MODEL SWZ
OPERATOR’S MANUAL
THIS MANUAL CONTAINS THE OPERATING
INSTRUCTIONS AND SAFETY INFORMATION
FOR YOUR SCAG MOWER. READING THIS
MANUAL CAN PROVIDE YOU WITH ASSIS-
TANCE IN MAINTENANCE AND ADJUST-
MENT PROCEDURES TO KEEP YOUR MOWER
PERFORMING TO MAXIMUM EFFICIENCY.
THE SPECIFIC MODELS THAT THIS BOOK
COVERS ARE CONTAINED ON THE INSIDE
COVER. BEFORE OPERATING YOUR MA-
CHINE, PLEASE READ ALL THE INFORMA-
TION ENCLOSED.
PART NUMBER 03044

FAILURE TO FOLLOW SAFE OPERATING PRACTICES
MAY RESULT IN SERIOUS INJURY.
* Keep all shields in place, especially the grass discharge chute.
* Before performing any maintenance or service, stop the machine and
remove the spark plug wire and ignition key.
* If a mechanism becomes clogged, stop the engine before cleaning.
* Keep hands, feet and clothing away from power-driven parts.
* Read this manual completely as well as other manuals that came
with your mower.
REMEMBER - YOUR MOWER IS ONLY AS SAFE AS THE OPERATOR!
Hazard control and accident prevention are dependent upon the awareness,
concern, prudence, and proper training of the personnel involved in the
operation, transport, maintenance, and storage of the equipment.
lways use the entire serial number listed on the serial number
tag when referring to this product.
WARNING:
This manual covers the operating instructions
and illustrated parts list for:
SWZ36-14KA with seri l number of 3230001-3239999
SWZ36-14KH with seri l number of 3240001-3249999
SWZ48-14KA with seri l number of 3250001-3259999
SWZ48-14KH with seri l number of 3260001-3269999
SWZ48-14KAE with seri l number of 3270001-3279999
SW48-16BV with seri l number of 3280001-3289999
SWZ-14KA with seri l number of 3300001-3309999
SWZ-16BV with seri l number of 3310001-3319999
SWZ-16BVE with seri l number of 3320001-3329999
SWZ-18BV with seri l number of 3330001-3339999
SWZ-20CVE with seri l number of 3340001-3349999

1
SIGNAL WORDS
This symbol means Attention! Become Alert!
Your Safety is Involved!" The symbol is used with
the following signal words to attract your attention
to safety messages found on the decals and through-
out this manual. The message that follows the
symbol contains important information about safety.
To avoid injury and possible death, carefully read the
message! Be sure to fully understand the causes of
possible injury or death.
Signal Word:
It is a distinctive word on safety decals and through-
out this manual that alerts the viewer to the existence
and relative degree of the ha ard.
The signal word DANGER denotes that an ex-
tremely ha ardous situation exists on or near the
machine that could result in high probability of death
or irreparable injury if proper precautions are not
taken.
The signal word WARNING denotes that a ha ard
exists on or near the machine that can result in injury
or death if proper precautions are not taken.
The signal word CAUTION is a reminder of safety
practices on or near the machine that could result in
personal injury if proper precautions are not taken.
INTRODUCTION
Your mower was built to the highest standards in the
industry. However, the prolonged life and maximum
efficiency of your mower depends on you following
the operating, maintenance and adjustment instruc-
tions in this manual.
We encourage you to contact your dealer for repairs.
All Scag dealers are informed of the latest methods
to service this equipment and provide prompt and
efficient service in the field or at their service shop.
They carry a full line of Scag service parts.
A replacement Operator's Manual is available from
your Scag Servicing Dealer or by contacting Scag
Power Equipment, Service Department, at P.O. Box
152, Mayville, WI 53050. Please indicate the com-
plete model and serial number of your Scag product.
USE O OTHER THAN ORIGINAL SCAG
REPLACEMENT PARTS WILL VOID THE
WARRANTY.
The Right and Left, Front and Rear of the
machine are referenced from the operators perspec-
tive when in the normal operating position and facing
the forward travel direction.
GENERAL SAFETY INSTRUCTIONS
READ THIS OPERATOR'S MANUAL and
instructions furnished with attachments.
Perform only those maintenance procedures de-
scribed in this manual. If major repairs are ever
needed or assistance is desired, contact an Author-
i ed Scag Dealer. To ensure optimum performance
and safety, always purchase genuine SCAG replace-
ment parts and accessories.
Your safety and the safety of others depends signifi-
cantly upon your knowledge and understanding of all
correct operating practices and procedures of this
machine.
WARNING:
CAUTION:

2
BEFORE OPERATING
1. Know the controls and how to stop quickly.
2. Do not allow children to operate the machine.
Do not allow adults to operate the machine
without proper instruction.
3. Remove all debris or other objects that might be
picked up and thrown by the cutter blades. Keep
all bystanders away from the mowing area.
4. Keep all shields, safety devices, and decals in
place. If a shield, safety device or decal is defec-
tive or damaged, repair or replace it before
operating. Also, check all nuts, bolts and screws
for proper tightness, to assure the machine is in
safe operating condition.
5. Do not operate the machine while wearing
sandals, tennis shoes, sneakers or shorts. Also,
do not wear loose fitting clothing which could get
caught in moving parts. Always wear long pants
and substantial shoes. Wearing safety glasses and
safety shoes is advisable and required by some
local ordinances and insurance regulations.
6. Fill the fuel tank with clean, fresh gasoline, with a
minimum octane rating of 87. Avoid spilling
gasoline. Gasoline is highly flammable, handle it
carefully.
A. Use an approved gasoline container.
B. Do not fill the tank while the engine is hot or
running.
C. Do not smoke while handling gasoline.
D. Fill the fuel tank outdoors and up to approxi-
mately 1" (25 mm) below the bottom of the
filler neck.
E. Wipe up any spilled gasoline.
7. Before attempting to start the engine, move the
speed adjustment lever into the neutral position,
move the blade engagement switch to the OFF
position, apply the parking brake, and move the
neutral latches to neutral.
WHILE OPERATING
1. Start the engine when the neutral latches are in
the neutral lock position, the cutter blades are
disengaged, the parking brake is on and the speed
adjustment lever is in the neutral position.
2. Do not run the engine in a confined area without
adequate ventilation. Exhaust fumes are ha ard-
ous and could possibly be deadly.
3. Using the machine demands attention. To
prevent loss of control:
A. Mow only in daylight or when there is good
artificial light.
B. Watch for holes or other hidden ha ards.
C. Do not drive close to a drop-off, ditch, creek
bank, or other ha ard.
D. Reduce speed when making sharp turns and
when turning on hillsides.
E. Always be sure of your footing. Keep a firm
hold on the handles and walk---never run.
F. Do not operate where conditions are slippery.
4. The discharge chute must always be installed and
in the down position on the side discharge cutter
deck except when the Scag optional grass
catcher or mulching plate are properly installed.
If the discharge area should plug, shut the engine
off and wait for all movement to stop before
removing the obstruction.
5. Disengage the blades and wait for them to stop
before crossing gravel drives, walks or roads.
6. Shut the engine off and wait until the blades
come to a complete stop before removing the
grass catcher container.
7. Never raise the cutter deck while the blades are
rotating.
8. Always park the mower and/or start the engine
on a level surface. Apply the parking brake to
prevent the mower from moving when you are
not in the operators position.

3
9. If the cutting blades should strike a solid object
or the equipment should start to vibrate abnor-
mally, stop the engine, disconnect the spark plug
wire, and check immediately for the cause.
Vibration is generally a warning of trouble.
Check the machine for damaged or defective
parts. Repair any damage before starting the
engine or operating the cutter deck. Be sure the
blades are in good condition and the blade bolts
are tight.
10. Reduce speed and exercise extreme caution on
slopes and in sharp turns to prevent tipping or
loss of control. Be especially cautious when
changing directions on slopes.
DO NOT operate on steep slopes. To check a
slope, attempt to back up it (with the cutter deck
down). If the machine can back up the slope
without the wheels slipping, reduce speed and
use extreme caution. ALWAYS FOLLOW OSHA
APPROVED OPERATION.
11. Do not touch the engine or muffler while the
engine is running or soon after it is stopped.
These areas could be hot enough to cause a burn.
12. Before leaving the operators position or leaving
the mower unattended, move the speed adjust-
ment lever into the neutral position, place the
neutral latches in the neutral lock position, apply
the parking brake, and move the blade engage-
ment switch to OFF. Shut the engine OFF and
remove the key.
13. Do not pass or stand on the grass discharge side
of any mower with the engine running. Stop
operation when another person approaches.
14. Use only Scag approved riding attachments.
Scag Approved Riding Attachments:
RS-ZT
Using unapproved attachments, (especially "stand-
up" riding attachments) may be ha ardous.
MAINTENANCE AND STORAGE
1. Disconnect the spark plug wire from the spark
plug to prevent accidental starting of the engine
when servicing, adjusting or storing the machine.
2. If the mower must be tipped to perform mainte-
nance or adjustment, remove the battery, drain
the gasoline from the fuel tank and the oil from
the crankcase.
3. To reduce potential fire ha ard, keep the engine
free of excessive grease, grass, leaves and accu-
mulations of dirt.
4. Be sure the machine is in safe operating condition
by keeping nuts, bolts, and screws tight. Check
the blade mounting bolts and nuts frequently to
be sure they are tightened.
5. If the engine must be running to perform a
maintenance adjustment, keep hands, feet, cloth-
ing and other parts of the body away from the
cutter deck blades and other moving parts.
6. Do not overspeed the engine by changing gover-
nor settings. To be sure of safety and accuracy,
have an authori ed dealer check maximum engine
speed with a tachometer.
7. The engine must be shut off before checking the
oil or adding oil to the crankcase.
8. Allow the engine to cool before storing the
mower in any enclosure such as a garage or
storage shed. Make sure the fuel tank is empty if
the machine is to be stored in excess of 30 days.
Do not store the mower near any open flame or
where gasoline fumes may be ignited by a spark.
WARNING:
WARNING
FALLING HAZARD
USE ONLY SCAG APPROVED
RIDING ATTACHMENTS
SEE OPERATOR'S MANUAL
481109

