Schaltbau C137 Series User manual

33
Contactors
C137, C163, C164, C165 series
Single pole contactors
for battery voltages
Installation and maintenance
instructions
Manual B60-M.en

22019-05-24 / V1.0
Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
Document Revision History
Date Rev. Level Description Pages
2019-05-24 1.0 First release all
Content
1. Important basic information......................................................................................... 4
1.1 Legal notes .............................................................................................................................. 4
1.2 Conventions for this manual............................................................................................. 4
2. General and security information ................................................................................ 4
2.1 Observing the instructions................................................................................................ 4
2.2 User obligations..................................................................................................................... 5
2.3 Intended use........................................................................................................................... 5
2.4 Ambient conditions.............................................................................................................. 5
3. Dangers and security measures.................................................................................... 6
3.1 Electrical dangers.................................................................................................................. 6
3.2 Other dangers ........................................................................................................................ 6
3.3 Measures for avoiding damages and malfunctions ................................................. 7
4. Product information........................................................................................................ 8
4.1 Contactors of the C137, C163, C164, C165 series ...................................................... 8
4.2 Special features...................................................................................................................... 8
4.3 Applications ............................................................................................................................ 8
4.4 Technical information and material specication..................................................... 8
4.5 Survey of the C137, C163, C164, C165 series (stock items).................................... 9
SPST-NO contactor C137 C ................................................................................................ 9
Changeover (SPDT) contactor C137 H ........................................................................10
SPST-NO contactor C163 C ..............................................................................................11
Changeover (SPDT) contactor C163 H ........................................................................12
SPST-NO contactor C164 C ..............................................................................................13
Changeover (SPDT) contactor C164 H ........................................................................14
SPST-NO contactor C165 C ..............................................................................................15
Changeover (SPDT) contactor C165 H .......................................................................16
5. Storage.............................................................................................................................17
6. Unpacking.......................................................................................................................17
6.1 Unpack the device ..............................................................................................................17
6.2 Check parts for transport damage................................................................................17

3
2019-05-24 / V1.0 Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
7. Installation ......................................................................................................................18
7.1 Mechanical installation.....................................................................................................18
Dimensions and further technical specications....................................................18
Preliminaries .........................................................................................................................18
Correct mounting positions............................................................................................18
Required minimum clearance .......................................................................................19
Ventilation requirements .................................................................................................19
Safety.......................................................................................................................................19
Required tools and auxiliaries ........................................................................................19
Install the contactor ...........................................................................................................19
DIN rail mounting................................................................................................................20
7.2 Electrical installation..........................................................................................................21
Electrical data and further technical specications................................................21
Preliminaries .........................................................................................................................21
Safety.......................................................................................................................................22
Required tools and auxiliaries ........................................................................................22
Connect the auxiliary contact ........................................................................................22
Connect the coil terminals...............................................................................................23
Connect the main contacts .............................................................................................24
Connect the normally closed contacts
(changeover (SPDT) contactors only) ..........................................................................25
Tie bars for contactors in series connection..............................................................26
7.3 Checks .....................................................................................................................................27
8. Maintenance...................................................................................................................28
8.1 Safety.......................................................................................................................................28
8.2 Preventive maintenance...................................................................................................28
Intervals for regular checks..............................................................................................28
Regular check activities ....................................................................................................29
Check the main contacts..................................................................................................30
8.3 Corrective maintenance ...................................................................................................33
Replace the auxiliary contact..........................................................................................33
Checks .....................................................................................................................................33
9. Spare parts......................................................................................................................34
10. Technical data.................................................................................................................34
11. Disposal ...........................................................................................................................34

