CYP CPLUS-V2PEL User manual

CPLUS-V2PEL
4K UHD+HDMI to Dual HDMI Scaler
with Signal Event Automation
Operation Manual
Operation Manual

DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes no
commitment to update or to keep current the information contained
in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means—
electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise—without express written permission and consent from
Cypress Technology.
© Copyright 2018 by Cypress Technology.
All Rights Reserved.
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.

SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the PSU
if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
• Please completely disconnect the power when the unit is not in
use to avoid wasting electricity.
REVISION HISTORY
VERSION NO. DATE SUMMARY OF CHANGE
RDV1 18/05/18 Preliminary release
VS1 21/05/18 Final technical review

CONTENTS
1. Introduction......................................................1
2. Applications.....................................................1
3. Package Contents ..........................................1
4. System Requirements......................................2
5. Features............................................................2
6. Operation Controls and Functions.................3
6.1 Front Panel ................................................. 3
6.2 Rear Panel.................................................. 4
6.3 OSD Menu.................................................. 5
6.4 RS-232 Control ......................................... 15
6.5 RS-232 Commands.................................. 15
7. Connection Diagram ....................................27
8. Specications ................................................28
8.1 Technical Specications ........................ 28
8.2 Video Specications............................... 29
8.2.1 Supported Resolutions................... 29
8.2.2 4K Conversion Rules....................... 30
8.3 Audio Specications............................... 31
8.4 Cable Specications .............................. 32
9. Acronyms .......................................................32

1
1. INTRODUCTION
This HDMI 4K UHD Scaler with Test Patterns and Signal Event
Automation is designed to upscale 1080p signals into 4K UHD (18Gbps)
or downscale 4K UHD (18Gbps) signals into 1080p with synchronized
digital audio output. A friendly and simple interface design allows
the user to control the unit while viewing the OSD directly on the
HDMI outputs. The input signal can be output to both HDMI outputs
simultaneously with a different resolution on each or the unit can
generate a test pattern at a preferred video resolution for easy on-site
display testing and validation.
Additional functionality such as EDID and HDCP management, and
basic signal event automation (via RS-232 or CEC) is also provided.
This UHD Scaler is the best tool to use with your HD and UHD signals.
This unit can be controlled easily by use of the front panel controls (with
OSD) or by RS-232.
2. APPLICATIONS
• HDMI signal splitting
• On-site equipment testing
• Production testing
• R&D design and testing
3. PACKAGE CONTENTS
• 1×HDMI to Dual HDMI Scaler
• 1×5V/2.6A DC Power Adapter
• 2×3-pin Terminal Block to 9-pin D-sub Adapter Cable
• 1×Shockproof Feet (Set of 4)
• 1×Operation Manual

2
4. SYSTEM REQUIREMENTS
• HDMI input source equipment such as a media player, video game
console or set-top box.
• HDMI receiving equipment such as HDTVs, monitors or audio
ampliers.
• The use of “Premium High Speed HDMI” cables is highly
recommended.
5. FEATURES
• HDMI input and output with 18Gbps (600MHz) 4K UHD with HDR
support
• DVI 1.0 compliant with the use of an HDMI-DVI adaptor
• HDCP 2.2 and HDCP 1.x compliant
• 1 HDMI input and 2 HDMI outputs
• Supports HDCP 2.2 to HDCP1.4 conversion
• HDMI signal bypass on both outputs or upscales 1080p signals to 4K
on output B and downscales 4K signals to 1080p on output A
• Supports HD resolutions up to 3840×2160@60Hz (4:4:4, 8-bit)
• Supports 4K HDR at 24/30Hz (YUV 4:4:4) and 50/60Hz (YUV 4:2:0) with
up to 12- bit color
• Supports 16-bit Deep Color up to 1080p@60Hz
• Supports pass-through of many audio formats including LPCM
2.0/5.1/7.1, Bitstream, and HD Bitstream
• Supports color space conversion of 4K@50/60Hz (4:4:4, 8-bit) or
4K@any (10/12-bit) sources
• Integrated EDID and HDCP management
• Basic signal event automation (via RS-232 or CEC)
• Test pattern generation at selected resolutions for on-site display
testing
• Controllable via front panel with OSD, and RS-232

