sauter SFE 701 Instruction Manual

Oven
SFE 701
EN GUIDE TO INSTALLATION
We cook so well together
99642021_A.qxp 27/03/2007 17:25 Page 1

2
As part of our commitment to constantly improving our products, we reserve the right to make
changes to them based on technical advances to their technical and functional features and
appearance.
Warning:
Before installing and using your appliance, please carefully read this Guide to
Installation and Use, which will allow you to quickly familiarise yourself with its operation.
Dear Customer,
You have just acquired a SSAAUUTTEERRoven and we would like to thank
you.
We have invested all our dedication and know-how in this appliance
so that it would best meet your needs. With innovation and perfor-
mance, we designed it to be always easy to use.
In the SSAAUUTTEERRproduct range, you will also find a wide choice of
microwaves, cooking hobs, ventilation hoods, cookers, dishwashers,
washing machines, driers, fridges and freezers, that you can coordi-
nate with your new SSAAUUTTEERRoven.
Visit our website wwwwww..ssaauutteerr--eelleeccttrroommeennaaggeerr..ccoommwhere you will
find all of our products, as well as useful and complementary
information.
SSAAUUTTEERR
We cook so well together
02EN
99642021_A.qxp 27/03/2007 17:25 Page 2

3
TABLE OF CONTENTS
1 / INFORMATION FOR THE USER
••Safety instructions _________________________________________ 04
••Environment ______________________________________________ 05
2 / INSTALLING YOUR APPLIANCE
••Choice of location__________________________________________ 06
••Build-in __________________________________________________ 06
••Electrical connection _______________________________________ 07
••Changing the power supply cable_____________________________ 08
3 / DESCRIPTION OF YOUR APPLIANCE
••Introduction to your oven ____________________________________ 09
••Description of the accessories _______________________________ 10
••Description of your programmer ______________________________ 11
4 / USING YOUR APPLIANCE
••Using the programmer ______________________________________ 12
ºHow to set the time_____________________________________ 12
ºHow to adjust the time __________________________________ 12
ºInstant cooking ________________________________________ 13
ºProgrammed cooking ___________________________________ 14
ºUsing the timer function _________________________________ 16
5 / OVEN COOKING MODES_______________________________________ 17
6 / CARING FOR AND CLEANING YOUR APPLIANCE
••Changing the catalytic walls _________________________________ 18
7 / TROUBLESHOOTING __________________________________________ 19
••Changing the bulb _________________________________________ 20
EN
99642021_A.qxp 27/03/2007 17:25 Page 3

4
1 / INFORMATION FOR THE USER
SAFETY INSTRUCTIONS
— This oven was designed for use by private
persons in their homes. It is intended solely
for cooking foodstuffs. This oven does not
contain any asbestos-based components.
— This appliance is to be used by adults.
Make sure that children do not touch it and
that they do not treat it as a toy. Make sure
that they do not touch the appliance’s
control panel.
— When you receive the appliance, unpack it
or have it unpacked immediately. Give it an
overall inspection. Make note of any concerns
or reservations on the delivery slip and make
sure to keep a copy of this form.
— Your appliance is intended for standard
household use. Do not use it for commercial
or industrial purposes or for any other pur-
pose than that for which it was designed.
— Do not modify or attempt to modify any of
the characteristics of this appliance. This
would be dangerous to your safety.
— Keep young children away from the
appliance while it is in operation. In this way
you will avoid the danger of them being bur-
ned by knocking over cooking recipients.
Moreover, the front of your appliance is hot
during use.
— Never pull your appliance by the door
handle.
— Before using your oven for the first time,
heat it while empty for approximately 15 minu-
tes. Make sure that the room is sufficiently
ventilated. You may notice a particular odour,
or a small release of smoke. All of this
is normal.
— During cooking, ensure that the door of your
oven is completely closed so that the seal can
do its job properly.
— When in use, the appliance becomes hot. Do
not touch the heating elements located inside
the oven. In doing so, you would run the risk of
suffering serious burns.
— When placing dishes inside or removing
them from the oven, do not place your hands
close to the upper heating elements, use heat-
protective kitchen gloves.
— At the end of cooking, do not pick up dishes
(grills, rotisserie...) with bare hands.
— Never place aluminium foil directly in contact
with the oven shelf (see the chapter on oven
description), the accumulated heat may cause
deterioration of the enamel.
— Do not place heavy weights on the open
oven door, and make sure that children are
able neither to climb nor sit on it.
— In order to avoid damaging your oven
controls, do not leave the door open when it is
in operation or still hot.
— The oven must be turned off when cleaning
inside the oven.
— Intensive and prolonged use of the appliance
may give rise to the need for additional ventila-
tion, by opening a window, or by increasing the
power of the mechanical fan.
— Additionally to the accessories supplied with
your oven, only use dishes which resist high
temperatures (follow the manufacturer’s ins-
tructions).
— After using your oven, make sure that all the
controls are in their stop position.
— Never use steam or high-pressure devices to
clean the oven (requirement imposed by elec-
trical safety concerns).
••
Warning
Keep this user guide with your
appliance. If the appliance is ever sold or
transferred to another person, ensure that
the new owner receives the user guide.
Please become familiar with these recom-
mendations before installing and using your
oven. They were written for your safety and
the safety of others.
EN
99642021_A.qxp 27/03/2007 17:25 Page 4