42019-05-24 / V1.0
Important basic information
Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
1. Important basic information
1.1 Legal notes
Without prior written consent of Schaltbau GmbH, this
manual is not allowed to be electronically or mechani-
cally reproduced – as a whole or in parts – be distrib-
uted, changed, transmitted, translated into another
language or used in any other way.
Schaltbau GmbH cannot be held liable for damage
caused by not observing (or only partly observing) the
manual.
1.2 Conventions for this manual
This manual describes the installation and maintenance
of the contactors.
Cross references are presented in bold italics.
To highlight particularly important safety instructions
and other information, the following symbols are used
in this instructions:
DANGER
Indicates a hazardous situation with a high level
of risk which, if not avoided, will result in death or
serious injury.
WARNING
Indicates a hazardous situation with a medium level
of risk which, if not avoided, could result in death or
serious injury.
CAUTION
Indicates a hazardous situation with a low level of
risk which, if not avoided, may result in minor or
moderate injury.
NOTICE
Indicates a hazardous situation which, if not avoided,
may result in property damage, such as service inter-
ruption or damage to equipment or other materials.
Refers to technical features and methods
aimed at facilitating work or to particu-
larly important information.
This manual refers to single pole NO contactors and sin-
gle pole change over contactors of the types:
C137 C/H, C163 C/H, C164 C/H, C165 C/H
This manual describes only stock items of the above
mentioned contactor types. If you need a special vari-
ant feel free to contact us.
2. General and security information
The contactors dealt with in this document are intend-
ed for use with high-voltage systems for special instal-
lations. They are designed and tested in compliance
with the generally recognised state of the art. However,
improper use, operation, handling, maintenance of or
tampering with electric equipment can cause serious
or fatal injury to the user or others, and the appliance or
other property can be damaged.
The operation, maintenance and installation instruc-
tions for the contactors must therefore be strictly fol-
lowed.
Any uncertainties must be claried and all queries must
include details of the type of device and the serial num-
ber.
Only authorized and trained personnel are allowed to
plan and carry out all mechanical and electrical installa-
tions, transport, commissioning, as well as maintenance
and repair work. This applies to the observation of the
general installation and safety regulations for high-volt-
age systems as well as the proper use of tools approved
for this purpose. Electric equipment requires protection
from moisture and dust during installation and storage.
2.1 Observing the instructions
X All sta must read and understand the instructions
in this manual and adhere to them when working
with the device.
X Always carefully observe all safety warnings!

5
2019-05-24 / V1.0 Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
General and security information
2.2 User obligations
X Observe all applicable national provisions, all safe-
ty, accident prevention and environmental regula-
tions as well as the recognized technical rules for
safe and proper working.
X Carry out regular inspections of all protection and
safety devices to see if they work properly.
X Work on electric equipment may only be per-
formed by an expert or trained personnel working
under the direction and supervision of an expert
according to the applicable rules of electrical en-
gineering.
X An expert is a person who can judge and recog-
nise the possible dangers of the jobs commended
to him based on his training, knowledge and ex-
perience and by knowledge of the appropriate
regulations.
X Work on the contactors must only be carried out
by sta who meets the requirements set out in this
manual.
X Sta must be informed clearly about who is re-
sponsible for the maintenance of the contactors.
X After each installation work and/or after any other
modications, alterations or maintenance works,
always perform complete checks according to
these standards:
-IEC 60077-2
-IEC 60947-4-1
2.3 Intended use
X The contactors have been designed and tested ac-
cording to national and international standards.
Due to their unique features they can also be used
in a variety of applications.
X The contactors must only be used under operating
conditions according to the technical specication
and the instructions in this manual.
X None of the operating conditions dened in the
corresponding data sheets and in our catalogue
B60 in section “Specications“, such as voltages,
currents, ambient conditions, etc. may be changed.
The catalogue B60 is available under:
https://www.schaltbau.com/en/media-library/
X The contactors may only be used when all protec-
tive devices are present, have been installed prop-
erly and are fully operational.
X Contactors may not be used without further pro-
tective measures in potentially explosive atmos-
pheres and/or in aggressive media.
X Do not use the contactor without properly mount-
ed arc chute cover.
X The contactor has unprotected live parts
X The required clearance of live parts to earth and
other parts of the contactor is to be observed as
well as the safety regulations of the applicable
standards.
X Switching at maximum breaking capacity might
require larger clearance! Do not hesitate to ask our
advice for dimensioning.
X Improper handling of the contactors, e.g. when
hitting the oor with some impact, can result in
breakage, cracks and deformation. Always handle
the contactors with care.
X Use the contactor only according to its intended
use. Replace or repair damaged parts exclusively
with original parts. Any other usage of or tamper-
ing with the contactors is considered contrary to
its intended use. No liability is assumed for damag-
es and accidents caused due to non-compliance
with the instructions in this manual or improper
use of the contactors.
2.4 Ambient conditions
NOTICE
The contactors are constructed for specic ambient
conditions.
X Operate the contactors only according to the
ambient conditions, like temperature ranges,
pollution degree, etc., as dened in the corre-
sponding data sheets and in our catalogue B60.
The catalogue B60 is available under:
https://www.schaltbau.com/en/media-library/

