Satcom Resources WC1000 User manual

Metrodata WAN-in-a-CAN
WC1000 LAN Extender
Installation Guide
WC1000

INTRODUCTION
1
1 INTRODUCTION
1. 1 About the WC1000
The Metrodata WC1000 is a four port auto sensing 10/100BaseT Ethernet Switch with an E1
Uplink. The product can be used to extend four LAN ports across a WAN link to a remote
site. Each LAN port may be connected to a single LAN workstation or to a hub or switch
supporting multiple workstations. The exact configuration will depend upon the user’s
network design and workload characteristics.
The WC1000 Ethernet Switch can switch between local LANs connected to its four ports,
and the unit may thus reduce the need for local LAN hubs and switches. The Ethernet switch
has full wirespeed filtering so that the WAN port carries only traffic destined for the remote
WAN-linked site, and an efficient HDLC encapsulation of packets ensures maximum
throughput over the WAN link. There is internal packet buffering to smooth out bursty traffic.
WC1000’s are used in pairs, one on either side of a WAN link.
Figure 1. 1 WC1000 installation
WAN

INTRODUCTION
2
1. 2 Performance
Switching and filtering is performed at wirespeed: 148810 packets/second. The WC1000
can handle a traffic level of 4064 packets/second over the E1 link.
1. 3 Safety
The WC1000 should not be connected to cabling which would be required by BS6701 to be
equipped with over-voltage protection. The following ports are designated SELV (Safety
Extra Low Voltage) within the scope of EN41003:
E1 Line (or WAN) port (BNC or RJ45)
4 x 10/100 BaseT Ethernet ports
These ports should only be connected to SELV ports on other equipment in accordance with
EN60950 clause 2.3.
1. 4 Electromagnetic Compatibility
In order to ensure EMC compliance all signal and data cables and connectors must use a
screened connector shell with a screened cable. The cable screen must be terminated to the
screened connector shell and not connected to any pins of the connector. Failure to use the
correct connector may compromise EMC compliance.
1. 5 EN55022 Declaration
The WC1000 is a Class A product. In a domestic environment it may cause radio
interference in which case the user may be required to take adequate measures.
1. 6 FCC Declaration
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radiocommunications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at its own expense.

WC1000 DESCRIPTION OF PARTS
3
2 WC1000 DESCRIPTION OF PARTS
2. 1 Rear panel
All connections into and out of the WC1000 are made through the rear panel which is shown
in schematic form below for both AC and DC powered models.
Figure 2. 1 WC1000 rear panels for AC & DC models
2. 2 Status display - rear panel
There is a status LED on the right hand side of the rear panel which indicates the status of
the unit as shown in the figure below.
Figure 2. 2 Rear panel status LED
2. 3 Status display - LAN ports
Each LAN port RJ45 connector on the rear panel has two miniature LEDs mounted on it. The
left hand (green) LED shows link activity, and the right hand (yellow) LED shows operation
at 100Mbps when it is illuminated.
Status LED Meaning
Off No mains power present
On Green Status OK
On Red E1 WAN port LOS Alarm
SUBSCRIBER PORT 10/100 BASE T
Green: Link/Act
Ye l l o w : S p e e d
Tx Rx
Line
Activity
1234
SUBSCRIBER PORT 10/100 BASE T
Green: Link/Act
Yellow: Speed
Tx Rx
Line
Activity
1234
Pin1
-48V
Pin3
0V
L
_
_

WC1000 DESCRIPTION OF PARTS
4
2. 4 Power Supply
The WC1000 is powered by a mains supply with an input voltage of 100-250VAC 50-60Hz
and with an input current of 60 to 24 mA, and an input power consumption of 6 watts
approximately.. The WC1000 is provided ex-factory with a 250mA internal fuse. Mains
power is connected via the IEC inlet on the rear of the unit.
An alternative -48VDC powered unit is available. The input voltage and current ranges are
minus 36 to 72 volts DC, 200 - 100mA. A Buccaneer type socket is fitted to the rear panel,
and a plug is provided with the unit for the customer’s own wiring. The connections are
labelled on the rear panel of the WC1000.
On some units, an additional Ground stud may be located on the rear panel to permit a
separate Ground connection to be made.
Figure 2. 3 -48VDC connections
Note: The WC1000 must be connected to mains safety earth for correct operation.
Excessive voltages are present inside the unit. There are no user serviceable parts inside
the unit, and the cover should not be removed by unqualified personnel. The unit must not
be exposed to damp or condensing conditions.
2. 5 Unbalanced BNC E1 Line port
The network is connected to the BNC connectors at the rear of the unit as shown below:
Figure 2. 4 BNC connection
Cable lengths should be restricted to those defined below. The total maximum attenuation
of each of the cables attached to the network port must not exceed 6dB when measured at
1⋅024 MHz. The frequency/attenuation characteristic of the cables attached to the network
port shall follow a root frequency law.
Figure 2. 5 Cable lengths
Pin no Connection
1-48VDC
2 Ground
30VDC
Pin Function
Tip Signal
Ring Shield
Cable Max Length (metres)
UR202 720
RG59U 600
BT2002 650
BT2003 680