5
1 / INFORMATION FOR THE USER
ENVIRONMENT
••
— This appliance’s packing materials are recyclable. Recycle them and play a role in protecting the
environment by depositing them in municipal containers provided for this purpose.
— Your appliance also contains many recyclable materials. It is therefore marked with this logo to
indicate that used appliances must not be mixed with other waste. Recycling of the
appliances organised by your manufacturer will thus be undertaken in optimum condi-
tions,in accordance with European directive 2002/96/CE relative to electrical and elec-
tronic equipment waste. Consult your city hall or your retailer to find the drop-off points
for used appliances that is nearest to your home.
— We thank you for your help in protecting the environment.
Warning
IInnssttaallllaattiioonnsshhoouullddoonnllyybbeeppeerrffoorrmmeeddbbyyiinnssttaalllleerrssaannddqquuaalliiffiieeddtteecchhnniicciiaannss..
TThhiissaapppplliiaanncceeccoommpplli
ieesswwiitthhtthheeffoolllloowwiinnggEEuurrooppeeaannddiirreeccttiivveess::
--LLoowwTTeennssiioonnDDiirreeccttiivvee7733//2233//CCEEEEmmooddiiffiieeddbbyyddiirreeccttiivvee9
933//6688//CCEEEEffoorriinnsseerrttiioonnooffEECCmmaarrkkiinngg..
--EElleeccttrroommaaggnneettiiccCCoommppaattiibbiilliittyyDDiirreeccttiivvee8899//333366//CCEEEEmmooddiiffiieedd
bbyyddiirreeccttiivvee9933//6688//CCEEEEffoorriinnsseerr--
ttiioonnooffEECCmmaarrkkiinngg..
--EECCrruulleenn°°11993355//22000044ccoonncceerrnniinnggmmaatteerriiaallssaan
nddoobbjjeeccttssiinntteennddeeddffoorrccoonnttaaccttwwiitthhffooooddssuubbssttaanncceess..
EN
99642021_A.qxp 27/03/2007 17:25 Page 5

6
holes designed for this purpose on the lateral
mounts (fig.1).
BUILD-IN
To do this :
1) Remove the rubber screw covers to access
the mounting holes.
2) Drill a Ø 3 mm hole in the cabinet panel to
avoid splitting the wood.
3) Attach the oven with the two screws.
4) Replace the rubber screw covers (they also
absorb the shock caused by closing the oven
door).
(*) if the cabinet is open, its opening must be 70
mm (maximum).
Tip
To be certain that you have properly
installed your appliance, do not hesitate to
call on a household appliance specialist.
••
CHOICE OF LOCATION
The above diagrams determine the dimen-
sions of a cabinet that will be able to hold your
oven.
The oven can be installed under a work top or
in a column of cabinetry (open* or closed)
having the appropriate dimensions for built-in
installation (see adjacent diagram).
Your oven has optimised air circulation that
allows it to achieve remarkable cooking and
cleaning results if the following guidelines are
followed:
• Centre the oven in the cabinet so as to gua-
rantee a minimum distance of 5 mm between
the appliance and the neighbouring cabinet.
• The material or coating of the cabinet must
be heat-resistant.
• For increased stability, fix the oven in the
cabinet by means of 2 screws through the
••
2 / INSTALLING YOUR APPLIANCE
585
560
550
70 550
Fig. 01
EN
99642021_A.qxp 27/03/2007 17:25 Page 6