3
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
SERV.
POWER 4K2K SYNC MENU PATTERN
TEST
ENTER
-
+
1 2 3 4 5 6 7
1SERV.: This slot is reserved for rmware update and EDID upload
use only.
2POWER LED: This LED will illuminate to indicate the unit is on and
receiving power.
34K2K LED: This LED will illuminate when the input source contains a
4K UHD signal.
4SYNC LED: This LED will illuminate when the input source is sending
signal.
5MENU Button: Press to enter the OSD menu, or to back out from
menu item.
6 − & +/TEST PATTERN Buttons: When the OSD menu is in use, press
these buttons to move within the menu. Outside of the OSD,
press these buttons together to instantly set the output timing to
1280x720@60Hz and display test patterns on both outputs.
7ENTER Button: Press to conrm a selection within the OSD or to go
deeper into a menu item.

4
6.2 Rear Panel
HDMI IN HDMI OUT RS-232
DC 5V
A B
OUT
IN
1 2 3 4
1HDMI IN: Connect to HDMI source equipment such as a media
player, game console or set-top box.
2HDMI OUT A~B: Connect to HDMI TVs, monitors or ampliers
for digital video and audio output. Each output can display a
different resolution with a choice between the HDMI source or a
test pattern.
3RS-232: Connect the upper 3-pins directly to a PC, laptop or other
serial control device to send RS-232 commands to control the unit.
Connect the lower 3-pins directly to a serial controllable device to
send signal event automation RS-232 commands to it.
4DC 5V: Plug the 5V DC power adapter into the unit and connect it
to an AC wall outlet for power.

5
6.3 OSD Menu
All primary functions of this unit can be controlled by using the OSD (On
Screen Display) which is activated by pressing the Menu button on
the front of the unit. Use the + (PLUS), − (MINUS), and ENTER buttons to
navigate the OSD menu. Press the Menu button to back out from any
menu item and then press it again to close the menu.
MAIN MENU STRUCTURE
Output
EDID
HDCP
OSD
Test Pattern A
Test Pattern B
Information
Firmware Update
EDID Upload
Factory Setting
The individual functions of the OSD will be introduced in the following
section. Items marked in BOLD are the factory default settings.
OUTPUT
2nd Level 3rd Level
Output A
Input 4K2K PASS THROUGH
Down Scaler 1080P
Fix Color YUV 4:2:0
Fix Deep Color 8 bit
YUV 4:2:x to RGB
Fix Color RGB
Output B
Input 1080P PASS THROUGH

6
OUTPUT
2nd Level 3rd Level
Input 1080P Up Scaler 4K2K
Up Scaler 4K2K YUV 4:2:0
Input 4K2K PASS THROUGH
Fix Color YUV 4:2:0
Fix Deep Color 8 bit
YUV 4:2:x to RGB
Fix Color RGB
Up 4K2K Scaler Enhancement
Gain Level 1 (Weak)
Level 2
LEVEL 3
Level 4
Level 5
Level 6 (Strong)
Output A
1) Input 4K2K: Controls the scaling of 4K sources on Output A.
■Pass Through: Will pass all 4K sources without modication.
■Down Scaler 1080P: Will convert all 4K sources to 1080P at the
same frame rate as the original.
■Fix Color YUV 4:2:0: Will convert 4K@50/60 (4:4:4) sources to the
YUV 4:2:0 color space.
■Fix Deep Color 8 bit: Will reduce any 4K sources with a bit depth
above 8-bit to 8-bit color.
■YUV 4:2:x to RGB: Will convert any 4K source using the YUV 4:2:2
or 4:2:0 color space to the RGB color space.
■Fix Color RGB: Will convert any 4K source using the YUV color
space to the RGB color space.
Output B
2) Input 1080P: Controls the scaling of 1080P sources on Output B.