4
9. Always store gasoline in a safety-approved, red
container.
10. Be careful when servicing the battery as it con-
tains acid, which is corrosive and could cause
burns to skin and clothing.
11. Batteries release explosive gases when being
charged or discharged. Keep batteries away
from any source of sparks and/or flame.
12. Make sure all hydraulic connections are tight and
all hydraulic hoses and lines are in good condi-
tion before starting the machine.
13. Hydraulic fluid is under high pressure. If you
need service on your hydraulic system, please see
your authori ed Scag dealer.
INITIAL RUN-IN PROCEDURES
(FIRST DAY OF USE OR APPROXI-
MATELY 10 HOURS)
1. Check the belts for proper tension at 2, 4 and 8
hours. Adjust as needed.
2. Check the steering control rods and the speed
control for neutral adjustment. (See Adjust
ments, page 6-8)
3. Check the tires for proper pressure.
Caster Wheels 25 psi.
Drive Wheels 15 psi.
4. Check for loose hardware. Tighten as needed.
5. Check the safety switches for proper adjustment:
* The engine should crank and start if the
machine is in neutral, the PTO engage-
ment switch is OFF and the parking brake
is ON.
6. Apply lubricant to all the grease fittings. Lubri-
cant was applied at the factory. This is just a
precautionary check to make sure that all the
fittings have been lubricated.
MOWER OPERATION
-NOTE-
Use gasoline with an octane rating no less than
87.
* The speed adjustment lever must be in
NEUTRAL.
* The blade clutch switch must be in the OFF
position.
* The neutral latches must be in the neutral
lock position.
* The key switch must be on.
* The parking brake must be on.
3. Start the engine:
* Choke as required. If the engine is cold, pull
the choke knob out. When the engine starts,
slowly push the choke in. If the engine stalls,
repeat the above operation. When the engine
is warm, choking may not be necessary.
4. Engage the cutter blades by lifting and pushing
the blade cluch switch into the ON position. Pull
the switch to the OFF position to disengage the
cutter blades.
-NOTE-
When PTO is engaged or (possibly) disengaged,
a squealing sound rom the underside o the
machine is normal. It is caused by the electric
clutch plates meshing as the mower comes up to
speed. For best equipment li e, engage the
clutch with the engine at 1/2 throttle, not under
ull load.
1. Read and understand the safety instructions
before attempting to operate this machine.
2. Before starting the engine:
* Check the oil level in the engine and the
hydraulic reservoir.
* Fill the fuel tank with clean, fresh, lead-free
gasoline.
* Open the fuel valve on the bottom of the
fuel tank.

5
If you are not familiar with the operation of the
hydrostatic drive and zero turn feature, practice
turning and maneuvering with the hand controls
before engaging the blades.
5. Release the parking brake. Move the speed
adjustment lever to the desired mowing speed.
-NOTE-
Top speed is suggested only or transport!
6. While squee ing the steering brake levers with
both hands, release both neutral latches.
7. When the steering brake levers are released, the
machine will travel straight. To make a right
turn, squee e the RH lever. To turn left,
squee e the LH lever.
8. TO STOP, squee e both levers, lock the neutral
latches, and move the speed adjustment lever to
neutral.
9. To move the machine in reverse, squee e up on
both steering control levers.
10. To "freewheel" or move the machine around
without the engine running, turn the dump valve
levers located at the back of the pumps to the
"freewheel" positions.(see Figure 1). To operate
the machine the dump valve levers must be
returned to the closed positions.
ire pressure can be adjusted for
WARNING:
Dump Valve Levers
(normal position)
SGB112
Figure 1 Dump Valves
CUTTER DECK BELT ADJUSTMENTS
-NOTE-
The hydro drive belt is spring loaded and does
not require adjustment.
1. Remove the belt cover.
2. Adjust the cutter deck drive belt using a belt
tension gauge. Adjust the belt so that the belt
moves 1/2" with 10 pounds of pressure. Adjust
the tension by tightening or loosening the J-bolt
nut. (See figure 2)
SC400G
BELT
WASHER
"J" BOLT
NUT
CUTTER DECK DRIVE BELT TENSION
ALIGNMENT IDLER - L.H.
END OF L-SHAPED
BRACKET
Figure 2 Deck Drive Belt Adjustment
-NOTE-
Due to initial belt stretch and to prevent the belt
rom slipping, check this adjustment a ter the
irst 2 hours, 4 hours and 8 hours o operation.
3.Adjust the RH blade drive belt using a belt
tension gauge. Adjust the belt so that the belt
moves 1/2" with 10 pounds of pressure. Adjust
the tension by tightening or loosening the J-bolt
nut. (See figure 3)

6
"J" Bolt
Nut
Belt
Deck
Washer
Figure 3. Cutter Deck Belt Adjustment R.H.
4. Replace the belt cover.
CUTTER DECK ADJUSTMENTS
Due to the many cutting conditions that exist, it is
difficult to suggest a cutter deck setting that will
work for every lawn. There are two adjustments
that can be made on these decks, pitch and height.
PITCH is the angle of the blades (comparing front
to rear). A 1/4" downward pitch (front of deck
down) is recommended for best cutting perfor-
mance.
HEIGHT is the nominal distance the blade is off of
the ground. This measurement is made with the
blades pointed side to side and distance is measured
between cutting tip and ground. (Also see Blade
Height Adjustment)
Changes to the cutting height can be achieved by
repositioning the cutter deck. (This adjustment will
also effect the pitch of the deck). There are three
available positions (see figure 4).
SC405G
LOW CUT (1 3/4"- 3")
HIGH CUT (3 1/4"- 4 1/2")
MID RANGE
(2 1/2"- 3 3/4")
CUTTER DECK HEIGHT ADJUSTMENT
Figure 4 Cutting Height Adjustment
Caster spacers also can be repositioned to change
cutting heights and to change the pitch of the deck.
(See figure 5)
SC406G
PIN SPACERS
REPOSITIONING SPACERS
Figure 5. Caster Wheel Spacers
BLADE HEIGHT ADJUSTMENT
Adjusting the blade height can be done by moving
any number of the five smaller 1/4" spacers on the
blade mounting bolts to the top of the spindle shaft or
below the spindle shaft.
-NOTE-
All blades should be positioned equally.
For best cut and discharge, a minimum of three
spacers should be installed between the blade and the
spindle. (See figure 6)