7
••
ELECTRICAL CONNECTION
Single-phase 20A Counter
220-240V~ 50Hz
Electrical outlet
220-240 V ~ Single-phase line
Power
supply cable
length 1.50 m
approx.
16A fuse or differential
circuit breaker
Electrical safety must be guaranteed by cor-
rectly fitting the appliance. During build-in and
maintenance operations, the appliance must
be unplugged from the electrical grid; fuses
must be switched off or removed.
The electrical connections are made before
the appliance is installed in its housing.
Ensure that:
- the electrical installation has sufficient voltage,
- the electrical wires are in good condition
- the diameter of the wires complies with the ins-
tallation requirements.
Your oven must be connected with a (standar-
dised) power cable with 3 conductors of
1.5mm2(1 live + 1 neutral + earth) which
must be connected to a 220-240V~ single-
phase grid
via the intermediary of a 1 live + 1 neutral +
earth CEI 60083 standardised power socket
or via an all-pole cut-off device or in com-
pliance with the installation rules.
Warning
The safety wire (green-yellow) is connec-
ted to the appliance’s terminal and must
be connected to the earth terminal of the
electrical set-up.
In the case of connection to an electric wall
socket, it must remain accessible after instal-
lation.
The fuse in your set-up must be 16 amperes.
If the power cable is damaged, it must be
replaced by a cable or a special kit available
from the manufacturer or its After-Sales
Service Department.
2 / INSTALLING YOUR APPLIANCE EN
99642021_A.qxp 27/03/2007 17:25 Page 7

8
••
——The power cable (H05 RR-F, H05 RN-F or H05 VV-F) must be of sufficient length to be connec-
ted to the build-in oven while it sits on the floor in front of the cabinet.
To do this the appliance must be disconnected from the electrical network:
——Open the inspection flap located at the lower right of the back cover by unscrewing the two
screws, then pivot the inspection flap.
——Strip 12 mm along each wire of the new power cable.
——Carefully twist together the strands.
——Loosen the screws from the terminal board and remove the power cord to be replaced.
• Introduce the power cable through the side of the cover in the cable clip located to the right of
the terminal board.
——All the strands of the electricity wires must be captured under the screws.
— The phase wire on the L terminal.
— The green-yellow coloured earth wire should be connected to the terminal .
——The neutral conductor (blue) on the N terminal.
——Screw down tightly the screws on the terminal board and check the connection by pulling on each
wire.
——Attach the cable with the cable clip located to the right of the terminal board.
——Close the inspection flap using the 2 screws.
Warning
WWeeccaannnnoottbbeehheellddrreessppoonnssiibblleeffoorraannyyaacccciiddeennttrreessuullttiinnggffrroommiinneexxiisstteenntt,,ddeeffeeccttiivveeoorr
iinnccoorrrreecctteeaar
rtthhiinngg..
IIfftthheeeelleeccttrriiccaalliinnssttaallllaattiioonniinnyyoouurrrreessiiddeenncceerreeqquuiirreessaannyycchhaannggeessiinnoorrddeerrttoohhooookkuuppyyoou
urr
AApppplliiaannccee,,ccaalllluuppoonnaapprrooffeessssiioonnaalleelleeccttrriicciiaann..
IIfftthheeoovveennmmaallffuunnccttiioonnssiinnaannyywwaayy,,uunnpplluuggtthheea
apppplliiaanncceeoorrrreemmoovveetthheeffuusseeccoorrrreessppoonnddiinngg
ttootthheesseeccttoorrwwhheerreetthheeoovveenniisshhooookkeedduupp..
CHANGING THE POWER SUPPLY CABLE
2 / INSTALLING YOUR APPLIANCE
EN
99642021_A.qxp 27/03/2007 17:25 Page 8

9
••
INTRODUCTION TO YOUR OVEN
3 / DESCRIPTION OF YOUR APPLIANCE
A
B
Programmer
Temperature selector switch
Function selector switch
C
D
E
Light
Wire shelf supports
Tip
This Guide to Installation and Use is valid for several models. Minor differences in details
and fittings may emerge between your appliance and the descriptions provided.
E
D
B
A
C
EN
99642021_A.qxp 27/03/2007 17:25 Page 9

