U S E R M A N U A L
HDMI-CAT-HDMI Extender
Model No: HDEX007M1
Enjoy the i id world!

INTRODUCTION
Dear customer
Thank you for purchasing this product. For optimum performance and safety, please read
these instructions carefully before connecting, operating or adjusting this product. Please keep
this manual for future reference.
Our series of HDM converters, switchers, extenders, matrixes and splitters are designed to
make your A/V device use more convenient, more comfortable, more productive and more
cost-efficient.
The HDEX007M1 Extender use Single cat-5E or cat-6(recommended) cables up to 50 meters
instead of HDM cable to transmit high definition signal, for cutting down cost. Long distance
transmission of high definition is very difficult because HDM cable is very expensive and
infrequent. The Extender is designed to supply for long distance transmission of high definition
signal.
Our devices offer solutions for noise, space and security concerns, data center control,
information distribution, conference room presentation, school and corporate training
environments.
FEATURES
 Support video input : 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
 Use one cat5e/cat6 cable to transmit the HDM Signal and R signal, the max cat cable
length can be up to 50m.
 Support video output : 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
 Support Resolution up to 1080P/60HZ.
 Support R extender, it can do long distance control to the HD Source by using the R
received at the receiver.
 Support EDID Management and Control
 CAT connections according to IEEE-568B
 LED indication: when power is supplied or device is working, LED relative to is light.
 No loss of quality
 nstalls in minutes
 Need DC5V/1A power supply

The accessories with the machines lists as picture：
：：
：
1、HDM Transmitter 1PCS
2、HDM Receiver 1PCS
3、Windband R Tx cable 1PCS
4、windband R Rx cable 1PCS
5、 5V/1A power adapter 1PCS
6、 User manual 1PCS
Physical Connection Showing Picture：
：：
：
Picture1.0 Transmitter Port Showing Picture
HDM n: HDM Signal nput Port
ED D: EDID EDID Control Switch when switch set to left, it is default EDID when switch set to right, it will copy
the EDID of HDMI Output connected TV.
HDM Loop Out: HDM Signal Loop Output Port for connecting the HDM Display or TV.
R Out: R Output Port for insert the TX R Blaster cable (can be used by match the RX R
Cable).
：Signal Status Led Light, the Led Light will go bright when cat cable connection is ok.

CAT： RJ45 Port: it can use one standard cat cable to connect the transmitter with the
receiver.
: Power Led Light: it will go bright when power is connected.
DC 5V: 5V DC Port
Picture 1.1 Receiver Port Showing Picture
EQ：Equalizer Switch
EQ Set-Up Tips
Position Cat Cable Length Position Cat Cable
Length
<15m 15-30m
30-40m 40-50m
HDM Out: HDM Signal Output Port for connecting the HDM Display or TV.
R n: IR Input Port for insert the IR Receiver cable (it can be used by match the TX IR Cable).
： Signal LED Status Light: the Led Light will go bright when signal output is working
without problem.
CAT：RJ45 Port: it can use one standard cat cable to connect the transmitter with the receiver.
: Power Led light, it will go bright when cat cable connection is ok.

IR Extender Function Introduction
1、30KHz-50KHz Wide-band R Frequency Support Range:30 KHz-50 KHz
2、To insert the TX R Blaster Cable to the R OUT port and put the R Head at the front of the
TV
3、To use the RX R Receiver Cable to the R N Port and use the Remote to point at the R
Receiver Head to do control and can transmit the R signal to the RX R Cable by cat cable.
4、TX R and RX R Pins Diagram：
Operating and Connecting：
：：
：

1. To use one HDMI Cable(up to 5m) to connect the HD Source with the HDMI Input
port of the Transmitter
2. To use one HDMI Cable(up to 8m) to connect the HDMI Output port of the
transmitter with the HD Display
3. To use one HDMI Cable(up to 8m) to connect the HDMI Output port of the
receiver with the HD Display
4. To use one cat 5e or cat 6 cable to connect the transmitter with the receiver( the
cat cable length can be up to 50m)
5. connect the 5V power adaptor to the extender
SPECIFICATIONS:
HDEX007M1
Length of CAT-6 cable between Rx and TX.....Up to 50 meters

HDM nput...........24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
HDM Output........24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
Max bandwidth...165MHz
Max baud rate......4.95Gbps
nput Video signal ...... 0.5~1.5Volts p-p
Output DDC signal  5Volts p-p (TT1L)
nput/Output HDM cable distance....≤5m AWG26 HDM standard cable
Max working current......600mA
Power adapter format.. nput: ...AC (50HZ, 60HZ) :100V-240V; Output: DC5V/1A
Operating Temperature range...-0 to +40℃
Storage Temperature range -20 to +60℃
Operating Humidity range...5 to 85%RH (No Condensation)
Storage Humidity range...5 to 95%RH (No Condensation)
Dimension (L x W x H) .67X61X21 (mm)
Weight.......226g
Notes:
Pls use the machine as the instruction listed to keep the long use lifetime of the machine.
1. The machine should be placed at the spot far from the Damp, High-Temperature, Dusty,
Erosive, and oxidative environment.
2. All parts will be free from the strong shake, hit, fall.
3. Touching the power adaptor with the wet hands is prohibited.
4. Pls hold the power adaptor head and do not pull the power cord when cut off from the
socket.
5. Pls turn the power off when the machine is not used for long time.
6. Pls do not open the cover and do not touch the inside parts.
7. Pls use the original factory power adaptor.
Before power on, pls check the connection line carefully. And make sure that all interfaces

are normally connected. The common trouble shooting way shows below:
Serial NO
Trouble
Description
Cause and Ways to deal with
1
Non-Power-
Connected
1、Check if the power adaptor head is truly and
correctly inserted the power socket.
2、Check the power switch if it is in on status.
2 No Picture
1、Pls to make sure that the TV is on and has been
connected with the machine.
2、To check if the signal source is on and well
connected.
3、Check the system connection quality.
4、Check if the line is all good quality.
5、Check the cable quality
3 Obscure Picture
1、To try again to connect the cable to be free from the
unsuccessful connection.
2、HDM Cable Quality