7
CUTTER BLADES
Do not sharpen beyond 1/3 of the width of the blade.
(See figure 7)
-NOTE-
Dress the blade with a ile. Using a wheel
grinder may burn the blade. Check the balance
o the blade. I blades are out o balance, vibra-
tion and premature wear o spindle assembly can
occur. See your authorized Scag dealer or
blade balancing or special tools, i you choose to
balance your own blades.
SC407G
Figure 6. Blade Spacers
SC4O8G
ANGLE BLADE BACK
DO NOT CUT IN
X MUST NOT EXCEED
1/3 BLADE WIDTH
X
30
Figure 7. Blade Sharpening
NEUTRAL ADJUSTMENT
1. Raise the drive wheels off the ground and block
the caster wheels.
2. Remove the speed control spring and the steer-
ing control rod from the machine. (See figure 8)
Steering Control
Rod
Spring Handle Bellcrank
SC160G
Bolts
Figure 8 Neutral Adjustment
3. Loosen the wing nut and let the speed adjust-
ment bearing lever fall away from the cam.
4. Start the engine and observe the drive wheels. If
the drive wheels are rotating, Loosen the bolts
on the neutral adjustment handle and move the
handle up or down until the wheels are in neu-
tral. (See figure 8)
5. Tighten the bolts on the neutral adjustment
handle. When tightening the bolts, hold the
bellcrank to prevent it from moving and throw-
ing off the neutral adjustment.
6. Turn the engine off.

8
STEERING CONTROL ROD
ADJUSTMENT
-NOTE-
This adjustment is made to allow the steering
control levers to be moved out o the neutral
latch without engaging reverse.
1. Connect the steering control rods into the steer-
ing control levers on the handle. Do not install
the hair pin at this time.
2. Turn the swivel joint on the steering control rods
until the swivel joint is centered in the slot in the
bellcrank.
3. Remove the steering control rods from the
machine. Install the speed control spring onto
the swivel joint. Reinstall the steering control
rods onto the machine and secure using the hair
pins.
-NOTE-
Be ore proceeding with this adjustment be sure
that the tire pressures are correct. (see page 4)
and that the neutral adjustment and the steering
control rod adjustment have been completed.
1. Engage the neutral latch on both steering control
levers and move the speed adjustment lever into
the neutral position.
2. Position the speed adjustment lever so that the
bearing just contacts the speed adjustment cam.
(See figure 9)
Steering Control Rod
Speed Control Spring Bellcrank
SC161G
Swivel
Joint
Speed Adjustment
Cam
Bearing
Speed
Adjustment
Bearing Lever
TRACKING ADJUSTMENT
3. Tighten the bearing securing the speed adjust-
ment bearing lever and repeat on the opposite
side.
4. With the machine on a flat level surface, start the
engine and place the speed adjustment lever into
the speed that will most often be used.
5. Squee e the steering control levers and release
the neutral latch. Slowly release the steering
control levers allowing the machine to move
forward.
6. If the machine pulls to one side, put the speed
adjustment lever back into the neutral position
and turn the engine off.
7. On the side that the machine pulled toward,
loosen the wing nut securing the speed adjust-
ment bearing lever and move the bearing 1/16"
away from the cam. Start the engine and recheck
the tracking. Adjust as needed.
8. If tracking cannot be achieved, contact your Scag
servicing dealer.
PARKING BRAKE
1. Adjust the parking brake so that when the brake
hand lever is against the stop on the handle bar,
the brake levers on the brake shaft weldment are
against the stops on the engine deck.
Adjust the brake only enough to hold the
machine. Excessive force may cause damage
to the machine or brake components.
2. Adjust the brake actuator rod on either side of
the machine to obtain proper brake adjustment.
CAUTION:

9
COMMENTS
PROCEDURE
LUBRICATION & MAINTENANCE
BREAK-IN
8 HOURS (DAILY)
40 HOURS (WEEKLY)
100 HOURS (BIWEEKLY)
500 HRS OR ANNUALLY
+ Grease spindle until grease comes out the relief valve
Compatible Greases: Lidok EP #2 (found at industrial shops)
Ronex MP (Exxon service stations)
Shell Alvania (Shell service stations)
Mobilux #2 (Mobil service stations)
Super Lub M EP #2 (Conoco service stations)
X
XCheck all hardware for proper tightness
Change engine oil and filter at 5 hours
X Check engine oil Do not over fill
X Remove debris from under belt cover More often if needed
X Sharpen cutter blades More often if needed
X Grease spindle bearings US Lithium MP White Grease 2125
X Clean air filter More often if needed
X Check belt tension
X Check tire pressure Add or adjust as required
X Check battery level Adjust as needed
X Replace air filter More often if needed
X Grease caster wheel bearings Chassis grease
X Grease caster wheel pivot shafts Chassis grease
X Grease idler pulley bracket on cutter deck Chassis grease
X Change hydrostatic oil filter Clean area before removing the filter
X Change engine oil and filter See engine manufacturer information
X Grease idler arm pivots Chassis grease
X Grease brake hand lever Chassis grease
X Grease brake actuator levers Chassis grease
X Check all hardware for proper tightness
X Adjust air gap on electric clutch Contact your Scag dealer for information about
X Drain hydraulic system and replace oil making this adjustment