WC1000 DESCRIPTION OF PARTS
5
2. 6 Balanced RJ45 E1 Line Port
The layout of the female RJ45 line or network port mounted on the rear panel is shown
below:
Figure 2.6 RJ45 network port layout
2 . 6. 1 Connecting to a terminal device
A connecting cable from the network port to a terminal port such as a router or a PABX is
straight through. Connections are defined in the table below.
Figure 2.7 Connection from WC1000 to terminal device
Pin Function
1Tx tip
2Tx ring
3Tx shield
4Rx tip
5Rx ring
6Rx shield
7Not connected
8 Not connected
DSU
port pin
DSU port
function
Terminal port
pin
Terminal port
function
1Tx tip 1Rx tip
2Tx ring 2Rx ring
3Tx shield 3Rx shield
4Rx tip 4Tx tip
5Rx ring 5Tx ring
6Rx shield 6Tx shield
7Not connected Not connected Not connected
8 Not connected Not connected Not connected

WC1000 DESCRIPTION OF PARTS
6
2 . 6. 2 Connecting to a network device
A connection from the network port to a network device such as an E1 line or an NTU
requires a crossover cable. Connections are defined in the table below.
Figure 2.8 Connection from WC1000 to network device
2 . 6. 3 RJ45 Connector layout
Figure 2.4 shows both the plug and socket head on so that any connecting wires are behind
the connector. The connector numbering is shown.
Figure 2.9 RJ45 layout
DSU
port pin
DSU port
function
Network port
pin
Network port
function
1Tx tip 4Rx tip
2Tx ring 5Rx ring
3Tx shield 6Rx shield
4Rx tip 1Tx tip
5Rx ring 2Tx ring
6Rx shield 3Tx shield
7Not connected Not connected Not connected
8 Not connected Not connected Not connected
1234567
8
8 7 6 5 4 3 2 1
LOCKING TAB

WC1000 DESCRIPTION OF PARTS
7
2 . 6. 4 Cable lengths and types
Cable lengths should be restricted to those defined below:
Figure 2.10 Cable lengths
Note: The total maximum attenuation of the cable attached to the network port must not
exceed 6dB when measured at 1⋅024 MHz. The frequency/attenuation characteristic of the
cables attached to the network port shall follow a root frequency law. This port type is
approved to CTR12, CTR13.
Cable Max Length
(metres)
Belden 8132 (28 AWG) 175
Belden 9841 (24 AWG) 300

WC1000 DESCRIPTION OF PARTS
8
2. 7 LAN ports
The four LAN ports are supported by an array of four RJ45 female connectors mounted on
the rear panel of the WC1000.
These ports automatically sense the LAN interface and switch between MDI and MDI-X
configurations. This removes the potential requirement for Crossover cables when
connecting LANs to the WC1000 whatever LAN equipment is being used. The ports also
automatically sense the LAN speed and operate at either 10 Mbps or 100 Mbps, and sense
whether operation should be in full or half duplex mode.
There is a miniature LED on the lower right corner of each RJ45 socket on the rear panel
which is illuminated yellow when operation is at 100 Mbps. The miniature LED on the lower
left corner of each RJ45 socket is illuminated green when the link is active.
The RJ45 connector layout for an auto-sensing MDI/MDI-X port is shown below:
Figure 2. 11 LAN port connector layout
The pin numbering for the connector is shown below:
Figure 2. 12 RJ45 connector layout
Pin No MDI Signal MDI-X Signal
1Tx Data +ve Rx Data +ve
2Tx Data -ve Rx Data -ve
3Rx Data +ve Tx Data +ve
4Not connected Not connected
5Not connected Not connected
6Rx Data -ve Tx Data -ve
7Not connected Not connected
8Not connected Not connected
8 7 6 5 4 3 2 1
LOCKING TAB

