Scarlet Tech Hercules User manual

Hercules
User Guide
Wireless Crane Camera System

Table of Contents
Product List
Product Overview
Product Information
Hook Camera
Hook AP
Battery Pack
StreamLink Station
Cabin AP
Android Tablet
Installation
StreamLink station Set-up
Hook Camera, Hook AP & Battery Pack Set-up
Cabin AP and Android Tablet Set-up
Hercules App
Login Flow
Login Page
Home Page
Single Camera Page
Menu (Admin Account)
Menu (Operator Account)
Camera Configuration Page
Add New Camera Page
Account Management Page
APP Information Page
Account and Password Information
FAQ ‒ Frequently Ask Questions
Warranty & Services
2
3
4
4
5
6
7
8
9
10
10
13
19
23
23
23
24
25
26
27
28
29
30
31
32
33
34

2
Product List
Main Products
(1) Hook Camera (with Waterproof LAN Cable 1.2M)
(2) Hook AP
(3) Battery Pack
(4) StreamLink Station
(5) Cabin AP
(6) Android Tablet
Antennas
(7) 5 GHz Omnidirectional Antenna x 6pcs
(8) 2.4 GHz Omnidirectional Antenna x 1pc
Power Adapters and Cables / Cords
(9) Power Cord 1.2M (Battery Pack to Hook AP)
(10) Three-core Power Cord 50M (StreamLink Station)
(11) Power Adapter and Power Cord (Cabin AP)
(12) Power Adapter & USB C to USB A Charging Cable (Android Tablet)
(13) Power Adapter and Power Cord (Battery Pack)
Other Accessories
(14) Android Tablet Holder with Clamp
(15) Cable Holder with D-ring & Magnet x4pcs
(16) Safety Rope with D-ring x4pcs
(1) (2) (3)
(4) (5) (6)

3
Product Overview
Hercules is ultra-modern wireless crane camera system built for lifting safety and worksite moni-
toring. The system can be easily deployed by following our step-by-step instructions in less than 1
hour.
Hercules consists of 4 main parts, Hook-view Camera, StreamLink Station, Android Tablet, and
Worksite Monitoring Network. The sound and live-view from camera installed on the crane’s hook
is transmitted and received wirelessly via the monitoring network to the Android Tablet inside the
crane cabin.
This enables the crane operator to get a clear live audio-visual feed of the load and critical
surroundings, that was impossible to see and hear without Hercules system. At the same time,
manager and supervisor benefit from the system by having access of remote worksite monitoring
that is accessible anytime and anywhere from tablet via Hercules App (Free download on iOS and
Android).
Video streaming for crane driver
Video streaming for construction site office/control room
1
2
3
21 3
Streamlink
Camera Tablet
4
Central Monitoring System
Optional

4
Camera
Image Sensor
Electronic Shutter
Lens
AOV
Night Vision
Defog
Dimension
Weight
Video & Audio
Resolution & Pixels
Compression Standard
MIC
Two-way Communication
Video Storage & Playback
Others
Power Supply
Waterproof
API for Integration
Installation
Operation Temperature
1/2.8" CMOS
1/25s - 1/10000s
2.8mm
110°
Starlight Technology
Digital Defog
180 x 122 x 122 mm (excluding cable)
2.5kg (excluding cable)
2K QHD 2304 x 1296, 3MP / HD 1280 x 720, 1MP
H.265 / H.264 / MJPEG
Yes
No
4 full days (24hours per day)
DC 12V2A / POE (IEEE 802.3af)
IP67
ONVIF
Mounting by magnets
-10℃~60℃
Product Information
1. Hook Camera
Lens
Magnets
Magnets
MIC
LAN Cable to Hook AP

S4
S3
S2
S1
LAN
PWR
5
Dimension
Weight
Wireless Technology
Antenna
I/O port
LED Indicator
Power Supply
Waterproof
Installation
Operation Temperature
265 x 265 x 82 mm (excluding antenna)
2.2kg
Wi-Fi 5GHz (802.11 ac a/n)
Omnidirectional 5GHz x2
Antenna connector x2
Ethernet port x1 (for Hook Camera)
3-pin power jack
Power status x1
LAN connection status x1
Signal strength x4
DC 12V
IP67
Mounting by magnets
-10℃~60℃
2. Hook AP
Magnets
Magnets
3-pin Power Jack
LED Indicators for
LAN Connection Status
N-type PortsN-type Ports
RJ45 Port to Hook Camera

6
Dimension
Weight
Battery Type
Battery Volume
Power Input
(Charging by Power Charger)
Power Output
Working Hours
Charging Time
I/O port
LCD Display
LED Indicator
Waterproof
Installation
Operation Temperature
272 x 146 x 91 mm
5kg
Molicel 26700 LiFePO4
28000mAh
DC 14.3~14.6V2A
12V4A (Max)
35 hours or above
14 hours (from 10V to 13.6V)
One 3-pin power connector to Hook AP
One power jack for charging
Battery voltage status
Power status x1
IP67
Mounting by magnets
-20℃~75℃
3. Battery Pack
Magnets
Magnets
3-pin Power Jack to Hook AP
Power On/Off
LED Indicator for Power Status
LCD Display for Battery Voltage Status
Power Jack for Charging

S4
S3
S2
S1
LAN
PWR
7
Dimension
Weight
Wireless Technology
Antenna
I/O port
LED Indicator
Power Supply
Waterproof
Installation
Operation Temperature
230 x 230 x 93 mm (excluding antenna)
1.1kg
Wi-Fi 5GHz (802.11 ac a/n)
Omnidirectional 5GHz x2
Antenna connector x2
Ethernet port x1 (for config if necessary)
3-pin power jack
Power status x1
LAN connection status x1
Signal strength x4
DC 24V
IP67
Mounting by magnets
-10℃~60℃
4. StreamLink Station
Magnets
Magnets
LED Indicators for
LAN Connection Status
3-pin Power Jack
RJ45 Port for Configuration
N-type Ports
N-type Ports

