MODEL SSZ
OPERATOR’S MANUAL
THIS MANUAL CONTAINS THE OPERATING
INSTRUCTIONS AND SAFETY INFORMATION
FOR YOUR SCAG MOWER. READING THIS
MANUAL CAN PROVIDE YOU WITH ASSIS-
TANCE IN MAINTENANCE AND ADJUST-
MENT PROCEDURES TO KEEP YOUR MOWER
PERFORMING TO MAXIMUM EFFICIENCY.
THE SPECIFIC MODELS THAT THIS BOOK
COVERS ARE CONTAINED ON THE INSIDE
COVER. BEFORE OPERATING YOUR MA-
CHINE, PLEASE READ ALL THE INFORMA-
TION ENCLOSED.
PART NUMBER 03032

FAILURE TO FOLLOW SAFE OPERATING PRACTICES
MAY RESULT IN SERIOUS INJURY.
* Keep all shields in place, especially the grass discharge chute.
* Before performing any maintenance or service, stop the machine and
remove the spark plug wire and ignition key.
* If a mechanism becomes clogged, stop the engine before cleaning.
* Keep hands, feet and clothing away from power-driven parts.
* Read this manual completely as well as other manuals that came
with your mower.
REMEMBER - YOUR MOWER IS ONLY AS SAFE AS THE OPERATOR!
Hazard control and accident prevention are dependent upon the awareness,
concern, prudence, and proper training of the personnel involved in the
operation, transport, maintenance, and storage of the equipment.
lways use the entire serial number listed on the serial number
tag when referring to this product.
WARNING:
This manual covers the operating instructions
and illustrated parts list for:
SSZ-18, 20, and 22CV
with a serial number of XXX70001 - XXX79999

1
SAFETY INSTRUCTIONS
Do not operate mower on steep slopes. Riding lawn
mowers can tip over when used on an excessive
slope. To check a slope, attempt to back up with
cutter deck down. If wheels slip when backing up
slope, stay off the slope. If you are in doubt about
hillside operation, stay off the slope.
Always back up when loading a machine on ramps
or tilt bed trailers.
1. Know the controls and how to stop quickly. READ
THIS O ERATORS MANUAL and instructions
furnished with attachments. A replacement
Operator's Manual is available from your Scag
Servicing Dealer. To order, contact your dealer with
the complete model number and serial number of your
Scag product.
2. Do not allow children to operate this machine. Do
not allow adults to operate this machine without
proper instruction.
3. Do not carry passengers. Never mow toward or near
anyone.
4. Clear the area of objects such as wires, sticks, and
rocks that can be picked up and thrown by the
mower blades.
5. Disengage all attachment clutches and engage parking
brake before attempting to start the engine.
6. Disengage all attachment clutches and engage the
parking brake before leaving the operators position.
Your mower was built to the highest standards in the industry. However, your mower is only as
safe as you, the operator, make it. Carelessness or error on the part of the operator may result in
serious bodily injury. Hazard control and accident prevention depend upon the awareness, con-
cern, prudence, and proper training of the personnel involved in the operation, transport, and
storage of this equipment. Make sure every operator is properly trained and thoroughly familiar
with all of the controls and safety instructions before operating the equipment.
7. Disengage the power to attachments, stop the
engine, and remove the key before making any
repairs or adjustments.
8. Disengage the power to attachments when
transporting the machine or when attachments are
not being used.
9. Take all possible precautions when leaving the
machine unattended including disengaging the
power to attachments, lowering the attachments,
setting the parking brake, and removing the key.
10. Do not stop or start suddenly when going up or
down a hill. Mow up and down the face of slopes;
never mow across slopes.
11. Reduce speed and be very careful when operating on
slopes or making sharp turns to prevent tipping or
loss of control. Be especially cautious when
changing direction on slopes. If necessary to turn
on a hill, always turn downhill.
12. Watch for holes, rocks, roots in the terrain, and
other hidden hazards. Keep away from dropoffs.
13. Watch for traffic when crossing roadways or
operating near roadways.
14. When using any attachments, never directly
discharge materials towards bystanders or allow
anyone near mower while it is operating.
15. Handle gasoline with care - it is highly flammable.
a. Use an approved gasoline container only.
b. Never remove the fuel cap while the engine is
running or hot. Allow the engine to cool for
several minutes before removing the cap and
adding gasoline. Never fill the fuel tank
indoors. Always clean up spilled gasoline.
c. Do not run the engine indoors.
WARNING:

2
25. erform only the maintenance described in this
manual. If additional maintenance or major repairs
are needed, contact an authorized Scag Servicing
Dealer. To ensure optimum performance and safety,
always purchase genuine Scag replacement parts
and accessories. Never use WILL FIT replace-
ment parts and accessories made by another manu-
facturer. Using such parts may void the warranty.
Do not operate the machine while wearing sandals,
tennis shoes, sneakers, or shorts. Also, do not wear
loose fitting clothing which could get caught in mov
ing parts. Always wear long pants and substantial
shoes.. Wearing safety glasses and safety shoes is
advisable.
Stop engine and remove key from ignition before
making any adjustments. Wait for all moving parts
to come to a complete stop before beginning work.
Engine and drive unit can get hot during operation.
Allow engine and drive components to cool before
making any adjustments.
To prevent personal injury or equipment damage,
do not operate the machine without the cutter deck
properly mounted.
CAUTION:
WARNING:
WARNING:
SAFETY INSTRUCTIONS - CONT’D
16. Keep the machine and attachments in good
operating condition. Make sure all safety devices
and shields are in place and operate the equipment
as intended.
17. Keep all nuts, bolts, and screws tight to be sure
equipment is in safe operating condition.
18. Never store the equipment with gasoline in the tank
in a building where fumes may reach an open flame
or spark. Allow the engine to cool before storing
the machine in any enclosure.
19. To reduce fire hazard, keep the engine free of grass,
leaves, or excess lubricants.
20. If the machine or attachments strike a foreign
object, disengage the power to the attachments and
stop the engine immediately. Wait for all moving
parts to stop, then inspect for damage. Repair the
damage before restarting or operating the
equipment.
21. Do not change the engine governor settings or
overspeed the engine.
22. When using the machine with a mower:
a. Mow only in daylight or good artificial light.
b. Never dismount the machine to adjust the
cutting height while the engine is running.
c. Shut the engine off and remove the key before
removing the grass catcher or unclogging the
chute.
d. Check the blade mounting bolts frequently for
proper tightness.
23. Disengage the power to the blades before backing
up. Do not mow in reverse unless absolutely
necessary and then only after careful observation of
the entire area behind the mower.
24. The discharge chute must be installed and be in the
down position on a side discharge mower except
when the optional grass catcher or the mulching
plate is completely installed. If the discharge chute
clogs, shut the engine off, remove the key, and wait
for all movement to stop before removing any
obstruction.

3
HYDRAULIC SAFETY
1. Hydraulic fluid is under high pressure. If you need
service on your hydraulic system, please see your
dealer.
Keep body and hands away from pin holes or nozzles
that eject fluid under high pressure. Use paper or
cardboard, not hands, to search for leaks.
Hydraulic fluid escaping under high pressure may
have sufficient force to penetrate your skin and cause
serious injury. If fluid is injected into your skin, a
physician familiar with this form of injury must re
move it surgically within a few hours or gangrene
may result.
2. Make sure all hydraulic fluid connections are tight
and all hoses and lines are in good condition before
applying pressure to the system.
ADJUSTMENTS
Neutral Adjustment
1. Set the machine up on jack stands so the drive
wheels are free to rotate. Block the caster wheels to
prevent an accident if the machine should acciden-
tally fall off the jack stands.
2. Run Position: Move the dump valve lever (on Left
Hand side of mower) behind the hook on the frame
to close hydraulic dump valves on the pump. (See
Figure 1)
Free Wheel Position: ull lever back and to the
left, then push forward to relieve pressure. (See
Figure 1)
Figure 1
3. Start the engine and check if one or both of the
drive wheels are turning.
4. Adjust each drive wheel separately by using the
turnbuckles located under the seat. Loosen the jam
nut on the turnbuckle. (See Figure 2)
5. If the drive wheel is rotating forward, adjust the
turnbuckle clockwise. If the drive wheel is rotating
rearward, adjust the turnbuckle counterclockwise.
Adjust until the drive wheel stops turning. (See
Figure 2)
Figure 2
JAM NUT
Adjust TURNBUCKLE
clockwise or
counterclockwise until drive
wheels stop rotating
SC201G
WARNING:
DUMP VALVE
LEVER
RUN
POSITION
FREE
WHEEL
POSITION
SC200G