7
■Pass Through: Will pass 1080p sources without modication.
■Up Scaler 4K2K: Will scale all 1080p sources to 4K(4:4:4) at the
same frame rate.
■Up Scaler 4K2K YUV 4:2:0: Will scale all 1080p@50/60Hz sources
to 4K(4:2:0) at the same frame rate.
3) Input 4K2K: Controls the scaling of 4K sources on Output B.
■Pass Through: Will pass all 4K sources without modication.
■Fix Color YUV 4:2:0: Will convert 4K@50/60 (4:4:4) sources to the
YUV 4:2:0 color space.
■Fix Deep Color 8 bit: Will reduce any 4K sources with a bit depth
above 8-bit to 8-bit color.
■YUV 4:2:x to RGB: Will convert any 4K source using the YUV 4:2:2
or 4:2:0 color space to the RGB color space.
■Fix Color RGB: Will convert any 4K source using the YUV color
space to the RGB color space.
Up 4K2K Scaler Enhancement
1) Gain: Provides control over the aggressiveness of the digital gain
processing when applied to the scaled output image.
EDID
2nd Level
INTERNAL FHD 2CH
Internal FHD 8CH
Internal UHD 2CH
Internal UHD 8CH
Internal UHD+ 2CH
Internal UHD+ 8CH
User
Sink Output A
Sink Output B
1) EDID: Select the EDID to use with the HDMI input.

8
HDCP
2nd Level
HDCP Support Off
Reference to Source
REFERENCE TO DISPLAY
1) HDCP: Selects the HDCP logic to use with the HDMI input.
OSD
2nd Level 3rd Level
Display Information ON
Off
OSD Timeout Off
5 SEC.
10 Sec.
15 Sec.
20 Sec.
25 Sec.
30 Sec.
35 Sec.
40 Sec.
1) Display Information: Enable or disable the informational OSD.
2) OSD Timeout: Set the length of time to wait before automatically
turning off the OSD menu if there is no user interaction. The timer
may also be disabled.

9
TEST PATTERN A
2nd Level 3rd Level
Mode OFF
On
Auto Pattern
Auto Timing
Pattern WHITE COLOR
Red Color
Green Color
Blue Color
Magenta Color
Yellow Color
Cyan Color
Color Bar
Ramp
Toggle
Resolution 720×480p@60
720×576p@50
1280×720p@50
1280×720P@60
1920×1080p@50
1920×1080p@60
3840×2160p@24
3840×2160p@25
3840×2160p@30
4096×2160p@24
4096×2160p@25
4096×2160p@30
HDCP DISABLE
Enable

10
TEST PATTERN A
2nd Level 3rd Level
Switch Time 10 SEC.
20 Sec.
30 Sec.
40 Sec.
50 Sec.
1 Min.
2 Min.
3 Min.
5 Min.
Auto Timing Select 720×480p@60
720×576p@50
1280×720p@50
1280×720p@60
1920×1080p@50
1920×1080p@60
3840×2160p@24
3840×2160p@25
3840×2160p@30
4096×2160p@24
4096×2160p@25
4096×2160p@30
1) Mode: Enable or disable the test pattern function on Output A.
■Auto Pattern: Will make the test patterns automatically change
based on the “Switch Time” setting.
■Auto Timing: Will show the selected test pattern and make the
output resolution automatically change based on the “Switch
Time” setting and the resolutions enabled under “Auto Timing
Select”.