S4
S3
S2
S1
LAN
PWR
8
Dimension
Weight
Wireless Technology
Antenna
I/O port
LED Indicator
Power Supply
Waterproof
Installation
Operation Temperature
269 x 239 x 82 mm (excluding antenna)
2.6kg
Wi-Fi 5GHz (802.11 ac a/n)
Wi-Fi 2.4GHz (802.11 b/g/n)
Omnidirectional 5GHz x2
Omnidirectional 2.4Ghz x1
Antenna connector x3
Ethernet port x3 (for POE cameras)
Power jack
Power status x1
LAN connection status x1
Signal strength x4
DC 52V1.25 A
N/A
Mounting by magnets
-10℃~60℃
5. Cabin AP
LED Indicators for
LAN Connection Status
Power Jack
N-type Ports for 2.4GHz Antennas
N-type Ports for 5GHz Antennas
RJ45 Ports for PoE Cameras

9
Dimension
Weight
OS
Display
Resolution
Wireless Connectivity
CPU
Memory
Power Supply
Installation
Operation Temperature
247 x 193 x 40 mm (including TPU case & holder)
700g
Android 10
10” IPS Touch Screen
1280 x 800
Wi-Fi 2.4GHz (802.11 b/g/n)
Octa-core Processor
2G RAM + 32G ROM
DC 5V2A
Mounting by bracket with clamp
0℃~45℃
6. Android Tablet
3/4” Screw Hole for Mounting Bracket
USB Type-C Port for Charging
Power ON/OFF
Volume UP/DOWN

10
Installation
StreamLink Station Set-up
Install one 5 GHz omnidirectional antennas on the N-type port of StreamLink station.
Install another 5 GHz omnidirectional antenna on the 90° angle antenna transmitter
which is pre-installed on the N-type port of StreamLink station.
Wipe clean the crane jib surface.
Mount the StreamLink station on the crane’s jib surface and then use safety rope to lock
the StreamLink station to the jib for safety.
- StreamLink station should be placed as least half of the jib length and closer to the crane hook.
- One antenna should point to the front direction and another one point to the left or right direction.
These two should be parallel to the ground.
1
2
front
1
2
3
4

11
Connect the 3-pin power cord (50 meters) to the StreamLink Station.
5

12
Do wire stripping for the power cord and then connect to your DC 24V power source.
Check the LED indicator on the StreamLink Station. If the PWR becomes green steady, it
means the StreamLink Station is boot-up successfully.
POSITIVE +
NEGATIVE -
No Function
PWR
LAN
S1,
S2,
S3 &
S4
Definition
OFF: No power
Steady Green: Power ON
OFF: No data transmission
Flashing Green: Data transmission is on-going
OFF: No signal
S1 Steady Green: Signal strength very bad
S2 Steady Green: Signal strength bad
S3 Steady Green: Signal strength normal
S4 Steady Green: Signal strength good
Description
Power status
Data transmission status of configuration
port
Shows wireless signal strength status
between StreamLink station and other
connected devices.
6
7

13
Install two 5 GHz omnidirectional antennas on the 90-degree angle antenna transmitter
which is pre-installed on the N-type port of Hook AP
Wipe clean the crane hoist surface.
1
2
Hook Camera, Hook AP & Battery Pack Set-up

14
safety rope
Note: For better wireless signal quality, two antennas of Hook AP should be parallel to the ground.
Mount the Hook AP on the crane’s hoist surface and then use safety rope to lock the
Hook AP to the crane hoist for safety
Mount the battery pack on the crane’s hoist surface and then use safety rope to lock
the battery pack to the crane hoist for safety.
3
4
3
4

15
Mount the Hook Camera on the crane’s hoist surface and then use safety rope to lock
the Hook Camera to the crane hoist for safety.
Connect the battery pack and the Hook AP using 1.2 meters power cable.
Connect to Battery Pack
Connect to Hook AP
5
6
safety rope

16
LAN Cable from Hook Camera
LAN Cable to Hook AP
Connect the Hook Camera and the Hook AP using waterproof LAN cable.
7

17
Press the power ON button to supply battery power to Hook AP and Hook Camera.
Check the LCD display and LED indicators on the battery pack.
LED Indicator
LCD Display
LCD Display
LED Indicator
Definition
>=14V: Full charged
<=12V: Low voltage, camera will shutdown
OFF: No power
Steady Red: Battery life is less than 3 hours.
Steady Green: Battery life is longer than 3 hours.
Description
Voltage information
Battery life status
8
9

18
Check the LED indicator on the hook AP. If PWR is green steady, it means the hook AP
is boot-up successfully
PWR
LAN
S1,
S2,
S3 &
S4
Definition
OFF: No power
Steady Green: Power ON
OFF: No data transmission
Flashing Green: Data transmission is on-going
OFF: No signal
S1 Steady Green: Signal strength very bad
S2 Steady Green: Signal strength bad
S3 Steady Green: Signal strength normal
S4 Steady Green: Signal strength good
Description
Power status
Data transmission status
Wireless signal strength between Hook
AP and StreamLink Station
10

19
Install two 5 GHz omnidirectional antennas on the 90-degree angle antenna transmitters
which is pre-installed on the N-type ports on the rear side of cabin AP.
Install one 2.4 GHz omnidirectional antenna to the port on the right side of cabin AP.
Connect the cabin AP, power cable and power adapter, then plug the power.
Cabin AP and Android Tablet Set-up
1
2
3
1
1
2