4
ADJUSTMENTS - CONT’D
Neutral Adjustment Cont'd
6. Tighten the jam nut to secure the neutral position.
7. Adjust the other drive wheel if necessary.
8. Actuate the hand control levers forward and reverse.
Allow the levers to self-center and check that the
drive wheels remain in neutral.
NOTE: The neutral return mechanisms on the
fenders are adjusted at the factory. Readjustment
should not be necessary.
Straight Line Running Adjustment
1. Before making this adjustment, check the tire
pressure of the drive wheels. Tire pressure for each
wheel must be equal. (See Figure 3) If the tire
pressures are not equal, the machine will pull to the
side with the lower tire pressure.
Figure 3
NOTE: Make this adjustment only on the LH
pump. The RH pump has a fixed speed and
cannot be adjusted.
2. Locate the turnbuckle for LH pump under the
operator seat in front of the hydraulic oil tank. (See
Figure 4)
3. Loosen nut securing turnbuckle to bellcrank. (See
Figure 4)
Figure 4
SC203G
SLOWER
FASTER NUT
BELLCRANK
TURNBUCKLE
ESC202G
CASTER WHEELS
25 PSI
DRIVE WHEELS
12 PSI
Stop engine and remove key from ignition
before making any adjustments. Wait for
all moving parts to come to a complete stop
before beginning work.
Engine and drive unit can get hot during
operation. Allow engine and drive compo-
nents to cool before making any adjust-
ments.
CAUTION:

5
3. To adjust RH blade drive belt: Adjust RH belt
tension so belt moves 1/2" with 10 pounds pressure.
Adjust tension by tightening or loosening J-bolt.
(See Figure 6 for SMZ 52; See Figure 7 for
SMZ 61 & SMZ 48)
4. Carefully unlatch foot plate support rod and lower
foot plate.
Drive Belt Replacement
Figure 6 - SMZ-52
NUT
"J" BOLT
WASHER
BELT
SC206G
Stop engine and remove key from ignition be-
fore making any adjustments. Wait for all mov-
ing parts to come to a complete stop before
beginning work.
1. Lift foot plate and secure with foot plate support
rod.
2. To adjust cutter deck drive belt: Adjust until end of
spring aligns with end of L-shaped bracket. (See
Figure 5)
Figure 5
NOTE: Due to initial belt stretching, check this
adjustment after the first 2 hour, 4 hour, and 8 hour
intervals.
Cutter Deck Drive Belts
NUT "J" BOLT
WASHER
BELT
SC205G
Figure 7 - SMZ-61 & SMZ-48
ADJUSTMENTS - CONT’D
Straight Line Running Adj. - Cont'd
4. Adjust position of turnbuckle by moving it in
mounting slot either forward to slow left wheel or
backward to speed up left wheel. If unit pulls to the
right, left wheel is too fast. If unit pulls to the left,
left wheel is too slow.
5. Tighten nut to secure turnbuckle.
6. Readjust neutral if necessary. (See Figure 2)
NUT "J" BOLT
WASHER
BELT
END OF L- SHAPED
BRACKET
SC204G
CAUTION:

6
ADJUSTMENTS - CONT’D
Drive Belt Replacement
When replacing the drive system belt use ex-
treme caution. The idler arm is under spring
tension.
Remove the two 1/4" nuts on the belt guard and remove
the guard. To remove the old belt, use a 1/2" drive
breaker bar and insert it into the square hole on the idler
arm. ull the idler arm down until the belt becomes slack
and can be removed easily from the idler pulley. Slowly
move the idler arm up until the stop bolt rests against the
hydraulic tank support. Remove the old belt and mount
the new belt around the engine drive pulley and the two
pump pulleys. Feed the belt up toward the idler pulley.
ull the idler arm down so that the new belt can easily be
mounted on the idler pulley. Slowly move the idler arm
up until the belt is firmly engaged. Remove the breaker
bar and remount the belt guard. Check to ensure that the
belt is riding properly in all pulleys.
ontrol Handle Position
Hand Control Handle Position
The position of the hand control handles can be adjusted
for operator comfort. Loosen the bolts holding the
handle to the lever bar just enough to allow movement of
the handle. Adjust to position most comfortable for
operator. Retighten bolts.
INITIAL RUN, INSPECTION, AND
OPERATING INSTRUCTIONS
1. Check that all belts are routed correctly.
2. Check cutter blade drive belts for correct tension.
!
3. Make sure the engine oil level (10W30) is at FULL
on the dipstick. When performing oil changes, fill
the engine to the full mark on the engine dipstick.
(Approximately 2 quarts will be needed for Kohler
engines) DO NOT OVERFILL.
4. Check the oil level (SAE 20W50) in the hydraulic
reservoir. The reservoir is under the seat. The oil
level should be 2" below the top of the tank. When
performing oil changes, fill the reservoir until 2"
below top of tank. (Approximately 4 quarts will be
needed) DO NOT OVERFILL.
5. Check that all fasteners are tightened properly.
Make sure all safety devices are in place and
working correctly.
6. Fill the fuel tank with clean, fresh, lead-free
gasoline with a minimum octane rating of 87.
7. Check the safety interlock system. With the
operator on the seat, the engine must not start unless
the control handles are in the neutral lock position
and the cutter drive is disengaged.
IMPORTANT: If the engine is running, the
engine must stop if the operator leaves the seat
when one or both handles are in the drive
position or the cutter drive is engaged.
WARNING:
Gasoline is highly flammable. Be careful when
filling tank. Do not fill tank while engine is run-
ning or hot from operation. Extinguish open
flames, matches, and smoking materials be-
fore filling tank. Do not overfill tank. Wipe up
all gasoline spills.
CAUTION:

7
10. Release the parking brake. Check that the machine
does not creep forward or backward. If the machine
does creep, adjust the neutral control. See Neutral
Adjustment instructions.
CAUTION: Stop engine and remove key from
ignition before making any adjustments. Wait
for all moving parts to come to a complete stop
before beginning work.
Engine and drive unit can get hot during op-
eration. Allow engine and drive components
to cool before making any adjustments.
11. Operate the machine forward and backward.
Check that all the systems function correctly. If the
machine does not move, make sure the hydraulic
dump valve lever near the left wheel is engaged.
(See Figure 1 page3)
To engage the parking brake, move the lever up and
out into the bracket. To disengage the parking
brake, pull the lever up and in, away from the
bracket. (See Figure 9)
Figure 9
INITIAL RUN, INSPECTION, AND
OPERATING INSTRUCTIONS -
CONT’D
8. To start the engine:
a. The operator must be sitting in the seat.
b. lace control handles in neutral lock position.
c. ull mower engagement switch to off position.
d. ut parking brake in engaged position.
e. Adjust throttle and choke as required.
f. Turn ignition key to start. Release ignition key
when engine starts. Key will return to RUN
position.
9. ull the mower engagement switch out and push it
forward to engage the cutter drive belts. (See
Figure 8) Allow the belts to run for five minutes.
NOTE: For best belt life, engage the clutch at
half throttle and not under load.
NOTE: When the TO is engaged (or possibly
disengaged), a squealing sound from the under
side of the machine is normal. It is caused by the
electric clutch plates meshing as the mower
comes up to speed.
Figure 8
CAUTION:
PULL UP
THEN FORWARD
TO ENGAGE
SC208G1
MOWER DECK ON
MOWER DECK OFF
PULL UP AND PUSH
FORWARD TO ENGAGE
PULL BACK
TO DISENGAGE
PARKING BRAKE
OFF
ON
SC209G1

8
Sharpen blades as shown on Figures 10 and 11.
Figure 10
Do not sharpen (X) beyond 1/3 of blade width (Y).
Figure 11
Suggestion: Dress blade with a file. Wheel grinder may
burn the blade.
Curb Climbing
INITIAL RUN, INSPECTION, AND
OPERATING INSTRUCTIONS -
CONT’D
12. Shut off the engine, remove the key from the
ignition, and wait for all moving parts to stop.
Recheck the cutter deck drive belts for proper
tension. Correct and adjust as necessary.
13. ark the machine on a level area, set the parking
brake, and remove the key from the ignition to
prevent engine starting.
14. Before transporting the machine, latch the seat stop
cable to avoid damage to the seat.
MAINTENANCE g
Free Wheeling
To release the drive wheels, so the machine will roll
without the engine running, pull the dump valve lever
back from the hook on the frame, move it to the left, and
push it forward to relieve the pump pressure. The lever
is on the LH side of the machine. (See Figure 1 on page
3)
Cutter Blades
Blade is sharp! Blade at rest can cause se-
vere cuts. Rotating blade can cut fingers off.
Always lift deck using handles provided.
WARNING:
Y
X
DO NOT CUT IN,
LEAVE ORIGINAL
STARTING POINT ANGLE BLADE
BACK
SC210G
THE EDGE OF BLADE SHOULD
BE AT A 30 DEG. ANGLE
30
SC211G

9
MAINTENANCE - CONT'D
g
Curb Climbing
When driving a riding mower up and over a curb, first
raise the cutter deck to the highest position. Then, drive
in reverse and at an angle so that the back drive wheels
go over the curb one at a time. When both drive wheels
are over the curb, turn the machine so that both front
caster wheels contact the curb at the same time.
(See Figure 12)
Figure 12
SC212G