10
Stringers - Occasional Low engine RPM Run engine at full 3600 RPM
Blades of Uncut
Grass Ground speed too fast Slow speed to adjust for conditions
Wet grass Cut grass after it has dried out
Dull blades, incorrect sharpening Sharpen blades
Deck plugged, grass accumulation Clean underside of deck
Belts slipping Adjust belt tensions
Streaking - Strips of Dull, worn blades Sharpen blades
Uncut Grass in Cutting
Path Incorrect blade sharpening Sharpen blades
Low engine RPM Run engine at full 3600 RPM
Belt slipping Adjust belt tension
Deck plugged, grass accumulation Clean underside of deck
Ground speed too fast Slow speed to adjust for conditions
Wet grass Cut grass after it has dried out
Bent blades Replace blades
Width of Deck
SGB018
CONDITION CAUSE CURE
Width of Deck
SGB020
Width
of
Deck
Width
of
Deck
SGB019
Streaking - Strips of Not enough overlapping Increase the overlap of each
Uncut Grass Between between rows pass
Cutting Paths
TROUBLESHOOTING CUTTING CONDITIONS

11
CONDITION
TROUBLESHOOTING
CAUSE CURE
Sloping Ridge Across Tire pressures not equal Check and adjust tire pressure
Width of Cutting Path Wheels uneven Check and adjust tire pressure
Deck mounted incorrectly See your authorized SCAG dealer
Uneven Cut on Flat Lift worn off of blade Replace blade
Ground - Wavy
High-Low Blade upside down Mount with cutting edge toward
Appearance, ground
Scalloped Cut, or
Rough Contour Deck plugged,grass accumulation Clean underside of deck
Too much blade angle (deck pitch) Adjust pitch and level
Deck mounted improperly See your authorized SCAG dealer
Bent spindle area See your authorized SCAG dealer
Dull blade Sharpen blade
Uneven Cut on Uneven ground May need to reduce ground speed,
Uneven Ground - raise cutting height, and/or change
Wavy Appearance, direction of cut
High-Low Scalloped
Cut, or Rough Contour
Width of Deck
SGB020
Width of Deck
SGB021
Width of Deck
SGB023

12
Scalping - Blades Low tire pressures Check and adjust pressures
Hitting Dirt or
Cutting Very Close to Ground speed too fast Slow speed to adjust for conditions
the Ground Cutting too low May need to reduce ground speed,
raise cutting height, change direction
of cut, and/or change pitch and level
Rough terrain May need to reduce ground speed,
raise cutting height, and/or change
direction of cut
Ground speed too fast Slow speed to adjust for conditions
Wet grass Cut grass after it has dried out
Step Cut Blades not mounted evenly Adjust pitch and level
Ridge in Center of
Cutting Path Bent blade Replace blade
Internal spindle failure See your authorized SCAG dealer
Mounting of spindle incorrect See your authorized SCAG dealer
Slope Cut - Sloping Bent spindle mounting area See your authorized SCAG dealer
Ridges Across Width
of Cutting Path Internal spindle failure See your authorized SCAG dealer
Bent deck housing See your authorized SCAG dealer
TROUBLESHOOTING
CONDITION CAUSE CURE
Width of Deck
SGB024
Width of Deck
SGB025
Width of Deck
SGB022

13
TECHNICAL SPECIFICATIONS
ENGINES
General Type: Heavy duty industrial/commercial
Brand: Kohler, Kawasaki, Briggs & Stratton
Models: Kohler CV14T, CVE 20;Kaw. FC420V;B&S 303776, 350777
Horsepower: Kohler 14HP& 20HP; Kaw. 14HP; B&S 16HP & 18HP; Kaw. 17HP
Type: 4 cycle gas, vertical shaft engines
Displacement: Kohler: 14HP = 398cc, 20 HP= 624 cc
Kawasaki: 14HP = 423cc, 17HP = 494cc
B & S 16HP = 480 cc, 18HP = 570cc
Cylinders: Varied - see manufacturer's specifications
Governor: Mechanical type governor with variable speed control set
at 3600 rpm (+75 rpm), idle set at 1200 rpm (+75 rpm)
Exhaust Group: Single exhaust canister muffler
Fuel Pump Group: Varied - See manufacturer's specifications
Oil Pump Group: Varied - See manufacturer's specifications
Valve Group: Varied - See manufacturer's specifications
Starter/Electrical: Electronic Ignition with recoil starter or 12 volt battery with
alternator, solid state ignition with key start
Charging System: 15 amp
ENGINE DECK
Thickness: 7 gauge steel
Fuel Tank: 5 gallon (19.0 litres) seamless polyethylene
Drive Wheels/Tires: 16x6.50-8 four-ply pneumatic tubeless, radius edge
Brakes: Dynamic braking through hydro drive system
Axles: 1" tapered
Handle Bars: 1-1/4" diameter
DRIVE SYSTEM
Type: Hydro drive with two variable displacement pumps and two
cast-iron high torque motors
Hydro Pumps: Two Hydro-Gear Model BDP 10L pumps with dump valves for
movement without running the engine
Drive Wheel Motors: Two 12 cu. inch cast-iron high torque motors
Hydro Fluid Cooling Group: Heavy-duty cooling radiator, 7 qt. capacity cooling
reservoir, uses, SAE 10W30 fluid and 10 micron filter
Steering / Travel Control:: Independent handle controls for each wheel, squeeze to move
from forward to neutral to reverse, neutral lock lever, speed
range controlled with single lever (patented design), in-field
tracking adjustment with no tools necessary
Parking Brakes: 7.5" drum, band brake, one on each wheel
Dump Valves: Allows for movement without engine running
Axles: 1" tapered motor shafts
Wire Harness: 14 gauge wire
Safety Group: Handle actuated operator presence system (patented design),
blade / clutch and transmission interlock to engine kill
Forward Speed Range: 0 to 7.4 mph
Reverse Speed Range: 0 to 3.0 mph
Date of Issue: December 8, 1997
SpecificationsSubjecttoChangeWithoutNotice

