Schischek ExPro-CTF Series User manual

Schischek GmbH Germany, Mühlsteig 45, Gewerbegebiet Süd 5, 90579 Langenzenn, Tel. +49 (0)9101 9081-0, Fax +49 (0)9101 9081-77, E-Mail [email protected]
www.schischek.com
EXPLOSIONPROOF
ExCos-D... transducer ExPro-C... sensor Example: room sensor Example: duct sensor ExCos-D...-CT
Shown:
ExPro-...-CTF…
Description
Application
Highlights transducer
Transducer
Connectable sensors (compulsory for ExCos-D... transducer) – see separate data sheet
Highlights sensor
Electrical, explosionproof transducers only connectable to ExPro-C...
temperature and humidity sensors.
24 VAC/DC supply, 0…10 V / (0)4…20 mA output
PTB-certified in acc. with ATEX directive 94/9/EC for zone 1, 2, 21, 22.
For all type of gas, mixtures, vapours and dust for use in zone 1, 2, 21 and 22
No addional Ex-i module required
No intrisically safe wiring /installation between panel and sensor required
No intrisically safe wiring /installation and no space in the panel required
Integrated Ex-e junction box
Power supply 24 VAC/DC
Display with backlight, can be switched off
Scalable analogue output, selectable 0…10 V / (0)4…20 mA
Compact design and small dimension (L × W × H = 180 × 107 × 66 mm)
Robust aluminium housing in protection class IP66
Down to – 20°C ambient temperature applicable
Password locking
Optional IS-output (0)4…20 mA for external indicator in Ex-areas
CT versions have an excellent resistance to chemicals and seawater
For all type of gas, mixtures, vapours and dust for use in zone 1, 2, 21 and 22
Plug-and-socket connection to ExCos-D... transducer, removable
The ExPro-C... probe appropriates the function (temperature, humidity or combination)
Mounting of ExPro-C... probe (front/back side) appropriates use for duct or room application
ExCos-D Transducer for ExPro-C... sensors (probes)
ExPro-C... Temperature/humidity sensors (°C, %rH)
1 / 4
The ExCos-D... transducer generation from together with direct coupled
ExPro-C... sensors are a revolution for measuring temperature and/or
humidity in HVAC systems, in chemical, pharmaceutical, industrial and
Offshore-/Onshore plants, for use in hazardous areas zone 1, 2 (gas)
and zone 21, 22 (dust).
Highest protection class (ATEX) and IP66 protection, small dimension,
universal functions and technical data guarantee safe operation even
under difficult environmental conditions.
The measuring ranges are scalable within the maxium ranges. The
analogue output signal is either 0...10 VDC or (0)4...20 mAand can be
selected on site. The integrated display is for actual value indication
which can be switched off.
All sensors are programmable on site without any additional tools.
ExCos-D-A transducer are additionally equipped with a (0)4…20 mAIS
(IS = intrinsically safe) output, e.g. for an external indicator.
Subject to change!
Type of transducer:
ExCos - D
ExCos - D - A
ExCos - D... - CT
Type of sensor (probe):
ExPro - CT...
ExPro - CF...
ExPro - CTF...
Type Supply Installation area Connectable sensors Function of sensors Sensor connection Wiring diagram
ExCos - D 24 VAC/DC zone 1, 2, 21, 22 ExPro-CT..., ExPro-CF..., ExPro-CTF... °C, % rH, combination °C/% rH via plug-and-socket connection SB 2.0
ExCos - D - A as above, but with additional intrisically safe analogue output to connect an external digital indicator (0)4...20 mA (Ex-i) SB 3.0
ExCos - D...- CT Type as above but with aluminium housing and Amercoat painting (sensor connection cable glands nickel-plated, screws in stainless steel)
Type Function Measuring range Length of sensor connectable to Installation sensor Installation transducer
ExPro - CT… temperature –40...+125 °C* 50/100/150/200 mm ExCos-D..., RedCos-D... zone 1, 2, 21, 22 zone 1, 2, 21, 22 (ExCos…)
ExPro - CF… humidity 0...100 % rH 50/100/150/200 mm ExCos-D..., RedCos-D... zone 1, 2, 21, 22 zone 1, 2, 21, 22 (ExCos…)
ExPro - CTF… combination temp./humidity –40...+125 °C*/0...100 %rH 50/100/150/200 mm ExCos-D..., RedCos-D... zone 1, 2, 21, 22 zone 1, 2, 21, 22 (ExCos…)
* at 50 mm length –40…+80 °C sensor length

