLE
SC 92 YES CARTRIDGE FLOOR
——ONLY NOZZLE
SC 92S YES CARTRIDGE FLOOR
——ONLY NOZZLE
Sc 91 SUCTION YES YES CARTRIDGE FLOOR
CONTROL —ONLY NOZZLE
SUCTION CARTRIDGE FLOOR
Sc 90 CONTROL ——ONLY NOZZLE
. . . . . . . . . . . . . . . . . . . ... . .

IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic precautions should always be
followed, including the following:
READ ALL INSTRUCTIONS
BEFORE USING THIS APPLIANCE
WARNING
To reduce the risk of fire, electric shock, or injury:
Do not leave appliance when plugged in. Unplug from outlet when not
in use and before servicing.
Do not use outdoors or on wet surfaces.
Do not allow to be used as a toy. Close attention is necessary when
used by or near children,
Use only as described in this manual. Use only manufacturer’s recom-
mended attachments.
Do not use with damaged cord or plug. If appliance is not working as it
should, has been dropped, damaged, left outdoors, or dropped into
water, return it to aservice center.
Do not pull or carry by cord, use cord as a handle, close adoor on cord,
or pull cord around sharp edges or corners. Do not run appliance over
cord. Keep cord away from heated surfaces,
Do not unplug by pulling on cord. To unplug, grasp the plug, not the
cord,
Do not handle plug or appliance with wet hands.
Do not put any object into openings. Do not use with any opening
blocked; keep free of dust, lint, hair, and anything that may reduce air
flow.
Keep hair, loose clothing, fingers, and all parts of body away from
openings and moving parts,
Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
Do not use without paper bag/or filters in place.
Turn off all controls before unplugging.
Use extra care when cleaning on stairs.
Do not use to pick up flammable or combustible liquids such as gasoline
or use in areas where they may be present,
UnplugMore conrwlng any hw attwhment wxwmry,
Hold plug when rewinding onto cord reel, Do not allow plug to whip
when rewinding.
Avoid using in avertical position.
SAVE THESE INSTRUCTIONS
CAUTION (For Special area only)
If the supply cord of this appliance is damaged, it must only be replaced by a
repair shop appointed by the manufacturer, because aspecial purpose tool is
required.
–l–
I
-’>
(i
I
,1
NAME OF PARTS (Assembleas indicated in the center illustration.)
Suction control
(Hold By Friction Type)
Wands
Floor nozzle
4r
*
Wand
/
UT
Hose
(Lock With Positive
Power control
A
Handle grip
/holder I
\Wands
.------ --- .-,
Click Type)
w%;hy~;m
compartment
Turbinelbrush w
How to detach the hose
To detach, pressing the
hose stopper, pull the hose
toward you. \
Hose
stopper
OTHERATTACHMENTS
Bedding tool
I II I C6rd rewind pedal
Hahdle JI!lustindicator
Iidingshutter
SLction inlet
Dusting brush
&
Fragrance cartridge
Upholstery brush Crevice tool Incense metal Perfume bottle
&
m- I

OPERATION
1. Cord
Pull out the cord and plug it in the Rewinding
power outlet. To retract the cord back into the
(Caution) vacuum cleaner, press the cord
Do not pull out the cord from the wind pedal.
vacuum cleaner beyond the red \
re-
marker line.
E
I
Cord rewin
2. Switch
(Power Control Type)
To start cleaner, first turn on the masterswitch, then turn on the power control.
TCIstop cleaner momentarily, turn off power control. When vacuumingisfinished,
turn off Dowercontrol andthe masterswitch.
*%
Power control
OQ
<
0
Ma&ter switch \\
(Master Switch Only Type)
3.
4.
Step on master switch for starting or stopping the vacuum cleaner.
Power control 3.
AdjuIt power cmrrtrcdm“MAX’;
wctiort pew(?rbwXmwsrnwimwm
\\
LED Power level indicator -
Suction control
Suction power getswaek when open.
ed. Normally usein closedcondition.
LED lights to indicate the suction
M
HIGH F.3wER
,O,., oo -
power level. ,,0
MIN ,.,’
POWER CCUTFIOL
OPERATION
5. Turbine brush 5. Floor nozzle
The two-way turbine brush has aThe two-way floor nozzle has alever
lever with two positions. with two positions.
(Caution) FLOOR: For vacuuming wooden
Do not clean bare floors with lever floors, linoleum or plastic
position “RUG”. covered floors.
This might damage the floor. RUG: -For” vacuuming rugs and
carpets.
,UG,D,A
FLOOR
FLOOR-RUG
il ILever
6.
7.
,’
[j
L/Ill ‘--
Dust indicator
The dust indicator shows when the paper bag or cloth bag is full. When the dust
indicator has turned from green to red, empty the bag.
(When checking the dust)
●
●
●
●
Set the power control to “MAX”.
Closa the suction control.
Lift the turbine brush or floor nozzle off the floor.
Remove the crevice tool. n/
DUST INDICATOR
Handy attachmen~ compartment
The compartment stores adusting brush, upholstery brush, crevice tooi and fra~
graneecartridge, aquick salectionfor ali your cleaning needs. Depressthe “PUSH”
mark to open the tool cover.
–3– –4–
ml