10
LUBRICATION & MAINTENANCE
Break-In
8 hours (Daily)
40 hours (Weekly)
100 hours (Biweekly)
200 hours (Monthly)
Procedure Comments
XCheck all hardware for proper tightness
X Change engine oil and filter at 5 hours See engine manufacturer information
XCheck belt tension 2 hour, 4 hour, and 8 hour intervals.
XCheck engine oil level Do not overfill
XRemove debris from oil cooler See engine manufacturer information
XClean hydraulic pump cooling fins MORE OFTEN IF NEEDED
XRemove debris from under belt cover MORE OFTEN IF NEEDED
XSharpen cutter blades MORE OFTEN IF NEEDED
-Grease spindle bearings (2 pumps of hand gun) + US Lithium MP White Grease 2125
XClean air filter MORE OFTEN IF NEEDED
XCheck tire pressure Add air if necessary
XCheck battery acid level Use distilled water only
XCheck belt tension Adjust as needed.
XReplace air filter MORE OFTEN IF NEEDED
XChange engine oil See engine manufacturer information
XGrease caster wheel bearings Chassis grease - Qty 2
XGrease caster wheel pivots Chassis grease - Qty 2
XGrease idler arm pivots Chassis grease - Qty 3
XGrease push arms Chassis grease - Qty 2
XGrease control levers Chassis grease - Qty 2
XGrease bell crank Chassis grease - Qty 4
XGrease height adjustment Chassis grease - Qty 1
XCheck all hardware for proper tightness
XChange engine oil filter See engine manufacturer information
XCheck hydraulic fluid reservoir level Add oil if needed (SAE 20W50)
XClean and adjust spark plugs See engine manufacturer information
Every 500 hours (Bimonthly)
Drain hydraulic system and replace fluid Use SAE 20W50 motor oil
Change hydrostatic oil filter * Clean area before removing filter
Adjust air gap on electric clutch Contact your Scag dealer for information
about making this adjustment
* IMPORTANT: Use only Scag Authorized part for proper filtration.
+ Compatible Greases:
Lidok EP #2 (found at industrial shops)
Ronex MP (Exxon service stations)
Shell Alvania (Shell service stations)
Mobilux #2 (Mobil service stations)
Super Lube-M EP #2 and Super Lube-M #2 (Conoco service stations)

11
Stringers - Occasional Low engine RPM Run engine at full 3600 RPM
Blades of Uncut
Grass Ground speed too fast Slow speed to adjust for conditions
Wet grass Cut grass after it has dried out
Dull blades, incorrect sharpening Sharpen blades
Deck plugged, grass accumulation Clean underside of deck
Belts slipping Adjust belt tensions
Streaking - Strips of Dull, worn blades Sharpen blades
Uncut Grass in Cutting
Path Incorrect blade sharpening Sharpen blades
Low engine RPM Run engine at full 3600 RPM
Belt slipping Adjust belt tension
Deck plugged, grass accumulation Clean underside of deck
Ground speed too fast Slow speed to adjust for conditions
Wet grass Cut grass after it has dried out
Bent blades Replace blades
CONDITION CAUSE CURE
Streaking - Strips of Not enough overlapping Increase the overlap of each
Uncut Grass Between between rows pass
Cutting Paths
TROUBLESHOOTING CUTTING CONDITIONS
Width of Deck
SGB020
Width
of
Deck
Width
of
Deck
SGB019
Width of Deck
SGB018

12
CONDITION
TROUBLESHOOTING
CAUSE CURE
Sloping Ridge Across Tire pressures not equal Check and adjust tire pressure
Width of Cutting Path Wheels uneven Check and adjust tire pressure
Deck mounted incorrectly See your authorized SCAG dealer
Uneven Cut on Flat Lift worn off of blade Replace blade
Ground - Wavy
High-Low Blade upside down Mount with cutting edge toward
Appearance, ground
Scalloped Cut, or
Rough Contour Deck plugged,grass accumulation Clean underside of deck
Too much blade angle (deck pitch) Adjust pitch and level
Deck mounted improperly See your authorized SCAG dealer
Bent spindle area See your authorized SCAG dealer
Dull blade Sharpen blade
Uneven Cut on Uneven ground May need to reduce ground speed,
Uneven Ground - raise cutting height, and/or change
Wavy Appearance, direction of cut
High-Low Scalloped
Cut, or Rough Contour
Width of Deck
SGB020
Width of Deck
SGB021
Width of Deck
SGB023

