Savant PAV-VIMAP8S User manual

Savant Video Input IP Transmitter QRG | 009-1604-03 45 Perseverance Way, Hyannis, MA 02601
Copyright 2021 Savant Systems, Inc. | 210416 1 of 2 Savant.com | 508.683.2500
Savant® ProAV Video 8 or 4 Input IP Transmitter 4K UHD with Audio Processing
and Control [PAV-VIMAP8S/PAV-VIMAP4S]
Quick Reference Guide
Box Contents
(1) Audio/Video over IP Switch
(PAV-VIMAP8S-xx/PAV-VIMAP4S-xx)
(1) Installation Kit (075-0192-xx/075-0197-xx)
(2) Standard 3U Rack Mounting Brackets (071-0638-xx)
(4) M5 x 8 mm Flat-head Phillips Screws (039-0180-xx)
(1) 4 ft Power Cord (064-0443-xx N. America)
or 4ft Power Cord (International. Can vary.)
(16 or 8) 3-pin Control Connectors (028-9351-xx)
(1) Product Regulatory Insert (009-1950-xx)
Compliance
Safety and
Emissions
FCC Part 15 CE C-Tick ETL
RoHS Compliant
Supported Releases
PAV-VIMAP8S-00 da Vinci 8.8 and higher
PAV-VIMAP4S-00
PAV-VIMAP8S-10 da Vinci 9.3.4 and higher
PAV-VIMAP4S-10
Power
Input Power 100-240V AC 50/60Hz, (5A maximum)
Nominal Power N. America - 144VA - (1.2 A @ 120V AC, 60Hz)
International - 156VA - (.68 A @ 240V AC 50Hz)
Maximum Power N. America - 400VA - (4 A @ 120V AC, 60Hz)
International - 432VA - (1.8 A @ 240V AC 50Hz)
Power Cable IEC320 C13 three-pole detachable power card.
Dimensions and Weights
Height Width Depth Weight
Device 5.21 in
(13.23 cm)
17.30 in
(43.94 cm)
14.24 in
(36.17 cm)
14.5 lb
(6.59 kg)
Shipping 22.0 in
(55.88 cm)
22.0 in
(55.88 cm)
10.0 in
(25.4 cm)
18.25 lb
(8.27 kg)
Rack Space 3U
Environmental
Temperature 32° to 104° F (0° to 40° C)
Humidity 10% to 90% Relative Humidity (non-condensing)
Cooling 70 cubic feet per minute (CFM) recommended.
BTU 1365 BTU/hr
Specifications
Required Components
– Savant Audio/Video over IP Device
– Savant System Host
– Savant qualified 10G Managed Network Switch
– Savant User Interface (Pro App)
– Savant Development Environment (SDE)
ABC D E
Item Description
On / O
Button
Reboots the main board (MCU) and power
cycles the IP Video transmit (Tx) cards
Reset Button
Press and Release: Resets the IP Video transmit
(Tx) cards.
Press and hold: Clears the network settings.
Press and hold button for 5 seconds until Sta-
tus LED blinks red rapidly; then release.
Power LED
Green: Main board is powered.
Amber: FPGA is currently being updated.
O: Device is o. No power applied.
Status 1 LED
Green: Host has established communications
with the embedded system.
Green Blinking: Embedded system is ready, but
no communication has been established with
the host.
Amber: Host is updating the embedded
firmware.
Amber Blinking: Embedded system has a valid
link local IP address and is connecting to the
host.
Red: Host has determined the firmware needs
to be updated, but a problem occurred during
the process that will initiate a reset.
Red Blinking: Embedded firmware is running,
but has not received a DHCP IP address.
O: Embedded processor is resetting, or is
powered up, and is booting the embedded
firmware.
Hardware Failure: If a hardware failure occurs,
the status LED indication will be interrupted
every three seconds with a solid red indication.
For example, If the LED is blinking green when
a hardware failure occurs, the LED will
alternate between blinking green and solid red
at three-second intervals.
Status 2 LED Reserved for future use.
A
B
C
D
E
Network Requirements
For more information, see the Savant Device Networking Guidelines on
the Savant Customer Community.
Front Panel
Additional Information
Refer to the following documents located on the Savant Customer
Community for additional information.
