Disclaimer
The SCAN~LINK Armour SystemTM is not ‘safety rated’ and thus cannot be relied on as front-line defense against
equipment-to-pedestrian or equipment-to-object strikes. It is intended as a supplementary safety system only, to
improve operator and pedestrian awareness and to help ‘fill in’ blind spots. There is no replacement for proper training
and operation of equipment. The SCAN~LINK Armour SystemTM is designed to augment existing site safety practices and
policies, to further inhibit the chances of worker injuries and fatalities. Remember, pedestrians will not be detected if they
are not wearing functioning, SCAN~LINKTM tagged safety wear. All employees and visitors to any operations site should
be trained in the functionality of the SCAN~LINK Armour SystemTM and be fully aware of their surroundings while on site.
The SCAN~LINK Armour System’sTM installation, operation and maintenance, in all its forms, is covered by various legal
documents, disclaimers and procedures, all of which are available upon request. By using the SCAN~LINK Armour
SystemTM or any of its components, you are bound to adhere to the conditions and practices outlined therein.

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
4
Product Description
The SCAN~LINK Armour System™ has been designed to increase the probability of detection of a tagged ground worker
or tagged object in the vicinity of mobile heavy equipment. The SCAN~LINK Armour System™ scans for Radio Frequency
Identification (RFID) tags using an Ultra High Frequency (UHF) transceiver operating in the unlicensed 902MHz to 928
MHz Industrial Scientific and Medical (ISM) frequency band. Proper operation of the SCAN~LINK Armour System™
requires that the work site is free of interference causing Radio Frequency (RF) devices. Such interference causing devices
may include 2-way radios, wireless crane controllers and other RFID based scanning systems operating within or near the
902MHz to 928MHz ISM frequency band. SCAN~LINK Technologies Inc. recommends that all potential customers
perform a Wireless Site Survey to ensure that the work site is free of interference causing Radio Frequency (RF) devices
before installing the SCAN~LINK Armour System.
The SCAN~LINK Armour System™ consists of two units, the Antenna Unit, and the Display Unit. The Antenna Unit is
typically mounted on the back of a vehicle to detect the presence of ground workers wearing an Armour equipped Safety
Vest and/or Hard Hat. When a tagged ground worker is detected, the Antenna Unit sends a message to the Display Unit
mounted inside the cab which then alerts the operator through an audible and visual alarm. The Display Unit displays the
operational status of the SCAN~LINK Armour System™ whenever the vehicle ignition is on, but only gives visual and
audio alarms for ground worker detection when the Reverse Input Line to the Antenna Unit or the Display Unit is Positive
Active. The SCAN~LINK Rapid Pair™ software is used to configure the operating parameters of the SCAN~LINK Armour
System™, including which Reverse Input Line to use to enable visual and audio alarms.
Antenna Unit
The Antenna Unit transmits and receives digital RFID signals over the 902MHz-928MHz frequency band to search for
SCAN~LINK Armour safety apparel within its detection range. The Antenna Unit processes information from the
responding tags to identify if any genuine SCAN~LINK Armour vests and/or safety hats are in the range. If SCAN~LINK
Armour safety apparel is detected, the Antenna Unit transmits a separate signal in the 2.4GHz frequency band to the
Display Unit to activate an audible and visual warning.
Figure 1: SCAN~LINK™ Antenna Unit
The Antenna Unit requires power from the vehicle’s power source. It also requires a positive activation of the Reverse
Input Line if this input is configured to be used to activate the Antenna Unit only on reverse vehicle operation. All other
functions of the antenna are performed over the 2.4GHz radio link. The wires into the Antenna unit are routed with a
splash-proof connector to protect the device against water leakage. A moisture vent is incorporated in the Antenna Unit
case so that moisture inside the case can vent to the outside.

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
5
In-Cab Display Unit
The Operator Display unit seen below is to be installed inside the vehicle cabin in the vicinity of the operator, but no closer
than 20cm (8 inches) , so that it can be clearly seen and heard. The Operator Display receives signals from the antenna
when genuine Armour safety apparel is detected in the range of the Antenna Unit.
The Display Unit is in periodic contact with the Antenna Unit to ensure the communication link and tag detection
throughput between the antenna element and the display is functioning properly and reporting no errors. If the wireless
connection between the display and the antenna is compromised, the power LED will blink amber and an optional audible
sound (if enabled through the SCAN~LINK Rapid Pair™ software) will be generated. SCAN~LINK™ apparel will not be
detected if the power LED is amber.
Figure 2: SCAN~LINK™ Display Unit
In-Cab Display Unit Interface
Function Description
Power LED
Solid Green Normal Operation
Flashing Amber Communication Error with Antenna Unit
Solid Red Display Hardware Error
In-Reverse LED On when the Reverse Input is Positive Active
LED Cluster
In normal operation, the LED cluster illuminates when SCAN~LINK™ Apparel is detected.
When adjusting the volume, the speaker volume level is shown.
When in Diagnostics Mode, error codes are displayed.
Speaker Emits an audible 3Hz beep when SCAN~LINK™ Apparel is being detected and the Reverse Trigger is enabled.
Volume Button
When not detecting SCAN~LINK™ Apparel, press momentarily or continuously to adjust the volume. As the
volume is being adjusted, the LED cluster will indicate the volume settings. The more LEDs that are on, the
higher the volume.

