Sapcon CAPVEL-ICT User manual

CAPVEL-ICT
Capacitance Level Transmitter
INSTRUCTION MANUAL
Version 2.0

User Manual & Datasheet V 2.1
Contents
RevisionHistory................................................... 4
1Introduction.................................................... 5
2OperatingPrinciple ................................................ 5
3SystemDescription ................................................ 5
4Features...................................................... 5
5Applications.................................................... 5
6Capvel-BTFeatures................................................ 5
7Capvel-ICTFeatures ............................................... 5
8MechanicalSpecification ............................................. 6
9ElectricalSpecification .............................................. 6
10MeasurementSpecification ........................................... 6
11InstallationGuidelines .............................................. 7
11.1TankMountingInstallation ......................................... 7
12ElectricalConnections .............................................. 7
13Calibration .................................................... 7
14ErrorDisplayandRemedy............................................ 10
15MenuandDescription.............................................. 11
16 RS-485 Serial Commands for Communication with Capvel . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
17Settings...................................................... 13
18Maintenance ................................................... 13
19Support Training ................................................ 13
20CustomerSupport ................................................ 13
List of Figures
1 Capvel ..................................................... 5
2 ConnectionDiagram.............................................. 5
3 Calibration................................................... 8
4 TankStrapping ................................................ 9
Sapcon Instruments Pvt.Ltd. R
2

User Manual & Datasheet V 2.1
List of Tables
1 MechanicalSpecifications........................................... 6
2 ElectricalSpecifcations ............................................ 6
3 MeasurementSpecifications.......................................... 6
4 ErrorDisplayandRemedy........................................... 10
5 Menu...................................................... 11
6 Menu...................................................... 12
7 PercentageLevelInformation......................................... 12
8 Configuring and Asking Sensor ID on Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Sapcon Instruments Pvt.Ltd. R
3

User Manual & Datasheet V 2.1
Revision History
Revision Date Author(s) Description
1.0 18 Jan 2014 RND First Version Editing
1.1 25 Aug 2014 MRK Applications Revision
1.2 28 Jun 2015 RND Features Revision
1.3 10 Dec 2015 RND Specs Revision
1.4 23 Jul 2016 RND Specs Revision
2.0 08 Jan 2017 BRND Revised Format
2.1 17 Sep 2017 BRND Branding Revisions
1
1
•Copyright: All content on this document, such as text, graphics, logos and images is the property of Sapcon Instruments Pvt. Ltd.
The selection, arrangement and presentation of all materials on this document and the overall design of this document is the exclusive
property of Sapcon Instruments Pvt. Ltd.
•The images shown in this manual may differ from the actual instrument / housing in terms of dimensions, color and design. Please refer
to GA drawings for dimensional details.
•Values (of performance) described in this manual were obtained under ideal testing conditions. Hence, they may differ under industrial
environment and settings.
General Instructions
•Instrument shouldn’t block the material filling inlet.
•Secure the cover of housing tightly. Tighten the cable glands. For side mounting, the cable glands should point downwards.
•For side mounting, provide a baffle to prevent the material from falling on the probe.
•When handling forks, do not lift them using their tines. While using them with solids, ensure that material size is less than 10mm.
•Deforming the shape of the tines may interfere with the fork’s operating frequency.
•Make all electrical connections as instructed in the manual. Don’t power on the device before verifying the connections.
Sapcon Instruments Pvt.Ltd. R
4