– Savant Video over IP Deployment Guide (009-1551-xx)
– Savant Video over IP Network Configuration Guide (009-1552-xx)
– Savant IP Audio Deployment Guide (009-1571-xx)

Savant Video Input IP Transmitter QRG | 009-1604-03 45 Perseverance Way, Hyannis, MA 02601
Copyright 2021 Savant Systems, Inc. | 210416 2 of 2 Savant.com | 508.683.2500
Item Description
1 Gigabit
Ethernet
1G of reserved network data bandwidth.
Commonly used to connect any network
compliant device to transmit its data onto the
Ethernet network by sharing the 10G network
link. 8-Pin RJ-45 female connection.
IMPORTANT NOTES:
– Do not connect these ports to a network
switch.
– This is a courtesy port. It will not work for all
network functions. For example, Spanning
tree devices are not supported by this port.
10 Gigabit
Ethernet
SFP+ Housing; Used for connectivity to the 10G
Ethernet Network Switch.
IMPORTANT! For all 10G connections, use only
Savant certified SFP+ Direct-Attach Copper
(DAC) cables, or Savant certified fiber and fiber
connectors along with Savant certified SFP+
modules.
Rx/Tx LEDs
(10 GbE)
Rx – Link Activity LED indicator for all data
received on the 10G connection
Tx – Link Activity LED indicator for all data
transmitted from the 10G connection
HDMI In
19-Pin Type A HDMI female digital audio/video
input.
Supports HDMI 2.0a
HDMI 2.0 compliant cable is required for 4K
content.
Power Input
Module
100-240V AC 5A 50/60Hz power input module
with On/O switch.
I – Applies power to the device.
O – Removes power to the device.
NOTE: Includes a field replaceable 5A 250V Fast
acting fuse. For replacement information see the
Replacing the Fuse section below.
RS-232
Control Port
RS232 – 3-pin Screw down plug-in connection.
Transmits and receives serial data to and
from serial controllable devices. For pin-out
information, refer to the RS-232 Wiring section
below.
IR Control
Port
IR - 3-pin Screw down plug-in connection.
Transmits IR signals via an IR Flasher
(5V tolerant) to devices with an IR input or IR
receiver. For pin-out information, refer to the IR
Wiring section below.
Push Buttons Push buttons – Reserved for future use.
Ethernet
8-Pin RJ-45 female connection. Used to
communicate with the Savant System Host.
Supports Audio Video Bridging (AVB)/Time
Sensitive Networking (TSN).
Grounding Chassis Ground (optional)
A
B
C
D
E
F
G
H
I
J
Rear Panel Wiring and Connections
IR connections are made using a 3-pin
Control Connector supplied with the device.
The wire slips into the hole and locks with a
screw located at the top of the connector.
IMPORTANT: IR Wiring Precautions
Ensure that all IR emitters are within 15 feet
(4.6 meters) from the controller’s location.
Use of 3rd party blinking IR emitters with
Talk Back is not recommended. These types of emitters can draw
voltage away from the IR signal that can degrade IR performance.
3
2
1
Out
G
PIN 1
PIN 2
PIN 3
Not Used
IR +
IR -
IR Wiring
Serial control connections are made using
a 3-pin Control Connector supplied with
the device. The wire slips into the hole and
locks with a screw located at the top of the
connector.
RS-232 Wiring
3
2
1
Rx
Tx
G
PIN 1
PIN 2
PIN 3
Receive
Transmit
Ground
Enhanced small form-factor pluggable connection. Use
a Savant certified Direct Access Copper (DAC) SFP+
cable to connect the chassis to the 10G switch, or Savant
certified fiber and fiber connectors along with Savant
certified SFP+ modules.
Transport Distance
DAC cable 6 ft (2 m)
OM3 multi-mode Fiber 1000ft (300 m)
SFP+ 10 GbE
Tx
G
Rx
GbE
P1
P2
1
Out
G
IR
RS232
Rx
Tx
G
RS232
HDMI
GbE
In
1
Rx
10
Tx Rx
P1
P2
HDMI
Tx
G
Out
GbE
GbE
Rx
G
Tx
P1
P2
GbE
1
G
Out
IR RS232 IR
HDMI
2
In
Tx
GbE
10
3
Rx
Rx
G
Tx
RS232
1
P1
P2
1
GbE
G
Out
IR
Rx
In
10
4
HDMI
In
Tx
GbE
10
RS232RS232 IR
Rx
G
Tx
P1
P2
1
GbE
Rx
G
Tx
G
Out
5
Rx
In
HDMI
10
Tx
GbE
P1
P2
1
GbE
G
Out
IR
Rx
G
Tx
RS232
6
HDMI
In
Tx
GbE
10
Rx Rx
Ethernet
HDMI
GbE
GbE
RS232
P1
P2
GbE
1
G
Out
Rx
G
Tx
IR
P1
P2
1
G
Out
IR
HDMI
In
GbE
10
Tx
78
In
Rx Tx
10
Compliance
Fast Acting
50/60 Hz
Fuse: 250V, 5A
Max Current: 5A
100 - 240 V ~
Serial Number
HIPOT
JI
H
GF
ED
C
BA
Installation
The Savant Audio/Video over IP 8-Port / 4-port Transmitter chassis
can be mounted using the included rack mounting ears and hardware
in a 3U rack style enclosure and is compatible with all standard 19-inch
National Electrical Manufacturers Association (NEMA) rack mounts.