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
6
In-Cab Display Unit Indications
The following display modes are possible with the SCAN~LINK In-Cab Display Unit:
DISPLAY LIGHTS
AUDIBLE
MEANING
WORKING
NONE The system is off (unpowered).
NONE The In-Cab Display and Antenna units are functioning properly.
NONE The In-Cab Display and Antenna units are functioning properly.
Reverse Input is active.
Beeping at 3Hz In-Cab Display and Antenna units are functioning properly.
Reverse Input is active. SCAN~LINK™ Apparel or Tags detected.
MALFUNCTIONING
NONE In-Cab Display Hardware Error
Beeping at 0.5Hz if ‘Buzz on
Communications Error’ is
enabled via Rapid Pair™
Wireless Communications Error
Throughput Detection Error, Reverse Input is Active
Throughput Detection Error
Antenna Start-up Parameter Setup Error
Tag Detection Power Level Setting Error
Antenna Detection Error (Reader Response Error)
Antenna Temperature Range Error
Antenna Soft Reset Error
Antenna Communications Protocol Error
Indicator Communications Protocol Error

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
7
Detection Range
The factory set detection range is approximated as a fan shaped beam, shown in Figure 3. The range is adjustable using
the SCAN~LINK Rapid Pair™ software. The strength of the received digital RFID signals increases as the separation
between the Antenna Unit and the SCAN~LINK Armour System™ safety apparel decreases. The onset of detection
typically begins at 6 meters, however, consistent detection at 6 meters cannot be guaranteed.
Personnel can be detected by the SCAN~LINK Armour System™ if they are wearing the SCAN~LINK Armour safety
apparel and are within the detection range of the SCAN~LINK Antenna unit. Multiple RFID tags are used within the
SCAN~LINK Armour safety apparel to improve the probability of detection. The ability of the SCAN~LINK Armour
System™ to detect a tag will vary with tag orientation, movement, mounting surface, moisture content, line of sight and
proximity to the human body.
SCAN~LINK Safety apparel should be tested regularly using a SCAN~LINK Tag Health Tester and should be kept dry and
free of dirt, snow, ice and other contaminants. Proper tag mounting and orientation instructions should be followed when
installing SCAN~LINK RFID Tags into Hard Hats. SCAN~LINK Safety Vests should be fully fastened to improve front and
back detection.
Personnel wearing multiple articles of SCAN~LINK Safety apparel, such as a SCAN~LINK equipped Safety Vest and Hard
Hat, will have a higher probability of being detected by the SCAN~LINK Armour System™ than those wearing only a
single article of SCAN~LINK Safety apparel.
Figure 3: Approximate Detection Range

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
8
Product Specification
Antenna Unit Models
There are three SCAN~LINK Armour SystemTM Antenna Models. They can be identified by part numbers below:
SLAU-UV-NB-04 Base
Single wire exits case bottom on the left side
SLAU-UV-NB-RT-04 Relay Trigger
‘Base’ + four-pin relay output connector exiting case bottom on the
right side
SLAU-UV-NB-ERT-04
Enhanced Relay Trigger
‘Relay Trigger’ replaces four-pin connector with twelve-pin
enhanced relay output connector exiting case on the bottom right
side
A Data Logging software upgrade may be programmed onto any of the three models.
Absolute Specifications
Physical Specifications
Item Minimum Maximum Notes
Input Voltage +9 VDC +34 VDC Do not attempt to operate outside nominal 12-28VDC
Operating Temperature -20º C 50º C Cold temperature version available
Storage Temperature -30º C 80º C
Ingress Protection IP65 Do Not Immerse
Reverse Polarity Protected Yes
Voltage Spike Withstand SURVIVAL < 3ms: -600V/+400V
Item Metric (mm) Imperial (in) Notes
Height 128 mm 5 1/16” ‘Depth’ when mounted on equipment
Length 246 mm 9 11/16” ‘Height’ when mounted on equipment
Minimum Install Length 292 mm 11 1/2” Clearance for cable gland and wire bend
Width 165 mm 6 1/2”
Wire Length 400 mm 15 5/8” Measured from case to tip of connector
Back Plate Black Anodized Aluminum
Casing Yellow Polycarbonate/ABS Alloy Plastic
Mounting Channels 11 mm 7/16” Designed for 6mm (1/4”) bolts
Installation Orientation Vertical, Cables Down Moisture vent must face downward
Power Connector Deutsch DTM04-6P Mates w/Deutsch DTM06-6S
Relay Connector Deutsch DT04-4P Mates w/Deutsch DTM06-4S
Enhanced Relay Connector Deutsch DTM04-12PA Mates w/Deutsch DTM06-12SA

