Schaefer TFT 480 User manual

TFT 480
TFT 640
TFT 800
User Manual TFT

2
Kapitelbezeichnung
Kapitelbezeichnung
X.X Unterpunkt
SCHAEFER GmbH
Winterlinger Str. 4
72488 Sigmaringen
Germany
Phone [phone]
Fax [phone]
[e-mail]
www.ws-schaefer.de
Support
If you have any questions regarding this product please contact:
Phone [phone]
Fax [phone]
Copyright
Duplication (copy, print, microfilm or any other form) as well
as electronic spreading of this document
is only permitted after formal writting consent of SCHAEFER GmbH.
SCHAEFER GmbH reserves the right to carry out alterations
of technical details without prior notice.
For all transactions our General Conditions of Sale and Delivery shall be applicable.
All rights reserved.
Ress. 013717
Revision: 2011-07-11

3
Index
User Manual TFT
Index
1General description ....................................... 4
2 Screen display ........................................... 4
2.1 Display types .......................................................4
2.2 Screen display options ......................................5
3 Configuration/Simulation ........................ 6
4 Contacting/Assignment ........................... 6
4.1 TFT 480 .................................................................6
4.2 TFT 640 .................................................................7
4.3 TFT 800 .................................................................8
4.4 Additional devices ..............................................8
5 Operation .................................................. 9
5.1 Configuration ......................................................9
5.2 Settings ................................................................9
6 Installation dimensions ...........................10
6.1 TFT 480 .............................................................. 10
6.2 TFT 640 ...............................................................11
6.3 TFT 800 ...............................................................12
7 Characteristics ........................................13
8 Versions ...................................................14

4
12
3
4
5
6
1
2
34
5
6
1
2
3
4
5
6
General description | Screen display
1General description
TFT 480 / TFT 640 / TFT 800 are high-quality TFT dis-
plays with LED backlighting. They are characterised by
a brilliant screen display and durable LEDs.
For optimal utilization of the available space , installa-
tion is possible both vertically and horizontally.
The displasy can show floor information, direction and
re-starting arrows, special texts, logos and other
images. The images may change with the floor or also
run as "slide show". With the arrows can be animated
via the "travel" input.
The functions can be configured using a PC.
2Screen display
2.1 Display types
TFT 480 (4,3")
2.1 Display types
arrows
floor designation
special symbol/logo
capacity information
lift data
floor-independent
background image
horizontal vertical
Rear view

5
1
2
34
5
6
1
2
3
4
5
6
12
3
4
5
6
TFT 640 (5,6")
Screen display
arrows
floor designation
special symbol/logo
capacity information
lift data
floor-independent
background image
horizontal vertical
Rear view

6
1
2
3
4
5
6
1
2
3
4
5
6
7
1
2
3
4
5
6
7
TFT 800 vertical + horizontal
These illustrations show standard layouts.
Screen display
arrows
floor designation
special symbol/logo
capacity information
lift data
floor-independent
background image
day, date, time
horizontal vertical
Rear view
Update TFT 800 / 11.07.2011
REVISION a

7
Screen display
2.2 Screen display options
2.2 Screen display options
floors: max. 63
arrows: - up/down in same position
- up/down in separate positions
- animation
special display: max. 4
- 4 special displays in place of logo
- 2 special displays in place of logo and 2 special displays as full image
- 4 special displays and full image
logo: yes
lift data: yes
floors info: max. 631
slide show max. 311
time/date: yes2(only for horizontal design)
1The max. amount depends on the image size (number of pixels).
2automatic conversion of summer and winter time
Layout Variants
car fixture layout, background image indicator fixture layout, background white

8
4.1 TFT 480
Configuration/Simulation | Contacting/Assignment
3 Configuration/Simulation
If the TFT display is to be tested prior to installation,
the Simulation Kit is suitable
4 Contacting/Assignment
4.1 TFT 480
GND V-
+24V V+
opposite* COM
addr. 0 B0
addr. 1 B1
addr. 2 B2
addr. 3 B3
addr. 4 B4
addr. 5 B5
up arrow B6
down arrow B7
special B8
special B9
special B10
special B11
Mini-USB PC
MOD key
DAT key
* Opposite potential to B0 - B11
Common anode: COM = V+
Common cathode: COM = V-
(see section
”Operation)

9
4.2 TFT 640
4.2 TFT 640
+24V V+
GND V-
opposite* COM
addr. 0 B0
addr. 1 B1
addr. 2 B2
addr. 3 B3
addr. 4 B4
addr. 5 /travel B5
up arrow B6
down arrow B7
special B8
special B9
special B10
special B11
Mini-USB
PC
MOD key
DAT key
* Opposite potential to B0 - B11
Common anode: COM = V+
Common cathode: COM = V-
Contacting/Assignment
(see section
"Operation")