For more information see the Savant Video over IP Deployment Guide
on the Savant Customer Community.
The following is a description of connections that can be made to the
Audio/Video over IP Switch:
1 = at 24 Hz
2 = at 25 Hz
3 = at 30 Hz
4 = at 50 Hz 5 = at 60 Hz
Video
HDR Supported
Supported
Formats
640x4805
720x4805
720x5764
800x6005
1024x7685
1280x7204
1280x7205
1280x10245
1920x10801
1920x1080
1920x10804
1920x10805
1920x12005
3840x21601
3840x21601
3840x21602
3840x21603
3840x21604
3840x21605
4096x21603
4096x21605
Dolby® Vision
Audio (Pass-through)
–DTS®
–DTS-X®
–DTS-HD Master Audio™
–DTS-HD (LBR)
–DTS-HD (HRA)
–DTS Digital Surround 96/24™
–Dolby® Atmos
–Dolby® TrueHD™
–Dolby® Digital (AC-3)
–Dolby® Digital Plus (E-AC-3)
–Multi-Channel PCM
–All HDMI Audio Formats
Audio (Down Mix)
–DTS®
–DTS-X®
–DTS-HD Master Audio™
–DTS-HD (LBR)
–DTS-HD (HRA)
–DTS Digital Surround 96/24™
–Dolby® TrueHD™
–Dolby® Digital (AC-3)
–Dolby® Digital Plus (E-AC-3)
–Multi-Channel PCM
Supported Audio and Video Formats

Savant Video Input IP Transmitter QRG | 009-1604-03 45 Perseverance Way, Hyannis, MA 02601
Copyright 2021 Savant Systems, Inc. | 210416 3 of 2 Savant.com | 508.683.2500
ELECTRIC SHOCK HAZARD: Prior to starting the process of removing and replacing a fuse, remove the AC Power by unplugging the power
cord from the rear of the unit.
1. Verify the power cord is unplugged from either the wall outlet or
the rear of the unit.
2. With a small flat blade screwdriver or similar, pry open and pivot
down the fuse holder cover.
3. Using that same screwdriver, gently loosen and pull the fuse
cartridge slowly out from the unit. Make note of the orientation
of the fuse cartridge as it is removed. When re-Installing, it is
important that it be positioned the same way as it came out to
ensure proper operation. Refer to diagram below
TIP: Mark the chassis and fuse holder to ease the re-installation
process.
4. Remove the old fuse from the cartridge and discard. Place the new
fuse into the cartridge.
5. Place the cartridge part way into the receptacle being careful to
align it as defined in the diagram. Gently push the fuse cartridge
until it seats with the terminals at the rear of the slot. If resistance
is encountered, DO NOT apply more pressure. Stop pushing on the
cartridge, remove it, verify the orientation is correct, and repeat
step 5 until cartridge is seated.
IMPORTANT: The orientation of the cartridge within the unit and location of the fuse within the cartridge are crucial to proper operation.
Make note of the orientation of the cartridge and the fuse location within the cartridge before removing.
Replacing the Fuse
2
3
4
5
When making connections, follow the guidelines set below to ensure a
safe and secure connection.
3-Pin Screw Down Connections
1. With a small slotted screwdriver,
turn the screws on the connector
counterclockwise (CCW) until the
silver crimps open enough to slide a
wire into the square slots.
2. Strip back insulation on each wire to
1/ inch and insert the stripped wire
into the proper connection.
3. Turn the screw clockwise (CW) until
the crimps tighten around each wire.
Gently tug on each wire a bit to
verify they are secure.
< 1/8 inch of
bare wire
exposed