User Manual & Datasheet V 2.1
1 Introduction
2 Operating Principle
CAPVEL is composed of specially developed capaci-
tance change gauging circuit. It uses fast RISC based
processor to perform all the complicated jobs of evaluat-
ing the level out of the capacitance. This capacitance is
formed by the sense rod and the metallic container wall,
where containers are non-metallic or non-uniformly wide
or having turbulent fluid, a metallic stilling well is pro-
vided. The amount of capacitance is proportional to the
level of material between the sense rod and metallic wall
of stilling tube or container.
Figure 1: Capvel
3 System Description
CAPVEL is composed of cast aluminium housing,
supplied with suitable mounting arrangement viz.NPT,
BSP or Flanges and two metallic cable entries. An
external Earthing / Grounding terminal is also provided.
The sensing rod which is mostly Teflon coated. This
sensing rod can be replaced by flexible probe for some
applications. The stilling tube is also provided for
turbulent fluids, irregular width tanks, non-metallic
tanks or for fluids with low dielectric (e.g. diesel).
Opening the threaded aluminium cover, an electronic
insert could be found. This is the electronic unit which
converts the level into 4-20 mA signal depending on the
calibration. The status LED is a bi-color LED that blinks
alternately in Red and Green to indicate instrument is in
process of converting the level to 4-20 mA signal. Two
DIP switches are provided to calibrate the 4 mA and
20 mA points. The calibration is easy and a complete
procedure is given in "Calibration" page. The two wires
connected at the back are pre-connected sensor wires
and should not be disturbed. Also while calibration try
to keep hands away from the wires of terminal 6 and 7.
Now referring to the "Connection Diagram", Capvel can
be wired in two possible combinations. Preferred one
is galvanically isolated, 4-wire combination where only
one source of power is available, 3-wire, non-isolated
combination can also be used. The converted level signal
can be sensed using a 4-20 mA indicator or PLC 4-20
mA input or multimeter in 40 mA range or any-other
device that takes 4-20 mA signal as input.
4 Features
5 Applications
6 Capvel-BT Features
•User Interface : 2 DIP switches + 2 LED
•Output-1 : 4-20 mA, Galvanically Isolated
•Output-2 : Rs-485 Digital Data
7 Capvel-ICT Features
•User Interface : 4 Digit Display with 4 Keys + 2
LED
•Output-1 : 4-20 mA, Galvanically Isolated
•Output-2 : Rs-485 Digital Data
•Output-3 : Controlling Devices connected with Ex-
ternal Relay
3-wire Single Supply Operation
mAmp
Maximum Internal Resistance of Indicator/PLC/Scanner
[(Sensor Supply - 4V) x 50] Ohm
Indicator or
Scanner
or PLC
4-20mA
mAmp
Maximum Internal Resistance of Indicator/PLC/Scanner
[(Loop S upply - 4V) x 50] Ohm
Indicator or
Scanner
or PLC
4- 20mA
4-wire Dual Supply Operation ( Galvanic Isolated )
J umpers
( Towards ISO )
J umpers
( Towards LOOP )
I
S
O
L
A
T
I
O
N
Figure 2: Connection Diagram
Sapcon Instruments Pvt.Ltd. R
5

User Manual & Datasheet V 2.1
8 Mechanical Specification
For Mechanical Specification please refer Table 1
PARAMETER VALUE
Housing Cast aluminium weather and Flame proof suitable for
mounting in hazardous area Gas Group IIA and IIB as per
IS-2148
Mounting
•Integral with sense rod or probe with SS /MS(plated)
•Screw - 1"/1 1/2" BSP/NPT (M)
•Flanged - (As per your order)
Cable Entry 2 X 1/2"/3/4" BSP/NPT, Brass
Gland type Double Compression Gland
Sensing Fully or Partially Teflon Coated Rod, Flexible Probe SS316
Stilling Tube Pipe, GI / SS
Overall Dimensions Please refer enclosed probe drawing
Table 1: Mechanical Specifications
9 Electrical Specification
For Electrical Specification please refer Table 2
PARAMETER VALUE
Mains
•Capvel-BT : 9V to 55V DC
•Capvel-ICT : 9V to 30V DC
Power Consumption
•Capvel-BT : Max. 0.5 watt @12 V
•Capvel-ICT : Max. 1 watt @12 V
Table 2: Electrical Specifcations
10 Measurement Specification
For Measurement Specification please refer Table 3
PARAMETER VALUE
Measurement Span 15 to 3000 pf above Zero
Response Time 0.5 to 5 secs.( Adjustable )
Accuracy +/- 1% FSL or better
Electronics Ambient Temp. 0◦C. to +60◦C
Fail-Safe Feature Reverse Calibratable (Low Level: 20 mA, High Level: 4
mA)
Table 3: Measurement Specifications
Sapcon Instruments Pvt.Ltd. R
6

User Manual & Datasheet V 2.1
11 Installation Guidelines
Note:
During installation, all electrical connections must
be powered OFF and the fuel tank must be empty.
11.1 Tank Mounting Installation
Note:
It is recommanded that the tank must be empty
while following steps in this section.
12 Electrical Connections
13 Calibration
Sapcon Instruments Pvt.Ltd. R
7

User Manual & Datasheet V 2.1
0% Level
100% Level
Fill the tank at Low Level
0% Level
100% Level
1
2
3
Lower Calibration has done !
1
Calibrating L ower L evel
Procedure of Calibration
When material is at 0% or 4mA level.
Now the Sensor is in RUN MODE again !
We can Calibrate 4mA and 20mA in any order according to our choice.
The order of empty-fill or fill-empty is immaterial.
C alibrating H I GH L evel
Upper Calibration has done !
DOWN
2
Press and Hold This K ey
UP
For 3 Seconds
Wait for around 5 Seconds
3
Wait for around 5 Seconds
Press and Hold This K ey
For 3 Seconds
Fill the tank at High Level
High-SCAL%
Low-SCAL%
Figure 3: Calibration
Sapcon Instruments Pvt.Ltd. R
8