10
Rear
Front
••Anti-rocking safety grid (fig.1)
The grid can be used to hold all dishes and
moulds containing foodstuffs to be cooked or
browned.
It can be used for barbecues (to be placed
directly on the grid).
DESCRIPTION OF THE ACCESSORIES
••
fig.1
3 / DESCRIPTION OF YOUR APPLIANCE
fig.2
••Multi-purpose dish (fig.2)
It serves as a cake dish and has a sloped
edge. It is used for cooking pastries such as
cream puffs, meringues, cup cakes, puff pas-
try, etc.
Inserted under the grid, it catches barbecue
juices and grease. It can also be used half-full
of water for double-boiler cooking methods.
Avoid placing roasts or meats directly in the
dish because this is certain to cause signifi-
cant spattering on the oven walls.
fig.3
••Cake dish (fig.3)
It serves as a cake dish and has a sloped edge.
It is used for cooking pastries such as cream
puffs, meringues, madeleines, puff pastry, etc.
EN
99642021_A.qxp 27/03/2007 17:25 Page 10

11
DESCRIPTION OF YOUR PROGRAMMER
••
A
E
F
A
B
Time and cooking time display
Temperature indicator
Cooking time indicator
C
DCooking end time indicator
Timer indicator
Selection touch control (cooking time and time)
E
F
3 / DESCRIPTION OF YOUR APPLIANCE
B
C
D
EN
99642021_A.qxp 27/03/2007 17:25 Page 11

12
USING THE PROGRAMMER
••
•How to set the time
--When supplied with electricity
The display flashes at 12:00 (fig.1)
Set the time using the + and - buttons (holding
down the + or - makes the numbers go faster)
(fig.2).
Example: 12:30
Press the “ ” touch control to validate.
The display stops flashing (fig.3).
•How to adjust the time
- To set the time on the clock
The function selector switch must be in the 0
position (fig.1).
Hold down the “ ” button for a few
seconds until 0.00 appears. Keep held down
until the time appears again, then let go
(fig.2).
While the time is flashing, set the time using
the selector (fig.3).
Press the “ ” touch control to validate
(fig.4).
fig.1
fig.3
fig.2
4 / USING YOUR APPLIANCE
Warning
If there is no confirmation from the
“ ” button, the time is recorded auto-
matically after a few seconds.
fig.2
fig.3
fig.4
EN
99642021_A.qxp 27/03/2007 17:25 Page 12

13
•Instant cooking
— The programmer should display only the
time.
It should not be flashing (fig.1).
Turn the function selector to the position of
your choice.
Example: select “ ” (fig.2).
Your oven recommends the ideal temperature
for the chosen cooking mode (fig.3).
It is, however, possible to adjust the tempera-
ture. The temperature symbol flashes (fig.4).
Set the temperature using the + or - selector
(fig.5).
Example: temperature set to 210°C (fig.6).
PPllaacceeyyoouurrddiisshhiinntthheeoovveennbased on the
recommendations provided by the cook book.
After these steps, the oven heats up and the
temperature indicator flashes.
A series of beeps will be emitted when the
oven reaches the selected temperature.
The temperature stops flashing.
fig.2
fig.6
Warning
All types of cooking are done with the door closed.
Warning
After a cooking cycle, the cooling fan continues to operate for a period of time in order
to guarantee optimal oven reliability.
4 / USING YOUR APPLIANCE
fig.5
fig.1
fig.3
fig.4
EN
99642021_A.qxp 27/03/2007 17:25 Page 13

14
--
Cooking with immediate start and pro-
grammed duration
- Select the desired cooking mode and adjust the
temperature (fig.1).
Example: select ,,temperature 210°(fig.2).
- Press the “ ” button until the cooking time
indicator flashes “ ”.
The display flashes 0:00 to indicate that you can
now adjust the setting (fig.2).
- Use the + or - selector to set to the desired tem-
perature.
Example: 25 mins cooking time (fig.3).
The cooking time is automatically recorded after
a few seconds.
The cooking time display stops flashing and re-
turns to temperature mode (fig.4).
The countdown of the cooking time begins imme-
diately after it has been set.
AAfftteerrtthheesseetthhrreeeesstteeppss,,tthheeoovveennhheeaattssuupp::
A series of beeps will be emitted when the oven
reaches the selected temperature.
At the end of cooking (end of programmed time),
- the oven stops,
- 0:00 is displayed (fig.5),
- A series of beeps is emitted for a few minutes.
The beeps can be stopped by pressing the “ ”
button.
The display shows the time once again when the
function selector switch is returned to 0 (fig.6),
fig.2
fig.3
PROGRAMMED COOKING
••
4 / USING YOUR APPLIANCE
fig.6
fig.1
fig.4
fig.5
EN
99642021_A.qxp 27/03/2007 17:25 Page 14

