Satvision IQ-200 User manual

Super Car-Cam
Patent . LDWS . Distance Alarm . 720P

Content
Foreword
Certificate
Product Accessories
Product Feature
Structure
Product Size
Key Functions
Quick Start Guide
Main interface introduction
Taking picture
Time Setup
Connecting With Computer
Product Specification
Charging
1
2
2
3
3
4
5
5
9
12
12
13
16
17
19
20
21
21
Video Setup
Picture Setup
Play Back
22
System Setup
Detailed user manual
23
Certificate

Foreword
Thanks for choosing our product.
When driving in highway, sometimes you will need a
friendly reminding.
However, among all fetal accidents, 44% is related with
changing lane. At the same time, changing lane is
thought as the main reason why a car overturns. Besides,
according to the analysis, 66% drivers ever sleep during
driving.
The above percentages are so surprising to prove the
necessity of LDWS.
Now with our accurate pixel analysis technology, it is not
only a car recorder, but also an affordable valuable safety
device. When you are changing lane or getting too close
to the front car, it will remind you of that, just like a
friend on the car does the same thing.
But please also be well noted, it could be Max 98%
accurate, due to all kinds of road situations and weather
conditions. Even for human we will sometimes make
wrong judgement, right?
Enjoy the kind reminding, enjoy recording on the road.
Thank you!
Please use the product as a tool only and use driver's
safety while driving.
1

Product Accessories
2
Certificate
The product is in conformity with CE/FCC and ROHS.It
is authorized to bear FCC/CE and ROHS mark
EU Environment Protection: Waste electrical
products should not be disposed of with household
waste. Please recycle where facilities exist. Check
with your local Authority or retailer for recycling advice
Camera
User manual
USB cable
9
Super Car-Cam
Pat ent . LDW S . Dista nce Al arm . 720 P
GPS bracket
(not included)
Car bracket
Power adaptor

Product Feature
With Lane departure warning system
With Distance alarm
720P 30FPS
Software speed calculation
Sharp Low-Light performance
With reset pen
Product Size
49.0MM
18.0MM
57.0MM
137.0MM
3

Structure
Car bracket socket
GPS Port
Micro-SD Port
Mode Next Previous Exit
OK
LCD Screen
Lens
USB Port
Power
360°
Fasten
Loosen
Install on windows
Reset hole
Mic
Reset pen
4
Adjustable
Speaker

Quick Start Guide
steps:
1).Put Micro-SD and power onin
2).Install the bracket on windows, the higher the better
Totally it has 6 keys：
: Hold on power for 3 seconds, it will power on.
Hold on power 3 seconds again, it will automatically
power off.
: To move back or forth to choose.
: Confirmation key, to start/stop recording; in
picture mode, take a picture. Hold on OK for 3 seconds,
you will get into the manual settings.
: One press to witch among video/photo display/
video display; hold on for 3 seconds to switch
LDWS ON/OFF
: To return to the previous.
Key Functions
Best position
Best position
5

6
Car windows
Certain angle
3).Install LDWS (Lane departure warning system)
3.1)Please drive to a road side which do not block other
cars but with clear lane lines. Adjust bracket angle to let
the camera have a certain angle as below picture . And
now you will have a clearview from LCD.
3.2).Hold on for 3 seconds,
and will appear ״ ״
in the LCD.
06/04/2013 13:25:30
HD
0 1 : 2 4
06/04/2013 13:25:30
HD
0 1 : 2 5
Hold on
3.3). Loosen the bracket, slightly adjust the camera.