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
9
Electrical Specifications
Item Minimum Maximum Notes
Nominal Input Voltage (VCC) +12 VDC +28 VDC On models with ‘UV’ in model number
Input Current @ 12 VDC 0.28 A Nominal (not including VCC Relay Load)
Input Current @ 24 VDC 0.14 A Nominal (not including VCC Relay Load)
Recommended External Fuse 5A Ensure fuse accommodates connected relay loads
Reverse Input Trigger Voltage 4.5 VDC VCC Opto-isolated
Reverse Input Current Draw 1.5 mA 6 mA Resistor limited
Detection Relay Contact Rating - 2A @ 5VDC RT/ERT Models Only
Solid State Relay Voltage - 220 V ERT Model Only
Solid State Relay Current - 80mA ERT Model Only
Fault Relay Contact Rating - 2A @ 5VDC ERT Model Only
RFID Scanner Radio Frequency 902.3 MHz 927.7 MHz Unlicensed ISM Band, FHSS, 3W EIRP
Wireless Link Frequency 2405 MHz 2475MHz Unlicensed ISM Band, 0.085W EIRP
IC ID 9283A-SLAU270NB Under SCAN~LINK Technologies Inc.
FCC ID YUU-SLAU270NB Under SCAN~LINK Technologies Inc.
IFT ID 201801C03800 Under Skyetech / Synapse
Pinout Specifications
Power
Connector
Pin 1
Power Supply
VCC (+12
-
28
VDC )
Pin 6
Communications*
RS485 Signal +, Do Not Connect
Pin 2
Power Supply
VDD (
-
) Equipment Ground
Pin 5
Communications*
RS485 Signal
-
, Do Not Connect
Pin 3
Reverse
Reverse Input
Pin 4
Communications*
RS485
Signal Comm
on
., Do Not Connect
Relay
Connector
Pin 1 Power VCC (+) Pin 4 Power VDD (-)
Pin 2 VCC Relay Detecting Open Pin 3 VCC Relay Detecting VCC (+), 1A Max
Not Detecting VCC (+), 1A Max Not Detecting Open
Enhanced
Relay
Connector
Pin 1
+ Power Always VCC (+)
Pin 12
- Power Always VDD (-)
Pin 2
VCC Relay
Detecting Open Pin 11
VCC Relay
Detecting VCC (+), 1A Max
Not Detecting VCC (+), 1A Max Not Detecting Open
Pin 3
Solid State Relay
Detecting Open Pin 10
Solid State Relay
Common
Always 80mA / 60 Ohms
220V Max
Not Detecting
Connected to Solid State
Relay Common
Pin 4
Detection Relay
Normally Open
Detecting Open Pin 9
Fault Relay Normally
Open
Fault or No Power Open
Not Detecting
Connected t
o
Detection Relay Common No Fault
Connected to
Fault Relay Common
Pin 5
Detection Relay
Common Always Detection Relay Common Pin 8
Fault Relay Common Always Fault Relay Common
Pin 6
Detection Relay
Normally Closed
Detecting
Connected
t
o
Detection Relay Common Pin 7
Fault Relay
Normally Closed
Fault or No Power
Connected to
Fault Relay Common
Not Detecting Open No Fault Open

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
10
RS-485 Communications Note
The RS-485 connections on the power harness are used for diagnostic and repair purposes only. They do not allow
configuration, firmware upgrades or other features without specialized, proprietary software and procedures . Any
connection to these pins for any purpose or any attempt to communicate with the device not only voids any warranty
claims, but may also destroy the functionality of the device beyond repair and compromise its ability to act as
supplementary safety equipment.
Compatibility Specifications
In-Cab Display Unit Models
There are two SCAN~LINK Armour SystemTM Display Models. They can be identified by part numbers below:
Absolute Specifications
Item Minimum Maximum Notes
Input Voltage +9 VDC +34 VDC Do not attempt to operate outside nominal 12-28VDC
Operating Temperature -20º C 50º C
Storage Temperature -30º C 80º C
Ingress Protection IP52 Indoor Use Only
Reverse Polarity Protected Yes 100V/20A
Voltage Spike Withstand SURVIVAL < 3ms: -600V/+400V
RapidPair
TM
RapidPair 2.0 Dongle Only (RPD-SS200 or RPD-SN220)
In-Cab Display Unit SLDU-006SR and SLDU-006SRE
SLDU-006SR Standard In-Cab Display Unit
SLDU-006SRE Enhanced In-Cab Display Unit
SLDU-006SR model plus three extra wires for detection and
fault relays, 15 foot (4.5 meter) cable