INSTALLATION & SET-UP
9
3 INSTALLATION & SET-UP
3. 1 Setting-up the bit-switches
The bit-switches on the base of the unit must be set-up before making any connections to
the unit. There is an explanatory label on the unit’s base which defines the bit-switch set-up
options and alarms.
Figure 3. 1 WC1000 Base Panel label
3 . 1. 1 Bit-switch definitions
The default settings of the bit-switch are shown in bold:
Figure 3. 2 Bit-switch definitions
Bit-switch Control On Off
1Timing mode Internal Loop
2E1 Port select BNC RJ45
3Loopback test None Remote
4Normal
5Normal
6Normal
7LAN Mode 100M FD Auto-negotiate
8Auto MDI/MDI-X Disabled Enabled
Serial No:
WC1000
LAN TO E1 CONVERTER (AC)
For product manual
and other information:-
www.metrodata.co.uk
Metrodata Ltd
TW20 8RY UK
Tel [phone]
Fax [phone]
17-08-299A
Part Number 80-05-541
OFF
ON
1 2 3 4 5 6 7 8
Bitswitch Control ON
1
2
3
4
5
6
7
8
Timing Mode
Internal
LAN Mode
Auto MDI / MDI-X
Port Select
BNC
Loopback
None
Normal
Normal
Normal
100 FD
OFF
Loop
RJ45
Remote
Auto-negotiate
Enabled
Disabled
Bold characters = Factory Default
Status LED
Off
On Green
On Red
Meaning
No mains power present
OK
WAN Port LOS

INSTALLATION & SET-UP
10
3 . 1. 2 Timing
TIMING determines the source for the LINE E1 transmit clock, and is set by bit-switch no1.
The options are ON or OFF.
With the switch set to ON, the E1 transmit clock is derived from the WC1000's own
internal oscillator.
With the switch set to OFF, the E1 transmit clock is derived from the LINE E1 receive clock.
3 . 1. 3 E1 Port select RJ45/BNC
This single switch is used to select which type of connector (RJ45 or BNC) is to be used to
connect the E1 line.
With the switch set to ON, the BNC ports are selected to give G.703 75 ohm unbalanced
interface.
With the switch set to OFF, the RJ45 port is selected to give G.703 120 ohm balanced
interface.
3 . 1. 4 Loopback test
This switch is used to initiate loop testing. It is fully described in the next section.
The switch is set to ON for normal operation of the unit without any loopbacks.
With the switch set to OFF, Loopback is applied, so that Transmit data = Received data on
the E1 port.
3 . 1. 5 LAN mode
Bit-switch ON: 100 Mbps Full Duplex operation.
Note that this option enables 100M full duplex connection to be implemented. Auto-negotiate
does not distinguish between full versus half duplex modes when negotiating with a fixed
(i.e. non-negotiating) 100Mbps port.
Bit-switch OFF: Auto-negotiate Mode (default).
3 . 1. 6 Auto MDI/MID-X
With switch set to ON, the LAN ports are fixed as MDI-X for direct connection to a PC. This
may be necessary for reliability when connecting some older non-auto hubs
With switch set to OFF, the LAN ports automatically sense the interface and switch between
MDI and MDI-X connections.
3 . 1. 7 E1 Line port
No configuration of the E1 Line port is required. Operation is unframed. The Line Coding
setting is built into the unit (no bit-switch) and cannot be altered. It is HDB3 (High-Density
Binary 3). The maximum line rate is 2.048Mbps. The maximum corresponding packet rate
is 4064 packets per second.
3 . 1. 8 MAC FCS
On older units, bit-switch 7 enabled the transmission of the MAC FCS. This feature has now
been disabled and the WC1000 always strips the MAC FCS from the ethernet packet.