14
TECHNICAL SPECIFICATIONS (CON'T)
CUTTER DECKS SWM 36, SWM 48, SWM 52, SWM 61, SWM 72
Type: Out-front design with anti-scalp rollers
Construction: SWM36,48: 7-gauge steel with 7-gauge (3/16") steel skirt
SWM52,61,72:10-gauge steel with 7-gauge (3/16") steel
skirt
Cutting Width: 35.5" (90.2 cm), 48.0 (122.0 cm), 52.0 " (132.0 cm),
61.0 " (155.0 cm), 71.5" (181.6 cm)
Cutting Height Adjustment: Adjustable from 1-3/4" to 4-1/4" in 1/4" increments
Cutter Blades: .204 thick, milled edge, 5150 alloy steel
SWM 36: Two (2) 18" SWM 48: Three (3) 16.5"
SWM 52: Three (3) 18"SWM 61: Three (3) 21"
SM72: Three (3) 24" blades
Blade Engagement: Electric blade brake clutch with instrument panel switch
Discharge Opening: Extra wide 11.5", 13.75 " discharge opening with hinged
chute
Caster Wheels: 9.4 x 3.5 smooth tread flotation, inner tubes, split rims, roller
bearings, with quick pin removal
Spindles: Cast housing, taper roller bearing, low maintenance with
top access grease fitting and grease overfill relief poppet
Spindle Pulleys: Cast-iron with easily removed taper hubs
Idler Pulley: 5" diameter pulley, welded and riveted construction,
1-3/8" O.D. Bearing
Idler Arm: Heavy duty idler arm of 1/4" channel steel
Cutter Deck Belts: B-section with Kevlar cord
ADDITIONAL SPECIFICATIONS
OPTIONAL ITEMS/ATTACHMENTS
Fabric Grass Catcher: GC-F4 Grass Catcher with 4 cubic ft. capacity
Metal Grass Catcher: GC-4D Grass Catcher with 4 cubic ft. capacity and rope pull
dump or pick-up and dump
Steerable Sulky: RS-ZT Steerable Sulky with padded seat and full articulation
for zero-radius turning
Mulching Plate: Steel plate fits over discharge opening. No blade change or
or removal required. Installs and removes in the field.
APPROXIMATE DIMENSIONS SWM36 SWM48 SWM52 SWM61 SWM72
Length: 74.0" 74.0" 74.0" 76.0" 76.0"
Length with Grass Catcher: 74.0" 74.0" 74.0" 76.0" 76.0"
Tracking Width: 37.0" 42.0" 42.0" 42.0" 42.0"
Width: 54.5" 60.0" 60.0" 70.0" 81.0"
Width (with discharge chute up): 37.5" 53.0" 53.0" 63.0" 74.0"
With with grass catcher: 55.0" 69.0" 69.0" 80.0" 91.0"
Height: 40.5" 40.5" 40.5" 40.5" 40.5"
Height with grass catcher: 40.5" 40.5" 40.5" 40.5" 40.5"
Weight 510 lbs. 550 lbs. 590 lbs. 625 lbs. 695lbs.
Weight with grass catcher: 550 lbs. 590 lbs. 630 lbs. 665lbs. 730 lbs.
Turning Radius: Zero Zero Zero Zero Zero
Date of Issue: December 8, 1997
SpecificationsSubjectToChangeWithoutNotice

2
36" CUTTER DECKS
19
20
21
22
21
20
24 23
18
25
37
26
27
28
29
30 31
33 4
34 32 31
35
14 1
36 38
45
11
43
42
44
45
43
46
44
11 59
60
58
9
48
2
14
58
22
42
50
52
51
49
69
49
SC409GC
8
62
5
22
3
65
63
6
66
67
64
5
39 41
41
A
A
57
14
56
40
55
35
11
10
17
16
15
15A
12
11
13
37
754
55
53
61
47
40
68