User Manual & Datasheet V 2.1
0%
43.75%
100%
4.0mA
11.0mA
20.0mA
14 L (Offset)
72+6=78 L
=28/7=4 L /mA (Linear)Volume/mA
Change of volume per mA is linear from bottom to mid level, while it is non-linear at top
(volume per mA decreases as level approaches 20mA)
PLC thus should convert level (mA) to volume from 4 to 11.0 mA linearly as :-
Volume =Offset Volume+Change of Volume per mA x (measured mA - 4)
However, as soon as non-linear range starts (11.0mA) PLC should begin level to volume conversion differently.
The tank now should be strapped into a number of small zones (of level) where volume within each zone could be safely
considered linear. Then as long as level stays between those individual straps, volume can be calculated as
Volume =Previous Volume +(difference of volume / difference of mA) x (measured mA - 4)
Previous level is volume measured before existing strap
Difference of volume is Maximum Volume - Min Volume within the strap
Difference of mA is Maximum mA - Min mA within the strap
Measured mA is mA just received by PLC
For example shown above, Volume of tank at various mA is:
= 14L+(28L/7mA) x(measured mA-4) if measured mA is between 4.0mA & 11.0mA
11.0mA & 13.25mA
= 54L+(10L/2.25mA)x(measured mA-4) if measured mA is between 13.25mA & 15.5mA
= 64L+(8L/2.25mA) x(measured mA-4) if measured mA is between 15.5mA & 17.75mA
= 72L+(6L/2.25mA) x(measured mA-4) if measured mA is between 17.75mA & 20.0mA
= 42L+(12L/2.25mA)x(measured mA-4) if measured mA is between
Volume at various strapping level can be found by taking notes of amount of fluid needed to raise the level, or it can be
calculated mathematically from tank dimensions.
Also, the more the number of straps the better the approximation is.
Strap1
Strap2
Strap3
Strap4
Offset Volume
57.8125%
71.875%
85.9375%
28+14=42 L
Diff of mA =2.25mA
Diff of Vol=12 L
Diff of mA =2.25mA
Diff of Vol=10 L
Diff of mA =2.25mA
Diff of Vol=8 L
Diff of mA =2.25mA
Diff of Vol=6 L
13.25mA
15.5mA
17.75mA
42+12=54 L
54+10=64 L
64+8=72 L
Volume/mA =12/2.25=5.33L/mA
Volume/mA =10/2.25=4.44L/mA
Volume/mA =8/2.25=3.56L/mA
Volume/mA =6/2.25=2.67L/mA
Diff of mA =7 mA
Diff of Vol=28 L
Measurement
begins from here
Tank
Sense Probe
Method of approximating volume of fluid in tanks
for P LC/SCADA using 4-20mA output
irregular shape
CAP VE L
Caution :- Devices that work on capacitance principle for measurement of level of fluids, are for indicative
purpose only. These devices should never be used for inventory control, weights and measures or any other
place where highly accurate measurement of fluid level/volume/weight etc is needed.
Figure 4: Tank Strapping
Sapcon Instruments Pvt.Ltd. R
9

User Manual & Datasheet V 2.1
14 Error Display and Remedy
For Error Display and Remedy please refer Table 4
CODE ERROR DISPLAY ERROR DESCRIPTION TROUBLESHOOTING
1 PrOP Probes are OPEN circuited Check the probes with
multimeter
2 PrSC Probes are SHORT cir-
cuited
Check the probes with
multimeter
3 ECAL Calibration Error Calibration is wrong,
Please recalibrate correctly
4 PrHI Over Capacitance Tank and probe dimen-
sions are not matched
5 PrLO Under Capacitance Tank and probe dimen-
sions are not matched
6 RFOP Internal reference got open
circuited
Internal fault in sensor
7 RFSC Internal reference got short
circuited
Internal fault in sensor
8 RFHI Internal reference satu-
rated
Internal fault in sensor
9 RFLO Internal reference negligi-
ble
Internal fault in sensor
10 OSC Oscillations stopped Internal fault in sensor
Table 4: Error Display and Remedy
Sapcon Instruments Pvt.Ltd. R
10