INSTALLATION & SET-UP
11
3. 2 Connecting up
Safety Notice: Ports that are identified as SELV in this manual should only be connected to
SELV ports on other equipment in accordance with EN 60950 clause 2.3.
Step 1: Mounting.
The WC1000 is housed in a convenient 1U table top enclosure. 19 inch rack-mount options
are also available, as well as rack nests for two or 18 units.
Step 2: Set up bit-switches
These switches are located on the base of the unit and are used to configure the unit.
Step 2: LAN ports
Connect the WC1000 to the LAN ports using the four labelled RJ45 ports on the rear panel.
Step 3: E1 LINE (WAN)
Connect the WAN by means of either the two BNC bayonet connectors labelled E1 LINE Rx
and E1 LINE Tx, or the single RJ45 connector located between the two BNC connectors.
Remember to set the PORT SELECT bit-switch to the correct connector type before
connecting.
Step 4: Power Supply
Finally, connect the main power lead and re-check all connections for security. Then turn on
the power supply. Check the rear panel status LED to ensure that it is continuously lit green.
Warning: Do not connect the WC1000 to excessive voltage. Read the safety information
before continuing.
3. 3 Optional rackmounting
Rackmounting kits may be used to mount two WC1000 units side by side in a 19” rack.
The first two of these kits have a flat mounting plate with separate cut-outs for power cables
and signal cables. 80-05-252 is suitable for AC mains powered units, while 80-05-254 is
suitable for units powered by -48VDC.
The third kit, Part no 80-05-256, has a recessed plate to permit fibre bends to be made within
the envelope of a 19” rack. It also has a single cut-out for all connections to the rear of the
WC1000. The installation method is the same in all cases.
First remove the two rear panel screws securing each unit’s lid. Fasten the two WC1000
units to the rackmount adaptor plate using the screws that you have removed, as shown in
the illustrations below.
Then secure the rack mounting plate complete with the two WC1000 units to the 19” rack
using the locating holes at the ends of the adaptor plate. If you have set the bit-switches on
the base plate of the units before fixing them to the adaptor plate, check that the settings are
still correct.

INSTALLATION & SET-UP
12
Figure 3. 3 2-unit flush AC & DC rackmount schematics
Figure 3. 4 2-unit recessed rackmount plan & elevation
SUBSCRIBER PORT 10/100 BASE T
Green: Link/Act
Ye llo w : Sp ee d
Tx Rx
Line
Activity
1234
SUBSCRIBER PORT 10/100 BASE T
Green: Link/Act
Ye llo w : Sp ee d
Tx Rx
Line
Activity
1234
SUBSCRIBER PORT 10/100 BASE T
Green: Link/A ct
Yellow: Speed
Tx Rx
Line
A
ctivit
y
1234
Pin1
-48V
Pin3
0V
L
_
_
SUBSCRIBER PORT 10/100 BASE T
Green: Link/A ct
Yellow: Speed
Tx Rx
Line
Activity
1234
Pin1
-48V
Pin3
0V
L
_
_
Recessed space to accommodate fibre bends
WC1000 WC1000
Part No: 80-05-256
SUBSCRIBER PORT 10/100 BASE T
Green: Link/Act
Ye llo w : Sp ee d
Tx Rx
Line
Activity
1234
SUBSCRIBER PORT 10/100 BASE T
Green: Link/Act
Ye llo w : Sp ee d
Tx Rx
Line
Activity
1234

ALARMS, TROUBLESHOOTING & TESTING
13
4 ALARMS, TROUBLESHOOTING & TESTING
4. 1 Alarms
The Status LED on the WC1000 rear panel shows alarm conditions as shown in the table:
Figure 4. 1 Rear panel LED alarms
4. 2 Troubleshooting
Step 1: Verify the power supply
Check the status LED on the right hand side of the rear panel of the unit at both ends of the
link. If either is OFF, power is not present on that unit. Check the mains connection to the
unit. If mains supply is satisfactory, we recommend that the unit be taken out of service and
returned to a repair centre. Unqualified users should not open the WC1000.
Step 2 Establish and verify the LAN links
Connect up to 4 LAN cables to the LAN ports. If the LED on the bottom left hand corner of
the RJ45 socket goes green, or flashes green, then there is a LAN connection. If the LED
remains dark, there is no LAN connection, and investigatory action should be taken on the
LAN and/or its cables.
Step 3 Establish and verify the WAN links
If there is LAN activity, then check for WAN activity by observing the green Tx and Rx LED’s
on the rear panel. If packets are being transmitted or received the LEDs will be ON. If they
are dark, there is no traffic being forwarded over the WAN link, or there is a problem with the
WAN link. This could be bit errors on the data lines, or no clocks present.
WC1000 with BNC connectors - Step 3A
If the status LED is red, first check that the PORT SELECT bit-switch on the base panel is
set to BNC. If it is set correctly, try swapping the E1 LINE BNC connections at that unit.
If the status LED remains red, try looping the BNC connections on the unit with a short piece
of cable. If the status LED goes steady green, then the external BNC cabling is faulty. Check
for cable continuity and network connections, etc.
WC1000 with RJ45 connectors - Step 3B
If the status LED is red, first check that the PORT SELECT bit-switch is set to RJ45. If it is
set correctly, check the connections on the RJ45 cable. Check for cable continuity and
network connections, etc.
The WC1000 provides a TE presentation for direct connection to the network equipment. If
LOS is experienced, a cross-over cable may be required.
Status LED Meaning
Off No mains power present
On Green Status OK
On Red E1 WAN port LOS