13
Scalping - Blades Low tire pressures Check and adjust pressures
Hitting Dirt or
Cutting Very Close to Ground speed too fast Slow speed to adjust for conditions
the Ground Cutting too low May need to reduce ground speed,
raise cutting height, change direction
of cut, and/or change pitch and level
Rough terrain May need to reduce ground speed,
raise cutting height, and/or change
direction of cut
Ground speed too fast Slow speed to adjust for conditions
Wet grass Cut grass after it has dried out
Step Cut Blades not mounted evenly Adjust pitch and level
Ridge in Center of
Cutting Path Bent blade Replace blade
Internal spindle failure See your authorized SCAG dealer
Mounting of spindle incorrect See your authorized SCAG dealer
Slope Cut - Sloping Bent spindle mounting area See your authorized SCAG dealer
Ridges Across Width
of Cutting Path Internal spindle failure See your authorized SCAG dealer
Bent deck housing See your authorized SCAG dealer
TROUBLESHOOTING
CONDITION CAUSE CURE
Width of Deck
SGB022
Width of Deck
SGB025
Width of Deck
SGB024

14
SPECIFICATIONS FOR SCAG SSZ ZERO-TURN RIDER
MODELS:SSZ-18CV, SSZ-20CV, SSZ-22CV,ALL SSZ-LT
ENGINE
General Type: Heavy duty industrial/commercial
Brand: Kohler
Model: Kohler 18CV, 20CV, 22CV Command Vertical Engine
Horsepower: 18HP, 20HP, 22HP @ 3600 RPM
Type: 4 cycle gas, twin cylinder, vertical shaft engine
Displacement: 18HP=624 cc, 20HP=624cc, 22HP=624cc
Cylinders: 2 cast-iron sleeves
Governor: Mechanical type governor with variable speed control set at
3600 rpm (+ 100rpm), idle set at 1400 rpm
Air Cleaner: Large capacity dual element, chopper-type grass screen
Exhaust: Single exhaust canister muffler
Fuel Pump Group: Mechanical fuel pump with inline fuel filter, fixed jet
carburator with Smart- Choke and fuel shutdown solenoid
Valve Group: Kohler-hydraulic valve lifters standard
Starter/Electrical: 12 volt battery with alternator, solid state ignition with key
start
Charging System: 15 amp
ENGINE DECK
Fuel Tank: 5 gallon (19.0 litres) seamless polyethylene tank with
fuel gauge gas cap
Drive Wheels/Tires: 20x10.0-8 four-ply pneumatic tubeless, radius edge, offset
rims to improve operator's view
SSZ-LT=22x11.0-8 four-ply pneumatic tubeless, radius edge
Parking Brake: Lever operated integral disc brake
Frame: Compact tractor frame with structural steel tubing
construction
DRIVE SYSTEM
Type: Hydro drive with two hydrostatic transmissions for
independent control of each drive wheel
Hydrostatic Transmissions: Two Hydro-Gear Model #BDU 10L with integral
pump/motor and axle
Transmission Belt Idler: Self-adjusting, self-tightening
Dump Valve: Single lever, allows for movement without engine running
Hydro Fluid Cooling Group: 6 qt. capacity nylon fluid reservoir, uses SAE 20W50 fluid
and 10 micron filter, fan driven off pump drive belt cools fins
on pump/motor transmission
Steering/Travel Control: Twin lever fingertip steering control with individual
control to each wheel
Axles: 1" heavy-duty, heat-treated flanged axle
Wire Harness: 14 gauge wire
Safety Group: Seat actuated engine kill, neutral interlock, mower
engagement (BBC) switch with interlock
Instrument Panel: Ammeter, hour meter, key switch, throttle, fuses, manual
choke, BBC switch
Forward Speed Range: 0 to 6.8 mph
Reverse Speed Range: 0 to 3.5 mph
Date of Issue: September 26, 1996
SpecificationsSubjecttoChangeWithoutNotice
TM