15
--
Cooking with delayed start and chosen
cooking end time
PPrroocceeeeddaasswwiitthhpprrooggrraammmmeeddccooookkiinngg..
- After setting the cooking time, press the
“ ” button until the end of cooking indicator
flashes “ ”
The time display flashes to indicate that you
can now adjust the setting (fig.1).
- Press the ++or --touch control to set the des-
ired cooking end time.
Example: end of cooking at 13:00 (fig.2).
The cooking end time is automatically recor-
ded after a few seconds.
The cooking end time display stops flashing.
AAfftteerrtthheessee33sstteeppss,,tthheeoovveennhheeaattiinnggiiss
ddeellaayyeeddssootthhaattccooookkiinnggeennddssaatt1133::0000..
At the end of cooking (end of programmed
time),
- the oven stops,
- 0:00 is displayed,
- A series of beeps is emitted for a few minu-
tes. The beeps can be stopped by pressing
the “ ” button.
The display shows the time once again when
the function selector switch is returned to 0
(fig.3),
In the case of programmed cooking cycles,
the cavity lights up until cooking begins, and
remains lit until cooking is finished.
fig.2
fig.3
PROGRAMMED COOKING
••
4 / USING YOUR APPLIANCE
fig.1
EN
99642021_A.qxp 27/03/2007 17:26 Page 15

16
4 / USING YOUR APPLIANCE
--YYoouurroovveenn’’sspprrooggrraammmmeerrccaannbbeeuusseeddaassaann
iinnddeeppeennddeennttttiimmeerrtthhaattaalllloowwssyyoouuttooccoouunntt
ddoowwnnaattiimmeewwiit
thhoouuttooppeerraattiinnggtthheeoovveenn..
In this case, the timer display has priority over
the clock display.
- Press the “ ” (fig.1) button until the timer
symbol begins to flash
-> 0.00 flashes.
- Adjust the chosen time by pressing the + or -
selectors.
- Press the “ “ button to confirm or wait a
few seconds (fig.2).
Warning
It is possible to change or cancel the timer at any time.
fig.1
fig.2
USING THE TIMER FUNCTION
••
The display stops flashing after a few seconds and the timer starts working, counting down the
time in seconds.
Once the time has expired, the timer emits a series of beeps to notify you.
The beeps can be stopped by pressing the “ ” button.
EN
99642021_A.qxp 27/03/2007 17:26 Page 16

17
5 / OVEN COOKING MODES
CCIIRRCCUULLAATTIINNGGHHEEAATT
(recommended temperature 118800°°CC- Min. 35°C - Max. 235°C)
•
Cooking is controlled by the heating element located at the back of the oven and by the
fan.
•
Preheating unnecessary except for cooking programmes requiring very short times
(biscuits on several levels).
•
Recommended for preserving tenderness in meats, vegetables and fish and for multiple
cooking on up to three levels.
TTRRAADDIITTIIOONNAALL
(recommended temperature 224400°°CC- Min 35°C Max - 275°C)
•
Cooking controlled by the upper and lower heating elements with no fan.
•
Requires preheating before the dish is placed in the oven.
•
Recommended for ssllooww,,ggeennttlleeccooookkiinngg::tender game meat, etc. To seal rrooaassttssof red
meat. To simmer in a ccoovveerreeddsstteewwppaanndishes that were begun on the hob (coq au vin,
stew, etc.).
SSHHAABBBBAATT
temperature 9900°°CC
PPUULLSSEEDDGGRRIILLLL
(recommended temperature 220000°°CC- Min. 180°C - Max. 230°C)
• Cooking is controlled alternately by the upper element and the fan.
• Preheating unnecessary. Roasts and poultry that are juicy crispy and all over.
• Recommended for all ppoouullttrryyor rrooaassttssto seal and cook through lleeggrrooaasstt, bbeeeeffrriibbss
For preserving tenderness in filets of ffiisshh.
HHIIGGHHGGRRIILLLL
(recommended temperature 227755°°CC- Min 180°C Max - 275°C)
•
Cooking controlled by the upper element without the fan.
• Preheat the oven for five minutes. Slide the drip tray onto the lower shelf support to
collect greases.
• Recommended for grilling cchhooppss,ssaauussaaggeess, sslliicceessooffbbrreeaadd, pprraawwnnssppllaacceeddoonntthheeggrriidd.
PPRREEHHEEAATTIINNGG
• Preheat the oven on this fonction before your cooking if you want and where the
temperature is reach turn the fonction selectar to the cooking position of your choice.
EN
99642021_A.qxp 27/03/2007 17:26 Page 17