62019-05-24 / V1.0
Dangers and security measures
Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
3. Dangers and security measures
3.1 Electrical dangers
DANGER
The contactors are used to switch voltage. The touching of electrically conducting parts may result
in serious injuries or even death!
Energized parts are all metal parts belonging directly to one of the circuits or wires leading there. All
other visible metal parts and wires may also be energized in the case of a failure.
Before beginning any work on the contactors, always observe the following safety regulations:
X Disconnect on all sides
X Ensure that it is not possible to reconnect unintentionally
X Clearly mark your work area
X Make sure that there is no voltage present
X Earth and short circuit the installation; this also includes the discharging of any capacitors in
the main circuit
X Besides the main electric circuit, also disconnect additional and auxiliary circuits
X Cover or insulate adjacent energized parts
X Only an electrically skilled person may determine if there is no voltage present
X When the work has been concluded, proceed the other way round.
3.2 Other dangers
WARNING
Exclusively use the contactors for purposes as indicated in the specications and data sheets.
A wrong application can cause accidents and severe damages to persons!
X The manufacturer doesn‘t take the responsibility for accidents which were caused by improper
use of the product.
CAUTION
During continuous operation the contactors may become hot. Risk of burns!
X Before beginning any checks or maintenance work on the contactors make sure that the heat-
ed components have cooled down.
CAUTION
The contactors contain sharp-edged parts. Risk of injury!
X Use appropriate tools for installation and maintenance works on the contactors.
X Wear protective gloves when working with sharp-edged components.

7
2019-05-24 / V1.0 Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
Dangers and security measures
3.3 Measures for avoiding damages and malfunctions
NOTICE
Aggressive uids may damage the contactors.
X Make sure that the contactors are not exposed to aggressive uids.
NOTICE
Improper handling of the contactors, e.g. when hitting the oor with some impact, can result in breakage, cracks
and deformation.
X Make sure that the contactors are always used properly.
X Do not throw the contactors to the oor.
X Regularly sight-check the contactors for potential damages.
X Immediately replace damaged components.
NOTICE
Depending on the product type, contactors can contain strong (permanent) magnets. These magnets can attract
ferromagnetic particles and may damage the contactors.
X Make sure that the contactors are installed at a location, where no ferromagnetic particles can be attracted.
NOTICE
Depending on the product type, contactors can contain strong (permanent) magnets. These magnets can de-
stroy data on credit cards or similar cards.
X Keep credit cards or similar cards away from the contactors..
NOTICE
During the switching o, strong electromagnetic elds are generated in the surroundings of the contactors.
These may inuence other components close to the contactors.
X Make sure that the contactors are installed at a location, where no other components can be aected.
NOTICE
In the case of damage, wear and tear and/or soiling of the contactor components - in the form of a partial break,
sharp edges and discoloured surfaces - the functional safety of the contactors is no longer guaranteed.
X Carry out regular visual checks to detect wear and tear and dirt.
X Immediately replace damaged parts.
X Immediately remove dirt without leaving any residues.
X Immediately replace parts with stubborn dirt.
NOTICE
Detent-edged rings and detent-edged washers have a limited life time. After 3 times opening of screws secured
with detent-edged rings or detent-edged washers, the rings or washers must be replaced by new ones.
X Record the frequency of screw opening in the work log.
X After 3 times opening of screws, replace detent-edged rings or detent-edged washers by new ones..