ALARMS, TROUBLESHOOTING & TESTING
14
Other steps
It may be useful to set the AUTO MDI/MDI-X bit-switch to DISABLED, in which case the port
presents a fixed MDI-X interface to the LAN.
Note that for 100M full duplex operation between the WC1000 and a fixed (i.e. non-
negotiating) LAN port, Bit-switch 7 must be set to 100M FD. If this is not done, the WC1000
will operate at the correct speed, but in half duplex mode, and with a heavy error count.
4. 3 Test Loop
Figure 4. 2 Test loop on remote WC1000
Set the remote WC1000 base panel bit-switch labelled LOOPBACK to the ON position.
When the TEST LOOP is activated at the remote WC1000, the signal received from the local
Bit Error Rate Tester (BERT) unit at the E1 port is passed directly back to the BERT at the
line interface.
If the local BERT recognises its own transmissions, then the E1 link has been validated.
Remote WC1000 Loopback Switch On
WAN-in-a-CAN
Bit Error Rate Tester
(BERT)
PRBS
Signal

WC1000 SPECIFICATIONS
15
5 WC1000 SPECIFICATIONS
Disclaimer
Metrodata Ltd makes no representations or warranties with respect to the contents hereof and specifically dis-
claims any implied warranties or merchantability or fitness for any particular purpose. Further, Metrodata Ltd
reserves the right to revise this publication and to make changes from time to time in the content hereof without
obligation of Metrodata Ltd to notify any person of such revision or changes.
Trademarks
The Trademarks of other Corporations which may be used in this manual are hereby acknowledged.
Copyright © 2006 by Metrodata Ltd
All Rights Reserved
E1 LINE Definition
E1 LINE Interface G.703 compliant, Sensitivity -10dB. Line coding HDB3.
Interface types:
75 ohm unbalanced coax (BNC) or 120 ohm balanced RJ45.
Interface selected by bit-switch
Jitter Tolerance Per G.823.
Barrier EN 41003 compliant barrier provided on the E1 interface
Framing Unframed
Encapsulation HDLC
Clocking options E1 Line: Internal or Loop: E1 line receive clock
Line Rate 2.048 Mbps
Maximum packet rate 4064 pps (packet per sec)
LED Indicators Tx/Rx Packet, Alarm
Alarms E1 LOS
Diagnostics External Loop Test initiated by bit-switch
Subscriber (LAN) Ports Definition
LAN Interface 4 x RJ45, Auto switched MDI or MDI-X, or fixed MDI selected by bit-switch
Operating mode Auto-negotiated 10/100 Mbps, Full / Half Duplex, or 100Mbps FD Fixed
Port filtering rate 148810 pps (packet per sec)
Port switching rate 148810 pps (packet per sec)
Switch mode Any to Any
MAC address table 4096 entries
Min/Max Packet size 64 bytes / 1522 bytes
General Definition
Power supply 100-250 VAC, 50-60 Hz, 60-24 mA or -36 to -72VDC, 200-100mA
Dimensions 202 x 132 x 44 mm (w x d x h) Enclosure only
202 x 132 x 47 mm (w x d x h) Overall including feet
Environmental Range
Ambient Temperature 0degC to +45degC
Storage Temperature -20degC to +70degC
Relative Humidity 0% - 95% non condensing
Barometric Pressure 86 KPa - 106 KPa