3
1 46850 Cutter Deck (Includes decals)
2 46631 CutterSpindleAssembly
3 43312 Spacer,Outside
4 48307-08 TaperedNut,5/16-24
5 481022 TaperedBearing(two)
6 43294 SpindleHousing,TaperedBearing
7 04001-108 Bolt,5/16-18x4-1/14" Hex Head
8 43298 SpindleShaft
9 04001-77 Hex Head Bolt, 3/8-16 x 3-1/2"
10 04063-08 Key, 1/4 x 2"
11 43278 Spacer,CutterBlade
12 04001-10 Hex Head Bolt, 5/16-18 x 1-1/4"
13 481050 Spring,ChuteReturn
14 04019-03 Nut,5/16-18SerratedFlange
15 48108 CutterBlade,18"
15A 48185 CutterBlade,18"High Lift
16 04040-10 Flat Washer, 5/8" W
17 04001-41 Hex Hd. Bolt, 5/8-11 x 9-1/2"
18 46079 CasterAssembly (includes19-28)
19 04066-01 Quick Pin
20 43037-01 Spacer, Caster Yoke, 1/2" thick
21 48100-01 BronzeBearing
22 48114-04 GreaseFitting
23 46082 Support Assy. (incl. 21-23)
24 45006 CasterYoke
25 43022 Sleeve,CasterWheelBearing
26 04001-37 Hex Hd. Bolt, 1/2-13 x 5-1/2"
27 04021-07 HexLocknut, 1/2-13
28 48307 WheelAssy. (incl. 4,29-34)
29 48307-02 Tireonly,CasterWheel
NS 48006-03 Inner Tube Only (notshown)
30 48307-04 RimPair,CasterWheel
31 48006-07 Retainer,Bearing,CasterWheel
32 48006-06 RollerBearing,CasterWheel
33 48114-03 GreaseFitting 45deg.,1/4-28
34 48006-05 Hub Assy. (incl. bolts)
35 04017-16 Capscrew, 5/16-18 x 3/4" Serr. Flange Hex Head
36 461054 DischargeChute
37 04021-10 Hex Nut, 5/16-18 Elastic Stop
38 04001-09 Hex Head Bolt, 5/16-18 x 1"
39 46797 Belt Cover Assembly
Ref. Part
No. No. Description Ref. Part
No. No. Description
36" CUTTER DECK
40 04041-07 Flat Washer, 3/8" (.391 x .938 x .105)
41 04029-03 WingNut,3/8-16
42 48924 Pulley
43 48926 TaperedHub,1.125Bore
44 04001-01 Hex Head Bolt, 1/4-20 x 3/4"
45 04020-09 HexNut,5/8-11
46 48204 Belt,Blade Drive
47 43077 Spacer
48 04021-05 Nut,CenterLocknut - 3/8-16
49 04019-04 Nut,3/8-16SerratedFlange
50 04004-02 Support,BeltCover
51 04017-42 Capscrew, 7/16-14 x 1" Serr. Flange
52 04019-05 HexNut,7/16-14SerratedFlange
53 43277 Spacer,J-Hook
54 04041-07 FlatWasher
55 04021-09 Nut,3/8-16ElasticStop
56 45423 IdlerPivot
57 46748 Idler Arm Assy. (incl. 22 & 58)
58 48100-02 Bushing,1-1/8x 1.0Flanged
59 04050-05 RetainingRing,1-1/8"Ext."E"
60 44078 J-Hook
61 48269 IdlerPulley, Belt Clutch
62 481024 Seal,CutterSpindle
63 43297 SpindleBushing
64 43296 Spacer,Inside
65 481035 Nut
66 48677 ReliefFitting,CutterSpindle
67 481025 Seal,CutterSpindle
68 48098 Shield,Spindle
69 04029-04 WingNut3/8-16(SM)
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.

4
48", 52", 61", & 72" CUTTER DECKS
19
20
21
22
21
20
24 23
18
25
37
26
27
28
29
30
31
33 82
34 32 31
35
79
14
80
38
1
49
52
50 55 54
45
11
43
4
44 45
43
47
44
11 48
11
44
45
43 42
46
51
64
65
9
61
14
60
22
56
61
59
51
62 40
74
40
76
63
14
22
77
78
77
67
57
68
64
51
75
40
51
35
35
50
14
41 63
40
58
2
SC151GC
8
66
5
22
70
69
71
6
7
72
3
5
11
10
16
15
12
11
17
36
13
37 73
38
A
A
81
81
81
53
41
41
39
14