ATTACHMENT USE HOW TO ENJOY FRAGRANf?F
~
ATTACHMENT Furniture Drapes stairs
Dusting
ax
brush –,-.. x x
Upholstery
brush &x x x
..
%
Floor -
nozzle ‘
THERMAL SAFETY DEVICE
LEI
.
3are
Ioors
.
x
x
—
x
—
ING Al
1
arpeted
floors
x
x
x
:EA
3=
Blanket Betweer
cushion
x
*
x
x
Ix
lugsWalls
x
x
x
x
Built in thermal safety device protects the cleaner motor from overheating. If the
cleaner hose or air intake clogs up with dust, or if the paper bag or cloth bag becomes
full and continues to run the cleaner, the cleaner will shut off automatically to prevent
the motor from overheating. If this happens, disconnect the plug from power outlet,
remove the clogged material or change paper bag or empty cloth bag and let the cleaner
cool down. Approximately one hour after, you can restart your cleaner, If the cleaner
will not start, please consult aSanyo Service Center.
If you prefer afragrance while cleaning, follow the steps below.
1. Push the “PUSH” mark to open the 2. Pull out the fragrance cartridge.
tool cover.
-1 (With Incense Metal And Perfume Bottle Type)
3. Take out the incense metal and Pour two or three drops of perfume
perfume bottle. on the incense metal and allow then
Then twist the cap of the perfume to soak In. After that Insert them
bottle and pull to open, back in the fragrance cartridge.
Twist. <‘Utl”
f)
Perfume bottle
4
e
\
mIncense metal
4, Closethe cover, 5, Insert the fragrance cartridge into the
hahdy attachment compartment and
close the cover.
–5– –6–
DEl

HOW TO USE THE “Mite Hunter”
●
●
Construction and Method of Extermination
The “Mite Hunter” exterminates mites in two steps. First, mites are vacuumed into
adisposable paper bag or cloth bag. Then they are exterminated inside the filter at
temperatures of 50°C or higher by exhaust fumes circulated from the motor. (Mites
cannot survive at temperatures above approx. 50”C)
Operation
1. Shut the sliding shutter.
If “Mite Hunter” button was Sliding shutter
pushed before you shut the slid.
ing shutter, “Mite Hunter” func.
tion will start automatically when
you shut the sliding shutter.
ZPush the “Mite Hunter” button, Light the Mite sign.
Start “Mite Hunter” operation.
Mite hunter
A%tton e
3. “Mite Hunter” operation.
The motor will circulate the hot exhaust fumes inside the filter approx. 2to
8minutes, and then automatically turn off.
(Caution)
.The “Mite Hunter” may become slightly hot during operation, and the dust indi-
cator may turn red. This occurs with normal use and is not acause for concern.
.If ambient temperature is high, immediate after operation of cleaner, “Mite Hunter”
may not function. In this case, try it again after 30 minutes.
–7-
DUST DISPOSAL
Turn the motor off, pull the hose out of the vacuum cleaner and empty out the dirt
as follows:
1. Open the dust compartment cover
by pulling out the clamp button.
Dust compartment
cover
(Cloth Bag Type)
3, Removethe cloth bagfrom the filter
frame and open the fastener of the
cloth bag, then empty out the dirt.
2. Take out the filter frame.
Filter fra
4, Close the fastener of the cloth bag
and set the cloth bag to the filter
frame.
wH
Groo
(Paper Bag Type)
3. Remove the paper bag from the 4. Set the new paper bag to the filter
filter frame and dispose the used frame.
paper bag. \\
H
G
(Caution)
Unless the paper bag or cloth bag is correctly mounted, dust compartment cover will
not close for safe use.
–8–
m

HOW TO USE THE HOSE STAND
The vacuum cleaner with theturbine brush or floor nozzle, wands, and hose can be
stored while still connected.
1. lnsertthe wand holder into thehole of the vacuum cleaner.
Wand holder
Hole
2, Attach thehose clip tothehose clip holder.
Hos~ clip holder 41’IF
—
L- “
Hose clip
holder Hose clip
3. la3ertthe plp@dfthe bbdding fo6itothe convex of thewafidhoider.
(Caution)
dding tool
Convex
Do not move or carry the vacuum cleaner while it is in the storage position, as the hose
or wands may fall out and become damaged.
–9–
Aseverely soiled or clogged filter should be thoroughly washed with fresh tepid water.
Aneutral detergent could be used if required.
1. Washing
2. Drying
Cloth bag (Cloth Bag Type Only)
@io
Remove the filter
water.
(Caution)
and rinse it with
Never insert the cloth bag or filter into
the vacuum cleaner unless it is com-
pletely dry.
&
o
[o
.-----
I=.-
Cloth bag
Filter
CARE OF TURBINE BRUSH
Before caring for the turbine brush, be sure to turn OFF the switch of the unit and dis-
connect the plug from the outlet.
if needles, pins or waste paper get stuck in the suction inlet, remove them after going
through the aboveprocedure,
Trying to removethem during operation isdangerous. 4
IMPORTANT (Paper BagType Only)
●Use only genuine Sanyo paper bagsto assurebest results.
.Genuine Sanyo bags are available through your dealer.
(Be sure to state the type number SC-P8)
-lo–

CARE AND MAINTENANCE
If you have aproblem with your vacuum cleaner, consult the handy guide
below. If the vacuum cleaner is malfunctioning, do not operate it. Contact
your dealer or the nearest Sanyo Service Cent~r. “
Problem Possible cause Possible solution
(1) Cleaner won’t 1. Not firmly plugged in. 1. Plug unit in firmly.
run. 2. No voltage in wall outlet. 2. Check fuse or breaker.
3. Thermal safety device 3. Refer to page 5“Thermal
operated. safety device”.
Approximately one hour
later, you can restart the
cleaner.
(2) The dust indi- 1. Paper bag or cloth bag 1. Change throw away paper
cater moves full. bag or cleaning cloth
immediately to bag.
the red zone. 2. Filter dirty. ‘2. Clean out the filter.
(3) Cord doesn’t 1. Cord twisted or uneven. 1. Pull out cord and rewind.
fully rewind.
SANYO Electric Co., Ltd.
OSAKA, JAPAN
9BF-6-Pill-00521 @ @ Printed in Japan