7
In middle of the lane for distance alarm
To the border of car and on the road
Parallel with the two lane lines
1
2
3
is ״ ״
same as shown in the picture .
1
2
3
3.4) Please carefully check it, make sure
Then hold on again to let the interface disappear.
After finish adjusting the above, remember to fasten the
bracket as well as you could. So there is no necessary to
adjust it any more. And you could easily take the camera
up to the bracket before driving, or down from it after car
stopped. If there is many false warning , it means you
should possibly double check installation.
״ ״

4).Important Notice
It is a must that the lane lines be clearly visible; or the
lane departure warning and distance alarm will not be
accurate.
LDW shortcut key: You may easily turn on or turn off
LDW by holding on . For example,
you may turn on it before go into highway; turn it off
when you go out of highway.
5).Connect with car power, it will record automatically.
Once you are about 50km or above, it will make warnings
upon changing lane or getting close to the front car.
6).Check the video records. With recording stopped,
press OK and enter “play back”, you will see many
videos. Then hold on to play, to quit.
for 3 seconds
Congratulations! Now you already manage it successfully!
09/04/2013 13:21:48
HD
09/04/2013 13:21:50
HD
09/04/2013 13:21:51
HD
8
11
Play Back
1 2
4
65
3
MOV-20130904-6
Full screen
MOV-20130904-6
You may also connect it with PC by the USB cable,
just like a U-disk.

9
1).Important
This guide provides important information on the user
and operation of the product. All information could be
changed without notice due to system and firmware
upgrades. please read all the information carefully prior
to using the product for the best performance and to
prevent any damage/injuries or misuse of the device.
Customers are entitled to have read through this complete
user's manual before using the product. any unapproved
changes or modifications will void your warranty. please
ensure to have a complete understanding of the following
restrictions.
Note: Please check your local laws and regulations to
determine if windshield mounting is legal in your state
2).Restrictions
When using the product, the safety precautions below
must be taken to avoid possible legal liabilities and
damages. Retain and follow all product safety and
operation instructions. Observe all warnings in the
product operating instructions. To reduce the risk of
bodily injury, electric shock, fire and damage to the
equipment, observe the following precautions. please
note that under certain circumstances, audio or video
recording may be prohibited by law. this device should
be used only in compliance with all applicable federal,
state and local statutes.
Detailed user manual

2.1). DO NOT use this product near water, for example,
near a bathtub, washbowl, kitchen sink, or laundry tub,
in a wet basement, or near swimming pool
2.2). DO NOT use this product to infringe on one's privacy,
spying intercepting and related activities are illegal and
punishable by law. Monitoring one's privacy activities
without consent is illegal and this product is not designed
or manufactured for these purposes
2.3). DO NOT place this product on an unstable cart,
stand, or table. The product may fall, causing serious
damage to the product.
2.4). DO NOT disassemble this product, Opening or
removing covers may expose you to dangerous voltages
or other risks. Incorrect reassembly can cause electric
shock during subsequent use.
2.5). DO NOT use this product to carry out any illegal
activities such as sneak preview, etc. We shall not be
responsible for any consequences of illegal conducts
made by users.
2.6). DO NOT cover the car cigarette lighter adapter
when it is connected to any outlet, place the adapter near
heaters, or put it on the floor which is equipped with a
heater. the above mentioned operation might cause fire
or incidents.
2.7). DO NOT plug in the car cigarette lighter adapter
with wet hands might cause electric shock.
2.8). DO NOT put the plastic packaging bags in reach of
children or babies. Plastic bags can create a suffocation
hazard when place over the nose and mouth
10

3.1). Please make sure that you are following the
regulations and laws set by your country/city prior to
mounting your camera. This manual does not intent to
provide any specific legal advice.
3.2). Please check the features periodically to ensure
that it is operating as required.
3.3). During a car accident, the impact of the collision
must be hard enough to trigger the impact sensor in
order for the product to lock the recorded files.
3.4). Please use the product as a tool only while driving
and use driver's safety while driving.
3.5). we shall not be responsible for any traffic
violations related to the improper use of our product.
3).Disclaimers
11

Main interface introduction
05/04/2013 13:25:30
HD
Video mode
Recording
Battery capacity
Video resolution
Micro-SD No SD
Current time and date
Current record seconds
Or
Camera mode
1280x720 848x480
Taking picture
2013/09/04 13:21:48
0 0 : 1 4
2013/09/04 13:24:48 2013/09/04 13:30:48
Picture resolution
12
Or
During recording, press to stop it. You may press
to have picture mode. Now every press on
it will take one picture.
Or
NOTE:
1.It will show “SD Card Full” if micro-sd card is full
2. It will auto power off if there's no operation for 1 minute
Lane departure
03:23