15
SPECIFICATIONS FOR SCAG SSZ ZERO-TURN RIDER
MODELS:SSZ-18CV,SSZ-20CV, SSZ-22CV, ALLSSZ-LT
CUTTER DECK SMZ 48, SMZ 52, SMZ 61
Type: Floating, adjustable, anti-scalping, hybrid design combines
out-front and belly-mount designs
Construction: 10-gauge steel with 7-gauge (3/16") steel skirt
True Cutting Width: 48.0" (122.0 cm), 52" (132.0 cm), 61: (155.0 cm)
Cutting Height Adjustment: Hand operated lever adjustment from operator's seat, 1-3/4"
to 4-1/2" in 1/2" increments
SSZ-LT=2-1/4" to 5-1/4" in 1/2" increments
Cutter Blades: .204 thick, milled edge, 5150 alloy steel
SMZ 48: Three (3) 16.5" blades
SMZ 52: Three (3) 18 blades
SMZ 61: Three (3) 21" blades
Blade Engagement: Electric blade engagement clutch with control panel switch
Discharge Opening: Extra wide 11.5" discharge opening with spring loaded
discharge chute
Caster Wheels: 12x 3.5 with quick pin removal
Spindles: Heavy duty 1-1/8" top dimension spindle shaft, cast housing,
taper roller bearing, low maintenance with top access grease
fitting and grease overfill relief poppet
Spindle Pulleys: Cast-iron with easily removed taper hubs
Cutter Deck Belts: B-section with Kevlar cord
ADDITIONAL SPECIFICATIONS
Seat: Thick cushion with padded with arm rests
OPTIONAL ITEMS/ATTACHMENTS
Grass Catcher: Spindle driven GC-SSZ-48 has 48 gallon capacity molded
plastic hopper. GC-SSZ-6KH has 6 HP Kohler auxillary
engine, 48 gallon capacity molded plastic hopper.
Mulching Plate: Steel plate fits over discharge opening. No blade change
or removal required. Installs and removes in the field.
APPROXIMATE DIMENSIONS SMZ 48 SMZ 52 SMZ 61
Length: 72.0" 77.0" 77.0"
Tracking Width: 46.0" 49.0" 49.0"
Width: 59.0" 64.5" 73.5"
Width (with discharge chute up): 49.0" 53.0" 62.0"
Height: 48.0" 51.0" 51.0"
Turning Radius: zero zero zero
Weight: 790 lbs. 835 lbs. 865 lbs.
Weight with GC-SSZ-48: 1060 lbs.
Width with GC-SSZ-48 59.0"
Length with GC-SSZ-48: 78.0"
Weight with GC-SSZ-6KH: 1055 lbs. 1085 lbs.
Width with GC-SSZ-6KH: 73.5" 82.5"
Length with GC-SSZ-6KH: 83.0" 83.0"
NOTE: SSZ-LT models have same specifications as respective models above except the height measurement.
Add 1" to the height of the above specification for SSZ-LT models.
Date of Issue: September 26, 1996
SpecificationsSubjectToChangeWithoutNotice

2
2
4
12
38
37
25 48 46
10
49
20
12
44
47
71
30
41
31
32
70
65
3
24
439
28
17
21
222366
3
70
32 68 69
31
34
27
26
24
36
49
43
41
25
42
15
25
18
18
16
20
35
40
3
24
39
14
20
45
13
11
13
64
67
52
A
63
9
33
60
50
1
53
54
25
58
19
29
56
55
57
51
62
61
14
59
54
A
48", 52" & 61" CUTTER DECKS
10
24 3
5
7
68
B
B
SC214G