82019-05-24 / V1.0
Product information
Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
4. Product information
4.1 Contactors of the C137, C163, C164,
C165 series
With its proven line of C137 through C165 Series con-
tactors Schaltbau oers a scalable solution for handling
direct current loads in the range of 40 A to 220 A for the
most common battery voltages up to 110 V.
When utilizing a contactor its coil is powered by a bat-
tery and a magnetic eld is generated around its arma-
ture by the direct current voltage coming from the bat-
tery. That is why Schaltbau battery contactors feature
extra wide coil tolerance.
The contactors have double-break contacts, are com-
pact in size and known for their reliability.
Version »C« are single-pole NO contactors with mag-
netic blowout, whereas version »H« are single-pole
changeover contactors which feature an additional,
electrically seperated contact element. This extra nor-
mally closed contact is, however, without blowout
magnets and not designed to make and break current.
Bistable versions: C163 Series contactors are also avail-
able with magnetic latching. The change towards one
of the two bistable positions of the main contact is op-
erated by a pulse of 100 msec. duration. The coil con-
sumes no power except for the short pulse necessary to
close and reopen the main contact, see also catalogue
B164.
4.2 Special features
X Compact design
X Four dierent sizes
X Double breaking main contacts
X Extra wide coil tolerance for industrial and rail-
way applications in accordance with VDE and UIC
standards
4.3 Applications
X Main contactor for industrial trucks
X Starting lift/lower control as well as speed and di-
rectional controls of industrial trucks
X Heater and air conditioning control of electric lo-
comotives and multiple units
X Contactor for battery powered electric functions
in passenger coaches
X Deep discharge protection for batteries of uninter-
ruptible power supplies (UPS)
4.4 Technical information and material
specication
For technical information and material specications,
refer to the corresponding data sheets and to our cata-
logue B60. The catalogue is available under:
https://www.schaltbau.com/en/media-library/

9
2019-05-24 / V1.0 Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
Product information
4.5 Survey of the C137, C163, C164, C165 series (stock items)
SPST-NO contactor C137 C
A
C
A
B
D
D
B
C
A
E
A
C
A
B
D
D
B
C
A
E
F
G
H
Fig. 1: SPST-NO Contactor C137 C, standard version
A Mounting holes for screws M3, Tightening torque 2 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M6, Tightening torque: max. 3 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
Fig. 2: SPST-NO Contactor C137 C, tted with auxiliary
contact (F) and varistor (G) or diodes (H)
A Mounting holes for screws M3, Tightening torque: 2 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M6, Tightening torque: max. 3 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
F Auxiliary contact (1x microswitch, SPDT),
Terminals: Flat tabs 2.8 x 0.5 mm
G Coil suppression with varistor
H Coil suppression with diodes

10 2019-05-24 / V1.0
Product information
Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
Changeover (SPDT) contactor C137 H
A
C
A
B
D
D
B
C
A
E
F
G
A
C
A
B
D
D
B
C
A
E
I
H
I
Fig. 3: Changeover (SPDT) contactor C137 H,
standard version
A Mounting holes for screws M3, Tightening torque: 2 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M6, Tightening torque: max. 3 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
I Normally closed contacts (break), without magnetic blow-
out, designed to carry current only but not to make and
break current, Terminals: M6, Tightening torque: max. 3 Nm
Fig. 4: Changeover (SPDT) contactor C137 H, tted with
auxiliary contact (F) an varistor (G) or diodes (H)
A Mounting holes for screws M3, Tightening torque: 2 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M6, Tightening torque: max. 3 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
F Auxiliary contact (1x microswitch, SPDT),
Terminals: Flat tabs 2.8 x 0.5 mm
G Coil suppression with varistor
H Coil suppression with diodes
I Normally closed contacts (break), without magnetic blow-
out, designed to carry current only but not to make and
break current, Terminals: M6, Tightening torque: max. 3 Nm