Schischek GmbH Germany, Mühlsteig 45, Gewerbegebiet Süd 5, 90579 Langenzenn, Tel. +49 (0)9101 9081-0, Fax +49 (0)9101 9081-77, E-Mail [email protected]
www.schischek.com
EXPLOSIONPROOF
2 / 4
ExCos-D...
Technical data ExCos-D...
Accessories
Explosion proof ExCos-D...
Power supply 24 VAC/DC ± 20% (19,2 ... 28,8 VAC/DC) 50...60 Hz
Current, power consumption 150 mA, ~ 4 W, internal fuse 500 mAT, without bracket, not removable
Galvanic isolation supply – analogue output 1,5 kV (Ex 60 V)
Electrical connection terminals 0,14…2,5 mm² at integrated Ex-e junction box
Cable entry M16 × 1,5 mm Ex-e approved, cable diameter ~ Ø 5...10 mm, (...-CT in nickel-plated)
Protection class Class I (grounded)
Display 2 × 16 digits, dot-matrix with backlight, display for configuration, user guidance, parameter and actual value indication
Control elements 3 buttons for configuration
Housing protection IP66 in acc. to IEC 60529
Housing material aluminium casting, coated (...-CT= version in marine painting, seawater-resistant)
Dimensions/weight L × W × H = 180 × 107 × 66 mm / ca. 950 g
Ambient temperature/-humidity –20…+50 °C / 0…95 % rH, non condensed
Storage temperature –40…+70°C
Sensor connection Only for ExPro-C... sensors! via plug-and-socket connection at front or back side of the transducer, to appropriate the use for room or
duct mounting. Attention: only one ExPro-C... probe can be connected to one transducer!
ExPro-C... sensors please have a look on the separate data sheet for ExPro-C... sensors
Measuring range measuring ranges are scalable within the maximum measuring range
Maintenance maintenance free, nevertheless maintenance must be complied with regional standards, rules and regulations
Response time of sensor T90 ~ 1 s
Accuracy temperature ± 0,2 % of end value + accuracy of ExPro-C... sensor ± 0,3 °C at 25 °C ± 0,025 °C/°C
Accuracy humidity ± 0,2 % of end value + accuracy of ExPro-C... sensor 10…90 % rH ± 2% and < 10 % rH and > 90 % rH ± 4% + 1% hysteresis
Non linearity and hysteresis ± 0,1 % of end value
Start delay 5 s
Stability long term stability < 0,2 %/year, temperature influence < 0,02 %/K, supply voltage influence < 0,01 %
Output voltage U (V) or current I (mA) selecable via menu on site (at combi sensors not separately adjustable)
Output protection against short circuit and external voltage up to 24 V, protected against polarity reversal
Voltage output U from 0...10 VDC adjustable, invertible, burden > 1 kΩ, influence < 0,05% / 100 Ω
Current output I from 0...20 mA adjustable, invertible, burden < 500 Ω, influence < 0,1% / 100 Ω, open circuit voltage < 24 V
Output at alarm mode increasing or decreasing output signal, selectable on site, down to 0 VDC/0 mA or up to 10 VDC/20 mA
Wiring diagram (SB) SB 2.0
Delivery (changeable on site) output 4…20 mA, output with decreasing alarm situation to 0 V / 0 mA
Included in delivery ExCos-D... with 3 screws 4,2 × 13 mm self-tapping
Installation area transducer in Ex-area zone 1, 2, 21, 22
Additional information for ExCos-D-A:
Analogue output (0)4…20 mA
Ex-i Intrinsically Safe (IS)
Burden max. 400 Ω
Accuracy ± 0,5 %
Plug cable diameter Ø 6...8 mm
Delivery version ...-D-A incl. 2 × plug
PTB-testet PTB 07 ATEX 2061
acc. to ATEX directive 94/9/EC (ATEX)
Approval for gas II2(1)G Ex e ma [ia] IIC T6 for zone 1, 2
Approval for dust II2(1)D Ex tD A21 [iaD] IP66 T80°C for zone 21, 22
Identification CE No. 0158
EMC 2004/108/EC EMC directive
Electrical safety 2006/95/EC low voltage directive
Protection type IP66 in acc. to EN 60529
Potential compensation external PA-terminal, 4 mm²
EXC-RIA-16 LCD indicator (IS), installation in Ex-areas zones 1, 2, 21, 22,
connectable directly to ...Cos-... transducer
MKR Mounting bracket for round ducts up to Ø 600 mm
MFK Mounting flansh for probe positioning

