Battery Replacement Guide
NOVA R and MULTIMATCH R
2021-06-02 By RU
1
Battery Replacement Guide
This guide covers the replacement of the internal battery for the following products:
•03.5456 –Nova R
•03.5652 –Multimatch R
Step 1
Remove the back cover.

Battery Replacement Guide
NOVA R and MULTIMATCH R
2021-06-02 By RU
2
Step 2
Unplug the flat cable.

Battery Replacement Guide
NOVA R and MULTIMATCH R
2021-06-02 By RU
3
Step 4
Unplug the battery connector.

Battery Replacement Guide
NOVA R and MULTIMATCH R
2021-06-02 By RU
4
Step 5
Remove the battery and mount the new battery.

Battery Replacement Guide
NOVA R and MULTIMATCH R
2021-06-02 By RU
5
Step 6
Connect the battery to the battery connector.
Note: It is a good idea to secure the connector with a small dab of hot glue.

Battery Replacement Guide
NOVA R and MULTIMATCH R
2021-06-02 By RU
6
Step 6
Connect the flat cable. Note the orientation of the cable in the connector.

Battery Replacement Guide
NOVA R and MULTIMATCH R
2021-06-02 By RU
7
Step 7
Mount the back cover.