11
2019-05-24 / V1.0 Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
Product information
SPST-NO contactor C163 C
C
A
B
D
D
A
E
A
B
C
C
A
B
D
D
A
E
A
B
C
F
G
H
Fig. 5: SPST-NO contactor C163 C, standard version
A Mounting holes for screws M5, Tightening torque: 6 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M8, Tightening torque: max. 6 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
Fig. 6: SPST-NO Contactor C163 C, tted with auxiliary
contact (F) and varistor (G) or diodes (H)
A Mounting holes for screws M5, Tightening torque: 6 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M8, Tightening torque: max. 6 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
F Auxiliary contact (1x microswitch, S840),
Terminals: Flat tabs 6.3 x 0.8 mm
G Coil suppression with varistor
H Coil suppression with diodes

12 2019-05-24 / V1.0
Product information
Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
Changeover (SPDT) contactor C163 H
C
A
B
D
D
A
E
A
B
C
D
A
B
C
C
A
B
D
A
EG
I
F
I
H
Fig. 7: Changeover (SPDT) contactor C163 H,
standard version
A Mounting holes for screws M5, Tightening torque: 6 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M8, Tightening torque: max. 6 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
I Normally closed contacts (break), without magnetic blow-
out, designed to carry current only but not to make and
break current, Terminals: M8, Tightening torque: max. 6 Nm
Fig. 8: Changeover (SPDT) contactor C163 H, tted with
auxiliary contact (F) and varistor (G) or diodes (H)
A Mounting holes for screws M5, Tightening torque: 6 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M8, Tightening torque: max. 6 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
F Auxiliary contact (1x microswitch, S840),
Terminals: Flat tabs 6.3 x 0.8 mm
G Coil suppression with varistor
H Coil suppression with diodes
I Normally closed contacts (break), without magnetic blow-
out, designed to carry current only but not to make and
break current, Terminals: M8, Tightening torque: max. 6 Nm

13
2019-05-24 / V1.0 Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
Product information
SPST-NO contactor C164 C
C
A
B
D
D
A
E
A
B
C
C
A
B
D
D
A
E
A
B
C
F
G
H
Fig. 9: SPST-NO contactor C164 C, standard version
A Mounting holes for screws M5, Tightening torque: 6 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M8, Tightening torque: max. 6 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
Fig. 10: SPST-NO Contactor C164 C, tted with auxiliary
contact (F) and varistor (G) or diodes (H)
A Mounting holes for screws M5, Tightening torque: 6 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M8, Tightening torque: max. 6 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
F Auxiliary contact (1x microswitch, S840),
Terminals: Flat tabs 6.3 x 0.8 mm
G Coil suppression with varistor
H Coil suppression with diodes

14 2019-05-24 / V1.0
Product information
Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
Changeover (SPDT) contactor C164 H
C
A
B
D
D
A
E
A
B
C
F
G
I
C
A
B
D
D
A
E
A
B
C
H
I
Fig. 11: Changeover (SPDT) contactor C164 H,
standard version
A Mounting holes for screws M5, Tightening torque: 6 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M8, Tightening torque: max. 6 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
I Normally closed contacts (break), without magnetic blow-
out, designed to carry current only but not to make and
break current, Terminals: M8, Tightening torque: max. 6 Nm
Fig. 12: Changeover (SPDT) contactor C164 H, tted with
auxiliary contact (F) and varistor (G) or diodes (H)
A Mounting holes for screws M5, Tightening torque: 6 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M8, Tightening torque: max. 6 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
F Auxiliary contact (1x microswitch, S840),
Terminals: Flat tabs 6.3 x 0.8 mm
G Coil suppression with varistor
H Coil suppression with diodes
I Normally closed contacts (break), without magnetic blow-
out, designed to carry current only but not to make and
break current, Terminals: M8, Tightening torque: max. 6 Nm

