Scale NOMAD 12Ft User manual

NOMAD Conference
Models: 12Ft/10Ft/Sport
INSTRUCTIONS`

+
+
2 3
Step 1
Place frame structure & make sure taps are facing down.
Step 2
Connect leg assemblies to struts as shown.
Step 3
Install cross bars with springs
and install screws as shown.
If you receive NOMAD frame preassembled,
please go directly to Step 6 to nish installation.
LEG FRAME STRUCTURE
ASSEMBLY INSTRUCTIONS
Assemble the item on a soft, non-abrasive surface, such as carpet or cardboard
to avoid damaging the item. Seek assistance to assemble this product.
1/2” SOCKET WRENCH &
SCREW DRIVER & LEVEL
or
TABLE TOPCROSS BAR WITH SPRING
ELECTRICAL COMPONENT
(Optional)
2x
4x
2x 2x
CONNECTOR SCREW
30x

4 5
Step 6
Open up the table frame assembly. Tighten lever on both sides of frame.
Lock the brake of center hinge. Lock the brake of casters.
1-1 Pull out, rotate, release
plunger-lock.
1-2 Rotate allowing plunger-lock
to engage.
2-1 Push release button in to
Lever-Lock.
2-2 Rotate clockwise to tighten.
Press & rotate to reposition
lever-lock.
*** Use caution - Spring assembly
is very strong.
*** Make sure to push weight
down and keep the top at.
1-2
1-1
2-2
2-1
*** Level-Lock available only on
NOMAD 12’ model.
(Not installed on NOMAD
Sport or NOMAD 10’)
Step 4
Fold the frame assembly. And install shoulder bolts to connect legs with cross
bars.
Legs should be connected with cross bars from the opposite side.
Step 5
Flip the assembly over to make it stand.

6 7
All done. Great job. Enjoy!
NOMAD Conference
For more information about other products and accessories
www.scale1to1.com
12Ft/10Ft/Sport
Step 7
Place a table top and install screws. Align steel tabs with threaded inserts
on the bottom of table top.
Step 8
Congrats! You are done with the assembly of NOMAD.
Make sure to unlock caster brakes only on one side when folding and unfolding.

SPECIAL WARNINGS:
- DO NOT CRAWL, STAND, OR SIT ON THE TABLE TOP.
- AVOID PLACING EXTREMELY HOT & COLD ITEMS ON THE TABLE TOP.
WARRANTY:
Table:
This warranty is a limited warranty, and applies to the original purchase only.
This collection carries a 1 year limited warranty and is valid from original date of
purchase to the original owner (proof of purchase required; refer to your retailer).
NOTE: Breakage of any kind voids the warranty automatically.
Scratches, chips, and abrasion due to normal wear and tear are not covered.
Exclusions:
Failure caused by unreasonable or abusive use, re, freight damage, acts of
nature (such as, but not limited to freezing or high winds), suntan oil or other
chemicals, normal fading, scratching or chipping of the nish, weathering or
staining or discoloration of furniture, accidental damage, repair, or modications
by customer, table breakage, normal wear and tear are excluded from
the warranty.
Furniture used in commercial, contract or any other non-residential applications;
clearance items, display models, and all other as is purchased items are not
covered under this warranty. In addition, SCALE 1:1 Inc. will not be responsible for
loss of use or time, inconvenience, travel, packaging, or any other consequential/
incidental damages. In no event shall SCALE 1:1 Inc.’s responsibility exceed the
value of the replacement part/product.
CARE and MAINTENANCE:
Clean your NOMAD with water and dry with a soft absorbent cloth towel.
Do not use bleach or solvents to clean this product! This will void the warranty.
Lack of original receipt will void warranty!
IMPORTANT:
Refer to your retailer for further details of your SCALE 1:1 product purchase
policies. Return policy is strictly under the retailer discretion. SCALE 1:1 is exempt
of responsibility or accepting product returns direct from a consumer when the
product was not purchased direct from SCALE 1:1’s inventory.