Schischek GmbH Germany, Mühlsteig 45, Gewerbegebiet Süd 5, 90579 Langenzenn, Tel. +49 (0)9101 9081-0, Fax +49 (0)9101 9081-77, E-Mail [email protected]
www.schischek.com
EXPLOSIONPROOF
In acc. to the connected ExPro-C...
sensor you get output signals at
following terminal:
sensor terminal terminal
ExPro-CT... 3 - 4
ExPro-CF... 4 - 5
ExPro-CTF... 3 - 4 und 4 - 5
It's either output mA or V adjustable.
Attention !
Humidity output below 0 °C no
function
ExCos-D... SB 2.0
The ExPro-C... probe can be mounted to
the front or the back side of the transducer.
The protective cap must be removed.
Unused connectors must be covered by a
protective cap against mechanical damage
and dirt.
Values IS (optional)
Uo = 15,8 V
Io = 85 mA
Po = 336 mW
Ci = 0
Li = 0
Co(IIC) = 0,33 nF
Lo(IIC) = 2 mH
Terminals SB 3.0 Head side of ExCos-D-Asensor
Connector 1 for output of sensor 1 (°C)
Connector 2 for output of sensor 2 (%rH)
Push button
ENTER
Display for
programming and
indication
Push button
for level select
Uo = 7,9 V
Io = 48 mA
Po = 95 mW
Ci = 0
Li = 0
Co(IIC) = 1,3 nF
Lo(IIC) = 2 mH
Digital ExPro-C... sensor
to connect e.g.
an external LCD indicator
41
2
5
3
Male connector
1 2
43
Female connector
Dimensions / Drillings
PA
1 2 3 4
~
–
~
+
24 VAC/DC
PE
(0)4…20 mA
0…10 V
GND
°C /% rH
5
(0)4…20 mA
0…10 V
°C % rH
EXPLOSIONPROOF
Ø ExPro
68
157,5
117
129
166
80
107
55
66
~ 180
20
–+
3 / 4
ExCos-D...
Electrical wiring
The default/ delievery setup is 0000. In this configuration the password input is not
activated. To activate a password, go to menu point 20, change the 4 digits into your
choosen numbers (e.g. 1234) and press Enter.
Please keep your password in mind for next parameter change!
Due to a new parameter setup the password is requested.
Before starting parametrisation of ExCos-D... transducer an ExPro-C... sensor must be
connected. ExPro-C... sensors are available as ExPro-CT... for single temperature measure-
ment, as ExPro-CF... for single humidity measurement and as ExPro-CTF... for combined
measurement of temperature and humidity. All types are connectable to an ExCos transducer
but only one sensor to one transducer. In acc. with the sensor type you need to set parameter
for one or two measuring ranges.
Wiring diagram ExCos-D...
Values intrinsically safe (IS) for ExPro-C... sensors
Password input
Parameter
Wiring Ex-i output (optional) at ExCos-D-...A transducer
Important information for installation and operation
A. Installation, commissioning, maintenance
The cable has to be drawn through the cable gland. After electrical connection the
cable gland must be fixed tighten. IP66 must be fulfilled.
In acc. with operation ExCos sensors are maintenance free. Nevertheless maintenance
must comply with regional standards, rules and regulations.
The sensors must not be opened by the customer. For outdoor installation a protective
housing against rain, snow and sun should be applied. For electrical connection use
the internal approved Ex-e junction box.
Attention: Note the explosion proof rules before opening the internal junction box.
Cut off the power supply.
B. ExPro-C... sensors
ExPro-C... sensors are supplied with an instrinsically safe circuit from the ExCos-D...
transducer. Unused connectors must be covered by a protective cap.
C. Long cabling
For using long signal wires, shilded cables are recommended. The shield must be
connected to the ExCos-D transducer inside the terminal box.
D. Separate ground wires
Use for supply and signal wires a separate ground.
ExCos-D... transducer require a 24 VAC/DC power supply.The supply has to be connected at
terminal 1 (–/~) and 2 (+/~), the analogue output at terminal 3 (mA/V) and 4 (GND) for
temperature, at terminal 5 (mA/V) and 4 (GND) for humidity. The electrical wiring must be realized
via integrated Ex-e junction box in acc. to ATEX. Type of protection for the terminals is "Ex-e".
Attention! Before opening the junction box cover, the supply voltage must be shut off!
The optional analogue output at ExCos-D-A is intrinsically safe. Note the maximum connection
values of intrinsically safe parameters (see table below).
Display and Buttons
To change from operation to parametrisation mode and vice versa, push the enter button
for minimum 3 seconds.
A blinking star in the display shows that data is received and the device is working.
Change operation-/ parametrisation mode
Indication of data logging