15
2019-05-24 / V1.0 Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
Product information
SPST-NO contactor C165 C
C
A
B
D
D
A
E
B
C
C
A
B
D
D
A
E
A
B
C
F
G
H
A
Fig. 13: SPST-NO contactor C165 C, standard version
A Mounting holes for screws M5, Tightening torque: 6 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M10, Tightening torque: max. 10 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
Fig. 14: SPST-NO Contactor C165 C, tted with auxiliary
contact (F) and varistor (G) or diodes (H)
A Mounting holes for screws M5, Tightening torque: 6 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M10, Tightening torque: max. 10 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
F Auxiliary contact (1x microswitch, S840),
Terminals: Flat tabs 6.3 x 0.8 mm
G Coil suppression with varistor
H Coil suppression with diodes

16 2019-05-24 / V1.0
Product information
Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
Changeover (SPDT) contactor C165 H
F
G
C
A
B
D
D
A
E
A
B
C
I
C
A
B
D
D
A
E
A
B
C
I
H
Fig. 15: Changeover (SPDT) contactor C165 H,
standard version
A Mounting holes for screws M5, Tightening torque: 6 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M10, Tightening torque: max. 10 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
I Normally closed contacts (break), without magnetic blow-
out, designed to carry current only but not to make and
break current,
Terminals: M10, Tightening torque: max. 10 Nm
Fig. 16: Changeover (SPDT) contactor C165 H, tted with
auxiliary contact (F) and varistor (G) or diodes (H)
A Mounting holes for screws M5, Tightening torque: 6 Nm
B Plasma exits
C Permanent magnets
D Main contacts, normally open contact (make), designed
to make and break current like an open style power relay,
Terminals: M10, Tightening torque: max. 10 Nm
E Coil terminals A1 and A2, Flat tabs 6.3 x 0.8 mm
F Auxiliary contact (1x microswitch, S840),
Terminals: Flat tabs 6.3 x 0.8 mm
G Coil suppression with varistor
H Coil suppression with diodes
I Normally closed contacts (break), without magnetic blow-
out, designed to carry current only but not to make and
break current,
Terminals: M10, Tightening torque: max. 10 Nm

17
2019-05-24 / V1.0 Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
Storage
5. Storage
NOTICE
Moisture and dust can damage the contactor. If
the device is to be stored for a prolonged period
of time,
► store it in its original packaging,
► store it in a dry and dust-free location.
Return shipments
Schaltbau recommends to keep the original packing
box for any return shipments. If no original packing box
is available care must be taken to pack the contactor in
a way that prevents damage during shipment.
6. Unpacking
6.1 Unpack the device
X Before opening the packaging, perform a visual
inspection for any signs that could indicate dam-
age having occurred during transport (impacts,
bumps, falling etc.).
X If any signs indicate that the contactor has been
subject to excessive shock inuence do not install
the contactor.
6.2 Check parts for transport damage
NOTICE
If parts are damaged, the functional reliability of the
contactor is no longer given.
X Before installing, check all parts for any possible
transport damage.
X Do not install a damaged contactor.

18 2019-05-24 / V1.0
Installation
Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
7. Installation
7.1 Mechanical installation
Dimensions and further technical
specications
The dimensions and further technical specications are
given in the respective data sheets or in our catalogue.
Refer to our catalogue B60.
The catalogue is available under:
https://www.schaltbau.com/en/media-library/
Preliminaries
X For the fastening of the contactor an appropriate
mounting plate with 4 mounting holes (c) accord-
ing to Fig. 17 has to be provided.
12
14
11
A2
A1
2
1
a
b
c
Fig. 17: Dimensions and arrangement of the mounting holes
X Depending on the contactor type, the table be-
low shows measurements (a/b) for the mounting
holes, the screw size (c) and the reqired tightening
torque:
Series C137 C163 C164 C165
Dimension a [mm] 30 ± 0.2 35 ± 0.2 40 ± 0.2 60 ± 0.2
Dimension b [mm] 62 ± 0.2 85 ± 0.2 105 ± 0.2120 ± 0.2
Screw size c M3 M5
Torque 3 Nm 6 Nm
X The mounting holes can either be
-threaded holes (for threaded screws)
-or through holes (for threaded screws and nuts).
X The length of the xing screws has to be deter-
mined according to the constructional conditions.
X In order to secure the mounting screws against
self-loosening, appropriate screw locking ele-
ments have to be provided. Schaltbau strongly
recommends Schnorr-Washers (or similar) to se-
cure the screws.
Correct mounting positions
The contactors are designed for horizontal or vertical
mounting positions
-horizontal: main contacts (1) must point upwards
-vertical: plasma exits (2) must point upwards
Examples for intended mounting positions are shown
in Fig. 18/(A)
Not permissible are suspended or inverted mounting
position as shown in Fig. 18/(B).
AB
1
2
1
2
Fig. 18: Examples for intended mounting positions (A) and
not permissible mounting positions (B)