3
48", 52", & 61" CUTTER DECKS - CONT’D
1 46852 Cutter Deck (Includes decals) X
46615 Cutter Deck (Includes decals) X
46611 Cutter Deck (Includes decals) X
2 421058 BeltCover,Front X
421451 BeltCover,Front X
421299 BeltCover,Front X
3 04041-07 Flatwasher, 3/8" Special (.391 x .938 x .105)X X X
4 04029-03 WingNut,3/8-16 X X X
5 48584 Anti-ScalpWheel X X X
6 04001-79 Bolt, Hex Head 5/8-11 x 4-1/2" X X X
7 42882 Anti-ScalpWheelBracket X X X
8 04017-27 Bolt, Hex Serrated Flange 3/8-16 x 1" X X X
9 04040-10 Flatwasher, 5/8" (.688 x 1.75 x .134) X X X
10 04021-13 Nut, Hex Elastic Stop 5/8-11 X X X
11 46727 DischargeChute X X
46728 DischargeChute X
12 04001-09 Bolt, Hex Head 5/16-18 x 1" X X X
13 04021-10 Nut, Hex Elastic Stop 5/16-18 X X X
14 04017-16 Bolt, Hex Serrated Flange 5/16-18 x 3/4" X X X
15 44078 “J” Rod X
44101 “J” Rod X X
16 45037 Idler Pivot Base X X X
17 04001-46 Bolt, Hex Head 3/8-16 x 2-1/4" X X X
18 48100-05 Bushing X X X
19 481035 Nut,Special1-1/16-18 X X X
20 04019-03 Nut,HexSerratedFlange5/16-18 X X X
21 46081 Idler Arm (Includes bushings &
greasefittings) X X X
22 43077 Spacer X X X
23 43028 “J” Rod X X
44078 “J” Rod X
24 04021-09 Nut, Hex Elastic Stop 3/8-16 X X X
25 48114-04 GreaseFitting X X X
26 04041-08 Flatwasher,3/4" X X X
04041-08S Flatwasher,3/4"Special X X X
27 04050-02 Ring,Retaining3/4" External“E” X X X
28 48181 Pulley,Idler X X X
29 43297 SpindleBushing,Bottom X X X
30 48924 Pulley,LHSpindle X X
48753 Pulley,LHSpindle X
31 48926 TaperedHub,1-1/8Bore X X X
32 04001-01 Bolt, Hex Head 1/4-20 x 3/4" X X X
33 04001-41 Bolt, Hex Head 5/8-11 x 9-1/2" X X X
34 48087 Belt, RH Blade Drive X
48285 Belt, RH Blade Drive X
48265 Belt, RH Blade Drive X
35 04001-23 Bolt, Hex Head 3/8-16 x 4-1/2" X X X
36 48550 Pulley,IdlerCutterEngagement X X X
37 48923 Pulley,DoubleGroove X X
48940 Pulley,DoubleGroove X
38 48799 Belt,Blade Drive X
481001 Belt,BladeDrive X
48996 Belt,BladeDrive X
Ref. Part
No. Number Description 48 52 61
39 04041-12 Flatwasher, 3/8" (.375 x 1.5 x .06) X X X
40 48807 Spring,IdlerTension X X X
41 48100-02 Bushing X X X
42 46750 Idler Arm (Includes bushings &
greasefittings) X X
43 45329 Idler Pivot Base X X X
44 04001-97 Bolt, Hex Head 5/8-11 x 3" X X X
45 43282 Spacer X X
46 04020-16 Nut, Hex 5/8-18 UNF X X X
47 48763 RodEnd X X X
48 46460 Push Arm (Includes 25, 46, 47, and 49) X X X
49 48100-06 Bushing X X X
50 45332 Push Arm Shaft X X X
51 46631 SpindleAssembly X X X
52 43298 SpindleShaft X X X
53 481024 Seal,Top X X X
54 481022 BearingAssembly(1 required perspindle) X X X
55 48667 ReliefFitting,TaperedSpindle X X X
56 43294 SpindleHousing X X X
57 481025 Seal,Bottom X X X
58 43312 Spacer,Outside X X X
59 43296 Spacer,Inside X X X
60 04063-08 Key, 1/4 x 1/4 x 2" X X X
61 04001-10 Bolt, Hex Head 5/16-18 x 1-1/4" X X X
62 43279 Spacer,TaperedSpindle X X X
63 48110 CutterBlade,16-1/2"Standard X
48184 CutterBlade, 16-1/2"HighLift X
48108 CutterBlade,18"Standard X
48185 CutterBlade,18"High Lift X
48111 CutterBlade,21"Standard X
48304 CutterBlade,21"High Lift X
64 481050 Spring,DischargeChute X X X
65 48786 ElectricClutch X X X
66 04001-108 Bolt, Hex Head 5/16-18 x 4.25" X X X
67 421616 Belt Cover, LH X
421615 Belt Cover, RH X
42889 Belt Cover, LH X
42890 Belt Cover, RH X
421292 Belt Cover, LH X
421293 Belt Cover, RH X
68 48924 Pulley,RHSpindle X X X
69 04001-109 Bolt, Hex Head 1/4-20 x 1.375 Full Thread X X X
70 * Nut, Hex 5/8-11 UNC X X X
71 04050-05 Ring,Retaining1-1/8"External“E” X X X
72 46963 Idler Arm (Includes bushings &
greasefittings) X
73 04001-51 Bolt, Hex Head 3/8-16 X 3 3/4" X
74 04030-04 Lockwasher3/8 X
75 43369 Nut,3/8-16SpecialW/Washer X
Ref. Part
No. Number Description 48 52 61
* Common hardware which should be purchased locally. All bolts Grade 5 plated, all other fasteners zinc plated.

4
10
13
11
3
15
4
5
9
5
7
6
2
1
21
2
20
20
2
2
8
35
17
18
5
2
2
16
23
24 27
26
32
26
14
28 14
14
29
14 29
14
31
30
29
23
30
14
16
5
5
23
25
33
19
35
17
19
SC215G
48" DECK
37
34
22
2
12
36
29
CUTTER DECK CONTROLS 48", 52", & 61" DECKS
34