Schischek GmbH Germany, Mühlsteig 45, Gewerbegebiet Süd 5, 90579 Langenzenn, Tel. +49 (0)9101 9081-0, Fax +49 (0)9101 9081-77, E-Mail [email protected]
www.schischek.com
EXPLOSIONPROOF
EXPLOSIONPROOF
4 / 4
ExCos-D...
D.EC-D-01.05-en
12-July-2012
To change from operation to parametrisation mode push
"enter button" for minimum 3 seconds. Back over the
menu save and exit.
Language English
Range 0...+50 °C, 0...100 % rH
Output each 0…10 VDC, 0…20 mA
Outputs Ex-i 4…20 mA
Parametrisation and commissioning of ExCos-D (-A) transducers after an ExPro-C... sensor ist connected
Change operation-/ parametrisation mode Example of parameters
Menu 1
DE, EN, FR
english
Menu 2
unit sensor 1
°C
range 1
0..50 °C range 1
0..50 °C
output V/mA
V
output range 1
0..10V
sensor error 1
10V / 20 mA
output 1
increasing
output Exi 1
4..20 mA
output Exi 1
4..20 mA
no function - menu skip
DE, EN, FR
select language: German, English, French
Menu 3 no function - menu skip
Menu 4 unit sensor 1
select physical unit
°C, °F
deutsch, english, francais
Menu 5 range 1
adjust the measuring range
adjust lower limit adjust higher limit
Menu 6 no function - menu skip
Menu 7 output V, mA
select output signal as VDC or mA
mA, V
Menu 8 output range 1
adjust the output range
adjust lower limit adjust higher limit
output range 1
0..10V
Menu 9 sensor error 1
select signal at sensor error
10V / 20 mA or 0V / 0mA
Menu 10 output 1
select if signal output is increasing or decreasing
increasing, decreasing
Menu 11 unit sensor 2*
select physical unit
Menu 12
Menu 13
Menu 14
Menu 15
Menu 16 output Ex-i 1 (option, only at ExCos-D-A)
adjust 4...20 mA or 0...20 mA IS output signal
Menu 17
Menu 18
Menu 19 display function
select display on/off, illuminated or backlight off
Menu 20 password
select password protection
Menu 21 save and exit
select save data / factory setting / discard
or back to menu
Menu IndicationFunction Select Enter Next selsctionEnter Next menuNext indication Enter
display function
on illuminated
new password
yes no
save and exit
save data
unit sensor 2
%rH
%rF, %rH
range 2
0..100 %rH range 2
0..100 %rH
range 2*
adjust the measuring range
adjust lower limit adjust higher limit
output range 2
0..10V
output range 2*
adjust the output range
adjust lower limit
output range 2
0..10V
adjust higher limit
sensor error 2
0V / 0 mA
sensor error 2*
select signal at sensor error
10V / 20 mA or 0V / 0mA
output 2
increasing
output 2*
select if signal output is increasing or decreasing
increasing, decreasing
output Exi 2
4..20 mA output Exi 2
4..20 mA
output Ex-i 2 (option, only at ExCos-D-A)*
adjust 4...20 mA or 0...20 mA IS output signal
no function - menu skip
Menu 22 Set offset 1
Add / subtract from measures value
Menu 23 Set offset 2 *
Add / subtract from measures value
set offset 1
0.00°C
sett offset.2
0.00%rH
password
0000
on-illuminated, on, off
adjust lower limit
adjust lower limit adjust higher limit
adjust higher limit
*only available if combination sensor type ExPro-CTF... is connected
OperationParametrisation, push for 3 sec.
If password (PW) protection is active: put PW in, push
Preparation of parametrisation/ operation
This manual suits for next models
6
Table of contents
Popular Measuring Instrument manuals by other brands

Measurement Computing
Measurement Computing TC-32 user guide

Precision Digital Corporation
Precision Digital Corporation PD686 manual

Diesella
Diesella DT2236E user manual

DigiTrak
DigiTrak FALCON F5 quick start guide

Bosch
Bosch GLL 2-10 Professional Original instructions

Brooks Instrument
Brooks Instrument Sho-Rate Series Installation & operation manual

ISE
ISE DT-501X instruction manual

Rice Lake
Rice Lake MSI9000 Operator's manual

IFM Electronic
IFM Electronic Efector 300 SI1007 operating instructions

Zenner
Zenner L868 ID A Installation and operating instruction

Sibelmed
Sibelmed Sibelsound 400 quick start guide

Konica Minolta
Konica Minolta CM-26dG instruction manual