18
CHANGING THE CATALYTIC WALLS (OPTIONAL)
••
BBeeffoorreeccoommmmeenncciinnggddiissaasssseemmbbllyy,,aalllloowwtthhee
aapppplliiaanncceettooccoooollddoowwnnaannddcchheecckktthhaatttthhee
ccooookkiinnggsseelleeccttoorrsswwiittcchhiissiinntthhee00ppoossiittiioonn..
LLaatteerraallwwaallllss((11))
Unhook the wire shelf support ((22))at the front
by lifting it (
diagram AA ). Pull the shelf support
structure towards you, lifting it so as to un-
hook the rear attachment (
diagram BB
)). Re-
move it from the 2 holes ((33) in the catalytic
wall and from the oven cavity. Then remove
the catalytic wall ((11))..Replace the new ele-
ments (wall and/or shelf supports) by perfor-
ming the reverse operations.
BBaacckkwwaallll((44))
BBeeffoorreeppeerrffoorrmmiinnggtthhiissooppeerraattiioonn,,uunnpplluuggtthhee
oovveenn..
Completely unscrew the screw (5) located at
the top of the back wall. Tilt the wall for-
wards in order to remove it from the oven
cavity. Position the new panel by reversing
these steps.
PPlluuggiinntthheeoovveennaaggaaiinn..
6 / CARING FOR AND CLEANING YOUR APPLIANCE
B
A
1
3
4
2
5
Warning
- The oven must be turned off when cleaning inside the cavity.
EN
99642021_A.qxp 27/03/2007 17:26 Page 18

19
Tip
In all circumstances, if your efforts are not sufficient, contact the After-Sales Service
Department without delay.
WWHHAATTSSHHOOUULLDDYYOOUUDDOO??
➡Plug in your oven.
➡Replace the fuse in your electrical
set-up and check its capacity (16A).
➡Increase the selected temperature.
IIffyyoouuhhaavveeaaddoouubbttaabboouutttthheeccoorrrreeccttffuunnccttiioonniinnggooffyyoouurroovveenn,,this does not necessa-
rily mean that there is a malfunction.
IInnaannyyeevveenntt,,cchheecckktthheeffoolllloowwiinnggiitteemmss::
➡Change the bulb.
➡Plug in your oven or change the
fuse.
➡The recommended temperature of
your choice has been reached.
➡Your programmed cooking cycle is
finished.
7 / TROUBLESHOOTING
Warning
- Repairs to your appliance should only be performed by professionals. Non-standard re-
pairs may be a source of danger for the user.
EN
PPOOSSSSIIBBLLEE
CCAAUUSSEESS
- The oven is not connected
to the power supply.
- Your fuse is out of order.
- The selected temperature
is too low.
- The light is out of order.
- The oven is not connected
or the fuse is not working.
- During cooking.
- At the end of a cooking
cycle.
YYOOUUOOBBSSEERRVVEE
TTHHAATT……
TThheeoovveenniissnnootthheeaattiinngg..
TThheeoovveennlliigghhttiissnnoott
wwoorrkkiinngg..
YYoouurroovveennssttaarrttssbbeeee--
ppiinngg..
99642021_A.qxp 27/03/2007 17:26 Page 19

20
7 / TROUBLESHOOTING
Bulb
Unscrew
Port
The bulb is located on the ceiling of your oven’s
cavity.
a) Unplug the oven.
b) Unscrew the lighting port (fig.1).
c) Unscrew the bulb in the same direction.
Bulb specifications:
- 15 W
- 220-240 V ~
- 300°C
- E 14 cap
d) Replace the bulb then reposition the port
and reconnect your oven.
CHANGING THE BULB
••
Tip
To unscrew the port and the bulb, use a rubber glove, which will make disassembly
Warning
- Disconnect your oven before performing any task on the bulb to avoid the risk of electric
shock and, if necessary, let the appliance cool down.
fig.1
EN
99642021_A.qxp 27/03/2007 17:26 Page 20