19
2019-05-24 / V1.0 Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
Installation
Required minimum clearance
NOTICE
Switching electrical currents at high voltages will
produce arcing and plasma may exit out of the arc
chambers. It is essential to observe the minimum
clearance to earth and to the connecting bus bars to
avoid the risk of a ash-over.
Depending on the contactor type, the table below
shows the required minimum clearance measurements:
Series Minimum clearance
C137 15 mm
C163 15 mm
C164 20 mm
C165 50 mm
Ventilation requirements
X Ensure sucient ventilation, especially in the case
of heavy arc switching. Allow the exchange of sur-
rounding atmosphere to avoid the risk of ash-
overs and excessive corrosion.
Safety
X The installation has to be carried out by qualied
trained personnel.
NOTICE
During installation, ensure that dirt caused by sur-
rounding construction activities does not get into
the contactor.
NOTICE
Detent-edged rings and detent-edged washers have
a limited life time. After 3 times opening of screws
secured with detent-edged rings or detent-edged
washers, the rings or washers must be replaced by
new ones.
X Record the frequency of screw opening in the
work log.
X After 3 times opening of screws, replace detent-
edged rings or detent-edged washers by new
ones.
Required tools and auxiliaries
-Socket wrench set
-Hexagon socket wrench set
-Torque wrench
Install the contactor
X Make sure, that the mounting surfaces of mount-
ing plate (5) and contactor are free from dirt and
other contamination (e. g. metal cuttings).
X Place the contactor (3) on the mounting plate (5)
with the prepared mounting holes.
X Screw the contactor with 4 screws (4) on the
mounting plate (5).
-When using threaded holes: Screw the screws
with appropriate screw locking elements direct-
ly in the threaded holes.
-When using through holes: Fasten the screws
with appropriate screw locking elements and
nuts.
X Depending on the contactor type, tighten the
screws with the torque as stated in the table.
Series C137 C163 C164 C165
Screw size M3 M5
Torque 3 Nm 6 Nm
5
4
3
Fig. 19: Install the contactor to the mounting plate

20 2019-05-24 / V1.0
Installation
Contactors C137/C163/C164/C165 – Installation and Maintenance Instructions
DIN rail mounting
The contactor can also be installed by means of DIN rail
mounting. DIN rail mounting sets can be ordered from
Schaltbau GmbH.
The installation is possible either at the rear side or at
the bottom side of the contactor.
Installation on the rear side
X Fix the DIN rail adapter (4) with 4 cylinder screws
M3 x 5 (6) and 4 washers (5) on the mounting plate
(3). Torque for the cylinder screws: 0.6 Nm
X Place the mounting plate (3) at the rear side of the
contactor an x it from the front side with 4 cylin-
der screws (1) and 4 washers (2).
X Tighten the cylinder screws (1) with the deter-
mined torque according to the table:
Series Cylinder screws (1) Torque
C137 M3 x 8 0.6 Nm
C163
M5 x 10 1.4 Nm
C164
C165
X Attach the installed contactor with the DIN rail
adapter (4) to the DIN rail (7).
1
2
3
45
6
7
Fig. 20: DIN rail mounting: Installation on the rear side (the gure shows C163, the procedure for C137, C164 and C165 is the same)