11
2) Pattern: Selects the test pattern to output.
3) Resolution: Selects the output resolution to use.
4) HDCP: Enable or disable HDCP while outputting the test pattern.
5) Switch Time: Select the length of time between pattern or
resolution changes in the “Auto Pattern” and “Auto Timing”
modes.
6) Auto Timing Select: Select the resolutions to rotate through when
the “Auto Timing” mode has been enabled.
TEST PATTERN B
2nd Level 3rd Level
Mode OFF
On
Auto Pattern
Auto Timing
Pattern WHITE COLOR
Red Color
Green Color
Blue Color
Magenta Color
Yellow Color
Cyan Color
Color Bar
Ramp
Toggle
Resolution 720×480p@60
720×576p@50
1280×720p@50
1280×720P@60
1920×1080p@50
1920×1080p@60
3840×2160p@24

12
TEST PATTERN B
2nd Level 3rd Level
Resolution 3840×2160p@25
3840×2160p@30
4096×2160p@24
4096×2160p@25
4096×2160p@30
HDCP DISABLE
Enable
Switch Time 10 SEC.
20 Sec.
30 Sec.
40 Sec.
50 Sec.
1 Min.
2 Min.
3 Min.
5 Min.
Auto Timing Select 720×480p@60
720×576p@50
1280×720p@50
1280×720p@60
1920×1080p@50
1920×1080p@60
3840×2160p@24
3840×2160p@25
3840×2160p@30
4096×2160p@24
4096×2160p@25
4096×2160p@30

13
1) Mode: Enable or disable the test pattern function on Output A.
■Auto Pattern: Will make the test patterns automatically change
based on the “Switch Time” setting.
■Auto Timing: Will show the selected test pattern and make the
output resolution automatically change based on the “Switch
Time” setting and the resolutions enabled under “Auto Timing
Select”.
2) Pattern: Selects the test pattern to output.
3) Resolution: Selects the output resolution to use.
4) HDCP: Enable or disable HDCP while outputting the test pattern.
5) Switch Time: Select the length of time between pattern or
resolution changes in the “Auto Pattern” and “Auto Timing”
modes.
6) Auto Timing Select: Select the resolutions to rotate through when
the “Auto Timing” mode has been enabled.
INFORMATION
2nd Level 3rd Level
Timing
Input
[Current Status Details]Output A
Output B
HDCP
Output A [Current Status Details]
Output B
Firmware Version [Current Firmware Version]
1) INFORMATION: This screen displays information about the unit’s
current state, input and output status, as well as the current
rmware version.

14
FIRMWARE UPDATE
2nd Level 3rd Level
Are You Sure? NO
Yes
1) Firmware Update: Provides a way to update the unit’s rmware.
Insert a USB thumb drive, with a valid rmware le (*.bin format) in
the root directory, into the unit’s USB service port then select this
option. After the update is complete the unit will automatically
reboot.
EDID UPLOAD
2nd Level 3rd Level
Are You Sure? NO
Yes
1) EDID UPLOAD: Provides a way to upload a previously saved user
EDID. Insert a USB thumb drive, with a valid EDID le (*.bin format)
in the root directory, into the unit’s USB service port then select this
option. After the upload is complete the EDID will be available
under the EDID option as “User”.
FACTORY SETTING
2nd Level 3rd Level
Are You Sure? NO
Yes
1) FACTORY SETTING: Selecting this will reset all of the unit’s settings
back to their factory defaults.

15
6.4 RS-232 Control
Terminal Block In Controlling PC Serial Port Settings
Pin Denition Pin Denition Baud Rate 19200
1 TX 1 Data Bits 8
2 RX 2 RxD Parity Bit None
3 GND 3 TxD Stop Bits 1
4Flow Control None
Terminal Block Out 5 GND
Pin Denition 6
1 TX 7
2 RX 8
3 GND 9
6.5 RS-232 Commands
COMMAND
Description and Parameters
?
Show the full command list.
? N1
Show information about command N1.
N1 = {command} [RS-232 command]
HELP
Show the full command list.
HELP N1
Show information about command N1.
N1 = {command} [RS-232 command]