10
4.3 TFT 800 | 4.4 Additional devices
Contacting/Assignment
4.3 TFT 800
B11 special B10 special B9 special B8 special B7 down arrow B6 up arrow B5 addr. 5 / travel B4 addr, 4 B3 addr. 3 B2 addr. 2 B1 addr. 1 B0 addr. 0 COM opposite* V+ +24V V- GND
MOD key DAT key
(see section
”Operation“)
*Opposite potential to B0 - B11
Common anode: COM = V+
Common cathode: COM = V-
4.4 Additional devices
With the control types Dual or Gray the lines can be
connected directly to the terminals.
With control 1 out of n and up to 6 stops the lines can
also be connected directly.
An Encoder is required for more than 7 stops.
It can be mounted directly on the rear reinforcement
plate of the TFT display.
not required

11
Operation
5.1 Configuration |5.2 Settings
5Operation
5.1 Configuration
To configure the display, the device must be connected
via USB to the PC.
The MOD and DAT keys must now be pressed and held,
the power supply must be plugged in at the same time.
The keys can be released after approx. 2 sec.
The display is now in the configuration mode and can
be configured using the PC.
5.2 Settings
The following modes can be selected with the TFT 640
and TFT 800 displays using the MOD key:
Time HH: hours
MM: minutes
Date YY: year
MM: month
DD: day
WW: weekday
Brightness BR: brightness
FL control: BIN (Dual)
GREY
BCD
… (not needed)
7SEG (7-segment)
1W1F (1ausN)
Other ID: Not required
The values can be set accordingly with the DAT key.
MOD key DAT key

12
128
97
+0,05
0
55,2
+0,05
0
R3
32
2 (3)
100
45±0,145±0,1
55,1
96,9
118±0,1
55
910
147
55
5
128
97
+0,05
0
55,2
+0,05
0
100
5
45±0,145±0,1
5
55,1
96,9
118±0,1
5
9
147
R3
32
2(3)
10
Installation dimensions
6.1 TFT 480
6Installation dimensions
6.1 TFT 480
horizontal
Dimensions Cutout
vertical
Dimensions Cutout
welding stud
M3x10
space for
cables
welding stud
M3x10
space for
cables

13
150
140±0,1
130
60,5±0,1
59,5±0,1
55
86,9
114,9
115
+0,05
0
87
+0,05
0
R3
11,5
71
69
55
32
2(3)
65,564,5
161,5
150
140±0,1
130
60,5±0,159,5±0,1
55
86,9
114,9
115
+0,05
0
87
+0,05
0
11,5 71 69 55
65,564,5
R3
161,5
32
2(3)
6.2 TFT 640
Installation dimensions
6.2 TFT 640
horizontal
Dimensions Cutout
vertical
Dimensions Cutout
welding stud
M3x10
space for
cablesl
welding stud
M3x10
space for
cables

14
145
175
65.5±0.1 5
69.5 ±0.1
154
+0.05
0
95
+0.05
0
R3
153.9
165±0.1
5
34
2(3)
94.9
70.5
74.5
145
65.5 ±0.1 5
69.5 ±0.1
153.9
5
94.9
70.574.5
175
165 ±0.1
154
+0.05
0
95
+0.05
0
R3
34
2(3)
Installation dimensions
6.3 TFT 800
6.3 TFT 800
horizontal
Dimensions Cutout
vertical
Dimensions Cutout
welding stud
M3x10
welding stud
M3x10

15
81-71
EN
81-70
EN
81-70
EN
81-70
EN
Characteristics |Versions
8 Versions
In addition to the standard version other versions can
be supplied as well:
• water-proof design IP X3
• vandal-resistant; lift design
according to lift category 1 and 2 as per
EN 81-71
7Characteristics
TFT 480
Supply voltage 12 V … 27 V DC, smoothed
Current consumption 120 mA at 24 V
Resolution 480 x 272 pixel
Temperature range 0 °C … +60 °C
Display size 96 x 54 mm, 4.3“
LED lifespan 60 000 h
Control Dual/Gray/
7-segment via terminals
Control 1 out of n via terminals or Encoder
Compliance optional EN 81-70
TFT 640
Supply voltage 12 V … 27 V DC, smoothed
Current consumption 200 mA at 24 V
Resolution 640 x 480 pixel
Temperature range 0 °C … +60 °C
LED lifespan 60 000 h
Display size 116 x 87 mm, 5.6“
Control Dual/Gray/
7-segment via terminals
Control 1 out of n via terminals or Encoder
Compliance EN 81-70
TFT 800
Supply voltage 12 V … 27 V DC, smoothed
Current consumption 300 mA at 24 V
Resolution 800 x 480 pixel
Temperature range 0 °C … +60 °C
LED lifespan 60 000 h
Display size 152 x 91 mm, 7“
Control Dual/Gray/
7-segment via terminals
Control 1 out of n via terminals or Encoder
Compliance EN 81-70

16