User Manual & Datasheet V 2.1
15 Menu and Description
For Menu please refer Table 5 and 6
MENU SUB MENU CHANGE DESCRIPTION REMARK
rLdr (Relay Drive) r. FS FS. H <>FS. L Fail Safe Selection
FS.H/ FS.L:Fail Safe
High/Low
rLdr (Relay Drive) r.oPt o.Ind<>o.PUM Control Action Selection
Ind : Individual, PUM :
Pump
rLdr (Relay Drive) r. SP S.000<>S.100 Set point Only in Indi-
vidual Controlling
rLdr (Relay Drive) r.SPH h.001<>h.100 Higher Set point Only in
Pump Controlling
SPH must be higher
than SPL
rLdr (Relay Drive) r.SPL L.000 <>L.099 Lower Set point Only in
Pump Controlling
SPH must be higher
than SPL
rLdr (Relay Drive) r.Cd C.000 <>C.100 Cover Delay in Seconds
rLdr (Relay Drive) r.Ud U.000 <>U.100 Uncover Delay in Sec-
onds
SCAL (Scal Factor) SC.-H H.020<>H.100 Higher SCALE LEVEL SCAL-HIGH must be
20% or more Higher
than SCAL-LOW
SCAL (Scal Factor) SC.-L L.000<>L.080 Lower SCALE LEVEL SCAL-HIGH must be
20% or more Higher
than SCAL-LOW
dISP(Display) d.PER<>d.AmP Display Options PER
: Percentage, AmP :
mAmp
Table 5: Menu
Sapcon Instruments Pvt.Ltd. R
11

User Manual & Datasheet V 2.1
MENU SUB MENU CHANGE DESCRIPTION REMARK
trbu (Turbulence) t.001 <>t.010 Turbulence Immunity
vts (Vehicle Mode) 1 = ON 0 = OFF Immunity to vehicle gen-
erated fluctuations
Only usefully in Vehicle
Tracking Systems
c. ID Id.00 <>id.99 Communication ID of
Sensor on RS-485 Net-
work
Com (Communication
Settings)
c.bAU b.00.3<>b.38.4 Communication Baud
Rate 9.6 x 1000 =
9600bps and so on
Com (Communication
Settings)
c.Flo F.CMd<>F.AUt Flow Control
•CMD : Send data
when Commanded
•AUT : Send Data
Automatically
Com(Communication
Settings)
c.dur d.001<>d.250 Auto Data Sending Du-
ration in Seconds
(Flow : AUT)
othr o.LEN LE0.0 <>LE9.9 Probe Length in meters Only for optimization
othr o.PRF PR.1 <>PRF.9 Profile Only for optimization
InFo i.SEr 12345678 Serial No Factory Sated and Read
Only
InFo i.dAt 12345678 Mfd. Date in DD-MM-
YY format
Factory Sated and Read
Only
Table 6: Menu
16 RS-485 Serial Commands for
Communication with Capvel
For RS-485 Serial Commands please refer Table 7
COMMAND DESCRIP-
TION
COMMAND TO BE
SEND TO SENSOR
EXPECTED RESPONSE
FROM INSTRUMENT
EXPLAINATION
Level would be calculated
by dividing incoming five
digit number with 10.Please
note that:- Application Soft-
ware must have to take care
of any possible errors dur-
ing turn-on or off durations,
change in nature of service
material etc.
<A,PER?>or
<B,PER?>or
<a,PER?>or
<z,PER?>or
<Z,PER?>
<A,PER=01000,H>
<B,PER=01000,N>
<a,PER=00625,N>
<z,PER=00000,N>
<Z,PER=00000,L>
100.0% (OVER)
100.0% (NORMAL)
62.5% (NORMAL)
0% (NORMAL)
0%(LOW)
Table 7: Percentage Level Information
Sapcon Instruments Pvt.Ltd. R
12

User Manual & Datasheet V 2.1
COMMAND DESCRIP-
TION
COMMAND TO BE
SEND TO SENSOR
EXPECTED RESPONSE
FROM INSTRUMENT
EXPLAINATION
Asking single letter ID of in-
strument on RS-485 network
<*,ID?> <A,ID?-A> Instrument is telling it’s ID
Setting single letter ID
of instrument on RS-485
network.Example-setting id
as:- ’A’ (Capital A)
<*,ID=A> <A,OK> ID is taken by instrument
and this is the acknowledge-
ment from it
Table 8: Configuring and Asking Sensor ID on Network
17 Settings
18 Maintenance
19 Support Training
20 Customer Support
Thank you for going through the instructions given in this manual. To further ease the process of installation and use,
we have developed special demo videos which are hosted on YouTube.
Sapcon’s YouTube channel, SAPCON INSTRUMENTS, lists all these videos: https://goo.gl/dnxfcz
Should you require further information regarding installation, use or working of the instrument, please don’t hesitate
to contact us. Kindly provide the following information at the time of contacting:
•Instrument Model and Serial Number
•Purchase Order Number and Date of Purchase
•Description of the query
•Your contact details
In an attempt to serve you better, we are open seven days a week (9:30am to 7:30pm). We are available at:
•www.sapconinstruments.com
•[e-mail]
•[phone]
Sapcon Instruments Pvt.Ltd. R
13