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
11
Physical Specifications
Item Metric (mm) Imperial (in) Notes
Height 35 mm 1 3/8”
Length 75 mm 3”
Minimum Install Depth 95 mm 3 3/4” Clearance for wire bend
Width 100 mm 4”
Cable Length (SLDU-006SR) 2130 mm 84” Last 3” (75 mm) are stripped back
Cable Length (SLDU-006SRE) 4570 mm 180” Last 3” (75 mm) are stripped back
Hook-and-Loop Thickness 5 mm 1/4”
Casing Black ABS UL945VA Rated
Cable Specs (SLDU-006SR) 3-Wire, 18ga. Bare Wire
Cable Specs (SLDU-006SRE) 6-Wire, 20ga. Bare Wire
Min. Install Distance from Operator 200 mm 8”
Beeper Min Volume 88±1 dBa Measured @ 200 mm (8”), Typical
Beeper Max Volume 99±1 dBa Measured @ 200mm (8”), Typical
Electrical Specifications
Item Minimum Maximum Notes
Nominal Input Voltage (VCC) +12 VDC +28 VDC
Input Current @ 12 VDC 120 mA Nominal
Input Current @ 24 VDC 60 mA Nominal
Recommended External Fuse 1A
Internal Fuse 1.5A Auto-resetting
Fault/Detection Relay Current - 2A
Reverse Input Trigger Voltage* 4.5 VDC VCC Opto-isolated
Reverse Input Current Draw* 1.5 mA 6 mA Resistor limited
Wireless Link Frequency 2405 MHz 2475MHz Unlicensed ISM Band, 0.098W EIRP
IC ID 9084A-SM220 Under Synapse Wireless Inc.
FCC ID U90-SM220 Under Synapse Wireless Inc.
IFT ID 201801A01279 Under Skyetech / Synapse
Reverse Trigger Note
The Reverse Trigger (Orange) wire on the In-Cab Display Unit may be optionally tied to a reverse signal and used in place of the
Antenna’s reverse signal. However, operation in this mode requires additional configuration with RapidPairTM and has no function
whatsoever until the appropriate settings are changed.

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
12
Cable Specifications
Compatibility Specifications
Power Cable
Red Wire Power Supply Always VCC (+12-28VDC )
Black Wire Power Supply Always VDD (-) Equipment Ground
Orange Wire Reverse Input Always Reverse Input
Blue Wire (SLDU-006SRE Only)
Fault Relay
Fault / No Power Open
No Fault / Power Closed to Relay Common (Green)
Green Wire (SLDU-006SRE Only)
Relay Common Always
White Wire (SLDU-006SRE Only)
Detection Relay
Detecting / No Power Open
Not Detecting / Power Closed to Relay Common (Green)
RapidPair
TM
RapidPair 2.0 Dongle Only (RPD-SS200 or RPD-SN220)
Antenna SLAU-UV-NB-xx-xx-xx-xx-04

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
13
Agency Certifications
FCC
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
Any changes or modifications of this product, not approved by manufacturer will void the user’s authority to operate the
equipment.
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if
not installed and used in accordance with the installation manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his/her own expense.
IC/IFT
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two
conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including
interference that may cause undesired operation of the device.”
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de
brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
La operación de este equipo está sujeta a las siguientes dos condiciones: (1) es posible que este equipo o
dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia,
incluyendo la que pueda causar su operación no deseada.
FCC/IC
To comply with FCC/IC RF exposure limits for general population / uncontrolled exposure, the SCAN~LINK™ Antenna
Unit and the Operator Display Unit must be installed to provide a separation distance of at least 20cm (8 inches) from all
persons and must not be co-located or operating in conjunction with any other antenna or transmitter.
For further information on RF exposure and compliance, please visit the following links:
https://support.scan-link.com
https://apps.fcc.gov/oetcf/eas/reports/GenericSearch.cfm
https://sms-sgs.ic.gc.ca/search/radioEquipmentPortal

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
14
Installation Wiring Diagram: Ignition Trigger, no Alarm

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
15
Installation Wiring Diagram: Ignition Trigger with Alarm

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
16
Installation Wiring Diagram: Reverse Trigger, no Alarm

SCAN~LINK Armour User’s Manual (CAN/US/MEX) Rev 12.3)
611 Tradewind Drive, Unit 200, Ancaster, Ontario, Canada L9G 4V5
Phone: [phone] E-Mail: [e-mail] Web: www.scan-link.com
17
Installation Wiring Diagram: Reverse Trigger with Alarm