5
Ref. Part
No. No. Description 4852 61 72
1 46851 Cutter Deck (Includes decals) x
1 46751 Cutter Deck (Includes decals) x
1 46752 Cutter Deck (Includes decals) x
1 46608 Cutter Deck (Includes decals) x
2 46631 SpindleAssembly x x x x
3 43296 Sleeve,CutterSpindle x x x x
4 48924 Pulley x x x x
5 481022 TaperedBearing(two) x x x x
6 43294 SpindleHousing x x x x
7 48677 ReliefFitting,CutterSpindle x x x x
8 43298 SpindleShaft x x x x
9 45037 Idler Pivot xxxx
10 04063-08 Key, 1/4 x 1/4 x 2" x x x x
11 43278 Spacer,CutterBlade x x x x
12 04001-10 Hex Head Bolt, 5/16-18 x 1-1/4" x x x x
13 481050 Spring,ChuteReturn xxxx
14 04019-03 Nut,5/16-18Serr.Flange x x x x
15 48110 CutterBlade16-1/2" x
15 48108 CutterBlade18" x
15 48111 CutterBlade21" x
15 48112 CutterBlade24" x
15 48184 CutterBlade 16-1/2"HighLift x
15 48185 CutterBlade 18" High Lift x
15 48304 CutterBlade 24" High Lift x
16 04040-10 Flat Washer, (.688 x 1.75 x .134) x x x x
17 04001-41 Hex Head Bolt, 5/8-11 x 9-1/2" x x x x
18 46079 Caster Assy. (incl. 19-28) x x x x
19 04066-01 Quick Pin x x x x
20 43037-01 Spacer, Caster Yoke, 1/2"Thick x x x x
21 48100-01 Bushing, 5/8 x 1",Flanged x x x x
22 48114-04 GreaseFitting Str. 1/4-28 x x x x
23 46082 SupportAssy.,(incl.21-23) x x x x
24 45006 CasterYoke x x x x
25 43022 Sleeve,CasterWheelBearing x x x x
26 04001-37 Hex Head Bolt, 1/2-13 x 5-1/2" x x x x
27 04021-07 Nut,1/2-13ElasticStop x x x x
28 48307 Wheel Assy. , (incl. 29-34,81) x x x x
29 48307-02 TireOnly, Caster Wheel x x x x
NS 48006-03 Inner Tube Only, Caster Wheel x x x x
30 48307-04 RimPair,CasterWheel x x x x
31 48006-07 BearingRetainer,CasterWheel x x x x
32 48006-06 RollerBearing,CasterWheel x x x x
33 48114-03 GreaseFitting 45 Deg.,1/4-28 x x x x
34 48006-05 Hub Assy., (incl. Bolts) x x x x
35 04017-16 Capscrew, 5/16-18 x 3/4" x x x x
36 461055 DischargeChute x x
36 461054 DischargeChute x x
37 04021-10 Nut,5/16-18Elastic Stop x x x x
38 04001-09 Hex Head Bolt, 5/16-18 x 1" x x x x
39 46798 Belt Cover, (incl. Decals) x
39 461095 Belt Cover, SWM 48 17KA x
39 46804 Belt Cover, (incl. Decals) x
39 46805 Belt Cover, (incl. Decals) x
39 46848 Belt Cover, (incl. Decals) x
40 04041-07 Flat Washer, (.391 x .938 x .105) x x x x
41 04029-03 WingNut,3/8-16 xxxx
42 48924 Pulley x x
42 48753 Pulley x
42 48967 Pulley x
43 48926 TaperedHub xxxx
44 04001-01 Hex Head Bolt, 1/4-20 x 3/4" xxxx
45 04020-09 Nut,5/8-11HexHead x x x x
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.
46 48923 Pulley,Double x x
46 48940 Pulley,Double x
46 48966 Pulley,Double x
47 48087 Belt,RHBladeDrive x
47 48285 Belt,RHBladeDrive x
47 48265 Belt,RHBladeDrive x
47 48295 Belt,RHBladeDrive x
48 48089 Belt,Blade Drive x
48 48286 Belt,Blade Drive x
48 48088 Belt,Blade Drive x
48 48296 Belt,Blade Drive x
49 04021-05 Nut,3/8-16Centerlock x x x x
50 04019-04 Nut,3/8-16Serr.Flange x x x x
51 04021-09 Nut,3/8-16ElasticStop x x x x
52 04004-02 Support,BeltCover x x x x
53 04029-04 WingNut3/8-16(SM) x
54 04017-42 Capscrew, 7/16-14 x 1" Serr. x x x x
55 04019-05 Nut,7/16-14Serr.Flange x x x x
56 04041-08 FlatWasher, 3/4Special x x x x
57 44078 J-Hook x x x x
58 48181 Idler Pulley, "V" Groove x x x x
59 04050-02 Retaining Ring, 3/4" Ext. "E" x x x x
60 46081 Idler Arm Assy. (incl. 22 & 61) x x x x
61 48100-05 Bushing, 3/4 x 1/2" x x x x
62 43028 J-Hook, Idler Pulley x x x
62 44078 J-Hook, Idler Pulley x
63 43077 Spacer,Pulley x x x x
64 04041-12 Flat Washer, 3/8 x 1-1/2 x 16 Ga. x x x x
65 04001-46 Hex Head Bolt, 3/8-16 x 2-1/4" x x x x
66 481024 Seal,CutterSpindle x x x x
67 46748 Idler Arm Assy., (incl. 22 & 77) x x x x
68 43277 Spacer,J-Hook x x x x
69 481035 Nut,CutterSpindle x x x x
70 43312 Spacer,Outside x x x x
71 43297 SpindleBushing x x x x
72 481025 Seal,CutterSpindle x x x x
73 04001-108 Hex Head Bolt, 5/16-18 x 4-1/4" x x x x
74 04001-77 Hex Head Bolt, 3/8-16 x 3-1/2" x x x x
75 45329 IdlerPivot x x x x
76 48269 IdlerPulley, Clutch Belt x x x x
77 48100-02 Bushing,1-1/8x 1.0Flanged x x x x
78 04050-05 RetainingRing,1-1/8Ext."E" x x x x
79 48038 Guide,Roller x x x
80 45944 RollerShaft x x x
81 48098 Shield,Spindle x x x x
82 48307-08 Nut,5/16-24Tapered x x x x
Ref. Part
No. No. Description 4852 61 72
48", 52", 61", & 72" CUTTER DECKS