When recording stopped, Holding on for 3 seconds,
and you will get into manual settings. return to higher
options
System Setup
System Setup
Lane Departure
Distance Alert
G-Sensor
Auto LCD Off
繁体中文
Now use to choose, to confirm, return to higher
options
System Setup
2).Lane Departure Warning
13
9Off
High Speed
System Setup
简体中文
日本語
Language
Distance Alert
G-Sensor
Auto LCD Off
Off: LDW is off.
On: LDW is always on, whatever on highways or low
speed road.
It is suggested to use to turn on it before going into
highway; turn it off when you go out of highway

High speed: This mode is mainly designed with GPS
bracket. If you have GPS bracket, it will do lane
departure warning no less than 60KM/hour. Of course
GPS is more accurate in calculating speed. But if
without GPS, you could use LDWS "on" mode, which is
very accurate and suggested.
When it makes warning, the sound is like a doorbell ring
“DingDong”.
It is defaulted to be “on”.
Each warning will has an MIN interval of 3 seconds,
after which another warning should be made.
3).Distance Alert
In high speed, if you are getting too close to the front car,
it will remind you of that by "DD".
It is defaulted to be with high speed only.
And due to false alarms, it will not work in evening.
9Off
System Setup
Language
Lane Departure
G-Sensor
Auto LCD Off
9Off
System Setup
Language
Lane Departure
Distance Alert
Auto LCD Off
If the car hit anything, it will lock the previous video,
present video and the next video not to be recycled and
there will be a lock on the screen to remind there is
locked video. Once press OK the lock will disappear.
It is defaulted to be G-Sensor on.
4).G-Sensor
14

9
System Setup
Language
Lane Departure
Distance Alert
G-Sensor
5). Auto LCD Off
Without operation for 30 seconds, it will automatically
shut down the screen.
Important notice: If it is battery powered and no
operation for 1 minutes, it will automatically power off.
6). GPS Signal
No GPS
System Setup
Format
Beep
Restore Default
Version
If no GPS available, it shows NO GPS; if there is GPS,
it will show the signal strength, present longitude and
Latitude.
15
YES
System Setup
7). Format
Choose format to format the Micro-SD card
Format
Beep
Restore Default
Version
30S
1Min
3Min

8). Beep
It is defaulted to be beep on.
9). Restore Default
Restore default to set everything as the factory settings.
10). Version
It shows the software version for future upgrade.
On
System Setup
OK
System Setup
2 0 1 3 / 1 0 / 0 1
System Setup
1 . 0
16
Format
Restore Default
Version
Format
Beep
Version
Format
Beep
Restore Default
Time Setup
Time Setup
DD/MM/YYYY
MM/DD/YYYY
1 ). Time Format
Time and date
Choose the right date format, YYYY/MM/DD,
DD/MM/YYYY, or MM/DD/YYYY

2).Tme and date
Use to change year/month/date/hour/
minute, use to confirm each and quit
Time Setup
Time Format
Video Setup
1 1 / 1 0 / 2 0 1 3
13:34
1).Video resolution
You may choose 1280*720 or 848*480 as video
resolution. However, the Max recording time is
by 848*480 for more than 6 hours
Video Setup
Video Length
Recycle Record
Record Audio
Date Stamp
848x480
17
2). Video length
It means how long you want each video file will be.
3 Min is suggested.
Video Setup
Video Resolution
Recycle Record
Record Audio
Date Stamp
1 Min
3 Min
5 Min

3). Recycle Record
It means when the Micro-SD is full, you want it
recycled or not.
If G-sensor is on, it will not recycle the G-sensor
triggered files.
18
Video Setup
Video Resolution
Video Length
Record Audio
Date Stamp
On
4). Record Audio
It means if you want the video record with audio or not.
Video Setup
Video Resolution
Video Length
Recycle Record
Date Stamp
On
Video Setup
Video Resolution
Video Length
Recycle Record
Record Audio
On
5).Date Stamp
If you want time and date watermark on videos, just set
it on. If not, set it off please.
