Schecter Hellraiser Special C-1 User manual

Neck
Bridge
1 2 3
3-way switch settings
.1
9-Volt
battery
9-Volt
battery
Red
Bridge
volume
25k
Neck
volume
25k
Master
tone
25k
Red
3-way
switch
Hellraiser Special C-1
Wiring Diagram
Tone
Bridge Vol
Neck Vol
Tone
For technical or warranty questions please email: [email protected]
Diagram copyright Schecter Guitar Research 2011
= ground.
This symbol
is found where any ground connection
should be soldered.
Output Jack
Tip (hot output)
Sleeve (ground)
Ring (battery ground)
21
3
3-Way
Switch
Bridge pickup
EMG 81
Neck pickup
EMG 85
EMG
EMG
Bare
White
White
Bare
1
2
2
3

c
d
a
b
radius
Scale Length: 648mm/25.5”
A: Width at Nut- 42mm
B: Width at Last Fret- 56mm
C: Thickness at 1st Fret- 20mm
D: Thickness at 12th Fret- 22mm
Radius: 355mm/14”
Hellraiser Special C-1
Neck Specs:
Bridge Pickup
Name:
Model No:
Construction:
Magnet:
Description:
EMG 81
81
Humbucker
Ceramic/Steel
Output: Impedance 10K
Utilizing powerful ceramic magnets
and close aperture coils, the tone
was designed with detailed
intensity, incredible amounts of high
end cut and fluid sustain.
Traditionally used in the bridge
position, this pickup will make your
leads slice right through even the
densest mix.
Neck Pickup
Name:
Model No:
Construction:
Magnet:
Description:
EMG 85
85
Humbucker
Alnico V
Output: Impedance 10K
Featuring close aperture coils
loaded with Alnico V magnets,
the 85 is a powerful pickup with
exceptional organic tone and
versatility. Most often used in the
rhythm position, the alnico
magnets of this model provide a
muscular growl and smooth lead
tones to enable you to play the
muddiest of blues to the most
extreme metal.
Strings
6-String Guitar*
Tuning: E-A-D-G-B-E
Gauge: .046-.036-.026-.017-.013 .010
(EB Regular Slinky #2221)
*Changing to different string gauges and/or
alternate tunings may require minor neck/bridge
adjustments for optimal performance. For Schecter
setup tips refer to Schecter Setup Guide.

This model is equipped with a Graph Tech Black TUSQ XL
nut. The Black TUSQ XL delivers a rich and balanced tone
with big open lows and a noticeable increase in overall
sustain followed by a very balanced output from your strings.
Laboratory-proven to enhance harmonic content up to 200%
and sustain up to 16% and is engineered for maximum
vibration transfer. Designed to transfer the right frequencies
more efficiently from the string to the guitar body. Compared
to standard materials such as bone, micarta or corian, you'll
hear more harmonics with every note you play when you use
TUSQ XL on your guitar. As compared to TUSQ, you will
hear added midrange depth, and is impregnated with Teflon
to improve the tuning performance of the guitar.
